Yamaha MOTIF RACK Music System Instruction Manual

TONE GENERATOR
This document is printed on recycled chlorine free (ECF) paper with soy ink.
M.D.G., Pro Audio & Digital Musical Instrument Division, Yamaha Corporation
© 2003 Yamaha Corporation
WA24960 301MWAP25.2-02B0
Printed in Japan
DATA LIST
DATEN-LISTE
LISTE DE DONNÉES
Table of Contents
Normal Voice List . . . . . . . . . . . . . . 2
Drum Voice List . . . . . . . . . . . . . . . 10
Drum Voice Name List . . . . . . . . 10
Drum Kit Assign List . . . . . . . . . .11
Wave List . . . . . . . . . . . . . . . . . . . .23
Multi List . . . . . . . . . . . . . . . . . . . . 25
Multi Library List . . . . . . . . . . . . . . .25
Effect Type List . . . . . . . . . . . . . . . . 26
Effect Parameter List . . . . . . . . . . . . 28
Effect Data Assign Table . . . . . . . . . 37
Control List . . . . . . . . . . . . . . . . . . .40
Arpeggio Type List . . . . . . . . . . . . . 41
Audition Phrase List . . . . . . . . . . . . 42
MIDI Data Format . . . . . . . . . . . . . .43
MIDI Data Table . . . . . . . . . . . . . . . 46
MIDI Implementation Chart. . . . . . . 60

2
Normal Voice List
Some stereo Voices include stereo Elements. Since a stereo Element is made up of stereo (two-channel) data, the maximum Elements used in a Voice containing such
Elements may be more than four, even though a Voice can have only up to four Elements.
Preset1 (MSB=63, LSB=0)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap PowerGrand 4 2
2 Ap Jazz Grand 4 2
3 Ap Dark Grand 4 2
4 Ap CP 80 4 1
5 Kb CP80&EP 4 4
6 Kb Yama EP's 4 4
7 Ap BalladKeys 4 3
8 Ap 80s Layer 3 4
9 Ap Piano&Strg 4 4
10 Ap Piano Ooh 3 4
11 Ap PianoBakup 3 4
12 Kb Max Tine 4 3
13 Kb Early Fusn 4 2
14 Kb Vintage'74 4 1
15 Kb Sweetness 3 1
16 Kb DynoStrait 4 1
17 Kb ChorusHard 4 1
18 Kb VintagCase 4 1
19 Kb ChorusDyno 4 1
20 Kb 80th Boost 4 1
21 Kb Contempo 4 1
22 Kb Early 70's 3 2
23 Kb Tonight 4 1
24 Kb E.PianoPad 3 3
25 Kb TX802 3 2
26 Kb ChorusBel 2 2
27 Kb BellDX 3 3
28 Kb Dark DX 3 3
29 Kb GS Tines 3 2
30 Kb Rich FM 4 4
31 Kb FilteredDX 2 2
32 Kb Ice Piano 3 3
33 Kb WurliTrem 4 1
34 Kb WurliAmped 3 1
35 Kb TouchClavi 1 1
36 Kb SuperClavi 2 2
37 Kb StereoClav 2 2
38 Kb HollowClav 3 2
39 Kb Nu Phasing 4 2
40 Kb Digi Clavi 1 1
41 Kb PulseClavi 3 1
42 Cp Twinkle 4 4
43 Cp Stick Bell 3 3
44 Cp Bell Chiff 4 2
45 Cp FngrCymbl 4 2
46 Cp ChorusBell 2 2
47 Cp Tibetan 3 3
48 Cp EastBell 4 5
49 Cp Gamelan 3 2
50 Cp IceBells 4 4
51 Cp Digi Bell 1 1
52 Cp Marimbell 3 4
53 Or 16+8+5&1/3 4 4
54 Or Petit 1 1
55 Or Glassy 4 4
56 Or Jazzy 4 4
57 Or Slow Jam 3 3
58 Or Greasy 4 4
59 Or Swishie 2 2
60 Or Clean 2 2
61 Or Full/CVib 2 2
62 Or Mellow 2 1
63 Or Nu Shade 3 3
64 Or Cool Cat 4 4
65 Or Flutey 1 1
66 Or LeftManual 4 4
67 Or DrawContrl 4 4
68 Or Rocky 4 4
69 Or Expensive 4 4
70 Or Progressy 3 3
71 Or Crunchy 4 4
72 Or Early Bird 4 4
