YAMADA KGK-400 Series User manual

Doc. No. 100-487YO-01
METERING VALVE
MODEL. KGK-400 series
WARNING
Prior to operating this pump, be sure to read this operation manual for safety. After reading the manual, please keep it at
hand any time for your quick reference.
INSTRUCTION

1
[Introduction]
This instruction manual contains important safety information and operational instructions.
Read this manual before installation, operation, maintenance, and repair.
Do not use the product without reading this manual. Thoroughly read and understand all of the product information,
safety information, and warning information in the manual.
If you have any questions, please contact the store you purchased the product or our business office.
[For Safe Operation]
According to the hazard level, all safety notes in this manual are classified into “DANGER”, “WARNING”, and
“CAUTION”.
Be sure to read and observe the safety notes to ensure safety and correct use of this product.
indicates a potentially hazardous situation which, if not avoided, WILL result in
death or serious injury.
indicates a potentially hazardous situation which, if not avoided, COULD result in
death or serious injury.
indicates a potentially hazardous situation which, if not avoided, could result in
injury or property damage.
－ Table of Contents －
[Introduction]........................................................................................... 1
[For Safe Operation]................................................................................. 1
1. Precautions on Use ............................................................................. 2
2. Product Description ............................................................................ 3
3. Principle of Operation......................................................................... 4
4. Installation and Connection ................................................................ 5
5. Troubleshooting .................................................................................. 7
6. Disassembly and Assembly.................................................................. 9
7. Product and Part List for Grease Metering Valve ...............................12
8. Product and Part List for Grease Metering Valve with Sensor..............18
9. Product and Part List for Adhesive Metering Valve..............................25
10. Limited Warranty ...............................................................................29
WARNING
DANGER
CAUTION

2
1. Precautions on Use
The following warnings and cautions are very important. Be sure to observe them.
[Operating condition]
[Installation and piping]
[Operating method]
[Disassembly, maintenance and inspection]
CAUTION
- For your safety, read and understand all information provided in this manual.
If you have lost or damaged your instruction manual, please contact us or our distributor to place an
order.
- Never let anyone operate this unit without understanding this manual.
CAUTION
- Before maintenance operation, be sure to stop air, and release the internal pressure (both air and
material) of the product.
- Immediately stop using the product if there is any danger or defect. Be sure to eliminate the cause and
confirm safety before restarting.
- Follow the safety instructions for installation and be sure to use appropriate piping material and size to
avoid leakage and damage.
WARNING
- Understand this manual completely before operating the machine.
Operators and maintenance personnel are required to read this manual thoroughly before operating or
servicing. Do not handle this machine without understanding the instructions.
- Do not handle unspecified material with this product. It may cause a product failure.
- Do not use this product for improper purposes.
WARNING
- Shut off air supply to the product and remove residual pressure completely BEFORE disassembling.
- Alternating the unit may result in personal injury or product malfunction. Please do not try to alter,
modify, or change the machine.

3
[Shutdown and storage]
2. Product Description
KGK metering valves are able to apply metered shots of media such as greases and adhesives. By replacing a built-in
metering cylinder, KGK metering valves cover metered shot volumes between 0.5mL to 50mL.
CAUTION
- When leaving the product unused for a long time (more than a week) or shutting it down;
- remove material inside completely and wash the product and
- release material supply pressure.
CAUTION
- In grease metering valves, NBR and urethane rubber are used in seal parts. Do not try to handle any
material incompatible with these parts. If need arises, use adhesive metering valves which use seal parts
made with fluorine resin.
- Release residual pressure inside the valve BEFORE maintenance, inspection, and repair.
Air Inlet
（Rc1/4）
Material Outlet
（Rc1/4）
Material Inlet
（Rc1/4）
定量シリンダ
定量弁本体
Metering Valve
Bod
y
Metering Cylinder

