Yamaha SYSTEM57C User manual

Copyright (c) Yamaha Corporation. All rights reserved. PDF ’06.11
ELECTRIC ACOUSTIC GUITAR
SENSOR PICKUP
HAMAMATSU, JAPAN
SYSTEM57C
SERVICE MANUAL
011837
EG
SYSTEM57C: 20060901-115500
SPECIFICATIONS(総合仕様).................................................. 2
COLOR VARIATION(カラーバリエーション)......................... 3
PANEL LAYOUT(パネルレイアウト)...................................... 4
OVERALL ASSEMBLY(総組立).............................................. 5
■CONTENTS(目次)
SYSTEM57C
(57-CPX)
CPX900

SYSTEM57C (57-CPX)
2
■SPECIFICATIONS(総合仕様)
IMPORTANT NOTICE
This manual has been provided for the use of authorized Yamaha Retailers and their service personnel. It has been assumed that basic service
procedures inherent to the industry, and more specifically Yamaha Products, are already known and understood by the users, and have
therefore not been restated.
WARNING: Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury, destruc-
tion of expensive components and failure of the product to perform as specified. For these reasons, we advise all Yamaha
product owners that all service required should be performed by an authorized Yamaha Retailer or the appointed service
representative.
IMPORTANT: This presentation or sale of this manual to any individual or firm does not constitute authorization, certification, recognition of
any applicable technical capabilities, or establish a principal-agent relationship of any form.
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research engineering, and service
departments of Yamaha are continually striving to improve Yamaha products. Modifications are, therefore, inevitable and changes in specifica-
tion are subject to change without notice or obligation to retrofit. Should any discrepancy appear to exist, please contact the distributor’s Service
Division.
WARNING: Static discharges can destroy expensive components. Discharge any static electricity your body may have accumulated by
grounding yourself to the ground bus in the unit (heavy gauge black wires connect to this bus).
IMPORTANT: Turn the unit OFF during disassembly and parts replacement. Recheck all work before you apply power to the unit.
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition, other electrical/electronic and/or plastic (Where applicable)
components may also contain traces of chemicals found by the California Health and Welfare Agency (and possibly other entities) to cause
cancer and/or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC COMPONENTS IN YOUR MOUTH FOR ANY REASON WHAT SO
EVER!
Avoid prolonged, unprotected contact between solder and your skin! When soldering, do not inhale solder fumes or expose eyes to solder/flux
vapor!
If you come in contact with solder or components located inside the enclosure of this product, wash your hands before handling food.
SYSTEM-57 (Monaural 3 way)
Acoustic Resonance Transducer
VOL.., 3 Band (HIGH, MID, LOW) EQ control,
Sub pickup (Bass side, Treble side) volume,
Tuner ON switch
Combination end pin/power switch
1 kΩ
9V DC, S-006P (6F22) dry cell battery
• When not using the tuner: Approx. 60 hours
• When using the tuner: Approx. 57 hours
(When using the tuner for one minute per
hour of pre amplifier use.)
• Hexagonal wrench for neck adjustment x 1
• S-006P (6F22) dry cell battery x 1
• Sound Hole Cover x 1
System
Pickup
Controls
Output jack
Output impedance
Power supply
Battery life
Accessories
SYSTEM-57(モノラル-3way)
アコースティックレゾナンストランスデューサー
VOL..、3バンド(HIGH、MID、LOW)EQコント
ロール、サブピックアップ(Bassside、Treble
side)VOL、チューナーONスイッチ
エンドピン/電源スイッチ兼用
1kΩ
DC9V、S-006P(6F22)乾電池使用
・ チューナー不使用時:約60時間
・ プリアンプON1時間につきチューナー1分
使用時:約57時間
・ ネック調整用6角レンチ
・ S-006P(6F22)乾電池
・ サウンドホールカバー
システム
ピックアップ
コントロール
出力ジャック
出力インピーダンス
電源
電源寿命
付属品

SYSTEM57C (57-CPX)
3
■COLOR VARIATION(カラーバリエーション)
BS
Brown Sunburst
(ブラウンサンバースト)
UM
Ultra Marine
(ウルトラマリン)
MBL
Mocha Black
(モカブラック)
NT
Natural
(ナチュラル)

