XU1 XACP-2115 User manual

0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
25 Fox Drive, Dandenong South, Victoria, Australia 3175
Telephone: [phone]
XU1 Power tools
XACP-2115 0821
Operating Instructions
XACP-2115
21L 1 .5HP21L 1 .5HP
Oiled AirOiled Air
CompressorCompressor

0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSURE GAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
A B
E F
C
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSURE GAUGE
kg/cm²
D
1. Air Filter
2. Motor
3. On/Off Switch
4. Carry Handle
5. Pressure Regulator
6. Regulated Pressure Outlet
7. Pressure Gauge
8. Support Foot
9. Drain Valve
10. Pressure Tank
11. Wheel
12. Tank Handle
13. Oil Drain Screw
14. Oil Sealing Plug
4
4
6
7
5
11
12
14
13
1 2 3
910 8

Power Supply: 230-240V ~ 50Hz
Motor: 1100W (1.5HP) S3 50%
Tank Capacity: 21L
No Load Speed: 2,850/min
Max. Pressure: 8bar (116psi)
Max. Flow Rate: 140L/min
Free Air Delivery: 70L/min
IP Rating: IP20
Weight: 22.5kg
SPECIFICATIONS
5
CONTROLS
Switching The Compressor On/O󰀨
1. To switch the compressor on, pull the on/off switch
to the ‘I’ position. Allow the motor to run and the tank
to ll up. FIG. C
Note: The compressor will automatically cut off when
the tank pressure reaches 8bar and will automatically
start up again when the tank pressure drops to 6bar.
2. To switch the compressor off, press the on/off switch
to the ‘0’ position.
Thermal Overload Protection
This Air Compressor is tted with thermal protection
and will shut off to protect the compressor from
overheating.
The compressor may also have shut off due to
reaching max. cut off pressure. If you are unsure, use
an attached blow gun to release some of the pressure
until the tank pressure gauge drops below 6bar. If the
motor does not automatically start up, the unit has
overloaded and the thermal protection has activated.
If the thermal protection activates, switch off the
compressor and allow the compressor to cool down
for 15 minutes. Before attempting to restart the air
compressor, check that the oil level is sufcient
and that the air lter is not blocked. Refer to the
Maintenance section to clean air lter or add oil if
needed.
WARNING! Allow the air compressor to
cool before attempting any maintenance.
WARNING! Do not continue use of
the unit if the thermal protection activates
again immediately after the reset.
WARNING! Before connecting the
compressor to the power source, check for
broken components and accessories. Also
check for damage to the hose. Do not
proceed if any component or part shows
sign of wear or damage. Replace the part
or take it to an authorised repairer.
PROPER USE
This tool is intended for use in a DIY (Do It Yourself)
context or for hobbyist purposes. It is not built for
continuous daily use in a trade or professional
capacity.
Before using the machine, carefully read these
instructions, especially the safety rules to help ensure
that your machine always operates properly.
Before attempting to operate the machine, familiarise
yourself with the controls and make sure you know
how to stop the machine quickly in an emergency.
Save these instructions and the other documents
supplied with this machine for future reference.
SETUP
Pre-Setup Checks
• Examine the machine for signs of transit damage.
If damaged, do not use, return to place of purchase
• The compressor should be set up near to the user.
• Avoid long air lines and long supply lines
(extensions).
• Make sure the intake air is dry and dust-free.
• Do not set up the compressor in damp or wet
rooms. The compressor is designed to be used in
dry rooms. It is prohibited to use the compressor in
areas where work is conducted with sprayed water.
• Before you use the machine, make sure that the
mains voltage complies with the specications on
the rating plate.
• The compressor may only be used in suitable
areas (with good ventilation and an ambient
temperature from 5°C to 40°C). There must be no
dust, acids, vapours, explosive or ammable gases
in the room.
• The oil level in the compressor pump has to
be checked before putting the equipment into
operation.
WARNING! Always keep the
compressor upright. Tipping the
compressor on its side may cause the oil
in the motor to leak out and damage the
unit.
Fitting The Air Filter
1. Attach the supplied air lter by screwing it in
clockwise. FIG. A
Attaching The Support Foot
1. Place the supporting foot and then a small washer
onto the small bolt. Thread this through the hole in
the foot bracket.
2. Thread the other small washer and then the spring
washer onto the bolt. Secure the assembly with the
small nut.
Attaching The Wheels
1. Place the large bolt through the wheel and a large
washer. Then slide this through the hole in the
wheel bracket. Place a large washer then a spring
washer onto the bolt and secure this with a large
nut.
