Yamaha XTZ07AR 2024 User manual

DIC183
XTZ07AR (Ténéré 700)
1
2
3
4
5
6
7
8
9
10
11
12
BVW-28199-70
Read this manual carefully
before operating this vehicle.
MOTORCYCLE
OWNER’S MANUAL
Specifications
Consumer information
Motorcycle care and storage
Periodic maintenance and adjustment
For your safety – pre-operation checks
Instrument and control functions
Special features
Description
Safety information
Location of important labels
Operation and important riding points
Index
[English (E)]

EAU46094
Readthis manual carefully before operatingthis vehicle. This manual shouldstay with this vehicle if it is sold.
UBVW70E0.book Page 1 Friday, July 21, 2023 10:52 AM

Introduction
EAU45931
Congratulations on your purchase of the Yamaha XTZ07AR. This model is the result of Yamaha’s vast experience in the
production of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and
reliability that have made Yamaha a leader in these fields.
This manual will give you an understanding of the operation, inspection, and basic maintenance of this motorcycle. If you
have any questions concerning the operation or maintenance of your motorcycle, please consult a Yamaha dealer.
The design and manufacture of this Yamaha motorcycle fully comply with the emissions standards for clean air applicable
at the date of manufacture. Yamaha has met these standards without reducing the performance or economy of operation
of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention
to the recommended maintenance schedules and operating instructions contained within this manual.
Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most cur-
rent product information available at the time of printing, there may be minor discrepancies between your motorcycle and
this manual. If there is any question concerning this manual, please consult a Yamaha dealer.
WARNING
EWA10022
Please readthis manual carefully andcompletely before operatingthis motorcycle. Do not attempt to operate this
motorcycle until you have attainedadequate knowledge of its controls andoperatingfeatures anduntil you have
been trainedin safe andproper ridingtechniques. Regular inspections andcareful maintenance, alongwith good
ridingskills, will ensure that you safely enjoy the capabilities andthe reliability of this motorcycle.
UBVW70E0.book Page 1 Friday, July 21, 2023 10:52 AM

Important manual information
EAU10134
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is usedto alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoidpossible injury
or death.
A WARNING indicates a hazardous situation which, if not avoided, couldresult in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoiddamage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICE
TIP
UBVW70E0.book Page 1 Friday, July 21, 2023 10:52 AM

Important manual information
EAU10202
XTZ07AR
OWNER’S MANUAL
©2024 by Yamaha Motor Co., Ltd.
1st edition, June 2023
All rights reserved.
Any reprintingor unauthorizeduse
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printedin Japan.
UBVW70E0.book Page 2 Friday, July 21, 2023 10:52 AM

Table of contents
Location of important labels ........... 1-1
Safety information............................ 2-1
Description ....................................... 3-1
Left view ......................................... 3-1
Right view....................................... 3-2
Controls and instruments ............... 3-3
Main display screen........................ 3-4
Special features .............................. 4-1
Quick shifter (if equipped) .............. 4-1
CCU (Communication Control
Unit)............................................. 4-1
Compliance with Industry
Canada........................................ 4-3
Instrument andcontrol functions... 5-1
Main switch/steering lock............... 5-1
Handlebar switches........................ 5-2
Indicator lights and warning
lights............................................ 5-4
Main display screen........................ 5-5
Menu system ................................ 5-11
Clutch lever .................................. 5-14
Shift pedal .................................... 5-14
Brake lever.................................... 5-15
Brake pedal .................................. 5-15
ABS .............................................. 5-15
Fuel tank cap................................ 5-16
Fuel............................................... 5-17
Catalytic converter ........................ 5-18
Seats .............................................5-19
Adjusting the headlight beams .....5-20
Adjusting the front fork .................5-20
Front fork bleeding........................5-22
Adjusting the shock absorber
assembly....................................5-23
Luggage strap holders ..................5-25
Front fender .................................5-25
DC power outlets ..........................5-26
Sidestand ......................................5-27
Ignition circuit cut-off system .......5-27
For your safety – pre-operation
checks ...............................................6-1
Operation andimportant riding
points .................................................7-1
Engine break-in...............................7-1
Starting the engine..........................7-2
Shifting ............................................7-3
Parking ............................................7-4
Periodic maintenance and
adjustment ........................................8-1
Tool kit ............................................8-2
Periodic maintenance chart for the
emission control system..............8-3
General maintenance and
lubrication chart...........................8-5
Removing and installing the
cowling ...................................... 8-10
Checking the spark plugs............. 8-10
Canister ........................................ 8-11
Engine oil and oil filter cartridge ... 8-12
Why Yamalube.............................. 8-15
Coolant ......................................... 8-15
Replacing the air filter element
and cleaning the check hose .... 8-16
Checking the throttle grip free
play............................................ 8-18
Valve clearance............................. 8-18
Tires .............................................. 8-18
Spoke wheels ............................... 8-20
Adjusting the clutch lever free
play............................................ 8-20
Checking the brake lever free
play............................................ 8-21
Brake light switches ..................... 8-22
Checking the front and rear brake
pads .......................................... 8-22
Checking the brake fluid level ...... 8-23
Changing the brake fluid .............. 8-24
Drive chain slack........................... 8-24
Cleaning and lubricating the
drive chain................................. 8-26
Checking and lubricating the
cables........................................ 8-27
Checking and lubricating the
throttle grip and cable............... 8-27
UBVW70E0.book Page 1 Friday, July 21, 2023 10:52 AM

