XFIRE AUDIO DECIMATOR XFR10D11 User manual

AUDIO
XFR10D11/22 DECIMATOR
Extreme subwoofers
Owners manual
xfireaudio.com

A
C
B
D
E
F
Introduction
Congratulations on purchasing one of the finest autosound subwoofers in existence.
Born in the U.S.A from rigorous pursuits of exceptional sound, strength, performance, and style delivering kick ass mo-
bile audio! Relentless pride and passion with 30 plus years of experience and excellence in the 12 volt industry.
It’s Your Music, It’s Your Style, It’s Your Life, AMPLIFIED!
Purchase and serial number information. Record your new XFIRE AUDIO product information for future reference.
Purchase date
Retailer
Model #
Serial #
Welcome to XFIRE AUDIO ‘‘The New Breed Of Mobile Audio’’.
XFR DECIMATOR series subwoofers emit outstanding sonic reproduction and accuracy to downright nasty all out audio
aggression when you want it loud.
t %JFDBTUi%VSB'SBNFwCMBDLQPXEFSCBTLFUXJUIi%JSFDU$PJM$PPMJOHw
t 240ounce triple stacked ferrite magnet assembly
t Chrome machinedT-Yokes with XFIRE logo punched back plate
t wMBZFSDPQQFSWPJDFDPJMT
t 6MUSBMJHIUXFJHIUCMBDLDBSCPOmCFSDPOFXJUIi1SFDJTJPO-JOFBS%SJWFwEVBMTUJUDIFESFTJOmCFSTVSSPVOE
t i2VBE$PSFw$POFY4QJEFSBTTFNCMZVUJMJ[JOHJOEVTUSJBMXPWFOEVBMUJOTFMMFBET
t 9'*3&i4FDVSF4FBMwHBTLFU
XFR DECIMATOR series subwoofers; a force to be reckoned with. Power, Performance, Integrity!
Features
decimator series Life Amplified
XFR10D11/22
Diameter A 10.9’’- 277mm
Diameter B 9.4’’- 239mm
Diameter C 7.7’’- 195mm
Height D 3.5’’- 88mm
Height E 7’’- 177mm
Height F 0.7’’- 17mm
Dimensions

decimator series Life Amplified
Specifications
XFR10D11 XFR10D22
RMS Power 1500W 1500W
Max Power 4500W 4500W
Impedance Dual 1ΩDual 2Ω
Response )[ )[
Sensitivity 84.5dB 84.0dB
Fs )[ )[
Qms 6.39 6.49
Qes 0.33 0.43
Qts 0.31 0.40
Vas 0.38ft3- 10.8L 0.28ft3 - 7.9L
Re 2.0Ω4.0Ω
BL 19.0N/A 25.5N/A
Le 1.89mH 3.06mH
Sd 51.2sq’’- 330cm251.2sq’’- 330cm2
x-max, 1-way 1.18’’- 30mm 1.18’’- 30mm
All specifications are subject to change without notification due to continual product improvements.
9'3%&$*."503TFSJFTTVCXPPGFSTBSFEFTJHOFEGPSIJHIPVUQVUTZTUFNTBOEIBWFTVTQFOTJPOTPQUJNJ[FEGPSFYUSFNF
excursion in ported enclosures.
In this manual there are two, single subwoofer vented enclosure designs. One is a minimum recommended enclosure
option while the other is for optimal design for the best possible sound.
In addition there is an optimum dual XFR DECIMATOR series subwoofer vented enclosure design.
"MMEJNFOTJPOTHJWFOBSFJOUFSOBMEJNFOTJPOT9'*3&"6%*0BEWJ[FTUPVTFNJOJNVNNNUIJDLQBOFMTGPSBMMUIF
TJEFTBOENNUIJDLGSPOUQBOFM
Enclosure

decimator series Life Amplified
Gross volume Net volue Slot port Port length
1x XFR10D11/22
Minimum 1.48 ft3- 42 L 1.10 ft3- 31.1 L 17.6 sq’’- 114 cm222 ’’- 56 cm
1x XFR10D11/22
Optimum 2.27 ft3- 64.5 L 1.75 ft3- 49.5 L 28 sq’’- 180 cm221.5 ’’- 54.5 cm
2x XFR10D11/22
Optimum 4.55 ft3- 129 L 3.50 ft3- 99 L 56 sq’’- 360 cm221.5 ’’- 54.5 cm
Vented subwoofer enclosures
XFIRE AUDIO limited warranty.
64"XBSSBOUZEBZTZFBSJGJOTUBMMFECZBOBVUIPSJ[FEEFBMFS
8IBUJTDPWFSFE5IJTXBSSBOUZBQQMJFTPOMZUP9'*3&"6%*0QSPEVDUTTPMEUPDPOTVNFSTCZBVUIPSJ[FEEFBMFSTJOUIF64"1SPEVDUTQVSDIBTFECZ
DPOTVNFSTGSPNBOBVUIPSJ[FEEFBMFSJOBOPUIFSDPVOUSZBSFDPWFSFEPOMZCZUIBUDPVOUSZTEJTUSJCVUPS
8IPJTDPWFSFE5IFPSJHJOBMQVSDIBTFSPG9'*3&"6%*0QSPEVDUCPVHIUGSPNBOBVUIPSJ[FEEFBMFSJOUIF64"5PSFDFJWFXBSSBOUZUIFPSJHJOBMQVS-
chaser must provide a copy of the receipt with customer name, dealer, XFIRE model purchased with the date of purchase. Please retain all receipts
for warranty purposes should they be needed.Warranty is not transferable.
1SPEVDUTGPVOEUPCFEFGFDUJWFEVSJOHUIFXBSSBOUZQFSJPEXJMMCFSFQMBDFEXJUIBQSPEVDUEFFNFEFRVJWBMFOUBUUIFEJTDSFUJPOPG9'*3&"6%*0
What is NOT covered:
t "CVTFJODMVEJOHCVSOUWPJDFDPJMTJNQSPQFSJOTUBMMBUJPOPQFSBUJOHQSPEVDUPUIFSUIBOXIJDIJUXBTEFTJHOFEXBUFSEBNBHFUIFGUQSPEVDU
damage from vehicle accidents, or shipping damages.
t Any costs incurred for removal or reinstallation.
t Any product with altered, defaced or removed serial numbers.
t Damage to other components.
t 1SPEVDUTQVSDIBTFEGSPNVOBVUIPSJ[FEEFBMFSTSFUBJMFSTPSJOUFSOFUTJUFT
Buyers beware of the Internet. ANY XFIRE AUDIO product bought online that is NOT from and AUTHORIZED dealer will void any and all warranty. Limit
on implied warranties: Any implied warranties including warranties of fitness for use and merchantability are limited in duration to the period of
the express warranty set forth above. Some states do not allow limitations on the length of an implied warranty, thus limitations may not apply. No
person shall assume for XFIRE AUDIO any other liability in connection with the sale of products.
0CUBJOJOHXBSSBOUZ$POUBDUZPVSMPDBMBVUIPSJ[FEEFBMFS
Should you need additional assistance please email XFIRE AUDIO : salesusa@xfireaudio.com
©2016 XFIRE AUDIO ® LLC. All rights reserved.
‘‘XFIRE AUDIO’’, ‘‘LIFE AMPLIFIED’’, and ‘‘THE NEW BREED OF MOBILE AUDIO’’are either registered trademarks or trademarks of XFIRE AUDIO LLC.
