User Manual
XT-18AP-Dual band 1200Mbps Ceiling AP
POE
This is the user manual of XT-18AP, Dual band 2.4G &5.8G, 1200Mbps Ceiling AP, which
will approximate guide you how to set and apply the Ceiling AP, it provide a convenient
graphical interface for network construction and maintenance person, as well as a user
through a simple and accurate operation, and configuration management of the ceiling
wireless access point.

1st Hardware and Operation mode Instruction
LED indicator:
Green: Power Indicator
Blue: WiFi Indicator
AP Interface:
RST: Reset Button, it make AP revert to default data after press it 15 seconds.
WAN: Gigabit WAN Port, connect with ADSL modem or Internet mainly. It will be LAN port under Wireless AP and WiFi
Repeater operation mode
LAN: Gigabit LAN Port to end users
LED: LED Indicator of WAN port and LAN port
DC: DC power connector
Power Supply:
1. PoE Adapter Power Supply:
The connection diagram showed as P1, internet cable connect to PoE adapter’s LAN Port, Ceiling AP’s WAN port
connect to PoE adapter’s PoE Port, then PC will access into ceiling AP through cable or wireless
Pls note, if the PD Wireless AP support 24V passive PoE, then the PoE adapter should be 24V Passive PoE,.
If the PD wireless AP support 48V IEEE 802.3af standard PoE, the PoE adapter should be 48V PoE standard.
P1
2. Powered by PoE Switch
The connection diagram shows as P2, Internet cable from PoE Switch to Ceiling AP’s WAN Port, then PC access into

ceiling AP wired/wireless.
Pls note, if the PD Wireless AP support 24V passive PoE, then the PoE switch should be 24V Passive PoE,.
If the PD wireless AP support 48V IEEE 802.3af standard PoE, m the PoE switch should comply with 802.3af 48V PoE
standard.
P2
Operation Mode:
There are three operation mode on this wireless AP:
P3 Operation Mode
Connect Wireless AP with PC:
Use can connect the PC with wireless AP by Wireless SSID and LAN cable:
The diagram of wireless connection showed as follow:
Pls note: the default SSID is WirelessAP2.4G/5.8G, S SID ’s passw or d is 6 66 6 66 6 6

The diagram of LAN cable connection showed as follow:
2nd：Login
1）Connect the Ceiling AP with computer
2）Configure the PC’s local connection IP address as 192.168.188.X (X is number from 2 to 254), subnet mask is
255.255.255.0, follow P4 and P5 to finish.
P4 Setting of computer’s IP address

P 5 Setting of computer’s IP address
3) Input 192.168.188.253 into IE browser, then pop up the login page, the default login user name: Admin,
Passwords: admin, pls do following P6
P6 Login

3rd: WEB GUI interface Setting:
1) Status
After login, then P7 Device Status will be showed:
P7: Device Status
In this ceiling wireless AP, the default operation mode is AP mode.
Then in 2.4G Wireless Setting, GUI configuration page showed as below:
User can configure the SSID, password, band width, channel here, then Apply to finish.

P8. 2.4G Wireless setting
5.8G Wireless Setting GUI configuration setting showed as P8:
P9 5.8G Wireless Setting
LAN Setting to configure the DHCP or Fix IP

P10 LAN Setting
AP location setting: can mark where the AP set up, and AP name as P11:
P11 AP Position setting

2) Wizard Configuration:
Click Wizard in Status page, will pop up following page to configure the operation mode:
There are four operation mode of this ceiling wireless AP, and there are explanation for each operation mode for better
application.
P12 Operation mode
1. Gateway Mode:
Click Gateway mode, will pop up following pictures:
Pls choose the right WAN setting mode, then click next to continue.
P13. WAN setting in Gateway Mode

P14 Wireless Setting in Gateway Mode
When click Next, then will complete the Gateway mode setting and show following picture:
P15 Complete the setting in Gateway Mode

When return to Status, the page showed as follow:
P16 Status in Gateway Mode
2. WiFi Repeater mode
Click WiFi Repeater operation mode in Wizard, then following page will pop up, and choose the right SSID to bridge, then
next.
P17 Repeater Mode

After click Next button, then should configure the wireless settig as follow, then click Next to finish:
P18 Wireless Setting in Repeater Mode
Click Return button, will back to Status, show Repeater mode data, show fail or success and user can configure this
data in this page if required.
P19 Status in Repeater Mode
Pls note, when click wireless relay setting, following page will pop up, you can make change from here easy:

P20 Wireless Relay Setting
3. AP Operation mode:
Set the wireless data,AP Location info as required, then click next to continue and enter into LAN setting.
After LAN setting, complete the AP mode configuration and back to Status:

P26 Wireless setting in AP Mode
P21 LAN Setting in AP Mode
P22 Status in AP Mode
3) Advanced Setting:
In advanced setting, user can check the ceiling AP’s firmware version, working status, 2.4G wireless, 5.8G Wireless, LAN
Status,

upgrade firmware, Reset...
Let’s Click Advanced Setting in status page, will show return home, Setup Wizard which we showed before.
Let’s shown mode in Device Status, 2.4G Wireless, 5.8G Wireless, Network and Management.
P23 Device Status
Device Status: In this page, mainly to check the ceiling AP’s status in firmware version, 2,4G Wireless, 5.8G Wireless
and LAN status:
P24 2.4G Wireless Status

P25 5.8G Wireless Status
P26 LAN Status
2.4G Wireless Setting:
In this part, will show the 2.4G Basic Setting, Virtual AP, Access control and Advanced Setting:

P33 Basic Setting in 2.4G Wireless
P27 Wireless Analyzer
Virtural AP:
There are 3 virtural AP in 2.4G wireless, if need virtural SSID, then users can configure it showed in following picture:
P28 Virtual AP
2.4G Access Control: Mainly show MAC allow or deny:

P29 MAC Access Control
P30 Network Setting

P31 Tag VLAN Setting
Management:
In this part, show the system time, Logs, upgrade firmware, system, user info.
And we show System time, how to upgrade firmware and system page to users:
P32 System Time

P33 Firmware Upgrade
P34 System info
4th Share Internet and Obtain IP address automatically
Set computer’s TPC/IP as Obtain an IP address automatically, Obtain DNS server address automatically as following
picture showed.
