Xiaomi Smart Camera C500 Pro User Manual

Product Overview
Read this manual carefully before use, and retain it for future
reference.
Note: Illustrations of product, accessories, and user interface in the
user manual are for reference purposes only. Actual product and
functions may vary due to product enhancements.
Package Contents: Xiaomi Smart Camera C500 Pro, charging cable,
wall mounting kit, user manual, warranty notice
1
Lens
Microphone
Indicator
MicroSD Card Slot
(visible when
the lens is facing
upward)
Loudspeaker
Type-C
Power Port
Front View Rear View

How to Install
The camera can be placed on flat surfaces, such as desks, dining
tables, and coee tables. It can also be mounted on a wall.
Mounting the Camera on a Wall:
1. First use a pencil to mark the positions for the base mounting holes
on the wall, then drill two holes at the marked positions. The diameter
of each hole is approximately 6 mm, and the depth is approximately
30 mm.
2. Insert the plastic wall plugs into the drilled holes.
3. Place the side of the base with arrows facing outward, then align
the holes. Insert the screws and then tighten them into the wall plugs
with a Phillips head screwdriver.
on the base, then turn it clockwise until it locks into place.
2

The wall must be able to support at least three times the total
weight of the camera.
How to Use
Precaution for Mounting the Camera on a Wall
Installing a MicroSD Card
Make sure that the power to the camera is already disconnected.
Adjust the lens upward until the microSD card slot is revealed, then
insert the microSD card into the slot (the side with contact points
must be facing down).
Unplug the camera when installing or removing the microSD card.
Please use a microSD card (a minimum capacity of 8 GB and above,
and a maximum capacity of 256 GB and below) from a qualified
brand . It is recommended that the microSD card has a read/write
speed of no less than U1/Class 10.
WARNINGS
The camera must be securely fixed to the ceiling or wall
according to the installation instructions to prevent possible
injury.
3

microSD
Turning On
Indicator
Keeping blue: Connected successfully/Working normally
Blinking blue: Network error
Blinking orange quickly: To be connected
Blinking orange slowly: Updating
Plug the charging cable into the Type-C power port on the back of
the camera, the camera automatically turns on, and the indicator
quickly blinks orange.
Note: When the camera is working, do not turn the camera nor
force it to rotate. If the positioning of the lens is inaccurate, please
calibrate it in the Mi Home/Xiaomi Home app.
Note: Please make sure to use the LPS adapter cable for connection
to avoid abnormal operations.
4

Connecting with the Mi Home/Xiaomi Home App
This product works with the Mi Home/Xiaomi Home app*. Control
your device with Mi Home/Xiaomi Home app.
Note: The version of the app might have been updated, please follow
the instructions based on the current app version. Make sure the
camera turns on and the network connection is stable during
connecting. The indicator is quickly blinking orange when waiting for
a connection, and turns into blue once the camera is successfully
connected.
In case of changing the network that the camera is connected to or
the Xiaomi Account in the Mi Home/Xiaomi Home app that the
seconds. Once the indicator blinks orange quickly, the camera is
Mi Home/Xiaomi Home app.
microSD card.
Scan the QR code to download and install the app.
You will be directed to the connection setup page
if the app is installed already. Or search for
"Mi Home/Xiaomi Home" in the app store to
download and install it.
Open the Mi Home/Xiaomi Home app, tap "+" on
the upper right, and then follow the instructions
to add your device.
* The app is referred to as Xiaomi Home app in Europe (except for
Russia). The name of the app displayed on your device should be
taken as the default.
F61E1A4F
5
Restoring Factory Settings
camera is paired with, press and hold the reset button for about 7
restored to factory settings, and then reconnect the camera with the
Note: Restoring factory settings will not delete the content on the

Real-time Surveillance
Infrared Night Vision
In the camera's plugin of the Mi Home/Xiaomi Home app, you can
view the real-time surveillance screen, adjust the sharpness of the
image, change the horizontal and vertical angle of the camera,
capture and record the screen, and make remote calls.
The camera can automatically switch to night vision mode at night
according to the change in ambient light. With built-in infrared night
vision lights, the camera can clearly capture images/videos in the dark.
For the automatic turning on of the night mode, complete darkness is
required, otherwise, the night vision may not be automatically turned on.
Playback
6
The playback feature of the camera is only available when
a compatible microSD card is installed or a cloud storage service
is purchased for the camera.
In the camera's plugin of the Mi Home/Xiaomi Home app, tap the
playback button to enter the playback interface, then drag the
timeline to select the time period to be played back. Variable speed
playback is supported.

