Congratulations on your purchase of the Yamaha XT600E. This model is the result of Yamaha’s
vast experience in the production of fine sporting, touring, and pacesetting racing machines. It
represents the high degree of craftsmanship and reliability that have made Yamaha a leader in
these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance
of this motorcycle. If you have any questions concerning the operation or maintenance of your
motorcycle, please consult a Yamaha dealer.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 1
ProCarManuals.com
IMPORTANT MANUAL INFORMATION
1
2
3
4
5
6
7
8
9
Particularly important information is distinguished in this manual by the following notations:
The Safety Alert Symbol means ATTENTION! BECOME ALERT! YOUR SAFETY IS
INVOLVED!
Failure to follow WARNING instructions could result in severe injury or deathto the
motorcycle operator, a bystander, or a person inspecting or repairing the motorcycle.
A CAUTION indicates special precautions that must be taken to avoid damage to
the motorcycle.
A NOTE provides key information to make procedures easier or clearer.
Q
w
cC
NOTE:
NOTE:
8This manual should be considered a permanent part of this motorcycle and should remain
with it even if the motorcycle is subsequently sold.
8Yamaha continually seeks advancements in product design and quality. Therefore, while this
manual contains the most current product information available at the time of printing, there
may be minor discrepancies between your motorcycle and this manual. If you have any ques-
tions concerning this manual, please consult your Yamaha dealer.
EAU00005
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 2
ProCarManuals.com
TABLE OF CONTENTS
1 SAFETY INFORMATION
2 DESCRIPTION
3 INSTRUMENT AND CONTROL FUNCTIONS
4 PRE-OPERATION CHECKS
5 OPERATION AND IMPORTANT RIDING POINTS
6 PERIODIC MAINTENANCE AND MINOR REPAIR
7 MOTORCYCLE CARE AND STORAGE
8 SPECIFICATIONS
9 CONSUMER INFORMATION
INDEX
9
8
7
6
5
4
3
2
1
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 5
ProCarManuals.com
SAFETY INFORMATION
SAFETY INFORMATION...................................................................1-1
Safe riding..........................................................................................1-1
Protective apparel...............................................................................1-3
Modification........................................................................................1-3
Loading and accessories....................................................................1-3
Gasoline and exhaust gas..................................................................1-5
Location of the important labels..........................................................1-7
1
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 7
ProCarManuals.com
1-1
EAU00017
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
MOTORCYCLES ARE SINGLE TRACK VEHICLES. THEIR SAFE USE AND OPERATION ARE
DEPENDENT UPON THE USE OF PROPER RIDING TECHNIQUES AS WELL AS THE EXPER-
TISE OF THE OPERATOR. EVERY OPERATOR SHOULD KNOW THE FOLLOWING REQUIRE-
MENTS BEFORE RIDING THIS MOTORCYCLE.
HE OR SHE SHOULD:
1. OBTAIN THOROUGH INSTRUCTIONS FROM A COMPETENT SOURCE ON ALL ASPECTS
OF MOTORCYCLE OPERATION.
2. OBSERVE THE WARNINGS AND MAINTENANCE REQUIREMENTS IN THE OWNER’S MAN-
UAL.
3. OBTAIN QUALIFIED TRAINING IN SAFE AND PROPER RIDING TECHNIQUES.
4. OBTAIN PROFESSIONAL TECHNICAL SERVICE AS INDICATED BY THE OWNERíS MANUAL
AND/OR WHEN MADE NECESSARY BY MECHANICAL CONDITIONS.
Safe riding
1. Always make pre-operation checks. Careful checks may help prevent an accident.
2. This motorcycle is designed to carry the operator and a passenger.
3. The failure of motorists to detect and recognize motorcycles in traffic is the predominating cause
of automobile/motorcycle accidents. Many accidents have been caused by an automobile driver
who did not see the motorcycle. Making yourself conspicuous appears to be very effective in
reducing the chance of this type of accident.
Therefore:
a. Wear a brightly colored jacket.
b. Use extra caution when approaching and passing through intersections, since intersections
are the most likely places for motorcycle accidents to occur.
c. Ride where other motorists can see you. Avoid riding in another motoristís blind spot.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 8
ProCarManuals.com
1-2
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
4. Many accidents involve inexperienced operators. In fact, many operators who have been
involved in accidents do not even have a current motorcycle license.
a. Make sure that you are qualified and that you only lend your motorcycle to other qualified oper-
ators.
b. Know your skills and limits. Staying within your limits may help you to avoid an accident.
c. We recommend that you practice riding your motorcycle where there is no traffic until you have
become thoroughly familiar with the motorcycle and all of its controls.
5. Many accidents have been caused by error of the motorcycle operator. A typical error made by
the operator is veering wide on a turn due to EXCESSIVE SPEED or undercornering (insufficient
lean angle for the speed).
a. Always obey the speed limit and never travel faster than warranted by road and traffic condi-
tions.
b. Always signal before turning or changing lanes. Make sure that other motorists can see you.