73 Or Jazz Split 4 2
74 Or GosplSplit 4 3
75 Or Tradi 4 4
76 Or Sunday 3 4
77 Or BreathPipe 4 5
78 Or Fluty Pipe 3 3
79 Or Reedy Pipe 3 4
80 Pd OohPipes 4 6
81 Gt Flamenco 4 3
82 Gt Nylon Jam 4 3
83 Gt BriteSteel 2 2
84 Gt Strums 3 3
85 Gt Big Steel 4 4
86 Gt Folk Steel 4 4
87 Gt 18 String 4 4
88 Gt HarpsiGtr 3 3
89 Gt HybridGtr 3 3
90 Gt JazzGTmelo 2 2
91 Gt Velo Jazz 4 2
92 Gt FM Jazz 2 1
93 Gt For Funk 3 3
94 Gt Spanky 2 2
95 Gt Funkiest 4 4
96 Gt Vin Strum 3 3
97 Gt 1CoilChors 2 2
98 Gt CleanChors 4 2
99 Gt ChorusPlus 1 1
100 Gt SmoothChor 3 2
101 Gt TexBoogie 3 3
102 Gt Rockabilly 4 2
103 Gt 65 Combo 3 3
104 Gt VinTremolo 2 2
105 Gt Crunchoid 4 2
106 Gt DynamicAmp 3 3
107 Gt Feedback 3 3
108 Gt VOODOOMAN 2 2
109 Gt BlueLead 4 4
110 Gt MeloRckLd 4 4
111 Gt MetalMute 4 2
112 Gt OverTheTop 4 2
113 Ba RoundWound 3 2
114 Ba FingerMan 2 1
115 Ba PrecRW 3 2
116 Ba PrecFW 2 2
117 Ba HybridBass 4 4
118 Ba Stand Up 3 2
119 Ba Fretless 1 1
120 Ba Slap&Fx 3 2
121 Ba BriteSlap 4 2
122 Ba Velo Bass 4 2
123 Co Bs+Cym+Vb 4 3
124 Ba Boogie on 3 3
125 Ba MiniDetune 2 2
126 Ba Long Spit 3 2
127 Ba Tack Bass 3 3
128 Ba Fat Octave 2 2
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 2 Monday, January 6, 2003 11:10 AM

3
Preset2 (MSB=63, LSB=1)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 St Violin 4 2
2 St Viola 2 2
3 St Cello 3 2
4 St SoloSpicat 3 1
5 St 2 Solos 4 4
6 St Cello Duet 4 4
7 St Trio 3 3
8 St Chamber 4 4
9 St Small Ens 4 4
10 St Medium Ens 4 4
11 St Ens Mix 1 2
12 St Ensemble 1 2
13 St Hard Ens 2 2
14 St Background 3 5
15 St BigSymphny 3 4
16 Br Str/Horns 4 6
17 St Stringy 2 4
18 St Polystring 2 3
19 St JP Strings 2 2
20 St MournStrgs 2 3
21 St The Pizz 4 4
22 Br Fanfare 3 3
23 Br Hi Brass 3 3
24 Br Fat Sect 2 2
25 Br Sforzando 3 4
26 Br Symphony 4 5
27 Br Big Band 3 3
28 Br Big Band 2 4 5
29 Br SaxBigBand 3 4
30 Br MedmBrass 3 3
31 Br Soft Brass 3 3
32 Br SoftVeloBr 4 2
33 Br TrpRomantc 2 2
34 Br Phase Mute 3 1
35 Br Legend 2 2
36 Br Trombone 2 1
37 Br Flugelleaz 4 2
38 Br F.Horn Ens 4 4
39 Br SlowAttack 4 5
40 Br Strng/Bras 4 4
41 Br Movie Ens 4 6
42 Br Powered 3 3
43 Br ObStuff 3 3
44 Br Prophy 3 3
45 Br AnalogBras 3 3
46 Br After 1984 4 4
47 Rp Soprano 3 3
48 Rp Alto Vib 3 2
49 Rp SaxEnsembl 4 4
50 Rp Tenor Sax 4 2
51 Rp Tenor Soft 4 3
52 Rp The Winds 4 3
53 St WindOrch 4 5
54 Rp SweetFlute 3 1
55 Rp PanBottle 4 3
56 Rp AmpHarpMW 2 2
57 Ld SmoothSaw 2 2
58 Ld Lucky 2 2
59 Ld Tri Solo 1 1
60 Ld Syntrump 1 1
61 Ld PWM Lead 2 2
62 Ld Clicky Saw 4 4
63 Ld Mini Pulse 2 2
64 Ld Sync Lead 2 2
65 Pd Altair 3 6
66 Pd Analog 2 2
67 Pd Sweetland 4 5
68 Pd WarmSweepy 1 1
69 Pd SinePad 2 2
70 Pd Square 2 2
71 Pd VoxPad 4 4
72 Pd Pure Syn 2 2
73 Pd MovingPad 2 4
74 Pd SimpleSaws 3 3
75 Pd X-Shower 2 2
76 Pd PWM Pad 3 3
77 Pd Bell Choir 3 3
78 Pd ObSoft 3 3
79 Pd MellowAnlg 2 2
