X4-TECH A-1200 User manual
Available in:
Black Edition › White Edition › Silver Edition
Instruction manual
Hi-Fi stereo amplifier
Amplifier
A-1200
Similiar to illustration
23
Table of contents
5 Chapter 1 Intended use
5 Explanation of symbols
6 Chapter 2 Safety information
9 Before use
10 Chapter 3 The device
10 Features
10 The A-1200
12 Description of remote controls
17 Inserting batteries into the remote controls/Battery information
19 Chapter 4 Setup
20 Chapter 5 Connections
20 Connecting the device to a power supply
20 Connecting analog end devices
20 Connecting speakers
22 Chapter 6 General operation
22 Turning on and playing an audio source
23 Sound settings
24 Chapter 7 Troubleshooting
26 Chapter 8 Maintenance and cleaning
28 Chapter 9 Specications
28 Technical data
28 Delivery contents
45
Dear Customer:
Thank you for deciding on purchasing this quality product from X4-TECH.
This instruction manual will give you a general idea of how this device operates, as well as pro-
vide you with information on cleaning and safety procedures. Please take a few minutes to
read and follow all safety and operating instructions found in this manual carefully, in order to
maintain this products condition and ensure safe operation.
Retain this instruction manual for future reference and pass it along with the device if handed
over to a third party. Should you have any additional questions regarding the operation or instal-
lation of this device or should any suggestions arise, please contract a specialized dealer or our
service team for further information.
We look forward to your recommending us to others and hope you enjoy using this amplier
from X4-TECH.
Your X4-TECH Team
All company and product names mentioned in this document are registered trademarks of
their respective owners. All rights reserved.
We assume no liability for damage occurred as a result of improper use or damage resulting
from the failure to comply with the safety instructions found in this manual, improper operation
or handling! Under such circumstances, all claims under warranty will become void. We assume
no liability for consequential damage!
This product is EMV-certied and fulls all European and National guideline requirements. A
declaration of CE conformity has been established for this product. Certication has been docu-
mented and entrusted to the manufacturer.
The X4-TECH hi- amplier A-1200 is intended for the amplication of low-level audio signals
in home audio systems, which are intensied and transferred between signal sources and lou-
dspeakers.
› The amplier should only be used with a low-level audio source.
› This amplier is only authorized for connection to a AC 230 V~/50 Hz alternating voltage supply
and is intended for indoor use only.
› We recommend the use of this amplier with other hi- products from X4-TECH.
Please adhere to all of the safety information/instructions found in this instruction
manual!
Explanation of symbols
An exclamation mark is intended to inform the user of important information, operati-
on or maintenance instructions or that special attention is required.
This symbol is intended to alert you to the presence of unprotected, live parts or com-
ponents found within the product’s enclosure or of dangerous connections that upon
contact may be of sucient magnitude to constitute a risk of electric shock. Cables
intended for such connections should only be connected by qualied personnel or you
should only use ready to connect cables. There are no user-serviceable parts found in-
side the device, therefore the device is never to be opened.
1
Intended use
Chapter 1 Intended use
67
Chapter 2 Safety informationChapter 2 Safety information
Dear Customer:
The following safety and hazard warnings are not only for the protection of your device, but also
serve as a protection against potential health hazards. Please take time to read the following
instructions carefully.
We assume no liability for personal or property damage resulting from the failure
to comply with the safety instructions, improper operation and handling. Under
such circumstances, all claims under warranty will become void.
› For safety and licensing (CE) reasons any unauthorized modication and/or change
on the device is prohibited and will void the warranty and all warranty claims.
› Any persons operating, installing, setting up, or servicing this device must be trained
and qualied accordingly and observe these operating instructions.
› This is a protection class II device. Make sure that the voltage supply of the power
outlet used meets the required voltage specications (AC 230 V~/50 Hz).
› Ensure that the device has been set up accordingly by following all instructions
found in the instruction manual.
› Power supply cables should be routed so that they are not likely to be walked on,
squished or pinched by items placed upon or against them, paying particular attenti-
on to cords at plugs, convenience receptacles, and the point at which they exit from
the device. Avoid exposing the cable to extreme heat or cold. Ignoring the above
mentioned could result in cable damage and present the dangerous risk of electric
shock.
