Xtreamer e-TRAYz User manual

1

2
Contents
Overview .................................................................................................................................................................... 6
Xtreamer e-TRAYz Info. .......................................................................................................................................... 7
Major Functions ..................................................................................................................................................................................................................7
Storing and Sharing Files via the e-TRAY ........................................................................................................................................................7
Transferring data and Forwarding links via the RapidBox...............................................................................................7
Syncing Folder between sysadmin via SyncFolder ...........................................................................................................7
Downloading Entertainment data via e-Downloader/e-Torrent.....................................................................................7
Storing Music files and Enjoying via iTunes......................................................................................................................7
Website Hosting ..................................................................................................................................................................8
USB Print Server...................................................................................................................................................................8
USB Copy..............................................................................................................................................................................8
Specification..........................................................................................................................................................................................................................9
Appearance......................................................................................................................................................................................................................... 11
LED.......................................................................................................................................................................................................................................... 13
Button & Beef ................................................................................................................................................................................................................... 13
Disk Bay................................................................................................................................................................................................................................ 14
Xtreamer e-TRAYz Settings .................................................................................................................................. 15
Basic Setup ......................................................................................................................................................................................................................... 15
Disk................................................................................................................................................................................................................................... 15
Server name ................................................................................................................................................................................................................. 16
Administrator Information .................................................................................................................................................................................... 16
Mail Server.................................................................................................................................................................................................................... 17
Time ................................................................................................................................................................................................................................. 17
Port................................................................................................................................................................................................................................... 18
Router.............................................................................................................................................................................................................................. 19
DDNS............................................................................................................................................................................................................................... 21
Internet Connection ....................................................................................................................................................................................................... 22
Example of Internet Connection with a Router.......................................................................................................................................... 22
Example of Router Setup....................................................................................................................................................................................... 24

3
Settings .................................................................................................................................................................... 29
Access to e-TRAYz Home............................................................................................................................................................................................ 29
Disk and Volume Management................................................................................................................................................................................ 29
RAID mode changing............................................................................................................................................................................................ 29
Adding New disk..................................................................................................................................................................................................... 31
Using as External Disk .......................................................................................................................................................................................... 34
Power..................................................................................................................................................................................................................................... 36
Auto Shutdown ........................................................................................................................................................................................................ 36
HDD Sleep mode .................................................................................................................................................................................................... 36
Upgrade Firmware .......................................................................................................................................................................................................... 37
Current Firmware Info........................................................................................................................................................................................... 37
Download & Upgrade Firmware ..................................................................................................................................................................... 37
Reset ...................................................................................................................................................................................................................................... 38
Factory Reset............................................................................................................................................................................................................. 38
Configuration Reset ............................................................................................................................................................................................... 38
Router setup using UPnP ............................................................................................................................................................................................ 39
Backup & Recovery Firmware ................................................................................................................................................................................... 42
Current Firmware Info........................................................................................................................................................................................... 42
Backup & Recovery Firmware........................................................................................................................................................................... 42
File Storage & Sharing .......................................................................................................................................... 44
Disk Type ............................................................................................................................................................................................................................. 44
System Folder.................................................................................................................................................................................................................... 45
e-TRAYz ................................................................................................................................................................................................................................ 46
Run e-TRAYz ............................................................................................................................................................................................................ 47
Disk Using................................................................................................................................................................................................................... 49
Disk Disconnect........................................................................................................................................................................................................ 50
Setting .......................................................................................................................................................................................................................... 51
Share.............................................................................................................................................................................................................................. 52
Sharing options........................................................................................................................................................................................................ 55
Unshare ........................................................................................................................................................................................................................ 55
e-TRAYz web...................................................................................................................................................................................................................... 56
File management..................................................................................................................................................................................................... 57

