XINDAK CA-1 User manual

Pre-Amplifier / Power Amplifier
CA-1/PA-1
INSTRUCTIONS
®

It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collection
system for these products.
A. Information on Disposal for Users (private household).
1. In the European Union
Attention: If You want to dispose of this equipment, please do not use the ordinary dust bin.
Used electrical and electronic equipment must be treated separately and In accordance with legislation that requires proper treatment,
recovery and recycling of used electrical and electronic equipment.
Following the implementation by member states, private household within the EU states may return their used electrical and electronic
equipment to designated collection facilities free of charge*. In some countries* your local retailer may also take back your local
authority for further details.
If you used electrical or electronic equipment has batteries or accumulators, please dispose of these separately beforehand according
to local requirements.
By disposing of this product you will help ensure that waste undergoes the necessary treatment, recovery and recycling and thus
prevent potential negative effects on the environment and human health which could otherwise arise due to inappropriate waste
handling.
2. In the other Countries outside EU
If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.
For Switzerland: Used electrical or electronic equipment can be returned free of charge to dealer, even if you don’t purchase a new
product. Further collection facilities are listed on the homepage of www.swico.ch or www.sens.ch.
B. Information on Disposal of Business Users
1. In the European Union
If the product is used for business and you want to discard it:
2. In the other Countries outside the EU
If you wish to discard of this product, please contact your local authorities and ask for the correct method of disposal.
Attention: Your product is marked with this symbol.
Please contact local dealer who will inform you about the take-back of the product. You might be charged for the costs arising from
take-back and recycling. Small products (and small amounts) might be taken back by your local collection facilities.

1
!
Important Safety Instructions
EC
CAUTION: Changes or modifications to this equipment not expressly
approved by the manufacturer could void the users authority to operate the
equipment .
The information contained in the manual is subject to change without notice.
Please do not tear or remove any sticker on this component by yourself
otherwise it may influence user enjoy the after-sale service.
!
CAUTION

2
Unpack your CA-1 or PA-1 and keep all packing materials for future transport or service, locate and remove all
accessory items from the accessory box within the shipping carton.
Accessories Included:
Important Safety Instructions
Please read all instructions and precautions carefully and completely before operating your CA-1
preamplifier and PA-1 mono block power amplifier.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Always keep this unit out of the reach of children.
8. Do not install this product near any heat sources such as radiators, heat registers, stoves, or other apparatus (
including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10. Unplug this apparatus during lightning storms or on the condition of long-time non-using.
11. Always disconnect your entire system from the AC mains before connecting or disconnecting any cable, or when
cleaning any component.
12.This product must be terminated with a three conductor AC mains power cord which includes an earth ground
connection, to prevent it from shock hazard, all three connections must always be used.
13. AC extension cords are not recommended to use on this product.
14. Never use flammable or combustible chemicals for cleaning audio components.
15. Never operate this product with any cover removed.
16. Never pour or spill liquids directly onto this unit.
17. Never block air flow through ventilation slots or heat sinks.
18.Keep the fuse out of short circuit.
19.Never take replacement of fuse uith non-specified values.
20.Never attempt to repair this product, if a problem occurs, contact your dealer.
21.Never expose this product to extremely high or low temperatures.
22.Never operate this product in an explosive atmosphere.
Before Use
2. One piece of user manual (This manual)
1. One piece of AC power cord
S1
S2
S3
S4
Bal
Mute
F1
Volume
-
+
REMO TE CONT ROLLE R
3. One piece of remote controller

