Xcube X-503 BK User manual

INSTRUCTION MANUAL
INSTRUCTION MANUAL 3
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ 24
X-503 BK
portable multimedia player
503IM.indd 1 23.07.2007 9:23:31

2
503IM.indd 2 23.07.2007 9:23:31

English
3
Instruction Manual
Portable Multimedia
player X-503 BK
Copyright / Trademark
Thanks for your purchasing XCube
X-503 BK.
We’re very sure that X-503 BK
would sufficiently satisfy you and
make your life more exciting.
This manual will help you safely to
use the product.
Please be sure to check this manual
carefully before the usage.
1. Copyright
XCube is the registered trademark of New
Media Entertainment (NME),Inc in USA.
= This is for home use only and
cannot be used for business
purpose.
= New Media
Entertainment(NME),Inc. has
all the rights of trademarks
and intellectual property of this
manual.
= It is prohibited to distribute this
manual in part or whole parts
illegally.
= All software, audio, video and
game which have an intellectual
property is protected by the
copyright.
= We recommend Users to
register our homepage, www.
xcubedigital.com, which
provides all information of
company, products and other
related technical information.
= All contents included in this
User Manual are subject to
change without any prior
notice for improving features or
according to changing specifica
tion.
Specification
= 2.4’ QVGA 262K-Color TFT LCD
= Built-in Digital Camera: Taking
picture and video
= Support PC Camera
= Support to playback AVI video
format file. 25fps/ sec, QVGA
with good visibility.
= Support MP3/ WMA/WAV
format, LRC lyrics function
synchronous playback, 5 kind
of EQ mode.
= Support E-Book function(Text-
viewer) various codes of text
file.
English
503IM.indd 3 23.07.2007 9:23:31

English
4
= Support E-Book Bookmark
function, convenient user
configuration.
= Support JPG/GIF/BMP/PNG
format of picture file with
convenient zoom-in/out and
navigation functions.
= FM radio: Support Auto/Manual
Scan function, European/
Japanese frequency bandwidth
and easy handling.
= Built-in various games: Tetris,
Explode pigboat, Bet21... etc.
= Support NES game: Nintendo
game Emulator
= Powerful file navigation
function: Support convenient
file manage system such as
Windows.
= Multi-Tasking function: E-Book
or picture viewer while listening
to music.
= Support Video Resume
function.
= Support Intro mode: Finding
music as fast as possible.
= Capacity extension via T-FLASH
Card Slot.
= Support USB Mass storage
function.
= Support FAT32 File System.
= Multi-Language support.
= Easy Play-List function.
= Firmware Upgradeable.
Overview
Layout and Function keys
1. LCD
2. Power: press the button long to
turn on/off. Press shortly to exit
the menu.
3. MENU: menu button
4. A-B/REC: Section repeat
setting / Recording
5. PLAY: Button to confirm. While
media playback, press the
button to pause/play.
6. UP: Go to Up or Previous media.
7. DOWN: Go to down or Next
media.
8. LEFT: Move left/Decrease
volume.
9. RIGHT: Move right/Increase
volume.
10. MIC: Built-in MIC
11. RESET
English
503IM.indd 4 23.07.2007 9:23:32

English
5
12. USB connect/ Earphone
connect.
13. Insert T-FLASH card.
14. Camera.
Basic Operating
= POWER ON/OFF: Press the
Power button for more than
2 sec.
= Press the Play button in Menu
to move sub-menu or to select
the menu.
= Press the Menu button for at
least 2 seconds to lock keys.
= While playback in FM radio/
Music/Video mode, press Left/
Right button to manage volume.
= While playback music or video,
press the Play button shortly to
pause.
= While playback music, press
the Play button for at least 2
seconds to set “Keeping play
ON/OFF”
= While playback video, press
the Play button for at least 2
seconds to stop.
= If user set ‘Auto Power
off Time’, power turns off
automatically in the case of
nothing movement or operation
for selected minutes.
= If you push Power button while
playing MP3 (Must keep on
play!) or listening to FM radio,
you can move to main-menu.
And then, you can enjoy multi-
tasking with Photo view or E-
Book.
503IM.indd 5 23.07.2007 9:23:32

