Xcube X-505 BK User manual

X-505 BK
INSTRUCTION MANUAL
Instruction manual 2
Инструкция по эксплуатации 32
Portable multimedia player
505IM.indd 1505IM.indd 1 19.12.2006 14:12:1419.12.2006 14:12:1

English
2
Getting started
Copy right / Trade mark
Thanks for your purchasing portable multimedia player XCube X-505.
We’re pretty sure that X-505 would meet your expectations perfectly, and is able
to make your life more exciting.
This manual will help you to master the player safely.
Please, read this manual carefully before using the player.
1. Copyright
XCube is the registered trademark of New Media Entertainment (NME) Inc.,
USA.
This product is intended for home use only, and cannot be used for busi-
ness purpose.
NME, Inc. has all the rights of this trademark and the intellectual property of
this manual.
It is prohibited to distribute this product in part or in whole.
All software, audio, video or games which have an intellectual property are
protected by the copyright act.
We recommend the users of this product to visit our internet page www.
xcubedigital.com, which provides comprehensive information about the
company, products, and other related technical data.
All contents included in this manual are subject to change without any prior
notice for improving features, according to changing specification.
505IM.indd 2M.indd 2 19.12.2006 14:12:1619.12.2006 14:12:16

English
3
Safety Instructions
For your security and to prevent any damages, please read the following
safety instructions carefully.
Power Related
Do not plug in multiple AC adapters simultaneously.
This may cause fire.
Never modify, excessively bend, twist, or damage the AC adapter.
Avoid excessive pressure with hookup/disconnection. There is a
risk of electric shock or fire.
Do not touch the AC adapter with wet hands. It may cause electric
shock or damage to the product.
Disconnect the power cord in case of lightning. It may cause
electric shock or damage to the product.
If any liquid or alien substance is spilt or dropped onto the product,
turn it off and stop the power supply. This may cause fire or electric
shock.
If there is any abnormal sound, smell or fumes coming from the
unit, turn it off and interrupt the power supply. This may cause fire
or electric shock.
 Do not drop any metal objects (coins, hairpins, etc.) or inflammable sub-
stances onto the product. This may cause problems with the product.
 Do not place heavy objects on the product. This may cause problems with
or damage to the product.
 Do not place the product in a moist, dusty or sooty place. This may cause
problems with the product.
 Avoid letting any liquids, chemicals, cosmetics, etc. come into contact with
the product. This may cause damage to the product. Under no circum-
stances turn the product on and immediately contact a service center.
 Lightly clean the surface of the unit using a soft dry cloth. This may cause
problems with the product.
 Never use chemicals or cleansing solutions. This may damage the surface
of the product. This may cause problems with the product.
 Do not press two buttons at the same time. This may cause problems with
or damage to the product.
 Do not leave the unit in direct sunlight or near a heater. This may cause
problems with the product.
Product Related
 Do not drop any metal objects (coins, hairpins, etc.) or inflammable sub-
stances onto the product. This may cause problems with the product.
 Do not place heavy objects on the product. This may cause problems with
505IM.indd 3505IM.indd 3 19.12.2006 14:12:1619.12.2006 14:12:1

English
4
or damage to the product.
 Do not place the product in a moist, dusty or sooty place. This may cause
problems with the product.
 Avoid letting any liquids, chemicals, cosmetics, etc. come into contact with
the product. This may cause damage to the product. Under no circum-
stances turn the product on and immediately contact a service center.
 Lightly clean the surface of the unit using a soft dry cloth. This may cause
problems with the product.
 Never use chemicals or cleansing solutions. This may damage the surface
of the product. This may cause problems with the product.
 Do not press two buttons at the same time. This may cause problems with
or damage to the product.
 Do not leave the unit in direct sunlight or near a heater. This may cause
problems with the product.
 Do not drop the product and avoid strong pressure (vibration) or any impact
to the product. This may cause problems with or damage to the product.
 Do not place any magnetic bodies near the product.
 Magnetic bodies such as magnets, CRTs, TVs, monitors or speakers may
cause damage to the product.
 Never disassemble, fix, or modify the unit. This may cause problems with
or damage to the product. Keep the adapter away from heaters. This may
cause fire or electric shock.
Warning:
 For your security, uses only the AC adapter supplied with the product and
avoid any contact with water or other liquids. There is a danger of electric
shock or fire.
 Use only outlets that match the AC adapter plug. There is a danger of elec-
tric shock or fire. Firmly insert the plug of the AC adapter into the power
outlet. (The manufacturer is not liable for damages to the product caused
by using an adapter other than the supplied one.)
Safety Instructions for Using the AC adapter
To prevent operating problems when using the AC adapter, please read the User
Manual.
Only use described voltage (AC 110 - 220V). Failure to do so may cause fire.
Never open the case. There is a danger of electronic shock.
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Touching parts of the AC adapter may cause electric shock.
Do not open the charger case for your own safety.
505IM.indd 4M.indd 4 19.12.2006 14:12:1619.12.2006 14:12:16

