Xpresskit DBALL2 User manual
Index
Installation Guide
Update Alert: Firmware updates are posted to the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Vehicle Application Guide................................................................................................................................................
Understanding the Difference Between a Ford 80 Bit & a 40 Bit.....................................................................................
Installation (Wiring Diagrams & Vehicle Wiring Reference Charts)
Type 1 with T-Harness (THFD1)......................................................................................................................................
Type 1 without T-Harness................................................................................................................................................
Type 2 with T-Harness (THDF1)......................................................................................................................................
Type 2 without T-Harness................................................................................................................................................
SmartStart/XL202 Installation Notes...............................................................................................................................
Programming
Module Programming......................................................................................................................................................
Module Programming - 2 Keys are required....................................................................................................................
Key2 GO Programming for 40-bit key types ONLY (using 1 key)...................................................................................
Module Reset & Hard Reset............................................................................................................................................
Feature & Option List.......................................................................................................................................................
Feature Programming......................................................................................................................................................
LED Diagnostics & Troubleshooting................................................................................................................................
Parking Light Error Codes...............................................................................................................................................
Limited One-Year Consumer Warranty............................................................................................................................
Quick Reference Guide...................................................................................................................................................
02
03
04
05
13
14
16
17
18
18
19
20
21
22
24
25
26
® Ford is a registered trademark and property of Ford Motor Company.
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
The FORD6 firmware for DBALL2 is an all-in-one door lock and override module compatible with
specific Ford and Lincoln vehicles. This guide supports the installation of a DBALL2 in Remote Start
Ready (RSR) mode with or without a Plug & Play (THFD1) T-Harness (optional). This solution offers
three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF
System or SmartStart (all sold separately).
Two (2) key required for module programming.
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle
completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to
start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
This module can only be flashed and configured using XpressVIP at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to for more information.the Module Programming section on page n
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 2
Vehicle Application Guide
The following table lists the vehicles and features which are compatible with this product. The number assigned to each year
allows you to determine which installation type should be used for your vehicle.
[1] Ford Expedition and Lincoln Navigator are NOT
compatible with optional T-Harness THFD1.
Legend:
DL: OE Door Lock & Alarm Controls
PK: Transponder & Immobilizer Override
RS: Remote Start & Engine Controls
SS: Integrated Security & Monitoring
ST: Function/Feature Status
Vehicles
2016
2015
2014
2013
2012
2011
2010
2009
PK-Immobilizer Bypass-Data No Key Req'd
DL-Arm Factory Security
DL-Disarm Factory Security
DL-Door Lock Control
DL-Door Unlock
DL-Trunk / Hatch Release
Key2GO
RS-3x LOCK START (Start control using OEM Remote)
RS-3x LOCK STOP (Stop control using OEM Remote)
RS-RAP Shut Down (Retained ACC Power)
RS-Remote Start Ready
RS-SmartStart
RS-Tach / RPM Output
SS-Entry Monitoring ALL Door Pins
SS-Entry Monitoring Driver Door Pin
SS-Entry Monitoring Hood Pin
SS-Entry Monitoring Trunk/Hatch Pin
ST-Brake Status (foot brake)
ST-Door Locks Status
Ford
Edge (SA Key) 2 2 2 2 • • • • • • • • • • • • • • • • • •
Escape 1 1 • • • • • • • • • • • • • • • • • •
Escape Hybrid 1 1 • • • • • • • • • • • • • • • • • •
E-Series (SA Key) 1 • • • • • • • • • • • • • • • •
Expedition 1 1 • • • • • • • • • • • • • • • • • •
Expedition (SA Key) [1] 1 1 1 1 • • • • • • • • • • • • • • • • • • •
Explorer (SA Key) 2 2 2 2 2 • • • • • • • • • • • • • • • • • •
F-150 (SA Key) 1 1 1 1 • • • • • • • • • • • • • • • •
F-250 1 • • • • • • • • • • • • • • • •
F-250 (SA Key) 1 1 1 1 1 • • • • • • • • • • • • • • • •
F-350 1 • • • • • • • • • • • • • • • •
F-350 (SA Key) 1 1 1 1 1 • • • • • • • • • • • • • • • •
F-450 1 • • • • • • • • • • • • • • • •
F-450 (SA Key) 1 1 1 1 1 • • • • • • • • • • • • • • • •
Flex 1 1 1 1 1 • • • • • • • • • • • • • • • • • • •
Flex (SA Key) 1 1 1 1 • • • • • • • • • • • • • • • • • •
Fusion (SA Key) 1 1 • • • • • • • • • • • • • • • • • •
Mustang (SA Key) 1 1 • • • • • • • • • • • • • • • • • •
Taurus (SA Key) 1 1 • • • • • • • • • • • • • • • • • •
Lincoln
Navigator [1] 1 1 1 1 • • • • • • • • • • • • • • • • • •
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 3
This feature is required if only one key is available. You can program the interface without the need for Key2Go if two
keys are present.
Key2GO has been designed and developed to bypass the advanced encryption layers found in modern vehicles. It uses
an array of servers to generate a duplicate of the original key, allowing the installation of a remote starter without having to
give up a key.
The advantage is that this feature allows you to use one original key and the server to configure the bypass in the vehicle.
All Key2GO-compatible firmware are clearly indicated in the function list of each vehicle search result page and will also
appear on the flash page. Any first-time user must re-register to gain access to Key2GO, and some additional information
will be required to complete the registration process, such as your Directed account number and store name. Key2GO
requires an XKLoader.