4
Material delivered to the supply channel lifts up the valve
with its pressure and presses it against the seat on the
discharge side. While the valve is blocking material flow to
the discharge port, Chamber A (metering chamber) becomes
filled with material.
At the same time, material, under pressure from a supply
pump, is constantly being delivered to Chamber B (pressing
chamber) at the back of the metering piston through a bypass
groove around the valve.
At this time, when the same pressure is applied over both
Chamber A and B, the force acting on Chamber A is stronger
due to a difference of pressure receiving area.
Thus, the metering piston is pushed to Chamber B and
comes to a stop against the head of adjustment screw.
When the air piston is pushed down by supplied air, the
material inlet is closed and the material outlet opens. Then,
material pressure in Chamber A decreases with material flow
from the chamber. At the same time, regardless of valve
condition, material, under pressure from a supply pump, is
constantly supplied to Chamber B through the bypass
groove. Accordingly, the metering piston starts moving
forward and material in the metering chamber is discharged.
The metering piston pushes out all material inside the
metering chamber and comes to a stop against the end wall.
Discharge is now complete. Even when valve is open toward
the discharge side, material other than a metered shot will
not flow out.
After supplied air is discharged, the valve is lifted up by
material pressure and again pushed against the seat on the
discharge side to close the material outlet. Material flows into
the metering chamber as pushing the piston back. Residual
material in Chamber B flows back through the bypass groove
to Chamber A, being mixed together with newly delivered
material.
3. Principle of Operation
3-1Standby 3-2Discharge
3-3Completion 3-4Recharge
バルブ
定量室（A室）
押出し室（B室） 定量ピストン
液入口
バルブ
定量ピストン
エアピストン
液入口
液吐出
開 始
操作空気
バルブ
定量ピストン
液入口
吐出完了
操作空気
バルブ
定量室（Ａ室）
定量ピストン
排気
液入口
Metering Piston
Val ve
Material Inlet Material Inlet
Val ve
Air Inlet
Air Piston
Metering Piston
Material Inlet
Val ve
Metering Piston
Exhaust
Material Inlet
Val ve
Metering Piston
Air Inlet
Discharge end
Discharge start
Metering Chamber
(Chamber A)
Metering Chamber
(Chamber A)
Pressing Chamber
(Chamber B)

5
4. Installation and Connection
4-1 Selection of metering valve
Select an appropriate metering valve by referring “Cylinder
Size” in the table. The size of a cylinder should be closest to
your desirable amount of a shot. If you want to have 0.3mL
and 2mL shots using the same metering valve, provide a
1mL cylinder for 0.3mL shots and a 3mL cylinder for 2mL
shots. Replace a cylinder depending on the amount you want
to dispense.
Especially where an accurate shot is required, it is not
recommended to use a large cylinder for a small amount of shot.
* A metering error varies among materials. Usually, it is between plus or minus 1.5 - 2%.
4-2 Installation
Install your metering valve as close as possible to the equipment or its inlet port you are going to work on. The
longer the connection is, the more the discharge amount from the outlet varies.
4-3 Connection
①Material Inlet
Connect the material inlet (Rc1/4) of your metering valve
and a material supply pump with a pipe or hose.
CAUTION: Material supply pressure to the metering
valve depends on viscosity of material.
The working pressure of KGK metering
valves ranges from 2MPa to 20MPa. Set
the lowest air pressure at which your
metering valve works properly.
②Material Outlet
Connect a metal pipe such as copper or steel between the
outlet (Rc1/4) of the metering valve and dispensing
equipment such as a nozzle. In this time, keep the pipe
as short as possible.
CAUTION: Avoid using a soft material like a nylon
tube for connection. Metered shots will
be variable in amount. In case that you
have to use a flexible tube or pipe,
attach an automatic valve to the pipe
(tube) end to obtain accurate shots
equal to a metal pipe.
* When connecting the outlet of your valve to multiple nozzles, install 686441 Restrictor respectively close to
each nozzle. Adjust the restrictors to make each of metered shots equal amount.
* When applying a metered shot at a constant length, attach 686442 Automatic Valve (sold separately) or
686437 Automatic Flow Gun (sold separately) to a material outlet.
Cylinder Size
(mL)
Setting Range
(mL)
0.5 0.05-0.5
1 0.2-1
3 0.3-3
5 2-5
10 4-10
20 8-20
50 15-50
②Metered Shot
③Air Connection
①Material Connection