English
5
Using the Earphones
 For your driving safety, do not use the earphones while driving a bicycle, car
or motor cycle. It is dangerous and illegal depending on your local laws.
 It is dangerous to listen to music loudly while walking especially crossing the
road at a pedestrian crossing.
 For protection of your hearing ability, do not increase the volume of your
earphones to an excessive level. Doctors warn of the dangers of listening to
music at an excessive level through your earphones.
 If you are experiencing an echo in your ear, turn the volume down or stop
using the earphones.
About Rechargeable Battery
Please follow the Instructions below for your safety. Failure to do so may
cause fire or damages to the product.
Do not use a damaged internal rechargeable battery or charger.
 Do not charge the rechargeable battery for longer than the specified time.
 Charge the battery fully when using the battery for the first time or when
using the battery after a few months of non-use.
 Charge the battery fully, use it until it is completely discharged, and re-
charge it again to ensure a long lifetime. Charging the battery after a short
use may shorten the lifetime of the battery. In this case, repeat charging the
battery completely and discharging it completely several times. Then you
can use the battery for a longer time.
Over-charging and over-discharging shortens the life time of the recharge-
able battery.
When the use time of a rechargeable battery is significantly shorter than a
new one, replace the battery with a new one.
Since a rechargeable battery is an expendable supply, the use time of a bat-
tery decreases over time.
Take care not to short-circuit the AC adapter terminals or the rechargeable
battery (metallic parts) with any conductors such as a necklace, bracelet
etc. There is a danger of electric shock or fire.
Warning: Take care when using this unit while walking. There is a danger
of accidents.
Do not operate functions which require your attention for some time while
driving.
 To configure functions that may require your attention for some time, stop
your car before doing so.
 Avoid watching the screen for long periods of time while driving.
This may cause an accident.
 Do not turn the volume up excessively. Adjust the volume so that the sound
of other cars and emergency sirens can still be heard.
If you cannot hear the sounds of your surroundings while walking,
this may cause an accident.
505IM.indd 5505IM.indd 5 19.12.2006 14:12:1619.12.2006 14:12:1

English
6
Package Contents
The contents are subject to change for the purpose of improving the perform-
ance without prior notice.
505IM.indd 6M.indd 6 19.12.2006 14:12:1619.12.2006 14:12:16

English
7
General Description of Your Portable Media Player (PMP)
The appearance of the contents is subject to change for performance improve-
ment without notice.
505IM.indd 7505IM.indd 7 19.12.2006 14:12:1619.12.2006 14:12:1

English
8
Preparing to Use
Before using the product, charge
the battery by connecting the AC
adapter supplied.
Inserting the Battery Pack
Slide the battery pack into the groove
until it clicks.
Ejecting the battery pack
Note: Press and hold the Battery Eject
button and push the battery pack to
the opposite direction to the way of
attaching.
Using the Attachable Leg for Your
PMP
You can easily keep your PMP stand-
ing alone using the attachable leg
hanging at the end of the hand strip.
Connecting the AC Adapter
Connect the AC adapter to the DC 5V
jack of the product. Firmly plug the AC
adapter into the power outlet.
Charging the Battery Pack
While charging the battery, the charge
status light turns red. When the bat-
tery is fully charged, the red light of
the charge disappears.
Before using the unit, charge the
battery for about 3 hours so that it is
completely charged.
Checking the Battery Level
The Battery Level Display shows the
amount of battery power remaining in
the Battery Pack.
Battery Level Indicator State
Fully charged
40-60% used
60-80% used
The device turns
off automatically
5 seconds later in
order to protect the
inner circuitry.
505IM.indd 8M.indd 8 19.12.2006 14:12:1619.12.2006 14:12:16