Products Information
Sketch Map on CA-1 Front & Rear Panel
IR Sensoer
SLEEP
HEATING
3 4 5 7 8 62
1
3 4 5 7 62
1
1
3
4
5
7
8
6
2
1
3
4
5
7
6
2
1
3
Signal Input Terminal
RCA terminals are used for signal input.
Balance Signal Input Terminal
The signal is input by balance interconnect cable.
Balance Output Terminal
For connecting with balance input terminal of power
amplifier by balanced interconnect cable.
RCA Output Terminal
For connecting the RCA input terminals on power
amplifier by interconnect cable.
Power Button
For powering on and powering off the product.
Fuse Socket
Fuse socket is used for insert the fuse of the device.
Alternating Current Input Socket
Connect this socket with wall outlet by the attached
power cord.
Warm-up Indicator
The indicator will be lighted when the main power gets
through, then automatically shut off after 60 seconds or
so.
Sleep Indicator
After the power gets through and power on by the
power switch on the rear panel, this indicator will be
light, which indicates this product enter into sleep state.
After press the sleep button to power on the system
main power, this indicator will be dead.
Sleep Button
Press this button, the main system power will be on;
press again, the main system power will be off and enter
to sleep state.
Mute Button
Press the button during work state, the preamplifier will
be in mute mode. Press it again, the product will be
released from mute.
Input Button
The Input channel will be selected circularly from S1-S2-
S3-Bal in order, while press the button once in work
state.
VOL+ Button
Press the button, increase the volume; persist on
pressing, the volume will be increased continually.
VOL- Button
Press the button, decrease the volume; persist on
pressing, the volume will be decreased continually.
Remote Signal Receiving Window
Implement the remote control function by aiming the
remote controller to this window while operation.

Front & Rear Panel of PA-1
Power
4
Power
on/off
Power LED
indicator
Appearance
Speaker
output 1
Speaker
output 2
Balanced(XLR)
input
Single-Ended(RCA)
input
XLR/RCA
selection switch
AC mains
input

30° 30°
IR Sensoer
SLEEP
HEATING
5
Remote Control Unit
S - 1
S -2
S -3
S -4
B- 1
Mute
F1
Volume
-
+
5
4
2
3
1
5
2
3
1
4
Mute Button
F1 Sleep Button
Input Switch Button
Balance Input Switch Button
Volume Control Button
Install Batteries
1. Use the tool remove the rear cover of the remote control unit.
2. Install the 2 batteries (AAA) polarity.with correct +/-
3. Reinstall the rear cover of the remote control unit.
Battery Replacement
1. Install batteries observing the correct polarity,(+) and (-).
2. Do not use new and old batteries simultaneously.
3. Batteries with similar shapes may have different rated voltages Be sure to
use the correct batteries.
4. Remove batteries from the remote control unit if it will not be used for a long
period of time.
Using Remote Controller
If you use the remote control unit to control the amplifier:
1.The remote control range is approximately 5 meters.
2.Pointing the remote control on an angle to the receiver, will shorten the
useful distance of the remote control.
S - 1
S -2
S -3
S -4
B- 1
Mute
Temp
Volume
-
+
REMOTE CONTROLLER
AAA
AAA
!
Incorrect use of batteries can cause corrosion or damage.
The lower temperature, the shorter battery life.
Operation and maintenance for remote control

Operation Guide
How To Use
CA-1 Protection Function
This product has complete anti-impact function, including delayed protection on power on, shut off protection, which can
ensure no abnormal impulse current output.
CA-1 Operating Process
1. Check the connections between this product and related devices before power on.
2. Power on the product by press the power button, after the connections are confirmed to be connected well. The sleep
indicator will be lighted to indicate the preamplifier enter into sleep state.
3. Start the preamplifier by press sleep button by hand or F1 button on remote controller. The product will be shifted
between work state and sleep state automatically after each press. The sleep indicator will be dead after the pre-amplifier
enter into work state. The pre-amplifier will enter into the count down period for 60s while the sleep indicator is off and
the warm-up indicator is light. During this warm-up stage, except press the sleep button or F1 button, all other operation
are invalid. After the count down period for delay, the pre-amplifier will be automatically interconnected with the signal
input channel which is recorded in memory and keep the volume value in memory when shut off last time.
The volume will be automatically adjusted to volume 30 if it is over volume 75 before last time shut off.
4. After warm up, you can implement all controls by hand or remote controller. You can select the input channel, and set
the sound source in play mode, turn on the volume level slowly. Then, you can enjoy the music.
5. When shut off the audio system, please power off the power-amplifier at first, and then power off this preamplifier itself.
Caution: Must cut off the power for non-play for long-time.
PA-1 Protection Function:
This product has complete anti-impact function, including delayed protection on power on, shut off protection, which can
ensure no abnormal impulse current output.
PA-1 Processing:
1. Ensure the connections between this power amplifier and relevant devices are correct before power on;
2 Power on only if the cables are confirmed to be connected well, the indicator glitters to indicate the machine enters into
the warm up status. After about 8 seconds, the power amplifier enters into working state, then you can play the music.
3. When shut off the audio system, please power off the power amplifier at first, and then power off the preamplifier.
S-1
S-2
S-3
b-1
INPUT
S2
S3
Bal
6
Input signal select
There are two select models for signal: one is
directly select signal source by remote control
and the other one is select by Selector button on
panel. When select in the second models, press
Selector button each time, it will circularly select
the signal channel as the order shown in right
sketch.
Input select sketch map
Press Selector button
each time, it will
circularly select the
signal channel as the
order shown in right
sketch.

