Accessing Extended Features
Overview
This document applies
to the This document enables you to access the extended features of the WorkCentre
7425/7428/7435 in environments that do not have a custom print driver.
stated Xerox
product. It is assumed
that your device is
equipped with the
appropriate option(s)
to support the
information within this
document.
Note: The commands and syntax used in this document requires familiarity with either
PostScript (PS) or Printer Command Language (PCL).
This document provides the Printer Description Language (PDL) commands and syntax
for each feature. The following items are also included:
•A PCL table that describes the PCL features the WorkCentre supports and the syntax
to use the feature.
•A PS table that describes the PS features the WorkCentre supports and the syntax to
use the feature.
This document is not intended to be a complete PS or PCL reference manual. It is a
guide for using the PS and PCL commands with the WorkCentre 7425/7428/7435. Refer
to these sources for additional PS and PCL information:
•PostScript Language Reference Manual, Third Edition, ISBN 0-201-38922-8,
•PCL5 Printer Language Technical Reference Manual
(http://h20000.www2.hp.com/bc/docs/support/SupportManual/bpl13210/bpl13210.pdf),
•Printer Job Language Technical Reference Manual
(http://h20000.www2.hp.com/bc/docs/support/SupportManual/bpl13208/bpl13208.pdf), a
Hewlett-Packard manual.
Using this Guide
Search the Feature Table to determine whether the feature you wish to use is
supported.
Verify that the feature is supported by the platform. For example, the WorkCentre
must have an optional finisher installed to use stapling commands.
Follow across the table to find the syntax listed for the PDL examples shown.
Reference the “Dependencies/Caveats” section when working with PS and/or PCL
commands.
dc09cc0453
Customer Support Page 1

PCL
This WorkCentre supports PCL5e and PCL XL emulations that enable the features listed in the following
table.
Feature Description
Job Name The value for Job Name is stored for printing on the banner page.
Custom Paper Size Customer designated paper size on which to print a job.
Media Size The size of media on which to print a job.
Media Source Specifies the tray to supply the job’s media.
Output Location Indicates the output bin where the completed print job is sent.
Stapling Indicates use and location of staple(s).
Punch Indicates use, location, and number of holes to be punched.
Booklet This command enables you to print documents as booklets. The pages are
reordered sequentially and are oriented so when folded, the paging is
correct.
Collation Collated creates a set that includes 1 copy of each page. Uncollated
creates a stack of multiple copies of the same page.
Resolution Resolution used to image a job.
Quantity Use this command to specify the number of collated sets of a document.
Simplex Delivers one-sided output.
Duplex Delivers two-sided output.
Orientation Delivers output in landscape or portrait orientation.
Force Short Edge
Feeding Rotates orientation of job.
Job Mode Specifies the Job Mode.
Job Type Specifies Confidential Print or Proof Print.
Interleaving Paper
(transparency
separator)
Insert blank media to separate sheets of transparent media.
Job Based
Accounting Allows entry of an accounting code and user ID. To enable this feature the optional Network Accounting kit is required.
Auditron
Delayed Print Specify the time to print a job.
dc09cc0453
Customer Support Page 2

PCL/PJL Implementation
The following table contains the PCL feature commands and shows the syntax required to use the feature.
After the table are examples of how to use these commands and examples of a PCL file.
Feature Implementation Values
Job Name @PJL SET JOBNAME =
"jobname-string" Where jobname-string is a maximum of 32 characters
Custom
Paper Size –
available only
for PCL
You have to specify by PCL:
<ESC>&l101A
Width of Custom Paper is specified by
<ESC>&f#I
where # equals decipoints (89 mm – 320.0
mm).
Length of Custom Paper is specified by
<ESC>&f#J
where # equals decipoints (98 mm – 483
mm).
For instance:
4.25-inch x 5.5-inch will give
<ESC>&f3060I3960J by
4.25-inch x 720 decipoints/inch = 3060
and
5.5-inch x 720 decipoints/inch = 3960
Media Size @PJL SET PAPER = value Where value is one of the following:
A3: A3 (297 x 420mm)
A4: A4 (210 x 297mm)
A5: A5 (148 x 210mm) *
JISB4: B4 (257 x 364mm)
JISB5: B5 (182 x 257mm)
STATEMENT: Statement (5.5 x 8.5”) *
EXECUTIVE: Executive (7.25 x 10.5”) *
LETTER: Letter (8.5 x 11”)
JISEXEC: 8.5 x 13”
LEGAL: Legal (8.5 x 14”)
LEDGER: Tabloid (11 x 17”)
ROC16K = 16K (194 x 267mm) *
ROC8K = 8K (267 x 388mm) *
16KAIGCO = 16K (195 x 270mm) *
8KAIGCO = 8K (270 x 390mm) *
* Whether each paper is available depends on
NV memory setting.
The following paper sizes are only available with
bi-pass tray.
A6: A6 (105 x 148mm)
JISB6: B6 (128 x 182mm)
8X10 = 8 x 10"
SPANISH = 215 x 315mm
11X15 = 11 x 15"
A4COVER = A4 Cover (223 x 297mm)
LETTERCOVER = 9 x 11"
12X18 = Oversized Tabloid (12 x 18")
SA3 = SRA3 (320 x 450mm)
dc09cc0453
Customer Support Page 3