2. Repeat step 1 to t the second wheel on the
opposite side of the tank.
Connecting The Air Hose
1. Pull back the sleeve on the regulated pressure
outlet of the compressor and insert the male Nitto
end of the air hose..
2. Release the sleeve; the Nitto coupling should click
into place.
3. Check that the tting is secure by tugging gently on
the connector. If the hose detaches, repeat steps
2 & 3, pushing the Nitto connector rmly into the
outlet.
WARNING! Ensure you have a rm grip
on the air hose when disconnecting it from
the air compressor, as pressurised air in
the tank may cause it to whip around and
inict injury or damage.
Fitting The Oil Sealing Plug
1. Remove the transportation cover from the oil ller
opening with a athead screwdriver.
2. Insert the oil sealing plug into the oil ller opening.
FIG. B
Checking The Oil Level
1. Place the compressor on a level surface.
2. Check that the oil level is between the the ‘MAX’
and ‘MIN’ marks on the oil level window.
3. If the oil level is below the ‘MIN’ mark, refer to the
Maintenance section - Changing The Oil and follow
the directions for relling the oil in the compressor.
WARNING! Ensure the tool is turned off
and disconnected from the power supply
before performing any of the following
operations.
WARNING! The air compressor must
be used with a residual current device with
a rated residual current of 30ma or less.
WARNING! Do not leave the air
compressor unattended while the on/off
switch is in the ‘on’ position.

OPERATION MAINTENANCE
Cleaning
1. We recommend that you clean the appliance
immediately after you use it.
2. Keep the safety devices free of dirt and dust as
much as possible. Wipe the equipment with a clean
cloth.
3. Clean the appliance regularly with a damp cloth
and some soft soap. Do not use cleaning agents
or solvents; these may be aggressive to the plastic
parts in the appliance. Ensure that no water can get
into the interior of the appliance.
4. You must disconnect the hose and any spraying
tools from the compressor before cleaning. Do not
clean the compressor with water, solvents or the
like.
Storage
Pull the mains plug out of the socket and ventilate the
appliance and all connected pneumatic tools. Switch
off the compressor and make sure that it is secured in
such a way that it cannot be started up again by any
unauthorised person.
Store the compressor only in a dry location which is
not accessible to unauthorised persons.
Supply Cords
If replacement of the supply cord is necessary, this has
to be done by a certied electrician in order to avoid a
safety hazard.
Note: XU1 will not be responsible for any damage
or injuries caused by the repair of the tool by an
unauthorised person or by mishandling of the tool.
6
WARNING! Ensure the tool is turned off
and disconnected from the power supply
before performing any of the following
operations.
Adjusting The Output Pressure
The output pressure of the regulated pressure outlet
can be adjusted to suit the air tool connected and the
task at hand.
1. To do so, rst decrease the pressure to 0psi by
turning the pressure regulator anti-clockwise.
2. Then turn the pressure regulator clockwise until
the desired pressure is shown on the regulated
pressure gauge. FIG. D
WARNING! Do not attempt to adjust/
modify the safety valve in any way.
The Safety valve installed on this air
compressor is designed to automatically
release pressure in case of excess
pressure build up in the tank.
Starting Up The Compressor
For best practice, the compressor should be run
without any load for 20 minutes before rst use to
lubricate the bearings and piston. This procedure
should also be performed if the compressor has been
stored for 6 months or more without operation.
1. Disconnect all air hoses from the outlets and open
the drain valve fully with a spanner to prevent
pressurised air buildup in the tank.
2. Make sure the power switch is in the off position.
Plug the power supply cord into a mains outlet.
3. Switch the compressor on and allow it to run for 20
minutes without any loads/tools attached and allow
any liquid to drain from the tank.
4. Turn off the compressor and close the drain valve.
The compressor is now ready for use.
5. Attach the desired tool to one end of an air hose and
the air hose to an outlet depending on the tool or
application.
6. Turn the compressor back on and adjust the
regulated pressure to the desired level once the
pump has shut off and the compressor has reached
cut-off pressure (8bar).
Shutting Down The Compressor
Do not turn the air compressor off by unplugging it
from the mains power as it may result in damage to
the motor.
1. Turn the compressor off with the on/off switch and
then unplug the cord.
2. Attach a blow gun to the compressor and use it to
discharge any remaining air in the compressor tank.
3. Rotate the pressure regulator anti-clockwise until it
is fully closed; check the regulated pressure gauge
to ensure that it reads 0psi.
4. Also turn on the air tool to discharge any remaining
pressurised air in the air hose.
5. Remove the air hose and any other connected
accessories.