› Should any evident damage be seen on the device or on the connection cables, do
not come in contact with or touch these. Switch o the corresponding circuit brea-
ker in the power distribution panel rst, before carefully unplugging the power plug
from the wall outlet. Do not operate this device further! Please contact or take it to a
qualied service technician/specialty workshop.
› In order to completely cut o the power supply to the device, unplug the power
plug from the wall outlet. Merely turning the device o with the ON/OFF button is not
sucient enough. Make sure that receptacles are easily accessible.
2
Safety information
› Always pull on the plug’s grips and never on the cable to remove from a wall outlet.
› Unplug the device from the power outlet, if it is not in use for a longer period of time.
› For safety reasons, always unplug the device from the power outlet during thunder-
storms.
› Eliminate potential tripping hazards by routing cables in such a way that no one can
trip or stumble over them.
› Never use the device, if the power cable or device is damaged.
This device is not suitable for children under 3 years of age.
Small children are unaware of the serious and immediate dangers involved
when exposing themselves to or handling electronic devices. Furthermore,
this product contains small parts that could be swallowed.
› Keep packaging and protective foil away from children at all times to a void the dan-
ger of suocation.
› The device should never come in contact with water or moisture.
› To prevent the risk of re or electric shock make sure that liquids, such as dripping or
splashing water, rain or moisture, do not come in contact with the device and power
supply plug.
› Operate this device in a moderate climate and never expose to extreme tempera-
tures, such as high humidity.
› Condensation can build up suddenly, when this device is brought from a colder into
a warmer area (e.g. when transporting). Should this happen, allow the device to warm
up to room temperature rst before using.
› Care should be taken that liquids do not come in contact with the interior, this is
why containers containing liquids, e.g. bucket, vase or plants should never be placed
anywhere near this product, power supply plug inclusive. This could not only damage
the device, but also become a re hazard.
› It is imperative to avoid contact with moisture, e.g. in the bathroom.
89
› Never touch the power plug with damp or wet hands. There is the risk of electric
shock!
› Make sure the device is properly ventilated during operation and never operate it in
constricted areas, such as for example in a bookcase or shelf. Never block ventilation
openings with papers, magazines, blankets, curtains or similar.
› Make sure the device is placed on a rm and stable surface.
› Never place any sources of re on top of or near the device and power supply plug
(e.g. lighted candle).
› Please note that excessive sound pressure levels created when listening to loud vo-
lume levels with earphones or headphones can lead to permanent hearing damage.
› Please adhere to the additional safety information found in the individual chapters
of this instruction manual.
› When connecting other devices, please refer to the safety and operating instructions
found in these respective manuals.
› Please contact our technical hotline or a service technician for further information,
should you be in doubt about device operation, safety or when making connections
or if any questions arise that are not explained within this manual.
Contribute to a better environment by using a designated disposal system (e.g. Dual
System in Germany) or recycling site for the disposal of packaging material.
Chapter 2 Safety information
Before use
Please read this instruction manual thoroughly before operating this device and retain it for fur-
ther reference, questions and use. Following and heeding all information found in this instruc-
tion manual shall maintain this products condition and ensure safe operation.
This instruction manual contains information on how to operate and maintain this device.
Should a component require maintenance, servicing or repairs, then please consult a qualied
dealer or service technician.
Chapter 2 Safety information
10 11
9. DAB: Selects the DAB input as source
10. FUNCTION button (sound selection)
11. CONTROL dial for volume or sound settings (FUNCTION mode)
12. Power button on/o
1. Power inlet
2. Warning symbol
3. Loudspeaker outputs
4. LINE-OUT output
5. DAB stereo source input jack
6. Tuner stereo source input jack
7. DVD/CD stereo source input jack
8. Tape/AUX stereo source input jack
9. Phono stereo source input jack
10. Phono GND: Connector for your record player‘s ground wire
Chapter 3 The deviceChapter 3 The device
3
The device
Front panel
Features
› 400 W (P.M.P.O.)