English
9
Notes:
An insufficient battery charge
while recording video or transfer-
ring files may cause a serious
system error. Check the charge
level when using the product and
connect the AC adapter, if neces-
sary.
Check the battery charge status
and charge the battery before it is
completely discharged.
When the battery is completely
discharged, connect the AC
adapter for longer than one
minute and then turn it on.
Basic Operation
Turning on the Power
Push the power switch toward the ( )
mark then the blue power light comes
up and the main menu appears.
Turning off the Power
To automatically turn off your PMP:
If your PMP is idle for specific time
period, it automatically turns off.
For more information about sleep
timer, see page 33 “System
Configuration”.
To manually turn off your PMP:
Push the power switch toward the ( )
mark, to turned off the power.
Using the Lock Function
Push the Power switch toward the (
) mark. Lock icon ( ) appears on the
LCD display.
While the lock function is on, buttons
do not work for their function.
To unlock the PMP:
Push the Power switch against the
() mark.
Lock icon ( ) disappears on the LCD
display and all functions are set
to normal.
Adjusting the Volume
Adjust the volume using the Arrow
() buttons. You can adjust the
volume using 0 to 100 levels.
Using different menu options
Main menu consists of 9 modes,
which are MOVIE, MUSIC, PHOTO,
TEXT, FILE, RECORD, CONFIG, and
MONITOR. The FILE mode has sub-
menu of HDD and USB. The RECORD
mode consists of 3 recording modes,
which are VOICE, AUDIO and VIDEO
recordings. Detailed descriptions on
each mode are listed below.
Functions of Each Mode
Press the ENTER button using the Ar-
row () buttons to select.
MOVIE: Plays files with extensions
of avi, mp4, asf, wmv, mpg, and
mpeg, etc.
MUSIC: Plays files with extensions
mp3, wav, wmg, ogg, aac, and
ac3, etc.
PHOTO: Displays files with extensions
jpg, jpeg, gif, bmp, and png, etc.
TEXT: Displays text files with exten-
sions txt, html, smi, and info, etc.
505IM.indd 9505IM.indd 9 19.12.2006 14:12:1719.12.2006 14:12:1

English
10
FILE: Consists of HDD and USB sub
menus.
- HDD: It browses files/folders
inside HDD to execute or delete,
or copy onto a USB device such
as memory stick.
- USB: It browses files/folders in-
side the USB memory to execute
or delete, or copy onto HDD.
RECORD: Consists of Voice, Audio,
and Video recording modes.
- VOICE: Select when voice record-
ing through a microphone.
- AUDIO: Select when recording
audio from an external audio
device through the line in port.
- VIDEO: Select when recording
video files through an external
device.
CONFIG: System setup mode.
Using buttons in the main menu
Button Function
 Moves to the other
modes in the same
level
Confirms the
selection
Moves to the par-
ent mode that is 1
level higher when
in a sub mode
Selecting the Menu Language
You can select On Screen Display
(OSD) menu language.
1. Select CONFIG using the Ar-
row() buttons and press the
ENTER button.
2. Select Language using the Ar-
row() buttons and press the
ENTER button.
3. Select the desired language us-
ing the Arrow( ) buttons and
press the ENTER button. OSD
menu appears in the selected
language.
Setting the current time
You can set the current time.
1. Select CONFIG using the Arrow
() buttons and press the
ENTER button.
2. Select Set time using the Arrow
() buttons and press the
ENTER button.
3. Set the current time using the Ar-
row ( ) buttons and press
the ENTER button.
: Moves to the each item.
: Choose the settings value.
Using the File Browser
When you press the ENTER button in
the MOVIE, MUSIC, PHOTO, TEXT,
FILE, RECORD, CONFIG, and MONI-
TOR mode; each mode’s file browser
appears. The file browser consists
of a folder window on the left where
you can only see the folders and a file
window on the right where you can
see the sub-folders and files inside
the folders that you select.
The file names are sorted automati-
cally in alphabetical / numeric order.
505IM.indd 10M.indd 10 19.12.2006 14:12:1719.12.2006 14:12:17