6
③Air Inlet
Connect an appropriate air valve such as 3 port solenoid valve or mechanical valve.
CAUTION: Air should be supplied through an air filter, lubricator, and air regulator. Set the air pressure
between 0.4MPa to 0.5MPa.
WARNING: Do not set the air pressure over 0.7MPa.
4-4 Precaution for initial use
When you use the metering valve for the first time including the first use after repair, be sure to completely
remove trapped air from a material supply pump, hose, pipe, and metering valve.
Disconnect a pipe attached on the material outlet and run the metering valve to remove trapped air. Repeat
this procedure until all air is removed completely. Confirm that the valve is securely closed BEFORE
reconnecting a pipe to the outlet.
PRECAUTION FOR USE
- Be sure to shut off the air supply to a supply pump and set the material pressure (primary pressure) to
zero. Leaving a metering valve under pressure will be a cause of material leak or some other problem.
- Once a metered shot is dispensed, be sure to put the valve back to the standby condition.
- Avoid inclusion of air in material as much as possible.
Trapped air in material will be compressed through a pump, pipe, hose, and metering valve and expand
when material is dispensed. As a result, the metering valve will have difficulty stopping discharge and
thus it may seem to be leaking. Also, each shot will be variable in amount.
Furthermore, material will gush out of the outlet and splatter around.
Be sure to release air completely when using the product for the first time or after replacing a metering
cylinder.
- Do not use material which contains dirt and dust. Seal parts will be damaged, causing a material leak.
- In such problems that material continuously flows out from the outlet or a shot is variable in amount, it is
necessary to figure out whether a defect is caused by malfunction of the valve or some other equipment.
Carry out an operation test on your valve independently and investigate the condition of the material
outlet.
- Due to long term use, material which couldn’t be stripped off by a seal builds up little by little. This is not
always abrasion of a seal part. It is important to wipe off seal parts after use or periodically to extend the
life of these parts.

7
5. Troubleshooting
5-1 Troubleshooting (metered shot)
<Problem>
- Air leak occurs.
- Material leak occurs in air cylinder.
- Material still flows out after a
metered shot has been dispensed.
<Possible Cause>
①O ring is damaged or worn out.
②O ring is damaged or worn out or cylinder
inside is damaged.
③Packing is damaged or worn out.
④Piston rod is damaged.
⑤Sleeve inside or valve is damaged
⑥O ring is damaged or worn out.
⑦O ring is damaged or worn out or cylinder
inside is damaged.
⑧Valve or valve seat is not closed completed.
(Thin part of piston rod is deformed and rod
length has become shorter.)
CAUTION
- The life of a U-packing is reduced if the sleeve inside is severely damaged or clearance between the piston
and rod has become too much. At the time of replacing the U-packing, be sure to check the sleeve and
piston as well.
<Solution>
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.

8
5-2 Troubleshooting (return or waiting)
<Problem>
- Material leak occurs in outlet port.
- Material leaks out.
- Material in outlet doesn’t flow back after
metering valve is closed.
<Possible Cause>
⑨Piston rod is loose and pushes valve.
⑩Seat or valve is damaged or worn out.
⑪O ring is damaged or worn out.
⑫Joint of valve and sleeve is loose.
⑬O ring is damaged or worn out.
⑭Plug is loose.
⑮O ring is damaged or worn out.
⑯Packing is damaged or worn out.
⑰Piston is damaged or worn out.
CAUTION
- The life of a U-packing is reduced if the sleeve inside is severely damaged or clearance between the piston
and rod has become too much. At the time of replacing the U-packing, be sure to check the sleeve and
piston as well.
- When setting a shot volume, turn the adjustment screw with the outlet valve open. Once the exact value
has been set, secure the screw with a locknut.
<Solution>
- Apply adhesive to threaded part and
secure piton rod.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
- Secure plug tightly.
- Replace with a new one.
- Replace with a new one.
- Replace with a new one.
Stop

9
6. Disassembly and Assembly
PRECAUTION FOR USE
- Please contact the store you purchased the product or our business office if a metering error has
happened soon even though it didn’t occur at the beginning of use.
- When handling silicone grease, be sure to select a designated valve for silicone grease. If a grease or
adhesive metering valve is used, seizure of a valve and sleeve will occur, resulting in malfunction of a
metering valve.
CAUTION
If material flows out continuously even after a metered shot has been dispensed, it may be caused by
conditions of inlet or outlet lines or a procedure taken to restart operation after repair. Please follow the
following recovery procedures.
- When using a metering valve for the first time including after repair, run the valve without connecting
dispensing equipment, coupling, hose, or any other accessories to a material outlet. Keep running the
valve until all trapped air inside a material supply pump, hose, pipe, and metering valve is expelled
completely. Make sure that the valve is closed before making connection to the outlet.
- When material continuously flows out from dispensing equipment or an outlet of a secondary pipe, the
outlet of the metering valve doesn’t generally have a defect. In most of these cases, it is caused when a
pipe line is too long or short or when material of a pipe is flexible. To solve this problem, repeat
“Discharge” and “Standby” until continuous flow stops.
CAUTION
- Release residual pressure completely BEFORE disassembling metering valves.
- Wash the parts with wash oil and apply a thin layer of lithium grease BEFORE reassembling.
Be extremely careful not to let dust and dirt attach to any of the parts.

