UniBlade Trimmer User Manual

01
●
●
●
●
●
●
●
●
●
●
●
Read this manual carefully before use,
and retain it for future reference.
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
Children should be supervised to ensure that they
do not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Please keep the trimmer out of reach of children.
Do not let children play with it.
This trimmer is only to be used with the power
supply unit supplied with it.
The handheld part can be cleaned with water
only after being disconnected from the charging
cable.
Do not use damaged trimmer head and trimming
comb. Before use, please check whether the
trimmer is damaged and whether the sound is
normal.
Before turning off the trimmer, please make sure
the trimmer head is away from the human body.
Do not charge the trimmer in humid
environments.
Do not disassemble the trimmer to replace the
battery. This appliance contains battery that is
non-replaceable.
Do not directly pull the cable of charging dock
when plugging in and unplugging the charging
plug.
Safety Instructions
Warnings

This appliance contains built-in lithium-ion
battery. Do not disassemble, impact, crush the
battery or throw it into fire. If there is severe
swelling, do not continue to use. Do not leave the
battery in high temperature environment.
Do not place or insert any foreign objects into this
trimmer.
Do not modify or repair this trimmer yourself.
This trimmer is not suitable for use in the bathtub
or shower.
The trimmer head may become hot after
prolonged use.
This trimmer is only for trimming beard and body
hair. Do not use it for other purposes.
If you come into physical contact with any
substance that may leak out of the battery,
please rinse the contact area with plenty of water
and seek medical attention immediately.
This appliance contains battery that is only
replaceable by skilled persons.
For the purposes of recharging the battery, only
use the detachable supplied charging dock to
charge the trimmer.
This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
Do not expose the appliance or battery to
excessive temperatures.
Be aware of the risk of terminals of the
battery-operated appliance or battery being short
circuited by metal objects.

03
●
●
●
●
●
●
●
●
This indicates that the trimmer can
be rinsed under running water.
Use only with <A520-050100U-EU1>
supply unit.
Read operator's manual.
Notes:
When charging, make sure to use the supplied
adapter (5 V 1 A).
Fully charge the trimmer at least once every six
months, if it has not been used for an extended
period of time.
This trimmer is intended for indoor use only.
This trimmer is intended for use by a single
individual only.
When traveling, make sure the travel lock is
enabled to protect the trimmer.
Only charge, use, and store the trimmer at a
temperature between 5°C and 35°C.
Do not wrap the cable of the charging dock
around the trimmer to avoid damage to the
cable.
The body of this trimmer meets the IPX7
standard for waterproofing and can be
cleaned with water. However, it should not be
immersed in water for an extended period of
time.
Cautions
A520-050100U-EU1

04
Power
Adapter
Charging
Dock
Wall
Mount
Product Overview
Protective
Cover
Trimmer Head
On/Off Button
Trimmer
Battery Level/
Travel Lock
Indicator
Adjustable
Trimming
Comb
Illustrations of product, accessories, and user
interface in the user manual are for reference
purposes only. Actual product and functions
may vary due to product enhancements.
Note:
Warranty
Notice
User
Manual
Quick Start
Guide

05
Notes:
Prior to the first use, it is recommended to fully
charge the trimmer and clean the trimmer head.
When the trimmer cannot be turned on due to low
battery, it will take about six hours to fully charge it.
The trimmer can be used for about 60 minutes on
a full charge.
When the battery power is low, please charge in
time, as the trimmer cannot be used while charging.
Fully charge the trimmer at least once every six
months, if it has not been used for an extended
period of time.
Installation and Charging
Attach the wall mount to a wall using double-sided
tape, insert the charging dock into the wall mount,
then attach the charging area of the trimmer to the
charging dock, connect to the power adapter and turn
on power to start charging.
CAUTION: Make sure that the wall mount is secure,
close to the power outlet and away from fire and water.
Battery level indicator description:
Trimmer
status
Charging
Indicator status Battery level
Blinking orange
Blinking white
Keeping white
0–20%
20–100%
100%
Charging
Area

06
Notes:
How to Use
It is normal that the skin is slightly irritated
during the first few times you shave. It is
recommended that the trimmer is used
regularly (at least three times per week) over a
three-week period so that your skin can adapt
to it as quickly as possible.
Improper use of the product may easily damage
the trimmer head. Please check the product's
condition prior to use. If it is damaged, please
stop using it.
Turning on/off
Press the on/off button.
Trimming comb adjustment
Attach the adjustable trimming comb to the
trimmer head and turn the knob to the desired
length.
Shaving
Apply gentle, constant pressure while moving the
trimmer slowly over the skin for shaving and
grooming.
Note: The trimmer supports both wet and dry
use. For the more challenging areas, such as the
jaw and neck, it is recommended to shave
against the direction of hair growth.
Working
20–100%
10–20%
Keeping white
Blinking orange
Blinking orange rapidly
for three times
(Unable to turn on)
Less than
10%