SYSTEM57C (57-CPX)
4
■PANEL LAYOUT(パネルレイアウト)
• Pickups(ピックアップ部)
• Control Panel(コントロールパネル)
1VOL. (Volume) Control
2Tuner ON Switch
3BATT. (Battery Check) Indicator
4Tuner Indicator
53 Band Equalizer
6Sub Pickup/Volume Control
1音量調節
2チューナーONスイッチ
3バッテリーチェックランプ
4チューナー表示器
53バンドイコライザー
6サブピックアップ/音量調節
Battery Holder
(乾電池ホルダー)
Accessory
Sound Hole Cover
(付属品)
(サウンドホールカバー)
Control Section
(コントロール部)
Pickup
(ピックアップ部)
Output Jack (with power switch function)
(電源スイッチ兼用出力ジャック)
5
6
1
2
3
4

SYSTEM57C (57-CPX)
5
■OVERALL ASSEMBLY(総組立)
4b
4d
4e
4a
4c
12
1
7
5
4Pre-amplifier assembly
アンプA'ssy
Accessories of Endpin Jack
エンドピンジャック取付ネジ
6
11a
11
2 3
10
9
Detail of 1
1の詳細図
MAIN
Pickup
PU本体
Blue
青
Expand
拡大
Cross section
断面詳細図
1 2 3
SUB1
Detail of 2
2の詳細図
SUB6
Detail of 3
3の詳細図
Face to be put
(Adhesive rubber)
貼付面(粘着性ゴム)
White
白
Orange
橙
*1
*1
*1
*2
8
Note:
*1 Be sure to use the pickup locating template for replacement of the pickup.
Refer to the manual attached the pickup locating template for more information about the replacement procedures.
*2 Connect the pickup output terminals according to the “Connection of pickup output terminals”on page 6.
注意:
*1 必ずピックアップ取付位置テンプレートを使ってピックアップを交換してください。
交換方法はピックアップ取付位置テンプレートに付属の手順書を参照してください。
*2 「ピックアップ出力端子の接続」(6ページ)に従って接続してください。

SYSTEM57C (57-CPX)
6
•Connection of pickup output terminals(ピックアップ出力端子の接続)
Connect the pickup output terminals to the pickup input ter-
minals of the pre-amplifier so that the seal color of the pickup
output terminal accords with the seal color of the pickup in-
put terminal.
ピックアップ出力端子のシールの色が、ピックアップ入力端
子のシールの色と一致するように接続します。
OVERALL ASSEMBLY SYSTEM57C
1 Pickup Assembly P-MAIN
2 Pickup Assembly P-SUB1
3 Pickup Assembly P-SUB6
4 Pre-amplifier Assembly AMP-AB3C
*4a Knob Volume BPK6D-CPX
MASTER VOL./BASS SIDE/TREBLE SIDE
3
*4b Knob Slide BPK1D-CPX LOW/MID/HIGH 3
*4c Button BPB10D-CPX Tuner
4d Plate Front BSF1D-AB3C
*4e Spacer KRRU-CPX
5 Pan Head Screw 3x10 MFNI3BL 2
*6 Floating Nut 0.6t 2
*7 Truss Head Screw 2.5x6 MFZN2B3 4
8 Cord Clamp 302
9 Battery Holder 05
10 Cushion 03
11 Endpin Jack with Cord Z2BN-SP
11a Screw for Endpin Jack 2x10 With Endpin Jack 2
12 Tape 50x12x0.15
ACCESSORIES
Hexagonal Wrench #5 04
Battery 006P 9V Dry cell (PC10008)
JIGS
*Pickup Locating Template APX-6 FOR 6-STRING MODEL
WJ301500
WJ301700
WJ301800
WG661900
WJ302000
WJ301900
WJ307200
WJ302500
WG874800
WH260100
WH538500
WH258500
VC668400
QC111900
QC112000
WG909700
--
QC667300
AA805430
--
AAX79980
総組立
PU−Assy MAIN
PU−Assy SUB1
PU−Assy SUB6
アンプAssy(AB3C)
ボリュームノブ
スライドノブ
ボタン
フロントプレート
スペーサー
+ナベ小ネジ
フローティングナット
+トラス小ネジ
コード固定片
乾電池ホルダ
乾電池ホルダクッション
エンドピンジャック(コード付き)
エンドピンジャック取付ネジ
テープ
付属品
六角レンチ
乾電池
治具
ピックアップ取付位置テンプレート
RANKQTYREMARKSDESCRIPTIONREF NO. PART NO.
: New Parts RANK: Japan only
部品名
Endpin Jack Output Terminal
エンドピンジャック出力端子
Pickup input Terminal
ピックアップ入力端子
White
(白)
Orange
(橙)
Blue
(青)
SUB1
White(白)
MAIN
Orange(橙)
SUB6
Blue(青)
