XM NX1 User manual

XM Enterprise Co., Ltd.
User Manual NX1

Table
of
Contents
Safety Guidelines
Caution
Panel Controls
Front Panel
Left Side Panel
Right Side Panel
Assembly Instructions for
Module and Cables
Diagram of Module and Rack Bracket
Connection
Diagram of Module and External
Equipment Connections
Diagram of Module and Cable
Connections
Basic Operation
Operating the Module
Home Page
Editing Drum Values
Editing the Value of the Metronome
Quick Recording
Training Mode
Settings
AUX IN
MIDI
Troubleshooting
P03-P07
P08
P09-P10
P09
P10
P10
P11-P16
P11
P11-P12
P13-P16
P17
P18-P29
P18
P19
P19
P20
P21-P26
P27-P28
P29
P29
P30-P31

03
Safety Guidelines
INSTRUCTIONS FOR THE PREVENTION OF FIRE,
ELECTRIC SHOCK, OR INJURY TO USERS
WARNING
These instructions are instructions intended to alert
users to the risk of death or severe injury should the
unit be used improperly.
CAUTION
These instructions are instructions intended to alert
users to the risk of injury or material damage should
the unit be used improperly.
Material damage refers to potential damage or
other adverse effects caused to the user’s home,
its furnishings, as well as to domestic animals or
pets.
The symbol alerts the user to important
instructions or warnings.
The specific meaning of each symbol is
determined by the design contained within its.
In the case of the symbol shown to the left, this
is used for general cautions, warnings, or alerts
to danger.
The symbol alerts users to items that must
never be carried out (forbidden actions).
Specific actions that must not be done are
indicated by the design contained within the
circle icon.
In the case of the symbol shown to the left, it
means the unit must never be disassembled.
The symbol alerts users to actions that must
be carried out.
Specific actions that must be performed are
indicated by the design contained within the
circle icon.
In the case of the symbol shown to the left, it
means the power cord plug must be unplugged
from the power outlet.
About these WARNING and
CAUTION Notifications
About the Symbols Used in this Document

04
Safety Guidelines
- Do not open (or modify in any way) the
Unit or its AC adaptor.
- Do not attempt to repair the unit, or to
replace parts within it (except when this
manual provides specific instructions
directing you on how to do so).
Refer all servicing to your retailer, the
nearest XM eDrum Service Center, or an
authorized XM eDrum distributor.
- Never install the unit in any of the
following locations:
‧Areas subject to temperature extremes
(E.G. direct sunlight in an enclosed
vehicle, near a heating duct, on top of
heat-generating equipment)
‧Damp areas
(E.G. baths, washrooms, on wet floors)
‧Areas exposed to steam or smoke
‧Locations subject to salt exposure
‧Humid areas
‧Locations exposed to rain
‧Dusty or sandy areas
‧Locations subject to high levels of
vibration and/or shaking.
- When using the unit with a stand
recommended by XM eDrum, the stand
must be carefully placed so it is level and
will remain stable.
If not using a stand, you still need to make
sure any location you choose to place the
unit provides a level surface to support the
module properly and keep it from being
unstable.
- Be sure to only use the AC adaptor supplied
with the unit.
Also, make sure the line voltage at the
installation matches the input voltage
specified on the AC adaptor’s body.
Other AC adaptors may use a different
polarity, or be designed for a different
voltage, so their use could result in
damage, malfunction, or electric shock.
- Only use the attached power supply cord.
Also, the supplied power cord must not be
used in conjunction with any other device.
WARNING
ALWAYS OBSERVE THE FOLLOWING

05
Safety Guidelines
- Do not excessively twist or bend the power
cord, nor place heavy objects on it.
Doing so can damage the cord, producing
severed elements and short circuits.
Damaged cords are fire and shock hazards!
- This unit, either alone or in combination
with an amplifier, headphones, or speakers,
may be capable of producing sound levels
that could cause permanent loss of hearing
Do not operate at a high volume level for
a long period of time, or at a level that is
uncomfortable.
If you experience any hearing loss or ringing
of the ears, you should immediately stop
using the unit and consult an audiologist.
- Do not allow any objects (E.G. flammable
material, coins, pins), or liquids of any kind
(water, soft drinks etc.) to penetrate the
unit.
- Immediately turn the power off, remove
the AC adaptor from the outlet, and
request servicing by your retailer, the
nearest XM eDrum Service Center, or an
authorized XM distributor when:
‧The AC adaptor, the power supply cord, or
the plug has been damaged.
‧Smoke or unusual odors are emitted from
the unit.
‧Objects have fallen into, or liquid has
been spilled onto the unit.
‧The unit has been exposed to rain (or has
otherwise become wet).
‧The unit does not appear to operate
normally or exhibits a marked change in
performance.
- In households with small children, an adult
should provide supervision until the child
is capable of following all of the rules
essential for the safe operation of the unit.
- Protect the unit from strong impacts.
(Do not drop it!)

