INTRODUCTION
Yamaha developed the YHT-15 A/V Home Theater
package to turn your home into a theater. In addition
to enhancing the sound of a video source, like your TV
or VCR, the YHT-15 also superbly reproduces audio
sources, such as a CD player or a cassette deck.
This Quick-Connect Guide will help you get started.
Study the speaker system plan (below), and then use
the interconnect diagrams (on the following pages) to
connect the receiver and speakers to your system.
For the video portion, you will need a hi-fi stereo VCR or
laser disc player and a television or monitor. Refer to the
Yamaha R-V503 Owner’s Manual, as well as those that
came with your other components, for complete instruc-
tions and cautions. Be sure to turn off all power while
making connections.
Save this Quick-Connect Guide for future reference.
NOTE: Label the end of each speaker wire (i.e., left rear, right
front, etc.) before connecting them to the A/V receiver. For wire
runs over 30 feet, use larger 18- or 16-gauge speaker wire.
• Velcro (for secure fastening of NS-AC2A on TV)
• Toggle bolts, molly anchor screws, or sheet metal
screws (for securing NS-A76A speakers to walls)
NOTE: If you are unsure of how to securely and safely fasten
speakers to a wall, please contact a reliable source about the best
type of hanger for your particular wall's construction. Secure
installation is the purchaser's responsibility.
TOOLS AND PARTS
The YHT-15 Home Theater package consists of (1) R-V503
A/V receiver with (1) RAV141 remote control, (2) 2-way
NS-A203 front-channel speakers and 16' of speaker wire,
(1) NS-AP101 package containing (1) NS-AC2A 2-way
center-channel speaker and (2) NS-A76A surround
speakers with brackets and 72' of speaker wire, (1) YST-
SW40 Powered Subwoofer, and related owner’s manuals.
You will also need:
• Wire strippers (optional)
SPEAKER SYSTEM PLAN
C
L
NS-A203
(left side, same height as TV)
R
NS-A203
(right side, same height as TV)
S
L = Left Channel
R = Right Channel
C = Center Channel
S = Surround Channel
NS-A76A
(on stand or wall, at least
ear level or preferably higher)
S
NS-A76A
(on stand or wall, at least
ear level or preferably higher)
8'~10' apart
NS-AC2A
(on top or below TV)
6'~8' apart
Couch
Listening Area
Sub
YST-SW40 Subwoofer (on floor)

YHT-15 QUICK-CONNECT GUIDE
2
CONNECTING AUDIO COMPONENTS
Yamaha R-V503 Receiver (Rear Panel)
NOTE: For your convenience, the Yamaha R-V503 receiver is equipped with two
switched AC outlets (100 W max.). If desired, use them to power on connected
components (e.g., CD player or turntable) each time the receiver is turned on.
However, do not use them for components equipped with clocks (e.g., VCR).
PHONO TAPE
( MD )
TAPE
PB
REC
OUT
AUDIO SIGNAL
GND
CD
L Out
Ground
Use RCA Audio Cables For Audio Interconnections
R Out
L Out R Out
L Out* R Out*
* Use Playback Or Line Out
** Use Line In
L In** R In**
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
Turntable
CD Player (Changer)
Cassette Deck
R
L
R
L
R
L

YHT-15 QUICK-CONNECT GUIDE
3
CONNECTING THE YHT-15 SPEAKERS
NS-A76A
(Surround Right)
NS-AC2A
(Center Channel)
NS-A203
(Front Right Ch.)
NS-203
(Front Left Ch.)
NS-A76A
(Surround Left)
Yamaha R-V503
A/V Receiver
(Rear Panel
Speaker Terminals)
Set IMPEDANCE Selector
to top position
R
++−− L
RL
++−
Rear
Center
YST-SW40
(Subwoofer)
Red
Wire
Blk
Wire
Clear
Wire
Clear/
Stripe
Wire
Clear
Wire
Clear/
Stripe
Wire
Clear
Wire
Clear/
Stripe
Wire
Red
Wire
Blk
Wire
LR
LR
From Amplifier
To Speakers
+−− +
+−− +
Speaker
Wiring
BLK TERMINAL = (–)
❶Strip 1⁄4" off ends of speaker wires
❷Push and hold down levers
❸Insert speaker wires and
release levers
❶
❸
❷
RED TERMINAL = (+)

YHT-15 QUICK-CONNECT GUIDE
4
CONNECTING VIDEO CABLES FOR VIDEO COMPONENTS
Yamaha R-V503 Receiver Rear Panel
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line switch (on the VCR) to Line
position to record from another source connected to the Yamaha R-V503 receiver.
