Xpreen XPRE067 User manual

User Manual
Xpreen
Professional Light Teeth Whitening Kit
XPRE067
Dear customer, thanks for purchasing Xpreen Professional Light Teeth Whitening Kit.
This detailed user manual will help you get to know the product and its usage better.
Please read the user manual carefully before use and keep it for future reference.
Product Features
1. The device adopts cold-light teeth whitening technology, which uses high-intensity
blue light between 480-520nm, conducted by optical fibers, to pass through two 30-layer
coated special optical lenses, and then subject the blue light to special optical processing
to separate harmful UV light and infrared rays. Cold-light teeth whitening is a new
popular teeth whitening technology around the world. The cold-light of low temperature
causes no irritation to dental nerves during the whitening process. It can not only remove
stains on the teeth surface, but also whiten teeth from the deep part in a safe and
effective way. It's clinically proven to whiten teeth 5-14 Vita shades, more effective than
other similar products and common home-use teeth trays.
2. In order to achieve better teeth whitening effect, the teeth whitening kit is equipped
with newly developed teeth whitening gel. Reactive oxygen nondestructive formula was
used to make the gel mild and stable, which causes no soreness or irritation to gums and
does no harm to teeth structure or enamel. It's totally safe to use. Under the cold blue
light, oxidation-reduction quickly takes place on the teeth surface and active ingredients
penetrate into dentinal tubules to remove variety kinds of stains on and inside the teeth.
3. The teeth whitening kit is equipped with a powerful cold light controller and
ergonomically designed teeth tray. The cold-light energy is precisely controlled by built-
in exclusive cold-light chip and LED constant current output voltage. 2000mAh Li-
battery allows long time running and advanced type-c port makes charging more
convenient. The teeth tray is made of food-grade silicone, soft and comfortable, safe and
waterproof.
Product Overview （标黄部分字体可以大些以区分不同部件）
Cold-light Controller
Output Port/Charging Port

LCD Screen
Multifunction Button (1. Power On/Off; 2. Start Woking; 3. Pause/Continue)
Mode Button
Cold-light Teeth Tray
Type-c Connector
Teeth Whitening Gel
Teeth Tray Case
Precautions
1. The teeth are easily to be stained within 24 hours after the whitening process. Please
avoid eating deep colored food, drinking tea/coffee/cola/red wine/berry drinks, using
colored toothpaste/mouthwash, or smoking.
2. Porcelain teeth are not suitable for cold-light teeth whitening because this teeth
whitening method doesn't work on porcelain crown or filling.
3. Severe tetracycline teeth, dental fluorosis, or severe discolored teeth caused by other
reasons are not suitable for cold-light teeth whitening.
4. Do not swallow the teeth whitening gel. Avoid direct contact with children.
5. Pregnant women, people under the age of 16 and people with severe periodontal
diseases are not suitable for cold-light whitening.
Application Range
1. Yellow/black/gray teeth caused by smoking, drinking tea/coffee/red wine, eating betel
nut and other food;
2. Age-related yellow/black/gray teeth;
3. Yellow/black/gray teeth caused by mild and moderate tetracycline teeth, dental
fluorosis, etc.
4. People who want to have whiter and brighter teeth.
5. Different people have different teeth, so the whitening effect will be different, too.
This is normal.
Non-Application Range
1. Artificial teeth such as porcelain teeth and dentures;
2. Discolored teeth caused by diseases or drugs;
3. Yellow/black/gray teeth caused by severe tetracycline teeth, dental fluorosis, and
decayed teeth;
4. Incomplete enamel, dentin exposure, loose teeth and incomplete teeth;
5. People with severe allergies, pregnant women and children.

Tips
Tetracycline Teeth
During the growth of teeth, people, especially children under the age of 8 and pregnant
women, are easily to have teeth colored when taking tetracyclines (such as tetracycline,
oxytetracycline, doxycycline, etc.), which is called tetracycline stained teeth. This is
because tetracyclines will bind to calcium ions in dental tissues and stable tetracycline
calcium salts form. The discoloration will gradually get worse with age and tend to be
stable after 18 or so.
Dental Fluorosis
Dental fluorosis is mainly caused by excessive fluoride in drinking water. People with
mild symptom have opaque and chalky teeth; People with moderate symptom have
yellow or brown-yellow spots on the teeth surface; People with severe symptom have
incomplete enamel along with discoloration.
Pigmentation
Pigmented teeth are ideal for cold-light teeth whitening treating. If people smoke, drink
tea/coffee or eat food with soy sauce for a long term while keeping a bad teeth cleaning
habit, the pigments in these things will gradually deposit and penetrate into the deep part
of their teeth, thus make teeth surface yellow and black. Like ordinary washing cannot
make clothes as white as before after long time dyeing, ordinary teeth whitening method
cannot make stained teeth as white as before, too.
Charging Methods
1. Connect the cold-light controller with an adaptor (not included) via the type-c
charging cable.
2. Plug into the power supply. The LCD screen will light up and the battery symbol will
scroll during charging.
3. The solid battery symbol represents the charging is finished, which usually takes
about 3.5 hours.
Note -- The battery may be exhausted after long-distant transport. Please fully charge the
controller before first time use.
Application Methods
1. Brush and rinse; make your oral clean and teeth dry.
2. Open the teeth tray case and take the cold-light teeth whitening tray out. Then insert
the type-c port into the cold-light controller.
3. Unscrew the lid of the teeth whitening gel. Do not discard the lid for future use.
Rotate the bottom of whitening gel clockwise until the gel overflows into the brush head.