English
11
Using buttons in the File Browser
Buttons Functions
 Switches between
Folder Window,
Sub-folder Win-
dow, and File
Window
 Moves the cursor
up and down
In the folder win-
dow, whenever you
press the select
button in the up-
permost folder, the
sub-folder appears
and disappears.
In the file window,
when pressing
the select button
in the sub-folder,
the sub-folder
appears, and when
pressing the select
button after select-
ing a file, then the
selected file will
be running or play
back.
Displays or hides
the MENU screen.
When you press
the ESC button
while playing
a file, it moves
to file browser
mode, which is the
previ¬ous mode,
and pressing the
ESC button again
in file browser
mode moves to the
main menu.
Using the Remote Control
Aim the remote control directly to the
remote signal receiver while using the
remote control.
Replacing the batteries
1. After pressing in the direction of
the arrow as in the illustration,
take out the battery holder.
2. As in the illustration, insert the
lithium battery with the positive
terminal face up.
Warning: Keep the lithium battery out
of the reach of the children. Should
any battery be swallowed, consult a
doctor
Connecting to the PC using the
USB cable
You can connect your PMP with PC
using the USB cable.
1. Connect the AC adapter to the
main body and switch it on. Since
operating the unit in connection
with a PC consumes more power
than during normal operation and
insufficient unit power may cause
data loss, you need to connect
the unit to the AC adapter.
2. Connect the USB 2.0 Port on the
unit and the USB port of the com-
puter using the USB 2.0 cable.
Do not disconnect the connected
USB cable without completing
the proper procedures to prevent
505IM.indd 11505IM.indd 11 19.12.2006 14:12:1819.12.2006 14:12:1

English
12
data loss or a system error on the
PC or the PMP. (See ‘Disconnect-
ing the USB Cable’.)
3. The ‘Searching for a new device’
message appears and the USB
driver is installed. If the installa-
tion screen may not be displayed.
Open the Device Manager and
check whether the device driver
is properly installed.
4. When the USB driver is installed,
“USB 2.0 Storage Device USB
Device” will be displayed in the
[Device Manager].
Checking the USB Driver
For Windows 98/ME, check as
follows:
Control Panel -»System -> Device
Manager -> Disk Drive
->USB 2.0 Storage Device/USB 2.0
Storage Device USB Device
For Windows 2000 (Professional),
check as follows:
Control Panel -»System -> Hardware -
> Device Manager -^Disk Drive ->USB
2.0 Storage Device USB Device
For Windows XP (Professional
check as follows):
Control Panel -»System -> Hardware
-> Device Manager ->Disk Drive -
>USB 2.0 Storage Device USB Device
Using Folders
This model includes a high capacity
HDD and is a portable high capacity
storage device that can store a large
amount of data. For more information
about using folders, see page 14 “Us-
ing Folders”
It comes with a USB 2.0 interface for
faster data transfer. You can select
and play files without limitation on the
number of total folder and files, and
you may delete, move, and copy files.
You can freely create folders, but if
you want to play files in each mode,
you have to save the files in the cor-
rect folder.
Folder directories
This model has 6 physical folders,
MOVIE, MUSIC, PHOTO,
SECURITY, SYSTEM, and TEXT fold-
ers.
MOVIE folder: Folder for saving
video-related files, such as *.avi and
*.smi files.
MUSIC folder: Folder for saving
audio-related files, such as mp3 and
wma files.
PHOTO folder: Folder for saving
photo-related files, such as jpg files.
SECURITY folder: You can access
this folder after entering the
password.
Use this folder to save private files to
be kept in secrete.
SYSTEM folder: This folder contains
fonts and system files, therefore
do not remove this folder.
TEXT folder: This folder contains
text files.
505IM.indd 12M.indd 12 19.12.2006 14:12:1819.12.2006 14:12:18