MONITOR
OUT
VIDEO IN OUTVCR
VIDEO SIGNAL
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
Use RCA Video Cables And Jacks For Video Interconnections
Optional 75-ohm Coaxial Cable
VCR
DVD or LD Player (or
Video Game Player)
Video In Video Out
Video Out
Video InANT In
ANT Out
(RF Out)
Monitor/TV

YHT-15 QUICK-CONNECT GUIDE
5
CONNECTING A 5.1-CHANNEL DECODER
If you own a 5.1-channel decoder (or a unit which
incorporates a 5.1-channel decoder), you can connect
its discrete outputs to the R-V503 as shown below.
• To hear playback of a stereo or mono audio source
or one encoded with Dolby Pro Logic Surround*,
connect the unit (e.g., DVD player) to the DVD/LD
(or TV/DBS) AUDIO SIGNAL input terminals.
• The discrete signals feeding to the R-V503 cannot be
recorded by a tape deck, MD recorder, or VCR. To
record programs from a source (e.g., laserdisc
player), connect the source unit to the DVD/LD (or
TV/DBS) AUDIO SIGNAL input terminals.
• If your audio system does not include a subwoofer
(i.e., SUBWOOFER input terminals are not used), set
signal routing on the 5.1-Channel Decoder so that
the LFE channel feeds both LEFT and RIGHT MAIN
output terminals. For details, refer to the owner's
manual for your 5.1-Channel Decoder unit.
*Dolby Pro Logic Surround is a trademark of Dolby Laboratories Licensing Corp.
Yamaha R-V503 Receiver Rear Panel
R
L
V
VIDEO
R
MAIN
VIDEO
SUR
6CH
DISCRETE
INPUT
LR LC SUB
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
Use an RCA Video Cable And Jacks For Video Interconnections
Digital Audio Cable
(Optical or Coaxial)
DVD Player
Audio L Out Audio R Out
L Main Out
R Main Out
L Sur Out
Sub Out
Center Out
R Sur Out
Video Out
5.1-Channel Decoder

YHT-15 QUICK-CONNECT GUIDE
6
CONNECTING A DVD PLAYER WITH BUILT-INDOLBY DIGITAL (AC-3)* DECODER
*Dolby Digital and AC-3 are trademarks of Dolby Laboratories Licensing Corp.
Yamaha R-V503 Receiver Rear Panel
R
L
V
VIDEO
R
MAIN
VIDEO
SUR
6CH
DISCRETE
INPUT
LR LC SUB
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
Use an RCA Video Cable And Jacks For Video Interconnections
DVD Player
Mixed Audio L Out
Mixed Audio R Out
L Main Out
R Main Out
L Sur Out
Sub Out
Center Out
R Sur Out
Video Out

YHT-15 QUICK-CONNECT GUIDE
7
CONNECTING AUDIO CABLES FOR VIDEO COMPONENTS
Yamaha R-V503 Receiver (Rear Panel)
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line switch (on the VCR) to Line
position to record from another source connected to the Yamaha R-V503 receiver.
VIDEO VCRIN OUT
AUDIO SIGNAL
Audio
L Out
Audio
R Out
Audio
L In
Audio
R In
Use RCA Audio Cables And Jacks For Audio Interconnections
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
R
L
R
L
Audio L Out
Audio R Out
VCR
DVD or LD Player (or
Video Game Player)

YHT-15 QUICK-CONNECT GUIDE
8
CABLE HOOK-UP(BASIC AND PREMIUM CHANNELS)
Yamaha R-V503 Receiver (Rear Panel)
NOTE: When using a hi-fi stereo VCR, set the Tuner/Line switch (on the VCR) to Line
position to record from another source connected to the Yamaha R-V503 receiver.
IN OUTVCR
VIDEO SIGNAL
VCRIN OUT
AUDIO SIGNAL
R
L
IN OUTVCR
VIDEO SIGNAL
VCRIN OUT
AUDIO SIGNAL
R
L
Audio
L In
Audio
R In
Audio
L Out
Audio
R Out
RCA Audio Cables
ANT In Video Out
Video In
Basic Cable
(From Wall Jack)
ANT In
Premium Cable
(From Wall Jack)
(Channel 3 or 4
Output)
OR
RCA Cable Color Codes
Yellow = Video
White = Left Audio
Red = Right Audio
RCA Video Cables
Audio
L In
Audio
R In
Audio
L Out
Audio
R Out
RCA Audio Cables
Video Out
Video In
RCA Video Cables
VCR
VCR
(Tuner set to Channel 3 or 4)
Descrambler
Converter
Box

YHT-15 QUICK-CONNECT GUIDE
9
PROGRAMMING THE REMOTE CONTROL (RAV141)
POWER ON
1. Load the supplied batteries into the remote control.
2. Aim the unit at the receiver, press RECEIVER/TUN,
and then press POWER.
