x-net Network Box Camera User manual

XNET Network Box Camera User’s Guide
1 of 47
XNET Network Box Camera
User’s Guide
Ver. 1.0 (070918)

XNET Network Box Camera User’s Guide
2 of 47
Directions
This product is designed for indoor use only. When using this camera at outdoors or in an
environment that exceeds the limited range, you must separately use a water-resistant case.
Be careful not to cause any physical damage by dropping or throwing the unit. Especially keep
the device out of reach from children.
Do not disassemble this camera. You will be excluded from After Service when disassembled.
Use only the power adapter provided with this product.
If you would like to use this camera for security, monitoring, please check the legal
regulations within the country.
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generate, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into and outlet on a circuit different from that to which
the receiver is connected
Consult the dealer or an experienced radio/TV technician for help.
Caution
Any changes or modifications in construction of this device which are not explicitly
approved by the party responsible for compliance could void the user‟s authority to
operate the equipment.
This appliance and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter. A minimum separation distance of 20 cm must be
maintained between the antenna and the person for this appliance to satisfy the RF
exposure requirements.

XNET Network Box Camera User’s Guide
3 of 47
Table of Contents
1. Introduction............................................................................................................................................. 4
1.1. Overview ..................................................................................................................................... 4
1.2. Features of XNET/XNET-Wireless ........................................................................................ 4
1.3. Applications of XNET/XNET-Wireless.................................................................................. 4
2. Product Description ................................................................................................................................ 5
2.1. Contents...................................................................................................................................... 5
2.2. Preview ........................................................................................................................................ 5
2.3. Physical Description................................................................................................................. 6
2.4. PC Requirements ...................................................................................................................... 9
2.5 Quick Installation Guide .......................................................................................................... 9
3. Connecting XNET/XNET-Wireless to the Network ............................................................................ 12
3.1. Connecting to LAN ................................................................................................................. 12
3.2. Connecting to xDSL/Cable Modem ................................................................................... 13
4. IP-Installer............................................................................................................................................. 14
4.1. Main window of IP-Installer ................................................................................................ 14
5. Configuring XNET in Administrative Mode ........................................................................................ 15
5.1. Log On ....................................................................................................................................... 15
5.2. Basic Setup .............................................................................................................................. 16
5.3. Network Configuration.......................................................................................................... 19
5.4. Wireless Configuration(XNET-Wireless Only)................................................................. 22
5.5. CCD Adjustment ..................................................................................................................... 24
5.6. User Admin & Time Setup ................................................................................................... 26
5.7. Sensor & Capture Setup ...................................................................................................... 29
5.8. Alarm Device Setup............................................................................................................... 31
5.9. Motion Region Setup ............................................................................................................. 32
5.10. PTZ Setup(Zoom is not applicable for XNET/XNET-Wireless) ................................ 34
5.11. Encryption Set up ................................................................................................................ 36
5.12. Upgrade & Reset .................................................................................................................. 38
5.13. Status Report ........................................................................................................................ 40
6. Tips for using XNET/XNET-Wireless ................................................................................................... 41
6.1. ALARM-IN and ALARM-OUT................................................................................................. 41
6.2. Trouble Shooting .................................................................................................................... 44
6.3. Web Viewer .............................................................................................................................. 45
6.4. How to Upgrade the XNET/XNET-Wireless ..................................................................... 47