English
13
Saving files
You can playback files once you save
files to the required folders.
Since this model is a high-capacity
portable storage device, you can cre-
ate a temporary folder to save neces-
sary data files.
When purchasing the product for the
first time, there are 6 registered folder
names in the file manager: MOVIE,
MUSIC, PHOTO, SECURITY, SYSTEM,
and TEXT. (Do not delete SYSTEM
folder.)
If you mistakenly delete a folder
name, create the folder name again
and you can save files to it.
Using Removable Disk
To download and upload files:
1. Push the Power switch toward the
() mark to turn on your PMP.
The PMP turns on.
2. Connect your PMP with PC using
the USB cable.
3. Launch Windows Explorer from
the Start menu on the computer.
The PMP is represented as a
Removable Disk in Windows Ex-
plorer.
4. Select a folder on the removable
disk to save the files and drag and
drop the files to the desired loca-
tion.
Notes:
Since separating the cable while
downloading or uploading files
may cause a file system error on
the unit, do not separate the USB
until the procedure is complete.
The order of the files when they
are displayed when the Remov-
able Disk is selected in Windows
Explorer is not the playing order.
If a file is not copied to the cor-
responding playback folder, it will
not be played. (For example, if
test.avi (a video file) is copied to
the MUSIC menu folder, the files
will not be played.)
Disconnecting the USB Cable
When you finish transmitting the files,
unplug the cable according to the
procedures below:
1. Double-click the green arrow in the
notification area.
2. Select the USB device and press
the Stop.
When the Stop Hardware Device
screen appears, click the OK and
remove the USB cable.
Caution: Separating the cable while
downloading or uploading files may
cause data loss. Make sure to finish
all file operations before separating
505IM.indd 13505IM.indd 13 19.12.2006 14:12:1819.12.2006 14:12:1

English
14
the cable. It is recommended closing
all opened file folders before remov-
ing the cable.
Connecting External Equipment
(AV OUT Jack)
You can view movies and photos
saved in the unit through a TV or PC
monitor by connecting the AV OUT
jack of the product. To view movie/
music through the TV:
TV
1. Connect the AV cable plug to the
AV OUT jack of the unit and the
three RCA plugs to the External
TV In jacks. (Yellow: Video, White:
Audio (Left), Red: Audio (Right))
To view a photo or text file, only
connect the video (yellow) plug.
2. Switch to Video (External In)
Mode using the TV remote control
so that the signal from the PMP is
selected. The Operating Display
appears on the TV screen.
3. If you need to adjust the volume
while a file is in play, adjust the TV
volume with the TV remote con-
trol.
Note: If your PC monitor has a Com-
posite Input jack, you can view
movie or photos through the PC
monitor.
Watching Movies
You can watch movie files saved in
your PMP.
1. Select MOVIE in the main menu
using the Arrow( ) but-
tons and press the ENTER button.
2. Select the desired file with the
Arrow() buttons and EN-
TER button. You can watch saved
video files. You can view subtitles
if Smi file is provided
Using buttons while playing movie
files
Button Function
Increases volume
up to 100 steps
Decreases volume
If you press the
button, it searches
forward; if you hold
the button down,
it fast forward
searches.
If you press the
button, it rewinds;
if you hold the
button down, it fast
rewinds.
Toggles pause /
play while play-
ing back. Sets to
normal playback
speed while
searching.
505IM.indd 14M.indd 14 19.12.2006 14:12:1819.12.2006 14:12:18

English
15
Displays or hides
the sub menu.
The sub menu
includes: Informa-
tion, Subtitle Set-
tings, Repeat, and
LCD brightness.
Moves back to the
previous mode
(File Browser).
Changes video
aspect ratio
Pressing this but-
ton sets a book-
mark, and pressing
and holding it
down plays a sec-
tion repeat.
Viewing the Popup Menu while
Watching Movie
Select MOVIE using the Arrow
() buttons and press the
ENTER button.
When pressing the MENU button in
movie mode, the popup menu ap-
pears.
The popup menu includes: Informa-
tion, Caption display, Caption
color, Caption sync, Repeat, LCD
brightness, Capture, Auto resume,
and Play speed.
Information
Gives detailed information about the
currently-playing file. The detailed
information that appears is: File name,
File size, Running time, Video codec,
Video bitrate, Frame size, Audio co-
dec, and Audio bitrate.
Caption display
You can display the subtitles on the
LCD.
Caption color
You can set the subtitle display colors
that are displayed on the LCD.
Caption sync
You can set the subtitle display time
that is displayed on LCD.
Repeat
This function allows for repeat play-
ing of files. There are 3 modes of the
repeat menu as below.
Repeat Function
Off Cancels the
repeat mode.
One Repeats the se-
lected one file.
All Repeats all
the files in the
folder.
Note: The repeat operation is not
applied to the files in the sub folders
included in the folder.
LCD brightness
You can adjust the LCD brightness
settings.
You can adjust from 1-10 using the
Arrow() button.
Capture
You can capture and save still images
while playing a movie. Captured im-
ages are saved into the CAPTURE
folder under the PHOTO folder.
Auto resume
You can start watching movies from
the previous ending point. “Resume
505IM.indd 15505IM.indd 15 19.12.2006 14:12:1919.12.2006 14:12:1

