X-Tensions Emulator Edition User manual

Rec Room Masters www.recroommasters.com
email: [e-mail]
“Emulator Edition”
2 Players, With 3”Trackball, 10 LED Menu Buttons
USER MANUAL
Version 2 Software NOW with 3 Switchable Modes!
Keyboard / D-Input / X-Input
Windows™ MAC™ Raspberry Pi™

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 2
UNBOXING YOUR CONTROLLER
STEP 1: Carefully unpack your arcade control board. If you use a utility knife, please make
sure you do not damage any part of the product when unpacking.
STEP 2: Once unpacked, attach your controller to your 32” Xtension Arcade cabinet or
Pedestal and secure with the 4 - 60mm black bolts using the Allen wrench that was included
with your cabinet. If you did not order an Xtension Arcade cabinet, you will not need the 4 -
60mm black bolts.
STEP 3: Your Xtension Emulator Edition Controller has 1 USB cable. Plug your USB cable into
your PC, Mac or Raspberry pi and turn on your computer or pi. Your LED Menu buttons will
turn on and are powered by the USB input of your PC, Mac or Raspberry pi.
3 SWITCHABLE MODES
There are 3 dierent switchable gameplay modes for your controller. You can switch between
the 3 available modes by simply holding down player 1 start and an additional assigned
mode button for 10 seconds. That’s it! After 10 seconds, release both buttons and wait up to
30 seconds for the desired mode to take eect. The assigned mode will save and open when
restarting your system.
Your 3 mode options are Keyboard Mode, D-Input and X-Input. The controller will normally
ship with Keyboard mode defaulted . You can change to your desired mode without any 3rd
party software or rmware update. Use Keyboard Mode for Trackball use.
NOTE: The menu names labeled on the controller’s graphic are only for Keyboard Mode.
See the helpful video linked below on how to switch modes.
HOW TO SWITCH MODES:
https://youtu.be/d8jbvclHkkk
KEYBOARD MODE
Keyboard Mode is best used for PC Emulators , MAME and popular front end software like
Hyperspin and Launchbox. The Menu buttons functionality is VERY important for emulation
and navigation with PC emulators and front end software. Keyboard mode is the only
mode where you can access this full menu navigation feature and we highly recommend
this mode for use with PC Emulators, MAME, Hyperspin, LaunchBox and most PC arcade
front end software. The Keyboard mode is defaulted to the popular MAME software and we
recommend mapping all of your emulators to Keyboard mode when using a PC.

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 3
KEYBOARD MODE
KEYBOARD MODE (PC KEYBOARD DEFAULT MAPPING LAYOUT)
Press and Hold the Shaded Buttons for 10 Seconds to Get Back into Keyboard Mode
If you are not in Keyboard Mode and wish to switch back to Keyboard Mode, you will
need to hold down the following buttons for 10 seconds. Simultaneously press and hold the
Player 1 Start button and the Player 1 1st button for 10 seconds. After 10 seconds, you can
release both buttons and wait up to 30 seconds for the desired mode to take eect.
KEYBOARD MODE: Player 1 Start (1 Key) + Player 1 1st Button (Left CTRL Key)
(The buttons shaded in black above)
Emulator Mapping: The controls are pre-mapped to the default conguration of MAME.
However, you can use this Keyboard encoded conguration to custom map most any PC
emulator you would like. Custom mapping options can normally be performed in the menu
options of any 3rd party downloaded emulator software application.
Disabling Windows Keyboard “Hot Keys”: You may want to disable your Windows PC’s
“Hot Keys” by simply right clicking anywhere on your screen and selecting “Graphics
Options” and then “Hot Keys” and then “Disable”. This will prevent any unwanted multi key
activated pop up screens during game play.
The menu labels displayed on the controller printed graphic are labled
for Keyboard Mode only, for PC emulation navigation.
1
L CTRL
TRACKBALL

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 4
D-INPUT MODE
D-Input Mode is best used for 2 player Raspberry pi gameplay and Retro Pie software.
You can also use it for PC use. During PC use, the controller will show up as 2 individual
gamepads in your Windows Device Manager. This does not aect gameplay.
D-Input is NOT recommended for PC use with Steam games. X-Input is a better choice for
most Steam content, especially modern ghting games.
If you want to switch to D-Input Mode, you will need to hold down the following buttons
for 10 seconds. Simultaneously press and hold the Player 1 Start button and the Player 1 2nd
button for 10 seconds. After 10 seconds, you can release both buttons and wait up to 30
seconds for the desired mode to take eect.
D-INPUT MODE: Player 1 Start (P17) + Player 1 2nd button (P11)
(The buttons shaded in black on image below)
IMPORTANT INFORMATION: The Trackball will work when using a PC however, the
trackball will only work on some versions on MAME in Retro Pie software . Unfortunately, this
is how the 3rd party Retro Pie Software is set up and we have no control over any 3rd party
software. Left and Right Mouse WILL NOT Work on ANY system.
You can also see the helpful video linked below on how to set up a raspberry pi.
HOW TO SET UP A RASPBERRY PI:
https://youtu.be/LGIGfJoTpBQ
D-INPUT MODE (DEFAULT DUAL GAME PAD MAPPING LAYOUT)
Press and Hold The Shaded Buttons for 10 Seconds to Switch To D-Input Mode
IMPORTANT: The Trackball will only work with some
versions of MAME on Retro Pie!
TRACKBALL

