SERVICE MANUAL
11H-28197-10

2
FEATURES
XZ550RJ
Liquid-cooled V-Twin
The 70° V-Twin engine is liquid-cooled to maintain the best operating temperature range. The cooling system
features an aluminum-corrugate radiator which is extremely light and exhibits excellent heat-dissipating char-
acteristics. An automatically activated electric fan pulls air through the radiator in heavy-traffic situations. The
system has an automotive-type expansion and recovery tank which makes airspace in the radiator unneces-
sary and virtually eliminates coolant loss on even the hottest days. A thermostatic valve mounted in the engine
block provides quick warmups and stable coolant temperature.

3
YICS
To increase fuel economy through more efficient combustion, the engine is equipped with the patented Ya-
maha Induction Control System (YICS). In this configuration, the YICS consists of a chamber linked to the in-
take manifold by a tube. Upon intake, the vacuum in the manifold creates a vacuum in the chamber; when the
intake valve closes, the chamber draws in some air-fuel mixture. When the intake valve reopens, the mixture
in the chamber shoots back out through the angled tube and into the cylinder, mixing with and swirling the
main intake charge. The swirling charge is then compressed and ignited, burning more completely and produc-
ing more power than that of a conventional engine.
INTAKE SYSTEM AND YICS

4
LIQUID COOLING SYSTEM
Downdraft carb
The induction system on this motorcycle features downdraft carburetion. The 34 mm (1.34 in) Venturis are
positioned so that the incoming air takes a virtually straight path through the carbs and the intake manifolds to
the combustion chambers; intake efficiency is remarkably high. An accelerator pump is installed in the carbu-
retor assembly to eliminate hesitation when the throttle is opened at low engine speeds. A fuel pump delivers
gas from the tank to the float bowls, and a regulator sends excess fuel through a circuit back to the fuel pump
inlet.
DOHC 4-valve heads
Each cylinder head has dual overhead camshafts, and each camshaft acts directly on top of the valves; there
are no pushrods or rocker arms. Both heads have four valves, two intake and two exhaust, instead of one in-
take and one exhaust valve. By using two slightly smaller valves in place of each large valve, port area is sig-
nificantly increased. This provides a much greater volume of mixture and exhaust flow. In addition, the smaller,
lighter valves are easier to control at high engine speeds; the valves can follow the cam profiles more closely
to resist "floating" and allow a 9,500 r/min red line.

5
Chassis bits
The "hang-support" frame on this motorcycle allows a lower engine placement and center of gravity while pro-
viding excellent rigidity for precise handling. Cornering clearance is also enhanced. The trailing-axle front sus-
pension performs superbly. The axle placement helps to maintain a short wheelbase, allowing quick, sporty
handling. Yamaha's proven Monoshock rear suspension provides the excellent handling and comfort charac-
teristics for which it is famous. The spring preload is adjustable to five settings.
FRAME AND MONOCROSS SUSPENSION SYSTEM

6
NOTICE
This manual was written by the Yamaha Motor Company primarily for use by Yamaha dealers and their quali-
fied mechanics. It is not possible to put an entire mechanic's education into one manual, so it is assumed that
persons using this book to perform maintenance and repairs on Yamaha motorcycles have a hasic under-
standing of the mechanical concepts and procedures inherent to motorcycle repair technology. Without such
knowledge, attempted repairs or service to this model may render it unfit to use and/or unsafe.
This model has been designed and manufactured to perform within certain specifications in regard to perform-
ance and emissions. Proper service with the correct tools is necessary to ensure that the motorcycle will oper-
ate as designed. If there is any question about a service procedure, it is imperative that you contact a Yamaha
dealer for any service information changes that apply to this model. This policy is intended to provide the cus-
tomer with the most satisfaction from his motorcycle and to conform with federal environmental quality objec-
tives.
Yamaha Motor Company, Ltd. is continually striving to improve all models manufactured by Yamaha. Modifica-
tions and significant changes in specifications or procedures will be forwarded to all Authorized Yamaha deal-
ers and will, where applicable, appear in future editions of this manual.
NOTE:
This Service Manual contains information regarding periodic maintenance to the emission control system for
the XZ550RJ. Please read this material carefully.
Particularly important information is distinguished in this manual by the following notations:
NOTE: A NOTE provides key information to make procedures easier or clearer.
CAUTION: A CAUTION indicates special procedures that must be followed to avoid damage to the motorcy-
cle.
WARNING: A WARNING indicates special procedures that must be followed to avoid injury to a motorcycle
operator or person inspecting or repairing the motorcycle.
SERVICE DEPT.
INTERNATIONAL DIVISION
YAMAHA MOTOR CO., LTD.