3. The receiver should turn on.
SETTING UPYOUR TV
1. Look up a setup code for your television set (see
pages 12 and 13).
2. Turn on the television set.
3. On the remote control, press TV; then press and
hold SETUP until the indicator LED flashes twice.
4. Using the keypad, enter the three-digit number.
The indicator LED will flash twice after your entry.
5. The TV’s controls are now assigned to the remote
control buttons (see Quick Reference Card for use).
To test the code, press TV and then POWER. If the
TV does not respond, try an alternate code.
SETTING UPYOUR CABLE BOX (OR DSS)
1. Look up a setup code for your cable box or digital
satellite system (see pages 11 and 12).
2. Turn on the cable box (or DSS).
3. On the remote control, press CBL/DSS; then press and
hold SETUP until the indicator LED flashes twice.
4. Using the keypad, enter the three-digit number.
The indicator LED will flash twice after your entry.
5. The unit’s controls are now assigned to the remote
control buttons (see Quick Reference Card for use).
To test the code, press CBL/DSS and then POWER.
If the unit does not respond, try an alternate code.
SETTING UPYOUR VCR
1. Look up a setup code for your VCR (see pages 13
and 14).
2. Turn on the VCR.
3. On the remote control, press VCR; then press and
hold SETUP until the indicator LED flashes twice.
4. Using the keypad, enter the three-digit number.
The indicator LED will flash twice after your entry.
5. The VCR’s controls are now assigned to the remote
control buttons (see Quick Reference Card for use).
To test the code, press VCR and then POWER. If the
unit does not respond, try an alternate code.
continued on the next page...
The YHT-15 Home Theater package includes the
RAV141 Remote Control. It comes pre-programmed
with factory codes to control your R-V503 receiver
and most Yamaha audio components. To program
other brands of components (i.e., TV, VCR, etc.) or if
your Yamaha unit does not respond, you will need to
program the remote control with the manufacturer’s
codes (listed on pages 11 through 14).
NOTE: The RAV141 is designed to control most major
brands of audio and video components. For other units, use
the original remote control supplied with the product.
Perform the procedure for each component you own.
At the end of step 5, the remote control’s processor will
automatically assign the selected component’s control
functions to its own buttons, ready for your use.
NOTE: To clear the RAV141’s memory and return it to
the factory codes, press and hold SETUP; then enter 9 8 1.
1 2 3
4 5 6
7 8
0
9
DVD
LD
CD TAPE
TUN
RECEIVER
SET
UP PLAY
PRG +
PRG –
POWER
REW
TV
INPUT
PAUSE FF
STOP
DIR A
DIR B
SLEEP
TV
MUTE
TIME/
LEVEL–
DLY/CNT/REAR
TIME/
LEVEL+
UP
LEFT RIGHTMENU
DOWN
SKIP/CHAPTER
+100
—
—
+
+
DECK A/B
A/B/C/D/E
EFFECT
ON/OFF
DISC SKIP
PRESET
RAV141
VZ44810
REC/
PAUSE
TV
VCR
CBL/
DSS
CH VOL
INPUT SELECT
CD TAPE TUNER
PHONO
TV/DBS
TEST
DVD/LD VCR
ENT DISP
Indicator LED
Use Keypad
To Enter
Setup Codes
Turns On
Component’s
Power
Components
(Devices)
Components
(Devices)
For Code Setup

YHT-15 QUICK-CONNECT GUIDE
10
SETTING UPOTHER COMPONENTS (DEVICES)
1. Look up a setup code for your component (see pages
12 through 14).
2. Turn on the component.
3. On the remote control, press the appropriate
component button; then press and hold SETUP until
the indicator LED flashes twice.
4. Using the keypad, enter the three-digit number.
The indicator LED will flash twice after your entry.
5. The unit’s controls are now assigned to the remote
control buttons (see Quick Reference Card for use).
To test the code, press the appropriate component
button and then POWER. If the unit does not
respond, try an alternate code.
OPERATING THE REMOTE CONTROL (RAV141)
The RAV141 Remote Control will control up to seven
different types of components (including the R-V503
receiver), each of which becomes active when you press
a selection (e.g., TV, VCR, etc.). We can only briefly
describe some functions here, and we encourage you
use the Quick Reference Card and R-V503 Owner’s Manual
to gain additional experience with this powerful unit.
PLAYING A VIDEOCASSETTE
1. Aim the remote control at the receiver, press the
blue RECEIVER/TUN button, and then press
POWER to turn it on. Press VCR (or 6) in the Input
Select area.