English
6
Using Mode
Main Menu
Turn on the power, and then you
can see Main Menu. There are 9
modes: Music Player, Cinema, FM
radio, E-Book, Multi Record, Image
Browse, Games, Explorer, and Sys-
tem setting.
There are also Battery level, Real-
Time, and Volume Level icons.
Main Menu
Music Player
The player supports MP3, WMA,
and WAV formats and lyrics function
synchronous playback.
When copy songs in the audio
folder, it can play the songs directly;
when copy folder with songs in the
audio folder or u-disk, it need add
the folder to display of music, then it
can play music.
How to use: 1. select the folder in
the Explorer; 2. press menu button,
it shows the submenu, select “add
to list”; 3. press play button, it is OK.
Music Player Screen
Select “Music Player” on the main
menu. This mode screen is as fol-
lows;
= Real Time Clock.
= Play, Pause, and Stop state.
= Play progress bar.
= Total Time/Play Time.
= Volume Level bar(It can be
appeared when you manage
volume)
= Play Speed, Repeat, Play
mode, and Intro mode setting.
= Information about the song:
Title, lyrics, artist, and album.
503IM.indd 6 23.07.2007 9:23:32

English
7
Music Player Screen
In this screen, long press AB/REC
button, it shows Audio list, then you
can edit this screen.
1. Play/ Pause/Stop
2. Real time clock
3. Music player screen
4. Title
5. Lyrics
6. Total time
7. Play speed
8. Section repeat
9. Repeat mode
10. Pre-listen mode
11. Play mode
12. Play time
13. Progress bar
How to Use
= Press the Play button to
playback.
= Press the Play button shortly
while playing music, then, the
playing is paused.
= Press the Play button for more
than 2 sec. while playing music,
then you can set Keeping play
ON/OFF.
= Press the UP/DOWN buttons to
move to Previous/Next file.
= Press the Left/Right buttons at
least 2 seconds to operate Fast
Rewind/Fast Forward.
= Press the A-B / REC button to
set A-B section repeat. (Press
the key once, you can set
start point. And press the key
again, you can set end point. If
you cancel the section repeat
function, press A-B/REC key
again.) The icon “ ” color
should be changed as your
setting.
503IM.indd 7 23.07.2007 9:23:33

English
8
= Press Menu button to move to
“Mode Menu of Music Play”. If
you cancel this mode, press the
Power button.
= Press the Left/Right buttons to
manage volume.
Mode Menu of Music Play
Display of Music Mode Menu
FM Radio
Built-in FM radio can receive
the frequency range about
76MHz~108MHz bandwidth. You
should connect earphone. Ear-
phone works as an antenna.
Display of FM radio Mode
1. Frequency
2. Frequency scan star
3. Frequency mode
4. Listening state
5. Volume bar
How to Use
= Press the Play button at least 2
seconds to pause. Press Play
button again shortly to resume.
= Press the Menu button to move
FM Menu setting.
= Press the Power button to exit
the FM Menu setting.
= Press the UP/DOWN button to
increase/decrease frequency
by 0.05MHz
503IM.indd 8 23.07.2007 9:23:33

English
9
= Press the LEFT/RIGHT button to
adjust volume.
FM Menu setting
Press Menu button on FM radio
screen, the player moves to FM
Menu setting.
= Save/Delete channel and
confirm saved channels.
= Set the Scan Station (Channel
Auto Scan function.)
= Set the Europe bandwidth/
Japan bandwidth.
Display of FM Menu setting
Multi Record
This player is multi-function enter-
tainment product, so that it supports
Photo, video and successive cap-
ture functions.
Basic information
= Picture saved as JPEG format.
= Video saved as AVI format.
= Register contents information
of Photo/Video recording/Voice
recording.
= Register Date/Time/File
format/File name.
= Support successive capture.
503IM.indd 9 23.07.2007 9:23:34

English
10
How to Use
On Photo or Video mode screen
= Press Play button to run Photo
or Video mode.
= Press Play button again to
pause recording video.
= Press Menu button to move to
Camera Menu mode.
= Press Power button to exit each
mode.
Camera Menu mode
Press the Menu button on Photo or
Video mode.
Display of Camera Menu mode
= Support Photo, successive
capture, Video recording
function.
= Support Contrast, Brightness,
and Color Saturation
management function.
= Default Video save path is “:/
MOVIE/RECORD”
= Default Picture save path is
“:/IMAGE/CAPTURE/”
= Capture time set: Set one of 5
type; Cancel, 5 Sec, 10 Sec,
20 Sec and 30 Sec.
= Set Photo size: 640 x 480 and
1280 x 960
= Set Successive capture size:
352 x 288 and 176 x144
Image Browse
The player supports the followings;
= Image format such as BMP,
JPG, GIF, and PNG.
= Zoom In/Out, 90° location
function.
= Slide Show function.
= Indication of Photo information:
Title, File format, Photo size,
Picture rate.