WARNING! Release all air pressure
from the tank before opening the Drain
Valve. Take care when discharging air
through the drain Valve or air Outlets. The
discharged air can cause dust, stones,
or any other foreign particles to be blown
through the air at high pressure.
6. When no more air is released, open the drain valve
to release any accumulated liquid from the tank.
7. Close the drain valve, allow the compressor to cool
down, then clean and store the unit.

7
Draining The Pressure Tank
WARNING! Release all air pressure
from the tank before opening the Drain
Valve. Take care when discharging air
through the Safety Valve, Drain Valve
or air Outlets. The discharged air can
cause dust, stones, or any other foreign
particles to be blown through the air at
high pressure.
Air in the compressor tank causes water to
accumulate. This must be drained off frequently to
prevent corrosion and damage to the unit. This should
be performed after each use and prior to the next use.
1. Turn the drain valve plug anti-clockwise (when
viewed from the bottom of the tank) to open it. FIG.
E
2. Allow all of the water in the tank to drain out.
3. Replace the drain valve plug and turn it clockwise
to tighten it.
Note: The tank will not pressurise while the drain
valve is open.
Cleaning The Air Filters
The air lters prevent dust and dirt being drawn in. It is
essential to clean these lters at least after every 100
hours in service. Clogged air lters will decrease the
performance of the compressor dramatically.
1. Allow the compressor to run and build up
pressurised air in the tank. Once the motor has
stopped running, turn the compressor off and
disconnect it from the power supply.
2. With an air hose and blow gun connected to
the regulated pressure outlet, turn the pressure
regulator until the regulated pressure gauge shows
a pressure of around 3bar.
3. Undo the screw on the cover of the air lter unit and
lift off plastic cover.
4. Remove the lter sponge from the housing, tap it
and spray it with the blow gun to remove any dirt.
Re-insert it into the housing.
5. Re-attach the lid and replace the screw.
Changing The Oil
The oil should be relled for the rst time after 100
hours of operation. Thereafter, the oil should be
drained and relled after every 500 hours of service.
1. Release any accumulated air pressure from the tank
and ensure that it is disconnected from the power
supply.
2. Remove the oil drainage screw and use a vessel to
collect the oil from the unit as it drains out. FIG. F
Note: if the oil does not drain out completely, the
compressor may be tilted slightly to facilitate this.
3. Re-attach the oil drainage screw.
4. Remove the oil sealing plug and ll the pump with
oil up to the required level (approximately 200ml).
SAE 5W/40 oil or an alternative of the same quality
is recommended.
5. Replace the oil sealing plug.
6. Dispose of the old oil in a responsible manner by
taking it to an old oil drop off point. Check with your
local council for more information. DO NOT dispose
of old oil down the drain.
WARRANTY
YOUR WARRANTY FORM SHOULD BE RETAINED
BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST
RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE WITH YOUR BUNNINGS
REGISTER RECEIPT. PRIOR TO RETURNING YOUR
PRODUCT FOR WARRANTY. PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE
RELATING TO THE WARRANTY POLICY OR
PROCEDURE.
The benets provided under this warranty are in
addition to other rights and remedies which are
available to you at law.
Our goods come with guarantees that cannot be
excluded at law. You are entitled to a replacement or
refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are
also entitled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs
associated with a claim under this warranty, however,
where you have suffered any additional direct loss as a
result of a defective product you may be able to claim
such expenses by contacting our customer service
helpline above.
1 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 12 months
from the original date of purchase and is intended for
DIY (Do It Yourself) use only. If a product is defective
it will be replaced in accordance with the terms of this
warranty. Warranty excludes consumable parts, for
example: driver bits.
Ozito Industries Pty. Ltd.
25 Fox Drive, Dandenong South, Victoria, Australia
3175
WARNING
The following actions will result in the warranty being
void.
• Professional, Industrial or high frequency use.
• If the tool has been operated on a supply voltage
other than that specied on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any
way.

SAFETY
INSTRUCTIONS
1
ELECTRICAL
SAFETY
Description of symbols
CARING FOR THE
ENVIRONMENT
Power tools that are no longer usable
should not be disposed of with household
waste but in an environmentally friendly
way.
Please recycle where facilities exist.
Check with your local council authority for
recycling advice.
Check with your local council authority for recycling
advice.
Recycling packaging reduces the need
for landll and raw materials. Reuse of
recycled material decreases pollution in
the environment. Please recycle packaging
where facilities exist.
WARNING! When using mains-powered
tools, basic safety precautions, including the
following, should always be followed to reduce
risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you
know how to switch the tool off in an emergency,
before operating the tool.