When the home surveillance assistant feature is enabled, the
camera will record videos if it detects human movement and
changes in real-time within its monitored area. Then you will get the
app push notification.
You can enable or disable the home surveillance assistant feature
in the camera's plugin of the app.
time meeting your demands. Alert sensitivity and alert time
intervals can also be customized in the app.
Automatic Surveillance
Area Surveillance
When the area surveillance feature is enabled, the camera will set
specific surveillance scenes for family members, such as "key areas
monitoring" and "no motion detected for a long time" scenes. Users
area occur, you will get the app notification to get the status of family
members in time.
You can enable or disable the area surveillance feature via AI features
page on the camera's plugin homepage in the Mi Home/Xiaomi Home
app.
7
You can set surveillance of all-day, daytime, nighttime, or any other
can edit the surveilled areas and set the surveillance time. After the
settings are completed, when events like someone entering the key

In the camera's plugin of the Mi Home/Xiaomi Home app, you can
camera with others. The person the camera is shared with needs to
download the Mi Home/Xiaomi Home app and sign in with a Xiaomi
Account.
Video Sharing
When you don't need to use the camera, you can tap " " on the
real-time footage screen of the camera's plugin in the Mi Home/Xiaomi
Home app to enter the physical lens blocking status. You can also go to
the physical lens blocking feature or set scheduled automatic physical
lens blocking. The camera will automatically adjust the lens so that it is
covered by the casing of the camera itself to protect the user's privacy.
Physical Lens Blocking
8
select the device sharing option in the settings menu to share the
Settings > Camera settings > Physical lens blocking settings to enable

Name: Xiaomi Smart Camera C500 Pro
Net Weight: Approx. 301 g
Item Dimensions: 124 × 78 × 78 mm
Resolution: 2960 × 1666
Operating Temperature: -10°C to 40°C
Wireless Connectivity: Wi-Fi IEEE 802.11 a/b/g/n 2.4 GHz/5 GHz,
Bluetooth 5.2
Storage: MicroSD card (a minimum capacity of 8 GB and above, and a
maximum capacity of 256 GB and below)
Wi-Fi Maximum Output Power:
2400–2483.5 MHz, <20 dBm
5150–5350 MHz, <23 dBm
5470–5725 MHz, <23 dBm
5725–5850 MHz, <14 dBm
Bluetooth Maximum Output Power: 2402–2480 MHz, <10 dBm
The operating temperature range for this camera is between -10°C
and 40°C. Do not use the camera in environments with
temperatures above or below the specified range.
The camera is a precision electronic product. In order to ensure its
normal operation, do not install the camera in environments with
high humidity levels nor allow water to get into it.
To ensure the camera's performance, do not place its lens facing or
next to a reflective surface, such as glass windows or white walls, as
this will cause the image to appear overly bright in areas close to
the camera and darker in areas further away, or cause the camera
Specifications
Cautions
Model: MJSXJ16CM
Input: 5 V 2 A
Video Codec: H.265
9

WEEE Information
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU) which
should not be mixed with unsorted household waste. Instead,
you should protect human health and the environment by
handing over your waste equipment to a designated collection point
for the recycling of waste electrical and electronic equipment,
appointed by the government or local authorities. Correct disposal
and recycling will help prevent potential negative consequences to
the environment and human health. Please contact the installer or
local authorities for more information about the location as well as
terms and conditions of such collection points.
EU Declaration of Conformity
Hereby, Shanghai Imilab Technology Co., Ltd. declares that the
radio equipment type Xiaomi Smart Camera C500 Pro is in
compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
to produce white images.
Make sure the camera is installed in an area with a strong Wi-Fi
signal. Do not place the camera near objects that may aect its
Wi-Fi signal, such as metal objects and microwave ovens.
Under normal use of condition, this equipment should be kept a
separation distance of at least 20 cm between the antenna and the
body of the user.
10

Restrictions in the 5 GHz band:
According to Article 10 (10) of Directive 2014/53/EU, the packaging
shows that this radio equipment will be subject to some restrictions
when placed on the market in Belgium (BE), Bulgaria (BG), the Czech
Republic (CZ), Denmark (DK), Germany (DE), Estonia (EE), Ireland (IE),
Greece (EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus
(CY), Latvia (LV), Lithuania(LT), Luxembourg (LU), Hungary (HU),
Malta (MT),Netherlands (NL), Austria(AT), Poland (PL), Portugal (PT),
Romania (RO), Slovenia (SI), Slovakia (SK), Finland(FI), Sweden (SE),
Türkiye (TR), Norway(NO), Switzerland (CH), Iceland (IS),
Liechtenstein (LI), and Northern Ireland (NI).
The WLAN function for this device is restricted to indoor use only
when operating in the 5150-5250/5250-5350 MHz frequency range.
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Shanghai Imilab Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang
District, Shanghai, China
For further information, please go to www.mi.com
User Manual Version: V1.3
