OWNER SMANUAL
INSTALLATION,OPERATION, &PARTS
Beforeinstallation, besuretoread all instructionsand warnings carefully.
Refer toproductdataplate(s) foradditional operatinginstruction and specifications.
Inspection
Examine the equipment when received. Notifyyour dealer or carrierof anydamageormissingparts.Verify
that equipment isofsizeand modelspecified.
Important SafetyInstructions
Wheninstallingandusingthiselectricalequipment,basic safetyprecationsshould alwaysbe followed,
including the following:
1.READ AND FOLLOWALLINSTRUCTIONS.
2.WARNING Toreduceriskofinjury, do notpermitchildren tousethisproduct unless theyareclosely

2
supervised at all times.
3.WARNING (For cord& plug connected units). Risk of ElectricalShock. Connectonlytoagrounding type
receptacle protectedbyaground-fault circuit-interrupter (GFCI). Contact aqualified electrician if you cannot
verifythat thereceptacle isprotectedbyaGFCI.
4.WARNING (Forcord& plug connected units). Donotburycord.Locatecordtominimizeabusefromlawn
mowers, hedge trimmersandother equipment.
5.WARNING (For cord& plug connected units). Toreducethe riskofelectricshock, replacedamaged cord
immediately.
6.WARNING (For cord& plug connected units). Toreducethe riskofelectricalshockdonotusean extension
cordtoconnectunittoelectrical supply;provide aproperlylocatedoutlet.
7.CAUTION (For pumpswitha25 ft. (7.62mcord). Thispumpis for usewithstorable poolsonly. Donot use
withpermanentlyinstalled pools.Astorablepool is constructed sothat itmaybereadilydisassembled for
storage and reassembledtoitsoriginalintegrity.Apermanently installed pool is constructed inoron the ground
or in abuilding suchthat it cannot bereadilydisassembled for storage.
8.CAUTION (For pumpswith/without3ft.(91mcord) or6ft.(1.82mcord). Thispumpisforusewith
permanentlyinstalled pools andmayalso be usedwithhottubsand spasifsomarked.Donot usewith
storable pools.Apermanentlyinstalledpool isconstructed in or on the groundorin abuildingsuchthatit
cannot bereadilydisassembledforstorage.Astorable pool isconstructed sothat it maybereadily
disassembledforstorage and reassembledtoitsoriginalintegrity.
9.WARNING (For hot tuband spapumps). Donot install within anouter enclosureorbeneaththeskirt of the
hot tuborspa, unlesssomarked.
10. SAVE THESE INSTRUCTIONS!
Installation Location
Locatepumpasclosetopool/spa aspossible, preferablyin adry, well ventilatedarea awayfromdirect
sunlight. It should be onahard, levelsurface. Giveconsiderationto:
1. Drainage awayfrompump.
2. Ventilationofpumpmotor.
3.Accessfor futureservicing and winterizing.
4. Protection fromthe elements.
Pumpswithoutstrainerbodiesaredesigned forfloodedsuction(allsuction fittingsand suctionpiping below
water level) andwill notself-prime. Consequently, thepumpmustbe installed at anelevation that isbelowwater
level when pool orspaisfilled;however, if suction linevalvesareinstalled, the pumpmaybeclosedforpriming.
Keep verticaldistancetoaminimumif youchoosetomountpumpabovewater level.
Pumpswithstrainerbodiesareself-primingbut should bemountedasclosetothe water level aspossible or
belowfor easein priming.
General Plumbing
FOR SOLVENTWELD CONNECTION
Rigid or flexible PVC pipecan be used.Pipeendsshouldbe clean and free ofanyflashcausebythe cutting
operation.Besurethat the proper adhesiveisused onthetype ofpipespecified.
Note: Aprimerwill assurethatadhesivejointsaresuperior.SuregardP-3000 hasapurple tracertoqualifyin areas
wherecodesspecifyaprimermustbe used.