2. Aim the remote control at the TV, press the blue TV
button, and then press POWER to turn it on. Press
TV INPUT to select the correct input.
3. Aim the remote control at the VCR, press the blue
VCR button, and then press POWER to turn it on.
Put a tape in the VCR, press PLAY.
NOTE: At this point, the VCR controls are assigned to
the remote control, since VCR was the last blue device
button pressed. If you now press the VOLUME + (or –)
buttons, the TV/VCR volume will be raised (or lowered).
To adjust the receiver’s volume, you must press the blue
RECEIVER/TUN button to activate its functions.
PLAYING A DVD
1. Aim the remote control at the receiver, press the blue
RECEIVER/TUN button, and then press POWER to
turn it on. Press DVD/LD (or 5) in the Input Select area.
2. Press the power switch on the DVD player to turn
the unit on.
NOTE: If the DVD player is plugged into the switched AC
outlet (on the back of the receiver) and its power switch
was already engaged, the unit will come on each time the
receiver is powered on.
3. Load a DVD into the DVD player.
4. Aim the remote control at the DVD player, press the
blue DVD button, and then press PLAY.
NOTE: The DVD player’s controls are now assigned to
the remote control buttons, since DVD was the last blue
device button pressed.
5. Press the TV/DBS or DVD/LD button to switch the
R-V503 inputs from the 2-channel stereo mode to
the 6-channel discrete mode. This will accept signals
from the unit connected to the 6CH DISCRETE
INPUT terminals. Press the button again to return
the R-V503 inputs to the 2-channel mode.
PROGRAMMING THE REMOTE CONTROL (CONT’D)
SETTING UPYOUR DVD (OR LD) PLAYER
1. Look up a setup code for your DVD or LD player
(see page 12).
2. Turn on the DVD (or LD) player.
3. On the remote control, press DVD/LD; then press and
hold SETUP until the indicator LED flashes twice.
4. Using the keypad, enter the three-digit number.
The indicator LED will flash twice after your entry.
5. The unit’s controls are now assigned to the remote
control buttons (see Quick Reference Card for use).
To test the code, press DVD/LD and then POWER.
If the unit does not respond, try an alternate code.

YHT-15 QUICK-CONNECT GUIDE
11
SETTING THE MANUFACTURER’SCODE
Use the supplied RAV141 remote
control to operate Yamaha (or non-
Yamaha) equipment with an
infrared sensor.
Perform the steps below to set the
manufacturer’s code for a non-
Yamaha TV:
1. Turn on your TV; then press TV
on your remote control device.
2. Press and hold SETUP until the
indicator light flashes twice.
3. Use the keypad to enter the
three-digit manufacturer’s code
(from the below list). The indica-
tor light will flash twice after
your entry.
You may also operate a cable box,
satellite, compact disc player, etc.,
using the remote control device.
The following steps show how to
set the manufacturer’s code for a
VCR or DVD/LD player:
4. Turn on your VCR or DVD/LD;
then insert a tape or DVD/LD.
5. Press VCR or DVD/LD and
release; then follow steps 2 and 3
from above.
Set any manufacturer’s code by
entering numbers from the follow-
ing charts.
NOTE: To clear the RAV141’s memory
and return it to the factory codes, press
and hold SETUP; then enter 9 8 1.
