QUICK-CONNECT GUIDE

YHT-10 Quick-Connect Guide
2
Introduction
Yamaha developed the YHT-10 A/V Home Theater
package to turn your home into a theater. In addition
to enhancing the sound of a video source, like your TV
or VCR, the YHT-10 also superbly reproduces audio
sources, such as a CD player or a cassette deck.
This Quick-Connect Guide will help you get started.
Study the system plan (Figure 1 below), and then use
the wiring diagram (Figure 2 on opposite page) to
connect the speakers to the R-V502 A/V receiver.
For the video portion, you will need a hi-fi stereo VCR or
laser disc player and a television or monitor. Refer to the
Yamaha R-V502 Owner’s Manual, as well as those that
came with your other components, for complete instruc-
tions and cautions. Be sure to turn off all power while
making connections.
NOTE: Label the end of each speaker wire (i.e., left rear, right
front, etc.) before connecting them to the A/V receiver. For wire
runs over 30 feet, use larger 18- or 16-gauge speaker wire.
• Velcro (for secure fastening of NS-AC2 on TV)
• Toggle bolts, molly anchor screws, or sheet metal
screws (for securing NS-A76 speakers to walls)
NOTE: If you are unsure of how to securely and safely fasten
speakers to a wall, please contact a reliable source about the best
type of hanger for your particular wall's construction. Secure
installation is the purchaser's responsibility.
Tools And Parts
The YHT-10 Home Theater package consists of (1) R-V502
A/V receiver, (2) 3-way NS-A636 front-channel speakers
and 16' of speaker wire, (1) NS-AP100 package containing
(1) NS-AC2 2-way center-channel speaker and (2) NS-A76
surround speakers with brackets and 72' of speaker wire,
and related owner’s manuals. You will also need:
• Wire strippers (optional)
System Plan
Figure 1. This overhead view shows a typical system layout
for the YHT-10 Home Theater speaker package.
C
L
NS-A636
(left side, same height as TV)
R
NS-A636
(right side, same height as TV)
S
L = Left Channel
R = Right Channel
C = Center Channel
S = Surround Channel
NS-A76
(on stand or wall, at least
ear level or preferably higher)
S
NS-A76
(on stand or wall, at least
ear level or preferably higher)
8'~10' apart
NS-AC2
(on top or below TV)
6'~8' apart
Couch
Listening Area
Sub
Optional Subwoofer (on floor)

YHT-10 Quick-Connect Guide
3
Wiring Diagram
Figure 2. YHT-10 system wiring diagram.
NS-A76
(Surround Right)
NS-AC2
(Center Channel)
NS-A636
(Front Right Ch.)
NS-A636
(Front Left Ch.)
NS-A76
(Surround Left)
R-V502
A/V Receiver
(Rear Panel)
Red
Wire
Blk
Wire
Clear
Wire
Clear/
Stripe
Wire
Clear
Wire
Clear/
Stripe
Wire
Clear WireClear/Stripe Wire
Red
Wire
Blk
Wire
Speaker
Wiring BLK TERMINAL = (–)
❶ Strip 1⁄4" off ends of speaker wires
❷Push and hold down levers
❸Insert speaker wires and
release levers
❶
❸
❷
RED TERMINAL = (+)

YHT-10 Quick-Connect Guide
4
Consumer Precautions
Read these precautions carefully before operating your
YHT-10 home theater system:
• Since the NS-A76 speakers can be wall mounted, it
is essential that they are firmly secured. Be sure to
consult a reliable source about the best type of
hanger for your particular wall’s construction.
Secure installation is the purchaser’s responsibility.
• Do not attach the NS-A76 speakers to thin plywood
or soft wall surface materials as the screws may tear
free, causing the speakers to fall and be damaged, or
resulting in personal injury.
• Do not fasten the NS-A76 speakers to walls with
nails, adhesives, or other unsafe hardware. Long-
term use and vibrations may cause them to pull free.
• Do not place any speakers where they are liable to be
knocked over or struck by falling objects. Stable
placement will also ensure better sound performance.
• The NS-A636 and NS-AC2 speakers feature a
magnetically-shielded design, but there is still a
chance that placing them too close to a TV might
impair picture color. Should this happen, move the
speakers away from the TV.
• Placing speakers on the same stand or shelf as a
turntable can result in feedback.
• Never touch the woofer or tweeter units with your
hand or expose them to excessive physical shock. If
they are dented or bent, the sound will be distorted.
• Lower the R-V502 receiver volume control before
changing input sources. Never change input sources
(for example, FM to CD) at high listening levels.
Always turn the R-V502 receiver unit off when
installing or removing input cables.
• Any time you note distortion, reduce the volume control
on the R-V502 receiver to a lower setting. Never allow
your power amplifier to be driven into “clipping.”
• Do not attempt to clean the speakers with chemical
solvents, as this might damage the finish. To clean,
wipe with a dry, soft cloth.
• To prevent the enclosure from warping or discolor-
ing, do not place the speakers where they will be
exposed to direct sunlight or excessive humidity.
Specifications
MODEL: NS-A636 NS-AC2 NS-A76
QUANTITY: 212
TYPE: Bookshelf Speaker Center-Channel Speaker Surround, Effects (Pair)
SPEAKER COMPLEMENT: Magnetically-shielded Magnetically-shielded –
8" Woofer 2" x 5" Cone Woofer 5" Full-Range Driver
4" Ferro-Fluid Cooled Midrange – –
3/4" Dome-Type Tweeter 2" Cone Tweeter –
SENSITIVITY: 91 dB/1 W/1 m 90 dB/1 W/1 m 89 dB/1 W/1 m
FREQUENCY RESPONSE: 90 Hz ~ 20 kHz (+ 3 dB) 70 Hz ~ 20 kHz 95 Hz ~ 13 kHz
NOMINAL IMPEDANCE: 8 Ω8 Ω6 Ω
MIN. AMPLIFIER POWER: 10 W 10 W 5 W
MAX. AMPLIFIER POWER: 140 W 80 W 60 W
DIMENSIONS: 16 3 ⁄ 16" H x 10 1 ⁄ 2" W 5 1 ⁄ 4" H x 18 1 ⁄ 8" W 9" H x 6 1 ⁄ 2" W
x 12 1 ⁄ 2" D x 5 1 ⁄ 4" D x 4 3 ⁄ 4" D
WEIGHT: 34 lb pair (boxed) 13 lb (boxed with NS-A76) 13 lb (boxed with NS-AC2)
©1997 YAMAHA ELECTRONICS CORPORATION, USA
6660 Orangethorpe Avenue, Buena Park, CA 90620
PH: [phone]; FAX: [phone]
http://www.yamaha.com