This tool has been designed for 230V and
240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools
are interchangeable for Australia and New Zealand.
Using an Extension Lead
Always use an approved extension lead suitable
for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and
ageing. Replace the extension lead if damaged or
defective.
When using an extension lead on a reel, always
unwind the lead completely. Use of an extension
lead not suitable for the power input of the tool or
which is damaged or defective may result in a risk of
re and electric shock.
The power supply for this product should be
protected by a residual current device (rated at
30mA or less). A residual current device reduces the
risk of electric shock.
Read instruction manual
Warning
Regulatory Compliance Mark (RCM)
Wear hearing protection
Beware of electrical voltage
Beware of hot parts
Warning! The equipment is remote
controlled and may start up without
warning
Do not open the outlet before the air
hose is attached
Sound power level
V Volts
/min Revolutions per minute
n0No load speed
Hz Herts
~ Alternating Current
L Litres
bar Pressure rating
IP20 No protection against ingress from
water
W Watts

2
GENERAL
POWER TOOL
SAFETY
WARNINGS
equipment such as dust mask, gloves, non-skid
safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal
injuries.
c. Prevent unintentional starting.
Ensure the switch is in the o󰀨-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying power
tools with your nger on the switch or energising
power tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e. Do not overreach. Keep proper
footing and balance at all times.
This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from
frequent use of tools allow you to
become complacent and ignore tool
safety principles. A careless action can
cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will do the
job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the
switch does not turn it on and o󰀨. Any
power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c. Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of starting the
power tool accidentally.
d. Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are dangerous
in the hands of untrained users.
e. Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier
to control.
g. Use the power tool, accessories
and tool bits etc. in accordance
with these instructions, taking into
account the working conditions and
the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
WARNING! Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and
instructions for future reference.
The term “power tool” in all of the warnings
refers to your mains-operated (corded)
power tool or battery-operated (cordless)
power tool.
WARNING! Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate power tools in
explosive atmospheres, such as in
the presence of ammable liquids,
gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c. Do not expose power tools to rain or
wet conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
3. Personal safety
a. Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the inuence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result in serious
personal injury.
b.Use personal protective equipment.
Always wear eye protection. Protective
h. Keep handles and grasping surfaces
dry, clean and free from oil and
grease. Slippery handles and grasping
surfaces do not allow for safe handling and
control of the tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger
specied by the manufacturer. A
charger that is suitable for one type of battery
pack may create a risk of re when used with
another battery pack.
b) Use power tools only with
specically designated battery
packs. Use of any other battery packs may
create a risk of injury and re.
c) When battery pack is not in use, keep
it away from other metal objects,
like paper clips, coins, keys, nails,
screws or other small metal objects,
that can make a connection from one
terminal to another. Shorting the battery
terminals together may cause burns or a re.
d) Under abusive conditions, liquid may
be ejected from the battery; avoid
contact. If contact accidentally occurs, ush
with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that
is damaged or modied. Damaged or
modied batteries may exhibit unpredictable
behaviour resulting in re, explosion or risk of
injury.
f) Do not expose a battery pack or tool
to re or excessive temperature.
Exposure to re or temperature above 130 °C
may cause explosion.
g) Follow all charging instructions and
do not charge the battery pack or
tool outside the temperature range
specied in the instructions. Charging
improperly or at temperatures outside the
specied range may damage the battery and
increase the risk of re.
6) Service
a) Have your power tool serviced by a
qualied repair person using only
identical replacement parts. This
will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery
packs. Service of battery packs should only
be performed by the manufacturer or authorized
service provider.

WARNING! The appliance is not
to be used by persons (including
children) with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they have been given supervision or
instruction.
Young children should be supervised
to ensure that they do not play with the
appliance.
The appliance may not be suitable for use in
environments having a warm damp equable climate.
If the compressor repeatedly shuts off due to thermal
overload protection, stop using the compressor and
wait until the environment has sufciently cooled before
resuming use.
• Always remove the plug from the mains socket before
making any adjustments or performing maintenance.
• Avoid using an extension cord with this product. Use
additional air hose instead of an extension cord to prevent
power loss and possible damage to the motor. Use of an
extension cord voids the warranty.
• To reduce the risk of re or explosion, never spray
ammable liquids in a conned area. If sparks come into
contact with petrol vapours or solvents, they may ignite
the vapours and cause a re or explosion.
• Always operate the compressor in a well ventilated
area. Do not smoke while spraying. Do not spray where
sparks or ames are present. Keep the compressor as far
away from the spray area as possible.