4. Paint the whitening gel on your teeth back and forth. Avoid direct contact with gums.
You can paint more gel on ugly teeth.
5. The instructions of the cold-light controller
a. Press and hold the multifunction button (MFB) for 2 seconds to turn it on. (Turn it off
by the same way.)
b. The default mode is the 30-minute mode. And the mode will be shown on the LCD
screen. Short press the mode button to select certian mode.
Note -- There 4 modes: 5 minutes, 10 minutes, 15 minutes and 30 minutes.
c. Press the MFB to begin your teeth whitening process.
Note -- During the process, you can press the MFB to pause at any time and press it
again to continue.
6. Place the teeth tray in your mouth and bite down gently. Then turn on the controller
and choose desired mode. And the teeth whitening process begins.
Note -- It's recommended to put the teeth tray in your mouth before turning on the
controller in order to avoid discomfort to eyes caused by sudden light.
Note -- It's recommended to lie on the side or lie down to prevent saliva from
overflowing during the whitening process. It's safe to swallow saliva during the
whitening process, and by doing this, the whitening gel won't be diluted so the whitening
result won't be affected. It's recommended to watch videos or TV programs to distract
your attention. Thus, you will find the whitening process more pleasant and faster.
7. There is a built-in memory chip in the cold-light controller, and it memorizes you last
choice each time use, so you don't have to choose modes again if there is no need. To
save energy, the controller will turn off automatically while there's no operation more
than 10 minutes.
8. The cold-light controller is equipped with a 2000mAh battery to support long runtime.
The battery symbol on the LCD screen will flash when the battery is low. Please charge
in time. The battery symbol will scroll during charging.
Note -- It's recommended to protect the battery by charging the device every other month
if it is not in use for a long time.
9. When time's up, the controller will stop work automatically and the cold-light beads
will go out automatically. Then take the teeth tray out of your mouth and clean your
teeth by brushing or gargling. Remember to clean the teeth tray and put it back to its
case.

10. It's recommended to choose the 5-minute mode for the first time use and select other
modes gradually. Besides, it's recommended to use the device for about 30 minutes each
time for better teeth whitening effect.
Note -- Different people have different oral conditions. It's normal that some people
produce a lot of saliva during the whitening process. It's recommended to pause for a
while, spit out saliva, and then continue the process.
11. Please use up the whitening gel in three months once it's unsealed. Please rinse and
dry the bristles after each use. Wash with clean water if your skin or clothes get contact
with the whitening gel accidentally. Keep the product out of reach of children.
12. It's recommended to use the teeth whitening kit for consecutive 7-10 days and 15-30
minutes each time. It's best to use before bed.
13. Different people have different oral conditions. If irritation (such as redness,
swelling, soreness) of the gums or the mouth occurs, discontinue use and consult a
dentist.
Whitening Effect
The whitening effects may vary based on different teeth conditions. The teeth will be
whitened 10 shades after using for consecutive 5-8 days.
Specifications
Model: XPRE067
Name: Professional Light Teeth Whitening Kit
Output: 5V
Input: 5V
Working Current: 240mA
Battery Capacity: 2000mAh
Material (Cold-light Teeth Tray): Food-grade Silicone
Ingredients (Teeth Whitening Gel): Hydrogen Peroxide, Carbomer, Menthol, ETDA,
Glycerin, Sodium Hydroxide.
Package Contents
1 * Cold-light Teeth Tray
2 * Teeth Whitening Gel
1 * Teeth Tray Case
1 * Type-c Charging Cable
1 * Color Card
1 * User Manual