XNET Network Box Camera User’s Guide
4 of 47
1. Introduction
1.1. Overview
The XNET is a state-of-the-art network camera which transmits synchronized video and audio
data in real time with D1 resolution at full frame rate. This is possible through MPEG4 CODEC
technology, which provides high quality video with highly compressed data streams. This
products can be connected, controlled and monitored from a remote location through an IP
connection over internet or intranet. Unlike other CCTVs or DVRs, the XNET is easy to install
and user will experience cost and space savings in the installation.
Based on Embedded Software Solution (Embedded Web Server, Embedded Streaming Server,
Network Protocol), the XNET ensures unprecedented performance and stability to be an ideal
network camera solution for system integration solutions.
The wired XNET series is offered with standard Ethernet interface while the wireless XNET series
is offered with embedded WiFi solution.
1.2. Features of XNET
1 channel synchronized real time Video/Audio streaming
MPEG-4 video, ADPCM audio.
Bi-directional audio communication
Real time audio communication between the product and the client PC
The viewer assisted recording and playback functions.
1 Alarm sensor input/1 relay output
Motion detection –Up to 3 motion detection zones
Arbitrary shape motion detection zone
Motion detection can initiate video recording, which is sent to the user through FTP and/or E-
mail.
Resolution
NTSC : 720x480, 352x240, 176x144.
PAL/SECAM : 720x576, 352x288, 176x144
RS-485 interface for Pan/Tilt device connection
Remote administration control
Entire operational parameter set up, Software upgrade
Embedded WiFi interface (XNET-Wireless only) –IEEE 802.11b/g
Proprietary PoE (Power over Ethernet) for convenience of installation and cost savings
1.3. Applications of XNET/XNET-Wireless
Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks,

XNET Network Box Camera User’s Guide
5 of 47
government facilities, military, etc.)
Real time Internet broadcasting
Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)
Teleconference (Bi-directional audio conference)
Remote Learning
Weather and environmental observation
2. Product Description
2.1. Contents
Open the package and check if you have the followings:
Components
Description
Remarks
XNET/XNET-Wireless
XNET/XNET-Wireless Network Camera
Power adapter
Input : 100~250V 50-60Hz
Output : +12V, 3.33A
Standard Power
AC power cable
AC 250V, 10A~16A
Antenna
XNET-Wireless only
CD-ROM
Software & User‟s Guide
Quick Reference Guide
Quick installation guide
Will be provided
2.2. Preview
XNET/XNET-Wireless
IP-Installer
XNET-NVR
MPEG-4 Network
Camera
PC software to allocate an IP
address to the XNET
PC software to view and record
the A/V streaming data
transmitted from the XNET.
There are two editions available
(NVR/XNVR).
Wired LAN Type
Wireless LAN Type

XNET Network Box Camera User’s Guide
6 of 47
2.3. Physical Description
2.3.1. Side View
Figure 2-1. Side view of IG Series (Wired LAN)
Figure 2-2. Side view of WG Series (Wireless LAN)
Lens: XNET/XNET-Wireless basically delivered without Lens assembly. Standard C or CS type
lens can be accommodated into XNET/XNET-Wireless. Either DC Iris lens or Non-DC Iris lens
can be used with XNET/XNET-Wireless.
Auto-Iris Control: Plug in the cable from standard DC-Iris lens.
Antenna: This antenna is used only for the XNET-Wireless cameras(WG Series) to transmit
images via wireless network.
Antenna
Lens
Auto-Iris Control

XNET Network Box Camera User’s Guide
7 of 47
2.3.2. Rear panel
Figure 2-3. Rear Views of XNET/XNET-Wireless
MIC /LINE IN: Connect external audio source or microphone. Use a standard stereo
earphone jack for the connection
Audio In
Ground
Not used
Audio In
Ground
Not used
Audio out
Ground
Not used
Audio out
Ground
Not used
Figure 2-4. Pin assignment of the plug for MIC / LINE IN (left) and
LINE OUT (right)
LINE OUT: Connect speakers with built in amplifier. Audio from remote site is output through
Line out in bi-directional audio mode. Use the standard stereo earphone jack for the
connection.
Reset Button: Factory Default Switch
There is a switch provided for returning the network camera to factory default state. Press the
switch about 3 seconds through a tiny hole at the left of the 100BaseT connector using tools
with sharp tip for a few seconds while power is applied.
RS232C &
Analog Video Out
Reset Button
Status LED
Link LED
RS485 &
Alarm Input / Output