80 Pd Glasschoir 4 4
81 Pd PeaceVox 2 2
82 Pd StackChoir 4 3
83 Pd Bronx 4 4
84 Pd IceChoir 4 7
85 Pd Fast Oohs 2 4
86 Pd Ooze & OZ 4 5
87 Pd NeoCrystal 4 4
88 Pd Pop Synth 2 2
89 Pd Fantasy 4 6
90 Pd Heavenly 4 4
91 Pd Retro 2 3
92 Pd Airy Nylon 4 6
93 Pd Antares 3 3
94 Pd Pan Sphere 4 6
95 Pd Tamburax 2 2
96 Pd IndianFlai 4 5
97 Me SAKURA 4 4
98 Me RisingHigh 3 2
99 Me Champ 4 4
100 Me Gladiator 4 4
101 Me Hades 4 4
102 Me Glacy 4 4
103 Me Forest 4 5
104 Me MirrorRing 3 3
105 Sc Poly 1 1
106 Sc AnaTonk 2 2
107 Gt Jaipur 4 3
108 Gt Dulcitar 2 2
109 Cp Cimbalon 3 3
110 Rp EthncFlute 4 3
111 Rp Hichiriki 2 1
112 Rp Ryuteki 3 3
113 Rp Gagaku 4 2
114 St Kokyu 2 1
115 Rp Digidoo 3 2
116 Dr Bali 4 3
117 Gt Indo 4 1
118 Dr Trip East 3 3
119 Dr Tabla 4 2
120 Dr Djembe 3 1
121 Cp Djerimbe 2 1
122 Dr Udu 4 2
123 Dr Tribal 4 4
124 Cp Log&Drum 3 3
125 Dr Afro 3 2
126 Co Japanesque 2 2
127 Me EthnoShock 4 4
128 Dr Ethnology 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 3 Monday, January 6, 2003 11:10 AM

4
Preset3 (MSB=63, LSB=2)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap Wide Comp 3 3
2 Ap 78rpmPiano 4 2
3 Ap Bristol 2 2
4 Ap Mono Comp 4 1
5 Ap Dance 2 3
6 Ap Houze 4 4
7 Kb Glass EP 3 3
8 Kb VintSwitch 3 1
9 Kb Early Case 3 1
10 Kb RdsScape 3 3
11 Ap RichEcho 3 3
12 Kb StringyPno 2 2
13 Or Champagne 2 2
14 Or Moet 2 2
15 Or Compact 4 2
16 Or 1967 Keys 4 1
17 Or YD-45C 4 3
18 Ba Gnarly 2 2
19 Ba Modular 3 3
20 Ba Dark Jack 1 1
21 Ba OneVoice 1 1
22 Ba Dry Syn 1 1
23 Ba PlasticBas 4 4
24 Ba Bassline 1 1
25 Ba RubbaRap 2 2
26 Ba Juicy 1 1
27 Ba Dark 1 1
28 Ba UniBass 1 1
29 Ba Flyer 2 2
30 Ba QuackBass 4 4
31 Ba Moonbass 1 1
32 Ba ClassicSub 2 2
33 Ba DX100 4 2
34 Ba Lately 2 2
35 Ba FMBass 1 1
36 St Oct String 4 4
37 St 3 Octave 4 4
38 St TapeStrngs 3 3
39 St VP Strings 1 2
40 Br BriteTeeth 2 2
41 Br XDance 2 2
42 Br Timeless 2 2
43 Br FatSynth 2 2
44 Br Big Syn 2 2
45 Rp Bluesharp 1 1
46 Ld Sync 2 2
47 Ld Atk Reso 2 2
48 Ld Singleline 3 2
49 Ld Free LFO 1 1
50 Ld Soft Lead 3 3
51 Ld PulseWound 1 1
52 Ld Big Drone 4 4
53 Ld Big Tune 4 4
54 Ld PowerWheel 4 4
55 Ld Flangefilt 2 2
56 Ld G-Funk 1 1
57 Ld Maria AT 1 1
58 Ld InThePast 2 2
59 Pd FatSawPad 2 2
60 Pd Wide Sweep 2 2
61 Pd Sunbeams 4 4
62 Pd BPFx 3 3
63 Pd FrozenPad 4 4
64 Pd MICHINOKU 1 1
65 Pd Esmeralda 4 4
66 Pd Romance 4 4
67 Pd Circle 2 2
68 Pd Dreamspher 3 3
69 Pd Silverlake 4 4
70 Pd Shadow 3 3
71 Pd Platinum 3 2
72 Pd Gently 3 4
73 Pd Warming 3 3
74 Pd PW-EMMY 3 3
75 Pd X-fade Pad 4 4
76 Pd Zosma 4 4
77 Pd NoizRezz 2 2
78 Pd Mira 3 3
79 Pd MultiPulse 4 4
80 Pd VoxWaves 4 3
81 Pd LazySweep 3 4
82 Pd Doomed 4 3
83 Sc PerkaVox 2 2
84 Sc Punchy 1 1
85 Sc Eyeliner 2 2
86 Me Quieck 4 4
87 Me Aladdin 2 2
88 Me QuadSwell 4 4
89 Me Lilley Pad 4 6
90 Me Didje Baz 3 4
91 Me RING PAD 4 4
92 Me Chaser 1 3 3
93 Me Chaser 2 4 4
94 Me Spacebreat 4 4