7
CHAPTER 1. GENERAL INFORMATION
MOTORCYCLE IDENTIFICATION………………………………………………………………………………..... 8
Frame serial number……………………………………………………………………………………….. 8
Engine serial number………………………………………………………………………………………. 8
Vehicle identification number…………………………………………………………………………….. 8
SPECIAL TOOLS……………………………………………………………………………………………………... 9
For tune-up…………………………………………………………………………………………………… 9
For engine service………………………………………………………………………………………….. 9
For chassis service…………………………………………………………………………………………. 12
For middle gear service……………………………………………………………………………………. 12
For shaft drive service……………………………………………………………………………………... 13
For electrical components………………………………………………………………………………… 13

8
MOTORCYCLE IDENTIFICATION
Frame serial number
The frame serial number is stamped into the right
side of the steering head pipe.
1. Frame serial number
Engine serial number
The engine serial number is stamped into the ele-
vated part of the right rear section of the engine.
Starting serial number:
XZ550RJ 11H-000101
NOTE
The first three digits of these numbers are for model
identification; the remaining digits are the unit pro-
duction number.
1. Engine serial number
Vehicle identification number
The vehicle identification number is on the left side
of the steering head pipe.
1. Vehicle identification number
GENERAL INFORMATION

9
SPECIAL TOOLS
The proper special tools are necessary for complete
and accurate tune-up and assembly. Using the cor-
rect special tool will help prevent damage caused by
the use of improper tools or improvised techniques.
For tune-up
Inductive tachometer (P/N YU-08036)
Inductive timing light (P/N YU-08037)
Fuel level gauge (P/N YM-01312)
Cooling system tester (P/N YU-24460)
Compression gauge (P/N YU-33223)
Compression gauge
12 mm (0.47 in) adapter (P/N YU-33223-3)
Vacuum gauge (P/N YU-08030)
This gauge is needed for carburetor synchronization
For engine service
Universal clutch holder
(P/N YM-91042)
This tool is used to hold the clutch when removing
or installing the clutch boss locknut
Tappet adjusting tool (P/N YM-28899)
This tool is necessary to replace valve adjusting
pads.
Valve spring compressor
(P/N YM-04019)
This tool must be used for removing and installing
the valve assemblies
Vavle guide remover
(P/N YM-04064)
This must be used to remove the valve guides

10
Valve guide reamer
(P/N YM-04066)
This must be used when replacing the valve guide.
Valve guide installer
(P/N YM-04065)
This tool is needed for proper installation of the
valve guides.
Valve seat cutter set
(P/N YM-91043)
This tool is needed to resurface the valve seat.
Flywheel puller
(P/N YU-33270)
This tool is used for removing the flywheel
8mm (0,3 in) wrench adapter
(P/N YM-28897)
This tool is used to loosen or tighten the cylinder
head securing nut.
Water pump seal installer
(P/N YM-33221)
This tool is needed for proper installation of the wa-
ter pump seal.

11
Piston pin puller
(P/N YU-01304)
This tool is used to remove the piston pin.
#30 Torx driver
(P/N YU-29843-6)
This tool is used to loosen or tighten the drive axle
bearing stopper bolt
#25 Torx driver
(P/N YU-29843-4)
This tool is used to loosen or tighten the shift cam
segment securing bolt
46 mm (1.8 in) offset wrench
(P/N YM-04045A)
This tool is used to loosen and tighten the primary
drive gear/balancer drive gear securing nut.
Plain bearing driver/installer
(P/N YM-28898)
Handle (P/N YM-04058-1)
These tools are used for removing and installing the
crankshaft plain bearing.