FAQ
1. What kind of dental problem does cold-light teeth whitening work on?
Cold-light teeth whitening especially works on tobacco-stained teeth, tea-stained teeth,
dental fluorosis and yellow teeth.
2. How long will it take to see the whitening effect?
Generally, the whitening effect can be seen in 5 days if correct instructions are followed.
And for darker colored teeth, obvious whitening effect can be seen after 10-day use.
3. How long will the whitening effect maintain?
The actual time may vary depending on different eating habits and teeth structures. The
whitening effect will maintain 1-2 years on average.
4. Is the cold-light teeth whitening kit safe? Will it damage my teeth?
Cold-light teeth whitening is a safe and fast teeth whitening technology. Low
temperature cold-light does no irritation to dental nerves. Under the cold blue light,
oxidation-reduction quickly takes place on the teeth surface and active ingredients
penetrate dentinal tubules to remove variety kinds of stains on and inside the teeth.
Faster and more effective. No irritation and no side effect. Safe for gums and enamel.
5. Who is not suitable for cold light teeth whitening?
Dead teeth is not suitable for cold light teeth whitening cause it will fade quickly after
whitening;
Cold-light teeth whitening doesn't work on porcelain crown or filling;
Severe tetracycline teeth, dental fluorosis, or severe discolored teeth caused by other
reasons are not suitable for cold-light teeth whitening.
Pregnant women, children under the age of 16 years and people with severe periodontal
diseases are not suitable for cold-light whitening.
6. How to maintain the cold light teeth whitening device?
The device needs no special maintenance. Just wipe the cold-light teeth tray with alcohol
(75%) or warm water after each use and then put it back to its case. Keep it in a cool, dry
place and avoid direct sunlight.

正面
品牌：Xpreen
产品名称：专业冷光牙齿美白套装
产品型号：XPER067
背面
Xpreen专业冷光牙齿美白套装
冷光美白是一项正流行于世界的最新牙齿美白技术，搭配独家配方的
美白凝胶，不仅可以去除牙齿表面的色素沉积，同时可进入牙齿深层
达到脱色的效果，并且安全有效。根据临床实验表明，使用冷光牙齿
美白技术，牙齿美白效果可提高5－14个vita色阶。
定期使用Xpreen专业冷光牙齿美白套装会为您带来更闪亮更迷人的笑
容！
特点
冷光牙齿美白技术
对牙神经无刺激
更安全更有效
人体工程学设计牙托
食品级硅胶材料
佩戴舒适，安全防水
Type-C接口，更方便
独家冷光控制器
2000毫安大容量电池
警告
如果牙龈或口部有刺激现象发生（如发红，发肿或酸痛），停止使用
并咨询牙医。
本产品不适合孕妇及16岁以下人士使用。
避免凝胶直接接触牙龈。
避免本产品直接接触眼睛。
放在儿童接触不到的地方。
成分（美白凝胶）
过氧化氢，卡波姆， 薄荷脑，ETDA，甘油， 氢氧化钠
材料
食品级硅胶
内含物品
冷光牙托一副
美白凝胶两支
牙托收纳盒一个
对比色卡一张
充电线一条
说明书一份

侧边
小亮点
冷光技术
无刺激
安全有效
Type-C接口
2000毫安电池
防水
人体工程学设计
食品级硅胶
使用方法
1.刷牙并擦干牙齿。
2.将牙托连接到控制器。
3.在牙齿上涂美白凝胶。
4.将牙托放入口中并开机。
5.选择合适时间并享受美白过程。
6.用完后，清洗牙托，刷牙。

Xpreen
Professional Light Teeth Whitening Kit
XPRE067
Xpreen Professional Light Teeth Whitening Kit
Cold-light teeth whitening is a new popular teeth whitening technology around the
world. With the special teeth whitening gel, this teeth whitening kit can not only remove
stains on the teeth surface, but also decolorize the deep part of teeth in a safe and
effective way. It's clinically proven to whiten teeth 5-14 Vita shades.
Regularly using Xpreen Professional Light Teeth Whitening Kit will bring you brighter
and more beautiful smiles all the time!
Features
Cold-light Teeth Whitening Tech
No irritation to Teeth Nerve
Safer and More Effective
Ergonomically Designed Teeth Tray
Food-Grade Silicone Teeth Tray
Comfortable and Waterproof
Convenient Type-C Interface
Exclusive Cold-light Controller
2000mAh High Capacity Battery
Warnings
If irritation (such as redness, swelling, soreness) of the gums or the mouth occurs,
discontinue use and consult a dentist.
The product is not suitable for the use of pregnant women and children under the age of
16.
Avoid direct contact of teeth whitening gel with the gums.
Avoid contact of the product with the eye.
Keep the kit out of reach of children.
Ingredients (The Teeth Whitening Gel)
Hydrogen Peroxide, Carbomer, Menthol, ETDA, Glycerin, Sodium Hydroxide.
Material (The Teeth Tray)
Food-grade silicone
Package Contents
1 * Cold-light Teeth Tray
2 * Teeth Whitening Gel
1 * Teeth Tray Case
1 * Color Card
1 * Type-c Charging Cable
1 * User Manual

Spotlights
Cold-light Tech
No Irritation
Safe & Effective
Type-C Port
2000mAh Battery
Waterproof
Ergonomic Design
Food-grade Silicone
How to Use
1. Brush and dry your teeth.
2. Connect the teeth tray with the controller.
3. Paint the teeth whitening gel on your teeth.
4. Put the teeth tray into mouth and turn the device on.
5. Select desired time and enjoy the process.
6. After use, clean the teeth tray and brush your teeth.