95 Me Long HiPa 4 4
96 Me Action Y 4 4
97 Me Trancelan 2 2
98 Me Eternal 2 2
99 Me VirtualSyn 2 2
100 Me Interlude 3 2
101 Me Flying 3 3
102 Me TheSlayer 3 3
103 Me White Rabb 4 4
104 Me Siam 1 1
105 Co Ududu 2 2
106 Co Particle 2 2
107 Co Shaper 2 2
108 Co VintageArp 2 2
109 Co Aah Dance 4 6
110 Co Joker 1 1
111 Co Holiday 4 4
112 Co Android 3 3
113 Co Spacious 4 4
114 Co VoiceCuica 2 1
115 Co Pop Arp 2 2
116 Co Ping Pong 1 1
117 Se Amoeba 1 1
118 Se Landing 4 4
119 Se I was born 3 3
120 Se PsychoGtr 3 3
121 Se NoGravity 1 1
122 Se Pulser 1 1
123 Se Racer 2 2
124 Se Storm 4 4
125 Se Oscillatin 2 2
126 Se FamlyFeud 4 1
127 Se WatrForest 3 3
128 Se Spacecraft 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 4 Monday, January 6, 2003 11:10 AM

5
Preset 4 (MSB=63, LSB=3)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap MultcmpPno 4 2
2 Ap Light 4 2
3 Ap ConcrtGrnd 4 2
4 Ap Balld Stck 1 2
5 Ap Hard CP80 4 1
6 Ap StereoComp 4 2
7 Ap MetalPiano 3 3
8 Ap Old Piano 4 2
9 Ap Diablo 4 2
10 Kb Satellite 4 1
11 Kb SummerTime 4 2
12 Kb SparkleTin 3 2
13 Kb Tine E 2 2
14 Kb Mr. Klank 2 2
15 Kb DX7+Pad 4 3
16 Kb PluckBells 3 3
17 Kb RetroWurli 4 2
18 Kb DampedClav 2 2
19 Kb Dummy 4 1
20 Kb Neo Soul 2 1
21 Kb EpfCrusher 2 2
22 Kb PlukdThing 3 3
23 Kb Hiss Pad 2 2
24 Cp GlassBells 4 4
25 Cp YumiBell 1 1
26 Cp Pad Bells 4 5
27 Cp EthnoStone 2 2
28 Cp BellsAbuzz 2 2
29 Cp Icey Vibe 2 2
30 Cp Gongladeer 1 2
31 Cp ScaryNight 4 2
32 Or MoreDrwbrs 4 4
33 Or Soulemn 3 3
34 Or Green 1 1
35 Or JimyPercC3 2 2
36 Or Dirt Organ 2 2
37 Or Vint Drive 1 1
38 Or Yoshi Perc 3 3
39 Or Big Track 2 2
40 Or Circus 2 3
41 Or Mikuni’sFI 3 3
42 Or Elemental 2 2
43 Or Farfasso 4 2
44 Or Willis 2 2
45 Or Reed 2 2
46 Or Partita 1 2
47 Gt Policia 2 2
48 Gt Jazzmaster 2 2
49 Gt Trip Rotor 1 1
50 Gt Radio Cmp2 2 2
51 Gt Simple WAH 1 1
52 Gt Wah-Riff 3 3
53 Gt Guitar&Pad 4 4
54 Gt Coral 4 2
55 Gt Harp 2 2
56 Gt RnB Harp 1 1
57 Ba Precsn Cmp 1 1
58 Ba TubeFinger 1 1
59 Ba Finger Amp 1 1
60 Ba It'sRounda 2 2
61 Ba NoResBass 1 1
62 Ba Fat Sine 4 4
63 Ba Wobble 2 2
64 Ba Decor 1 1
65 Ba Thump 2 2
66 Ba EmFunk 1 1
67 Ba FatOctaRes 3 3
68 Ba Org Bass 1 1
69 Ba FM Klick 2 2
70 Ba Fat Low 2 2
71 Ba SimplePowr 1 1
72 St VeloString 3 5
73 St NoSofia St 1 2
74 St HoodStrngs 3 4
75 St FullStrngs 3 4
76 St Chamber AT 2 2
77 St Big Swell2 2 3
78 St BlueString 2 3
79 St Old String 2 3
80 St 78rpmStrgs 1 1
81 St Ens+Flute 3 3
82 St Bells&Bows 4 6
83 St The Pad 1 2
84 St Full PWM 4 4
85 Br HybridSect 2 3
86 Br TaniBrass 4 5
87 Br Hybrid 3 4
88 Br F HornSec2 3 3
89 Br Hi Brass 2 3 3
90 Br Brassy 2 2
91 Br Hybri Pad 3 3
92 Br Oberhorns 2 2
93 Br PiccoloTpt 3 2
94 Br Flugelist 2 2
95 Rp Soprano 3 2 2
96 Rp 4Brothers 4 3
97 Rp Antique 1 1
98 Rp Flutter Fl 4 3
99 Rp Real Flute 2 2
100 Rp Querfloete 1 1
101 Rp Oboe+EHorn 3 3
102 Rp FluteChord 4 4