3
Caution: Werecommend thatyou consider climaticconditionswhen applying adhesives. Certainatmospheric
situations,suchashigh moisturecontent, makeadhesiveaction ofcertain glueslesseffective. Check the
manufacturer’sinstructions.
FORTHREADED CONNECTIONS
UseonlyTeflontapeorequivalenton threaded plumbingconnections. Other pipe compoundsmaydamage
threads.Wedonot recommendthe useofsilicone or
petroleumbased compounds.DONOTOVERTIGHTEN HAND TIGHTEN PLUS ½TURN IS SUFFICIENT.
Pump Plumbing
Suction pipe should be aslargeor larger thatdischarge pipe. Avoid using suctionpipesmallthat pump
connection.
Keep thepipingasstraight andshort aspossible, and ofsuitable size.Avoid connectinganelbowdirectlyinto
the pumpinlet (usealengthofstraightpipetoallowaproperentryfor the water). Arrange horizontalrunstoslope
upwardtothepumptoprevent highspotsthatcould formairpockets. Support the pipeindependentlysothat it
placesno strain on the pump.Keep asmuchofthe suction line aspossible belowthe water leveltoreduce priming
time.Installvalvesand unionsin the pumpsuction and return linestofacilitateservicing.Valvesarerecommended
for throttling
maintenanceif the systemisinstalledbelowdecklevel. Suction valvesareessentialfor primingallpumpswithout
strainer bodiesinstalled abovewater level. Pumpswith
strainer bodiesareself-priming, nevertheless,werecommendthe useofcheck valvein thesuctionpipe ator
belowthe water levelifthe suction liftis morethat fivefeetorif thedrysuction ismorethatten feet long. Keep the
valvein thesuction linefullyopen duringoperation.
ElectricalData
Refer toinformation on motor nameplatefoelectricalservicedata.Allmotorsshouldhavefuseddisconnect
switchorcircuitbreaker.Besurewiresizeis sufficientforpumpHPand distancefrompowersource.Wiring should
be done inaccordancewithapplicablecodesbyacompetentelectrician.
We recommend the installationof aground faultcircuit interrupter for maximumsafety.
Pump Start Up
Donot operatepumpuntil it hasbeen primed aswater actstocool and lubricatetheseal. For pumpswithout
strainer bodiesand locaterabovewater, closesuctionline valveandfillpumpwithwater in order toprime.For
pumpswithstrainerbodiesandlocated abovewater,prime byremovingstrainer coverand filling strainer bodywith
water. Pumpslocated belowwater level will selfprimeifallpiping is alsobelowwater level.After pumphasbeen
primed, energizemotor and open allsuction and discharge line valves.It maytakesometimeforpumptoremove
air fromsuction lines.If noflowis observedin fiveminutes, stop the motor andre-prime. Ifthe pumpfails to
operate, checkfor airleaks. Refer to TroubleShootingsection.
After about ten minutesofoperation, checkthereturnfittingsfor airbubbles.Acontinuousflowof air indicates
leaksinsuction line. Locateandcorrectanyleaksimmediately.
CONTROLLINGTHE OUTPUT
Keep the gate valvein the suctionline fullyopenduringoperation.Should itbenecessarytocontroltheoutput,
useavalveinthe returnline.
Caution: Donot retighten strainer Ring-Lokduring operation.
Caution: Donot operatepumpwithclosedsuction ordischarge valves.

4
Two-Speed Pumps
Two-speed modelsarerecommended in aswimming pool when high speedisneeded for maximumfiltration
at peakperiodsand wheneverturbiditylevelsarehigh.At other times,switchtolowspeed. For backwashing and
vacuuming,high speedisrequired.
Inspasandhottubs,usehighspeedtoattain fullperformancein the hydro-therapymode.Atothertimes,such
asfilter/heatcyclemode,uselowspeed.Lowspeedprovidessufficient flowtoactivatemost spaheatersand
providessufficient flowfor filtration.
Injettedtubs,usehigh speed toattainfull performancein the hydro-therapymode and uselowspeed modeto
prime.The belowpictureshowshowtoswitchbetween the high speedandlowspeed.
ON-OFF Single-Speed Pumps
Inorder tohaveasaferandquickerstart of theswimmingpool filtrationsystems(or pumps), itis verynecessa
-rytoinstallON-FF switch.Withoutit, everystart orshut downneedtoplug/unplugthepower cord, itwill causea
lot ofsafetyrisks, suchas,sparkoccurswhen plug/unplug thepower cordandfrequentplug/unplug will causepo
or contact between plugandsocket. The belowpictureshowshowtoswitchbetween ON and OFF.
================================================================

