XOCECO LC-26KT42 User manual

Before connecting, operating or adjusting this product, please read the manual completely.
Please keep this manual for future reference.
LCD TV
Operating Manual
LC-26KT42

Table of Contents
Important Information ......................................................................................................................1
Important Safety Instructions...........................................................................................................2
Important Notice ..............................................................................................................................5
Preparations ......................................................................................................................................6
Identification of Controls ..................................................................................................................8
Connections .....................................................................................................................................11
Basic Operations..............................................................................................................................15
Getting Started ...............................................................................................................................19
Adjusting PICTURE Menu Options
Adjusting AUDIO Menu Options 1
Adjusting SETUP Menu Options 2
Parental Controls.........................................................................................................................23
Closed Caption ............................................................................................................................26
Time & Menu Settings 7
Input Label/Restore Default/Audio Only 8
Adjusting CHANNEL Menu Options
Troubleshooting...............................................................................................................................32
Specifications...................................................................................................................................34
Assembling the stand and removing the stand column ................................................................35
................................................................................................20
...................................................................................................2
...................................................................................................2
.................................................................................................................2
....................................................................................2
.............................................................................................29
Image Adjustments for VGA (PC) Mode........................................................................................31

1
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION-To reduce the risk of electric shock, do not
perform any servicing other than that contained
in the operating instructions unless you are
qualified to do so.
This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury. Disposal of these materials may be
regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eia.org
FCC STATEMENT
FCC Notice
LCD TV: A CLASS B digital device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly
approved by the manufacturer could cause harmful interference and would void the user's authority to operate
this device.
WARNING: This is a CLASS B product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures to
counter interference.
Important Information

2
Important Safety Instructions
Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN
RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe
the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service
life of your TV product, please read the following precautions carefully before using the product.
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions---All operating instructions must be followed.
5. Do not use this apparatus near water---for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming
pool, and the like.
Do not use immediately after moving from a low temperature to high
temperature environment, as this causes condensation, which may result in fire,
electric shock, or other hazards.
The apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
6. Clean only with dry cloth---Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.
7. Ventilation---Do not block any ventilation openings. Install in accordance
with the manufacturer instructions. The vents and other openings in the cabinet
are designed for ventilation. Do not cover or block these vents and openings
since insufficient ventilation can cause overheating and/or shorten the life of the
product. Do not place the product on a bed, sofa, rug or other similar surface,
since they can block ventilation openings. This product is not designed for built-
in installation; do not place the product in an enclosed place such as a bookcase
or rack, unless proper ventilation is provided or the manufacturer’s instructions
are followed.
8.Heat sources---Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
9.Grounding or Polarization---Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
NOTE: where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain
readily operable.
11.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not
recommended by the manufacturer. Use of improper attachments can result in accidents.

3
Important Safety Instructions (Continued)
12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. Do not place the product on an unstable
trolley, stand, tripod or table. Placing the product on an unstable base can cause the
product to fall, resulting inserious personal injuries as well as damage to the product.
When mounting the product on a wall, be sure to follow the manufacturer’s instructions.
Use only the mounting hardware recommended by the manufacturer.
13. Move carefully---When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over. Sudden stops, excessive force and uneven
floor surfaces can cause the product to fall from the trolley.
Never attempt to move the TV unless the AC power cord has been disconnected.
14. Lightning---Unplug this apparatus during lightning storms or when unused for long
periods of time.
For added protection for this television equipment during a lightning storm, or when it is
left unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the equipment due to lightning and
power-line surges.
15. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
16. Replacement parts---In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
17.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this
can result in a risk of fire or electric shock.
18.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltage flows
in the product, and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill
water or liquid on the product.
19.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not
described in the instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality
in the product indicates that the product needs servicing.
20.Safety checks---Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.
21.Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to
the method recommended by the manufacturer. This is a safety feature.