10
702K161 キャップ
640K046 Oリング
702K714 ピストン
702K715
ピストンロッド
702K716
リテーナ
680K139
Uパッキン
702K931
ボディ
634K360
プラグ
702K932 ベースプレート
615K067
六角穴付ボルト M6×10
631K282 ワッシャー
701K351
バルブシート
701K351
バルブシート
643K015
Oリング
643K015
Oリング
701K350
バルブスリーブ
680K087
バルブ
640K018
Oリング
702K166
プラグ
640K123
Oリング
ピストン組立
770K226
スリーブ
①②
②
③
④
⑤
⑦
⑥
⑧
6-1 Disassembly of metering valve
①Unscrew 702K161 Cap to remove it. Remove 640K123
O Ring.
②Pull out Piston Assembly. Remove 640K046 O Ring.
Unscrew 702K715 Piston Rod to separate from
702K714 Piston.
At the time of reassembly, apply adhesive to the
threaded part of Piston Rod and secure tightly.
③Unscrew 702K716 Retainer to remove it and pull out
770K226 Sleeve.
④Remove 680K139 U Packing.
⑤Remove four 615K067 Bolts and 631K282 Washers.
Separate 702K932 Base Plate from Body. Unscrew
634K360 Plug to remove it.
⑥Unscrew 702K166 Plug to remove it from 702K931
Body. Remove 640K018 O Ring from Plug.
⑦Insert a brass bar (φ10) from the top of 702K931 Body to
push out two 701K351 Valve Seat, two 701K350 O
Rings, and 701K350 Valve Sleeve.
⑧Push 680K087 Valve to remove it from Valve Sleeve.
702K161 Cap
640K046 O Ring
702K714 Piston
640
K
12
3
O Ring
702
K
715
Piston Rod
770
K
22
6
Sleeve
Piston Assembly
631
K
282 Washer
702
K
71
6
Retainer
702K932 Base Plate
640K015
O Ring
680
K
139
U-Packing
701
K
351
Valve Seat
701
K
351
Valve Seat
640
K
01
8
O Ring
680
K
087
Valve
Valve Sleev
e
61
5
K
067
Bolt
634
K
360
Plug
702
K
16
6
Plug
702
K
931
Body
701
K
350

11
702K931
ボディ
640K116
Oリング
640K118
Oリング 701K446
シリンダ
643K643
バックアップリング
703K020 ピストン
680K139
ロッドシールパッキン
680K138
バックアップリング
703K022
リテーナ
703K021
ハウジング
627K493
ロックナット
701K194
調整ネジ
770K226
スリーブ
640K013
Oリング
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑮
6-2 Disassembly of metering cylinder
CAUTION
- To reassemble, reverse procedure to disassembly.
- When reassembling the disassembled meter valve,
be sure to replace O Rings and Packings with new
ones at the same time as defective parts.
- The figure above shows a 5mL grease metering
valve. The other metering valves consist of mostly
the same except sizes and shapes.
(See [Product and Part List] for more details.)
The structure of adhesive metering valves is also
the same as the grease valves except that
U-Packings (④and ⑭) are changed to special
parts made with fluorine resin and material of O
Ring is changed from nitrile rubber to fluorine
resin.
⑨Unscrew 703K021 Housing to remove it from
702K931 Body.
⑩Pull out 701K446 Cylinder from Body.
⑪Remove 640K013 O Ring and 640K116 O Ring from
Body.
⑫Pull out 703K020 Piston from 701K446 Cylinder.
Remove 640K013 O Ring and 643K643 Backup Ring.
⑬Unscrew 703K022 Retainer to remove it from
703K021 Housing.
⑭Remove 680K139 Packing and 680K138 Backup
Ring from Housing.
⑮Remove 701K194 Screw and 627K493 Lock Nut from
Retainer and pull out 770K226 Sleeve.
O Rin
g
702
K
931
Body
70
3
K
020 Piston
64
3
K
64
3
701
K
44
6
Cylinder
640
K
11
8
O Ring
640
K
01
3
O Ring
640
K
11
6
Backup Rin
g
627
K
49
3
Lock Nut
770
K
22
6
Sleeve
701
K
194
Adjustment Bolt
70
3
K
021
Housing 70
3
K
022
Retainer
680
K
13
8
Backup Ring
Packin
g
680
K
139