103 Ld Mini Soft 2 2
104 Ld Portatone 3 3
105 Ld Sine Ld 2 1 1
106 Ld Bare Saw 1 1
107 Ld Green Eyes 1 1
108 Ld inda Night 1 1
109 Pd Shine on 2 2
110 Pd Simp. Pad 1 1
111 Pd Voxxaire 2 3
112 Pd Angelvoice 2 3
113 Pd Shangralo 2 2
114 Pd Warm PWM 2 2
115 Pd Balcony 4 4
116 Pd Alabaster 2 3
117 Pd BackPad MW 2 2
118 Pd Dark Tower 1 1
119 Sc Basic Poly 1 1
120 Sc Straight 3 3
121 Sc Soleil 3 5
122 Sc Ana Synth1 2 2
123 Sc PopularSyn 3 3
124 Co For Bertje 2 2
125 Co Udu Too 2 2
126 Co Funky Mood 3 3
127 Co Step Down 1 2
128 Co Shantasma 4 4
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 5 Monday, January 6, 2003 11:10 AM

6
Preset 5 (MSB=63, LSB=4)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co Gruvmaster 2 2
2 Co ANbasicARP 2 2
3 Co Europa 3 3
4 Co Q Machine 3 3
5 Co Happy Boy 4 6
6 Co X-Pulsar 2 2
7 Co Tekno Spy 4 4
8 Co Tuff Arp 2 2
9 Co Polygroove 4 4
10 Co OrangeMW 3 3
11 Co Hip Chordz 2 2
12 Co Em Arp 2 2
13 Co LostIsland 4 4
14 Ba Bobby Bass 2 2
15 Ba RnBass 2 2
16 Ba SimpleBss2 2 2
17 Ba SimpleReso 2 1
18 Ba BobbyJuice 1 1
19 Ba Bass&Comp! 4 4
20 Ba TranceBass 2 2
21 Ba Emlate 1 1
22 Ba Velomaster 1 1
23 Ba Kick Bass 3 3
24 Ba Hollow 2 2
25 Ba Em Bass 1 1
26 Ba Oxide 2 2
27 Ba Acidd 3 3
28 Ba Pirate 1 1
29 Ba AgressoFx 1 1
30 Ba LOFI-BASS 2 2
31 Ba Quack 1 1
32 Ba ConeFlappe 4 4
33 St Warmest 2 2
34 St FatStrings 3 3
35 St Superstrgs 3 4
36 St JupiterStr 1 1
37 St MIDIPAD 2 2
38 Br AKIRABRASS 2 2
39 Br TV Brass 4 2
40 Br Oberbrass 3 3
41 Br Thinth 2 2
42 Br Trendy 3 3
43 Ld Tech Lead 1 1
44 Ld PulseWidth 1 1
45 Ld Mr. Finger 2 2
46 Ld Punch Lead 2 2
47 Ld GOA LEAD 3 3
48 Ld I.C.U.2. 1 1
49 Ld Space Lead 2 2
50 Ld Lead Wait 4 4
51 Ld Pig Lead 3 3
52 Ld Chordz 4 4
53 Pd Twilight 3 2
54 Pd VDU Pad 3 3
55 Pd HPF+LPFpad 2 2
56 Pd Sonar Pad 4 5
57 Pd Whisperer 3 3
58 Pd Flangerous 2 2
59 Pd Sadness 2 3
60 Pd Super Back 2 2
61 Pd Bastille 3 4
62 Pd Fat Swell 2 2
63 Pd Pad&Syn 4 4
64 Pd Eurostar 3 3
65 Pd Pretty far 4 4
66 Pd Needles 3 3
67 Pd VectorPad1 3 3
68 Pd Wake Up 3 3
69 Pd Ether 4 4
70 Pd Spiralised 4 4
71 Pd RezSinePad 1 2
72 Pd Granular 3 3
73 Pd Ropey 4 4
74 Pd Smear 3 3
75 Pd Mizar 3 3
76 Pd Homesick 3 4
77 Pd Lost. 2 2
78 Pd Haunting 1 1
79 Pd Infant 3 2
80 Pd High Sine 2 2
81 Pd Sm.OrganPd 2 2
82 Pd Chianti 4 4
83 Pd Guitar Pad 4 4
84 Pd Tuscan 3 4
85 Pd Shuttle 4 4
86 Pd Ether 2 4 4
87 Sc Sine Comp 3 1
88 Sc Queens 3 3
89 Sc Kairo 4 5
90 Sc Synes XL 4 4
91 Sc FaaatDance 2 2
92 Sc Random LFO 1 1
93 Sc Vacuum 4 4
94 Sc RezzPunch 4 4
95 Sc Kordal MW 2 2
96 Sc M-Trance 2 2
97 Sc Euro 4 4
98 Sc DX Metal 2 2
99 Me Atlantis 4 4
100 Me Meteors 3 3
101 Me Girlfriend 2 4
102 Me Nebula AT 2 2
103 Me CosmicRain 4 4
104 Me Contact 3 3
105 Me Dalahi 3 4
106 Me CrushpadMW 4 4
107 Me Ar-tic 3 3
108 Me Alaska 4 6
109 Me Clusters 4 4
110 Me Glister 4 4
111 Me SliceIt Up 2 2
112 Me Chaser 3 4 4