CABLE SET-UPCODES
MANUFACTURER CODE
ABC ............................... 001, 003, 007, 008
ABC ............................... 011, 013, 014, 017
Antronix ....................................... 022, 207
Archer ...........................022, 153, 207, 797
Belcor .................................................... 056
Cable Star ............................................. 056
Cabletenna ........................................... 022
Funai ..................................... 171, 179, 180
Futuretech ............................................ 180
Cableview ............................................ 022
Century ................................................ 153
Citizen .......................................... 153, 315
Colour Voice ............................... 025, 031
Comtronics .......................................... 040
Contec................................................... 019
Eastern .................................................. 002
Everquest ..................................... 015, 040
Focus ..................................................... 400
Garrard ................................................. 153
G C Electronics ........................... 056, 207
Gemini .................................................. 015
General Instrument ............ 011, 276, 476
GoldStar ....................................... 040, 144
Hamlin .........................009, 020, 034, 259
Hitachi .................................................. 011
Hytex .................................................... 007
Jasco .............................................. 153, 315
Linsay ................................................... 440
Magnavox ............................................ 027
Memorex .............................................. 000
Movie Time ................................. 063, 156
Novaplex.............................................. 618
NSC ............................................... 063, 156
Oak ................................................ 007, 019
Panasonic ............................. 000, 021, 107
Panther ................................................... 63
Paragon ................................................ 000
Philips........................... 025, 027, 031, 153
Pioneer ................................. 023, 144, 533
Popular Mechanics ............................. 400
Prelude ................................................. 770
Pulsar .................................................... 000
Radio Shack ......................................... 797
RCA ...................................................... 021
Realistic ................................................ 207
Recoton ................................................ 400
Regal ............................................. 020, 259
Regency ................................................ 002
Rembrandt ........................................... 011
Runco.................................................... 000
Samsung ....................................... 040, 144
Scientific Atlanta ........008, 017, 277, 477
Seam ..................................................... 510
Signal ............................................ 015, 040
Signature .............................................. 011
St. Marx ................................................ 040
Sprucer ................................................. 021
Starcom ........................................ 003, 015
Stargate ................................ 015, 040, 770
Starquest .............................................. 015
Sylvania ................................................ 001
Tandy ................................................... 258
Teleview ............................................... 040
Texscan ................................................. 001
TFC ....................................................... 310
Tocom ........................................... 012, 013
Toshiba ................................................. 000
Tusa ...................................................... 015
TV86 ...................................................... 063
Unika .................................... 022, 153, 207
United Artists...................................... 007
United Cable ....................................... 003
Universal............. 022, 056, 153, 191, 207
Viewstar ............................... 027, 063, 258
Zenith ................................................... 000
Zentek................................................... 400
CD PLAYER SET-UPCODES
MANUFACTURER CODE
ADC ...................................................... 018
Adcom .......................................... 155, 234
Aiwa ..................................... 012, 124, 157
Akai ...................................................... 156
Audio Alchemy .................................. 194
Audio-Technica .................................. 170
BSR ................................................ 194, 245
Burmeister ........................................... 420
California Audio Lab ......................... 029
Carrera ................................................. 194
Carver ................................... 157, 179, 437
Crown ................................................... 122
DAK ...................................................... 245
DBX ....................................................... 254
Denon ........................................... 003, 034
DKK ...................................................... 000
Emerson .......................155, 164, 305, 469
Fisher ................... 048, 088, 174, 179, 342
Garrard ................ 245, 280, 393, 420, 425
GE.......................................................... 009
Genexxa................................ 032, 164, 305
GoldStar ............................................... 417
Harman/Kardon ................................ 426
Hitachi .......................................... 032, 155
JVC ................................................ 072, 655
Kenwood...................... 028, 037, 048, 190
Kodak ................................................... 287
Krell ...................................................... 157
Kyocera ................................................ 018
Luxman ................................................ 093
LXI ......................................................... 305
Magnavox ............................................ 157
Marantz ................................ 029, 157, 180
McIntosh .............................................. 287
MCS .............................................. 029, 043
Mission ................................................. 157
USING SET-UP CODES

YHT-15 QUICK-CONNECT GUIDE
LM12
USING SET-UP CODES
CD PLAYER SET-UP CODES (CONT’D)
MANUFACTURER CODE
MTC ...................................................... 420
Nakamichi ........................................... 147
NEC .............................................. 043, 234
Nikko .................................... 164, 170, 174
NSM ...................................................... 157
Onkyo ................................................... 101
Optimus .............. 000, 032, 037, 087, 175
Optimus ............. 179, 194, 196, 280, 305
Optimus .............. 342, 420, 426, 437, 468
Panasonic ............................. 029, 367, 752
