MIDI Reference
MIDI-Referenz
Référence MIDI
Referencia MIDI

MIDI Reference/MIDI-Referenz/Référence MIDI/Referencia MIDI
2
YAMAHA [ Digital Piano ] Date:5-FEB-2013
Model DGX-650
MIDI Implementation Chart Version:1.0
Transmitted Recognized Remarks
Function...
Basic Default 1 - 16 1 - 16
Channel Changed x x
Default 3 3
Mode Messages x x
Altered ************** x
Note 0 - 127 0 - 127
Number : True voice ************** 0 - 127
Velocity Note ON o 9nH,v=1-127 o 9nH,v=1-127
Note OFF x 9nH,v=0 x
After Key's x x
Touch Ch's x o
Pitch Bend o o 0-24 semi
Prog o 0 - 127 o 0 - 127
Change : True # **************
System Exclusive o o
: Song Pos. x x
Common : Song Sel. x x
: Tune x x
System : Clock o o
Real Time: Commands o o
:All Sound OFF x o(120,126,127)
Aux :Reset All Cntrls x o(121)
:Local ON/OFF x o(122)
Mes- :All Notes OFF x o(123 - 125)
sages:Active Sense o o
:Reset x x
0,32 o o Bank Select
1,11,84 x *1 o
6,38 o o Data Entry
7,10 o o
Control 64,66,67 o o Pedal
71 x *1 o Harmonic Content
Change 72 o o Release Time
73 x *1 o Attack Time
74 x *1 o Brightness
91,93,94 o o Effect Depth
96-97 x *1 o RPN Inc,Dec
100-101 o o RPN LSB,MSB
MIDI Implementation Chart / MIDI-Implementationstabelle /
MIDI Implementation Chart / Gráfico de implementación MIDI
*1 Refer to #2 on the next page.
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO x : No

MIDI Reference/MIDI-Referenz/Référence MIDI/Referencia MIDI 3
MIDI Data Format / MIDI-Datenformat / Format des données MIDI /
Formato de datos MIDI
NOTE:
1 By default (factory settings) the instrument ordinarily functions as a
16-channel multi-timbral tone generator, and incoming data does not
affect the panel Voices or panel settings. However, the MIDI mes-
sages listed below do affect the panel Voices, Auto Accompaniment,
and Songs.
• MIDI Master Tuning
• System exclusive messages for changing the Reverb Type, Chorus
Type and DSP Type.
2 Messages for these control change numbers cannot be transmitted
from the instrument itself. However, they may be transmitted when
playing the accompaniment, Song or using the Harmony effect.
3Exclusive
<GM System ON>
F0H, 7EH, 7FH, 09H, 01H, F7H
• This message automatically restores all default settings for the
instrument, with the exception of MIDI Master Tuning.
<MIDI Master Volume>
F0H, 7FH, 7FH, 04H, 01H, ll, mm, F7H
• This message allows the volume of all channels to be changed
simultaneously (Universal System Exclusive).
• The values of “mm” is used for MIDI Master Volume. (Values for
“ll” are ignored.)
<XG Master Tuning>
F0H, 43H, 1nH, 4CH, 00H, 00H, 00H, ddH, ddH, ddH, ddH, F7H
• This message simultaneously changes the tuning value of all chan-
nels.
• The values of “dd” are used for XG Master Tuning.
• The default value of “dd” are 00H, 04H, 00H, 00H, respectively.
<Reverb Type>
F0H, 43H, 1nH, 4CH, 02H, 01H, 00H, mmH, llH, F7H
• mm : Reverb Type MSB
• ll : Reverb Type LSB
Refer to the Effect Type List on the Data List.
<Chorus Type>
F0H, 43H, 1nH, 4CH, 02H, 01H, 20H, mmH, llH, F7H
• mm : Chorus Type MSB
• ll : Chorus Type LSB
Refer to the Effect Type List on the Data List.
<DSP Type>
F0H, 43H, 1nH, 4CH, 02H, 01H, 40H, mmH, llH, F7H
• mm: DSP Type MSB
• ll: DSP Type LSB
Refer to the Effect Type List on the Data List.
4 When the accompaniment is started, an FAH message is transmitted.
When accompaniment is stopped, an FCH message is transmitted.
When the clock is set to External, both FAH (accompaniment start)
and FCH (accompaniment stop) are recognized.
5 Local ON/OFF
<Local ON> Bn, 7A, 7F
<Local OFF> Bn, 7A, 00
Value for “n” is ignored.
U.R.G., Digital Musical Instruments Division
© 2013 Yamaha Corporation