5
Winterizing
Consult your dealer foradvice onwinterizing your
equipment iffreezingtemperaturesoccur inyour
locality. His knowledge ofyourequipmentmakeshim
the bestqualified sourceof information.Followhis
recommendations, and if theseincludedraining the
filtersystem,proceed asfollows:
1.If yoursystemdoesnotcontain afilter,proceedto
step2.
A. Forsand filters: BACKWASH for 3to5minutes
and set dialvalvetoWINTERIZE.
B.Forcartridgefilters:Clean the filterelementand
storein adryplace.
2.Drainsystembyloosening drainplugs(drain plugs
will drain withoutcompletelyremoving the plug from
unit) and/or removing pipecaps.
WaterChemistry
Aproperandconsistent useofchemicalsis
necessarytomaintainclean,sanitarywater, prevent a
spreadofgerminfection andcontrolthe growthof
algaewhichcan spoil the appearanceand enjoyment
of your pool or spa.
Chlorineisthemostcommonly used chemical to
provide clean,sanitarywater.Eitherdryor liquid
chlorine (calciumor sodiumhypochlorite) can beused
whichshouldbe addeddailyasitis dissipatedbydirt
and germsaswell asbe the sun andwind.
It is alsoimportantthatthecorrect level ofacidity
or alkalinityofthe poolwater bemaintained.Thisis
the pH of your pool withpH7.0being neutral.
Readingsabove7.0arealkaline and belowareacid.A
desirablerange is7.2 7.4.
Pump Maintenance
1. Motorsareself-lubricating no lubrication required.
2.Cleanhair&lintstrainerifyou haveastrainerbody
pump.
3. Visuallyinspectmotorforblockage of air ventson
motorshell. Removeanydebrisafter breakeroff.
4.Shaftseals maybecomewornand mustbe replaced
if leakage isobserved.
Cleaning
Switchpower off. Closevalvesinsuction and
returnline. Unscrewstrainer Ring-Lok
counterclockwise and removethe strainer cover from
hair and lintstrainerand lift out strainerbasket. Clean
and replacethe basket. Takecaretoseat basket
properly.Clean O-Ring andre-lubricatewithpetroleum
jellyifnecessary. CleanO-Ringseatson cover and
strainer. Refitcover and strainer hand tighten only
and open valves. Putpumpback intooperation.
Caution: Donot retighten strainer during operation.
Service & RepairParts
Referall servicetoyourlocal dealerashis
knowledgeofyourequipmentmakeshimthebest
qualifiedsourceofinformation.Orderallrepairparts
throughyourdealer.Givethefollowing information
when orderingrepairparts:
1. Unitnameplatedata.
2. Descriptionofpart.
TroubleShooting
MOTOR DOES NOTSTART
1.Disconnect switch or circuitbreakerin OFFposition.
2.Fusesblownorthermaloverloadopen.Locked
motorshaft.
3. Motor windings burned out.
4. Defectivestarting switchinside single-phasemotor
5. Disconnected or defectivewiring
6. Lowvoltage
MOTOR DOES NOTREACH FULLSPEED
1. Lowvoltage
2. 2speedmodelset onlowspeed
3.Motorwindings connected forwrong voltage on dual
voltage model.
MOTOR OVERHEATS (Protect trips)
1. Lowvoltage
2.Motorwindings connected forwrong voltage on dual
voltage model.
3. Inadequateventilation

