No. STK CODE Parts No. Description QNo. STK CODE Parts No. Description Q
1 6010-202502 LEAD WIRE 1 13 6038-202501 HOUSING (R) 1
2 6010-202501 WIRE 1 14 6SDABB04-14 SCREW 4
3 6028-202502 SWITCH BUTTON 1 15 6SDAB-06-46 SCREW 1
4 6022-230001 SWITCH 1 16 6207-202505 SHAFT HOUSING (R) 1
5 6154-840001 TRIMINAL BLOCK 2 17 6SDAB-06-28 SCREW 1
6 6099-202502 MOTOR 1 18 6068-202505 HANDLE HOUSING (R) 1
7 6SDABB04-18 SCREW 2 19 6068-202506 HANDLE HOUSING (L) 1
8 6072-202501 MOTOR PLATE 1 20 6NAB-06 NUT 2
9 6SDAZJ03-08 SCREW 10 21 6207-202506 SHAFT HOUSING (L) 1
10 6270-202502 STRING HEAD CARRIER 1 22 6038-202502 HOUSING (L) 1
11 6024-202604 SPRING 1 23 6228-202402 DEBRIS SHIELD ASS'Y 1
12 6228-202004A SPOOL CARRIER ASS'Y 1 23-1 6262-202501 GUARD 1
12-1 6059-202004 SPOOL COVER 1 23-2 6250-202503 WIRE CUTTING BLADE 1
12-2 6008-202001A SPOOL CARRIER 1 23-3 6SDABB04-10 SCREW 2
12-3 6194-202001 WIRE-CUTTING 1 24 6WFB-06 FLAT WASHER 2
12-4 6059-202005A SPOOL COVER 1 25 6WSB-03 SPRING WASHER 4
12-5 6140-B23101 PILOT 226 6032-090-01 BAND, PLASTIC 1
:
-
REVISED
DATE
DATE
1/18/2006
MODEL NO.
SPECIFY MODEL NO. WHEN ORDERING PARTS
9" String Trimmer
41CA025P900/MTD25P
SERVICE SPARE PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
12-1
12-2
12-3
12-4
12-5
13
7
15
16
17
18
19
20
21
20
22
23
24
24
14
23-3
23-2
23-1
25
26
7
7