Refer to page 18 of this guide for instructions on how to program features using Key2GO.
Ford introduced an 80-bit encryption in late 2009 and this caused a lot of confusion as to which models it was available
on. The main question is which models use the 80 and which use the old 40 bit?
Contrary to popular belief, the SA marking on the key does NOT indicate a vehicle uses 80-bit encryption. In reality, the
SA marking indicates that the key is 80-bit compatible, but the vehicle itself could still be using 40-bit encryption.
What does it mean?
It means that Ford did in fact release SA keys equipped with an 80-bit transponder, but the reality is that the same
transponder can also be used in 40-bit vehicle, making it backward compatible with older vehicles. Consequently, if you
see an SA key it is important that you do not automatically assume it is an 80-bit type. It all depends on the vehicle, not
the key.
How do I Differentiate Between the 40 & 80 Bit?
To determine which encryption type you are dealing with, you must test pin 1 at the 4-pin IMMO connector on the key
barrel for the following conditions to determine if it is 40 or 80-bit type.
An 80-bit vehicle should provide the following values:
§NO key in barrel: 0v
§Key in barrel with IGN OFF: (+) 12V
§Key in barrel with IGN ON: (+) 12V
A 40-bit vehicle should provide the following values:
§NO key in barrel: 0v
§Key in barrel with IGN OFF: 0v
§Key in barrel with IGN ON: (+) 12V
Understanding the Difference Between a Ford 80 Bit & a 40 Bit
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Refer to the Vehicle
Wiring Reference Charts
on next pages for
wire colors and location.
10
DBALL2
RF
LED
4
14 12 2
Driver Door Trigger
(-) Lock
(-) Unlock
(-) Trunk
Page 4
(-) Unlock Output: Red/Black
(-) Trunk Release Output: Violet/Brown
(-) Lock Output: Green/Black
RAP Off Interrupt: Yellow/Red
RAP Off Interrupt: Orange/Red
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
MS CAN High: pin 3
MS CAN Low: pin 11 HS CAN Low: pin 14
OBDII
Diagnostic
Connector
1 8
169
MS CAN High: Tan/Black
MS CAN Low: Tan
HS CAN Low: Orange/Brown
HS CAN High: Orange/Green
HS CAN High: pin 6
Headlight
Switch Ground
(-) Parking Light
Connector C
2
3
Headlight Ground Interrupt (vehicle side): Yellow
(-) Parking Lights Output: White
Headlight Ground Interrupt (switch side): Orange/White
Connector D
7
5
Headlight Switch Connectors
(see Wiring Reference Chart)
[1]T-Harness is NOT compatible with Ford Expedition or Lincoln Navigator.
Ignition
Switch
(connector side)
P.A.T.S.
4-pin
(connector side)
74
2
13 5 6
74
2
13 5 6
Ignition
Barrel
4321
1 432
Refer to the Wiring Reference Chart for more
information on specific wiring and connections.
Type 1 with T-Harness (THFD1)
The Remote Start
Safety Override
Switch MUST be in
the OFF position.
Remote Start Safety
Override Switch
Violet
Attention! DO NOT cut loop in
RSR application.
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
Prog. Button
Cut
Cut
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Refer to the Vehicle
Wiring Reference Charts
on next pages for
wire colors and location.
Type 1 without T-Harness Page 5
MS CAN High: Tan/Black: 3
MS CAN Low: Tan: 4
(-) Unlock Output: Red/Black: 4
(-) Trunk Release Output: Violet/Brown: 9
(-) Ground: Black: 14
(+) 12V Input: Red: 13
RAP Off Interrupt: Orange/Red: 10
RAP Off Interrupt: Yellow/Red: 11
(+) Ignition Output: Yellow: 8
(+) Ignition
(+) Accessory/Keysense Output: Gray/Black: 7
(-) Lock Output: Green/Black: 2
10
DBALL2
RF
LED
4
14 12 2
(+) 12V Input: Brown: 7
Important!
The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL2.
(+) Start Output: Gray: 6
(-) Unlock
(+) Start
(-) Lock
(+) 12V
Driver Door Trigger
(-) Trunk Release
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
(-) Parking Lights Output: Blue/Red: 12
RX: pin 4
TX:
pin 3
MS CAN High: pin 3
MS CAN Low:
pin 11
HS CAN Low: pin 14
OBDII
Diagnostic
Connector
1 8
169
HS CAN High: pin 6
HS CAN Low: Orange/Brown: 6
HS CAN High: Orange/Green: 5
6: White/Black: (-) Hood/Remote
Start Safety Override Switch
Hood Pin
Remote Start Safety
Override Switch
Note: hood pin only required
on vehicles not equipped with
a factory hood pin.
30
86 85
87
87a
74
2
13 5 6
Headlight
Switch
Ground
Connector C
2
3
7
5
Connector D
4
1
3
2
P.A.T.S. Connector
(Black 4-pin conn.