Feature Implementation Values
JPOST = Postcard (100 x 148mm)
JPOSTD = Postcard (148 x 200mm)
POSTCARD = Postcard (4 x 6")
50X70 = 5 x 7"
TYOUKEI3 = Envelope (120 x 235mm)
COM10 = No. 10 Envelope (4.1 x 9.5”)
MONARCH = Monarch Envelope (3.9 x 7.5”)
DL = DL Envelope (110 x 220mm)
C5 = C5 Envelope (162 x 229mm)
<ESC>&l int A Where int is one of the following:
25 = A5 (148 x 210mm) *
26 = A4 (210 x 297mm)
27 = A3 (297 x 420mm)
45 = B5 (182 x 257mm)
46 = B4 (257 x 364mm)
41 = Statement (5.5 x 8.5") *
1= Executive (7.25 x 10.5") *
2= Letter (8.5 x 11")
18 = 8.5 x 13"
3= Legal (8.5 x 14")
6= Tabloid (11 x 17")
219 = 16K (194 x 267mm) *
220 = 8K (267 x 388mm) *
* Whether each paper is available depends
on NV memory setting.
The following paper sizes are only available with
bypass tray.
24 = A6 (105 x 148mm)
44 = B6 (128 x 182mm)
208 = 8 x 10"
43 = 215 x 315mm
217 = 11 x 15"
200 = A4 Cover (223 x 297mm)
201 = 9 x 11"
213 = Oversized Tabloid (12 x 18")
197 = SRA3 (320 x 450mm)
71 = Postcard (100 x 148mm)
72 = Postcard (148 x 200mm)
216 = Postcard (4 x 6")
204 = 5 x 7"
218 = Envelope (120 x 235mm)
81 = No. 10 Envelope (4.1 x 9.5”)
80 = Monarch Envelope (3.9 x 7.5”)
90 = DL Envelope (110 x 220mm)
91 = C5 Envelope (162 x 229mm)
dc09cc0453
Customer Support Page 4

Feature Implementation Values
Media
Source @PJL SET MEDIASOURCE = value Where value is one of the following:
TRAY1: Feed from paper tray1
TRAY2: Tray2
TRAY3: Tray3
TRAY4: Tray4
TRAY5: Tray5 (Bypass)
<ESC>&l int H Where int is one of the following:
0: Feed paper from default tray
4: Tray1
1: Tray2
5: Tray3
8: Tray4
20 = Auto
2or 3= Tray5 (Bypass)
Output
Location @PJL SET OUTBIN = value Where value is one of the following:
UPPER: Center Tray
MAINTRAY: Center Tray
CENTERTRAY: Center Tray
MAINTRAY2: Center Tray - Upper
LOWER: Left Top Tray (Face Up)
SIDETRAY: Left Top Tray (Face Up)
MAINTRAY3: Right Top Tray (w/ B-Finisher
or C-Finisher)
OUTBIN101: Finisher Tray (w/ A-Finisher or
B-Finisher or C-Finisher)
BOOKLETTRAY: Right Bottom
Tray(Booklet Maker) (w/
C-Finisher and booklet
module)
<ESC>&l int G Where int is one of the following:
0: Automatic Selection
1: Center Tray
2: Left Top Tray (Face Up)
4: Center Tray - Upper
6: Finisher tray (w/ finisher)
Stapling @PJL SET STAPLE = value Where value is one of the following:
TOPDUAL
TOPLEFT
TOPRIGHT
BOTTOMDUAL
BOTTOMLEFT
BOTTOMRIGHT
LEFTDUAL
RIGHTDUAL
SADDLE
NONE
dc09cc0453
Customer Support Page 5

