Xiamen Smarttek PCT513-TY User manual

PCT513-TY
Wi-Fi Touchscreen Thermostat
Quick Start Guide

2
Safety Handling
WARNING: Failure to follow these safety notices could result in fire,
electric shock, other injuries, or damage to the Thermostat and other
property. Read all the safety notices below before using the Thermostat.
• Avoid high humidity or extreme temperatures.
• Avoid long exposure to direct sunlight or strong ultraviolet light.
• Do not drop or expose the unit to intense vibration.
• Do not disassemble or try to repair the unit on your own.
• Do not expose the unit or its accessories to 󽗊ammable
liquids, gases or other explosives.

Part 1 Welcome
Page4 A brief introduction to the smart thermostat
Part 2 In the box
Page4 Products in the box
Part 3 Installation Guide
Page5-8 Check your old thermostat, and choose the guide you need
Page9-12 Installing with a C-wire
Page13-21 Installing without a C-wire (Optional)
Page22-24 Wiring diagrams
Part 4 Further setup your device
Page26-29 Con󽗉guration of thermostat
Part 5 Meet Your Thermostat
Page30-33 Introduction of main interfaces
Page34-39 The prompt appears on the interface and menu overview
Page39-41 App Overview
Part 6 FAQ
Page42 How to pair the thermostat with zone sensors?
Page43 Wi-Fi con󽗉guration of the thermostat failed
Page43 Device o󽗌ine
Page44-47 Con󽗉gure the network in AP mode
Page48-50 Technical speci󽗉cations
Overview of this guide

4
Welcome
1
The Wi-Fi Touchscreen thermostat makes it easier and smarter to control
your household temperature. With the help of zone sensors, you can
balance hot or cold spots throughout the home to achieve best comfort.
You can schedule your thermostat working hours so it will work based on
your plan.
This guide will provide you with an overview of the product and will help
you understand how to use it.
In the box
2
PCT513
Wi-Fi Touchscreen Thermostat
Power module SWB511
(optional)
Remote Zone Sensor
(optional)
Wall Plate
User guide
PCT513 Wi-Fi Touchscreen Thermostat
Quick Start Guide
2*Screws 2*Drywall plugs
Wire Tags
Label 1.
Label 2.
Thermostat
If you have a C
wire, you will not
need the label 2
below.
Control board
C C
RC RC
RC RC
RH RH
R R
C C
S S
G G
R R
RC RC
RH RH Y2 Y2
Y/Y1 Y/Y1
Y/Y1 Y/Y1
W/W1 W/W1
W/W1 W/W1
W2 W2
O/B O/B
* *
G G

5
RC RH G C
Y1 Y2 W1 W2 O/B
Step 1. Switch o󽗈 your HVAC system
Before you start, please switch off your HVAC system to protect you and
avoid blowing a fuse. Wait a few minutes, try to adjust the temperature in
your old thermostat to double check if the system is o󽗈.
Installation Guide
3
3-1 Removing your old thermostat
Step 2. Remove the old thermostat
Remove the old thermostat from the wall, keep the wallplate with wires.
Do not remove
the wallplate
Old thermostat
Breaker box Switch

6
Step 4. Take a photo
Take a picture of the wires connected to the terminal of your old
thermostat. You may need to reference this photo later.
RC RH G C
Y1 Y2 W1 W2 O/B
Step 3. Compatibility Check
If you find a thick wire with wire nuts on the backplate of the old
thermostat, or if the voltage of your old system is 120v or higher, it will not
be compatibled with PCT513. If none of the above, then please proceed to
the next step.
OR
120V
or
higher

7
RC RH G C
Y1 Y2 W1W2 O/B
C
RC
G
W1
Y1
RC RH G C
Y1 Y2 W1W2 O/B
C
RC
G
W1
Y1
Step 5. Label the Wires with Tags
Label each wire on the wallplate with the tags (label 1) provided. Then
carefully disconnect the wires.
Note: If there are any jumper wires between Rh, Rc, or R terminals, do not
label them. PCT513 does not need jumpers. Remove them and save along
with your old thermostat.
Remove

8
Terminal designation:
Terminals What it means
RC 24VAC primary for cooling
RH 24VAC primary for heating
C24VAC common
W1 1st stage Primary heating relay / Aux heat
W2 2nd stage Secondary heating relay / Aux heat
Y1 1st stage Primary compressor contactor
Y2 2nd stage Secondary compressor contactor
GFan relay
O/B Changeover valve for heat pumps
SOptional wiring module terminal to combine Y and G, while
reserve an extra in-wall wire to power on the thermostat
Do you have a C wire connected to your old thermostat?
3-2 Connect wires
RC RH G C
Y1 Y2 W1W2 O/B
RC
G
Y1
W1
C
YES  3-2-1 NO  3-2-2

9
3-2-1 Install the thermostat with a
C-wire
Step 1. Remove the wallplate
Unscrew the wallplate from the wall, gently pull it out to ensure the wires
will not fall back into the hole.
Step 2. Attach the base of PCT513 to the wall
Bundle and insert the wires through the hole of wall plate and the base of
PCT513, then attach the base to the wall with the screws.
RC RH G C
Y1 Y2 W1W2 O/B
C
RC
G
W1
Y1
↑
↑
↑
↑
Wall plate
Base

