Xanes TAP-05A User manual

TAP-05A

8
8
1. Please charge power for the battery before using.
2. In order to protect and extend the battery and air pump life, we do
not recommend use the air pump constantly for long time. It shall be
stopped for 3 minutes and start again after 8 minutes continuous
works.
3. Never expose the air pump or battery to wet cold environment like
water, rain, frost, snow below -20℃ and hot locations above 50℃.
As well as not charging the battery in humid and wet places.
4. Children are forbidden from operating the air pump and playing the
air pump accessories in unattended situation. Please store the air
pump away from children when charging.
5. Please remove the battery from the device if non-use for long time.
Charging the battery at least one time per 3 months.
Caution
Warning
Warranty Card
This product from sale or gearing of press contract to
agreement from day the free maintenance in term fix.
Belong to the one of the following circumstances,
practices to charge to fix, change piece:
1. Protect the product that fix the period expires;
2. Did not press manual request the operation but damage;
3. Because accident factor or usages are not appropriate but
damage;
4. Having not yet my company admits, dismantling to unload
to fix to result in the damage by oneself;
Model
Number
Buyer Seller
Product
Name
Date of
Purchase
Invoice
Number
Item Model Suggestion for the range of
tire pressure. (kg/cm2) Remark
Home use car Seden/hatchback car 2.2-2.5
Home use car SUV 2.2-2.5
bicycle home use bicycle 3.5-5.0
bicycle Road cycling 5.6-9.1
Please follow the
air pressure
standard of car tire
Please follow the
air pressure
standard of tire
Suggestion for tire pressure

TPMS(Tire Pressure Monitoring System)
Inflation for Pro-Bike, bicycle, motorcycle, electric bike and home
use cars.
Inflation for various life buoys, inflatable swimming rings, inflatable
boats and inflatable beds.
Inflation for all kind of balls.
The maximum current: 5A
Inflated speed: 25-35L/min
The maximum of air inflation: 150PSI(10bar / 10kg / 1000Kpa)
Pressure gauge accuracy: ±0.5PSI
Lithium battery capacity: 1000mAh
Charging Time: 40 minutes
The length of air hose: 150mm
Operating temperature: -20℃~+60℃
Product size: 221mm*ø55mm
The weight of product: 400g
Specification
Quick Guide

(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11)
(12) (13) (14) (15) (16) (17)
(1)Air hose
(2)Filler hose hole
(3)LED Light
(4)"-"key for setting/adjustment
(5)"+"key for setting/adjustment
(6)LCD monitor
(7)"U"key for switch unit/Switch ON-OFF for LED light
(8)button for start/shut down
(9)Air pump main body
(10)Battery
(11)Button for battery indicator
(12)Battery indicator for volume/charging
(13)Air adapter for balls
(14)Air adapter for swimming rings.
(15)Air adapter for presta valve
(16)Air adapter for others.
(17)USB cable for charging.
Product Diagram Instruction
1. Take out the main body and battery from the packaging box, short
press the button (11) to check the battery power, then connect the
main body and battery to finish installation.
2. Start: After installation, please short press the Start key (8) to activate
LCD monitor.
3. Pressure Pre-set
①. Switch the unit
After started, please short press key (7) to select the suitable unit
(PSI, BAR, KPA, KG/CM2)
②. Setting air pressure
After selected the unit then long pressure +/- button for 1-2 seconds,
the monitor number will be flashing and enter per-set model. Then
long pressure +/- button to adjust the air pressure. 5 seconds later
the monitor number will stop flashing then finish pre-set.
4. Air pressure checking and inflation.
Connect the air hose to main body and install the suitable air
adapter, then connect the product what you want inflate for. The
TPMS system will work automatically to show the air pressure at
this moment. Short press the start key (8), the air pump will start to
working and stop working until the pressure reached pre-set value.
Then remove the air hose and air adapter.
5. Shut down
①. The background light for LCD will be turned off in 30 seconds
after air pump stopped working, then air pump shut down 60
seconds.
②. Long press button (8) to shut down air pump
6. Charging
①. Remove the main body with battery.
②. In-Plug the Micro port to the battery then connect the USB cable
to the any chargers with output powers at 5V 1A/2A/3A.
③. While charging, battery indicator will flashing blue light and
lighting up with red.
④. After full charged, all light will be blue.
⑤. Please stop charging in 3 hours after battery full charged.