4
Important Safety Instructions (Continued)
23.Panel protection---The display panel used in this product is made of glass.
Therefore, it can break when the product is dropped or impacted upon by other objects.
Be careful not to be injured by broken glass pieces in case the display panel breaks.
24.Pixel defect---The display panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few
non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the
performance of your product.
22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you
are not sure of the type of power supply to your home, consult your product dealer or local power company. For added
protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the cable system. This will prevent damage to the product due to lightning and power line
surges. When the unit has to be used with another power supply voltage, the power cable must be changed. Consult your
product dealer. The socket outlet should be installed near the equipment and easily accessible. Use only the power cord
designated by our dealer to ensure safety and EMC. When connecting other products such as VCRs and personal computers,
you should turn off the power of the unit for protection against electric shock.
WARNING: For continued safety, apparatus with class I construction shall be connected to a mains socket outlet with a
protective earthing connection.

Do not use in hot and cold rooms (locations)
!When the unit is used in rooms (locations) with low temperature, the picture may
leave trails or appear slightly delayed. This is not a malfunction, and the unit will
recover when the temperature returns to normal.
!Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location
exposed to direct sunlight or near a heater, as this may cause the cabinet to deform
and the to malfunction.
!Storage temperature: 0°C to +50°C
!Working temperature: 5°C to +40°C
screen
About Temperature
About After-Image The extended use of fixed image program material can cause a permanent after-image
on the screen.
This background image is viewable on normal programs in the form of a stationary fixed
image. This type of irreversible screen deterioration can be limited by observing the
following steps:
A. Reduce the brightness/contrast setting to a minimum viewing level.
B. Do not display the fixed image for extended periods of time.
C. Turn the power off when not in actual use.
Important Information Regarding Use of Video Games, Computers,
Captions or Other Fixed Image Displays.
!Do not allow a still picture to be displayed for an extended period, as this can cause a
permanent after-image to remain on the screen.
Examples of still pictures include logos, video games, computer images, teletext and
images displayed in 4:3 mode.
CAUTIONS:
!The permanent after-image on the screen resulting from fixed image use is not an
operating defect and as such is not covered by the warranty.
!This product is not designed to display fixed images for extended periods of time.
Do not let images display in 4:3 mode for extended periods of time.
Cleaning and
Maintenance
To clean this unit, wipe with a soft, dry cloth.
If the surfaces are extremely dirty, use a soft cloth dipped in a soap and water solution or
a weak detergent solution.
!
!
!
Use eyeglass cleaner to remove stubborn dirt from the screen.
Never use alcohol, paint thinner or benzine to clean this unit.
Before using a chemically treated cloth, read the instructions that came with the
cloth carefully.
Important Notice
5

<Use the remote control by pointing it towards the remote sensor window of the
set. Objects between the remote control and sensor window may prevent proper
operation.
Cautions regarding use of remote control
<Do not expose the remote control to shock. In addition, do not expose the remote
control to liquids, and do not place in an area with high humidity.
<Do not install or place the remote control under direct sunlight. The heat may cause deformation of the unit.
<The remote control may not work properly if the remote sensor window of the main unit is under direct sunlight or strong
lighting. In such a case, change the angle of the lighting or the TV set, or operate the remote control closer to the remote
sensor window.
If the remote control fails to operate the TV functions, replace the batteries in the remote control.
Precaution on battery use
! Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.
1. Place batteries with their terminals corresponding to the (+) and (–) indications.
2. Different types of batteries have different characteristics. Do not mix batteries of different types.
3. Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old batteries
to leak chemicals.
4. Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a rash. If chemical leakage is
found, wipe with a cloth.
5. If the remote control is not used for an extended period of time, remove the batteries from the remote control.
6. The batteries (battery pack of batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
! Dispose of batteries in a designated disposal area.
! Batteries should always be disposed of with the environment in mind. Always recycle or dispose of batteries in accordance
with applicable laws and regulations.
Open the battery cover.
1
<(Place the batteries with their terminals corresponding to the (+)
and (–) indications in the battery compartment.)
Insert two size AAA batteries.
2
Replace the cover.
3
Preparations
Using the Remote Control
Installing the Batteries
6