around ignition switch)
TX: Yellow/Black: 10
RX: Orange/Black: 11
(-) Parking Lights
Headlight Switch Connectors
(see Wiring Reference Chart)
(+) Keysense
(+) Accessory
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
Prog. Button
Cut
1A
Diode
Fuse 5A
Cut
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart Page 6
Function
Color Pin Polarity Location Color No. Pin
Ford E-Series (SA Key) 2014
RX Violet/Gray 4 Data PATS connector at ignition switch Black 4
TX Yellow/Orange 3 Data PATS connector at ignition switch Black 4
Headlight Switch Ground Black/Blue 3 (-) Headlight Switch Gray 10
Parking Lights Gray 2 (-) Headlight Switch Gray 10
12V Blue/Red 2 (+) Ignition Switch Gray 13
Accessory Brown/Yellow 8 (+) Ignition Switch Gray 13
Ignition White/Orange 1 (+) Ignition Switch Gray 13
Keysense Blue/Gray 10 (+) Ignition Switch Gray 13
Start Blue/White 5 (+) Ignition Switch Gray 13
MS CAN High Gray/Orange 3 Data OBDII Diagnostic Connector Black 16
MS CAN Low Violet/Orange 11 Data OBDII Diagnostic Connector Black 16
HS CAN High White/Blue 6 Data OBDII Diagnostic Connector Black 16
HS CAN Low White 14 Data OBDII Diagnostic Connector Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB in driver's side dash Gray 26
Lock Gray/Yellow 17 (-) SJB in driver's side dash Gray 26
Unlock Violet/Gray 4 (-) SJB in driver's side dash Gray 26
Ford Escape 2008-2012
RX Violet/Gray 4 Data PATS connector at ignition switch Black 4
TX Yellow/Orange 3 Data PATS connector at ignition switch Black 4
Headlight Switch Ground Black/Blue 7 (-) Headlight Switch Gray 10
Parking Lights Blue/Gray 5 (-) Headlight Switch Gray 10
12V Blue/Red 4 (+) Ignition Switch Gray 7
Accessory Violet/Green 6 (+) Ignition Switch Gray 7
Ignition White/Orange 1 (+) Ignition Switch Gray 7
Keysense Blue/Gray 5 (+) Ignition Switch Gray 7
Start Blue/White 7 (+) Ignition Switch Gray 7
MS CAN High Gray/Orange 3 Data OBDII Diagnostic Connector Black 16
MS CAN Low Violet/Orange 11 Data OBDII Diagnostic Connector Black 16
HS CAN High White/Blue 6 Data OBDII Diagnostic Connector Black 16
HS CAN Low White 14 Data OBDII Diagnostic Connector Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB in passenger side center console Gray 26
Trunk/Hatch Release Brown 7 (-) BCM/SJB in passenger side center console Gray 26
Lock Blue/Green 17 (-) SJB in passenger side center console Gray 26
Unlock Yellow/Violet 4 (-) SJB in passenger side center console Gray 26
Ford Escape Hybrid 2008-2012
RX Violet/Gray 4 Data PATS connector at ignition switch Black 4
TX Yellow/Orange 3 Data PATS connector at ignition switch Black 4
Headlight Switch Ground Black/Blue 7 (-) Headlight Switch Gray 10
Parking Lights Blue/Gray 5 (-) Headlight Switch Gray 10
12V Blue/Red 4 (+) Ignition Switch Gray 7
Accessory Violet/Green 6 (+) Ignition Switch Gray 7
Ignition White/Orange 1 (+) Ignition Switch Gray 7
Keysense Blue/Gray 5 (+) Ignition Switch Gray 7
Start Blue/White 7 (+) Ignition Switch Gray 7
MS CAN High Gray/Orange 3 Data OBDII Diagnostic Connector Black 16
MS CAN Low Violet/Orange 11 Data OBDII Diagnostic Connector Black 16
HS CAN High White/Blue 6 Data OBDII Diagnostic Connector Black 16
HS CAN Low White 14 Data OBDII Diagnostic Connector Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB in passenger side center console Gray 26
Trunk/Hatch Release Brown 7 (-) BCM/SJB in passenger side center console Gray 26
Lock Blue/Green 17 (-) SJB in passenger side center console Gray 26
Unlock Yellow/Violet 4 (-) SJB in passenger side center console Gray 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 7
Function
Color Pin Polarity Location Color No. Pin
Ford Expedition 2015-2016
RX Blue/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Brown 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray/Yellow 7 (-) Power liftgate switch. Black 8
Headlight Switch Ground Black/White 7 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
12V Green/Red 4 (+) Ignition switch Gray 7
Accessory Violet/Green 7 (+) Ignition switch Gray 7
Ignition White/Orange 1 (+) Ignition switch Gray 7
Keysense Blue/Gray 5 (+) Ignition switch Gray 7
Start Blue/White 7 (+) Ignition switch Gray 7
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel. Gray 26
Lock White/Brown 6 (-) BCM/SJB in passenger kick panel. Gray 26
Unlock Blue/Brown 8 (-) BCM/SJB in passenger kick panel. Gray 26
Trunk/Hatch Release Brown 23 (-) BCM/SJB in passenger kick panel. Gray 26
Ford Expedition (SA Key) 2011-2014
RX Blue/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Brown 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray/Yellow 7 (-) Power liftgate switch. Black 8
Headlight Switch Ground Black/White 7 (-) Headlight switch Gray 10
Parking Light Blue/Gray 5 (-) Headlight switch Gray 10
12V Blue/Red 8 (+) Ignition switch Gray 10
Accessory Brown/Yellow 7 (+) Ignition switch Gray 10
Ignition White/Orange 1 (+) Ignition switch Gray 10
Keysense Blue/Gray 3 (+) Ignition switch Gray 10
Start Blue/White 10 (+) Ignition switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB in passenger kick panel. Gray 26
Lock White/Brown 17 (-) BCM/SJB in passenger kick panel. Gray 26
Unlock Blue/Brown 4 (-) BCM/SJB in passenger kick panel. Gray 26
Trunk/Hatch Release Brown 20 (-) BCM/SJB in passenger kick panel. Gray 26
Ford F150 (SA Key) 2011-2014
RX Violet/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 8
Function
Color Pin Polarity Location Color No. Pin
Ford F250 2016
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Ford F250 (SA Key) 2011-2015
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red or Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Ford F350 2016
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 9
Function
Color Pin Polarity Location Color No. Pin
Ford F350 (SA Key) 2011-2015