10
Step 3. Connect the wires
Connect wires to the corresponding terminal in the base. Take a picture of
the wires when you 󽗉nished. You may need to refer it for the wirings in the
setup wizard later.
Do you have more than one R wire (R, RC, and RH)?
NO：
R, RC, or RH wire into the RC terminal
R or RC wire into the RC terminal
RH wire into the RH terminal
YES：
G
S
Y1
Y2
M1
M2
RC
C
RH
O/B
W1
W2
W1
R/RC/RH
C
G
Y1
G
S
Y1
Y2
M1
M2
RC
C
RH
O/B
W1
W2
W1
R/RC
C
G
Y1
RH

11
Step 4. DIP Switch
Adjust the DIP switch on the back of the thermostat to 'Disconnect' if
you have connected both the RC-wire and the RH-wire to the wallplate,
otherwise, switch it to the 'Connect' side.
RC&RH
Connect
Disconnect
DIP switch
Step 5. Attach the PCT513 to the base
Gently press the PCT513 into the base until it clicks.
→→
→
→

12
Step 6. Power on your system
Congratulation! The installation is finished. Please power on your HVAC
system.
When the power is successfully energized, the thermostat's screen will
light up and go into wizard. You can complete the following con󽗉guration
according to section 4.
Breaker box Switch
Hi,
Welcome

13
Power module requires your system to have the following wires:
4 wires: W/W1, Y/Y1, G, and R (or Rc or Rh)
or 3 wires: Y/Y1, G, and R (or Rc or Rh)
If you do not have these wires, your system may not be
compatible with the power module.
3-2-2 Install the thermostat without a
C-wire (Optional)
RC RH G C
Y1 Y2 W1W2 O/B
RC
G
Y1
W1
Power module

14
Power module
To thermostatTo HVAC control board
The C-wire is used to provide power to the thermostat. If your system does
not have "C" wire, you can use the power module to power your thermostat
using the exiting wires.
There are two sides with connections. One side (4 terminals) is for
thermostat connections, the other side, pre-wired (5 terminals), is for the
control board connections.
Description:

15
WC G Y R
Control Board
W
R
G
Y
Step 1. Find the HVAC terminals
Find the control board of your HVAC system. Open your HVAC system’s
cover and take a picture of the wires connected to the terminals of your old
thermostat. You may need to reference this photo later.
To thermostat
Step 2. Label the wires
Label only the wires from the control board to your old thermostat with the
tags provided (label 2 control board).
WCG Y R
HVAC
Control Board
→→
W C G Y R
Label 1.
Label 2.
Thermostat
If you have a C
wire, you will not
need the label 2
below.
Control board
C C
RC RC
RC RC
RH RH
R R
C C
S S
G G
R R
RC RC
RH RH Y2 Y2
Y/Y1 Y/Y1
Y/Y1 Y/Y1
W/W1 W/W1
W/W1 W/W1
W2 W2
O/B O/B
* *
G G

16
R
Y
G
W
Control Board
W
R
G
Y
↓
W C G Y R
To thermostat
Step 3. Disconnect the wires
Disconnect the W/W1, G, Y/Y1, R wires from the control board.
Step 4. Connect the wiring module
Reconnect them correspondingly to the 4 terminals side of the power
module.
RRC W/W1W GC Y/Y1S
To thermostat
Power module

17
HVAC Control Board
WC G Y R
Power module
R
Y
G
W
Step 6. Position the wiring module
The power module should be installed between your thermostat wiring and
your control board. Install it at the right position then close the HVAC cover
panel securely and return to your thermostat.
Step 5. Connect the wires
Generally, the control board will have W, C, G, Y, R terminal, connect the
pre-wired side of the power module (5 terminals) to the corresponding
terminals.
To HVAC control board To thermostat

18
RC RH G C
Y1 Y2 W1W2 O/B
RC
RC
G
C
S
W1
Y1
↑
↑
Step 8. Remove the wallplate
Unscrew the wallplate from the wall, gently pull it out and ensure the wires
will not fall back into the hole.
Step 7. Add new tags
Add new tags to the following tags to simplify your wiring:
R/RC/RH RC G
 C Y/Y1 S
RC RH G C
Y1 Y2 W1 W2 O/B
RC
RC
C
G
W1
Y1
S
Label 1.
Label 2.
Thermostat
If you have a C
wire, you will not
need the label 2
below.
Control board
C C
RC RC
RC RC
RH RH
R R
C C
S S
G G
R R
RC RC
RH RH Y2 Y2
Y/Y1 Y/Y1
Y/Y1 Y/Y1
W/W1 W/W1
W/W1 W/W1
W2 W2
O/B O/B
* *
G G

19
Step 9. Attach the base of PCT513 to the wall
Bundle and insert the wires through the hole of wall plate and the base of
PCT513, then attach the base to the wall with the screws.
Step 10. Connect the wires
First, connect 3 wires as shown below：
RC, C, S
G
S
Y1
Y2
M1
M2
RC
C
RH
O/B
W1
W2
RC
RC
G
C
W1
Y1
S
↑
Then connect other wires to the corresponding terminal in the base. Take
a picture of the wires when you 󽗉nished. You may need to refer it for the
wirings in the setup wizard later.
↑
↑
Wall plate
Base

20
Step 11. DIP Switch
Adjust the DIP switch on the back of the thermostat to the 'Connect' side.
Step 12. Attach the PCT513 to the base
Gently press the PCT513 into the base until it clicks.
→→
→
→
RC&RH
Connect
Disconnect
DIP switch