113 Me Surface 4 6
114 Me Stalagtite 3 3
115 Me 4ling Star 4 4
116 Me Old Skool 3 3
117 Me Katsu 3 3
118 Me Genie 2 2
119 Se Dream Text 4 4
120 Se Ambi Rain 1 1
121 Se Bitzz MW 1 1
122 Se JumpQ MW 1 1
123 Se Molt 1 1
124 Se Samsara 1 1
125 Se FX-MWSweep 2 2
126 Se Static 2 2
127 Dr Wriggle 3 3
128 Dr Kraftbeat 4 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 6 Monday, January 6, 2003 11:10 AM

7
GM (MSB=0, LSB=0)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Ap NaturlGrnd 4 2
2 Ap Rock Brite 2 1
3 Ap CP 2001 4 1
4 Ap Honkytonk 4 2
5 Kb E.Piano 1 4 1
6 Kb E.Piano 2 2 2
7 Kb Harpsicord 1 1
8 Kb Brite Clav 4 2
9 Cp Celeste 3 3
10 Cp Glocken 4 2
11 Cp Music Box 3 3
12 Cp Vibes 4 2
13 Cp Marimba 3 1
14 Cp Xylophone 2 2
15 Cp TublarBell 4 3
16 Cp Dulcimar 2 2
17 Or Draw Organ 2 2
18 Or Perc Organ 3 2
19 Or Rock Organ 2 2
20 Or ChurchOrgn 2 3
21 Or Reed Organ 4 2
22 Kb Accordion 1 1
23 Rp Harmonica 1 1
24 Kb TangoAccrd 1 1
25 Gt Nylon 2 2
26 Gt Steel 1 1
27 Gt ModernJazz 3 2
28 Gt Clean 1 1
29 Gt Mute 2 2
30 Gt Overdrive 2 2
31 Gt Distortion 3 2
32 Gt Harmonics 2 2
33 Ba Accoustic 2 2
34 Ba FingerBass 2 2
35 Ba Pick Bass 1 1
36 Ba Fretless 2 1 1
37 Ba SimpleSlap 3 2
38 Ba Velo Slap 4 1
39 Ba SynthBass1 4 2
40 Ba SynthBass2 2 2
41 St Violin 2 4 2
42 St Viola 2 4 1
43 St Cello 2 2 2
44 St Contrabass 4 2
45 St TremoloStr 2 2
46 Gt Pizz 2 1
47 Gt Harp 3 2
48 Cp Timpni+Cym 3 2
49 St StereoSt1 1 2
50 St StereoSt2 2 2
51 St Grand Saw 3 3
52 St SynStrings 3 3
53 Pd Aah Choir 1 2
54 Pd Ooh Choir 1 2
55 Pd Syn Voice 2 3
56 Me Orch.Hit 2 2
57 Br Trumpet 3 1
58 Br Trombone 2 1 1
59 Br Tuba 2 1
60 Br MuteTrpt 2 1 1
61 Br F.Horns 2 2
62 Br Brass Sect 3 3
63 Br SynthBrass 3 3
64 Br Soft Brass 3 3
65 Rp Soprano 2 2 2
66 Rp Alto Sax 2 2
67 Rp TenorSax 2 3 2
68 Rp Bari Sax 3 2
69 Rp Oboe 1 1
70 Rp Eng.Horn 2 1
71 Rp Bassoon 2 2
72 Rp Clarinet 1 1
73 Rp Piccolo 2 1
74 Rp Flute 3 2
75 Rp Recorder 2 2
76 Rp Panflute 1 1
77 Rp Bottle 3 2
78 Rp Shakuhachi 2 2
79 Rp Whistle 2 2
80 Rp Ocarina 2 2
81 Ld Square Ld 2 2
82 Ld Saw Ld 4 2
83 Ld Caliop Ld 3 2
84 Ld Chiff Ld 1 1
85 Ld Charan Ld 2 2
86 Ld Voice Ld 2 4
87 Ld Fifth Ld 2 2
88 Ld Bass&Ld 1 1
89 Pd New Age 2 2
90 Pd Warm Pad 2 2
91 Pd Poly Synth 2 2
92 Pd Choir Pad 2 3
93 Pd BowedPad 2 2
94 Pd Metal Pad 2 2
95 Pd Halo Pad 2 3
96 Pd Sweep Pad 2 2
97 Me Rain Pad 2 2
98 Pd SoundTrack 2 3
99 Cp Crystal 2 3
100 Pd Atmosphere 2 3
101 Sc Brightness 3 2
102 Me Goblin 3 2
103 Me Echoes 2 4
104 Pd Sci-Fi 2 2
105 Gt Sitar 1 1
106 Gt Banjo 2 1
107 Gt Shamisen 2 1
108 Gt Koto 1 1
109 Cp Kalimba 2 2
110 Rp Bagpipe 2 2
111 St Fiddle 4 2
112 Rp Shanai 3 2
113 Cp Tinkerbel 4 2
114 Dr Agogo 1 1
115 Cp Steeldrum 3 2
116 Dr Woodblock 1 1
117 Dr Taikodrum 2 2
118 Dr MelodicTom 2 1
119 Dr Synth Drum 2 1
120 Se Rev Cymbal 1 1
121 Se Fret Noise 1 1
122 Se BreathNoiz 2 1
123 Se Seashore 2 2