Parasound ............................................ 194
Philips........................................... 157, 287
Pioneer ......................... 032, 244, 305, 468
Proton ................................................... 157
QED ...................................................... 157
Quasar .................................................. 029
RCA ............. 099, 053, 155, 179, 305, 764
Realistic ....... 155, 164, 175, 179, 180, 420
Rotel .............................................. 157, 420
SAE ....................................................... 157
Sansui ................................... 157, 202, 305
Sanyo ............................................ 087, 179
Scott ...................................... 155, 164, 305
Sears ...................................................... 305
Sharp............................................. 037, 180
Sherwood .....................114, 180, 196, 426
Shure ..................................................... 043
Sony ..............................000, 185, 605, 727
Soundesign .................................. 145, 425
STS ........................................................ 018
Tascam ................................................. 420
Teac ...............................174, 180, 393, 420
Technics ............................... 029, 207, 303
Vector Research .......................... 195, 417
Victor .................................................... 072
Yamaha ........................ 036, 170, 187, 261
Yorx ...................................................... 461
CASSETTE DECK SET-UPCODES
MANUFACTURER CODE
Aiwa ..................................... 029, 197, 200
Akai ...................................................... 283
Carver ................................................... 029
Denon ................................................... 076
Fisher .................................................... 074
Garrard ......................................... 308, 439
JVC ........................................ 244, 273, 310
Kenwood ..... 070, 071, 092, 205, 233, 234
Magnavox ............................................ 029
Marantz ........................................ 009, 029
Mitsubishi ............................................ 283
Onkyo ........................................... 136, 282
Optimus ....................... 027, 220, 337, 439
Philips................................................... 029
Pioneer ................................. 027, 099, 220
Revox .................................................... 190
Sansui ........................................... 009, 029
Sharp..................................................... 205
Sherwood ............................................. 337
Sony ...................................... 170, 243, 291
Teac ............................................... 289, 308
Technics ....................................... 229, 353
Victor .................................................... 273
Wards ................................................... 027
Yamaha ............... 094, 097, 205, 460, 478
DVD/LD PLAYER SET-UPCODES
MANUFACTURER CODE
Panasonic DVD ................................... 490
Toshiba DVD ....................................... 503
Yamaha DVD ...................................... 490
Aiwa ..................................................... 203
Carver ................................... 064, 194, 323
Denon ................................................... 172
Disco Vision ........................................ 023
Funai ..................................................... 203
Hitachi .................................................. 023
Magnavox .................................... 194, 217
Marantz ........................................ 064, 194
Mitsubishi ............................................ 059
NAD ..................................................... 059
Panasonic ............................................. 204
Philips........................................... 064, 194
Pioneer ......................................... 023, 059
Quasar .................................................. 204
Realistic ................................................ 203
Samsung ............................................... 323
Sega ....................................................... 023
Sony .............................................. 193, 201
Theta Digital ........................................ 194
Yamaha ........................................ 217, 451
SATELLITE SET-UPCODES
MANUFACTURER CODE
AlphaStar ............................................. 772
Chaparral ............................................. 216
Echostar................................................ 775
General Instrument ............................ 361
HTS ....................................................... 775
Hughes Network System .................. 749
Jerrold ........................................... 361, 627
Panasonic ............................................. 701
Primestar ...................................... 361, 627
RCA ...................................................... 566
Sony ...................................................... 639
TELEVISION SET-UPCODES
MANUFACTURER CODE
A-Mark ................................................. 003
Abex ...................................................... 032
Admiral ................................................ 093
Adventura ........................................... 046
Aiko ...................................................... 092
Akai ...................................................... 030
Alleron ................................................. 179
Ambassador ........................................ 177
Anam .................................................... 180
Anam National ................................... 055
AOC ..................... 003, 019, 030, 052, 185
Archer ................................................... 003
Audiovox ..................................... 003, 180
Belcor .................................................... 019
Bell & Howell .............................. 016, 154
Bradford ............................................... 180
Brockwood .......................................... 019
Broksonic ............................................. 003
Candle .......................... 030, 046, 056, 186
Carnivale.............................................. 030
Carver ................................................... 054
Celebrity .............................................. 000
Citizen ..........................030, 039, 046, 056
Citizen ..........................060, 092, 186, 280
Clairtone .............................................. 185
Concerto ............................................... 056
Contec........................................... 180, 185
Craig ..................................................... 180
Crown ........................................... 039, 180
Curtis Mathes ..... 030, 039, 060, 154, 415
CXC ....................................................... 180
Daewoo ........................ 019, 039, 092, 451
Daytron ................................................ 019
Dumont ........................................ 017, 019
Electroband ................................. 000, 185
Electrohome ........................................ 409
Emerson .............. 019, 038, 039, 154, 177