XNET Network Box Camera User’s Guide
8 of 47
100BaseT: 100Mbps Ethernet connector (RJ-45) with proprietary PoE.
-Status LED: Green color indicates that the camera is in normal operation mode, while red
color indicates that the camera is in abnormal condition.
-Link LED: Continuous yellow light means that network cable is plugged in. It will flicker
when there is traffic.
RS-232C & Video-out: 3 Pins from the bottom of the connector are assigned for RS-232
port, while the remaining 2 pins are used for checking composite video output from the
camera. Please note that the bottom most pin is numbered as 1.
Pin
Description
Misc.
1
TxD of RS-232C
For debugging & factory
use only.
2
RxD of RS-232C
3
Ground of RS-232C
4
Video out from the camera
For use in installation.
5
Ground for Video out.
For use in installation
12VDC:Power input of XNET/XNET-Wireless.
Do not apply power through this power input when power is applied through LAN cable using
proprietary PoE.
RS-485 and ALARM IN/OUT: Used for connecting P/T device, sensor, and alarm devices to
XNET/XNET-Wireless. Pin assignments are as follows
Pin
Description
Misc.
1
RS-485 (-)
2
RS-485 (+)
3
Alarm In (-)
NC/NO selectable in admin mode.
4
Alarm In (+)
5
Alarm Out
See section “6.1. ALARM-IN
and ALARM-OUT”
6
Alarm Out
-RS-485:Used for connecting Pan/Tilt and Zoom devices having RS-485 interface standard.
-Alarm In: Connect external alarm sensors such as the infrared sensors, heat sensor,
magnetic sensors, etc. NC/NO selectable in the admin page.
-Alarm Out: It is used for connecting external alarm generators such as sirens, flashing light,
etc. When activated, relay output configures a closed circuit.
Please refer to Section 6.1 for more detailed description on the Alarm In/Out connections.
When connecting a power source to the XNET, the status LED will be lit red for a
second and then it will change to green.
1
5
1
6

XNET Network Box Camera User’s Guide
9 of 47
Antenna Connector: Connector for connecting 3dBi antenna supplied with XNET-Wireless
2.4. PC Requirements
AV streaming data received from XNET/XNET-Wireless can be decoded or stored in a PC running
XNET-NVR program which is a viewing & recording program for a PC. Minimum requirement of
the PC is described below:
Item
Minimum
Recommended
CPU
Pentium III 700
Pentium IV 1.2G above
Main Memory
128 MB
256MB above
Operating system*
Windows 2,000 or later
Windows 2,000 or later
Web browser
Internet Explorer 5.0
Internet Explorer 5.0 above
Resolution
1,024*768
Higher than 1,024*768
Network
10 Base-T Ethernet
100 Base-T Ethernet
* Supported O/S: Windows 2000 Professional
Windows XP Professional / Windows XP Home Edition
2.5 Quick Installation Guide
Brief information for rapid installation is provided in this section. For more detailed information
you are recommended to refer to pertinent documentations provided with the product or refer
to our official website. (http://www.cnbtec.com)
①Connect XNET/XNET-Wireless to the LAN by using one of the following method
i. If you have power adaptor with PoE, connect the network camera and PC as illustrated
in Figure 2.5. Both power and network connection is made with a single LAN cable. The
propriety PoE (Power over Ethernet) adds convenience in installing the network camera
by providing both power and LAN connection using single LAN cabling.
Figure 2-5. Connecting Network camera and PC using PoE Adaptor
LAN Hub
PC
PoE Adaptor
LAN
AC In
Cam
XNET
100BaseT

XNET Network Box Camera User’s Guide
10 of 47
ii. If you have standard power connect the network camera and PC as illustrated in Figure
2.6.
Figure 2-6. Connecting Network camera and PC using AC Adaptor
②Install “IP installer” and “XNET-NVR” on your PC
Detailed information for installing these software can be found in [IP-Installer User’s
Guide] and [XNET-NVR User’s Guide] respectively.
③Assign IP address to XNET/XNET-Wireless using IP installer
Identify the type of the network environment and set up IP address. Detailed process of
setting up IP address can be found in [IP-Installer User‟s Guide]. If network type is xDSL or
Cable modem you need supplementary information provided by your ISP.
④Connect to the XNET in Administrative Mode for initial parameter set-up
All parameters are set to factory default state when XNET/XNET-Wireless is delivered. You
are asked to configure the system for your environment in administration mode. Detailed
information of using administration mode can be found in [5. Configuring XNET/XNET-
Wireless in Administrative Mode]. Among the parameters, the parameters in the
following table should be set-up with proper values. Detailed information for the parameters
in Administrative Mode is found in [5. Configuring XNET/XNET-Wireless in
Administrative Mode]
[Note]: Set-up values are preserved even the power is turned off.
The table below shows the Administrator Mode‟s parameters list.
XNET
DC In
AC Adaptor
AC In
LAN Hub
100BaseT
PC
The XNET Series does not support standard PoE. Do not connect the network
camera directly to a hub supporting standard PoE. We assume no
responsibility for the damages caused by use of standard PoE device with
this product.