English
16
from the last stop?” message appears
when you re-play the same movie.
Play speed
You can adjust playback speed from
X0.8 to X1.4 levels.
Using the A-B repeat playback
function: (A-B local repeat play-
back)
This function allows for repeat-
playing of random sections.
1. From the point where repeat be-
gins, press and hold the MARK-
button while playing the file. An
icon (A) displays on the menu bar.
2. At the point where repeat is
stopped, press and hold the
MARK button again. An icon (B)
displays on the menu bar. The
selected section will continuously
repeat.
3. Press and hold the MARK button
again to cancel A-B repeat play-
back.
Note: The repeating section should be
at least 5 seconds or longer.
Using the bookmark function
Setting the Bookmark While Play-
ing a File
If you set a bookmark at the currently-
playing location, then when the file
is played again it will play from the
bookmarked location. You can book-
mark only once and later bookmarks
overwrite previous bookmarks. The
bookmark set while playing will be
automatically canceled.
1. While playing, press the MARK
button at the location where you
want to bookmark. The “Book-
mark is set!” message appears.
The Bookmarked files are marked
by the ( ) icon in the file list.
2. To cancel a bookmark: if you play
the bookmarked file, it will auto-
matically cancel.
505IM.indd 16M.indd 16 19.12.2006 14:12:1919.12.2006 14:12:19

English
17
Listening to Music
Select MUSIC mode in the main menu by using the Arrow () button and
ENTER button and select the desired file with the Arrow ( ) buttons and
ENTER button. You can listen to saved music files. Lyric subtitles are supported.
Using buttons while playing music files
Button Function
Increases volume up to 100 steps
Decreases volume
Skips to next file when pressed.
Skips to previous file when pressed within 5
seconds from the beginning of the current
file. Rewinds to the beginning of the current
file when pressed after 5 seconds from the
beginning of the current file.
If pressed while in play, it toggles between
pause and play.
Displays or hides the popup menu. The
popup menu includes: Information, Add to
playlist, Repeat, Shuffle, Equalizer, and LCD
turn-off.
Moves back to the previous mode (File
Browser).
Goes to the file browser to change the music
while in play.
Pressing this button sets a bookmark, and
pressing and holding it down plays a section
repeat.
505IM.indd 17505IM.indd 17 19.12.2006 14:12:2019.12.2006 14:12:2

English
18
Viewing the Popup menu while
Listening to Music
When pressing the MENUS) button
in music mode, the popup menu ap-
pears. On the file browser, the popup
menu includes: Information, Add to
playlist, Goto playlist, Repeat, Shuf-
fle, Equalizer, Set equalizer, Set play
scope, HDD sleep, Set Volume-up,
and Play speed.
Popup menu includes while playback:
Information, Add to playlist, Repeat,
Shuffle, Equalizer, Set equalizer, LCD
turn-off, and Play speed.
You can set up with the Arrow ()
buttons and the ENTER button.
Information
Gives detailed information about the
currently-playing file appears. The de-
tailed information that appears is: File
name, File size, Playing time, Encod-
ed type, Bit rate, Sampling frequency,
Artist, Album and Genre.
Add to playlist
The playlist is a list of music that
automatically plays one by one. You
can add music to the playlist with the
popup menu.
1. While the music is in play, select
the file you want to add to the
playlist or from the music file
browser and press the MENU
button then the popup menu ap-
pears.
2. Select Add to playlist using the
Arrow () buttons and press
the ENTER button. Select the
desired playlist using Arrow ()
buttons and press the ENTER
button. Selected file will be added
to the playlist.
3. Select Yes using the Arrow()
buttons and then press the EN-
TER button.
Note: Since the file added to the
playlist is a copy of the original file,
the original file remains in its original
location.
Go to playlist
You can go to the playlist file browser
using the submenu in order to play or
delete music on a playlist.
Playing Music files in the Playlist
1. Press the MENU button in the
music file browser.
The popup menu appears.
2. Select Go to playlist with the Ar-
row () buttons and press the
ENTER button. The playlist file
browser menu appears.
3. Select the music you want to play
using the direction buttons.
4. Press the ENTER button and then
the selected music will play.
Deleting a File from the Playlist
1. First, select the file to delete from
the playlist file browser and press
the MENU button. “Remove from
playlist” message appears.
2. Press the ENTER button. “Re-
move this file from playlist?” mes-
sage appears.
3. Select Yes with the Arrow ()
button and press the ENTER but-
ton; then the file will be deleted
from the playlist. The original
file will not be deleted but will be
archived.
505IM.indd 18M.indd 18 19.12.2006 14:12:2019.12.2006 14:12:20