06
Safety Guidelines
- Do not force the unit’s power supply cord
to share an outlet with an unreasonable
number of other devices.
Be especially careful when using extension
cords—the total power used by all devices
connected to the extension cord outlet
must never exceed the power rating (watts/
amperes) for the extension cord.
Excessive loads can cause the insulation
on the cord to heat up and eventually melt
through.
- Before using the unit in a foreign country,
consult with your retailer, the nearest XM
eDrum Service Center, or an authorized XM
eDrum distributor.
WARNING

07
Safety Guidelines
CAUTION
- The unit and the AC adaptor should be
located so their location or position does
not interfere with their proper ventilation.
- Always grasp the plug only on the AC
adaptor cord when plugging into, or
unplugging from, an outlet or this unit.
- At regular intervals you should unplug the
AC adaptor and clean it by using a dry cloth
to wipe all dust and other accumulations
away from its prongs.
Also, disconnect the power plug from
the power outlet whenever the unit is to
remain unused for an extended period of
time.
Any accumulation of dust between the
power plug and the power outlet can result
in poor insulation and lead to fire.
- Try to prevent cords and cables from
becoming entangled.
Also, all cords and cables should be
placed so that they are out of the reach of
children.
- Never climb on top of, nor place heavy
objects on the unit.
- Never handle the AC adaptor or its plugs
with wet hands when plugging into, or
unplugging from, an outlet or this unit.
- Before moving the unit, disconnect the AC
adaptor and all cords coming from external
devices.
- Before cleaning the unit, turn off the power
and unplug the AC adaptor from the outlet.
- Whenever you suspect the possibility of
lightning in your area, disconnect the AC
adaptor from the power outlet.

08
Caution
ＮＸ１
The module’s name/number
will be shown here
1
2
3
4
5
6
Please read these instructions carefully before use
1. The appliance should not be used near water (E.G. near a bathtub,
bathroom sink, kitchen sink, laundry tub, in a wet basement, or
near a swimming pool etc.), or outdoors on rainy days. Any fluid
that leaks into the device will damage the components inside.
2. To avoid signal interference, please do not use this device next to
other electrical appliances. (E.G. TV, Radio … etc.)
3. Please hold the cable’s plug when pulling it out. Do not pull the
cable hard, as it can damage the cable and its plug.
4. Before connecting the module to other electrical appliances, (E.G.
computer, speaker etc.), please turn the power of each appliance
to “OFF”.
Also, turn all volume controls down to 0 before turning these
appliances ON/OFF.
5. Please stop using the module if there is any problem with the
power cable, so as to avoid any accidents such as fire or electrical
shock.
6. Do not open the device’s case or make any changes to the
components inside the device by yourself. Doing so may damage
its components. Should you find the device to be malfunctioning
in any way, please stop using it and send it to our service
department for maintenance.

09
Panel Controls
> Front Panel
[MIX IN] Knob: Adjust the volume of the
MIX IN jack.
[PHONE OUT] Knob: Adjust the volume of
the PHONE OUT jack.
[MAIN OUT] Knob: Adjust the volume of
the MAIN OUT jack.
[ENTER] Knob: Rotate the knob to switch
between pages and edit values; Press the
knob to confirm a selection, or to enter
other screens.
[CLICK] Button: Press to quick-start the
metronome; Do a long press of the button
to enter/exit the metronome and/or adjust
the screen.
[REC] Button: Press to enter the
recording screen.
1
2
3
4
5
6
1 2 3
45 6
C


10
Panel Controls
> Left Side Panel > Right Side Panel
Power Button: Gently press the button to turn the
main device ON/OFF.
USB Port: Used for connecting the main device to a
computer. You can also exchange MIDI data via USB
with DAW software.
MAIN OUT Port: This is the main volume output
signal for the system. Connect this to a speaker.
MIX IN Port: Use a 3.5mm stereo cable to connect
with a music player or other source of music.
PHONE OUT Port: Used for stereo headphones.
1
2
3
4
5
1
2
3
4
5
DC IN Port: (Please use the XM power supply.)
TRIGGER INPUT: Connect to enable all drum
components.
AUX IN Port: To expand your kit with additional
eCymbals.
11 22 33 4 5

11
XM Drum Set
Assembly Instructions
for Module and Cables
> Module and Rack Bracket
Connection
> Module and External Equipment
Connections
Take three screws out of the Module
box and connect the Module to the
Module Rack by using a cross point
screwdriver as shown here.
Right Side Panel

12
PC XMP10 HEADPHONE SPEAKER
MP3
CD PLAYER
IPAD...
Assembly Instructions
for Module and Cables
POWER
|
USB
|
MAIN OUT
|
MIX IN
|
PHONE OUT
Left Side Panel
> Module and External Equipment Connections