Emerson .............. 185, 236, 280, 282, 463
Envision ............................................... 030
Fisher ............................................ 154, 159
Fujitsu ................................................... 179
GE......................... 021, 027, 047, 051, 055
GE.................................. 135, 178, 282, 451
Gibralter ............................... 017, 019, 030
GoldStar ....................... 019, 030, 032, 039
GoldStar ............................... 056, 178, 409

YHT-15 QUICK-CONNECT GUIDE
13
USING SET-UP CODES
TELEVISION SET-UPCODES (CONT’D)
MANUFACTURER CODE
Grunpy ......................................... 179, 180
Hallmark .............................................. 178
Harvard ................................................ 180
Hitachi ......... 032, 038, 056, 145, 151, 409
Infinity .................................................. 054
Janeil ..................................................... 046
JBL ......................................................... 054
JCB ........................................................ 000
Jerrold ........................... 003, 011, 012, 014
Jerrold ................................... 015, 276, 476
JVC ........................................................ 053
Kaypani ................................................ 052
KEC ....................................................... 180
Kenwood...................................... 019, 030
Kloss ............................................. 024, 046
KTV ...................... 030, 039, 180, 185, 280
Logik ..................................................... 016
Luxman ................................................ 056
LXI........................ 047, 054, 154, 156, 178
Magnavox .................... 020, 024, 030, 054
Magnavox .................... 096, 186, 187, 386
Majestic ................................................ 016
Marantz ........................................ 030, 054
Matsushita ........................................... 250
Megatron.............................. 003, 145, 178
MEI ....................................................... 185
Memorex ............. 016, 056, 150, 154, 178
MGA .............................019, 030, 150, 178
Midland....... 017, 032, 039, 047, 051, 135
Minutz .................................................. 021
Mitsubishi ............................ 019, 150, 178
Motorola ...................................... 055, 093
MTC ..................... 019, 030, 056, 060, 185
Multitech .............................................. 180
NAD ..................................... 156, 166, 178
NEC ...................................... 019, 030, 056
Nikko .................................... 030, 092, 178
Noshi .................................................... 018
NTC ...................................................... 092
Onwa .................................................... 180
Optimus ............................... 154, 166, 250
Optonica....................................... 093, 165
Orion..................................................... 236
Panasonic ............................. 051, 055, 250
Penney ................. 003, 018, 019, 021, 027
Penney ................. 030, 032, 039, 047, 051
Penney ................. 060, 135, 149, 156, 178
Philco ................... 019, 020, 030, 054, 096
Philips................................................... 054
Pilot ....................................... 019, 030, 039
Pioneer ......................................... 038, 166
Portland ............................... 019, 039, 092
Prism ..................................................... 051
Proscan ................................................. 047
Proton ................................... 003, 052, 178
Pulsar ............................................ 017, 019
Quasar ..........................051, 055, 165, 250
Radio Shack .................019, 030, 032, 039
Radio Shack .................047, 056, 154, 165
Radio Shack ......................... 178, 180, 409
RCA ............. 018, 019, 038, 047, 090, 135
Realistic ............... 019, 030, 032, 039, 056
Realistic ........................ 154, 165, 178, 180
Rhapsody ............................................. 185
Runco............................................ 017, 030
Sampo ........................... 030, 032, 039, 052
Samsung ....................... 019, 030, 032, 039
Samsung ............................... 056, 060, 178
Samsux ................................................. 039
Sanyo .................................... 146, 154, 159
Scimitsu ................................................ 019
Scotch ................................................... 178
Scott ..................... 019, 178, 179, 180, 236
Sears ..................... 047, 054, 056, 146, 149
Sears ..................... 154, 156, 171, 178, 179
Sharp............................. 039, 093, 165, 386
Shogun ................................................. 019
Signature .............................................. 016
Simpson ....................................... 186, 187
Sony .............................................. 000, 080
Soundesign .................. 178, 179, 180, 186
Spectricon ............................................ 003
Squareview .......................................... 171
SSS ................................................. 019, 180
Starlite .................................................. 180
Supre-Macy ......................................... 046
Supreme ............................................... 000
Sylvania ........................ 020, 030, 054, 096
Symphonic ........................................... 171
Tandy ................................................... 093
Tatung .......................................... 003, 055
Technics ....................................... 051, 250
Technol Ace ......................................... 179
Techwood ............................ 003, 051, 056
Teknika ........ 016, 019, 039, 054, 056, 060
Teknika ................ 092, 150, 179, 180, 186
TMK ...................................... 056, 177, 178
Toshiba ......................... 060, 149, 154, 156
Tosonic ................................................. 185
Totevision ............................................ 039
Universal .............................................. 027
Vector Research .................................. 030
Victor .................................................... 053
Vidikron ............................................... 054
Vidtech ......................................... 019, 178
Viking ................................................... 046
Wards .................. 016, 019, 020, 021, 027
Wards ........................... 030, 054, 056, 080
Wards ........................... 096, 165, 178, 179
Yamaha ........................................ 019, 030
Zenith ........................................... 016, 017
Zonda ................................................... 003
VCR SET-UPCODES
MANUFACTURER CODE
Adventura ........................................... 000
Aiko ...................................................... 278
Aiwa ..................................................... 000
Akai ...................................... 041, 061, 106
American High ................................... 035
Asha ...................................................... 240
Audiovox ............................................. 037