• The solvents trichloroethane and methylene chloride
can chemically react with the aluminium used in some
paint spray guns and form an explosion. If these solvents
are used, ensure that only stainless steel spray equipment
is connected. The compressor is not affected by the use
of these solvents.
• Never directly inhale the compressed air produced by
a compressor and do not use it for charging breathing
tanks.
• Do not use welding equipment in close proximity to the
compressor. Do not weld anything to the air tank of the
compressor: this could dangerously weaken the tank and
will void the warranty.
• Do not use the compressor outdoors when it is raining
or on a wet surface; either situation could cause an
electric shock.
• Always maintain a safety distance of at least 3 meters
between the compressor and the work area, Ensure that
the compressor is on a stable surface.
• Always use the handle to move the compressor.
• Never let the compressor come into contact with water
or other liquids, as the appliance is live, this could cause
electrocution or short-circuits. Never use the appliance
with bare feet, wet hands or wet feet.
• Never pull on the power cable to disconnect the plug
from the power outlet or to move the compressor.
• The compressed air produced by the compressor
cannot not be used for pharmaceutical, food or medical
purposes or to ll the air bottles of scuba divers.
• Do not cover the air inlets on the compressor.
• Compressors and lines reach high temperatures during
operation. Avoid contact! Risk of burns!
• Gases or vapours drawn in by the compressor have
to be kept free of constituents that may cause re or
explosions inside the compressor.
ADDITIONAL
SAFETY
WARNINGS
FOR AIR
COMPRESSORS
• Do not attempt to adjust/modify the safety valve in any
way. The safety valve installed on this air compressor
is designed to automatically release pressure in case of
excess pressure build up in the tank.
• Drain the moisture from the tank after use. It will help
prevent corrosion.
• When you disconnect the hose coupling, hold the
coupling element in your hand to prevent injury from the
whiplashing hose.
• Never point the blow-out gun at other persons and
never use it to clean clothes that are still being worn.
• Be certain to read all the labels on the containers of
paint or other materials to be sprayed. Closely follow all
safety instructions. Use a respirator mask if there is a
chance that you might otherwise inhale the spray material.
Carefully check the effectiveness of any respirator mask
you intend using.
• Always wear safety goggles or glasses when using the
air compressor. Never point the nozzle of an accessory
towards any part of your body or towards another person.
• Keep the compressor at least 300mm from the nearest
wall to ensure adequate ventilation for cooling purposes.
Protect the air hose and cordset from damage.
Inspect for weak or worn spots regularly and replace if
necessary.
Always switch off the compressor before switching off
the power or removing the power plug.
After using the compressor, switch off the on/off button,
disconnect the power supply and use a blow gun or
similar to release the remaining pressure in the tank.
Do not attempt to remove any part of the machine
whilst it is under pressure.
Always shut off the compressor after use and before
servicing. Push the on/off knob down, wait for the
pressurised air to bleed from the tank from the safety
valve and then remove the electrical plug from the
power supply.
Check the maximum pressure rating of any tools or
accessories that you intend using with the compressor.
The output pressure of the air from the compressor
must be regulated so that it never exceeds the rated
pressure of the tool or accessory.
To avoid the risk of burns and injury from moving parts,
do not operate the compressor with the safety shield
removed. Allow hot parts to cool before handling or
servicing.
Wear goggles, wear earmuffs, wear a breathing mask.
Use safety equipment including safety goggles or
shield, ear protection, breathing or respirator mask and
protective clothing.
Never apply the outlet air of this compressor directly on
to any part of a person’s body. Do not attempt to block
the air outlet with your nger or any part of your body.
The tool must be used only for its prescribed purpose.
Any use other than those mentioned in this Manual will
be considered a case of misuse. The user and not the
manufacturer shall be liable for any damage or injury
resulting from such cases of misuse.
The manufacturer shall not be liable for any changes
made to the tool nor for any damage resulting from
such changes.
Even when the tool is used as prescribed it is not
possible to eliminate all residual risk factors. The
following hazards may arise in connection with the
tool’s construction and design:
Damage to the lungs if an effective breathing mask is
not worn.
Damage to hearing if effective earmuffs are not worn.
Damage to the eyes if effective safety goggles or shield
are not worn.
WARNING! In the event that an air line is cut
or broken, the air supply must be turned off at the
compressor. A broken air line which is not supported
is extremely dangerous and can whip around very
quickly, both with the capability of striking people, and
3
blowing foreign particles into the air. Do not attempt to
catch the air line but immediately keep bystanders well
clear and turn off the air supply to the hose, turn off the
compressor at the On / Off button, and then remove
the hose from the compressor.