4
Linkmail ........................................................................................................................................................................................................................ 59
Linkcopy....................................................................................................................................................................................................................... 60
Share.............................................................................................................................................................................................................................. 61
Sharing options........................................................................................................................................................................................................ 65
Unshare ........................................................................................................................................................................................................................ 66
RapidBox .................................................................................................................................................................. 67
File Upload.......................................................................................................................................................................................................................... 68
Recent Upload .................................................................................................................................................................................................................. 69
Allow Guest access ......................................................................................................................................................................................................... 70
e-Downloader.......................................................................................................................................................... 71
File Download ................................................................................................................................................................................................................... 72
Extract.................................................................................................................................................................................................................................... 73
Download Option............................................................................................................................................................................................................ 74
Completed List.................................................................................................................................................................................................................. 74
Settings................................................................................................................................................................................................................................. 75
Download Setting ................................................................................................................................................................................................... 75
Premium Account info.......................................................................................................................................................................................... 75
SyncFolder ............................................................................................................................................................... 77
Add Friends ........................................................................................................................................................................................................................ 77
Folder I Sync ...................................................................................................................................................................................................................... 78
Synchronize................................................................................................................................................................................................................ 78
Sync with more friends ........................................................................................................................................................................................ 79
Remove Sync............................................................................................................................................................................................................. 80
Getting Synced ................................................................................................................................................................................................................. 81
Getting Synced......................................................................................................................................................................................................... 81
Sync Now .................................................................................................................................................................................................................... 83
Recent Sync Info...................................................................................................................................................................................................... 84
Setup Sync schedule.............................................................................................................................................................................................. 84
Changing Syncfolder ............................................................................................................................................................................................. 85
Remove Sync............................................................................................................................................................................................................. 86
e-Torrent .................................................................................................................................................................. 87
Torrent RSS......................................................................................................................................................................................................................... 88

5
Viewing the list of Torrent Files....................................................................................................................................................................... 88
Torrent Site Registration...................................................................................................................................................................................... 89
Torrent Search................................................................................................................................................................................................................... 91
Torrent Download ........................................................................................................................................................................................................... 92
File Download by using ‘Torrent RSS’ and ‘Torrent Search’.............................................................................................................. 92
File Download by using Torrent File Registration .................................................................................................................................. 93
ETC ............................................................................................................................................................................ 94
Print Connection .............................................................................................................................................................................................................. 94
Using iTunes....................................................................................................................................................................................................................... 96
USB AutoCopy .................................................................................................................................................................................................................. 97
Personal Homepage....................................................................................................................................................................................................... 98
Appendix.................................................................................................................................................................. 99
Application.......................................................................................................................................................................................................................... 99
FAQ.......................................................................................................................................................................................................................................102
Troubleshooting.............................................................................................................................................................................................................105

6
Overview
This USER GUIDE covers all major functions and management of Xtreamer e-TRAYz. Please refer to Online Guide for
further details.
-Online User Guide : http://www.eunicorn.co.kr/eTRAYz/manual/1.0.0/kr/user/manual.html
-Online Settings Guide : http://www.eunicorn.co.kr/eTRAYz/manual/1.0.0/kr/settings/manual.html

7
Xtreamer e-TRAYz Info.
Major Functions
Congratulation on your purchase of Xtreamer e-TRAYz. Xtreamer e-TRAYz is specially designed for the following
purposes.
Storing and Sharing Files vie the e-TRAYz
Users can easily save and share files within the Intranet or through the Internet using ‘e-TRAYz’. Especially,
Windows users can easily use e-TRAYz’ Disk just like Network Drive through the Internet.
Transfering data and Forwarding links via the RapidBox
Users can easily upload files onto e-TRAYz as well as to send a linkage of the file to others using RapidBox. If
guest receive permission, the guest can transfer files to e-TRAYz’ owner without user account on login browser.
Syncing Folder between sysadmin via SyncFolder
SyncFolder allow you to sync folders and share files with other users. After registering to ‘friend’ with IP(or
domain) and setting, you and your ‘friend’ can share and sync folders each other. You can set up a Sync
Schedule and synchronize the folders synced with me by using ‘Sync Now’ button right now.
Downloading Entertainment data via e-Downloader/e-Torrent
e-Downloader allow you to download sequentially the link of files divided by several parts from file sharing sites,
such as Megaupload or Rapidshare. If you use e-Downloader function, you can download files onto e-TRAYz
without authentication at each download. By using e-Torrent, you can download media files from the Internet
through BitTorrent to Xtreamer e-TRAYz. If you have an UPnP DMA connected in the LAN, you can share the
multimedia files on XTreamer e-TRAYz.
Storing Music files and Enjoying via iTunes
You can listen to the music saved in Xtreamer e-TRAYz by using iTunes client.

8
Website Hosting
Xtreamer e-TRAYz allows you to host website with Apache and PHP supported.
USB Print Server
You can share USB 2.0 Printers through the LAN.
USB Copy
The built-in ‘Copy’ button on the device allows instant copy of files from the USB device to Xtreamer e-TRAYz.