CA-1 FQA
7
Sound source turned off
Signal cable is broken
Speaker cable is broken
Signal selector switch wrong
Root noise of sound source too big
Signal shielding effect badly
Signal source input phase opposed
Speaker wire to channels has exchanged
or positive negative reversed
Turn on the sound source.
Check and change signal cable.
Check and change speaker cable.
Change a higher SNR sound.
Left and right
channel confused
Indicator always
glitters
There is problem on preamplifier,
Loudspeaker cable or loudspeaker
Check the preamplifier, loudspeaker
cable or loudspeakers
Problem Possible Cause Trouble-shootings
The amplifier is
not electrified
Power connector not plug well
Fuse has fused
Plug the power connector again.
Change the fuse coincide with the
prompt requirement.
Speaker no
sound
Noise too big
Tune input selection button
according to sound source.
Connect according to the indication
of left and right channel.
Change eligible signal cable
How To Use
In order to help user operate this amplifier more convenient, following is some frequently asked questions during the
operation. If you want more information, please visit our web site www.xindak.com or send e-mail to [e-mail].

PA-1 FQA
Q.Why operate on the input selector on panel or select switch and volume control button on remote control, there is
no response from amplifier?
A. The reason for that may because: 1. The amplifier is in preparation stage after power on. Please wait. 2. The
amplifier is in mute model, and the Mute mark glitters as 1Hz frequency. Please release the mute;
Q. why the attached remote control can not work?
A. This problem may because: 1. there is no batteries, please take out the batteries attached, open the rear cover of
the remote control by screwdriver and install them according the exploitation on the chapter “Operation and
maintenance for remote control”. 2. The batteries is spent, please replace the batteries. 3. There is barrier between
the IR sensor and infrared emitter. 4. The remote control has been out of the max available operation distance.
Q. Why there is no sound output after power on?
A. That may because: 1. The amplifier has not been connected to sound source or there is no output from sound
source. 2. The amplifier has not been connected to loudspeakers. 3. The signal indication is different with the input
signal, please select the correct signal channel. 4. The volume knob is set at the 0, please set the volume in proper
level.
Q. How to replace the fuse?
A. If the fuse melts, please pull out the power cord at first, then open the fuse socket on the power input socket. After
take out fuse, please check the fuse at first. If there is no black within it, please directly replace it with the fuse in
same specification. If there is fuse, which mean there is serious fault, please contact the xindak dealer.
8
In order to help user operate this amplifier more convenient, following is some frequently asked questions during the
operation. If you want more information, please visit our web site www.xindak.com or send e-mail to [e-mail].
How To Use

12V(RMS)
Max.Output Level
THD ≤0.02%
Frequency Response 10Hz-100KHz
Input Sensitivity 240mV(2V output)
Net Weight 9.5Kg
Dimension (W D H) 430mm 384mm 116mm
SNR 100dB
PA-1
CA-1
THD ≤0.02%
Output Power 250W(8Ω Load)
430W(4Ω Load)
Frequency Respons 10Hz-100KHz
Input Sensitivity
Damp Coefficient
2V
Static Power Consumption
Net Weight 34Kg
430mm 460mm 203mm
SNR 100dB
140
≤300W
9
Notice: Specification and design for improvements subject to change without notice.
Dimension (W D H)
Specifications

No.126, Section 2, East 1 Round Chengdu, Sichuan, China P.C. 610051
You can find your nearest authorized distributor and more product information on our website:
www.xindak.com
Print in China