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red or Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Ford F450 2016
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Ford F450 (SA Key) 2011-2015
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Gray 3 (-) Headlight switch Gray 10
Parking Light Yellow/Orange 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Lock Blue/Green 6 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Black 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 10
Function
Color Pin Polarity Location Color No. Pin
Ford Flex 2015-2016
RX Violet 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray 6 (-) Power liftgate switch. Black 6
Accessory Violet 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Blue 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Violet 9 Cut BCM/SJB under driver dash. Gray 26
Lock Blue 6 (-) BCM/SJB under driver dash. Gray 26
Unlock Yellow 8 (-) BCM/SJB under driver dash. Gray 26
12V Red 6 (+) BCM/SJB under driver dash. White 32
Trunk/Hatch Release Brown 23 (-) BCM/SJB under driver dash. Black 26
Ford Flex 2009-2011
RX Violet/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray/Yellow 6 (-) Power liftgate switch. Black 6
12V Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Blue 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB under driver dash. Gray 26
Lock Blue/Green 17 (-) BCM/SJB under driver dash. Gray 26
Trunk/Hatch Release Brown 7 (-) BCM/SJB under driver dash. Gray 26
Unlock Yellow/Violet 4 (-) BCM/SJB under driver dash. Gray 26
Ford Flex (SA Key) 2011-2012
RX Violet/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray/Yellow 6 (-) Power liftgate switch. Black 6
12V Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Blue 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB under driver dash. Gray 26
Lock Blue/Green 17 (-) BCM/SJB under driver dash. Gray 26
Trunk/Hatch Release Brown 7 (-) BCM/SJB under driver dash. Gray 26
Unlock Yellow/Violet 4 (-) BCM/SJB under driver dash. Gray 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 11
Function
Color Pin Polarity Location Color No. Pin
Ford Flex (SA Key) 2013-2014
RX Violet 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray 6 (-) Power liftgate switch. Black 6
Accessory Violet 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Blue 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB under driver dash. Gray 26
Lock Blue 6 (-) BCM/SJB under driver dash. Gray 26
Trunk/Hatch Release Brown 23 (-) BCM/SJB under driver dash. Gray 26
12V Red 6 (+) BCM/SJB under driver dash. White 32
Ford Fusion (SA Key) 2011-2012
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Violet 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB under driver dash. Gray 26
Lock Blue/Green 17 (-) BCM/SJB under driver dash. Gray 26
Trunk/Hatch Release Brown/Yellow 20 (-) BCM/SJB under driver dash. Gray 26
Unlock Yellow/Violet 4 (-) BCM/SJB under driver dash. Gray 26
Ford Mustang (SA Key) 2013-2014
RX Yellow/Orange 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Violet/Gray 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Blue/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition Gray/Violet 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/Violet 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 Cut BCM/SJB in passenger kick panel or at driver kick panel harness. Gray 26
Lock Blue/Green 17 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Gray 26
Trunk/Hatch Release
Brown/Yellow
or Brown/Violet 20 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Gray 26
Unlock Yellow/Violet 4 (-) BCM/SJB in passenger kick panel or at driver kick panel harness. Gray 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 1 - Vehicle Wiring Reference Chart (continued) Page 12
Function
Color Pin Polarity Location Color No. Pin
Ford Taurus (SA Key) 2013-2014
RX Violet/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange 3 Data P.A.T.S. connector at ignition switch. Black 4
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Headlight Switch Ground Black/White 3 (-) Headlight switch Gray 10
Parking Light Gray 2 (-) Headlight switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High Blue/White 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Open BCM/SJB under driver dash. Black 26
Lock Blue/Green 6 (-) BCM/SJB under driver dash. Black 26
Trunk/Hatch Release Brown/Yellow 23 or 4 (-) BCM/SJB under driver dash. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB under driver dash. Black 26
12V Red 6 (+) BCM/SJB under driver dash. White 32
Lincoln Navigator 2011-2014
RX Blue/Gray 4 Data PATS connector at ignition switch Black 4
TX Violet/Brown 3 Data PATS connector at ignition switch Black 4
Power Liftgate Gray/Yellow 7 (-) Power liftgate switch Black 8
Headlight Switch Ground Black/White 7 (-) Headlight Switch Gray 10
Parking Lights Blue/Gray 5 (-) Headlight Switch Gray 10
12V Blue/Red 9 (+) Ignition Switch Gray 10
Accessory Brown/Yellow 7 (+) Ignition Switch Gray 10
Accessory 2 Violet/Green 5 (+) Ignition Switch Gray 10
Ignition White/Orange 1 (+) Ignition Switch Gray 10
Keysense Blue/Gray 3 (+) Ignition Switch Gray 10
Start Blue/White 10 (+) Ignition Switch Gray 10
MS CAN High Gray/Orange 3 Data OBDII Diagnostic Connector Black 16
MS CAN Low Violet/Orange 11 Data OBDII Diagnostic Connector Black 16
HS CAN high White/Blue 6 Data OBDll diagnostic connector. Black 16
HS CAN Low White 14 Data OBDll diagnostic connector. Black 16
Driver Door Trigger Green/Violet 14 N.C. BCM/SJB in passenger kick Gray 26
Trunk/Hatch Release Brown 7 (-) BCM/SJB in passenger kick Gray 26
Lock White/Brown 17 (-) SJB in passenger kick Gray 26
Unlock Blue/Brown 4 (-) SJB in passenger kick Gray 26
Connector InformationWire Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
10
DBALL2
RF
LED
4
14 12 2
The Remote Start
Safety Override
Switch MUST be in
the OFF position.