9
Specification
Item Xtreamer e-TRAYz
System
CPU OXE8xx
Memory 128MB
Flash 4MB
HDD 3.5” HDD X 2
I/O Interface USB port Upper : 2.0 X 1 for Wireless LAN and USB External storage
Bottom : 1.1 X 1 for print server and USB External storage
Buttons Power, Reset, USB Auto-Copy
LAN Wireless LAN X 1 (802.11b/g/n, USB Type)
Wired LAN X 1 (Gbit)
FAN Smart FAN X 1 (Auto Sensing)
Dimenstion(H X W X D) 120mm*81mm*182mm
Network
DHCP Server YES
Dynamic DNS ***.myetrayz.net
Jumbo Frame YES
Network File Protocol CIFS, NFS, AFP
Additional Useful Protocol FTP with SSL/TLS, SSH, Secure SMTP
Client Platform e-TRAYz Web : Windows/Linux/Mac
e-TRAYz Connector : Windows 2000, 2003, XP, Vista, Win7(32bit)
Web Browser Internet Explorer, Firefox (recommended)
Web Server Apache, MySQL, SQLite, PHP
USB function USB auto-copy, Volume Expansion, Wireless LAN, Printer Server
Multimedia iTunes Music Server
UPnP device, Port mapping
RapidBox
Non-member can upload file to admin
URL Link mail & URL Link copy
Recent Event
SyncFolder
Synch Folder I share
Synch Folder shared with me
Scheduled Synch
Friend Management
e-TRAYz Connector
e-TRAYz Disk for admin’s private space. Admin can share sub-
folders with users
Private Disk for users’ private space
Public Disk for sharing with local devices and USB auto copy
External Disk for USB device
Start on system startup
System Tray

10
Disk connect/disconnect
e-TRAYz Web File manager
e-TRAYz Disk for admin’s private space. Admin can share sub-
folders with users
Private Disk for users’ private space
Public Disk for sharing with local devices(media player, game
device, settop box etc.) and USB auto copy
External Disk for USB device
Create user account with e-mail address automatically
Multi files upload / File&Folder download
URL Link mail for Big sized file
URL Link copy
e-Downloader Plugins Rapidshare.com, megaupload.com
Settings Premium account, Download control
e-Torrent Torrent RSS, Torrent Search, Download
RAID Level RAID 1, Linear
System Management
Web-based Settings
E-mail Alert
Alarm Buzzer
HDD/USB Disk Sleep mode
Scheduled Power Off
Language English, Korean
Limitations
1. e-TRAYz Connector only be supported to Windows users.
2. Each Xtreamer e-TRAYz supports 1 USB printer.

11
Appearance

12
Article Name Location Description
LED Front Display status of system, internal hard disk, USB device and so on.
FAN Rear The fan is built to exhaust waste heat out of Xtreamer e-TRAYz. It
will start automatically when the server starts.
Copy Rear Pressing the button will copy the data from the connected USB
device to the Xtreamer e-TRAYz’ internal HDD.
USB Port Rear Xtreamer e-TRAYz offers 2 USB ports for adding additional external
hard drives, USB printers, USB wireless LAN or other USB devices.
Reset Rear
This is for the reset of Network setup.
When the power switch is turned on while Reset button is pressing
for 2~3 sec, a booting initialization is done. You need to boot this
way when you reinstall software replacing internal hard disk.
LAN Rear The LAN port is where you connect RJ-4 cable to Xtreamer e-
TRAYz.
Power Port Rear The power port is where you connect the AC power adapter.

13
LED
LED Color Status Description
Power/Access BLUE
Turned on Connected power
Blinking Data read and write at HDD
Turned off Disconnected power
HDD A/HDD B RED Turned on Disconnected or abnormal status of HDD A/B
Turned off At normal status of HDD A/B
USB YELLOW
Cyclic Blinking Installing software or not installed the software
Non-Cyclic
Blinking Data read and write at USB device
Network GREEN Turned on Connected LAN cable normally
Turned Off Disconnected LAN cable
Button and Beep
Button/Beep Description
Copy
When the USB device is connected, this button is pressed for 1 sec and release, copy
starts from USB device to internal disk(External Disk – USB_copy) with a single beep.
During the copy, this button is pressed for 3 sec and released the copy stopped with
2 beep.
Reset
When this button is pressed for 3 sec, the network initialization is started with a
single beep and completed with 2 beeps.
When the power switch is turned on while Reset button is pressing for 2~3 sec, a
booting initialization is done.
Single Beep
When system booting is completed.
When system successfully recognizes the newly connected USB device.
When USB copy is started.
When the network initialization is started.
2 Beep
When USB copy is completed.
When USB copy is canceled.
When USB device is disconnected.
When the network initialization is completed.

14
Disk Bay
Disk Description
HDD A The disk slit on the Front-right side. When you use only one disk, please insert here.
HDD B The disk slit on the Front-left side.

