Xpresskit CHRSALL RS-CHLCD User manual

RS-CHLED
Understanding the RS-623 Remote................................................................................
Using the RS-623 Remote...............................................................................................
Listing the Available Commands.....................................................................................
RS-CHLCD
Understanding the RSS-5224 Remote............................................................................
Using the RSS-5224 Remote..........................................................................................
Out of Range...............................................................................................................
Replacing the Battery..................................................................................................
Programming the Remote Control Features................................................................
Using your 1-Way Remote Control..............................................................................
Using your 2-Way Remote Control..............................................................................
Understanding the Confirmations Emitted by the 2-Way Remote...............................
Upon Entering your Vehicle.........................................................................................
02
02
03
04
05
05
05
06
06
07
07
09
Cold Weather Start Feature............................................................................................. 09
Warranty.......................................................................................................................... 10
The RS-CHLED and RS-CHLCD kits each offer a complete remote start solution
including a 2-way LED or LCD transmitter/receiver and an all-in-one mobile
integration module.
RS-CHLED RS-CHLCD
Owner’s Guide
Index
TECHNICAL SUPPORT / INFORMATION
web resources:
www.xpresskit.com
www.xpressvip.com
www.directechs.com
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Understanding the RS-623 Remote
* Range based on line of sight, unobstructed testing in ideal conditions. Actual range will vary due to
local conditions including but not limited to environment, terrain, physical obstructions, vehicle
location and orientation, interference and other possible impediments.
2-way LED remote start kit with up to 1,500’ of range.*
The Astrostart RS-CHLED kit is a complete remote start solution, which includes a 2-way
LED transmitter/receiver and an all-in-one mobile integration module.
In the kit, you will find:
§1x 623-RX (Antenna).
§1x 623-TX (2-way transmitter).
§1x RF Interconnect Cable.
§1x CHALL Chrysler Interface.
§1x Xpress Start Plug-In Remote Start.
§1x CHTH1 T-Harness.
Affordable 2-way communication with 1500 feet range*, Simple LED read out for
confirmation of command and True confirmation of start via transmitter.
Using the RS-623 Remote
To ensure that commands are transmitted properly, press the desired button for 2
seconds. A command will not be executed if you do not press the button long enough.
The indicator light will flash while transmitting the command.
The remote included in your kit may differ from the one illustrated.
Page 2
The system can learn up to a maximum of 4
transmitters. Any transmitters can be stored in
more than 1 memory slot. When a 5th transmitter
is learned the 1st remote is erased (FIFO).
RS-CHLED
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Button Function
Lock the doors and arm the factory alarm.
Unlock the doors and disarm the factory alarm.
Open the trunk.
Panic ON: press the LOCK button and hold it for at least 4 seconds.
Panic OFF: press the UNLOCK button.
Start the vehicle.
Stop the vehicle (hold button for at least 4 seconds).
Set car to idle mode when it is already running.
Cold Weather Start feature (see page 9 for more information).
Open and close the sliding door (driver side). Only accessible with Chrysler Town & Country
2008-2010, Dodge Grand Caravan 2008-2010, and Volkswagen Routan 2009-2010.
The remote transmits a visual confirmation by means of an LED. Immediately following a
transmission, the LED will flash (single blink) green if the command was successfully
received by the system or red if the command was not received.
In the case of a start command, the LED provides a first confirmation to acknowledge the
command reception by the system then, a second confirmation is sent to indicate if the
starting was successful or not.
Page 3
+
+
+
Listing the Available Commands
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

RS-CHLCD
Page 4
2-way LCD remote start kit with up to 5,000’ of range.*
The Astrostart RS-CHLCD kit is a complete remote start solution, which includes a 2-way
LCD transmitter/receiver and an all-in-one mobile integration module.
In the kit, you will find:
§1x 5224-RX (Antenna).
§1x 5224-TX (2-way transmitter).
§1x 5224-TXC (1-way companion transmitter).
§1x RF Interconnect Cable.
§1x CHALL Chrysler Interface.
§1x Xpress Start Plug-In Remote Start.
§1x CHTH1 T-Harness.
If the vehicle is out of range, the transmitter will emit a soft chirp after 3 seconds to
indicate that the command has not been received by neither the module nor the
transmitter.
The RSS-5224 is the ultimate 2-way communication 4-button transmitter. It supports
multiple channels and vehicles, while providing a vehicle status indicator and command
confirmations with graphics, as well as audio tones.
A maximum of four remote controls can be assigned to your vehicle. See your dealer for
additional remote controls.