Beaumark ............................................. 240
Bell & Howell ...................................... 104
Broksonic ............ 121, 184, 211, 295, 361
Calix ...................................................... 037
Canon ................................................... 035
Capehart .............................................. 020
Carver ................................................... 081
CCE ............................................... 072, 278
Citizen .......................................... 037, 278
Colt ....................................................... 072
Craig .................... 037, 047, 072, 240, 271
Curtis Mathes ...................... 035, 041, 060
Cybernex .............................................. 240
Daewoo ................................ 020, 045, 278
Daytron ................................................ 020
Dynatech .............................................. 000
Electrohome ........................................ 037
Electrophonic ...................................... 037
Emerex ................................................. 032
Emerson ...... 000, 002, 036, 037, 043, 061
Emerson .............. 068, 121, 184, 208, 211
Emerson .............. 212, 278, 295, 361, 479
Fisher ............................ 047, 054, 066, 104
Fuji ................................................ 033, 035
Funai ..................................................... 000
Garrard ................................................. 000
GE.......................................... 035, 060, 202
GoldStar ....................................... 037, 038
Gradiente ............................................. 000
Harley Davidson ................................ 000
Harman/Kardon ................................ 038
Harwood ...................................... 068, 072
Headquarter ........................................ 046

YHT-15 QUICK-CONNECT GUIDE
LM14
USING SET-UP CODES
©1998 YAMAHA ELECTRONICS CORPORATION, USA
6660 Orangethorpe Avenue, Buena Park, CA 90620
PH: [phone]; FAX: [phone]
http://www.yamaha.com
VCR SET-UPCODES (CONT’D)
MANUFACTURER CODE
HI-Q ...................................................... 047
Hitachi .......................... 041, 042, 105, 166
Jensen ................................................... 041
JVC ........................................ 008, 041, 067
KEC ............................................... 037, 278
Kenwood .............................. 038, 041, 067
KLH ...................................................... 072
Kodak ........................................... 035, 037
Lloyd .................................................... 000
Lloyd’s .................................................. 208
Logik ..................................................... 072
LXI ......................................................... 037
Magnavox .................... 035, 039, 081, 149
Magnin ................................................. 240
Marantz ........................................ 035, 081
Marta .................................................... 037
Matsushita ........................... 035, 162, 454
MEI ....................................................... 035
Memorex ............. 000, 035, 037, 039, 046
Memorex ......................047, 048, 104, 240
MGA ............................................. 043, 061
MGN Technology ............................... 240
Minolta ......................................... 042, 105
Mitsubishi .................... 043, 061, 067, 173
Motorola ...................................... 035, 048
MTC .............................................. 000, 240
Multitech ...................................... 000, 072
NEC ..................... 038, 040, 041, 067, 104
Nikko .................................................... 037
Nikon ............................................ 034, 253
Noblex .................................................. 240
Olympus .............................................. 035
Optimus .............. 037, 048, 104, 162, 454
Optonica............................................... 062
Orlon............................................. 295, 479
Panasonic ..................... 035, 077, 162, 454
Penney ..........................035, 037, 038, 040
Penney .................................. 042, 054, 240
Pentax ........................................... 042, 105
Philco .................................................... 035
Philips................................... 035, 062, 081
Pilot ....................................................... 037
Pioneer ................................................. 067
Portland ............................................... 020
Protec .................................................... 072
Pulsar .................................................... 039
Quarter ................................................. 046
Quartz .................................................. 046
Quasar ..........................035, 077, 162, 454
Radio Shack ................................. 000, 037
Radix ..................................................... 037
Randex ................................................. 037
RCA .............................. 042, 060, 077, 105
RCA .............................. 106, 149, 202, 225
Realistic ............... 000, 035, 037, 046, 047
Realistic ............... 048, 062, 066, 104, 240
Ricoh ............................................. 034, 253
Runco.................................................... 039
Samsung ....................................... 045, 240
Sanky ............................................ 039, 048
Sansui ................................... 041, 067, 271
Sanyo ............................046, 047, 104, 240
Scott ..... 043, 045, 121, 184, 210, 211, 212
Sears ..................... 035, 037, 042, 046, 047
Sears ..............................054, 066, 104, 105
Sharp............................................. 048, 062
Shintom ................................................ 072
Shogun ................................................. 240
Singer .................................................... 072
Sony ..................... 032, 033, 034, 035, 253
STS ........................................................ 042
Sunpak ................................................. 253
Sylvania ........................ 000, 035, 043, 081
Symphonic ........................................... 000
Tatung .................................................. 041
Teac ............................................... 000, 041
Technics ....................................... 035, 162
Teknika................................. 000, 035, 037
TMK ...................................... 036, 208, 240
Toshiba ........ 043, 045, 060, 066, 210, 212
Totevision .................................... 037, 240
Unitech ................................................. 240
Vector ................................................... 045
Vector Research .......................... 038, 040
Video Concepts ................... 040, 045, 061
Videosonic ........................................... 240
Wards .......... 000, 035, 042, 047, 048, 060
Wards .................. 062, 072, 149, 212, 240
XR-1000 ................................ 000, 035, 072
Yamaha ................................................ 038
Zenith ................................... 033, 034, 039