Remote Start Safety
Override Switch
Page 13
(-) Unlock Output: Red/Black
(-) Trunk Release Output: Violet/Brown
(-) Lock Output: Green/Black
RAP Off: Yellow/Red
RAP Off: Orange/Red
You can connect to either a XL202
RFTD OR a SmartStart module.
Refer to the SmartStart/XL202
Installation Notes for more information.
MS CAN High: Gray/Orange, pin 3
MS CAN Low:
Violet/Orange,
pin 11
HS CAN Low: White, pin 14
OBDII
Diagnostic
Connector
1 8
169
MS CAN High: Tan/Black
MS CAN Low: Tan
HS CAN Low: Orange/Brown
HS CAN High: Orange/Green
HS CAN High:
White/Blue, pin 6
Violet
Attention! DO NOT Cut loop in
RSR application.
(+) Parking Light Output: White
(+) Parking Lights: Yellow/Blue, pin 6
74
2
13 5 6
BCM/SJB
Connector
(Gray 10-pin conn.
drivers kick panel
or under dash)
10
61
5
8 3
7 2
9 4
(+) 12V Input: Yellow
74
2
13 5 6
74
2
13 5 6
4321
Refer to the Wiring Reference Chart for more
information on specific wiring and connections.
Type 2 with T-Harness (THFD1)
1 432
Ignition
Barrel
Ignition
Switch
(connector side)
P.A.T.S.
4-pin
(connector side)
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
BCM/SJB C2280C
(Black 26-pin conn. drivers
kick panel or under dash)
13
123456
14 15 16 25
17 18
78910 11 12
19 20 21 22 23 24 26
Driver Door Trigger: Green/Violet, pin 9
123456
7
8
Trunk Release
(Black 8-pin
connector)
(Ford Explorer)
Ford
Explorer 2011+.
OR
Ford Edge
2011+.
(-) Power Liftgate:
Gray/Yellow,
pin 7
(-) Lock:
Blue/Green,
pin 6
(-)
Unlock:
Yellow/
Violet,
pin 8
(-) Trunk Release:
Brown, pin 23
(Ford Edge only)
Prog. Button
Cut
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
MS CAN High: Tan/Black: 3
MS CAN Low: Tan: 4
(-) Unlock Output: Red/Black: 4
(-) Trunk Release Output: Violet/Brown: 9
(-) Ground: Black: 14
(+) 12V Input: Red: 13
RAP Off Interrupt: Orange/Red: 10
RAP Off Interrupt: Yellow/Red: 11
(+) Ignition Output: Yellow: 8
(+) Accessory/Keysense Output: Gray/Black: 7
(-) Lock Output: Green/Black: 2
14 12 2
(+) 12V Input: Brown: 7
(+) Start Output: Gray: 6
(-) Parking Lights Output: Blue/Red: 12
HS CAN Low: Orange/Brown: 6
HS CAN High: Orange/Green: 5
TX: Yellow/Black: 10
RX: Orange/Black: 11
4
1
3
2
Type 2 without T-Harness Page 14
10
DBALL2
RF
LED
4
Important!
The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL2.
You can connect to
either a XL202 RFTD
OR a SmartStart
module.
Refer to the
SmartStart/XL202
Installation Notes for
more information.
MS CAN High: Gray/Orange, pin 3
MS CAN Low:
Violet/Orange, pin 11
HS CAN Low: White, pin 14
OBDII
Diagnostic
Connector
1 8
169
HS CAN High:
White/Blue, pin 6
6: White/Black: (-) Hood/Remote
Start Safety Override Switch
Hood Pin
Remote Start Safety
Override Switch
Note: hood pin only required
on vehicles not equipped with
a factory hood pin.
30
86 85
87
87a
P.A.T.S. Connector
(Black 4-pin conn.
around ignition switch)
74
2
13 5 6
BCM/SJB Connector
(Gray 10-pin conn. drivers
kick panel or under dash)
10
61
5
8 3
7 2
9 4
(+) Parking Lights:
Yellow/Blue,
pin 6
RX:
Violet/
Gray,
pin 4
TX:
Yellow/Orange,
pin 3
With the exception of the OBDII Diagnostic connector, all adapters are displayed from the wire side (unless specified otherwise).
Fuse 25 Amp
1234567
Ignition
Switch
(Black 7-pin
connector)
(+) 12V: Green/Red, pin 4
(+) Starter: Blue/White, pin 7
(+) Ignition:
White/Orange, pin 1
(+) Accessory: Violet/Green, pin 6
13
123456
14 15 16 25
17 18
78910 11 12
19 20 21 22 23 24 26
Ford
Explorer 2011+.
OR
Ford Edge
2011+.