12
Size Product No. Switching Valve Cylinder
0.5mL 686405 800K507 801K631
1mL 686406 800K507 800K856
3mL 686407 800K507 800K857
5mL 686408 800K507 800K858
10mL 686409 800K507 800K859
20mL 686410 800K507 800K860
50mL 686411 800K927 800K493
MODEL LIST
SizeABCDEF*GH I JKLM
0.5mL 172 26 45 82 50 128 55 Φ99074648037
1mL 172 26 45 82 50 118.5 55 Φ99074648037
3mL 172 26 45 82 50 133.5 55 Φ99074648037
5mL 172 26 45 82 50 154.5 55 Φ99074648037
10mL 172 26 45 82 50 186.5 55 Φ99074648037
20mL 172 26 45 82 50 259.6 55 Φ99074648037
50mL 202 40 45 94 72 285.5 70 Φ9 100 84 84 100 40
*set at a maximum value
DIMENSIONS
7. Product and Part List for Grease Metering Valve
7-1 Metering Valve
0.5mL-50mL Metering Valve (Standard Model)
Ｒｃ１／４操作空気
Ｒｃ１／４材料出口
Ｒｃ１／４材料入口
ＣＢ
Ｅ Ｆ
４－φＨ
底部取付寸法
Ｄ
Ｇ
Ｌ Ｋ
Ｊ
Ｉ
Ｍ
Ａ
A
ir Inlet Rc1/4
Material Inlet Rc1/4
Material Ou
t
let Rc1/4
Installation Dimensions

13
800K507 切換弁本体
800K507 切換弁本体
11702K161 キャップ
No. 部品番号 品 名 数
12 640K123 Oリング
13 702K714 ピストン
14 640K046 Oリング
15 702K931 ボディ
16 702K716 リテーナ
17 770K226 スリーブ
18 680K139 ロッドシールパッキン
19 702K715 ピストンロッド
110 680K087 バルブ
111 701K350 バルブスリーブ
212 643K015 Oリング
213 701K351 バルブシート
114 634K360 六角穴付プラグ
115 640K018 Oリング
116 702K166 プラグ
417 615K067 六角穴付ボルト
418 631K282 バネザガネ
119 702K932 ベースプレート
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
①②
800K927 切換弁本体
800K927 切換弁本体
11703K285 シリンダヘッド
No. 部品番号 品 名 数
12 640K131 Oリング
13 703K286 ピストン
14 640K059 Oリング
15 703K287 ピストンロッド
16 703K288 グランドリテーナ
17 770K300 スリーブ
18 703K293 パッキンウケ
19 770K301 バックアップリング
110 680K107 ロッドシールパッキン
211 703K291 バルブシート
212 643K016 Oリング
113 703K290 バルブスリーブ
114 703K292 バルブ
115 703K284 ボディ
116 640K117 Oリング
117 643K747 バックアップリング
118 634K360 六角穴付プラグ
120 703K289 バルブリテーナー
119 703K294 カラー
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
⑳
7-2 Switching Valve Body
No. Parts No. Description Q'ty
1 702K161 Cap 1
2 640K123 O ring 1
3 702K714 Piston 1
4 640K046 O ring 1
5 702K931 Body 1
6 702K716 Retainer 1
7 770K226 Sleeve 1
8 680K139 Packing 1
9 702K715 Piston rod 1
10 680K087 Valve 1
11 701K350 Valve sleeve 1
12 643K015 O ring 2
13 701K351 Valve seat 2
14 634K360 Plug 1
15 640K018 O ring 1
16 702K166 Plug 1
17 615K067 Bolt 4
18 631K282 Spring lock washer 4
19 702K932 Base plate 1
800K507 Switching Valve Body
800
K
507 Switching Valve Bod
y
800
K
927 Switching Valve Bod
y
No. Parts No. Description Q'ty
1 703K285 Cylinder head 1
2 640K131 O ring 1
3 703K286 Piston 1
4 640K059 O ring 1
5 703K287 Piston rod 1
6 703K288 Gland retainer 1
7 770K300 Sleeve 1
8 703K293 Packing retainer 1
9 770K301 Back up ring 1
10 680K107 Packing 1
11 703K291 Valve seat 2
12 643K016 O ring 2
13 703K290 Valve sleeve 1
14 703K292 Valve 1
15 703K284 Body 1
16 640K117 O ring 1
17 643K747 Back up ring 1
18 634K360 Plug 1
19 703K294 Collar 1
20 703K289 Valve retainer 1
800K927 Switching Valve Body