07
Note:
It is recommended to replace the trimmer head
every six months to ensure good performance of
the trimmer.
Travel lock
Enabling the travel lock: When the trimmer is turned
off, press and hold the on/off button for about 2.5
seconds. Then the motor will no longer rotate and the
travel lock will be enabled. The indicator will blink
three times and the trimmer will vibrate once.
Disabling the travel lock: Press and hold the on/off
button for about 2.5 seconds. Then the indicator will
blink three times and the trimmer will be turned on.
The travel lock will be disabled.
Note: When the travel lock is enabled, in the event of
pressing the on/off button, the indicator will blink but
the motor will not start, thus preventing the trimmer
from being turned on accidentally.
Care & Maintenance
To maintain optimal performance of the trimmer,
clean it after each use.
1. When cleaning the trimmer, make sure it is
turned off and not charging.
3. Rinse the trimmer, trimmer head and
adjustable trimming comb with water.
4. Allow all components to dry before
reassembling, charging and using.
2. Remove the adjustable trimming comb, and
clean the hair from it and the trimmer head.

08
Environmental Protection
When the trimmer reaches the end of its service life,
the built-in battery must be removed and properly
disposed of in accordance with the laws and
regulations of the country or region where it is
located. If the battery cannot be removed, it is
recommended to dispose of the trimmer in strict
accordance with the local regulations on the
classification and management of household
waste.
WARNINGS:
The trimmer contains a non-replaceable battery.
Do not expose the battery to fire to prevent it from
exploding or releasing toxic and hazardous substances.
Do not short-circuit the battery to prevent it from
igniting and causing a fire.

9
Trimmer
not
working
after
pressing
the on/off
button
Travel lock is
enabled.
Press and hold the
on/off button for
about 2.5 seconds
to unlock.
Battery is
depleted.
Charge the
battery in a
timely manner.
Contact the
after-sales
service team.
On/off button does
not function.
Skin is yet to adapt
to the trimmer.
Skin irritation will
fade after 2–3
weeks of use.
Replace the
power adapter.
Reposition the
charging
contact.
Contact the
after-sales
service team.
Charging contact is
poor.
Power adapter is
damaged.
Charging ambient
temperature is too
low or too high.
Charge in an
ambient
temperature
between 5°C
and 35°C.
Irritated
skin after
shaving
Charging
errors
Trimmer is
damaged.
Trimmer head is
damaged or
worn out.
Replace the
trimmer head.
Clean
thoroughly.
Trimmer is clogged
with stubbles.
Troubleshooting
Issues
Possible Causes Solutions
Poor-quality
shaving

10
It is affected by
shaving style and
beard density.
Load on the motor is
increased because
the trimmer head
hasn't been cleaned
for a long time.
Less than
60 minutes
usage time
after being
fully
charged
Clean
thoroughly.
It is normal.
Specifications
This device has been tested and meets applicable
limits for radio frequency (RF) exposure.
Name: Xiaomi UniBlade Trimmer
Model: X300
Operating Voltage/Power: 3.7 V /3 W
Operating Frequency: 142 kHz
Input: 5 V 1 A
IP Rating: IPX7
Battery Type: ICR 14500 3.7 V 1S1P 600 mAh
Charging Method: Wireless charging
Charging Time: Approx. 6 h
Maximum H-field Strength: 13.90 dBμA/m at 3 m
Electric Field Strength: 0.643 V/m at 10 cm

11
Power Adapter
Efficiency at Low
Load (10%) %64.588
Average Active
Efficiency %73.77
No-load Power
Consumption W0.075
Output Power W5.0
Output Current A1.0
Output Voltage 5.0
Input AC
Frequency Hz
50/60
lnput Voltage V~
100–240
lnput: 100–240 V~,
50/60 Hz, 0.2 A
Model ldentifier —
—
A520-050100U-EU1
lnformation
Published
UnitValue and
Precision
Jiangxi Jian Aohai
Technology Co., Ltd.
Manufacturer's
Name
V
Output: 5.0 V 1.0 A,
5.0 W

12
Europe-EU declaration
of conformity
Hereby, Shenzhen Soocas Technology Co., Ltd.
declares that the radio equipment type
X300 is in compliance with Directive 2014/53/
EU. The full text of the EU declaration of
conformity is available at the following internet
address: http://www.mi.com/global/service/
support/dec-laration.html
WEEE Disposal and Recycling
Information
All products bearing this symbol are waste
electrical and electronic equipment (WEEE as in
directive 2012/19/EU) which should not be
mixed with unsorted household waste. Instead,
you should protect human health and the
environment by handing
over your waste equipment to a designated
collection point for the recycling of waste
electrical and electronic equipment, appointed by
the government or local authorities. Correct
disposal and recycling will help prevent potential
negative consequences to the environment and
human health. Please contact the installer or
local authorities for more information about the
location as well as terms and conditions of such
collection points.

13
2
2
PA
P
Manufactured for: Xiaomi Communications Co.,
Ltd. Manufactured by: Shenzhen Soocas
Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 401, 402, 1101, 1102, 1103, 1104,
Building 2 Chongwen Area, Nanshan iPark, No.
3370 Liuxian Avenue, Fuguang Community,
Taoyuan Subdistrict, Nanshan District, Shenzhen,
China
For further information, please go to
www.mi.com User Manual Version: V1.0
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