Feature Implementation Values
Punch @PJL SET PUNCH =
value1
@PJL SET JOBATTR =
”@PNHN = value2”
Where value1 is one of the following:
TOP
RIGHT
LEFT
BOTTOM
NONE
Where value2 is one of the following:
TWO: 2 holes
THREE: 3 holes
FOUR: 4 holes
Folding @PJL SET JOBATTR =
"@FOLD = value1" Where value1 is one of the following: BIFOLDINSIDE ：Bi-Folding(single page)
BIFOLDMULTIOUTSIDE：Bi-Folding(multi
page)
The "Collated" feature needs to be enabled for
the booklet functions to work.
Booklet @PJL SET JOBATTR =
“@BKLT = value1”
@PJL SET JOBATTR =
“@BKSG = value2”
@PJL SET JOBATTR =
“@BKDN = int1”
@PJL SET JOBATTR =
“@BKDN = int2”
Where value1 is one of the following:
NONEDIVIDE: Compile a booklet as long
as the number of sheet does not exceed the
limit
AUTODIVIDE: Divide sheets into sets
automatically in case of exceeding the limit
number of sheets.
MANUALDIVIDE : Divide sheets based on
the specified limit manually
OFF : Do not compile a booklet
Where value2 is one of the following:
RIGHT = Right to left page order binding
LEFT = Left to right page order binding
Where int1 is:
1-9999 = Booklet dividing number for each
set
Where int2 is:
1 - 9999 = Booklet total pages of document
Collation @PJL SET QTY = int Where int is:
1 - 999
Resolution @PJL SET RESOLUTION =
value Where value is one of the following:
600
1200
Bits Per Pixel @PJL SET BITSPERPIXEL
= value Where value is one of the following:
1: 1 bit per pixel (per plane)
Quantity @PJL SET COPIES = int Where int is:
1-999
(This parameter used for uncollated mode.)
dc09cc0453
Customer Support Page 6

Feature Implementation Values
<ESC>&l int X Where int is:
1-999
@PJL SET DUPLEX =
value1 Where value1 is one of the following:
OFF: simplex
Simplex
<ESC>&l int s Where int is one of the following:
0: simplex
@PJL SET DUPLEX =
value1
@PJL SET BINDING =
value2
Where value1 is one of the following:
ON: duplex
Where value2 is one of the following:
LONGEDGE
SHORTEDGE
(value2 is used combined with value1 = ON)
Duplex
<ESC>&l int s Where int is one of the following:
1: Duplex Long Edge Binding
2: Duplex Short Edge Binding
@PJL SET ORIENTATION
= value Where value is one of the following:
PORTRAIT
LANDSCAPE
Orientation
<ESC>&l int O Where int is one of the following:
0: Portrait
1: Landscape
2: Reverse Portrait
3: Reverse Landscape
Force short
edge feeding @PJL SET PAPERDIRECTION = value Where value is one of the following:
SEF: Short Edge Feed
LEF: Long Edge Feed
Job Mode @PJL JOB MODE = value Where value is one of the following:
PRINTER for Printer
Job Type @PJL SET HOLD = value1
(See Example 3)
@PJL SET HOLDKEY
="four-digit string"
(See Example 4)
Where value1 is one of the following:
PROOF: proof print
STORE: confidential print (secure print)
The HOLDKEY variable acts as a password
without encryption to protect a held job.
Four-digit string can be any four-digit value
from 0000 to 9999. The default value is "".
When "" (null) is specified, no password is
required.
Interleaving
Paper
(Transparency
Separator)
@PJL SET SLIPSHEET =
value Where value is one of the following:
OFF: no slipsheet
BLANK: blank slipsheet
COPY: imaged slipsheet
dc09cc0453
Customer Support Page 7

Feature Implementation Values
Job Based
Accounting
Or
Auditron
@PJL SET JOBATTR =
"@JOAU = string1"
@PJL SET JOBATTR =
"@JOAP = string2"
@PJL SET JOBATTR =
"@DAID = string3"
Where string1 is a maximum of 32 characters
(ASCII characters in the range 20h - 7EH
only) as job owner (Capital character & small
character is distinguished)
Where string2 is a maximum of 12 characters
(ASCII characters in the range 20h - 7Eh only)
as password without encryption. It can be null
(zero length string)
Where string3 is a maximum of 32 characters
(ASCII characters in the range 20h - 7Eh only)
as account ID. It can be null (zero length
string)
Note: Auditron and JBA cannot be used at the
same time. So the same command works for
both modes.
Delay Print @PJL SET JOBATTR =
"@PRTM =
YYYY:MM:DD:hh:mm"
YYYY:MM:DD:hh:mm
YYYY: year (AD 2000 - 2099)
MM: month (1 - 12)
DD: day (1 - 31)
hh: hour (0 - 23)
mm: minute (0 - 59)
Banner Sheet @PJL SET JOBATTR=
"@BANR=value" Where value is one of the following: START: start sheet
DEVICE: depend on device setting
OFF: no banner sheet
PJL Template
This section illustrates a standard PJL template that is used to access general print features as
well as WorkCentre Product specific features. This template lists each feature and the syntax,
both PCL commands and PJL, required to use these features. The next section of this document
contains other examples of how to use these commands.
Section 1 (Opening Command, Required for all files)
<ESC>%-12345X@PJL JOB MODE=PRINTER
Section 2 (PJL Set Commands)
@PJL SET RESOLUTION=600
@PJL SET COPIES=1
Section 3 (PCL Code used to invoke PCL Language)
@PJL ENTER LANGUAGE=PCL
Section 4 (PCL Data Stream or ASCII Document inserted here for Options such as
selection Different Fonts, Simplex, Duplex, etc.)
,,,,,,,,,,
Section 5 (Closing Command, Required at end of Document)
<ESC>%-12345X@PJL EOJ
dc09cc0453
Customer Support Page 8