Understanding the RSS-5224 Remote
The range of your remote control can be affected by a weak battery, interference
from nearby metal structures, hydro poles, or crowded parking lots.
* Range based on line of sight, unobstructed testing in ideal conditions. Actual range will vary due to
local conditions including but not limited to environment, terrain, physical obstructions, vehicle
location and orientation, interference and other possible impediments.
The system can learn up to a maximum of 4
transmitters. Any transmitters can be stored in
more than 1 memory slot. When a 5th transmitter
is learned the 1st remote is erased (FIFO).
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

To send a command, press the corresponding button for two seconds. The command may
not be sent if the button is not pressed long enough.
The remote control beeps when a button is pressed, then emits eight short beeps during
the transmission, i.e. about one second after the button was pressed.
Your remote control can transmit on four different channels, allowing control of four
separate vehicles. Only the “Panic” command is transmitted on ALL channels
simultaneously.
To select a different channel, press the “P” button located on the back and hold it for 2
seconds, when the button is released the transmitter passes to the next channel.
The remote control shown may differ from the ones included in the kits.
Your system may be programmed in such a way that it can distinguish between two
groups of remote controls (maximum: two remotes per group). These groups let you
activate predefined settings (seat, mirror and other) when unlocking certain vehicles
(additional optional equipment required). This feature is available with certain firware only.
As soon as a command is sent, the remote switches over to standby mode in order to
receive and display confirmations sent by the command module installed in the vehicle.
These confirmations are sent to all the programmed remote.
These signals are transmitted only once and could be neutralized by radio or
electromagnetic interferences generated by electronic devices in the vicinity.
If no confirmation is received in a given location, move away from electronic devices and
activate the "Status” command. The start module will inform you of the status of door
locks, alarm (only if the Factory Alarm Trigger Monitoring feature is supported by the
firmware), and running of the engine.
Note that the communication between the vehicle and the transmitter operates in only one
direction at a time. This is why it is recommended to wait for the confirmation before
sending another command. Otherwise, the vehicle and the transmitter could transmit at
the same time wich would block the command as well as the returned confirmation.
Out of Range
If the vehicle is out of range, the transmitter will emit a soft chirp after 3 seconds to
indicate that the command has not been received by neither the module nor the
transmitter.
Replacing the Battery
The LCD of the 4-button remote has a battery icon telling you when to replace the battery.
We strongly recommend keeping a replacement battery in your glove compartment.
The remote controls require one AAA battery. See your dealer for spare batteries.
To replace the battery, slide the latch sideways and remove the battery cover on the back
of the remote control case, remove old battery and replace it with a new one. Make sure
the battery is placed the right way (see pictogram inside the cover).
Page 5
Using the RSS-5224 Remote
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Function Button
Lock the doors and arm the factory alarm. *
Unlock the doors and disarm the factory alarm. * ö
Open the trunk (hold button for at least 4 seconds).
Panic ON (hold button for at least 4 seconds).
Panic OFF
Start the vehicle.
Stop the vehicle. Ö
Set car to idle mode when it is already running.
Open and close the sliding door (driver side). **
Open and close the sliding door (passenger side). **
Cold Weather Start feature (see page 9 for more information).
Remote Valet feature.
Parameters Settings Button Display/Remarks
Lock
Unlock
Enabled
Disabled
Enabled
Disabled
Upon "Status" command
Upon any command
Never The back light shuts off.
Number of vehicles 1 - 4 (Default setting: 2) 1 2 3 4
The display lights up for
3 seconds.
Legend: DISPLAYED ICON (BLACK); MASKED ICON (GRAY); DEFAULT SETTING (BLUE).
Keyboard un/lock
Mute
Status confirmations
Back light
Refer to the vehicle user manual for more information on confirmations emitted by
your vehicle (i.e. the horn and parking lights). These confirmations are different for
each vehicle, depending on which module/firmware is used.
Note that the 1-way transmitter is automatically programmed.
Programming the Remote Control Features
To access the 2-way remote control programming mode, press the “P” button located on
the back of the remote and hold it for 5 seconds. The remote beeps once to indicate
entering programming mode.
/1BEEP
/2BEEPS
1BEEP
2BEEPS
/1BEEP
Using your 1-Way Remote Control
Page 6
+
+
/2BEEPS
+
+
+
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Page 7
*
Commands followed by an asterisk (*) apply only to modules equipped with a
security system.
** Only accessible with Chrysler Town & Country 2008-2010, Dodge Grand Caravan
2008-2010, and Volkswagen Routan 2009-2010.