English
19
Repeat
This function allows for repeat play-
ing of files. There are 3 modes in the
repeat menu.
Repeat Function
Off Cancels the
repeat mode.
One Repeats the se-
lected one file.
All Repeats all the
files in the folder.
Note: The repeat operation is not
applied to the files in the sub folders
included in the folder.
Shuffle (random playback)
When setting up the shuffle to On,
every music file in the current folder
will be played once, in a random order.
Note: Shuffle is not applied to the
subfolder files included in the folder. If
you select On for the files saved in the
MUSIC menu, only the files within the
MUSIC menu will be randomly played.
Equalizer
You can set the equalizer to select
various sound effects. Equalizer ef-
fects include: Normal, Jazz, Rock,
Classic, Ultra bass, Pop, Soft rock,
Dance, and Live.
Set equalizer
You can adjust the sound from low to
high by its frequency depending on
the user’s preference.
LCD turn-off
You can turn off the LCD window while
in play.
1. Press the MENU button while in
play. The popup menu appears.
2. Select LCD turn-off with the Ar-
row () buttons and press the
ENTER(O) button, then “LCD turn
off?” message appears.
3. Select Yes with the Arrow()
button and press the ENTER but-
ton; the LCD will turn off.
Play speed
You can adjust the playback speed.
Available playback speed: (Normal,
X0.7, and up to X1.6)
Playing a certain section repeat-
edly:
A-B Repeat Playback
This function allows for repeat playing
of random sections.
1. From the point where repeat
begins, press and hold the MARK
button while playing the file. A is
displayed on the operating dis-
play.
2. At the point where repeat is
stopped, press and hold the
MARK button again. AB is dis-
played on the operating display.
The selected section will continu-
ously repeat.
3. Press and hold the MARK button
again o cancel A-B repeat play-
back, press and hold the MARK
button again.
Note: The repeat section is displayed
on the play bar.
The repeating section should be at
least 5 seconds or longer.
505IM.indd 19505IM.indd 19 19.12.2006 14:12:2019.12.2006 14:12:2

English
20
Setting the Bookmark While Play-
ing a File
If you set a bookmark at the currently-
playing location, then when the file
is played again it will play from the
bookmarked location. You can book-
mark only once and later bookmarks
overwrite previous bookmarks. The
bookmark set while playing will be
automatically cancelled.
1. While playing, press the MARK
button at the location where you
want to bookmark. The book-
marked files are marked by the
() icon in the file list.
2. Bookmark is deleted after you
start playback.
Choosing the Playback methods
You can choose the playback meth-
ods while using the Repeat/Shuffle
function.
Playback Methods Functions
Current folder Plays music files in
the currently se-
lected folder
With sub-folders Plays music files in
the currently select-
ed folder including
its sub folders.
All Plays music files in
all folders.
HDD sleep
If not used, the next song is played
in short time delay. However, the
operating time for the battery can be
reduced.
Set Volume-up
Sound volume increases gradually.
Play speed
Adjusts the playback speed.
Viewing Photo Images
Select PHOTO mode in the main menu
using the Arrow () buttons
and ENTER button, and select the
desired file using the Arrow() but-
tons and ENTER button. You can view
saved photo files. You can display
saved pictures as slideshow.
Using buttons while viewing photo
files
Button Function
Moves to the next
file
Moves to the previ-
ous file
It turns the popup
menu display on
and off. The popup
menu includes:
Information, Slide-
show, Slideshow
interval, and LCD
brightness.
It changes to the
previous mode
(file browser state)
and changes from
zoom-in mode to
normal mode.
It displays the
file browser on
the screen to for
background music
play while in picture
viewing.
Zoom in on the screen
1. Press the ENTER button. Each
time the button is pressed, it
changes to 1X>2X>4X.
2. In the zoom-in mode, pressing
the Arrow() buttons
505IM.indd 20M.indd 20 19.12.2006 14:12:2019.12.2006 14:12:20
