Yale AC-101W User manual

Outdoor bullet camera with IR
night vision
The AC-101W is a colour CMOS Camera
that can be operated in almost all lighting
conditions, from bright daylight (provided the
camera is not directly pointed at the sun) to
complete darkness
In complete or near-total darkness the AC-
101W uses built in infrared LED’s to illuminate
the area covered up to a total 20 meters away.
The Infrared light is invisible to the human eye,
although you may notice a faint red glow which
is normal.
The AC-101W is extremely sensitive to
lighting conditions. You can make the most of
majority of light conditions. Colour image in the
day and Black & White in low light conditions.
Display extreme caution when using ladders or
steps. Please follow manufactures instructions.
Be careful when using hand & power tools
and follow the manufactures guidelines when
using them. Take care that the correct tools
are used. Wear goggles or protective clothing
where required.
In the event you feel unsure about the
installation please consult your local qualified
electrician.
Description
• Colour camera lens. Automatically switch to
Black & White mode in the dark.
• Infra-red LED for night vision
• Use supplied hex key to adjust camera angle
• Video output (BNC male connector)
• Power input (12V 500mA)
Pack contents
• 1 x Outdoor bullet Camera.
• 1 x Screw pack & hex key.
• 1 x 15m BNC/DC extension cable
• 1 x 12V 500mA Power adaptor
Information and illustrations are subject to
change within this document.
Yale reserves the right to alter the specification
and product design at anytime without notice.
Yale is a registered trademark.
2014 ASSA ABLOY. All rights reserved
Easy Fit CCTV System
LED for night vision
Camera lens
Hex screw
Power
Video
(AC-101W)

Connecting your camera
Connecting to your DVR
Connecting to your TV
15m
BNC/DC cable
DVR
Adaptor
*Do not switch on the socket
until everything is connected.
15m
BNC/DC cable
Adaptor
BNC male to
RCA male
adaptor
*not supplied
TV
*Do not switch on the socket
until everything is connected.

Mounting the camera
The Stand on the AC-101W is
adjustable. There are three adjustable
sections.
1) Rotate the camera by loosening the
hex screw (using the supplied hex key).
Once in position tighten the screw again
to secure in place.
2) Adjust the elbow joint by loosening
the hex screw. Once in position tighten
the screw again to secure in place.
3) Where the neck of the stand attached
to the mounting base, rotate the stand
by loosening the radial joint locking ring.
Once in position tighten the ring again
to secure in place.
To mount, use the supplied screws and
tighten the mounting plate against a flat
surface.
Troubleshooting
Video Loss
Video Loss appears where the camera
image should be displaying on my
Recorder
Check the Extension cable (power &
video) is connected to the camera
Check the video output from the
camera is securely connected to a video
input channel on the DVR
Check the power from the camera is
connected to the power adapter and
connected to a power supply and
switched on
Bright Spots at Night
When I view an image from the camera
at night I can only see a bright spot with
no image
This can be caused by a reflection from
the cameras built in infra-red LED’s
looking through a window. Re-position
the camera to the other side of the
window or to a different location
Can’t connect to my TV
The BNC extension cable will not
connect to my TV
Majority of TV’s do not have a BNC
connection. You will need to purchase
a BNC to RCA adapter (not included).
This will allow the camera to be
connected to a RCA input (Yellow
Socket) on the TV.
Technical Support
Email: [email protected]
Telephone: [phone]
Fax: [phone]
Write to: Yale UK, School Street,
Willenhall, West Midlands WV13 3PW
1 2
3

Specification
Video
Image Sensor: Super CMOS
Video Quality: 650TVL
Minimum Illumination: 0 Lux (IR on)
Day/Night Mode: Colour in lit up areas /
Black & White in dark (IR on)
Lens : Fixed 3.6mm
Viewing Angle: 60 Degrees
Night Vision
Night Vision distance: 20 Meters
IR Cut Filter: Yes for enhanced night
vision
Infra-red LED’s: 24
General
Indoor/Outdoor use: Yes Both
Operating power: DC 12V 500mA
IP Rating: IP55
Dimensions: 45mm(W)x120mm(L)
x45mm(H)
2 Year Instruction Statement:
This product is guaranteed for consumers
against faulty workmanship, materials and
function for a period of 2 years from the date
of purchase providing the full installation and
maintenance instructions are followed. Please
keep your proof of purchase safe, this must
be submitted when making a claim under this
guarantee.
Please note that it is a condition of this
guarantee that your Yale product:
• Has been correctly installed and
maintained in accordance with the
Yale installation and
maintenance instructions provided to
you at the time of purchase.
• Has not been modified or damaged in
any way.
• Has not been subjected to
unauthorized repairs.
Yale are responsible under this guarantee for
repairing the product or replacing the product
as we deem necessary. If there is fault with the
product, please contact Customer Services on
01902 364606, who will give you the name of
an expert and confirm what you need to do to
make a claim under this guarantee.
Please do not carry out any repairs without
our authority or by using an unauthorised
expert. Any repairs or other works carried
out without our authorization or by using an
unauthorized expert will not be covered under
this guarantee.
This guarantee is non transferrable and
applies to products purchased in the United
Kingdom only. This guarantee does not apply
to normal wear and tear. This does not affect
your statutory rights. A full copy of the product
instructions are available upon request or by
visiting our website www.yale.co.uk.