12
Plastigauge set “Green”
(P/N YU-33210)
This gauge is needed when measuring clearance
for connecting rod bearing.
For chassis service
T-handle (P/N YU-01268) and damper rod holder
(P/N YM-33256)
This tool is used to loosen and tighten the fron fork
cylinder holding bolt
Front fork cap socket (19mm) (0.75 in))
(P/N YM-01298)
This tool is needed when loosening and tightening
the front fork cap bolt
For middle gear service
Universal joint holder
(P/N YM-04062)
This tool is used when adjusting gear lash, in the
middle gear.
Middle drive gear holder
(P/N YM-33222)
This tool is needed when measuring gear back lash.
Dial indicator
(P/N YU-03097)
These tools are used when measuring gear lash for
middle gear.

13
For shaft drive service
Damper spring compressor
(P/N YM-04011)
This tool is needed to disassemble and reassemble
the middle gear damper.
Final drive gear lash tool
(P/N YM-01230)
This tool is needed when measuring gear lash for
final gear.
Ring gear holder
(P/N YM-01254)
This tool is needed when measuring gear lash.
Bearing retainer wrench
(P/N YM-33214)
This tool is used to loosen or tighten the bearing
retainer.
For electrical components
The uses of these tools are described in Chapter 6.
Electro tester
(P/N YU-03021)
Pocket tester
(P/N YU-03112)

14
CHAPTER 2.
PERIODIC INSPECTIONS AND ADJUSTMENTS
INTRODUCTION…………………………………………………………………………………………………….. 15
MAINTENANCE INTERVALS CHARTS…………………………………………………………………………. 15
PERIODIC MAINTENANCE EMISSION CONTROL SYSTEM………………………………………………… 15
GENERAL MAINTENANCE/LUBRICATION……………………………………………………………………. 16
ENGINE………………………………………………………………………………………………………………. 17
Valve clearance adjustment………………………………………………………………………………… 17
Spark plug……………………………………………………………………………………………………… 23
Crankcase ventilation system……………………………………………………………………………… 23
Fuel line………………………………………………………………………………………………………… 23
Exhaust system………………………………………………………………………………………………. 23
Carburetor synchronization………………………………………………………………………………… 23
Idle speed……………………………………………………………………………………………………… 24
Engine oil………………………………………………………………………………………………………. 24
Coolant…………………………………………………………………………………………………………. 25
Clutch adjustment……………………………………………………………………………………………. 26
Checking ignition timing……………………………………………………………………………………. 27
Compression pressure measurement……………………………………………………………………. 27
CHASSIS…………………………………………………………………………………………………………….. 28
Final gear oil…………………………………………………………………………………………………… 28
Air filter…………………………………………………………………………………………………………. 28
Front and rear brake…………………………………………………………………………………………. 29
Brake light switch adjustment……………………………………………………………………………… 30
Front brake pad……………………………………………………………………………………………….. 30
Rear brake shoe………………………………………………………………………………………………. 31
Brake fluid……………………………………………………………………………………………………… 31
Cable inspection and lubrication………………………………………………………………………….. 31
Brake and change pedals/brake and clutch levers…………………………………………………….. 31
Centerstand and sidestand.................................………………………………………………………… 31
Front fork oil change………………………………………………………………………………………… 32
Rear shock absorber adjustment…………………………………………………………………………. 33
Steering head adjustment………………………………………………………………………………….. 33
Wheel bearings………………………………………………………………………………………………. 33
Front wheel……………………………………………………………………………………………………. 34
Rear wheel…………………………………………………………………………………………………….. 34
Fuel cock………………………………………………………………………………………………………. 34
Tubeless tires and aluminum wheels…………………………………………………………………….. 35
ELECTRICAL……………………………………………………………………………………………………….. 35
Battery………………………………………………………………………………………………………….. 35
Headlight……………………………………………………………………………………………………….. 36
Fuse……………………………………………………………………………………………………………... 37

15
INTRODUCTION
This chapter includes all information necessary to
perform recommended inspections and adjust-
ments. These preventive maintenance procedures,
if followed, will ensure more reliable vehicle opera-
tion and a longer service life. The need for costly
overhaul work will be greatly reduced. This informa-
tion applies to vehicles already in service and to
new vehicles that are being prepared for sale. All
service technicians should be familiar with this en-
tire chapter.
MAINTENANCE INTERVALS CHARTS
Proper periodic maintenance is important. Espe-
cially important are the maintenance services re-
lated to emissions control. These controls not only
function to ensure cleaner air but are also vital to
proper engine operation and maximum perform-
ance. In the following maintenance tables, the serv-
ices related to emissions control are grouped sepa-
rately.
PERIODIC INSPECTIONS AND ADJUSTMENTS
PERIODIC MAINTENANCE EMISSION CONTROL SYSTEM