› Satin aluminium front panel
› Fluorescent display
› Phono, DVD/CD, Tuner, Tape/AUX, DAB, Line in connectors
› Loudness function for enhanced sound eects
› Headphone connector
› Infrared system remote control
The A-1200
1. LINE IN (input 3.5 mm stereo jack; e.g. for your MP3 player)
2. Earphone jack (6.3 mm jack)
3. Display
4. LINE IN: Selects the LINE IN input as source
5. PHONO: Selects the Phono input as source
6. TAPE/AUX: Selects the TAPE/AUX input as source
7. DVD/CD: Selects the DVD/CD input as source
8. TUNER: Selects the Tuner input as source
Rear panel
12 13
Description of remote controls
The included system remote control lets you comfortably control all of the main functions on
your device. If you have only purchased this model, please note that some of the functions on
the remote control will not be available for use. Please have a look at the following remote con-
trols to see which button functions are available for which components. Depending on the pro-
duct or system purchased, operation is also possible with other components from our X4-TECH
Hi-Fi 1200 series. Please feel free to contact our customer service for more information if any
questions arise.
Model 1
This remote control is suitable for use with the following X4-TECH Hi-Fi components/systems:
the TU-1200, the silver A-1200, the silver CD-1200M and the Hi-Fi Sound System 1200.
Tuner TU-1200
1. MUTE
Deactivates/Reactivates the sound
2. AM/FM button
Switches between AM and FM reception
3. INFO button
Select to display RDS information
4. PRESET +/–
Selects a preset station
5. TUNE +/–
Sets the reception frequency
6. Numeric buttons
For direct access to a preset station
7. MONO
Selects a one-channel mono operation
mode
8. MEMORY
Can be used to store stations
9. AUTO
Press to select an automatic channel scan (press for at least 3 seconds))
10. STR
Selects a two-channel stereo operation mode
CD Player CD-1200M
11.
Opens/Closes the CD compartment
12. /
Starts/Pauses playing a CD
13.
Stops playing a CD
14. REPEAT
Switches through available repeat function modes
15. INTRO
Plays the rst few seconds of each song on a CD
16.
Previous song
17.
Next song
18.
Fast reverse
19.
Fast forwards
20. Random
Plays songs in a random order
Amplier A-1200
21. MUTE
Deactivates/Reactivates the sound
Chapter 3 The deviceChapter 3 The device
14 15
Chapter 3 The deviceChapter 3 The device
22. Source selection
TAPE/AUX, DAB, PHONO, TUNER, LINE IN (select to play sources connected to the front
input), DVD/CD
23. TREBLE +/–
Regulates treble settings
24. BASS +/–
Regulates bass settings
25. VOL +/–
Regulates the volume
This remote control requires two„AAA”batteries for operation.
Model 2
This remote control is suitable for use with the
following X4-TECH Hi-Fi components/systems:
the IR-1200, the A-1200, the CD-1200M and the
Hi-Fi Sound System 1200IR.
CD Player CD-1200M
1. OPEN/CLOSE
Opens/Closes the CD compartment
2. Pause
Pauses playing a CD
3. Stop
Stops playing a CD
4. REPEAT
Switches through available repeat
function modes
5. INTRO
Plays the rst few seconds of each song
on a CD
6. PLAY
Starts playing a CD
7.
/ Previous/Next
Select to return to the previous/skip to the next song
8. / Fast reverse/Fast forward
Select to fast reverse/forward through a song
9. RANDOM
Plays songs in a random order
Amplier A-1200
10. TREBLE +/–
Regulates treble settings
11. BASS +/–
Regulates bass settings
12. Source selection
You can use these buttons to select the signal input to be used on your amplier:
Press the LINE IN button to select the front input on your amplier as source or use the
DAB, TUNER, DAB, DVD/CD, TAPE/AUX and PHONO buttons to select the respective inputs
on the back of the device.
13. LOUDNESS
Turns the loudness eect function on/o
14. MUTE
Deactivates/Reactivates the sound
15. VOL +/–
Regulates the volume
Internet Radio IR-1200
16. MUTE
Deactivates/Reactivates the sound
17. TUNE +/–
Automatically searches up/down for stations during tuner operation
16 17
Chapter 3 The deviceChapter 3 The device
18. ST/MO
Switches between a two-channel stereo and one-channel mono operation mode
19. / Play/Pause
Starts/Pauses playback
20. Navigation buttons
Move to the right, selects the next menu in a menu mode
Move to the left, selects the previous menu in a menu mode
Scans 0.05 MHz upwards during FM operation/moves upwards in a menu
Scans 0.05 MHz downwards during FM operation/moves downwards in a menu
21. Mode
Changes the playback mode
22. Numeric buttons
Direct access/stores memory presets 1 thru 5
23. P
Browses through preset radio stations
24. Stop
Stops playback
25. ENTER
Conrms a selection/setting
26. MENU
Press to enter a menu
27. INFO
Displays various information
28. SHIFT
Select/Store preset stations exceeding the numbers 6 thru 10 (6 = 5, then 1)
This remote control requires two„AAA”batteries for operation.
