XTM WM102-15C User manual

150PSI 250LPM
DUAL AIR COMPRESSOR
OWNERS MANUAL
THERMAL CUT-OFF AND CIRCUIT BREAKER PROTECTION
This XTM Dual Air Compressor is equipped with an automatic thermal cut-off protection. If the unit reaches to unsafe
operating temperature, a protection circuit will activate cutting off all power of the unit to prevent damage. Immediately
disconnect the unit from the power source and allow it to cool if the protection circuit activates. The unit should take approxi-
mately 15 minutes to cool depending on ambient conditions. The unit protection circuit will automatically reset when the
temperature returns to a safe operating level. Always allow your air compressor to cool before reuse. The auto reset circuit
breaker is built-in to protect an electrical circuit from damage caused by overload or short circuit.
MAINTENANCE
+ All moving parts within the air compressor have been permanently Iubricated during manufacture. It is
NOT necessary to lubricate this air compressor.
+ Before and after each use, carefully inspect the compressor unit and hoses for signs of damage.
+ Check the air filter regularly, at least every six months. Simply remove the cover and clean the air filter.
To clean the filter gently wash in mild soapy water and rinse well. Replace if worn.
SPECIFICATIONS：
Voltage: 12 Volt DC
Maximum Pressure: 150 PSI
Maximum Air Flow: 250 Litres Per Minute
Inline Fuse: 120A
Maximum Voltage: 13.8 Volt
Maximum Amp Draw: 90 Amp
Maximum Operating Temperature: 60℃
Minimum Operating Temperature: -40℃
Electrical Current Protection: Circuit Breaker
Thermal Cut-off Protection: Automatic Thermal Cut-off at I05℃
Cylinder Diameter: 2 X 60mm
Power Cord: 3 Metres Heavy Duty Cable With Durable Battery Clamps
Rubber Air Hose: 10 Metres with In-line Pressure Gauge, Pressure Release Button and Quick Connect Fitting
Valve Connectors: 1 X Screw-on Brass Inflator and 1 X Thumb Lock Adaptor
Pressure Gauge: 0-150 PSI / 0-1, 034 kPa Multi Readings with Plastic Protective Cover
Solid Base Plate: Metal Sand Tray With Rubber Anti - Vibration Feet - Can be Permanently Mounted To a Vehicle
Air Filter: Built-ln Cleanable Sponge Filter
Accessories: 3 X Nozzle Adaptors for Camping and Sporting Equipment
Storage: Handy Carry Bag
PLU: 606623 CODE: WM102-15C
Manufactured & packaged for
SRGS PTY LTD
ABN 23 113 230 050
6 Coulthards Avenue
Strathpine QLD 4500, Australia
MADE IN CHINA
Recyclable Paper

Page 1 Page 2
DON'T GET CAUGHT OUT WITH INADEQUATE GEAR
WHILE 4WDING BECAUSE THERE'S NOTHING WORSE
THAN BEING STRANDED OFF THE BEATEN TRACK!
The XTM 150PSI 25OLPM Dual Air Compressor would be a
great addition to your next adventure.
Our product is guaranteed to be free from quality and manufacturing defects for a period of
12 months.
If your product becomes defective during this period, SRGS PTY LTD will offer you either a
replacement, credit or refund where a product is faulty; wrongly described; different from the
sample shown to you or do not do what they are supposed to do.
This warranty will not cover substantially modified product; misuse or abuse of the product
contrary to user instructions or packaging label; change of mind and normal wear and tear.
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and failure does not amount
to a major failure.
To claim the warranty, take the product to the front Service Desk of your nearest store of
purchase. You will need to show receipt or other proof of purchase. Additional information
may be required to process your claim. Should you not be able to provide proof of purchase
with a receipt or bank statement, identification showing name, address and signature may be
required to process your claim.
Any expenses relating to the return of your product to the store will normally have to be paid
by you. For online store purchases, SRGS PTY LTD will pay for the return freight for any
product assessed as having a major failure.
The benefits to the customer given by this warranty are in addition to other rights and reme-
dies of the Australian Consumer Law in relation to the goods or services to which this
warranty relates.
This warranty is provided by SRGS PTY LTD, 6 Coulthards Avenue Strathpine, QLD
4500, Australia. Phone: [phone].
1. Before operating the air compressor, check that you are in a safe location away from busy roads and
traffic, inspect the air compressor and accessories for any sign of damage. If there are signs of damage,
DO NOT use the air compressor and replace damaged parts.
2. Remove the air compressor from the carry bag and place it on a dry level surface near the 12 Volt
vehicle battery or power source.
3. Connect the 10 metre rubber air hose to the air compressor using the quick connect fitting.
4. Choose whether you want to use the screw type connector or the thumb lock adaptor. The screw type
connector is already attached to the air hose and is ready for use. If you choose the thumb lock connector,
simply screw the end of the thumb lock adaptor into the screw type connector on the air hose and ensure
a good seal is made. The thumb lock adaptor is now ready to connect.
5. Connect the RED battery clamp to your 12 Volt vehicle battery or power source's POSITIVE (+) post.
Connect the BLACK battery clamp to your 12 Volt vehicle battery or power source's NEGATIVE(-) post.
6. Test the connections and air flow by switching the air compressor ‘ON’ with the ‘ON/OFF’switch which
located on the body of the air compressor. Direct the hose away from yourself or any persons nearby
when testing the air compressor.
7. To inflate the tyre,connect the air hose to the tyre by removing the valve cap (if equipped) from the tyre
valve system. Check that the tyre valve system is clean and free from dirt.
+ If using the screw type connector, screw the brass inflator onto the tyre valve system. Finger tight
the brass inflator only.DO NOT use any tool as you may damage the inflator and/or the tyre valve
system.
+ If using the thumb lock adaptor,using your thumb press and hold the lever down, firmly press onto
the tyre valve system to create a good seal, now release the lever.
Inflate the tyre by switching ‘ON’ the air compressor with the "ON/OFF" switch which located on the
body of the air compressor. Watch the pressure gauge closely to monitor the tyre pressure. Once the
correct or desired pressure has been reached, turn the air compressor ‘0FF’.
8. Remove the brass inflator or the thumb lock adaptor from the tyre valve system. Remember to refit
the valve cap after you have completed the inflation process.
9. Disconnect the battery clamps from the 12 Volt vehicle battery or power source.
10.Allow the air compressor to cool completely before placing inside the carry bag.Remember storing the
air compressor in a dry location.
Use extra caution when inflating small objects such as bicycle tyres,sport balls.Pay closely attention to
the pressure gauge and be prepared to stop the air compressor when the manufacturer's recommended
is reached.
WARRANTY
WARNING
OPERATING INSTRUCTIONS
+ Read entire owners manual thoroughly before use.
+ This air compressor can only operate on a 12 Volt electrical system.
+ Use extreme caution when connecting air compressor to a power source as vehicle's batteries
can spark and/or vent explosive gasses. The use of safety glasses is recommended whilst
using the unit.
+ All parts of this unit, including handle, hose, hose fitting, coupler and compressor generates
high heat during and after operation. To avoid the risk of burns and injury, allow whole unit
to cool before handling.
+ Only inflate tyres to the manufacturer's recommended pressure. DO NOT over inflate tyres
as tyre failure could resulting serious injury or even death.
