XROCKER XR Racing V2 User manual

USER MANUAL

CONTENTS
ENGLISH 1 - 12
FRENCH 13 - 24
DEUTSCHE 25 - 36
ESPAÑOL 37 - 48
NEDERLANDS 49 - 60
ITALIANO 61 - 72

-1-
Introduction
Thank you for purchasing the XR Racing V2 Multi-platform
steering wheel. This product is for use with major gaming
consoles such as PS4™, Xbox One™ and Switch™. For Xbox One™
and PS4™, you will use your official controller to connect, allowing you
to use this steering wheel with any racing game experience. The XR
Racing V2 steering wheel also features vibration motors for a tactile and
haptic driving experience, programmable buttons for the ideal setup
and suction pads/ clamps for a secure fix on your desk, or racing rig
setup.
For Support and firmware, please fill in the support form at
xrockeruk.com/pages/support
ENG

-2-
ENG
18 19
5
17
7
9
11
10
8
1
3 4 2
613 12

Function Number PS3™ PS4™
XBOX ONE™
PC (X-INPUT) PC (D-INPUT) SWITCH
Action
Key
1 X X A A 2 B
2 O O B B 3 A
3 X X 1 Y
4 Y Y 4 X
5 R1 R1 RB RB 6 R
6L1 L1 LB LB 5 L
7 R2 R2 RT RT 8 ZR
8 L2 L2 LT LT 7 ZL
9R3 R3 SR SR 12 R3
10 L3 L3 SL SL 11 L3
D-Pad 11
UP UP UP UP UP UP
DOWN DOWN DOWN DOWN DOWN DOWN
LEFT LEFT LEFT LEFT LEFT LEFT
RIGHT RIGHT RIGHT RIGHT RIGHT RIGHT
Function
Key
12 START OPTIONS MENU START 10 +
13 SELECT SHARE VIEW BACK 9 -
Direction 14 LX LX ///LX
L-Wing 15 L2 LT LT 1 B
R-Wing 16 X R2 RT RT 2 Y
Gear
Stick
17 L2 L1 LB LB 7 ZL
R2 R1 RB RB 8 ZR
L-Pedal 18 L2 LT LT 1 B
R-Pedal 19 X R2 RT RT 2 Y
Mode HOME X-GUIDE X-GUIDE 13 HOME

-4-
Function Introduction
Program Functions (Without memory)
Introduction
1. Program source button: /1/X/Y, O/3/B/A, /4/Y/X, X/2/A/B, L1/5/
LB/L, L2/7/LT/ZL, R1/6/RB/R,R2/8/RT/ZR;
2. Programmable button: L-Wing(Square/1/LT), R-Wing(X/2/
RT),Accelerator, (X/2/RT), Brake ( /1/LT) ,L3/11/SL,R3/12/SR),
Gear Stick (L2/7/LB,R2/8/RB)
Program setup
1. Press and hold SHARE + OPTIONS for 3 seconds until the green
LED is on.
2. Press the programmable button, and the green LED starts
blinking
3. Press the program source button. The green LED will turn off.
Program is now set.
ENG

-5-
Clear single program
1. Press and hold SHARE + OPTIONS/10/Menu for 3 seconds until
the green LED turns on
2. Press programmed button and the green LED will
start blinking.
3. Press programmed button again and the green LED will turn
off. The single programmed button is now cleared.
Clear all programs
1. Press and hold SHARE + OPTIONS for 3 seconds until the green
LED is on
2. Press OPTIONS and hold for 4 seconds. The green LED will
turn off. All of the programmed buttons are cleared with defaults
restored
Note: All settings are reset when the steering wheel is turned off.
ENG

-6-
Program Pedals as Y axis
1. Press and hold SHARE +OPTIONS 3 seconds until the green
LED turns on.
2. Press LEFT of the D-PAD. The green LED will turn off. Pedals
are programmed as Y function.
Program L-Wing and R-Wing as Y axis
1. Press and hold SHARE for 3 seconds until the green LED turns
on.
2. Press RIGHT of the D-PAD. The green LED will turn off. Pedals
are programmed as Y function.
3 levels wheel sensitivity adjustment
1. Press and hold SHARE + OPTIONS for 3 seconds until green
LED is on. Release the button.
2. Press SHARE again. Current sensitivity is displayed via the LED
on the wheel
3. Press SHARE a third time to select sensitivity level. It cycles as
below:
Middle (Green LED is flashing) High (Green LED flashes quickly) Low (Green LED flashes slowly)
- Press UP of the D-PAD to confirm and leave the settings mode
ENG