6
PUMPDELIVERS NOWATER
1. Pumpisnot primed
2. Closed valvein suctionor discharge line
3. Leakage orairintosuction system
4. Impeller clogged
LOWPUMPCAPACITY
1. Valvein suction ordischargelinepartlyclosed
2. Suctionor discharge line partlyplugged
3. Suctionor discharge line toosmall
4. Pumprunningat reduced speed (seeabove)
5. Pluggedbasket in skimmeror hairandlint strainer
6. Dirtyfilter
7. Impeller clogged
8.Wrong rotation (3phaseonly)
LOWPUMPPRESSURE
1. Pumprunningat reduced speed (seeabove)
2.Wrong rotation (3phaseonly)
3. Discharge valveorinlet fittingsclosed too much
HIGH PUMPPRESSURE
1. Discharge valveorinlet fittingsclosed too much
2. Returnlinestoo small
3. Dirtyfilters
NOISYPUMPAND MOTOR
1. Pluggedbasket in skimmeror hairin lintstrainer
2.Wornmotorbearings
3. Valvein suction line partlyclosed
4. Suctionline partlyplugged
5. Vacuumhosepluggedortoosmall
6. Pumpnot supported properly
LEAKAGE OFWATER ATSHAFT
1. Shaft seal requiresreplacement
AIR BUBBLES ATINLEYFITTINGS
1. Leakageairintosuction lineat connectionsor valve
stem
2.Covergasket of hairand lint strainer needscleaning
3. Restriction in suctionline
4. Lowwater level inpool
NOTE:If the recommendations intheTrouble
Shooting portion ofthismanual donot solveyour
particularproblem(s),please contactyourlocal
dealerforservice.
TECHNICALDATA
Model HP RPM Volte/ HZ Amps Remark
72712/72713 1/4HP 3450 115V/60HZ 2.5
Single- speed
72714/72715 1/3HP 3450 115V/60HZ 3.6
72720 1/2HP 3450 115V/60HZ 5
72721 1/2HP 3450 115V/60HZ 5
72728 0.75HP SPL 3450 115V/60HZ 7.3
72729 1.0HP SPL 3450 115V/60HZ 9
72729S 1.0HP SPL 3450 115V/60HZ 9
72730 1.5HP SPL 3450 115V/60HZ 12
72730S 1.5HP SPL 3450 115V/60HZ 12
72742 0.75 HP 3450 115V/60HZ 9.2
72743 1.0HP 3450 115V/230V/60HZ 11.5/5.7
72744 1.5HP 3450 115V/230V/60HZ 14/7
72747 1.0HP 3450 115V/230V/60HZ 11.5/5.7
72748 1.5HP 3450 115V/230V/60HZ 14.2/7.1
72726 1.0HP SPL 3450/1720 115V/60HZ 10A/3.2A Two- speed
72727 1.5HP SPL 3450/1720 115V/60HZ 12A/3.6A

7
72749 0.75 HP 3450/1720 115V/60HZ 10A/3.2A
72750 1.0HP 3450/1720 115V/60HZ 12A/3.6A
72751 1.5HP 3450/1720 230V/60HZ 7.5A/2.1A
72754 1.0HP 3450/1720 115V/60HZ 12A/3.6A
72755 1.5HP 3450/1720 230V/60HZ 7.5A/2.1A
PartsListing:72712 /72714/72720
Ref. No. Part No. Description QTY
1 647251201080 Pump housing 1
2a 647271271000 Impellerfor72712 1
2b 647251271000 Impellerfor72714 1
2c 647272071000 Impellerfor72720 1
3 65431069080 o-ring 1
4 65028013000 Seal assembly 1
5 647251202080 Pump cover 1
6a 65023017000 0.25HPmotorfor72712 1
6b 65023018000 0.35HPmotorfor72714 1
6C 65023151000 0.5HPmotorfor72720 1
7 65224024000 ScrewM5X20 4
a
b
c
a
b
c

8
PartsListing:72713 /72715/72721
Ref. No. Part No. Description QTY
1 647251503000 Cover 1
2 65431071080 o-ring 1
3 647251507001 basket 1
4 647251501080 Pump housing 1
5 65431070080 o-ring 1
6 647251504080 diffuser 1
7a 647271271000 Impellerfor72713 1
7b 647251271000 Impellerfor72715 1
7C 647272071000 Impellerfor72721
8 65431037080 o-ring 1
9 65028013000 Seal assembly 1
10 647251502080 Pump cover 1
11 65224004000 ScrewM6X25 6
12a 65023017000 0.25HPmotorfor72713 1
12b 65023018000 0.35HPmotorfor72715 1
12C 65023151000 0.5HPmotorfor72721 1
13 65224025000 ScrewM5X14 4
14 65231002000 Nut M6 6
15 65432002080 gasket 1
16 88601007000 Drainplug 1
a
b
c
a
b
c