XNET Network Box Camera User’s Guide
11 of 47
Page
Parameter
Setup value
Factory default value
Basic
Setup
Video Size
Set the resolution of the video
transmitted from XNET/XNET-
Wireless.
Make sure that you press Check
button to find out the number of
maximum possible simultaneous
users then set the number of
users smaller than or equal to
the number.
Max Upload Rate
Set this value smaller than the
upload speed of your network.
Frame Rate
The number of frames to be
transmitted per second.
Video Rate
Bandwidth assigned for video
transmitted from XNET/XNET-
Wireless.
User
Admin &
Time
Setup
Administrator
name &
password
For safety, you are recommended to
change these values from factory
default. For new connection, you
need to input changed values for
corresponding fields. Do not disclose
these values to others and
memorize these values.
Default value
Username : root
Password : dw2001
Current Time
Input correct time in this field.
Default value :
2001/1/1
⑤Connect the input and output signals to XNET/XNET-Wireless
Connectors
Function
Signal description
Number
LINE-
In/MIC
Audio in
Connect microphone or output from audio
devices.
1
Line Out
Audio out for speaker
Audio from remote site is available from
this connector in bi-directional audio
mode. Connect speaker with amplifier.
1
Alarm In
Connecting Alarm
Sensor
IR sensor, Motion Sensor, Smoke
Detector…
1
Alarm Out
Connecting Alarm
annunciating device
Siren, Flashing Light, …
1
RS485
PT device control
Remote P/T/Z device connection having
RS485 interface.
1
100Base-T
Network connection
Connect XNET/XNET-Wireless to the
network, LAN, ADSL or Cable modem.
1
12VDC
Power connector
The input power source is 12VDC
1

XNET Network Box Camera User’s Guide
12 of 47
⑥Remote video connection to XNET/XNET-Wireless
Run “XNET-NVR”on your PC. Before connecting to XNET/XNET-Wireless it is needed to
configure the connection information on the XNET-NVR. More detailed information of using
“XNET-NVR” can be found in [XNET-NVR User’s Guide].
⑦Brightness adjustment
Adjust the brightness setting for optimized image quality from the CCD control menu in the
administrator mode. When accessing the administrator mode for the first time, enter the
username (default: root) and password (default: dw2001).
3. Connecting XNET/XNET-Wireless to the Network
XNET/XNET-Wireless supports LAN, xDSL, and Cable modem. It also supports shared IP
environment where single IP address is shared by at least 2 IP devices. Refer to [IP-Installer
User’s Guide]for details of setting the IP address for XNET/XNET-Wireless.
3.1. Connecting to LAN
In case of connecting the XNET/XNET-Wireless to LAN, it is generally connected as in Figure
3-1.
Figure 3-1. Connecting the XNET to LAN
1) Follow through steps ①to ③in Section 2.5 to assign IP address to XNET/XNET-
Hub
XNET
Router
IP Network
(LAN/WAN)
Client PC
Client PC

XNET Network Box Camera User’s Guide
13 of 47
Wireless.
2) Install the viewer program (NVR or XNVR) and connect it to desired LAN.
3) Check if you can receive video data when connecting to XNET/XNET-Wireless using the
viewer program.
4) When one or more IP video products are connected through a IP sharing device (i.e.
router) to a larger network (i.e. the internet), in order to access each unit from outside
the local area network, each device must have a unique RTSP (Real Time Stream
Protocol) and HTTP port number. You must also configure your IP sharing device for
“port forwarding”. This is to enable the IP sharing device to forward packet data with
unique port number (RTSP and HTTP) to unique internal IP address (local IP address). If
you only plan to access multiple units from within a local area network, you do not need
to change the RTSP and HTTP port numbers, unless other IP sharing devices sit in-
between the client and the IP video products. For more detailed information regarding
the use of IP sharing device refer to the document [Use of Private IP network using
IP-sharing-device].
3.2. Connecting to xDSL/Cable Modem
1) Follow through steps ①to ③in Section 2.5 to assign IP address and other network
parameters to XNET/XNET-Wireless.
2) Install XNET/XNET-Wireless and connect it to xDSL or Cable modem as in Figure 3-2.
Figure 3-2. Connecting the XNET to ADSL Modem
②
XNET
IP Network
(LAN/WAN)
xDSL/
Cable
Modem
Client PC

