Xtreme Power 76045-XP Original instruction manual

1HP SUBMERSIBLE PUMP, 900W STAINLESS STEEL
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE
PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM
(OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM #76045-XP
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions may
result in electric shock, re and/or serious injury. Save all warnings and instructions for future
reference.
The warnings, precautions, and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be supplied by the operator. Read
carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure
to follow the safety rules and other basic safety precautions may result in serious personal injury.
1
Read and understand all instructions. Failure to follow all instructions may result in serious injury or
property damage.
DO NOT allow persons to operate or assemble the product until they have read this manual and have
developed a thorough understanding of how it works.
DO NOT modify this product in any way. Unauthorized modication may impair the function and/or
safety and could affect the life of the product. There are specic applications for which the product was
designed.
Use the right Pump for the job. DO NOT attempt to force a small Pump or attachment to do the work
of a larger industrial Pump. There are certain applications for which this Pump was designed. DO NOT
modify this Pump and do not use this Pump for a purpose for which it was not intended.
Maintain Pump with care. Inspect cords periodically and, if damaged, have them repaired by an
authorized technician.
Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered,
wet, or dark work areas can result in injury.
DO NOT use the product where there is a risk of causing a re or an explosion; e.g., in the presence
of ammable liquids, gases, or dust. The product can create sparks, which may ignite the
ammable liquids, gases, or dust.
Guard against electric shock. Prevent body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerator enclosures. It is strongly recommended that this Pump be plugged into a Ground
Fault Circuit Interrupter (GFCI). Ask a local electrician for easy installation instructions. To avoid electrical
shock, no person or animal should be in contact with the water being pumped. Never walk on wet or
damp area when pump is running in the same room.
Keep children and bystanders away from the work area while operating the pump. DO NOT allow
children to handle the product.
Water transfers in cycles. DO NOT attempt to manipulate the switch to keep Pump running continuously.
It is meant to shut off intermittently. Doing so will damage the Pump.
IMPORTANT SAFETY INFORMATION

2
Check for damaged parts before each use. Carefully check that the product will operate properly and
perform its intended function. Replace damaged or worn parts immediately. Never operate the product
with a damaged part.
Circulation of caustic uids, as well as the circulation of abrasive materials, must be avoided at all costs.
For your safety, maintenance should be performed regularly by a qualied technician.
DO NOT pump hazardous materials. DO NOT pump explosive or ammable materials such as Fuel
Oil, Kerosene, Gasoline etc. Do not pump in close proximity to ammable or explosive materials. DO
NOT pump fats, oils, salt or waste water. This Pump is designed to move clean or dirty water. DO NOT
pump hot liquid.
WARNING: People with pacemakers should consult their physician(s) before use. Electromagnetic
elds in close proximity to heart pacemaker could cause pacemaker interference or pacemaker
failure.
WARNING: Handling the cord on this product will expose you to lead, a chemical known to the
State of California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling. (California Health & Safety Code § 25249.5, et seq.)
Note: Performance of this Pump (if powered by line voltage) may vary depending on variations in local
line voltage. Extension cord usage may also affect Pump performance.
IMPORTANT SAFETY INFORMATION
SAVE THESE WARNINGS

3
ADJUSTABLE
FLOAT TETHER
TETHER
ADJUSTMENT NOTCH
UNIVERSAL FITTING
Driving motor in AISI 316 stainless steel
Handle coated with insulating rubber
Double mechanical seal with oil chamber
interposed, carbon/aluminum on motor
Silicon carbide on pump side
Dry motor, asynchronous, watertight, cooled
by the pumped liquid itself
FEATURES
SPECIFICATIONS
Standard thermal protection in the winding
NOTE: DO NOT install the Pump by suspending it unsupported from its delivery pipe or power cord. The
Pump must be suspended from the handle or be placed on the bottom of the basin. To ensure that the
Pump works properly, keep the bottom free from sludge and dirt of all kinds.
NOTE: If the water level sinks too low, any sludge in the basin will dry out and stop the Pump from
starting. To help ensure the Pump will start as required, check the Pump regularly with start-up tests.
AREAS OF USE
1. This Pump is designed to pump water only.
2. This Pump is designed to be used for: • Removing ground water from basements and outdoor job
sites • Very high ow
3. This Pump should NOT be used for: • Continuous run, fountain/pond water features • Basement
sump applications • Septic or sewage systems • Potable water systems
4. This Pump can also be used to transfer water (e.g. household, farming, plumbing).
DIAGRAM AND SPECIFICATIONS

4
This Pump should be plugged into an outlet tted with a
Ground Fault Circuit Interrupter (GFCI).
1. Make sure the Pump rests on a at, level, and solid
foundation.
2. Keep the pump inlet openings, near the suction base, clear
of debris.
4. Avoid installation in areas of extreme heat or cold.
OPERATION
WARNING: DO NOT let the pump run dry. It will increase wear to the unit and possible cause steel
damage.
1. Verify that the Pump rests on the oor of the basin, if it is not suspended by the handle.
2. Verify that the discharge pipe is properly connected.
3. Verify that the electrical socket is GFCI protected and in good condition. Test GFCI protected outlet
before use.
3. Attach one end of a discharge hose to the discharge port.
Place the other end as needed to direct the water discharge at
least 3 feet away from the source. Slope the discharge hose
downward, away from the source.
WARNING: Do not use an extension cord with this Pump.
Keep plug dry and secured away from water.
4. Verify that water and moisture cannot get near the power supply socket.
MAINTENANCE
PUMP MOTOR MAINTENANCE
1. Any repair or replacement of parts should be performed by a qualied service technician.
2. Inlets should be inspected periodically and any debris which clogs them should be removed (Before
performing inlet cleaning, disconnect the pump from the outlet).
3. Periodically clean the Lower Base, remove the Screws from the Base and remove any dirt or debris.
Replace the Lower Base.
NOTE: Many problems occur due a clogged Lower Base. Remove the Screws from the Lower Base and
remove the Lower Base. Clean out dirt or debris from the bottom of the Pump and replace Lower Base
using the same screws.
INSTALLATION

TROUBLESHOOTING
5

PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER
THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR
SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER
AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS
OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
OF NOTE
PRODUCT MADE IN CHINA