Trunk Release
(Black 8-pin
connector)
(Ford Explorer
only)
1
2
3
4
5
6
7
8
(-) Trunk Release: Brown, pin 23
(Ford Edge only)
Driver Door Trigger: Green/Violet, pin 9
(-) Lock: Blue/Green, pin 6
(-) Unlock: Yellow/Violet, pin 8
(+) Keysense: Blue/Gray, pin 5
(-) Power Liftgate:
Gray/Yellow,
pin 7
Prog. Button
Cut
1A
Diode
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Type 2 - Vehicle Wiring Reference Chart Page 15
Function
Color Pin Polarity Location Color No. Pin
Ford Edge (SA Key) 2011-2014
RX Violet/Gray 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange 3 Data P.A.T.S. connector at ignition switch. Black 4
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Power Liftgate Gray/Yellow 6 (-) Power liftgate switch. Black 6
Parking Light Yellow/Blue 6 (+) BCM/SJB under driver dash. Gray 10
Driver Door Trigger Green/Violet 9 Cut BCM/SJB under driver dash. Black 26
Trunk/Hatch Release Brown 23 (-) BCM/SJB under driver dash. Black 26
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDII diagnostic connector. Black 16
HS CAN Low White 14 Data OBDII diagnostic connector. Black 16
Lock Blue/Green 6 (-) BCM/SJB under driver dash. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB under driver dash. Black 26
Ford Explorer (SA Key) 2011-2015
RX Violet/Red or Violet 4 Data P.A.T.S. connector at ignition switch. Black 4
TX Yellow/Orange or Yellow 3 Data P.A.T.S. connector at ignition switch. Black 4
Power Liftgate Gray/Yellow 7 (-) Power liftgate switch. Black 8
12V Green/Red 4 (+) Ignition switch Black 7
Accessory Violet/Green 6 (+) Ignition switch Black 7
Ignition White/Orange 1 (+) Ignition switch Black 7
Keysense Blue/Gray 5 (+) Ignition switch Black 7
Start Blue/White 7 (+) Ignition switch Black 7
Parking Light Yellow/Blue 6 (+) BCM/SJB under driver dash. Gray 10
MS CAN High Gray/Orange 3 Data OBDII diagnostic connector. Black 16
MS CAN Low Violet/Orange 11 Data OBDII diagnostic connector. Black 16
HS CAN High White/Blue 6 Data OBDII diagnostic connector. Black 16
HS CAN Low White 14 Data OBDII diagnostic connector. Black 16
Driver Door Trigger Green/Violet 9 Cut BCM/SJB in driver kick panel. Black 26
Lock Blue/Green 6 (-) BCM/SJB in driver kick panel. Black 26
Trunk/Hatch Release Brown 23 (-) BCM/SJB in driver kick panel. Black 26
Unlock Yellow/Violet 8 (-) BCM/SJB in driver kick panel. Black 26
Wire Information Connector Information
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 16
The optional XL202 and antenna are not included and MUST be purchased separately.
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
4
4
XL202
Antenna
XOVER
SmartStart is optional and not included. It MUST be purchased separately.
SmartStart is optional and not included. It MUST be purchased separately.
The DBALL2 Remote Start Ready (RSR) solution offers two (2) configuration options to control your system: RF Kit
or SmartStart (both sold separately). This section provides specific installation information for SmartStart and XL202.
Configuration Wires (Gray & White)
Connect Gray wire to (-) Ground
5 pins
D2D (4 pins, white)
4 pins
2 pins,
not used
CABLE
CABLE
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
1. Use the D2D Crossover (XOVER) cable that is provided with XL202, and NOT the one in the DBALL2 package.
2. The modules must be connected in a specific order. Refer to the Module Programming section for more information.
The modules must be connected in a specific order. Refer to the Module Programming section for more information.
SmartStart/XL202 Installation Notes
SmartStart Revision B
RF Kit
RF Kit & PKE Combination
Refer to the Passive Keyless Entry (PKE) Installation Guide (N2102T) for detailed wiring information.
RF Kit, PKE & SmartStart BT Combination
SmartStart Revision A
DBALL2
DBALL2
LED
Prog.
Button
D2D (4 pins, white)
4 pins
2 pins,
not used
OR
SmartStart
Configuration Wires (White & Brown or Blue)
Cut Brown or Blue Loop
LED
THIS SIDE UP
LED
DBALL2
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Module Programming Page 17
Refer to the LED Diagnostics section more information and for troubleshooting purposes.
1
10-pin
D2D
st
1
12-pin
14-pin
nd
2
rd
3
&
Solid
Connect the 10-pin, 12-pin and 14-pin harnesses to
DBALL2, then wait until the LED turns ON solid red.
Important
10-pin
D2D
XL202
10-pin
D2D
SmartStart
OR
The DBALL2 module must be disconnected from any power source before SmartStart can
be connected to it. Failing to do so could damage DBALL2.
a. To ensure that the D2D communication between SmartStart and DBALL2 works properly,
the Gray wire must be connected to a ground source (Rev B SmartStart), and the Brown or
Blue loop must be cut (Rev A SmartStart).
b. Do NOT connect the 2-pin harness (on SmartStart). Power and ground will be provided by
the DBALL2 D2D connector.
Connect SmartStart to DBALL2 using the D2D port.
SmartStart Installation
Connect XL202 to DBALL2 using the D2D port.
XL202 Installation
Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to
ensure everything is correct prior to moving onto the next step.
Note: Before connecting either the XL202 or SmartStart module to DBALL, it is important to ensure that the proper feature and
function programming is selected using XpressVIP (version 4.5 or higher). Visit www.directechs.com to download the latest
version of the application.
Warning! To take advantage of advanced features, you must use XpressVIP 4.5 (and higher) or the Directechs Mobile app.
When the flashing operation is successful, you can proceed with the programming instructions below.
Flashing a module using your computer:
1. Connect the interface module to your computer using the
XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and
select the Config for RSR button.
3. Follow the instructions to select your vehicle, installation
type, and configure your options.
4. Once you have configured the firmware options, click on the
FLASH button.
