Yaber YR800 User manual
Language
01-08
09-16
17-24
25-32
33-40
41-48
English
Deutsch
Français
Italiano
Español
日本語
Package Content
1 x Jump Starter 1 x Smart Jumper clamps
1 x Type C Cable
1 x Storage Case1x EC5 Cigarette LighterAdapter
1 x User Manual
Car Battery Jump Starter
ENEN 01
Introduction
Key Features
Thank you for purchasing YABER YR800 car jump starter. Please
read the user manual carefully before you start to use the product.
★A Powerful Jump Starter: Car Jump Starter with 2500 amps peak
current can jump starts 12V cars, SUV, truck or van (all gasoline and
8L diesel) in seconds up to 30 times.
★To encure the faster charging efficiency, this external battery
charger is equipped with two USB Output including USB1 (QC3.0 5V
3A / 9V 2A / 12V 1.5A),USB2 (5V 2.4A) and 5V 2AType C input.
★Safety Protection: Premium cells, circuitry and safety features
protect you and your device from surge or short circuits.
★LED Lights & LCD Screen：LED light that has 3 mode: flashlight/
strobe/ SOS, that could use as emergency tool, extra red warning light
can remind the passing cars if there is an accident. The LCD screen
can exactly show the remaining power and output voltage.
★Convenient wireless charging：If you forget bring a charging
cable,this jump starter is your best choice.10W quickly wireless
charger or power bank on the go.
★Car saftey hammer: The jump starter with hardened sharp Stainless
Steel Points can shatter vehicle windows in an emergency.
EN 02
Know Your Product
① Jump starting port
② Flashlight
③QC 3.0 USB output
④ 5V/2.4A USB output
⑤ Type C input
⑥LCD display
⑦ Power swtich
⑧ Wireless charger
⑨ Compass
⑩ Saftey hammer
①Red jumper cable (+)
②Black jumper cable (-)
③ "Smart Clamp" plug
Powerful circuit protection system - Smart Clamps
①
②
③
①
② ③ ④ ⑤
⑧ ⑦ ⑥⑨⑩
EN 03
Getting Started
Charging your Jump Starter
1. Please use a 5V2A/9V2A/12V1.5A
adapter to charge the product.(Type C
cable is included, adapter is not
included)
2. Using a 5V/2A adaptor, it will take
approximately 5-6 hours to fully
charge the unit. In order to extend the
battery life it is recommended to fully
charge the unit every 3-6 months.
Turn On your Jump Starter
Short press the power switch to boot the jump starter, the display will be
turned on. For energy saving, the jump starter will be turned to standby
mode if there is no operation within 20 seconds.
LED Light
Turn on the jump starter. Long press the power switch more than 3
seconds to turn on the flashlight mode. There are four modes including
illumination, SOS and Strobe, warning light. Short press the power switch
button to change the 3modes(illumination, SOS and Strobe) or turn off the
flashlightmode. Double pressthe power switch buttonto enter thewarning
light mode or turn off the warning light mode.
QC3.0 & 5V 2.4A Dual USB Output
This portable jump starter is also equipped with two smart USB outputs
that provide the fastest charging speed(USB1 - QC3.0: 5V 3A/ 9V 2A/12V
1.5A; USB2 - 5V 2.4A) for your portable electronic devices, such as
phones,tablets, bluetooth earphones, etc
（adapter is not included）
EN 04
Start your Car
1. Please make sure that battery level is above
50% before you use it to jump start your car.
2.Insert the plugof the smart clip completely into
the jump starter, the green and red lights flash
alternately.
3. Correctly clip the red and black clamps to the
electrodes of the car battery (red to positive and
black to negative)(The green light stays on)
4. Start the vehicle.
5. When the vehicle is started, remove the
jumper cable from the vehicle battery immedi-
ately.
In any of the following situations, the smart clamp turns on protection
mode:
LED Indicator
The red/green led will flash
The green light is always on
Situations
Ready to work
Work status
EN 05
The red light is always on
The red light flashes slowly
The red LED flashes quickly
The green light flashes slowly
1.battery clamp is reversely connected
--- check whether the clip is reversely
connected
2.The clamp is short-circuited
---check whether two clamps together
connect or connect both cable clamps to the
same piece of metal
Back change protection, the voltage of the
car battery is higher than 12.6V
-No jump starter needed, the car battery is
enough to star your car
The temperature of the clamp exceeds
65(+/-5)degrees
--- remove the clamp untill the red green led
flash
The vollage of the starter is too low
--try to replace the startup power supply or
change it in time
Cautions
1. Use the original smart clip to start the car.
2. DO NOT use this unit if any cable clamp or cord is damaged.
3. Start only for 12V vehicles,or it will cause serous damages to the unit.
4. Do not jump start your car when the battery capacity is lower than 50%.
5. Do not connect two clamps together when the starter is powered on.And
do not connect both cable clamps to the same piece of metal.
6. If the engine does not start on the first try, disconnect it from the car
battery and wait for at least 20 seconds before reconnecting. Maximize
three attempts in two minutes.
7. Once the engine is successfully started, disconnect the clamps within 30
seconds.
EN 06
FAQ & Trouble Shooting
Q: How to turn off this power pack?
A: This power pack will power off automatically when no load or charging
is complete.
Q: What kind of adapter should I use?
A: You can use the adapter of your phone or tablet..
Q: How long time to full charge the YABER YR800 jump starter?
A:About 5-6 hours through the 5V2AAC adapter.
Q: How many times can this product start the vehicle with full capacity?
A: Up to 30 times.
Model
USB 1 OUTPUT
USB2 Output
Type-C Input
Short circuit protection
Over-discharge protection
Over-temperature Protection
Reverse polarity protection
Reverse charging protection
wireless charge
Dimension
YR800
QC3.0 5V 3A / 9V2A/12V1.5A
5V 2.4A
5V 2A
√
≦13v ± 0.3v
＞65 ℃± 5 ℃
√
≧(12.6v ± 0.3v)
10w
180*93*43mm
Care and Maintenance
1. DO NOT put the product under direct sunlight or hot areas.
2. DO NOT drop or knock your car jump starter.
3. DO NOT disassemble the equipment, it may cause damage.
EN 07
Warranty
Our company provides customers with warranty of 24 months from the
date of purchase.
Contact US
For additional assistance or warranty cover claim, please contact us:
E-Mail: support@yaberauto.com
4. DO NOT use chemicals or detergents to clean the product.
5. DO NOT place the products in high temperature environment for long.
The operating temperature: -20~60℃.
6. Check the power of the product at least every three months, and charge
the product in time.
EN 08