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 5
HELPFUL TIPS WITH SETING UP YOUR CONTROLLER USING
RETRO PIE SOFTWARE
For Raspberry Pi and Retro Pie Software Using D-Input Mode
TIP 1: When attempting to “CONFIGURE INPUT”,set up
your player 2 rst and do not congure a “HOT KEY”. When
Retro Pie asks what you want for your “HOT KEY”, just hold
down any button to skip this step and no “HOT KEY” will be
assigned. When setting up your player 1, you will then want to
assign your “HOT KEY” to the controller’s “COIN ONE” button.
This will then allow you to exit games by pressing “Player 1
Start” and “COIN ONE” simultaneously.
TIP 2: If you are using a fresh new install of Retro Pie on your
Raspberry Pi, and this is the rst ever controller that was
plugged into the pi, then upon plugging in your controller’s
primary USB you should see a “WELCOME” screen instruction
for you to hold ANY button on your controller.
TIP 3: We suggest setting up your conguration to the
mapping example displayed above.
TIP 4: If you already previously set up a dierent controller and
would now like to use the Xtension controller, you will need
to use the original controller you originally set up with your
Retro Pie software with and navigate to the “MAIN MENU”
by pressing “START” on your original controller. Then scroll
down and select to “CONFIGURE INPUT” using your original
controller. Then unplug your original controller from the
Raspberry Pi and plug in your Xtension controller. Then hold
down the “A” button shown above and proceed to start the
“CONFIGURE INPUT” process with your Xtension Controller.
VERY IMPORTANT:
The information on this
page is only helpful tips as
we do not oer any ocial
support on setting up your
3rd party software.
Use This Mapping For Both Player 1 & 2

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 6
X-INPUT MODE
X-Input Mode is best used for 2 player PC use with Steam games, especially modern
ghting games. During PC use, X-Input Mode will show up as 1 game pad in your Windows
device manager however, in most Steam games, you will actually be able to use player 1 and
2 simultaneously as 2 separate players. NOTE: YOU MUST UNPLUG AND REPLUG YOUR USB!
If you want to switch to X-Input Mode, you will need to hold down the following buttons
for 10 seconds. Simultaneously press and hold the Player 1 Start button and the Player 1 3rd
button for 10 seconds. After 10 seconds, you can release both buttons and wait up to 30
seconds for the desired mode to take eect. The Trackball will not work with X-Input.
X-INPUT MODE: Player 1 Start (P1 START) + Player 1 3rd button (P1X)
(The buttons shaded in black on image below)
SWITCHABLE MODE QUICK REFERENCE (3 Available Modes)
Keyboard Mode: Best used for PC Emulation, MAME and Arcade Software Front Ends
Player 1 Start (1 Key) + Player 1 1st button (Left CTRL Key)
D-Input Mode: Best used for Raspberry Pi and Retro Pie Software
Player 1 Start (P17) + Player 1 2nd button (P11)
X-Input Mode: Best used for PC Steam Games and Modern PC Fighting Games
Player 1 Start (P1 START) + Player 1 3rd button (P1X)
X-INPUT MODE (DEFAULT DUAL GAME PAD LAYOUT)
Press and Hold The Shaded Buttons for 10 Seconds to Get Back Into X-Input Mode
IMPORTANT: You MUST unplug and then replug in your
controller’s primary USB to enable player 2, OR IT WILL NOT WORK!
TRACKBALL

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 7
Additional Information
Controller Cleaning
Do not clean your plexiglass areas with anything but a soft dry rag. DO NOT use glass cleaner
or any liquid as it may damage your controller. Again, only clean the controller with a cloth or
soft dry rag.
Software Support
Unfortunately we cannot oer software support for MAME or any other 3rd party emulators
or software however we have thoroughly tested all controls for an emulation conguration.
There are many online tutorials on how to set up MAME and other emulators or software
and if you are unfamiliar with this process, we suggest searching online as there are many
beginner to advanced information, and helpful 3rd party software tutorials available.
IMPORTANT WARNING!
We do not recommend downloading any software or Firmware that is not approved by
Rec Room Masters. All approved Firmware and updating instructions are available on our
website. If you are looking to modify your Firmware, we recommend checking with us before
you download or open any 3rd party remapping software that is not listed on our website.
DO NOT ATTEMPT TO DOWNLOAD OR OPEN ANY “OLDER PRE-2015 WIN IPAC
SOFTWARE”! DOING SO WILL PERMANENTLY DAMAGE YOUR CONTROLLER AND THIS
WILL VOID YOUR WARRANTY!
Downloading any Pre 2015 WIN IPAC software and or upgrading the rmware may wipe out
your controller’s PCB and again, is NOT covered under warranty!
Compatible Xtension™ Cabinets
32” Pro Upright Sit-Down Pedestal Sit-Down Cabinet

Rec Room Masters www.recroommasters.com
email: [e-mail]
page 8
We stand behind all of our products!
If you are experiencing any issues with your controllers, please contact us at the number
listed below and we will be happy to address your issue on a case-by-case basis. There is no
time expiration to the warranty as long as you are the original purchaser of the product.
IMPORTANT: Warranty will be voided if any personal customizations have been
performed or any rewiring or reconguring of any electronic application.
RETURNS
IMPORTANT: Please retain your original shipping carton and protective packing in the
unfortunate event you need to return or exchange your controller. All returns for refund
MUST be issued within 14 days of product ship date.
Customers that do not have their original shipping packaging, CAN NOT return their
purchase. If you require a return for support and do not have your original shipping carton,
a return shipping carton can be sent to you for a TBD fee for US customers and a TBD fee
for Canadian customers. You also have the option to supply your own return packaging.
However, if the return controller is not packaged properly and UPS transit damage occurs, a
$125 controller replacement fee will apply.
LEDs
In the unfortunate event one of your LED lights on your push-button fails, please email
[e-mail] for assistance.
CONTACT SUPPORT
If for any reason you experience issues with your controller, please
contact customer service immediately by emailing us at [e-mail]
Thank You For Your Purchase, We Are Always Here To Help!
WARRANTY INFORMATION
