HDMI DA4 and HDMI DA6 • Setup Guide
Overview
These Extron distribution ampliers distribute one HDMIinput signal to four (HDMI DA4) or six (HDMI DA6) simultaneous outputs.
This setup guide provides basic instructions for installation by an experienced installer. For complete instructions, see the
HDMIDA4 and HMDI DA6 User Guide, on the Extron web site (www.extron.com).
Front Panel
HDMI DA6
HDMI DISTRIBUTION AMPLIFIER
CONFIG HDCP
1234
SIGNAL
INPUT OUTPUTS
EDID
56
HDMI DA4
HDMI DISTRIBUTION AMPLIFIER
CONFIG HDCP
1234
SIGNAL
INPUT OUTPUTS
EDID
1 2
3
4 5
1 2
3
4 5
aPower status LED — Lights green when power is applied to the unit.
bUSB Config port — Used for SIS configuration, monitoring, and firmware updates.
cSignal LEDs — Light green when a TMDS signal is detected on the HDMI input and is being transmitted on the
corresponding output.
dHDCP LEDs — Light green when a HDCP has been authenticated on the HDMI input and the appropriate output (if required).
eEDID LED — Lights green when the EDID from the selected output device (output 1 by default) is successfully stored. Lights
amber if factory-installed EDID is used or if the EDID was not successfully stored.
Rear Panel
50/60 Hz
100-240V ~ 0.3 A MAX HDMI DA4
RS-232
4321
Tx Rx G
REMOTEOUTPUTSINPUT
3 41 2
50/60 Hz
100-240V ~ 0.3 A MAX HDMI DA6
RS-232
4
36
521
Tx Rx G
OUTPUTS REMOTEINPUT
aPower input — Connect the provided IEC connector to a 100-240 VAC (50 or 60 Hz) power source..
bHDMI input — Connect a source device into this female HDMI type A connector.
cHDMI outputs — Connect display devices into these female HDMI type A connectors.
dRS-232 — Used for SIS conguration, monitoring, and rmware updates.

2
68-1844-51 Rev. A
06 13
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX [phone] FAX
Extron Europe
+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.299.1800
+971.4.299.1880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
(Inside India Only)
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2013 Extron Electronics All rights reserved. www.extron.com
HDMI DA4 and HDMI DA6 • Setup Guide (Continued)
Installation
1. Mount the HDMI DA in a suitable location (see the “Mounting” section of the HDMI DA4 and HDMI DA6 User Guide for
mounting options). Follow the instructions provided with the mounting kit.
2. (Optional) Connect the USB or RS-232 connector (see the gure below) to a PC for conguration and maintenance.
Use SIS commands to congure EDID Minder®, mute the video signal, mute the audio signal, adjust the video color bit
depth, or monitor the signal and HDCP status, as required. See the “SIS Commands” section of the HDMIDA4 and
HDMIDA6UserGuide.
RS-232
Tx Rx G
REMOTE
TransmitReceive
ReceiveTransmit
GroundGround
DB9 Pin Locations
Female
51
96
Pin 2 = Rx
Pin 3 = Tx
Pin 5 = G
Computer HDMI DA2
3. Connect and power on the display devices to the rear panel HDMI outputs. Connect the primary display to output 1. EDID
from output 1 is stored automatically, by default.
NOTE: Use the LockIt™HDMI cable lacing brackets provided to secure the HDMI connectors (see the
LockItHDMICable Lacing Bracket Installation Guide).
4. Connect to a 110-240 VAC (50 or 60 Hz) power supply using the provided IEC power cord.
5. Connect and power on the source device.
Typical Application (showing HDMI DA4)
50/60 Hz
100-240V ~ 0.3 A MAX
HDMI DA4
RS-232
4321
Tx Rx G
REMOTEOUTPUTSINPUT
131
42
31
42
3
1
4
2
2
3
100
LINK
ACT
COM IR INPUT RELAY
TX RX
R
IPL250
®
ON
OFF
DISPLAY
MUTE
SCREEN
UP
SCREEN
DOWN
VCR
DVD
DOC
CAM
LAPTOP
PC
Blu-ray Player
Extron
HDMI DA4
Distribution
Amplier
HDMI
Cables
RS-232
TCP/IP
TouchLink
Control
System
Flat Panel Displays
