XMODUS XM1710E User manual

OPERATING INSTRUCTIONS
XM1700E / XM1710E
GSM/GPRS ROUTER
1
1. Safety
ESD Protection:
RS232 Interface: +/- 15kV HBM
+/- 8kV IEC 61000-4-2
All other ports: +/- 15kV
IEC 61000-4-2, level 4
Operation:
The proper and safe operation of this device assumes
that the operating instructions and the safety warnings
given in this document are read carefully.
Electrical connections are observed. The device should
only be handled by appropriately trained personnel who
are familiar with it and authorised to work in electrical
installations.
2. Technical data
Serial Interface:
Type: Serial V.24 (EIA/TIA-232-E).
Connector: RJ45 (8 poles)
Pin designation:
1 RTS
2 DTR
3 TXD
4 GND
5 GND
6 RXD
7 DSR
8 CTS
This pin designation is equivalent to the Cisco console.
Therefor you can use the standard Cisco console cable.
GSM Antenna Interface:
Type: GSM 5-band Antenna.
RF Connector: SMA female
GSM-Bands: 850/900/1800/1900/2100Mhz
3
Power supply:
Do not connect the modem to the
mains power directly.
Input voltage: 9…32 V
DC
Power input: 400mA @ 9V
DC
(average)
Connector: Molex (43025-0400)
Contacts (430-30-0009)
Molex connector designation:
Pin 1: Minus (GND)
Pin 2: Plus (9…32 V
DC
)
Pin 3: Digital input
Pin 4: Digital output
Digital Input / Output:
Pin 3 and 4 of the Molex connector are providing digital
in and output ports. Leave this ports open if not used. To
activate these ports additional software is needed. Refer
to the Digital IO documentation for further information.
3. Connectors / Indicators
Make sure that all cables are not live when
making the connections! Impending
danger by high input voltage or high power
supply voltage!
1. Power Supply input (Molex type).
2. Serial (RS232) Interface (RJ45)
3. Ethernet 10/100base-T Interface
4. Reset 1s ON = Reset
5s ON = Reset to Default
5

5. Power Led (Green).
6. GSM Network LED (Blue)
7. Services LED (Yellow).
8. Services LED (Yellow)
9. Error Led (Red)
10. GPRS Traffic Led (Orange)
11. GSM Antenna Interface (SMA)
12. SIM card holder.
4. Antenna requirements
The antenna connection is an important
aspect in the full product operation as it
strongly affects the product overall
performances, hence read carefully and follow the
requirements and the guidelines for a proper operation:
Frequency range: Depending by frequency band(s)
provided by the network operator, use the most suitable
antenna for those bands.
Bandwidth (GSM/EDGE): 70MHz in GSM850, 80 MHz in
GSM900, 170 MHz in DCS & 140 MHz in PCS band.
Impedance: 50 Ohm
Input power: >33 dBm (2W) peak power in GSM
VSWR absolute max: ≤5:1 (limit to avoid damage)
VSWR recommended: ≤2:1 (limit for regulatory req.)
This device is to be used only for mobile and fixed application. In
order to re-use the Telit FCC/IC approvals the antenna(s) used
for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co-
located or operating in conjunction with any other antenna or
transmitter.
7
5. Environmental conditions:
Operating temp. -20°C to +75°C
Storage temp. -40°C to +85°C
Rel. humidity: ≤75% acc. EN60068-2-30
Protection type: IP50 acc. IEC529
Vibration: acc. EN60068-2-6
Shock : acc. EN60068-2-27
Dimensions: 110 x 65 x 30 mm
Mounting: any direction
6. Accessories
XM-PSU-001 External Power Supply 9V
XM-TSH-35/4 Top-hat rail mounting kit
xmodus swiss GmbH
Dachslernstrasse 63
CH – 8048 Zürich
Phone [phone]
Fax [phone]
e-mail:[e-mail]
http://www.xmodus.ch
Document-#: XM1700S-E00-102
21
4
3
1
23
4
Rear side
Front side
+
+
+
+
12
9
8
5 6
7 10
11
SIM

AT Commands and Software Documentation:
The Software and AT-Commands Manual should be downloaded at
http://www.xmodus.ch/manuals.html
Router Configuration and IP address:
The IP address is: 192.168.1.1
Configuration: use your Internet browser to load the configuration
Web page at address 192.168.1.1
Router Login:
Default username: root
Default password: root