Connect the power cord to the AC IN jack, then plug the other end into a power outlet.
= This illustration is for reference only. The AC plug may be different on different models.
=This product should be operated only from the type of power source indicated on the marking label.
=Always unplug the AC cord from power outlet when not using for a long period of time.
INSTALL the unit in a room where direct light will not fall upon the screen. Total darkness or a reflection on the picture
screen may cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.
Optimum reception of colour requires a good signal and will generally mean that an outdoor antenna must be used.
The exact type and position of the antenna will depend upon your particular area.
=It is recommended that the 75-ohm coaxial cable be used to eliminate interference and noise which may occur due to radio wave
conditions.
=The antenna cable should not be bundled with the power cord and the like.
=If the antenna is not installed properly, contact your dealer for assistance.
Antenna Connection
Preparations (Continued)
Power Connection
Note:
Note:
7
Plug into AC outlet.
AC cord
Household
power outlet
Wall Antenna Socket
RF Coaxial Cable(75 ohm)
AC IN

Main Unit (control panel)
Identification of Controls
Functions of CH5/6, VOL4/3, MENU, INPUT and POWER are also provided to the remote control. This operation
manual provides a description based on operating functions with the remote control.
1. POWER
2. INPUT
To access INPUT SOURCE menu
3. MENU
Press this button to access the menu main page
4. VOL
Press the VOL or VOL button to directly increase or decrease the sound volume level;
In menu operations, these buttons serve as right/left buttons.
5. CH
Press these two buttons to directly change the TV channel;
In menu operations, these buttons serve as up/down buttons.
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
4/3
43
5/6
Note:
8
Power Indicator
Remote Sensor
Channel Up/Down
Volume Up/Down
MENU
Input Source Select
Power On / Standby

Main Unit (connectors)
Identification of Controls (Continued)
1AC POWER: Connect the power cord to this jack, then plug the other end into a power outlet.
SERVICE PORT: For software update only. Do not use.
HDMI11/2: HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-digital audio/video interface
between this TV and any HDMI-equipped audio/video component, such as a set-top box and DVD player. HDMI
supports enhanced, or high-definition video, plus two-channel digital audio.
VGA PIC/AUDIO: Connect a computer to these jacks.
COMPONENT IN: Connect a component video device to these jacks.
AV1INPUT: Connect an AV device to these jacks.
AUDIO OUT: Connect an audio device such as audio amplifier to these jacks.
RF: Connect an antenna or cable TV to this jack.
S-VIDEO: Connect an S-Video device to the jack, then connect the audio to the AV1 IN audio jacks.
RS-232: For service only. Do not use.
AV2 INPUT: Connect an AV device to these jacks.
Headphone: Connect headphones to this jack.
9
2
3
4
5
6
7
8
9
10
11
12
11
3
12
2 43 5 6 7 8 9 101

Remote Control Unit
Identification of Controls (Continued)
10
POWER : Switches the TV power on or Standby.
ZOOM: Selects the screen size.
INPUT: Displays input source menu.
COMP/HDMI/VIDEO/TV: Direct input source select
COMP: Press to access Component mode.
HDMI: Press once to access HDMI 1 mode, press twice to access
HDMI 2 mode.
VIDEO: Press once to access AV1 mode, press twice to access
AV2 mode, press the third time to access S-Video mode.
TV: Directly access TV mode.
0 – 9 number buttons: Press to enter channel numbers or
input password.
RECALL: Recalls the last viewed channel.
VOL+/-: Increases or decreases the volume.
MUTE: Mutes the sound.
GUIDE: Press to display the program guide information (if
available) when watching a DTV program. You may be able to
view program broadcasting time and program name from the
guide.
5/6/3/4: Menu navigation buttons.
5/6: Press to move up or down in the menu.
3/4: Press to move left or right in the menu or to adjust a
menu setting.
ENTER: Press to confirm a selection and/or enter into a sub-
menu.
MENU: Displays the main menu screen.
SLEEP: Sets the sleep timer.
MTS/SAP: To select STEREO, SAP or MONO sound in analog
TV mode. To select audio track in DTV mode.
CCD: Press to turn closed captioning on or off.
CH-LIST: Displays a channel list.
Dot ( )button: Press to enter a program number for multiple
program channels such as 2-1, or 2-2.
CH+/-: Changes channel up and down.
FAVORITE: Displays the favorite program list.
DISPLAY: Press to display the information banner.
EXIT: Press to exit the menu.
PICTURE: Selects picture mode.
AUDIO: Selects sound mode.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