Sample PJL Headers
This section contains examples of these commands in use.
Example 1 Simple Print
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL COMMENT Beginning PCL Job<CR><LF>
@PJL SET OUTBIN=MAINTRAY<CR><LF>
@PJL SET QTY=1<CR><LF>
@PJL SET RESOLUTION=600<CR><LF>
@PJL SET JOBATTR="@JOAU=John"<CR><LF>
Example 2 Finishing Options (Stapling)
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=OUTBIN101<CR><LF>
@PJL SET FINISH=ON<CR><LF>
@PJL SET STAPLE=TOPLEFT<CR><LF>
Example 3 Finishing Options (Punch)
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=OUTPIN101<CR><LF>
@PJL SET FINISH=ON<CR><LF>
@PJL SET PUNCH=LEFT<CR><LF>
@PJL SET JOBATTR="@PNHN=TWO"<CR><LF>
Example 4 Finishing Options (Saddle stapling and folding)
It is an example of division in every 5 sheets.
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=BOOKLETTRAY<CR><LF>
@PJL SET FINISH=ON<CR><LF>
@PJL SET STAPLE=SADDLE<CR><LF>
@PJL SET JOBATTR="@FOLD=BIFOLDMULTIOUTSIDE"<CR><LF>
@PJL SET JOBATTR="@BKLT=MANUALDIVIDE"<CR><LF>
@PJL SET JOBATTR="@BKSG=LEFT"<CR><LF>
@PJL SET JOBATTR="@BKDN=5"<CR><LF>
Example 5 Finishing Options (Bi-Folding(multi page))
It is an example of division in every 5 sheets.
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=BOOKLETTRAY<CR><LF>
@PJL SET FINISH=NONE<CR><LF>
@PJL SET STAPLE=NONE <CR><LF>
@PJL SET JOBATTR="@FOLD=BIFOLDMULTIOUTSIDE"<CR><LF>
@PJL SET JOBATTR="@BKLT=MANUALDIVIDE"<CR><LF>
@PJL SET JOBATTR="@BKSG=LEFT"<CR><LF>
@PJL SET JOBATTR="@BKDN=5"<CR><LF>
@PJL SET QTY=1<CR><LF>
dc09cc0453
Customer Support Page 9

Example 6 Finishing Options (Bi-Folding(single page))
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=BOOKLETTRAY<CR><LF>
@PJL SET FINISH=NONE<CR><LF>
@PJL SET STAPLE=NONE <CR><LF>
@PJL SET JOBATTR="@FOLD=BIFOLDINSIDE"<CR><LF>
@PJL SET JOBATTR="@BKSG=LEFT"<CR><LF>
Example 7 Proof Print
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET HOLD=PROOF <CR><LF>
@PJL SET USERNAME="John" <CR><LF>
@PJL SET JOBNAME="Job1" <CR><LF>
Example 8 Confidential (Secure) Print without encryption
Password: 1234
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET HOLD=STORE <CR><LF>
@PJL SET HOLDKEY="1234"<CR><LF>
@PJL SET USERNAME="John" <CR><LF>
@PJL SET JOBNAME="Job1" <CR><LF>
Example 9 Banner Sheet
banner: start sheet
@PJL SET JOBATTR="@BANR=START"<CR><LF>
@PJL SET JOBATTR="@BCMT=Banner Comment String"<CR><LF>
Example 10 Job Based Accounting & Auditron
userID: Patricia, Password: none, accountID: none
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET JOBATTR="@JOAU=Patricia"<CR><LF>
@PJL SET JOBATTR="@JOAP="<CR><LF>
@PJL SET JOBATTR="@DAID="<CR><LF>
dc09cc0453
Customer Support Page 10