Inserting batteries into the remote control/Battery information
Inserting/changing batteries
› Carefully remove the battery compartment lid on the back of the remote control.
› Remove used batteries.
› Insert new batteries and ensure correct polarity, as graphically displayed inside the
compartment.
› Replace the battery lid carefully.
Information on handling batteries
Keep batteries out of children’s reach.
› Batteries are hazardous waste and do not belong in household waste.
› Ensure correct polarity when inserting batteries.
› Always remove batteries when the remote control is not in use for longer periods of time.
› Never leave batteries lying around unsupervised. These could pose a choking hazard to child-
ren and pets if swallowed. Seek emergency medical care immediately, should this happen.
› Never expose batteries to extreme temperatures, such as sunlight, re, ovens, etc. there is the
risk of explosion!
› Make sure that batteries are not short-circuited and never recharge non-rechargeable batte-
ries. There is a risk of explosion!
› Always follow manufacturer instructions, when recharging rechargeable batteries.
› Touching leaking or damaged batteries could cause skin burns. Use protective gloves suitable
for handling such batteries.
› Always ensure that the device has been turned o after use.
› Always change/replace all batteries at the same time. Never mix old and new batteries or bat-
teries of dierent types.
› Clean battery and device contacts before inserting, where required.
18 19
Chapter 3 The device Chapter 4 Setup
› The device should be set up on a stable and level surface. Make sure that proper ventilation is
provided to ensure adequate air circulation and that a minimum distance of 10 cm is maintained
above and behind the device. If you would like to place further hi- components on top of the
amplier, make sure that you enlarge the distance behind the device to avoid excessive heat
build-up. Never place or use other ampliers on top of one another.
Selecting a proper location should be taken into consideration before setting up your
device, for example the distance to the next power outlet, avoiding areas where the
device may be exposed to direct sunlight, vibration, dust, heat, cold and moisture, as
well as keeping it away from transformers or motors.
› Never drill or screw any additional screws into the housing to mount.
› Always ensure a safe and stable installation and keep away from objects that might fall onto
it. Improper setup could lead to device instability, resulting in signicant danger and accidents.
› Given the variety of paints and polishes used on furniture today does not excluded the fact
that a chemical reaction may be caused, leaving visible residue on furniture, when the mounting
feet of the device have been placed on furniture. Therefore, never place the device on furniture
surfaces without using proper protection.
4
Setup
20 21
Connecting the device to a power supply
Ensure that the power cable is unplugged before connecting further components.
Components already connected to the device should also be unplugged from the po-
wer supply.
› Make sure connections have been made accurately and not reversed, this means for example
left to left and right to right.
Connecting analog end devices
› Only use standard, shielded audio cables when connecting audio sources. Other cables may
cause interference. Only connect devices equipped with the appropriate jacks, in order to avoid
distortion and mismatching, which in turn could cause damage to the device. Before connec-
ting jacks, make sure the correct terminal has been selected. Audio cables/plugs, as well as the
terminals on most devices, are normally red and white to help distinguish what plug is to be
connected to what jack. Connection cables are not included in delivery and must be purchased
separately at your local dealer.
› You have the opportunity to use the following jacks for end devices:
Phono › This connection is only intended for record players!
Tape/Aux, DVD/CD, Tuner, DAB › This connection is for connecting devices, such as a DVD
or CD player, to the respective markings. These markings
serve in general as a way of helping you make the proper
connections. From a technical point of view you can also
connect a tuner to the DVD/CD or DAB jack.
Connecting speakers
A two-core wire connection is required to connect the speakers. Deisolate all wiring
points. Ensure that cables can not be damaged by any sharp edges.
Chapter 5 ConnectionsChapter 5 Connections
Only use speakers with a sucient power rating (2 x 40 watts RMS at 8 ohm and 2 x
50 watts RMS at 4 ohm).