Flashing a module using your smartphone or tablet
1. Connect the interface module to your XKLoader3.
2. Launch the Directechs Mobile app on your smartphone or
tablet.
3. Select FLASH YOUR MODULE and follow the on screen
instructions.
Go to the next page to complete the module programming.
3&
2nd Key IN
OFF
START
IGN
2nd Key OUT
OFF
START
IGN
Insert the second key and turn it to the IGN position:
the LED flashes orange.
Wait at least 3 seconds but no more than 10 seconds,
then remove the key.
within 5 seconds:
Flashes
2&
1st Key IN
OFF
START
IGN
Flashes
1st Key OUT
OFF
START
IGN
Insert the first key, turn the key to the IGN position,
the LED flashes green. Wait at least 3 seconds, but
no more than 10 seconds, then remove it.
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 18
Module Programming - 2 Keys Required
within 5 seconds:
The LED turns ON solid green
for 3 seconds, then turns OFF
once the module has been
successfully programmed. Then
the vehicle door lock will cycle.
&
Off
Solid &
Off
Solid
or
Press and HOLD the programming button.
The vehicle ignition will be triggered.
Release the Program button as soon as the Orange
LED goes out. If you wait too long to release the
programming button, you will have to start the
programming over.
The LED turns ON solid green for 3 seconds, then
turns OFF once the module has been successfully
programmed.
Press
4
2nd Key IN
OFF
START
IGN
Turn the key to the IGN
position again. Press and
HOLD the programming
button.
33
2nd Key OUT
OFF
START
IGN
Wait at least 3 seconds but no more
than 10 seconds, then remove the key.
Go to the next page to complete the web programming.
2Open an Internet Explorer browser (version 6 or higher), and go to www.directechs.com. The detail of the
platform and firmware that is currently saved on the interface module will be indicated in the top left corner
of the page.
1
3
5
8
4
7
6
Do not connect other harnesses to the DBALL2.
Connect the DBALL2 module to your computer using the XKLoader.
Flash your module with the firmware corresponding to FORD6 Key2GO.
Insert your key into the ignition barrel, then turn the ignition ON and OFF twice. The
LED starts flashing orange, indicating that it is ready for the next step.
Once the configuration is completed, reconnect the DBALL2 to the vehicle. The LED
flashes once orange, and then turns ON solid green for 3 seconds.
Connect the DBALL2 wiring to the vehicle first, and only then, plug the harnesses to
the DBALL2 without pressing the programming button. The LED turns ON solid red.
Select the method and click on Submit Key2GO Request.
Remove the DBALL2 from the vehicle and reconnect it to your computer. The Directechs web site will
automatically recognize that you are moving onto the second phase of the programming sequence.
Refer to the LED Diagnostics section on page 36 for more information and for troubleshooting purposes.
Version 4.5 or higher of XpressVIP must be installed on your computer to complete this programming sequence.
Method 2 : Key2 GO Programming for 40-bit key types ONLY (using 1 key) - Optional
Flashes
Solid x 3secs
Flashes once
&
Solid
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 19
1If required for your installation, connect the 10-pin & 12-pin
harnesses to the module. Press and hold the programming
button, then connect the 14-pin harness to the module.
10-pin
D2D
st
1
12-pin
14-pin
nd
2
th
4
rd
3
Warning Against Executing a Hard Reset!
A hard reset will revert the flashed firmware back to its default settings. Depending on the installation, some settings (such
as RFTD and D2D options) may have to be reconfigured. See the Feature & Option List section of this guide.
2
Solid
&
Release
3 Release the programming button. The LED turns ON solid red.
Module Reset
Hard Reset
2& &
1
Wait 3 seconds until the LED turns ON solid orange then release the
programming button. The LED turns ON solid red.
If required for your installation, connect the 10-pin & 12-pin
harnesses to the module. Press and hold the programming
button, then connect the 14-pin harness to the module.
10-pin
D2D
st
1
12-pin
14-pin
nd
2
th
4
rd
3
A module reset will only erase programming performed in the previous steps. All settings (firmware) and settings flashed
to the module using the web config tool will not be affected.
Solid Release Solid
Solid Flashes
&
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds
until the LED starts to flash orange and red.
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
© 2017 Directed. All rights reserved.
Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation Rev.: 20170516
Page 20
Feature & Option List
* Default Option
Feat. Operation Flashes/Options Description
1. No RF Output* Module is connected to a remote starter using a standard installation.
2. RFTD Output Module is connected to an XL202 using an RSR or RXT installation (when available).
3. SmartStart Module is connected to SmartStart using an RSR or RXT installation (when available).
1. Disabled
The OEM alarm will not be controlled by DBALL2 upon remote start. No disarm or arm command
will be executed at the beginning or end of the sequence; it must be controlled by the Remote
Starter.
2. Safelock Smart OEM Alarm Control will behave like a standard Safelock feature on a remote starter. It will
unlock at the beginning of the sequence, and relock after start and shutdown.
3. Enabled*
Smart OEM Alarm Control will synchronize with the OEM alarm so that it will disarm and rearm
the vehicle in the remote start sequence, only when required. The reason for this is, factory alarm
control must often be done by lock or unlock operation. This could create unnecessary actions
on door lock modules, such as the horn to honk. When possible, Smart OEM Alarm Control will
monitor the alarm and door lock status to detect if the disarm or rearm is required. If the vehicle
is unlocked or is not equipped with factory alarm, the disarm/rearm will not be executed. Smart
OEM Alarm Control will also monitor the remote starter actions so that the factory alarm control is
not done twice. A remote starter, for which the Safelock feature is active, will work perfectly with
this option and will make it invisible to the user.