13
Tempo Series
Assembly Instructions
for Module and Cables
> Module and External Equipment Connections
BD Blue
SD Brown FT White
T2 Yellow
T1 Gray RD Red
CR Green
HH Black
HHC Pink
CR GreenHH Black T1 Gray T2 Yellow RD Red
HHC Pink SD Brown BD Blue FT White

14
Busker Series
Assembly Instructions
for Module and Cables
BD Blue
SD Brown
T1 Gray RD Red
HH Black
HHC Pink
HH Black T1 Gray RD Red
HHC Pink SD Brown BD Blue
FT White
T2 Yellow
CR Green
Do not use
> Module and External Equipment Connections

15
Zen Series
Assembly Instructions
for Module and Cables
BD Blue
SD Brown FT White
T2 Yellow
T1 Gray RD Red
CR Green
HH Black
HHC Pink
CR GreenHH Black T1 Gray T2 Yellow RD Red
HHC Pink SD Brown BD Blue FT White
> Module and External Equipment Connections

16
Proceed Series
> Module and External Equipment Connections
Assembly Instructions
for Module and Cables
BD Blue
SD Brown FT White
T2 Yellow
T1 Gray
RD Red
CR Green
HH Black
HHC Pink
CR GreenHH Black T1 Gray T2 Yellow RD Red
HHC Pink SD Brown BD Blue FT White

17
Basic Operation
To turn on the device, gently press the Power button.
 When getting started, please lower the volume to
its minimum level in order to avoid damage to the
module’s main board and/or your speaker.
Use the [MAIN OUT] Knob to adjust the volume.
 Pressing the Power button a second time will turn
off the module. All settings on the NX-1 module
are automatically saved, so you won’t need to set
them up again when using this module.
Step Step
1 2

18
Operating the Module
There are four modes :
KIT mode: You can shift between Pop, Rock, Jazz, Metal,
and Effect.
Metronome mode: The speed can be adjusted, showing
the current speed at the time of use. (see P.19)
Training mode: Six different training modes. (see P.21~26)
Setting mode: Factory Reset, Drum Settings, RIM Settings,
HHP Settings , and Mixer Settings. (see P.27~28)
The speed can be adjusted, showing the current speed at the
time of use.
Remarks:
1. Rotate the [ENTER] Knob to move between the four modes. In
modes & , press the [ENTER] Knob to confirm a selection,
press again to exit, and do a long press of the [ENTER] Knob
to enter the mode’s Settings screen. In modes & , press
the [ENTER] Knob to enter the mode’s Settings screen.
2. Editing Drum Values
> Home Page
 

 



19
Operating the Module
The screen shows you graphics and labels of which parts you
have chosen.
After choosing the KIT mode, do a long press of the [ENTER]
Knob to enter the Editing Drum Values screen.
Press the [ENTER] Knob to choose the value you would like to
adjust, and then rotate the [ENTER] Knob to edit the chosen
value. To exit, press the [ENTER] Knob again.
After choosing the Metronome mode on the Home page, do
a long press of the [ENTER] Knob or Button to enter the
Edit Value screen.
Press the [ENTER] Knob to choose the value you would like to
adjust, and then rotate the [ENTER] Knob to edit this value.
To exit, press the [ENTER] Knob again.
Remarks:
Drum section
Drum graphic
Drum name
Save location
Remarks:
Speed: 30~240 bpm
Time Signature: 2/4, 3/4, 4/4, 5/4,
3/8, 6/8.
Tempo: Duplets, Triplets, Triplets
Split, Quadruplets, Quadruplets Split.
Volume: 1~50
Sound: 1~4
EXIT: Exit current
page
VOL: Volume (0~50)
SEN: Sensitivity (0~50)
MIDI: MIDI note (0~127)
EXIT: Exit the current page
C
> Editing Drum Values > Editing the Value of the Metronome




 






20
Operating the Module
Press the Button to start recording.
The screen will show “Ready”, and the metronome will be
turned on automatically - the Button will light up). Press
the [ENTER] Knob to choose the metronome’s speed, or the
volume, and then rotate the [ENTER] Knob to edit the related
value.
The recording begins when you play the first drum hit.
Note: The speed cannot be adjusted while making a recording.
The screen will then show how long you’ve been recording.
Press the Button to enter the recording mode (The
Button will then remain lit up).
 
Rotate the [ENTER] Knob to move between icons.
C
Remarks:
1. You can press the Button to turn On/Off the metronome.
2. You can do a long press of the Button to enter the Edit
Value screen.
3. In the recording mode, press the Button to Start/Stop, and
to play your recording.
C
C
Press the Button again to stop recording, and the screen
will show “Stop”.
Rotate the [ENTER] Knob to choose the Play icon, and then
press the Button to play your recording.
Press the Button again to stop playing the recording.





> Quick Recording
