Xena Networks XenaBay C4-12 User manual

© Xena Networks - 2017 1
XenaBay Chassis Installation Guide
HOW TO INSTALL XENA TEST MODULES
Version 2.8
Xena Networks ApS
Lottenborgvej 26, 2nd floor
2800 KGS Lyngby
Denmark
www.xenanetworks.com

© Xena Networks - 2017 2
SPECIFICATIONS
The XenaBay (C4-12) is a 12-slot, 4U heavy-duty steel rack mount chassis designed to operate reliably in
industrial environments.
Form Factor:
Standard 4U, 19” wide

Construction:
Metal

Number of Slots:
12
Cooling:
3 x 8cm Papst 8412NH / NGLE, and
6 x 4cm Sunon MB40201VX-000U-A99 (on fanbar)

Drive Bay:
1 x 2.5” SATA Drive with Hotswap/ anti vibration.
• Dimensions (DxWxH): 483 x 177 x 447mm (19" x 7" x 17.6")
• Weight: 16.5 kg (36lbs) without test modules
• Color: Black
Environmental
• Operating Temperature: 10 to 35º C
• Storage Temperature: -30 to 70º C
• Humidity: 8% to 90% non-condensing
Power • AC Voltage: 100-240 VAC
• Max watt: 1000W (100-114,9V) / 1200W (114,9-240V)
• Max. Noise 56 dBa.
Regulatory
• FCC (US)
• CE (Europe
TECH SUPPORT
Please contact your local Xena partner or send an email to [e-mail].
PACKING LIST
When you unpack the chassis, make sure the following items have been shipped.
• 1 x XenaBay (C4-12) Chassis
• 1 x Power cord
• 1 x Xena "Quick Start Guide"
• 1 x XenaBay Chassis Installation Guide
• 6 x 12v Power splitter cables

© Xena Networks - 2017 3
QUICK OVERVIEW
Installing test modules in the XenaBay C4-12 chassis requires the following steps to be completed.
NOTE: A slightly different procedure is needed for the M6SFP+, M6RJ45+/n and +25GE modules – see the
end of the document for instructions.
1. Remove the top cover by unscrewing the two bolts at the back of the chassis.
2. Unscrew the restraining bars that holds the module in place
3. Choose which slot the module should sit in and unscrew the bracket
4. Slide the module into place and use the screw to secure it*
5. Position the restraining bars in place.
6. Screw the restraining bars tightly in place.
For M6SFP+ and CFP cards - connect the power cable (see final section in this document)
* In August 2017 Xena improved the way test modules were mounted in the chassis by adding a plastic rail
attached with two screws to the test module. This rail ensures the test module is held very securely in place
when mounted in the chassis.
When transferring test modules with this plastic rail from a XenaBay purchased after August 2017 to an older
XenaBay, it is necessary to remove the plastic rail. This simply requires removing two screws.
7. Replace the top cover
The installation steps outlined above are described in detail below. Please refer to the relevant section.
IMPORTANT: ALWAYS REMOVE LONG TEST MODULES BEFORE SHIPPING
To minimize the risk of damage, please remove “long” test modules before transportation. This includes any
test module(s) that extend past the metal restraining bar under the chassis lid.
Always use the original Xena boxes for shipping (including the polystyrene foam and anti-static bags).

© Xena Networks - 2017 4
STEP 1:
Remove the top cover by unscrewing the two bolts at the back of the chassis.
STEP 2:
Unscrew the fan bar and support bar that holds the modules in place.
The metal support bar holds test modules securely in place. This is very important during transport.
It is also used to mount the fans that cool the chassis. These are attached to the chassis by four screws

© Xena Networks - 2017 5

© Xena Networks - 2017 6
If necessary, disconnect the plug that powers the fans.

© Xena Networks - 2017 7
STEP 3:
Choose which slot the module should sit in and unscrew the cover.
The cover at the front of the slot needs to be removed before you can slide the new test module into place.
You only need to remove one screw which you then (re)use in the next step.
Please note that the tri-speed 100G test module (M1CFP100) requires two slots, as does M2CFP40.

© Xena Networks - 2017 8
STEP 4:
Press the test module firmly but carefully into place – do not force it – and then fasten again with the screw
from Step 3.
IMPORTANT UPDATE:
In August 2017 Xena improved the way test modules were mounted in the chassis by adding a plastic rail
attached with two screws to the test module. This rail ensures the test module is held very securely in place
when mounted in the chassis.
If these new-generation test modules subsequently need to be installed in older versions of the XenaBay
chassis (those shipped before mid- 2017), the plastic rail needs to be unscrewed and removed. There are 3
versions of the rails but all are mounted on the “top” of the test modules (as shown below).

© Xena Networks - 2017 9
This photo shows the screw that needs to be removed.

© Xena Networks - 2017 10
STEP 5:
Now the restraining fanbar and support bar needs to be reattached. Both support bars are essential as they
hold the installed modules firmly in place. If adjustments are necessary, we recommend doing it from right to
left (Port 11 to Port 0).
STEP 6:
Once you are satisfied with the positioning of both support bars, screw the Four lock screws firmly in place. (It
can require a little juggling to ensure a proper fit.)
STEP 7:
Replace the top cover, by sliding it back into place and tightening the 2 screws at the back.

© Xena Networks - 2017 11
Change BIOS Battery
It can be necessary to replace the BIOS battery. This is a simple operation that involves opening the lid of the
chassis and finding the blue battery mounted on the motherboard on the right side of the chassis.
Simply detach it from the motherboard and you can easily replace the watch or button cell battery.

© Xena Networks - 2017 12
Attaching the Power Cables
There are small differences depending on which test modules you are installing in the Xena Bay.
You need to attach the power cables for some of the modules e.g. Xena’s “tri-speed” 10/401/100G test
module (M1CFP100) and the M2CFP40 require 2 slots in the chassis and have a larger power socket.
The 6-port 10G test module (M6SFP+) has a power socket that is half the size of the M1CFP100 and it
attaches to the test module, using a ‘2-to-1’ adapter as shown below.

© Xena Networks - 2017 13
40GE/100GE Test Module Power Cable
In the photo below you can see these four different test modules:
1. the short six-port M6SFP(B)
2. the mid-size M2SFP+
3. the large M2QSFP+
4. the 2-slot tri-speed M1CFP100

© Xena Networks - 2017 14
1
2
3
4

© Xena Networks - 2017 15
M1CFP100 & M2CFP40
First clip away the black plastic strip holding the power plug and cable in place.
Then connect it to the large plug on the test module:
Once connected, it will look like this:

© Xena Networks - 2017 16
More Information
1. User manuals and other technical documentation (Xena website)
2. Xena technical support options
Or send an email to: [e-mail]
IMPORTANT
ALWAYS REMOVE LONG TEST MODULES BEFORE SHIPPING
To minimize the risk of damage, please remove “long” test modules before transportation. This includes any
test module(s) that extend past the metal restraining bar under the chassis lid.
Always use the original Xena boxes for shipping (including the polystyrene foam and anti-static bags).