ÖThis command terminates the runtime, panic mode and alarm status (only if the
factory alarm trigger monitoring feature is supported by the firmware).
öTemporary valet mode if activated a second time during rearming delay.
ÊStart confirmation can take a few seconds except if the engine is already running.
Legend: Displayed icons (black); Hidden icons (gray)
Refer to the vehicle user manual for more information on confirmations emitted by
your vehicle (i.e. the horn and parking lights). These confirmations are different for
each vehicle, depending which Bypass is used.
Convenience Security
Lock the doors and arm the factory alarm. *
Unlock the doors and disarm the factory alarm. * ö
Open the trunk (hold button for at least 4 seconds).
Panic ON (hold button for at least 4 seconds).
Panic OFF
Start the vehicle.
Stop the vehicle. Ö
Set car to idle mode when it is already running.
Open and close the sliding door (driver side). **
Open and close the sliding door (passenger side). **
Cold Weather Start feature (see page 9 for more information).
Remote Valet feature.
Status request.
Vehicle selection (hold button for at least 1.5 seconds.)
Confirmations
Sent by Remote Control
Function Button
This button is located on the
back of the remote.
Ê
/
/
+
+
+
Using your 2-Way Remote Control
+
+
Understanding the Confirmations Emitted by the 2-Way Remote
The LCD displays the vehicle status at all time, the display is refreshed on
every transmission or when the status of the vehicle changes pertaining that
the “Status confirmation” function is enabled. The display shows the last
confirmation received.
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Page 8
Two types of confirmations are displayed on the remote:
Command confirmation: These confirmations are command acknoledgement, the icon
corresponding to the command is displayed to confirm reception of the command.
Status confirmations: These confirmations are displayed when the status of a zone,
monitored by the system, changes (i.e.: door openning, security system alarm state (only
if the Factory Alarm Trigger Monitoring feature is supported by the firmware), etc. - it
depends on which firmware you are using).
Command confirmations are returned immediatly following a command transmission
whereas the status confirmations may be returned up to 12 seconds after the event
happened depending on the communication protocol between the hand-held unit and the
vehicle.
Remarks: When the remote receives a confirmation that is intended to a vehicle other that
the one actually selected, most audible confirmations are made more discreet, vehicle
icon flashes (1-4) to warn you that the display reflect the status of that specific vehicle.
This is only applicable if the Factory Alarm Trigger Monitoring feature is supported by the
firmware.
When a command is transmitted, the vehicle selection gets back to the previously
selected unless the confirmation was related to an alarm condition.
In that case the selected vehicle is temporarely changed, to allow stopping the alarm
condition without having to change the vehicle selection, then gets back to previously
selected when the alarm condition is stopped.
The following diagram shows the usefulness of each icon of the display. Descriptions in
CAPITAL letters show confirmations pertaining to the security system’s functions.
1 2 3 4 5
15
14 6
16
1 Transmission
Battery charge indicator
2 Vehicle out of range
Auxiliairy outputs status
Sentinel mode status
SECURITY SYSTEM STATUS
IGNITION STATUS SENSOR
Remote starter status
HOOD STATUS
Valet mode status
Vehicle identification
3 Reception
4 Unlocking
5 Locking
6
7
8
TRUNK LID STATUS
9
14
15
16
10
11
12
13
DOORS STATUS
9
13
12
11
7
10
8
* Only if the Factory Alarm Trigger Monitoring feature is supported by the firmware.
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

To activate the Cold Weather Start feature, press the LOCK and START buttons on the
remote control and hold for 4 seconds.
Press the LOCK and START
buttons and hold for
4 seconds. OR
Page 9
Out of range: In the event that the environement prevents the confirmation from being
received by the remote control, all icons are cleared out. In this case, resend the
command or send the status command to refresh the display.
Cold Weather Start Feature
Upon Entering your Vehicle
DO NOT TURN IGNITION KEY TO START POSITION.
To avoid turning the engine off when
taking place behind the steering wheel, do
not apply the brakes until you have placed
the key in the ignition and turned it to the
RUN position.
To avoid turning the engine off when
taking place behind the steering wheel, do
not apply the brakes and do not remove
the parking brake until you have placed
the key in the ignition and turned it to the
RUN position.
Drive as usual. Drive as usual.
Automatic transmission vehicles Manual transmission vehicles
The parking lights will flash once to confirm the operation.
The engine will be started every 3 hours or 1.5 hours and will run for a period 15 minutes
or 5 minutes. The runtime is defined with function option 16. The default value is every 3
hours for 15 minutes.