› Connect the loudspeakers directly to the amplier. Never use an earphone adapter or distribu-
tion box. In case of doubt, consult a specialist for further information.
› Make sure that the loudspeakers are correctly polarized, i.e. that plus to plus terminals and mi-
nus to minus terminals correspond.
› The amplier has been developed for operation with loudspeakers that have an impedance
rating of 4 to 16 ohms.
› Never use loudspeakers with a lower impedance rating.
› Speakers should only be connected to these respective outputs.
› Connect the positive (+) terminal of the left speaker to the red speaker terminal.
› Connect the negative (–) terminal of the left speaker to the black speaker terminal.
› Connect the positive (+) terminal of the right speaker to the red speaker terminal.
› Connect the negative (–) terminal of the right speaker to the black speaker terminal.
5
Connections
22 23
Turning on and playing an audio source
Check that all connections are secure and proper, before turning the device on for the
rst time.
› The main switch should be switched on rst (position – ON), before putting the device into
operation.
› The current selected input source will appear on display, for example DVD/CD.
› Rotate the„VOLUME“ control dial completely to the left.
› Turn the audio source on, for example your CD player.
› Select the desired sound source by pressing the respective input source button (e.g. DVD/CD).
If the end device to be used is connected to a dierent connection, then select the respective
input source accordingly (such as Tape/AUX, DVD/CD, Tuner or DAB).
› Start playback of the selected playback source (e.g. CD player).
› Rotate the„VOLUME“ control dial in a clockwise motion to the desired listening level.
Warning
Please note that one should never listen to high volume levels for longer periods of time. This
could damage your hearing.This applies especially to listening to music with earphones or head-
phones. Excessive sound pressure levels created when listening to loud volume levels with ear-
phones or headphones can lead to permanent hearing damage. Set the volume to a minimum
before using earphones/headphones and try to maintain a comfortable volume level thereafter.
› You can press the„FUNCTION“ button to access the sound settings mode. Refer to next section
for more information on this function.
› Before turning the amplier o, rotate the„VOLUME“ control dial completely to the left rst and
then press the POWER button to turn the amplier o.
› Failing to comply with the above sequence could cause damage to the loudspeakers or the
amplier.
Chapter 6 General operationChapter 6 General operation
Sound settings
Press the„FUNCTION“ button on the device to select one of the following setting modes:
Selection Control dial
BAS Regulates the bass intensity by rotating the control dial.
TRE Regulates the treble intensity by rotating the control dial.
BAL Regulates the balance by rotating the control dial.
LOU OFF Select this mode to add an additional sound eect.
RESET Selecting „RESET“ and rotating the control dial returns all settings to a
factory default setting.
› You can use the „TREBLE +/–“ and the „BASS +/–“ buttons on the remote control to directly
adjust treble and bass settings. Balance settings can only be carried out directly on the device.
6
General operation
24 25
Chapter 7 TroubleshootingChapter 7 Troubleshooting
The device you have just purchased is equipped with state-of-the-art technology and is safe to
operate. Nevertheless, problems or malfunctions may occur.
Before contacting a service technician, refer to the following possible solutions:
Distorted sound or no sound is audible.
› Check if all cables are properly connected.
› Check if all devices have been turned on and/or are connected.
› Check if the right input source has been selected.
› Check the volume control’s position.
Remote control is not working.
› Check if the batteries have been inserted correctly.
› If batteries are empty, replace them with new ones.
› Point the remote control to the remote sensor and press to operate.
› Remove any objects found between the remote control and the remote sensor.
› Make sure the distance between the remote control and the device does not exceed 8 m.
Buttons do not function (on the device and/or remote control).
› Turn the device o and then on again. As an alternative, turn the device o, unplug it from the
power outlet and plug in again. (The device also may not be functioning due to a stroke of light-
ning, static electricity or other external factors.)
A channel does not function.
› The audio cable connected either to the end device or amplier input has become loose.
› A loudspeaker cable connected to the speaker terminal has become loose.
A buzzing sound can be heard.
› An overamplied signal has been transmitted to the amplier input.
› The volume is too high, causing speaker distortion.
› The treble and bass control dials have been turned up to high.
› There is no ground terminal connection or it’s been disconnected (this applies to record player
playback).
› An audio cable may be defec
Distortion results.
› An overamplied signal has been transmitted to the amplier input.