124 Se Tweet 1 1
125 Se Telephone 1 1
126 Se Helicopter 2 2
127 Se Applause 2 2
128 Se Gunshot 1 1
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 7 Monday, January 6, 2003 11:10 AM

8
User1 (MSB=63, LSB=8)
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co M25 M.W. 3 3
2 Pd Softstars 3 3
3 Ba Fast PWM 2 2
4 Ba Terminator 3 3
5 Me Soft Tar 4 4
6 Co Sorted 4 4
7 Ba Trendy Wah 3 3
8 Se Feed S&H 1 1
9 Me Didge 4 4
10 Ba Old House 4 4
11 Ld HPF Dance 1 1
12 Me Like Bees 4 4
13 Ba Exodus 3 3
14 Me S/H Gruv 4 5
15 Gt Funk It!! 2 1
16 Co Opening 4 4
17 Co DigDag 2 2
18 Pd Dark Light 2 2
19 Ba Boom Bass 2 2
20 Se Dirtbox 2 2
21 Pd Shandala 3 3
22 Co Titan 4 4
23 Ba Puls Step 2 2
24 Co Racket 2 2
25 Ld Big Lead 3 3
26 Ba Blush 2 2
27 Ld Squeaky 2 2
28 Se Duck Worm 1 1
29 Ba Jon 3 3
30 Co Weird scar 3 3
31 Gt Auto Wah 2 2
32 Co MINIMAL 3 3
33 Co MGul 4 4
34 Pd BrokenStar 3 5
35 Ba Smooth 2 2
36 Se Sawmill 4 4
37 Me Cavern 3 3
38 Co Supersnap 4 4
39 Ba Fuzzline 2 1
40 Ld Foreplay 1 1
41 Or Brooklyn 2 2
42 Ba Brief 2 2
43 Ld Dist-MW 3 3
44 Me Hit&Down 2 1
45 Ba Froglegs 4 4
46 Me Sand 2 2
47 Gt R&B Steel 2 2
48 Co Rabbit 1 1
49 Co ElecWorld 4 4
50 Me Sickday 4 4
51 Ba LoSnake 1 1
52 Se Boomeran 4 4
53 Me O+Ca+Si+Na 3 3
54 Co Space Run 2 2
55 Ba Additive 2 2
56 Ld Rap Lead 1 1 1
57 Me Nordic 3 3
58 Ba Hip Aco 4 3
59 Ld Mr. Cool 4 4
60 Me Orch Hits 4 1
61 Ba Damp Cat 2 2
62 Me FISHINREEL 4 4
63 Gt Melo Trmlo 1 1
64 Sc Fois Gras 2 2
65 Kb CheapEP 1 1
66 St AnaMarcato 4 4
67 Ba G Bass 2 2
68 Se Dolphin 4 3
69 Me Evolve 4 4
70 Me ARRIVAL 4 5
71 Ba Wazzo 2 2
72 Ld Rap Lead 2 1 1
73 Me Richard 4 4
74 Ba Hip Pick 2 2
75 Ld Early Lead 2 2
76 Se BDScrtch 4 1
77 Ba Dukes 4 4
78 Ld Mayday MW 1 1
79 Gt CoolWAH 2 2
80 Sc Mascara 3 2
81 Kb HipWahEP 1 1
82 Br ChorusComp 2 2
83 Ba Compton 2 2
84 Se Red Dots 1 1
85 Pd Fragile 3 3
86 Me SpookyVibe 2 2
87 Ba Gangsta 3 3
88 Ld Rap Lead 3 1 1
89 Sc 81Z Comp 2 2
90 Ba DarkBass 2 2
91 Ld HiPaWheel 1 1
92 Se Rap Scream 1 1
93 Ba InyerBass 3 3
94 Ld Pierced 2 2
95 Gt Hip Mute 2 2
96 St Hip Pizz 4 4
97 Kb R&B EP+DX 2 2
98 Br Kustom 3 3
99 Ba PortaBass 2 2
100 Se Sirens 4 1
101 Me Silver 3 3
102 Me Zanaks 3 2
103 Ba 2001 Sub 1 1
104 Ld Sine Lead 1 1
105 Ba UK Oam 3 3
106 Ba Fooger 2 2
107 Ld D-tune 4 4
108 Se Rap Toyz 4 1
109 Ba Mucus M 4 3
110 Ld Future Z 2 2
111 Gt FM Guitar 4 3
112 Me Trancedot 4 4
113 Me Dead?Alive 4 4
114 St SlowSuckr 4 4
115 Ba Clickk 2 2
116 Se KewBrick 3 4
117 Pd Munchkins 2 1
118 Me Ants 2 1
119 Ba Snoop Bass 2 2
120 Ld BabeMagnet 1 1
121 Ba Jones 3 3
122 Se 100 dreams 2 2
123 Ld FKitchen 2 2
124 Co Rabino 2 2
125 Ba Teknophobe 3 2
126 Me FizzWah 1 1
127 Ld Hip Voice 2 2
128 Me Strobe 3 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 8 Monday, January 6, 2003 11:10 AM

9
User2 (MSB=63, LSB=9)
The factory setting is the same as Preset 5.