9
PartsListing:72728 /72729/ 72729S/72730/72730S / 72726 /72727
Ref. No. Part No. Description QTY
1 647252772000 Cover1
2 65431042080 o-ring 1
3 647252704001 Basket1
4 647252705080 Clip1
5 647252703080 Strainerhousing 1
6 647252702080 Pump cover 1
7a 647272871000 Impellerfor72728 1
7b 647272971000 Impellerfor72729 /72729S/72726 1
7c 647252771000 Impellerfor72730 /72730S/72727 1
8 65028003000 Seal assembly 1
9 647252701080 Pump housing 1
10 65431040080 o-ring 1
11 65212016000 ScrewST5.5X25 8
12 65431029080 O-RING 1
13 65432002080 gasket 1
14 648860105080 Drainplug 1
15 647252708080 Motormounting plate 1
16a 65023005000 0.75HPmotorfor72728 1
16b 65023006000 1.0HPmotorfor72729/72729S 1
16c 65023007000 1.5HPmotorfor72730/72730S 1
16e 65023081000 1.0HPtwo-speed motorfor72726 1
16f 65023084000 1.5HPtwo-speed motorfor72727 1

10
PartsListing:72742/ 72743 /72744/ 72749/ 72750/ 72751
Ref. No. Part No. Description QTY
1 647252772000 Cover1
2 65431042080 o-ring 1
3 647252704001 Basket1
4 647254201080 Pump housing 1
5 65431032080 o-ring 1
6 647254203080 Diffuser1
7a 647274271000 Impellerfor72742 /72749 1
7b 647274371000 Impellerfor72743 /72750 1
7c 647254271000 Impellerfor72744 /72751 1
8 65431075080 o-ring 1
9 647254202080 Pump cover 1
10 65244005000 gasketM8 8
11 65221009000 ScrewM8X40 8
12 65028003000 Seal assembly 1
13 65231004106 Nut M8 8
14 65432002080 gasket 1
15 648860105080 Drainplug 1
16 647254205080 Foot insertwfepump 1
17 647254204080 Mountingfoot 1
18a 65023019000 0.75HPmotorfor72742 1
18b 65023020000 1.0HPmotorfor72743 1
18c 65023021000 1.5HPmotorfor72744 1
18d 65023087000 0.75HPtwo-speedmotorfor72749 1
18e 65023088000 1.0HPtwo-speed motorfor72750 1
18f 65023085000 1.5HPtwo-speed motorfor72751 1

11
PartsListing:72747/ 72748 /72754/ 72755
Ref. No. Part No. Description QTY
1 647252772000 Cover1
2 65431042080 o-ring 1
3 647252704001 Basket1
4 647254701080 Pump housing 1
5 65431032080 o-ring 1
6 65212025000 ScrewST4.2X38 2
7 647254703080 Diffuser 1
8a 647274771000 Impellerfor72747 /72754 1
8b 647274871000 Impellerfor72748 /72755 1
9 65431074080 o-ring 1
10 647254702080 Pump cover 1
11 65244015000 GasketM10 6
12 65225003000 Screw3/8-16*11/2UNC 6
13 65028014000 Seal assembly 1
14 647254705080 Foot insertwfepump 1
15 647254704080 Mountingfoot 1
16 65224003000 ScrewM6X20 2
17 65244016000 GasketM6 2
18 65231002106 Nut M6 2
19 65232001106 Nut 3/8-16 6
20 65432002080 Gasket 1
21 648860105080 Drainplug 1
22 65244015000 GasketM10 4
23 65221008000 ScrewM10X25 4
24a 65023022000 1.0HPmotorfor72747 1
24b 65023023000 1.5HPmotorfor72748 1
24c 65023083000 1.0HPtwo-speed motorfor72754 1
24d 65023086000 1.5HPtwo-speed motorfor72755 1