› The volume is too high, causing speaker distortion.
› The selected audio source is a high level device, which has been incorrectly connected to the
amplier’s PHONO input.
Playback occurs without bass.
› Connected loudspeaker poles are reversed (+ and – are mixed up).
› The„BASS“ control on the amplier has been set to minimum.
Playback occurs without treble.
› The„TREBLE“ control on the amplier has been set to minimum.
Any repairs other than those mentioned above are to be carried out solely by an autho-
rized technician. Never try to repair this device yourself!
7
Troubleshooting
26 27
Carry out a technical safety inspection on a regular basis, e.g. check if the power cable or housing
may have become damaged.
If there is reason to believe that the device can no longer be operated safely, then disconnect it
immediately from the power supply and secure it against any unintentional operation. Carefully
remove the power cable plug from the wall outlet and where applicable switch o the corre-
sponding circuit breaker rst.
It can be assumed that safe operation is no longer possible, if:
› there is visible damage to the device or power cable,
› the device no longer works,
› it has been stored for a longer period of time under unfavorable conditions
› or exposed to rigorous transport conditions.
Always adhere to the following safety instructions before cleaning and maintenance:
Live parts may be exposed, if the covering is opened or parts are removed.
› The device must be disconnected from the power supply source prior to service, maintenance
or repairs.
› Capacitors within the device may still carry voltage even though they have been disconnected
from all power supply sources.
› Repairs are only to be carried out by qualied personnel, who are familiar with the hazards in-
volved and the relevant regulations.
› Please retain the original box and the packaging material in case you need to transport or send
the device out for maintenance at a later date. Please note that the device should be repacked
in the original packaging. The box and packaging have been especially developed for this device
in order to protect it during transport and against damage. Retain this instruction manual for
future reference and where required pass it along with the device if handed over to a third party.
It contains important information on initial operation and handling.
Keeping the external case clean
Never use volatile uids near the device, as for example insect spray. Avoid letting the device
come in contact with rubber or plastic products for longer periods of time. These could other-
wise leave marks behind.
Chapter 8 Maintenance and cleaning Chapter 8 Maintenance and cleaning
Cleaning the device
Unplug the power cable before cleaning. Always use a soft and dry cloth to clean the unit’s ex-
terior. If the device is extremely dirty you can use a soft cloth, dampened with water or a mild
cleaning solution to clean. Never use any abrasive or harsh cleaning agents (e.g. alcohol, benzine
or thinners) as these could damage the controls, casing or any markings and labels found on the
device.
8
Maintenance and
cleaning
28 29
Chapter 9 Specications
Technical data
Inputs
› 5 x Stereo IN jacks (47 kohms; 390 mV)
› 1 x Phono IN jacks (47 kohms; 5 mV)
Sound settings
› Treble +/–14 dB at 10 kHz
› Bass +/–14 dB at 100 Hz
Power output
› 2 x 50 watts RMS at 4 ohms
› 2 x 40 watts RMS at 8 ohms
› SN/ratio: > 80 dB
› Distortion factor: < 0.5 % at 1 watt
General
› Power supply: AC 230 V~/50 Hz
› Dimensions: 430 x 314 x 80 mm (incl. feet)
› Weight: 5.9 kg
› Remote control: System remote control
Delivery contents
› X4-TECH amplier A-1200
› Remote control
› Batteries
› RCA cable
› Service data sheet
› User manual
9
Specications
Service
Should questions arise then please contact a specialist or our service hotline:
Hotline: +49 (0) 53 02/8 06-450
Address: x-services.eu gmbh
Service department X4-TECH
Brackestraße 3 · 38159 Vechelde/Germany
Information and updates: http://www.x4-tech.de
› Original X4-TECH spare parts and accessories can be found on the X4-TECH pages under
www.x-spares.de
› We reserve the right to alter specications and information contained in this manual without
notice.
› All brands mentioned are property of X4-TECH or of their respective owners.
› X4-TECH assumes no responsibility or liability for any errors or inaccuracies that may appear in
this instruction manual.
© 2010 X4-TECH All Rights Reserved.
Manufacturer
x-peer.de GmbH
Brackestraße 3 · 38159 Vechelde/Germany
Version 1.2 – 6/2010
www.x4-tech.de
Table of contents
Other X4-TECH Amplifier manuals