Connecting a VCR
Carefully check the terminals for position and type before making any connections.
The illustration of the external equipment may be different depending on your model.
Loose connectors can result in image or colour problems. Make sure that all connectors are securely inserted into their
terminals.
Refer to the operating manual of the external device as well.
When connecting an external device, turn the power off to avoid any issues.
Cautions Before Connecting
Connections
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and VCR.
Note: For better video, you can use the S-Video terminal if your source supports it.
How to connect:
1. Turn on your TV, then press INPUT button. The INPUT SOURCE menu opens.
2. Press 5or6to select AV1or S-Video, then press ENTER to confirm.
(Or you can press VIDEO button one or more times to select directly. )
3. Turn on your VCR , insert a videotape and press the Play button.
To play VCR
Note:
· AV1 and S-Video connection share the same audio jacks.
AV cable
TV REAR
VCR
S-VIDEO
S-VIDEO
cable
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
11

Connecting a Camcorder
Connections (Continued)
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and camcorder.
How to connect:
To playback Camcorder
Note:
The operations of the camcorder may be different and is dependant on your model. Please read the user manual of your
camcorder to confirm operation.
1. Turn on your TV, then press INPUT button. The INPUT SOURCE menu opens.
2. Press 5or6to select AV2, then press ENTER to confirm.
(Or you just press VIDEO button twice to go to AV2 mode directly.)
3. Turn on your camcorder and set it to output mode. (For details, refer to your camcorder user manual.)
4. Insert the tape into the camcorder and press Play button.
or
AV cable
Camcorder “PlayStation”
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
TV Side
Connecting an Audio Amplifier
Connect the Audio cables between the Audio (L/R) jacks on the unit and Audio System.
How to connect:
TV REAR
Cables are often color-
coded to connectors.
Connect red to red, white
to white.
AV cable
12
Audio System
To improve sound quality, you may connect your audio system to this TV’s audio output jacks to enjoy a high-quality sound
from the audio system.
1. Turn on your TV, select a program.
2. Turn on your audio system, and adjust the volume and other audio settings through your audio system.
To play audio system

Connections (Continued)
Connecting an HDMI device
Connect the HDMI cable between the HDMI interface on the unit and HDMI output on the device.
To play from the device using HDMI:
How to connect a device using HDMI Connection:
1. Turn on your TV, then press INPUT button. The INPUT SOURCE menu opens.
2. Press 5or6to select HDMI 1, then press ENTER to confirm.
(Or you just press HDMI button to select directly.)
3. Turn on your device and set it to the correct mode. See the device’s user guide for more information.
! If HDMI2 interface is used, please select HDMI2 mode.
! If the external device has DVI output only, use a DVI to HDMI adapter cable to connect to the HDMI terminal. Connect the
audio cable to the VGA AUDIO IN jack on the TV rear.
Note:
HDMI cable
Device with HDMI output
TV REAR
Connecting a Computer
How to connect:
1. Turn on your TV, then press INPUT button. The INPUT SOURCE menu opens.
2. Press5or6to select VGA, then press ENTER to confirm.
3. Turn on your computer, and adjust the display properties as required.
To play video from a computer
Connect a VGA cable between the VGA jack on the computer and the VGA input jack on the unit.
Connect an Audio cable between the AUDIO output on the computer and AUDIO input jack on the unit.
13
D-Sub cable
(analog RGB) To monitor port
(15-pin D-Sub)
To audio output jack
Audio cable
(stereo mini plugs)
TV REAR