16
GENERAL MAINTENANCE/LUBRICATION

17
ENGINE
Valve clearance adjustment
Adjust the valve clearance as follows:
NOTE:
Valve clearance must be measured when the en-
gine is cool to the touch.
1. Remove the seat, and remove the side cov-
ers, fuel tank, air filter assembly, and crank-
case ventilation pipes.
1. Fuel tank holding bolt
CAUTION:
After removing the air filter assembly, cover the
carburetors with a clean rag to prevent dust or
any foreign materials from entering.
2. Remove the radiator cover and the radiator
securing bolts. Gently and firmly push the
left side of the radiator assembly towards the
front wheel. The right side of the radiator and
connected pipes should remain in place.
NOTE:
It is not necessary to completely remove the radiator
from the motorcycle.
3. Remove the air baffle plate from behind the
front cylinder and remove the right side
frame tube.
1. Air baffle plate
1. Down tube frame
4. Disconnect the spark plug cap from each
cylinder head.
5. Remove the cylinder head covers.
NOTE:
Be careful so that the oil plugs on the camshaft caps
are not lost.
1. Oil plug
6. Remove the emblem plate and timing plug
from the left-side crankcase.

18
1. Emblem plate 2. Timing plug
7. Align the "T" mark (for the front cylin-der)Vpn
the flywheel with the stationary pointer on
the crankcase cover. The pointer can be
viewed through the timing window in the
crankcase cover. When the "T" mark is
aligned with the stationary pointer, the piston
is at Top Dead Center (TDC). Valve clear-
ance should be checked and adjusted when
the piston is at TDC on the compression
stroke. The piston is at TDC on compression
when there is free play in both valve adjust-
ers.
NOTE:
The crankshaft should be turned counterclockwise,
as viewed from the left side of the motorcycle.
The flywheel is marked as follows:
8. Use a feeler gauge to determine the clear-
ance. If clearance is incorrect, record the
measured amount of clearance. This must
be measured carefully.
Intake valve (cold):
0.11 ~0.15mm (0.0043 -0.0059 in)
Exhaust valve (cold):
0.16 ~ 0.20mm (0.0063 ~ 0.0079 in)
9. Valve clearance is adjusted by replacing the
adjusting pad on the top of the valve lifter.
Adjusting pads are available in 25 thick-
nesses, ranging from No. 200 (2.00 mm
(0.079 in)) to No. 320 (3.20 mm (0.130 in) >
in steps of 0.05 mm (0.002 in). The thick-
ness of each pad is marked on the pad face
that contacts the valve lifter (not the cam).
Adjustment of the valve clearance is accom-
plished as follows:

19
a. There is a slot in each valve lifter. The slots
must be positioned opposite of each other on
the exhaust and intake side before the tappet
adjusting tool is installed.
b. Turn the crankshaft until the camshaft identi-
fication mark (IN or EX) faces upward. Place
the tappet adjusting tool under the camshaft
with the tool match mark (•) and camshaft
I.D. mark aligned.
c. Turn the crankshaft until the lobe of the tool
depresses the valve lifters.
WARNING:
When turning the crankshaft, exercise care so
that the tappet adjusting tool does not contact
the mating surface of the cylinder head and the
cylinder head cover.
NOTE:
When installing the tappet adjusting tool onto the
camshaft, be careful so that the lobe of the tool
does not ride on the pad.
d. Remove the pads from the lifters. There is a
slot in each lifter. Use an air gun or a small
screwdriver and a magnetic rod to remove
the pads. Note the numbers on the pads.
e. Proper pad selection is made as follows:
(Use appropriate chart for exhaust or intake
valves.)
1) Find number of original (installed) pad
number on chart. Read down on chart.
2) Find measured valve clearance (from
step 1) on chart. Read across.

20
NOTE:
The new pad number is to be used as a guide only.
Verify the correctness of this choice in the following
step(s).
3) At the intersection of installed pad
number (down) and measured clear-
ance (across) is a new pad number.
EXAMPLE:
Intake valve, installed pad:
No.250 (read down)
Measured clearance:
0.32mm (0.013 in) (read across)
New pad number: No.270
(intersection of down & across)
