X-Vision XANB25 User manual

Night
Vision
Binocular
XANB2
5
User
Manual
X-Vision | 5140 Moundview Dr. | Red Wing, MN 55066

1
Table of Contents
1. Package Contents
2. About the Binocular
3. Quick Start
Install batteries
Insert a memory card (for photo and video taking)
Turn on the binocular
Take a picture or video
Use digital zoom
Playback
4. Display Information
5. Menu Settings
6. Trouble Shooting
7. Appendix: Specifications
Second Edition, March 2020. Published by X-Vision, Red Wing, Minnesota
© 2020 X-Vision. All rights reserved.
X-Vision | 5140 Moundview Dr. | Red Wing, MN 55066

2020-3-11 Version 2
1. Package Contents:
Binocular Neck Strap

2020-3-11 Version 3
2. About the Binocular:
①Power
Long press for power on and off
Short press for 3 levels of screen brightness
②Mode
● There are 4 modes: Photo / Video / Playback /
Menu (in a loop).
● When the power is on, the default mode is photo.
● Press Mode to change to the next mode.
③Zoom
●Press zoom to zoom in at multiple levels: 3X, 4.5X and 6X.
Once reaching 6X, keep pressing zoom to go back to 3X.
● Under Playback mode: Press zoom to playback to the next
file.
● Under Menu mode: Press zoom to go up.
④IR
● Press IR for 4 levels of brightness (IR Off-> IR1->IR2->IR3-
>IR Off...)
First time power on, IR is set to IR2. Make sure IR is on
for night use.
● Under Playback mode: Press IR to playback to the previous
file.
● Under Menu mode: Press IR to go down.
⑤
● Under Photo mode: Press
● Under Video mode: Press
to take photos.
to start video recording and
press one more time to stop recording.
● Under Playback mode: Press to enter selected item.
①
②
③
④
⑤
⑥

2020-3-11 Version 4
For memory card insert (when the power is off)
·Memory
Card Slot
·View
Area
·Strap
Hook
⑨Focus
Wheel
⑩Battery
Compartment
⑪Tripod
HOW TO FOCUS
⑨Turn Focus Wheel
⑦
⑧
⑩
⑩
⑨
⑪
Holder

2020-3-11 Version 5
3. Quick Start:
Install Batteries
(1) Open the covers.
(2) Put in 4 AA Alkaline batteries in each compartment in the
directions of + and –.
(3) Close the battery compartments.
Insert a memory card (for photo and video taking)
(1) First make sure the power is off.
(2) Then insert the card in the direction as shown. Push the
card into the slot to lock it.
(3) To remove the card, push it in to release. When the card is
partially ejected, pull it out.

2020-3-11 Version 6
Note:
When using a card with previous files saved, it is recommended
to save the files to your computer first and format the card
before use. To format the card, press Mode several times to
reach menu and select “Format SD”.
If the “Memory Full” warning message appears on the LCD
screen, the SD card is full. Please transfer all the files to your
computer and delete the files on the card. Then the card can be
used again.
Turning on your Binoculars:
(1) Long press the Power button to turn on the binocular. Once
the power is on, look into the LCD screen inside for preview.
(2) Adjust the focus by turning the focus wheel at the front
bottom. See below arrow for “focus wheel”
(3) For daytime use, make sure the IR is off. For night use, turn
on the IR by pressing the IR button. Increase the brightness
by pressing the button repeatedly. It has 4 levels of
brightness (0ff->1->2->3->0ff…).
(4) Long press the Power button to shut down the binocular.
(5) If the screen brightness needs to be adjusted, short press
the Power button or you can go to the “Menu Settings” to
adjust.
(6) The binocular will save the setting from last use.
(7) This binocular has an auto shut off feature; after 5 minutes
the binocular will power off to conserve battery power. To
change this setting, go to the “Menu Settings” to turn it off,
or change it to 10/15/30mins.

2020-3-11 Version 7
Take a Picture:
(1) When the power is on, the binocular is automatically under
the picture mode.
(2) Check the left bottom corner of the screen for the icon.
If the icon is not showing, press Mode multiple times
until the icon shows up.
(3) Adjust the focus by turning the focus wheel. (see “Turn on
the Binocular” section for details)
(4) If at night, adjust the brightness by pressing IR. (see “Turn
on the Binocular” section for details)
(5) Press to take pictures.
Take a Video:
(1) Turn on the Binocular.
(2) Press Mode to enter video-recording mode. Check the left
bottom corner of the screen for the icon. If the
icon is not showing, press Mode until the icon shows up.
(3) Adjust the focus by turning the focus wheel. (see “Turn on
the Binocular” section for details)
(4) If at night, adjust the brightness by pressing IR. (see “Turn
on the Binocular” section for details)
(5) Press to start video recording, and press it again to stop
recording.
Use Digital Zoom:
Press Zoom to zoom in at multiple levels: 3X, 4.5X and 6X.
Once reaching 6X, keep pressing Zoom to go back to 3X.
shows on the top left corner of
Playback:
(1) Press Mode until icon
the screen.
(2) The LCD Screen will show the last file saved. If it was a
photo, the photo will show on the screen with “JPG”
wording on the left bottom corner. If it was a video, wording
“AVI” will show on the left bottom corner.
(3) Press to play, delete, delete all, or exit.
(4) Press IR to go to the previous file, and press Zoom to go to
the next file

