Yamaha Jupiter Fi T115FS-5 User manual

DIC183
T115FS-5
OWNER’S MANUAL
Read this manual carefully before operating this vehicle.
BW7-F8199-E0
[English (E)]

EAU46091
Readthis manual carefully before operatingthis vehicle. This manual shouldstay with this vehicle if it is sold.
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM

Introduction
EAU10103
Welcome to the Yamaha world of motorcycling!
As the owner of the T115FS-5, you are benefiting from Yamaha’s vast experience and newest technology regarding the
design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
Please take the time to read this manual thoroughly, so as to enjoy all advantages of your T115FS-5. The Owner’s Manual
does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself
and others from trouble and injury.
In addition, the many tips given in this manual will help keep your motorcycle in the best possible condition. If you have any
further questions, do not hesitate to contact your Yamaha dealer.
The Yamaha team wishes you many safe and pleasant rides. So, remember to put safety first!
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and
this manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10032
Please readthis manual carefully andcompletely before operatingthis motorcycle.
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is usedto alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoidpossible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, couldresult in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoiddamage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM

Important manual information
EAUV0012
T115FS-5
OWNER’S MANUAL
©2016 by Yamaha Motor Vietnam Co., Ltd.
1st edition, April 2016
All rights reserved.
Any reprintingor unauthorizeduse
without the written permission of
Yamaha Motor Vietnam Co., Ltd.
is expressly prohibited.
Printedin Vietnam.
UBW7E0E0.book Page 2 Tuesday, February 9, 2016 11:48 AM

Table of contents
Location of important labels........... 1-1
Safety information............................ 2-1
Further safe-riding points ............... 2-5
Helmets .......................................... 2-6
Description ....................................... 3-1
Left view ......................................... 3-1
Right view....................................... 3-2
Controls and instruments ............... 3-3
Instrument andcontrol functions... 4-1
Main switch/steering lock............... 4-1
Keyhole cover................................. 4-2
Indicator lights and warning light ... 4-3
Speedometer unit........................... 4-3
Fuel gauge...................................... 4-4
Handlebar switches........................ 4-4
Shift pedal ...................................... 4-5
Front brake lever ............................ 4-5
Brake pedal .................................... 4-5
Fuel tank cap.................................. 4-6
Fuel................................................. 4-6
Catalytic converter ......................... 4-8
Kickstarter ...................................... 4-8
Seat ................................................ 4-9
Helmet holders ............................... 4-9
Storage compartment .................. 4-10
Sidestand ..................................... 4-10
For your safety – pre-operation
checks ...............................................5-1
Operation andimportant riding
points .................................................6-1
Starting and warming up
a cold engine ...............................6-1
Shifting ............................................6-2
Tips for reducing fuel
consumption................................6-3
Engine break-in...............................6-3
Parking ............................................6-4
Periodic maintenance and
adjustment ........................................7-1
Owner’s tool kit...............................7-1
Periodic maintenance chart for
the emission control system........7-2
General maintenance and
lubrication chart...........................7-3
Removing and installing cowlings
and panels ...................................7-7
Checking the spark plug...............7-10
Engine oil and oil filter element .....7-11
Replacing the air filter element
and cleaning the check hoses ...7-14
Adjusting the engine idling
speed.........................................7-15
Adjusting the throttle grip
free play .....................................7-16
Valve clearance.............................7-16
Tires .............................................. 7-17
Wheels .......................................... 7-18
Checking the brake lever
free play..................................... 7-19
Adjusting the brake pedal
free play..................................... 7-19
Brake light switches ..................... 7-20
Checking the front brake pads
and rear brake shoes ............... 7-20
Checking the brake fluid level ..... 7-21
Changing the brake fluid ............. 7-22
Drive chain slack........................... 7-22
Cleaning and lubricating the
drive chain................................. 7-24
Checking and lubricating the
cables........................................ 7-24
Checking and lubricating the
throttle grip and cable end........ 7-24
Checking and lubricating the
brake lever................................. 7-25
Checking and lubricating the
brake pedal ............................... 7-25
Checking and lubricating the
centerstand and sidestand........ 7-25
Lubricating the swingarm
pivots......................................... 7-26
Checking the front fork................. 7-26
Checking the steering................... 7-27
Checking the wheel bearings ....... 7-27
Battery .......................................... 7-28
Replacing the fuse........................ 7-29
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM

Table of contents
Replacing the headlight bulb.........7-30
Replacing a front turn signal
light bulb or an auxiliary light
bulb ............................................7-31
Replacing the tail/brake light
bulb or a rear turn signal light
bulb ............................................7-31
Front wheel....................................7-32
Rear wheel.....................................7-33
Troubleshooting ............................7-35
Troubleshooting chart ...................7-36
Motorcycle care andstorage..........8-1
Care.................................................8-1
Storage............................................8-3
Specifications....................................9-1
Consumer information ...................10-1
Identification numbers...................10-1
Index ................................................11-1
UBW7E0E0.book Page 2 Tuesday, February 9, 2016 11:48 AM

Location of important labels
1-1
1
EAU10385
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement
label is available from your Yamaha dealer.
123
4
ZAUV0667
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM

Location of important labels
1-2
1
14
100kPa=1bar kPa, psi kPa, psi
200, 29 225, 33
200, 29 280, 41
2VP-F1668-00
2
3
BW7-F1568-00
1DC-F815P-00
UBW7E0E0.book Page 2 Tuesday, February 9, 2016 11:48 AM

2-1
2
Safety information
EAUU1072
Be a Responsible Owner
As the vehicle’s owner, you are re-
sponsible for the safe and proper oper-
ation of your motorcycle.
Motorcycles are single-track vehicles.
Their safe use and operation are de-
pendent upon the use of proper riding
techniques as well as the expertise of
the operator. Every operator should
know the following requirements be-
fore riding this motorcycle.
He or she should:
Obtain thorough instructions from
a competent source on all aspects
of motorcycle operation.
Observe the warnings and mainte-
nance requirements in this Own-
er’s Manual.
Obtain qualified training in safe
and proper riding techniques.
Obtain professional technical ser-
vice as indicated in this Owner’s
Manual and/or when made neces-
sary by mechanical conditions.
Safe Riding
Perform the pre-operation checks
each time you use the vehicle to make
sure it is in safe operating condition.
Failure to inspect or maintain the vehi-
cle properly increases the possibility of
an accident or equipment damage.
See page 5-1 for a list of pre-operation
checks.
This motorcycle is designed to
carry the operator and a passen-
ger.
TIP
Although this motorcycle is designed
to carry a passenger, always comply
with the local regulations.
The failure of motorists to detect
and recognize motorcycles in traf-
fic is the predominating cause of
automobile/motorcycle accidents.
Many accidents have been
caused by an automobile driver
who did not see the motorcycle.
Making yourself conspicuous ap-
pears to be very effective in reduc-
ing the chance of this type of
accident.
Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are
approaching and passing
through intersections, since in-
tersections are the most likely
places for motorcycle accidents
to occur.
• Ride where other motorists can
see you. Avoid riding in another
motorist’s blind spot.
Many accidents involve inexperi-
enced operators. In fact, many op-
erators who have been involved in
accidents do not even have a cur-
rent driver’s license.
• Make sure that you are qualified
and that you only lend your mo-
torcycle to other qualified oper-
ators.
• Know your skills and limits.
Staying within your limits may
help you to avoid an accident.
• We recommend that you prac-
tice riding your motorcycle
where there is no traffic until you
UBW7E0E0.book Page 1 Tuesday, February 9, 2016 11:48 AM