14
No. Parts No. Description Q'ty
1 705K206 Cylinder case 1
2 644K116 O ring 1
3 644K118 O ring 1
4 682K063 Seal 1
5 770K425 Back up ring 1
6 682K065 O ring 1
7 705K207 Cylinder 1
8 705K208 Packing gland 1
9 682K064 Seal 1
10 705K209 Retainer 1
11 645K634 Back up ring 1
12 640K004 O ring 1
13 705K210 Cylinder housing 1
14 705K211 Piston 1
15 705K212 Stopper 1
16 627K491 Lock nut 1
17 701K198 Adjustment bolt 1
801K631 Metering Cylinder (0.5mL)
7-3 Grease Metering Cylinder
801K631 Metering Cylinder (0.5mL)
１ ２ ３ ４ ５ ６ ７ ８ ９
１０
１１ １２ １３ １４ １５ １６ １７
11 12 1
3
1
4
1
5
1
6
1
7
1 2
3
4
5
6
7
8
9
10

15
800K856 1mL定量シリンダ 800K857 3mL定量シリンダ
800K858 5mL定量シリンダ 800K859 10mL定量シリンダ
800K856 1mL定量シリンダ
11703K014 ピストン
No. 部 品 番 号 品 名 数
12 644K006 Oリング
13 644K116 Oリング
14 701K450 シリンダ
15 644K118 Oリング
16 703K015 ハウジング
17 680K185 ロッドシールパッキン
18 680K328 バックアップ
19 770K285 スリーブ
110 703K016 リテーナ
111 627K491 ロックナット
112 701K198 チョウセイネジ
800K857 3mL定量シリンダ
11644K116 Oリング
No. 部 品 番 号 品 名 数
12 701K354 シリンダ
13 703K018 ハウジング
14 644K118 Oリング
15 703K017 ピストン
16 644K011 Oリング
17 680K185 ロッドシールパッキン
18 680K328 バックアップ
19 770K285 スリーブ
110 703K019 リテーナ
111 627K491 ロックナット
112 701K198 チョウセイネジ
③
②
①
④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫
⑫
① ② ③ ④ ⑤ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬
800K858 5mL定量シリンダ
11701K446 シリンダ
No. 部 品 番 号 品 名 数
12 644K116 Oリング
13 703K021 ハウジング
14 644K118 Oリング
15 644K013 Oリング
16 645K643 バックアップリング
バックアップリング
17 703K020 ピストン
1
1
8 680K139
680K138
ロッドシールパッキン
1
9
770K226 スリーブ
1
10
703K022 リテーナ
1
11
627K493 ロックナット
1
12
13 701K194 チョウセイネジ
800K859 10mL定量シリンダ
11701K429 シリンダ
No. 部 品 番 号 品 名 数
12 644K116 Oリング
13 703K024 ハウジング
14 644K118 Oリング
15 644K016 Oリング
16 645K646 バックアップリング
17 703K023 ピストン
18 680K238 ロッドシールパッキン
19 770K268 バックアップリング
110 770K236 スリーブ
111 703K025 リテーナ
112 627K493 ロックナット
113 701K191 チョウセイネジ
⑥① ② ③ ④ ⑤ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬
⑥
No. Parts No. Description Q'ty
1 703K014 Piston 1
2 644K006 O ring 1
3 644K116 O ring 1
4 701K450 Cylinder 1
5 644K118 O ring 1
6 703K015 Housing 1
7 680K185 Packing 1
8 680K328 Back up ring 1
9 770K285 Sleeve 1
10 703K016 Retainer 1
11 627K491 Lock nut 1
12 701K198 Adjustment bolt 1
800K856 Metering Cylinder (1mL)
No. Parts No. Description Q'ty
1 644K116 O ring 1
2 701K354 Cylinder 1
3 703K018 Housing 1
4 644K118 O ring 1
5 703K017 Piston 1
6 644K011 O ring 1
7 680K185 Packing 1
8 680K328 Back up ring 1
9 770K285 Sleeve 1
10 703K019 Retainer 1
11 627K491 Lock nut 1
12 701K198 Adjustment bolt 1
800K857 Metering Cylinder (3mL)
No. Parts No. Description Q'ty
1 701K446 Cylinder 1
2 644K116 O ring 1
3 703K021 Housing 1
4 644K118 O ring 1
5 644K013 O ring 1
6 645K643 Back up ring 1
7 703K020 Piston 1
8 680K139 Packing 1
9 680K138 Back up ring 1
10 770K226 Sleeve 1
11 703K022 Retainer 1
12 627K493 Lock nut 1
13 701K194 Adjustment bolt 1
800K858 Metering Cylinder (5mL)
No. Parts No. Description Q'ty
1 701K429 Cylinder 1
2 644K116 O ring 1
3 703K024 Housing 1
4 644K118 O ring 1
5 644K016 O ring 1
6 645K646 Back up ring 1
7 703K023 Piston 1
8 680K238 Packing 1
9 770K268 Back up ring 1
10 770K236 Sleeve 1
11 703K025 Retainer 1
12 627K493 Lock nut 1
13 701K191 Adjustment bolt 1
800K859 Metering Cylinder (10mL)
800K856 Metering Cylinder (1mL) 800K857 M
e
tering Cylinder
(
3mL)
800K858 Metering Cylinder
(
5mL) 800K859 Metering Cylinder
(
10mL)
6
6
1 2 3 4 5 7 8 9 10 11 12 13 1 2 3 4 5 7 8 9 10 11 12 13
3
4
5
6
7
8
9
10 11 1 2
3
4
5
6
7
8
9
10 11 12
2
1
12