2020-3-11 Version 8
4. Display Information:
00038
LCD Screen
Memory card installed and
ready for photos.
If is showing, power
off and then insert the
Memory card
card.
Battery status
card.
Number of files
(including photos
and videos) taken.
Photo Mode: Ready to
take picture. Press
to take pictures.
LCD Screen
Battery status
Indicating the zoom in levels,
up to 6X.
Indicating backlight levels (1-3).
The higher the setting the
brighter the display.
Photo Mode:
The higher the setting the further you can see.
the next file.
Indicating IR levels (OFF,1,2,3).

Video Mode:
00:45:00
LCD Screen
Video Mode: Ready to take
videos. When pressing
to record, the time starts
running. Press again to
stop recording.
Minutes of videos
taken
Battery status
Memory card installed and
ready for photos.
If is showing, power
off and then insert the Memory
card
2020-3-11 Version 9

2020-3-11 Version 10
This means current
file is the 38th among
38 taken (including
photos and videos).
Battery status
Battery status
38/38
LCD Screen
This means the file shown
is a video. Press to
view. To go to the previous
file, press IR.
37/38
LCD Screen
This means current
file is the 37th among
38 taken (including
photos and videos).
This means the file shown
is a photo. To go to the
previous file, press IR.
Playback Mode:
Playback
Mode
Playback
Mode

2020-3-11 Version 11
5. Menu Settings:
Menu Mode
This is to set up parameters for the binocular if you wish to change default
settings. Press Mode multiple times until the Menu shows up. Press IR to
go down the menu or zoom to go up the menu. Press to enter. Once
the desired setting is selected, press to save it. Press Mode to exit back
to the photo mode.
To delete all the files in the memory card
To set up auto power off
To set up the date
To set up the time
50Hz (Default setting for EU)
60Hz (Default setting for U.S. and Japan)
To select the brightness level of the LCD screen
To show date and time on the photos
Version of the Firmware for reference only
To delete all the files in your memory
Not to delete all the files in your memory
Yes (to cancel the auto power off setting)
Auto power off in 10 mins without actions
Auto power off in 15 mins without actions
Auto power off in 30 mins without actions
Press to enter.
Press Zoom and IR to go left and right, up and down.
Press to saved settings.
Menu
Format Memory Card
Power Save
Date
Time
Flicker
LCD Backlight
Date/Time
Tag Version
Format Memory Card
Yes
No
Power Saver
Off
10min
15min
30min
Date
YY/ MM/ DD

2020-3-11 Version 12
Time
hr/ min/ sec
Flicker
50Hz
60Hz
LCD Backlight
Date/ Time Tag
Off
On
Version
Press to enter.
Press Zoom and IR to go left and right, up and down.
Press to saved settings.
Default setting for EU.
Default setting for U.S. and Japan.
Default setting is 1.
Indicating backlight levels (1-3). The higher the setting
the brighter the display.
Default setting is off.
Version of the Firmware for reference only.

2020-3-11 Version 13
6. Trouble Shooting:
Binocular Power Off:
If the binocular fails to activate, check for defective, missing or
improperly-installed batteries. Replace or install batteries correctly.
Please make sure to use Alkaline batteries.
Poor Image:
If you wear glasses, please keep them on while using the binocular.
During daylight hours, make sure the IR is off. For use during
nighttime hours, make sure the IR is on.
Adjust the focus by slowing turning the Focus Wheel at the front
bottom of the binocular. Make sure it is focused.
Why is “Please insert Memory Card” message showing on the
screen while the Memory Card has been inserted?
Please turn off the power, insert the card and check again. The
Memory Card needs to be inserted when the power is off.
If the issue persists, please check the Memory Card compatibility. In
some cases, Memory Card holders that hold micro Memory Cards
may have minor differences than regular Memory Cards, causing the
failure for the card to be read. In this case, try inserting another
Memory Card.

2020-3-11 Version 14
7. Appendix: Specifications
Viewfinder
EVF mode
Aspect ratio
4:3
Aperture
F1.4 with adjustable aperture Day and Night dual
mode
Operation
Preview / Photo Play back
Visual Distance
150 yards at Night, 400 yards at Day
Zoom
Up to 6X
Object Lens Focus
Manually adjust
Visual Angle
10° degrees
Photo Taking
Yes
Video Taking
Yes
Luminance
IR LED / total 2W
External Memory
Up to 32GB SD card
Power Supply
Alkaline AA battery x 8
Power
Consumption 2.5W with IR LED fully on
Size
7.28” X 5.70” X 2.16” (approx..)
Net Weight
Color
Black
Specifications are subject to changes without prior notice.
Patented in EU, U.S.A., Taiwan and China
US PATENT NO. US 10,466,467 B2
FOR CUSTOMER SERVICE CONTACT US AT:
1.33lbs (approx..)