-7-
For use with PS3™
1. Connect the wheel to your console using the included USB1. Connect the wheel to your console using the included USB
cable and connect the pedals to the wheelcable and connect the pedals to the wheel
2. Power on the console.2. Power on the console.
3. The active channel LED indicator will light up when3. The active channel LED indicator will light up when
connection is finished automatically. The wheel is now ready toconnection is finished automatically. The wheel is now ready to
useuse
4. During game play, press the HOME button once to4. During game play, press the HOME button once to
enter the XMB window; Press and hold the HOME button toenter the XMB window; Press and hold the HOME button to
enter MENU setup window.enter MENU setup window.
ENG

-8-
For use with PS4™
1. Connect the wheel to your console using a spare USB port and
connect the pedal to the wheel using the rear USB Port.
2. Power on the console.
3. Connect the racing wheel to controller by a USB cable,
consider the controller as a key to establish the
connection between the controller and racing wheel
(The controller needs to be powered off before connection)
4. After the connection been established, the RED LED on the
wheel will turn on, and the LED indicator on the controller will
turn on. Press the HOME button on the wheel and the wheel will
be ready to use/
5. During game play, press the HOME button once to enter the
Console menu;
ENG

-9-
For use with XBOX ONE™
1. Connect the wheel to your console using a spare USB port and
connect the pedal to the wheel using the rear USB Port.
2. Power on the console.
3. Connect the racing wheel to controller by a USB cable,
consider the controller as a key to establish the
connection between the controller and racing wheel
(The controller needs to be powered off before connection)
4. After the connection been established, the RED LED on the
wheel will turn on, and the LED indicator on the controller will
turn on. Press the HOME button on the wheel and the wheel will
be ready to use/
5. During game play, press the HOME button once to enter the
Console menu;
ENG

-10-
For use with Switch™
1. Connect the wheel to USB port on the console dock then
power on your console;
2. Alternatively, you can connect the wheel to console using a
USB Type-c cable for handheld or tabletop mode.
3. After the connection has been established, the RED LED on
racing wheel will turn on, and one channel LED will turn on. The
wheel is now ready to use.
ENG

-11-
For use with PC
1. X-INPUT
Connect the wheel directly to the PC using the included USB cable. If
you are connected to the internet, then a driver will automatically install
and be ready to use.
1) The Wheel will default to X-input mode on PC. X Input mode will be
displayed by a RED LED on the face of the wheel and with a red LED on
the rear channels.
2) To switch to Direct Input, Press HOME button for 3 seconds to enter
into Direct-input mode, the RED LED will flash 6 times and turn off the 4
channel LEDs.
ENG

-12-
Troubleshooting
User Safety Information
• Avoid direct contact with liquids. To clean, wipe with a damp cloth. If a spillage
occurs, switch off the XR Wheel and wait for the product to dry before reusing.
• Do not use any type of abrasive pad or abrasive cleaning solutions as these may
damage the surface material.
• Please consult X Rocker Support before unscrewing and disassembling any of
the electrical components or undertaking any changes to the product. If any
unauthorised modifications or repairs are made before consultation, then this
will void your warranty.
• To reduce potential trip or entanglement hazards, arrange and secure any ca-
bles so that people and pets are not likely to trip over or accidently pull on them
as they move around or walk through the area.
• If any of the cables or electrical equipment become damaged in any way, stop
using immediately and contact X Rocker for more details on how to replace the
component.
• When not in use, keep cables and power supplies out of reach of children,
please also ensure that these are not subject to harsh impacts such as dropping
or throwing the components.
• Never place any type of candle or naked flame on or near the XR Wheel at any
time. While X Rocker products are compliant with UK and European safety regu-
lations, prolonged exposure to naked flames will result in damage to the product
and other safety hazards.
ENG

-13-
Introduction
Merci d’avoir acheté la multiplateforme XR Racing V2
volant. Ce produit est destiné à être utilisé avec les principaux jeux
consoles telles que PS4 ™, Xbox One ™ et Switch ™. Pour Xbox One ™
et PS4 ™, vous utiliserez votre manette officielle pour vous connecter,
vous permettant d’utiliser ce volant avec n’importe quelle expérience de
jeu de course. Le volant XR Racing V2 comprend également des mo-
teurs de vibration pour une expérience de conduite tactile et haptique,
des boutons programmables pour une configuration idéale et des
ventouses / pinces pour une fixation sécurisée sur votre bureau ou une
configuration de plate-forme de course.
Pour l’assistance et le micrologiciel, veuillez remplir le
formulaire d’assistance sur xrockeruk.com/pages/support
FR

