XtendLan GEPON ONU User manual

GONU11
GEPON ONU
User’s Guide

Contents
Chapter 1: Product introduction
1. Goods listing
2. Front panel instruction
3. Back panel instruction
4. Indication light instruction
5. Main feature
6. Technology
Chapter 2: Installation and link
1. Attention items for setting
Chapter 3: software upgrade
1. Preparation
2. Means and process
- 2 -

Chapter 1: Product introduction
1. Goods listing
Open the package of fast Ethernet switch, and it contains the following:
A set of ONU, A power supply, a user’s manual and a stream line
Please contact with supplier if above product and accessory is missing or damaged.
2. Front panel instruction
Front panel of ONU have 17 kinds of status indicators, as the following picture
3. Back panel instruction:
Back panel of ONU from left to right in turn is PON Port, two RJ45 Ports, a bunch port, a
replacement switch and a power supply jack, as following illustrate.
4. Indication light instruction
The signification of indicator from left to right is as following:
LED Color Status Description
PWR
Green light the indicator will light when ONU is opened.
-- Non-light
Checking the TX or power supply adaptor, make sure power supply
has connected well.
OPT Green light Checking the TX or power supply adaptor, make sure power supply
has connected well.
-- Non-light Optic link is ok.
HW Green light Hardware is error
-- Non-light Normal work status
LLID1
-8
Green light Optic link is ok
-- Non-light Checking optic link is ok or not
100M Green light Corresponding indicator will light when 100Mbps equipment
connect with relevant port.
-- Non-light Non-light 100Mbps port does not joint equipment.
LINK
/ACT
Green light Light when equipment normally connect with 100Mbps ONU port
-- glitter Glitter when the port receive or transfer data
LINK100 Green light Light when 100Mbps equipment link to relevant port
-- Non-light Non-light when 100Mbps port does not joint equipment.
LINK1000 Green light Light when 1000Mbps equipment link to relevant port
-- Non-light Non-light when 1000Mbps port does not joint equipment.
DUP/
COL
Green light Light when port is working base on full duplex mode
-- Non-light Non-Light when port is working base on half duplex mode
ACT Green Light Light when equipment normally connect with 100Mbps ONU port
Green glitter Glitter when the port receive or transfer data
- 3 -

5. Main feature:
●Support single fiber WDM technology (downstream 1490mm, upstream 1310mm), only need to
link with OLT together by one fiber, the transfer length’s at least 20Km.
●Bandwidth distribution has flexible, downstream share bandwidth by adapting encrypt broadcast
transfer way for different user. .Upstream share bandwidth by TDMA . Adjust automatically speed
rate according to the line status. Support minimum speed rate adjustment base on 1kbps, and
establish firm basic to fractionize business for telecommunication dealer.
●Support generally team broadcast function. User can choose to achieve mutual video multimedia
business by themselves name (such as VOD, Video conference)
●Bind user, MAC address and IP address together in order to prevent account was embezzled
hostility, ramble, virus spread abroad and attack of hostility data stream., so that can provide
perfect safety guarantee measure for user.
●Support multi LLID and single LLID configuration mean. Different user and business can adapt
different LLID access. Guarantee user’s different OOS grade.
Installation and maintenance are very easy. Support differed local/long-distance and many means
to manage configuration and upgrade of software. Work in partial port OLT. It can make
long-distance malfunction diagnosis and orientation function come true, and greatly reduces
maintenance workload.
●Network connects: Provide high speed date business for user.
●FTTH connects: Provide high speed date business and CATV business for family user which
already has speech copper line resource.
●FTTB connects: adapt the mean of fiber to corridor or big corridor to provide high speed data
business.
Physics feature
●Physics dimension (length162 x width117 x high30, unit: mm)
●Power supply：DC 5V
●Function loss：5W
●Temperature：
Operating temperature：0～50℃
Storage temperature：-30～60℃
Relative humidity：10～90% (non-condensation)
●Weight：<500g
Technology guide line:
Standard :IEEE 802.3ah、IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3z 、IEEE802.1d、
IEEE 802.1p、IEEE 802.1q、IEEE 802.1x、RFC1155、RFC1157、RFC1112、RFC1113 and so
on.
●A fixed 10/100M BASE-TX Port
●A fixed 10/100/1000M BASE-TX Port
●128 digit AES Encrypt
●Support 8 logic link.
●Each Ethernet port support 64 Mac Addresses based on 802.1D Bridging
●Support 802.1Q VLAN
●Support 802.1P
●Support 40 stream (20 upstream/20 downstream)
●Inbuilt 1.25 MB buffering
●Support 802.3ah OAM
●Support 802.3ah transfer error and revise
●Inbuilt MIB
- 4 -

Chapter 2: Installation and link
1. Attention item for setting
Please insure that there is suitable work environment and enough free space before installing
machine. Please note the installing requirement as following:
Power supply requirement: 100v-240v alternating current, power supply jack and equipment
should be within 1.8m.
Machine should be putted in the ventilated and dry environment, there must leave 10cm free
space from front to back of machine to airiness
Insure that around for machine has enough airiness port in order to diffuse quantity of heat, at the
same time; don’t put anything heavy on the converter.
Chapter 3：Software upgrade
As below introduction of software upgrade is available for single ONU. If it is mixed with our
OLT, It’s better to operate it in the OLT’s management section depend on professional people.
3.1 Preparationz
1. A PC with RS-232-C port, a RS-232 stream line.
2. prepare Tera Term software in PC.
3. Prepare upgrade document: Boot3713_0093_SPI_8Mb.tkf,App3713_R132_SPI_8Mb.tkf ，
Pers3713_R132.tkf
3.2 Means and process:
1. Start PC, and click “Tera Termpro”, then start the upgrade software.
2. Set software, as following chart:
- 5 -

3. Connect ONU with relevant bunch port on the PC RS-232, then turn on the power, as following
chart:
- 6 -

4. As the dos prompt shown above, input load order as following chart:
5. Firstly, upgrade Boot code, as following dos prompt input ”rxboot” click the ”file” and choose
“send file” , then “Boot3713_00XX_SPI_8Mb.tkf” you want to upgrade, as following char:
- 7 -

Click “open”, start to upgrade”bootcode”, as following chart:
6. As above method, upgrade ”app”, “pers” in turn. Input”rxapp” order while upgrade “app”
choose”App3713_Rxxx_SPI_8Mb.tkf” file, input “rxpers” order when up grade “pers”,
choose”Pers3713_RXXX.tkf” file.
7. After finishing the upgrade. Pls restart ONU to check if the status is ok or not..