XNET Network Box Camera User’s Guide
14 of 47
4. IP-Installer
XNET/XNET-Wireless needs IP network parameters for connection to the network
(Internet/Intranet). IP-Installer is a PC program for the initial network configuration to IP video
products such as Network Camera or A/V Server. IP-Installer is provided in a CD supplied with
XNET/XNET-Wireless or it can be downloaded from “www.cnbtec.com”.
Detailed information of Installing and running IP-installer can be found in [IP-
installer user’s guide]
4.1. Main window of IP-Installer
Figure 4-1. IP Installer
All the basic network parameters needed for the initial connection to IP video products can be
assigned by IP-Installer. Once the basic parameters are assigned and the initial connection is
When a static IP address is assigned to the xDSL or Cable modem, follow the same
way as assigning a IP address for the case of LAN using IP-installer. To enable the
notification of the changed IP address to the user over e-mail when the IP address is
changed in dynamic IP environment, you have to assign the e-mail address when
user name and password are input using IP-installer.
When connecting XNET/XNET-Wireless to xDSL or Cable modem, usually a
straight LAN cable is required. But since some modems have crossover
connections, in this case, you should use a crossover LAN cable. Please contact
your service provider for detailed information.

XNET Network Box Camera User’s Guide
15 of 47
successfully made, you can connect to the administration page for more sophisticated control of
the network parameters and other operational parameters. Refer to Chapter 5 for more details
of the administration page.
5. Configuring XNET in Administrative Mode
5.1. Log On
There are two ways of connecting to XNET/XNET-Wireless administrative mode. One is through
Internet Explorer (IE) and the other is through “XNET-NVR”or “XNET-XNVR”program. But
this user‟s guide will explain accessing by IE and “XNET-NVR”only. (Please refer to the XNVR
user‟s guide in the supplied CD for using “XNET-XNVR”.)
5.1.1. Log on from Internet Explorer
The URL of the XNET administrative mode is as followings:
http://[Allocated IP address]/admin.htm
Example: http://172.16.64.133/admin.htm
If you changed the HTTP port from default value you can login by typing in:
http://[XNET/XNET-Wireless IP address]:[HTTP port]/admin.htm
Example: http://172.16.64.133:8080/admin.htm
5.1.2. Log on from “XNET-NVR”
Select video channel in the viewing window of “XNET-NVR”. Selected video channel will be
highlighted. Click button on the right side of the display screen.
Figure 5-1. Log on to administrative mode from “XNET-NVR”

XNET Network Box Camera User’s Guide
16 of 47
5.1.3. Input User Name and Password
After fallowing the method which explained in Section 5.1.1. or 5.1.2, the login screen will open.
Input the User Name and Password in the login screen shown in Figure 5-2.
Figure 5-2. Login screen
The default setting for the User Name and Password are „root‟ and „dw2001‟, respectively. Click on
“OK” button to enter into the Basic Setup page of Administrative Mode. If you have changed the
username and password of the Administrator, you must log on with the changed username and
password.
If you forget the user name and password, the only way to reset it is by resetting the
unit to factory default through the reset button. It will make all the settings go back
to default. In this case, you have to setup the network parameters again. Please refer
to section 3.
After login to the administrative mode, change the user name and password for
security. Please refer to section 5.6. “User Admin & Time Setup”for detailed
information.

XNET Network Box Camera User’s Guide
17 of 47
5.2. Basic Setup
Setup the basic parameters of the XNET/XNET-Wireless.
Figure 5-3. Basic Setup
Field/Button
Sub Field
/Button
Description
Language
Select a language of your choice. English, Korean, Chinese,
Japanese, Spanish, Italian, Portuguese are available.
System Name
Logical name of the XNET. It is same as the one set-up by IP-
installer. You can reassign the system name.
Screen Capture
in Web Viewer
Save a image file captured from the web viewer to the folder of
your choice. The file name format is as fallows
Capture_year_month_day_minute_second.bmp.