The Cold Start Weather feature is deactivated after 24 hours or once the hood is open.
To deactivate the Cold Weather Start feature, press the LOCK and START buttons again.
The parking lights will flash twice to confirm the operation.
This feature will also be disabled if the:
§Remote Valet feature is activated.
§Ignition is turned on.
§Brake pedal is pressed.
§Hood is opened.
§Engine is not turned on within 24 hours.
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD

Limited One-year Consumer Warranty
Page 10
For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security
product,DirectedElectronics.(“DIRECTED”)promises totheoriginalpurchaser,torepairorreplacewith
a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”),
which proves to be defective in workmanship or material under normal use, provided the following
conditions are met: the Part was purchased from an authorized DIRECTED dealer; and the Part is
returned to DIRECTED, postage prepaid, along with a clear, legible copy of the receipt or bill of sale
bearing the following information: consumer’s name, address, telephone number, the authorized
licenseddealer’snameandcompleteproductandPartdescription.
This warranty is nontransferable and is automatically void if the Part has been modified or used in a
manner contrary to its intended purpose or the Part has been damaged by accident, unreasonable use,
neglect, improper service, installation or other causes not arising out of defect in materials or
construction.
TOTHEMAXIMUMEXTENTALLOWEDBYLAW,ALLWARRANTIES,INCLUDINGBUTNOTLIMITED
TO EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS
FOR PARTICULAR PURPOSE AND WARRANTY OF NON INFRINGEMENT OF INTELLECTUAL
PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR
AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR
LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED HEREBY DISCLAIMS AND HAS
ABSOLUTELY NO LIABILITY FORANYAND ALLACTS OF THIRD PARTIES INCLUDING DEALERS
OR INSTALLERS. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS
SUBSIDIARY, THE PROPER VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF
CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND
GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM AGAINST DIRECTED
SHALLBESTRICTLYLIMITEDTOTHEAUTHORIZEDDIRECTEDDEALER’SPURCHASEPRICEOF
THE PART. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER,
INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES,
DAMAGES FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF
ECONOMIC OPPORTUNITY AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE
MANUFACTURERDOESOFFERALIMITEDWARRANTYTOREPLACEORREPAIRATDIRECTED’S
OPTIONTHEPARTASDESCRIBEDABOVE.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or
limitation of incidental or consequential damages. This warranty gives you specific legal rights and
you may also have other rights that vary from State to State. DIRECTED does not and has not
authorized any person or entity to create for it any other obligation, promise, duty or obligation in
connection with this Part.920-0007 07-06
This Interface kit / Data Bus Interface part has been tested on the listed vehicles. Other vehicles will be
added to the select vehicle list upon completion of compatibility testing. Visit website for latest vehicle
application guide. DISCLAIMER: Under no circumstances shall the manufacturer or the distributors of
the bypass kit / data bus interface part(s) be held liable for any consequential damages sustained in
connection with the part(s) installation. The manufacturer and it’s distributors will not, nor will they
authorize any representative or any other individual to assume obligation or liability in relation to the
interfacekit/databusinterfacepart(s)otherthanitsreplacement.N.B.:Undernocircumstancesshallthe
manufacturer and distributors of this product be liable for consequential damages sustained in
connection with this product and neither assumes nor authorizes any representative or other person to
assumeforitanyobligationorliabilityotherthanthereplacementofthisproductonly.
PROTECTED BY U.S. PATENTS:5,719,551;6,011,460B1*;6,243,004B1; 6,249,216B1; 6,275,147B1;6,297,731B1; 6 , 3 4 6 , 8 7 6 B 1 ;
6,392,534B1; 6,529,124B2; 6,696,927B2; 6,756,885B1; 6,756,886B2; 6,771,167B1; 6,812,829B1; 6,924,750B1; 7,010,402 B1;
7,015,830B1; 7,031,826B1; 7,046,126B1; 7,061,137B1; 7,068,153B1; 7,205,679B1; CDN. PATENT:2,320,248; 2,414,991; 2,415,011;
2,415,023;2,415,027; 2,415,038; 2,415,041; 2,420,947; 2,426,670; 2,454,089 EUROPEAN PATENT:1,053,128 PAT. PENDING:2,291,306;
MADE IN CANADA
2-Way LED & LCD Remote Start Kits Rev.: 20091218
© 2009 Directed Electronics. All rights
Model: CHRSALL RS-CHLED & RS-CHLCD