1. Disabled (no Factory
Alarm) No disarm operation on unlock or trunk.
2. Enabled* Will disarm vehicle by cycling the ignition before unlocking or opening Trunk.
RFTD Output
Type
1
3
Transponder
Ignition Disarm
with Unlock:
Smart OEM
Alarm Control
2
It is recommended to configure all the features and options listed below using the configuration tool found on the module
flashing page on www.directechs.com. The web offers more options; however, manual configuration of the features is possible
using the information on this page.
Parking Light Chart
Headlight Switch
Ground Parking Lights
Escape D black/blue, pin 7 blue/gray, pin 5
Escape Hybrid D black/blue, pin 7 blue/gray, pin 5
Expedition (SA Key) D black/white, pin 7 blu/gray, pin 5
F150 (SA Key) C black, pin 3 gray, pin 2
F250 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
F450 (SA Key) C black/gray, pin 3 yellow/orange, pin 2
Flex (SA Key) C black/blue, pin 3 gray, pin 2
Fusion (SA Key) C black/violet, pin 3 gray, pin 2
Mustang C black/violet, pin 3 gray, pin 2
Mustang (SA Key) C black/violet, pin 3 gray, pin 2
Vehicles / Connector
(C or D)
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 9 Trunk Release, pin 23 [2 ] Lock, pin 6 Unlock, pin 8
Edge 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown Blue/Green Yellow/Violet
Explorer 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [2] Blue/Green Yellow/Violet
F150 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F250 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F350 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
F450 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] N/A Blue/Green [1] Yellow/Violet [1]
Flex 2013 (SA Key) Gray/Orange Violet/Orange Violet Brown Blue Yellow
[1] The connections are available at driver kick panel harness (find the wire by color)
[2] The Trunk Release wire for Ford Explorer can be found at the trunk switch (8-pin connector) at pin 7.
CAN High, pin 3 CAN Low , pin 11 Driver Door Pin, pin 14 Trunk Release, pin 7 or 20 Lock, pin 17 Unlock, pin 4
Escape 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Expedition 2011-13 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 White/Brown Blue/Brown
Flex 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown, pin 7 Blue/Green Yellow/Violet
Fusion 2011-12 (SA Key) Gray/Orange Violet/Orange Green/Violet Brown/Yellow, pin 20 Blue/Green Yellow/Violet
Mustang 2013 (SA Key) Gray/Orange Violet/Orange Green/Violet [1] Brown/Yellow or
Brown/Violet, pin 20 [1] Blue/Green [1] Yellow/Violet [1]
[1] The connections are available at driver kick panel harness (find the wire by color)
Start, pin 7 (+) 12v, pin 4 (+) Ignition, pin 1 (+) Accessory, pin 6 (+) Keysense, pin 5 RX, pin 4 TX, pin 3
Edge 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Escape 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Explorer 2011-13 (SA Key) Blue/White Green/Red White/Orange Violet/Green Blue/Gray Violet/Red Yellow/Orange
F150 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
F250 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F350 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
F450 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Flex 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Violet/Gray Yellow/Orange
Flex 2013 (SA Key) Blue/White [1] White/Orange Violet Blue Violet/Gray Yellow/Orange
Fusion 2011-12 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Mustang 2013 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Yellow/Orange Violet/Gray
Start, pin 10 (+) 12v, pin 9 (+) Ignition, pin 1 (+) Accessory, pin 7 (+) Keysense, pin 3 RX, pin 4 TX, pin 3
Expedition 2011-13 (SA Key) Blue/White Blue/Red White/Orange Violet/Green Blue/Gray Blue/Gray Violet/Brown
Vehicles (B) Ignition Switch Gray 10 Pin P.A.T.S. 4 pin
OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
Vehicles
Vehicles (B) Ignition Switch Black 7 Pin P.A.T.S. 4 pin
Vehicles OBDII Connector (A) BCM/SJB Gray or Black 26 Pin
[1] The (+)12v wire for Flex 2013 can be found at the BCM under driver dash (white 32-pin connector) at pin 6 (red wire).
Wire jump template
Other manuals for DBALL2
8
Table of contents
Other Xpresskit Remote Starter manuals
Popular Remote Starter manuals by other brands
Toyota
Toyota PT398-00100 installation manual
Peak
Peak PKC0J1200 Owner's manual and warranty information
ProStart
ProStart CT-3200 installation guide
ProStart
ProStart CT-3371 Quick installation guide
Fortin
Fortin EVO ONE Addendum - Suggested Wiring Configuration
Bulldog Security
Bulldog Security RS82P owner's guide
Cool Start
Cool Start RS1-G5 operating instructions
ULTIMATE SPEED
ULTIMATE SPEED ULG 17 A1 Operation and safety notes
Bulldog Security
Bulldog Security RS1200 manual
Young Shin Electronics
Young Shin Electronics R1800-AM user guide
ADS
ADS FlashLogic FLRSBA Product guide
Schumacher Electric
Schumacher Electric SL1517 owner's manual
idatastart
idatastart CMBMXA0 installation guide
MEGATRONIX
MEGATRONIX Viking VS 200 installation manual
Code Alarm
Code Alarm ca5554 Professional series owner's guide
Audiovox
Audiovox Patinum APS-997 owner's manual
Firstech
Firstech FT-MB211-DC installation guide
Automotive Data Solutions
Automotive Data Solutions iDatastart TR3450AE owner's manual