-14-
FR
18 19
5
17
7
9
11
10
8
1
3 4 2
613 12

Function Number PS3™ PS4™
XBOX ONE™
PC (X-INPUT) PC (D-INPUT) SWITCH
Action
Clé
1 X X A A 2 B
2 O O B B 3 A
3 X X 1 Y
4 Y Y 4 X
5 R1 R1 RB RB 6 R
6L1 L1 LB LB 5 L
7 R2 R2 RT RT 8 ZR
8 L2 L2 LT LT 7 ZL
9R3 R3 SR SR 12 R3
10 L3 L3 SL SL 11 L3
D-Pad 11
UP UP UP UP UP UP
DOWN DOWN DOWN DOWN DOWN DOWN
LEFT LEFT LEFT LEFT LEFT LEFT
RIGHT RIGHT RIGHT RIGHT RIGHT RIGHT
Fonction
Clé
12 START OPTIONS MENU START 10 +
13 SELECT SHARE VIEW BACK 9 -
Direction 14 LX LX ///LX
L-Wing 15 L2 LT LT 1 B
R-Wing 16 X R2 RT RT 2 Y
Levier de
vitesse
17 L2 L1 LB LB 7 ZL
R2 R1 RB RB 8 ZR
L-Pedal 18 L2 LT LT 1 B
R-Pedal 19 X R2 RT RT 2 Y
Mode HOME X-GUIDE X-GUIDE 13 HOME

-16-
Introduction de la fonction
Fonctions du programme (sans mémoire)
introduction
1. Touche de source de programme: / 1 / X / Y, O / 3 / B / A,
/ 4 / Y / X, X / 2 / A / B, L1 / 5 / LB / L, L2 / 7 / LT / ZL, R1 / 6 / RB / R,
R2 / 8 / RT / ZR;
2. Bouton programmable: L-Wing ( / 1 / LT), R-Wing (X / 2 / RT),
Accelerator, (X / 2 / RT), Frein (/ 1 / LT), L3 / 11 / SL , R3 / 12 / SR),
Bâton d’engrenage (L2 / 7 / LB, R2 / 8 / RB)
Configuration du programme
1. Appuyez et maintenez SHARE + OPTIONS pendant 3 secondes
jusqu’à ce que le voyant vert s’allume.
2. Appuyez sur le bouton programmable et la LED verte
commence à clignoter
3. Appuyez sur la touche de source de programme. La LED verte
s’éteint. Le programme est maintenant défini.
FR

-17-
Effacer un seul programme
1. Appuyez et maintenez SHARE + OPTIONS / 10 / Menu pendant
3 secondes jusqu’à ce que le voyant vert s’allume
2. Appuyez sur le bouton programmé et la LED verte
commence à clignoter.
3. Appuyez à nouveau sur le bouton programmé et la LED verte
s’éteindra. Le bouton unique programmé est maintenant effacé.
Effacer tous les programmes
1. Appuyez et maintenez SHARE + OPTIONS pendant 3 secondes
jusqu’à ce que le voyant vert s’allume
2. Appuyez sur OPTIONS et maintenez pendant 4 secondes. La
LED verte s’éteint. Tous les boutons programmés sont effacés et
les valeurs par défaut sont restaurées
Remarque: tous les paramètres sont réinitialisés lorsque le volant
est éteint.
FR

-18-
Programmer les pédales comme axe Y
1. Appuyez et maintenez SHARE + OPTIONS pendant 3 secondes
jusqu’à ce que le voyant vert s’allume.
2. Appuyez sur la GAUCHE du D-PAD. La LED verte s’éteint. Les
pédales sont programmées comme fonction Y.
Programmer L-Wing et R-Wing comme axe Y
1. Appuyez et maintenez SHARE pendant 3 secondes jusqu’à ce
que le voyant vert s’allume.
2. Appuyez à DROITE du D-PAD. La LED verte s’éteint. Les
pédales sont programmées comme fonction Y.
Réglage de la sensibilité de la roue à 3 niveaux
1. Appuyez et maintenez SHARE + OPTIONS pendant 3 secondes
jusqu’à ce que le voyant vert s’allume. Relâchez le bouton.
2. Appuyez à nouveau sur SHARE. La sensibilité actuelle est
affichée via la LED sur la roue
3. Appuyez une troisième fois sur SHARE pour sélectionner le
niveau de sensibilité. Il cycles comme ci-dessous:
Milieu (la DEL verte clignote) Élevée (la DEL verte clignote rapidement) Faible (la DEL verte clignote lentement)
- Appuyez sur UP du D-PAD pour confirmer et quitter le mode
réglages
FR