6. The posture of the operator and passenger is important for proper control.
a. The operator should keep both hands on the handlebar and both feet on the operator footrests
during operation to maintain control of the motorcycle.
b. The passenger should always hold onto the operator, the seat strap or grab bar, if equipped,
with both hands and keep both feet on the passenger footrests.
c. Never carry a passenger unless he or she can firmly place both feet on the passenger
footrests.
7. Never ride under the influence of alcohol or other drugs.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 9
ProCarManuals.com
1-3
EAU00021
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
Protective apparel
The majority of fatalities from motorcycle accidents are the result of head injuries. The use of a safety
helmet is the single most critical factor in the prevention or reduction of head injuries.
1. Always wear an approved helmet.
2. Wear a face shield or goggles. Wind in your unprotected eyes could contribute to an impairment
of vision that could delay seeing a hazard.
3. The use of a jacket, heavy boots, trousers, gloves, etc., is effective in preventing or reducing
abrasions or lacerations.
4. Never wear loose-fitting clothes, otherwise they could catch on the control levers, footrests, or
wheels and cause injury or an accident.
5. Never touch the engine or exhaust system during or after operation. They become very hot and
can cause burns. Always wear protective clothing that covers your legs, ankles, and feet.
6. Passengers should also observe the precautions mentioned above.
Modifications
Modifications made to this motorcycle not approved by Yamaha, or the removal of original equipment,
may render the motorcycle unsafe for use and may cause severe personal injury. Modifications may
also make your motorcycle illegal to use.
Loading and accessories
Adding accessories or cargo to your motorcycle can adversely affect stability and handling if the
weight distribution of the motorcycle is changed. To avoid the possibility of an accident, use extreme
caution when adding cargo or accessories to your motorcycle. Use extra care when riding a motorcy-
cle that has added cargo or accessories. Here are some general guidelines to follow if loading cargo
or adding accessories to your motorcycle:
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 10
ProCarManuals.com
1-4
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
Loading
The total weight of the operator, passenger, accessories and cargo must not exceed the maximum
load limit of 202 kg. When loading within this weight limit, keep the following in mind:
1. Cargo and accessory weight should be kept as low and close to the motorcycle as possible.
Make sure to distribute the weight as evenly as possible on both sides of the motorcycle to mini-
mize imbalance or instability.
2. Shifting weights can create a sudden imbalance. Make sure that accessories and cargo are
securely attached to the motorcycle before riding. Check accessory mounts and cargo restraints
frequently.
3. Never attach any large or heavy items to the handlebar, front fork, or front fender. These items,
including such cargo as sleeping bags, duffel bags, or tents, can create unstable handling or a
slow steering response.
Accessories
Genuine Yamaha accessories have been specifically designed for use on this motorcycle. Since
Yamaha cannot test all other accessories that may be available, you must personally be responsible
for the proper selection, installation and use of non-Yamaha accessories. Use extreme caution when
selecting and installing any accessories.
Keep the following guidelines in mind, as well as those provided under “Loading” when mounting
accessories.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 11
ProCarManuals.com
1-5
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
1. Never install accessories or carry cargo that would impair the performance of your motorcycle.
Carefully inspect the accessory before using it to make sure that it does not in any way reduce
ground clearance or cornering clearance, limit suspension travel, steering travel or control opera-
tion, or obscure lights or reflectors.
a. Accessories fitted to the handlebar or the front fork area can create instability due to improper
weight distribution or aerodynamic changes. If accessories are added to the handlebar or front
fork area, they must be as lightweight as possible and should be kept to a minimum.
b. Bulky or large accessories may seriously affect the stability of the motorcycle due to aerody-
namic effects. Wind may attempt to lift the motorcycle, or the motorcycle may become unstable
in cross winds. These accessories may also cause instability when passing or being passed by
large vehicles.
c. Certain accessories can displace the operator from his or her normal riding position. This
improper position limits the freedom of movement of the operator and may limit control ability,
therefore, such accessories are not recommended.
2. Use caution when adding electrical accessories. If electrical accessories exceed the capacity of
the motorcycle’s electrical system an electric failure could result, which could cause a dangerous
loss of lights or engine power.
Gasoline and exhaust gas
1. GASOLINE IS HIGHLY FLAMMABLE:
a. Always turn the engine off when refueling.
b. Take care not to spill any gasoline on the engine or exhaust system when refueling.
c. Never refuel while smoking or in the vicinity of an open flame.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 12
ProCarManuals.com
1-6
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
2. Never start the engine or let it run for any length of time in a closed area. The exhaust fumes are
poisonous and may cause loss of consciousness and death within a short time. Always operate
your motorcycle in an area that has adequate ventilation.