16
No. Parts No. Description Q'ty
1 703K026 Piston 1
2 644K016 O ring 1
3 645K646 Back up ring 1
4 644K116 O ring 1
5 701K931 Cylinder 1
6 644K118 O ring 1
7 703K027 Housing 1
8 680K238 Packing 1
9 770K268 Back up ring 1
10 770K236 Sleeve 1
11 703K028 Retainer 1
12 627K493 Lock nut 1
13 703K504 Adjustment bolt 1
800K860 Metering Cylinder (20mL)
No. Parts No. Description Q'ty
1 643K119 O ring 1
2 644K026 O ring 1
3 645K656 Back up ring 1
4 643K122 O ring 1
5 701K890 Cylinder 1
6 702K110 Piston 1
7 702K088 Housing 1
8 680K106 Packing 1
9 770K210 Back up ring 1
10 770K211 Sleeve 1
11 702K090 Retainer 1
12 702K111 Cover 1
13 702K091 Adjustment bolt 1
14 627K496 Lock nut 1
800K493 Metering Cylinder (50mL)
800K860 Metering Cylinder (20mL)
800K493 Metering Cylinder (50mL)
６５４ ７ １ ２ ８ ９ １０ １１ １２ １３
３
１４
５ ６
３
２ ７４１ ８ ９
１０ １１
１２ １３
3
1 4 5 2 6 7 8 9 10 11
12 1
3
1
4
3
4 5 6 7 1 2 8 9 1011 12 13

17
Product No. 686405 686406 686407 686408 686409 686410 686411
Model KGK-401M KGK-402M KGK-404M KGK-405M KGK-406M KGK-407M KGK-408M
Applicable Material
Capacity 0.5 mL 1 mL 3 mL 5 mL 10 mL 20 mL 50 mL
Shot Range 0.05-0.5mL 0.2-1mL 0.3-3mL 2-5mL 4-10mL 8-20mL 15-50mL
Shot Accuracy
Maximum Operating Pressure
Withstanding pressure
Supply Air Pressure
Operating Temperature
Weight 2.6 kg 2.5 kg 2.6 kg 2.6 kg 2.8 kg 3.0 kg 7.9 kg
Note: Available material viscosity will vary according to use condition.
Room Temperature
Greases, High Viscosity Oils
- Please contact us if you are going to use any material such as silicone grease or
molybdenum disulfide grease which will affect the operation of a valve.
- Any material which contains particles such as aggregate or fast drying type of
material is NOT applicable.
- Wetted parts in a metering valve are made of steel and aluminum alloy and seal
parts are made of NBR and polyurethane.
Make sure that material you are going to use is compatible with these parts.
±2%
20 MPa
30 MPa
Maximum: 0.7MPa
Recommended: 0.4-0.5MPa
7-4 Specifications