XNET Network Box Camera User’s Guide
18 of 47
Audio Input
Selection
Select the type of input audio.
Select Line In for using Line-out from audio devices.
Select Mic for using microphone.
Video Quality &
Bandwidth
Control
Input Video
This filed is set by the factory
Video Size
Select a video size for transmission-
NTSC(30 fps Max.): 720x480, 352x240, 176x144
PAL/SECAM (25 fps Max.): 720x576, 352x288, 176x144
Interpolation/
De-Interlace
Select the imaging method when the video resolution is Full D1.
Interpolation: Filtering not used. Provides clear images than
De-Interlace method, but a jaggy image will appear to the
moving object.
De-Interlace: Using filtering. Proper to the moving objects,
but not clearer than Interpolation method.
Max. upload
rate
Assign maximum bandwidth of the uplink for the network
connected to XNET/XNET-Wireless.
Frame rate
Assign number of video frames to be transmitted for each second.
You can improve picture quality by lowering frame rate for the
same bandwidth.
Video rate
Assign bandwidth for transmitting video data.
Audio rate
Assign bandwidth for transmitting audio data. Audio data is not
transmitted if you select “NA”
Check
After you finish set up of video and audio for all the channels, click
on this box to obtain the possible maximum number of users
(Possible Max Users) and remaining network bandwidth
(Remained) remaining when possible maximum users are
connected.
Possible Max
Users
It shows the number of maximum simultaneous connections for
the network connection set-up.
Remained
It shows the network bandwidth remaining when Possible Max
Users are connected.
Limited users
Useful network bandwidth varies according to the condition of the
network. This parameter is used to limit the number of the
simultaneous connections below the number shown in Possible
Max Users.
Save
Save the set-up parameters when the set-up parameters are done.

XNET Network Box Camera User’s Guide
19 of 47
5.3. Network Configuration
Setup the network parameters appropriately in accordance with your network environment.
Many of the parameters in this page are same as those set up by “IP-Installer”.
Figure 5-4. Network Configuration

XNET Network Box Camera User’s Guide
20 of 47
Field/Button
Sub Field
/Button
Description
IP Assign
Type
The network types supported by the XNET/XNET-Wireless are
LAN(fixed IP), PPPoE, and DHCP(automatic IP allocation)
Static IP
Setup
When the network environment is fixed IP, select „LAN‟ in the
network type, and put the IP address, Subnet Mask,
Gateway, DNS1 and DNS2. Ask your network administrator
or ISP for the information. DNS2 is used when DNS1 does
not work.
PPPoE Setup
When the network environment is PPPoE and IP address is
assigned automatically, select „PPPoE‟ in the network type.
Next, fill in the „User Name‟ and „Password‟ fields with the
values assigned by the ISP.
DHCP Setup
When the network environment is “automatic IP allocation by
DHCP”, select „DHCP‟ in the network type. For cable modem
connection, select this mode.
Refer to [IP-installer user’s guide] for “Host name and
domain for Cable Modem
Clone MAC
Refer to [IP-installer user’s guide] for “Clone MAC”
Port Change
Each port should have a number below 65,535.
RTSP
The RTSP port is used for transmitting real time audio/video
data from the network camera. Default is 554.
HTTP
HTTP port is used for the connection to the admin page.
Default is 80.
IP Filtering
You can restrict the access to the administrator page from IP
addresses beyond certain IP address range.
Restrict
Administrator
Access
Check at this box to restrict administrative log on.
Base IP
Address
Input IP address of the PC which is intended to be used for
log on to administrative mode.
Mask
This is same as subnet mask. It is used to allow
administrative log on only to the PCs located in the same
subnet as the base IP address. If you want to allow only one
PC to access in administrative mode, set this value to
255.255.255.255.
E-Mail Setup
Notify for IP
Change
If you check this, the IP address will be sent via E-mail
whenever the IP address changes. It is sent to the E-mail