3. Always turn the engine off before leaving the motorcycle unattended and remove the key from
the main switch. When parking the motorcycle, note the following:
a. The engine and exhaust system may be hot, therefore, park the motorcycle in a place where
pedestrians or children are not likely to touch these hot areas.
b. Do not park the motorcycle on a slope or soft ground, otherwise it may fall over.
c. Do not park the motorcycle near a flammable source (e.g., a kerosene heater, or near an open
flame), otherwise it could catch fire.
4. When transporting the motorcycle in another vehicle, make sure that it is kept upright and that the
fuel cock(s) are turned to “ON” or “RES” (for vacuum type)/”OFF” (for manual type). If the motor-
cycle should lean over, gasoline may leak out of the carburetor or fuel tank.
5. If you should swallow any gasoline, inhale a lot of gasoline vapor, or allow gasoline to get into
your eyes, see your doctor immediately. If any gasoline spills on your skin or clothing, immediate-
ly wash the affected area with soap and water and change your clothes.
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 13
ProCarManuals.com
1-7
EAU00025
QSAFETY INFORMATION
1
2
3
4
5
6
7
8
9
EAU02977
Location of important labels
Please read the following important labels carefully before operating this motorcycle.
2
1
WARNING
Before you operate this vehicle,
read the owner’s manual.
English
3HP-21568-00
1
4AA-22259-40
2
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 14
ProCarManuals.com
DESCRIPTION
Left view.............................................................................................2-1
Right view...........................................................................................2-2
Controls and instruments....................................................................2-3 2
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 15
ProCarManuals.com
EAU00026
DESCRIPTION
1
2
3
4
5
6
7
8
9
2-1
1. Headlight (page 6-30)
2. Fuel cock (page 3-7)
3. Battery (page 6-28)
4. Owner’s tool kit (page 6-1)
5. Helmet holder (page 3-9)
6. Rear shock absorber spring preload
adjusting nut (page 3-9)
7. Fuse (page 6-29)
8. Starter (choke) knob (page 3-8)
9. Shift pedal (page 3-5)
1 2 3 4 5
6789
Left view
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 16
ProCarManuals.com
1
2
3
4
5
6
7
8
9
EAU00026
DESCRIPTION
2-3
1. Clutch lever (page 3-4, 6-17)
2. Left handlebar switches (page 3-3)
3. Speedometer unit (page 3-2)
4. Main switch/steering lock (page 3-1)
5. Tachometer (page 3-3)
6. Right handlebar switches (page 3-4)
7. Brake lever (page 3-5, 6-18)
8. Throttle grip (page 6-14)
9. Fuel tank cap (page 3-6)
1 2 3 4 5 6 7
89
Controls and instruments
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 18
ProCarManuals.com
INSTRUMENT AND CONTROL FUNCTIONS
Main switch/steering lock.......................................................................3-1
Indicator lights.......................................................................................3-2
Speedometer unit..................................................................................3-2
Tachometer...........................................................................................3-3
Handlebar switches...............................................................................3-3
Clutch lever............................................................................................3-4
Shift pedal..............................................................................................3-5
Brake lever............................................................................................3-5
Brake pedal...........................................................................................3-5
Fuel tank cap.........................................................................................3-6
Fuel........................................................................................................3-6
Fuel cock...............................................................................................3-7
Starter (choke) knob “1”.......................................................................3-8
Seat.......................................................................................................3-9
Helmet holder........................................................................................3-9
Adjusting the shock absorber assembly..............................................3-10
Sidestand.............................................................................................3-11
Ignition circuit cut-off system...............................................................3-11
3
3WR-9-2A (E) 1~5 6/28/00 9:00 AM Page 19
ProCarManuals.com
This manual suits for next models
1
Table of contents
Other Yamaha Motorcycle manuals
Yamaha
Yamaha X-MAX 125 ABS 2018 User manual
Yamaha
Yamaha FZ09E 2014 User manual
Yamaha
Yamaha NEO'S ESS025 2022 User manual
Yamaha
Yamaha XVS650H 2016 User manual
Yamaha
Yamaha TT-R50EY User manual
Yamaha
Yamaha YZF-R6 User manual
Yamaha
Yamaha Towny MJ50 User manual
Yamaha
Yamaha XS1100SH User manual
Yamaha
Yamaha Vmax VMX12M User manual
Yamaha
Yamaha XV19CSD User manual
Yamaha
Yamaha SCR 950 User manual
Yamaha
Yamaha FJR1300A User manual
Yamaha
Yamaha TRX850H User manual
Yamaha
Yamaha WARRIOR YFM350XP Manual
Yamaha
Yamaha YT125G Service manual
Yamaha
Yamaha FZS10Y User manual
Yamaha
Yamaha XT 125R 2005 Operating and installation instructions
Yamaha
Yamaha TT-R50EL 2019 User manual
Yamaha
Yamaha XJR1300T 2004 User manual
Yamaha
Yamaha YZ250(W)/W1 Application guide