18
SizeABCDEF*GH I JKLM
0.5mL 172 26 45 82 50 176.5 55 Φ99074648037
1mL 172 26 45 82 50 135 55 Φ99074648037
3mL 172 26 45 82 50 170 55 Φ99074648037
5mL 172 26 45 82 50 196.5 55 Φ99074648037
10mL 172 26 45 82 50 215 55 Φ99074648037
20mL 202 40 45 94 72 259.3 70 Φ9 100 84 84 100 40
50mL 202 40 45 94 72 326 70 Φ9 100 84 84 100 40
DIMENSIONS
*set at a maximum value
Size Product No. Switching V alve Cylinder
0.5mL 686418 800K507 801K637
1mL 686419 800K507 800K891
3mL 686420 800K507 800K903
5mL 686421 800K507 800K474
10mL 686422 800K507 800K485
20mL 686423 800K927 800K484
50mL 686424 800K927 800K486
MODEL LIST
8. Product and Part List for Grease Metering Valve with Sensor
8-1 Metering Valve with Sensor
0.5mL-50mL Metering Valve (Standard Model)
４－φＨ
Ｃ
Ｒｃ１／４操作空気
Ｒ ｃ１／４材料 入口
Ｒｃ１／４材料出口
底部取付寸法
Ｂ
Ｅ
Ｄ
Ａ
Ｉ
Ｍ
Ｊ
Ｋ Ｌ
Ｆ
Ｇ
A
ir Inlet Rc1/4
Material Inlet Rc1/4
Material Ou
t
let Rc1/4
Installation Dimensions

19
800K507 切換弁本体
800K507 切換弁本体
11702K161 キャップ
No. 部品番号 品 名 数
12 640K123 Oリング
13 702K714 ピストン
14 640K046 Oリング
15 702K931 ボディ
16 702K716 リテーナ
17 770K226 スリーブ
18 680K139 ロッドシールパッキン
19 702K715 ピストンロッド
110 680K087 バルブ
111 701K350 バルブスリーブ
212 643K015 Oリング
213 701K351 バルブシート
114 634K360 六角穴付プラグ
115 640K018 Oリング
116 702K166 プラグ
417 615K067 六角穴付ボルト
418 631K282 バネザガネ
119 702K932 ベースプレート
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
①②
800K927 切換弁本体
800K927 切換弁本体
11703K285 シリンダヘッド
No. 部品番号 品 名 数
12 640K131 Oリング
13 703K286 ピストン
14 640K059 Oリング
15 703K287 ピストンロッド
16 703K288 グランドリテーナ
17 770K300 スリーブ
18 703K293 パッキンウケ
19 770K301 バックアップリング
110 680K107 ロッドシールパッキン
211 703K291 バルブシート
212 643K016 Oリング
113 703K290 バルブスリーブ
114 703K292 バルブ
115 703K284 ボディ
116 640K117 Oリング
117 643K747 バックアップリング
118 634K360 六角穴付プラグ
120 703K289 バルブリテーナー
119 703K294 カラー
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭
⑮
⑯
⑰
⑱
⑲
⑳
8-2 Switching Valve Body with Sensor
No. Parts No. Description Q'ty
1 702K161 Cap 1
2 640K123 O ring 1
3 702K714 Piston 1
4 640K046 O ring 1
5 702K931 Body 1
6 702K716 Retainer 1
7 770K226 Sleeve 1
8 680K139 Packing 1
9 702K715 Piston rod 1
10 680K087 Valve 1
11 701K350 Valve sleeve 1
12 643K015 O ring 2
13 701K351 Valve seat 2
14 634K360 Plug 1
15 640K018 O ring 1
16 702K166 Plug 1
17 615K067 Bolt 4
18 631K282 Spring lock washer 4
19 702K932 Base plate 1
800K507 Switching Valve Body
800
K
507 Switching Valve Bod
y
800
K
927 Switching Valve Bod
y
No. Parts No. Description Q'ty
1 703K285 Cylinder head 1
2 640K131 O ring 1
3 703K286 Piston 1
4 640K059 O ring 1
5 703K287 Piston rod 1
6 703K288 Gland retainer 1
7 770K300 Sleeve 1
8 703K293 Packing retainer 1
9 770K301 Back up ring 1
10 680K107 Packing 1
11 703K291 Valve seat 2
12 643K016 O ring 2
13 703K290 Valve sleeve 1
14 703K292 Valve 1
15 703K284 Body 1
16 640K117 O ring 1
17 643K747 Back up ring 1
18 634K360 Plug 1
19 703K294 Collar 1
20 703K289 Valve retainer 1
800K927 Switching Valve Body