Table of contents
Checking and lubricating the
brake and shift pedals ...............8-27
Checking and lubricating the
brake and clutch levers..............8-28
Checking and lubricating the
sidestand ...................................8-29
Lubricating the rear suspension....8-29
Lubricating the swingarm pivots ...8-29
Checking the front fork..................8-30
Checking the steering ...................8-30
Checking the wheel bearings ........8-31
Battery...........................................8-31
Replacing the fuses.......................8-32
Vehicle lights .................................8-34
License plate light .........................8-34
Supporting the motorcycle............8-34
Troubleshooting ............................8-35
Troubleshooting chart ...................8-36
Motorcycle care andstorage..........9-1
Matte color caution .........................9-1
Care.................................................9-1
Storage............................................9-4
Specifications..................................10-1
Consumer information ...................11-1
Identification numbers...................11-1
Diagnostic connector ....................11-3
Use of your vehicle data................11-4
Reporting safety defects ...............11-6
Maintenance record...................... 11-7
YAMAHA MOTOR CANADA LTD.
MOTORCYCLE WARRANTY
GUIDE ....................................... 11-9
Index ................................................ 12-1
UBVW70E0.book Page 2 Friday, July 21, 2023 10:52 AM

Location of important labels
1-1
1
EAU10387
Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of
your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement
label is available from your Yamaha dealer.
2,31 4,5,6,7,8,9,10 11
1213
UBVW70E0.book Page 1 Friday, July 21, 2023 10:52 AM

Location of important labels
1-2
1
WARNING
BEFORE YOU OPERATE THIS VEHICLE, READ
THE OWNER’S MANUAL AND ALL LABELS.
ALWAYS WEAR AN APPROVED MOTORCYCLE
HELMET, eye protection, and protective clothing.
1TP-2118K-A2
NOTICE
8ET-2815K-01
AVERTISSEMENT
LIRE LE MANUEL DU PROPRIETAIRE AINSI QUE TOUTES
LES ETIQUETTES AVANT D’UTILISER CE VEHICULE.
TOUJOURS PORTER UN CASQUE DE MOTOCYCLISTE
APPROUVE, des lunettes et des vêtements de protection.
1TP-2118K-B2
BAG-F815P-00
TOOL KIT
POUCH
STORAGE ORDER
BAND
RIDER SEAT
21
34
UBVW70E0.book Page 2 Friday, July 21, 2023 10:52 AM

Location of important labels
1-3
1
TIRE INFORMATION
Cold tire normal pressure should be set
as follows.
FRONT
REAR
: 220 kPa, {2.20 kgf/cm²}, 32 psi
: 250 kPa, {2.50 kgf/cm²}, 36 psi
BAU-21668-00
La pression des pneus à froid doit normalement
être réglée comme suit.
AVANT : 220 kPa, {2.20 kgf/cm2}, 32 psi
ARRIERE : 250 kPa, {2.50 kgf/cm2}, 36 psi
BAU-21668-10
INFORMATION SUR LES PNEUS
WARNING
Improper loading can cause loss of control.
Read owner’s manual for proper loading.
3JJ-28446-A2
AVERTISSEMENT
Un chargement incorrect risque de causer une perte de contrôle.
Lire le manuel du propriétaire pour le chargement convenable.
3JJ-28446-B2
1,5 kg (3 lb)
3SA-24877-B2
CHARGE LIMITE
1.5 kg {3 lbs}
3SA-24877-A1
LOAD LIMIT
65
78
910