15
Xtreamer e-TRAYz Settings
Basic Setup
After installing software, you can setup default settings using Setup Wizard. At initial setup, you must complete
all steps to use the Xtreamer e-TRAYz.
The Setup Wizard automatically runs after login, and you can change the settings at any time
Disk
1. You can view information and status of the disk on the system and setup RAID mode.
Using 1 HDD Using 2 HDD.
2. Set RAID mode of internal hard disk as Linear or RAID 1. If security is more important than disk capacity,
choose the mirroring(RAID 1) mode, or if you want to use the maximum capacity of the disk, choose the
expansion(Linear) mode.
Expansion(Linear)
mode
The installed disks are integrated into one big logical disk: 2 physical 1-TB disks
are treated as one 2-TB disk.
Mirroring(RAID 1)
mode
The same data is copied on two different disks. Should one disk fail due to an
error, you can still read the data from the other disk, provided that you have
selected security mode.
3. Click ‘Volume configuration’. It may be take several minutes.

16
Server Name
1. Server name is displayed when searching equipment with iTunes, network drive or UPnP. Enter alphabet,
numbers, ‘_’ or combination of those. Click ‘Apply’ button to save the set information.
Administrator Information
1. Set information of administrator. Input sysadmin's password, e-mail address and name. The ID of
Administrator cannot be changed.
2. E-mail address is required to send Linkmail, Alarm mail and etc, so it must be accurately described.

17
Mail
1. Set mail server.
2. If mail server is not set, mail-related functions, such as Link mail or alarm mail, etc, are not activated. Please
set your mail server for useful e-TRAYz.
3. After mail setting, click ‘sending test mail’ and verify that mail sent correctly.
Time
1. Set current time and Time zone.
2. If you don't use NTP server, set date and time manually.

18
Port
1. Set service port. You can set Web port, e-TRAYz authentication port and e-torrent port.
2. When you use router, each service port of router must be opened to access e-TRAYz through the internet.
Web port Setup e-TRAYz Home port and e-TRAYz homepage port. Default port of e-
TRAYz Home port is 8080, and of homepage is 8000.
e-TRAYz port Setup authentication port of e-TRAYz. You must enter authentication port
at connector. Default port is 13196.
e-Torrent port
Setup e-Torrent port range. It can be set from 1024 to 65535 manually. The
last port value is automatically set with (starting port + 10). Default starting
port is 6890 and the last is 6900.

19
Router
Router setup is used to grant internet users access to an e-TRAYz on your network.
※This step can be skipped if you are not connected to the Internet via a router.
※Not all routers provide these functions. Different router models may use different terminology. For more
detailed information, refer to the router’s manual.
UPnP Port Mapping
UPnP port mapping can be used to access devices on your LAN from the Internet.
Devices on the LAN are identified by a port number. Your router has to support
UPnP Port mapping in order to use this function
DMZ DMZ can be used to access a single device on your LAN from the Internet. If DMZ
option is used then only e-TRAYz can be accessed.
Port Forwarding
(Virtual Server)
Port Forwarding can be used to access devices on your LAN from the Internet.
Devices on the LAN are identified by a port number.
※We recommend to use DMZ because it is simpler to setup than Port Forwarding.
※If you are using both DMZ and Port Forwarding simultaneously, Port Forwarding will be applied prior to
DMZ.

20
Router Setting
- Connect the e-TRAYz to a router or modem via a LAN cable.
- Select one of two following options.
1. Using router's UPnP function.
(1) Login to your router and activate the UPnP function.
(2) Log out.
(3) Login to e-TRAYz main menu page and go to [Setup Wizard]-[Router] menu.
(3) Select ‘Use router's UPnP function’ button.
(4) Click ‘Go to UPnP setup’ button then UPnP setting page will appear.
(5) Mark ‘Activate router port mapping function using UPnP’ checkbox and then click 'Change Setup' button.
Then you will see Port mapping settings.
(5) Enter a port number you want and click ‘Apply’ check box and 'Change Setup' button.
(6) Log out of e-TRAYz.
UPnP port mapping function may not work in following cases.
•If router does not support UPnP protocol
•If router's UPnP IGD can not communicate with e-TRAYz UPnP Client.
•Router may loose mapping information after a reboot. In this case you will need to configure it again.
2. Using router’s DMZ or Port Forwarding(virtual server) function.
(1) Login to your router.
(2) For DMZ go to DMZ setup Menu. You may need to activate your router's Firewall first.
- enter IP address of e-TRAYz to IP input box.
(3) For Port Forwarding(Virtual Server),go to Port Forwarding setup menu.
- enter IP address of e-TRAYz to IP input box.
- enter port number used by e-TRAYz to port input box.
- enter protocol to protocol input box.
(4) Log out.
Function Protocol Port Number
Private Homepage TCP 8000
e-TRAYz Home TCP 8080