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
1 Co Gruvmaster 2 2
2 Co ANbasicARP 2 2
3 Co Europa 3 3
4 Co Q Machine 3 3
5 Co Happy Boy 4 6
6 Co X-Pulsar 2 2
7 Co Tekno Spy 4 4
8 Co Tuff Arp 2 2
9 Co Polygroove 4 4
10 Co OrangeMW 3 3
11 Co Hip Chordz 2 2
12 Co Em Arp 2 2
13 Co LostIsland 4 4
14 Ba Bobby Bass 2 2
15 Ba RnBass 2 2
16 Ba SimpleBss2 2 2
17 Ba SimpleReso 2 1
18 Ba BobbyJuice 1 1
19 Ba Bass&Comp! 4 4
20 Ba TranceBass 2 2
21 Ba Emlate 1 1
22 Ba Velomaster 1 1
23 Ba Kick Bass 3 3
24 Ba Hollow 2 2
25 Ba Em Bass 1 1
26 Ba Oxide 2 2
27 Ba Acidd 3 3
28 Ba Pirate 1 1
29 Ba AgressoFx 1 1
30 Ba LOFI-BASS 2 2
31 Ba Quack 1 1
32 Ba ConeFlappe 4 4
33 St Warmest 2 2
34 St FatStrings 3 3
35 St Superstrgs 3 4
36 St JupiterStr 1 1
37 St MIDIPAD 2 2
38 Br AKIRABRASS 2 2
39 Br TV Brass 4 2
40 Br Oberbrass 3 3
41 Br Thinth 2 2
42 Br Trendy 3 3
43 Ld Tech Lead 1 1
44 Ld PulseWidth 1 1
45 Ld Mr. Finger 2 2
46 Ld Punch Lead 2 2
47 Ld GOA LEAD 3 3
48 Ld I.C.U.2. 1 1
49 Ld Space Lead 2 2
50 Ld Lead Wait 4 4
51 Ld Pig Lead 3 3
52 Ld Chordz 4 4
53 Pd Twilight 3 2
54 Pd VDU Pad 3 3
55 Pd HPF+LPFpad 2 2
56 Pd Sonar Pad 4 5
57 Pd Whisperer 3 3
58 Pd Flangerous 2 2
59 Pd Sadness 2 3
60 Pd Super Back 2 2
61 Pd Bastille 3 4
62 Pd Fat Swell 2 2
63 Pd Pad&Syn 4 4
64 Pd Eurostar 3 3
65 Pd Pretty far 4 4
66 Pd Needles 3 3
67 Pd VectorPad1 3 3
68 Pd Wake Up 3 3
69 Pd Ether 4 4
70 Pd Spiralised 4 4
71 Pd RezSinePad 1 2
72 Pd Granular 3 3
73 Pd Ropey 4 4
74 Pd Smear 3 3
75 Pd Mizar 3 3
76 Pd Homesick 3 4
77 Pd Lost. 2 2
78 Pd Haunting 1 1
79 Pd Infant 3 2
80 Pd High Sine 2 2
81 Pd Sm.OrganPd 2 2
82 Pd Chianti 4 4
83 Pd Guitar Pad 4 4
84 Pd Tuscan 3 4
85 Pd Shuttle 4 4
86 Pd Ether 2 4 4
87 Sc Sine Comp 3 1
88 Sc Queens 3 3
89 Sc Kairo 4 5
90 Sc Synes XL 4 4
91 Sc FaaatDance 2 2
92 Sc Random LFO 1 1
93 Sc Vacuum 4 4
94 Sc RezzPunch 4 4
95 Sc Kordal MW 2 2
96 Sc M-Trance 2 2
97 Sc Euro 4 4
98 Sc DX Metal 2 2
99 Me Atlantis 4 4
100 Me Meteors 3 3
101 Me Girlfriend 2 4
102 Me Nebula AT 2 2
103 Me CosmicRain 4 4
104 Me Contact 3 3
105 Me Dalahi 3 4
106 Me CrushpadMW 4 4
107 Me Ar-tic 3 3
108 Me Alaska 4 6
109 Me Clusters 4 4
110 Me Glister 4 4
111 Me SliceIt Up 2 2
112 Me Chaser 3 4 4
113 Me Surface 4 6
114 Me Stalagtite 3 3
115 Me 4ling Star 4 4
116 Me Old Skool 3 3
117 Me Katsu 3 3
118 Me Genie 2 2
119 Se Dream Text 4 4
120 Se Ambi Rain 1 1
121 Se Bitzz MW 1 1
122 Se JumpQ MW 1 1
123 Se Molt 1 1
124 Se Samsara 1 1
125 Se FX-MWSweep 2 2
126 Se Static 2 2
127 Dr Wriggle 3 3
128 Dr Kraftbeat 4 3
No. Category Voice Name Elements
Maximum
Simultaneous
Elements
MR_DL1.book Page 9 Monday, January 6, 2003 11:10 AM

10
Drum Voice List
Drum Voice Name List
Preset (MSB=63, LSB=32) User (MSB=63, LSB=40)
GM (MSB=127, LSB=0)
PRE No. Kit Name
1 PoweredStd
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 DryStandrd
3 RockSt1
4 RockSt2
5 RockMono1
6 Hip Hop1
7 Hip Hop2
8 HipStick1
9 T9HipKit1
10 R&B Kit1
11 R&B Kit2
12 AnalogT9
13 AnalogT8
14 Tekno Kit
15 House Kit1
16 House Kit2
17 Big Kit
18 Break Kit
19 Drum'nBass
20 Acid Kit
21 Jungle Kit
22 Electric
23 Human Kit
24 Hard Kit
25 DistrtdKit
26 AmbientKit
27 Jazz Kit
28 Hip Hop3
29 Hip Hop4
30 HipStick2
31 Garage
These original drum kits, programmed for the
MOTIF-RACK, feature a special non-standard
order for ease in playing.
32 ALL-ROUND
33 Rock Multi
34 Hip Multi
35 Percussion
These original kits feature a variety of
instruments and special sound effects, and are
grouped according to their type.
36 Latin Perc
37 Gtr/Bs Fx
38 Wacko Kit
39 Wood Bits
40 Metal Bits
41 Hands Kit
42 Scratches
43 AcstSnares
44 StSnares
45 AllKicks
46 DanceKicks
47 Snare & Fx
48 EasySnares
USER No. Kit Name
1 RockMono2
These drum kits have been specially
programmed for different music styles, yet
closely follow the standard instrument order of
the GM kit.
2 RockMono3
3 Hip Hop5
4 Hip Hop6
5 T9HipKit2
6 HipStick3
7 HipStick4
8 R&B Kit3
9 Motor City
10 MW AmpSim
GM Drum No. Kit Name
1 Stereo GM
MR_DL1.book Page 10 Monday, January 6, 2003 11:10 AM