Connecting Component Video
Connections (Continued)
To connect a device using component video:
1. Turn on your TV, then press INPUT button. The INPUT SOURCE menu opens.
2. Press 5or6 to select Component, then press ENTER to confirm.
(Or you just press COMP button on the remote control to select directly)
3. Turn on your external device and set it to the correct mode. See the device’s user guide for more information.
To play component video from an external device:
Connect the Component Video cable between the Y, Cb/Pb, Cr/Pr input jacks on the unit and Y, Cb/Pb, Cr/Pr output jacks
on the device .
Connect the Audio cable between the AUDIO input jacks on the unit and AUDIO output jacks on the device.
14
Component video cable
Audio cable
Device with component video
TV REAR
Cables are often color-coded
to connectors. Connect red to
red, white to white, etc.
Insert the plug of the headphone into the TV’s Headphone jack.
When using headphones, adjust the headphone volume so as to avoid excessive levels, as hearing damage may result.
Headphones
Connecting Headphones
TV Side

Basic Operations
With the power on, press the Power button on the unit or on the remote control to turn off the unit, and put the unit in
standby mode. To cut off the power completely, please disconnect the AC power cord.
Turning On
Insert the power cord into the wall outlet.
Press the Power button on the unit or on the remote control, the unit will be turned on and you will be ready to use its
features.
Turning Off
Turning On/Off the Power
Selecting the Input Signal Source
1
2
Press INPUT button.
Press 6or 5to select the input source. Options include:
On-Screen Menu Language Selection
1
3
Press MENU.
Press 5 or 6to select Menu Settings item, press ENTER to access.
Press 3or4to select Setup menu, press 6 to access the menu.
2
5Press EXIT to close the menu.
15
Note: If there is no signal input for a certain time, the TV will auto go to standby mode.
TV
AV2
S-Video
Component
HDMI1
HDMI2
VGA
INPUT SOURCE
AV1
4Press 5 or 6to select Menu Language item, press 3or4to select
your desired language.
Select Move MENU Exit
Transparency 25%
Menu Language English
Select Move MENU Exit
Time
Closed Caption
VGA Settings
Input Label
Restore Default
Audio Only
Audio Channel
Parental Controls
Off
SetupPicture
Menu Settings
Press ENTER
3Press ENTER button to confirm the selection.
!TV — Watch the TV signal.
!AV1 — Watch the signal from the AV 1 input terminals.
!AV2 — Watch the signal from the AV 2 input terminals.
!S-Video — Watch the signal from the S-VIDEO input terminal.
! Component — Watch the signal from the COMPONENT input terminals.
! HDMI1 — Watch the signal from the HDMI 1 input jack.
!HDMI2 — Watch the signal from the HDMI 2 input jack.
! VGA — Watch the signal from the VGA jack.
Note:
On the remote control four direct input source select buttons (VIDEO/COMP/HDMI/TV) are provided.
=
VIDEO button: Press once to select AV1, press twice to select AV2, press three times for S-Video.
=
COMP button: Press to select Component.
=
HDMI button: Press once to select HDMI1, press twice to select HDMI2.
=
TV button: Press to select TV.
Audio Channel SetupPicture

Basic Operations (Continued)
Main Menu Overview (TV mode)
Picture menu
Picture Mode
Contrast
Brightness
Color
Tint
Sharpness
Advanced Video (including Color Temp., Mode, Zoom
Noise Reduction, Overscan, items)Adaptive Contrast, Auto Zoom
Audio menu
Sound Mode
Bass
Balance
AVC
Channel menu
Air/Cable
Auto Scan
Favorite
Show/Hide
Channel No.
Channel Label
DTV Signal
List of main menus to help you with operations
Note
=Depending on the signal tuned, you may see different menu options on your screen. The above main menus are illustrated under TV
mode.
=Menu items that are not selectable are grayed out. If without special indication, this manual is described under TV mode.
=The illustrations and on-screen displays in this manual are for explanation purposes (some are enlarged, others cropped) and may vary
slightly from the actual ones.
(Refer to <Adjusting PICTURE Menu
Options> section for details.)
16
Select Move MENU Exit
Picture Mode
Contrast
Brightness
Color
Tint
Advanced Video
Custom
70
40
60
0
Sharpness 50
Treble
Surround
(Refer to <Adjusting AUDIO Menu
Options> section for details.)
Setup menu
Parental Controls
Time
Closed Caption
Menu Settings
VGA Settings
Input Label
Restore Default
Audio Only
Select Move MENU Exit
Time
Closed Caption
Menu Settings
VGA Settings
Input Label
Restore Default
Audio Only
Parental Controls
Off
Select Move MENU Exit
Auto Scan
Favorite
Show/Hide
Channel No.
Channel Label
DTV Signal:
Air/Cable Cable
2.1
Good
(Refer to <Adjusting SETUP Menu
Options> section for details.)
(Refer to <Adjusting CHANNEL Menu
Options> section for details.)
WGBH-SD
Select Move MENU Exit
Sound Mode
Bass
Treble
Balance
Surround
Audio Language
Custom
57
50
50
AVC
Off
English
Off
Audio Language
Audio Channel SetupPicture
Audio Channel SetupPicture
Audio Channel SetupPicture
Audio Channel SetupPicture

Basic Operations (Continued)
Note: To clearly introduce the menu operations, this
operation manual provides a description based on
operation with the remote control.
Menu Navigation
Press to display the Main menu.
1.
2.
Press to select menu.
3. Press to enter the menu field.
4.
Press to select menu items.
Press to confirm your operation, or enter the sub-menu.
Press to adjust the selected items or move the on-screen cursor leftward or rightward .
Pressing4also can enter the sub-menu.
5. Press to return to previous screen.
6. Press to close the menu.
Channel Selection
Digital sub-channels
A digital TV signal transmits more data than an analog signal. This ncrease in data provides a better picture and sound
with less static and interference.
The increased data capacity of a digital signal also lets broadcasters fit several channels into the same bandwidth as an
analog signal. Broadcasters may use these sub-channels to transmit a variety of information, such as weather forecasts,
foreign languages, commercials.
A digital sub-channel is indicated by the main channel number followed by a dot and the sub-channel number. For
example, 5.1 indicates sub channel 1 of the main channel 5.
i
You can use the following ways to change channels:
! Press CH+ or CH- to go to the next or previous channel in the memorized channel list.
! To select an analog channel, press the number buttons for the channel you want, then wait for the channel to change or
press ENTER to immediately change the channel.
! To select a main digital channel, press the number buttons for the main channel, then wait for the channel to change or
press ENTER to immediately change the channel.
! To select a digital sub-channel, press the number buttons for the main channel, press the dot(.) , then press the number
button for the sub channel. Wait for the channel to change, or press ENTER to immediately change the channel.
Note: Button presses must be within three seconds of each other.
! To go to the last channel viewed, press RECALL.
! To select a channel from the memorized channel list, press CH-LIST, press 5 or 6 to select the channel, then press
ENTER.
! To select a favorite channel from the favorite list, press FAVORITE, press 5 or 6 to select the channel, then press
ENTER.
Note: If the list has more than one page, press 3or4to scroll through the pages.
17

Basic Operations (Continued)
Press the VOL + or VOL- to increase or decrease the volume.
Press the MUTE button to temporarily turn off all sound. To restore the sound, press the MUTE button again.
Adjusting the Volume
Using the volume buttons (VOL+ and VOL – )
Using the Mute
Displaying the Information Banner
In DTV mode, your TV can display a program guide, if available. The guide may show a list of available programs, program
times, and program summaries. The displayed information is provided by the DTV channel.
! Press GUIDE, the program guide opens. If there is additional program information, press this button to display the
information.
! To close the program guide, press this button or wait a few seconds and the banner closes automatically.
Displaying the DTV Program Guide
You can press DISPLAY button to display information banner. The information banner will display current program
information such as channel number, or video input source, resolution, etc. To close the banner, press this button again or wait
a few seconds and the banner closes automatically.
l Some DTV programs’ information banner may not contain all the above information. It will vary depending on the
broadcaster and your setting.
Note:
In analog TV mode, it will display the following information:
- Channel number
- Channel label (if preset)
- Signal type
- Audio information (Stereo or SAP or Mono)
- Resolution
In DTV mode, it will display the following information:
- Channel number and station name
- Channel label
- Broadcast program name
- TV rating
- Signal type
- Audio information
- Resolution
- CC mode
- Current time, current program start and end play times
18
