Operator's Manual
ZMMKW34170 / 968999757
Please read the operator’s manual carefully and make sure you
understand the instructions before using the machine.

WARNING!
Failure to follow cautious operating practices can result in serious
injury to the operator or other person. The owner must understand these
instructions to operate the mower. Each person operating the mower must
be of sound mind and body and must not be under the influence of any
mind altering substance.
WARNING!
Engine exhaust, some of its constituents, and certain vehicle components
contain or emit chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
WARNING!
Battery posts, terminals and related accessories contain lead and lead
compounds, chemicals know to the State of California to cause cancer
and birth defects or other reproductive harm. Wash hands after handling.

CONTENTS
INTRODUCTION...........................................4
Congratulations ......................................4
General...................................................4
Driving and Transport on Public Roads..4
Towing ....................................................4
Operating................................................4
SYMBOLS AND DECALS ............................6
SAFETY ........................................................8
General Operation..................................8
Personal Safety Equipment..................10
Slope Operation....................................10
General Maintenance...........................13
Transport ..............................................15
Customer responsibilities .....................15
CONTROLS ................................................16
Motion Control Levers ..........................16
Tracking................................................16
Seat adjustment lever...........................17
Refueling ..............................................17
Hour Meter............................................18
Ignition Switch ......................................18
Choke Control.......................................18
Throttle Control.....................................18
Blade switch .........................................19
Circuit breaker......................................19
Parking Brake.......................................19
Mower Deck Cut Height Lift Lever........20
OPERATION ...............................................21
Operation..............................................21
Training.................................................21
Steering................................................21
Before Starting......................................22
Starting the Engine...............................22
Engine with weak battery......................24
Running................................................25
Operating on hills..................................26
Mowing Tips .........................................27
Stopping the Engine.............................28
Moving by Hand....................................29
MAINTENANCE..........................................30
Maintenance Schedule.........................30
Battery..................................................32
Ignition System.....................................33
Safety System ......................................33
Fuel Filter..............................................36
Fuel Pump Air Filter..............................37
Tire Pressures ......................................37
Parking Brake.......................................37
V-belts...................................................38
Pump Belt.............................................39
Blades...................................................39
Mower Deck..........................................41
Nose Roller...........................................42
LUBRICATION............................................44
TROUBLESHOOTING................................48
STORAGE...................................................50
Storage.................................................50
Service..................................................50
SCHEMATICS.............................................51
TECHNICAL DATA .....................................53
Accessories..........................................55
Torque Specifications ...........................55
CONFORMITY CERTIFICATES .................56
Conformity Certificates.........................56
SERVICE JOURNAL ..................................57

English-4
INTRODUCTION
Congratulations
Thank you for purchasing a Yazoo/Kees ride-on mower. This machine is built for superior efficiency to rapidly mow
in confined areas. A control panel easily accessible to the operator and a hydrostatic transmission regulated by
steering controls both contribute to the machine’s performance.
This manual is a valuable document. Read the contents carefully before using or servicing the machine. The
following of instructions (use, service, maintenance) by all who operate this machine is important for the safety
of the operator and others. It can also considerably increase the life span of the machine and increase its resale
value.
If you sell your machine, be sure to give the operator’s manual to the new owner.
The final chapter of this operator’s manual provides a Service Journal. Ensure that service and repair work are
documented. A well-kept service journal reduces service costs for the maintenance and affects the machine’s
resale value. Please contact your dealer for more information. Take the operator’s manual along when the
machine is taken to your dealer for service.
General
In this operator’s manual, left and right, backward and forward are used in relation to the machine’s normal driving
direction.
Continuous dedication to improve our products require that specifications and design are subject to change
without notice.
Driving and Transport on Public Roads
Check applicable road traffic regulations before transporting on public roads. If the machine is transported, you
must always use approved fastening equipment and ensure that the machine is well anchored. DO NOT operate
this machine on public roadways.
Towing
Do not tow this machine, it may cause damage to the drive system.
Do not tow any trailers with this mower. They may jackknife or overturn causing damage to the mower and
possible serious injury to the operator.
Operating
This machine is constructed only for mowing grass on lawns and even ground without obstacles such as stones,
tree stumps, etc. The machine can also be used for other tasks when equipped with special accessories provided
by the manufacturer. Operating instructions for the accessories are provided with delivery. All other types of uses
are incorrect. The manufacturer’s directions concerning operation, maintenance, and repairs must be carefully
followed.
Lawn mowers and all power equipment, can be potentially dangerous if used improperly. Safety requires good
judgement, careful use in accordance with these instructions and common sense.
The machine must only be operated, maintained, and repaired by persons familiar with the machine’s special
characteristics and who are also knowledgeable about the safety instructions. Use only approved repair parts to
maintain this machine.
Accident prevention regulations, other general safety regulations, occupational safety rules, and traffic regulations
must be followed without fail.
Unauthorized modifications to the design of the machine may absolve the manufacturer from liability for any
resulting personal injury or property damage.

English-5
INTRODUCTION
Good Service
Yazoo/Kees’ products are sold only in specialized retail stores with complete service. This ensures that you
as a customer receive only the best support and service. Before the product is delivered, the machine has, for
example, been inspected and adjusted by your retailer. See the certificate in the Service Journal in this operator’s
manual.
When you need spare parts or support in service questions, warranty issues, etc., please consult the following
professional:
Manufacturing Number
The machine’s manufacturing number can be found on the printed plate affixed to the left in the engine
compartment. Stated on the plate, from the top are:
• The machine’s type designation (I.D.).
• The manufacturer’s type number (Model).
• The machine’s serial number (Serial no.)
Please have the type designation and serial number available when ordering spare parts.
The engine’s manufacturing number is stamped on one of the valve covers.
The plate states:
• The engine’s model.
• The engine’s type.
• Code
Please have these available when ordering spare parts.
The Hydro Drive IZT gears have a barcode decal affixed to the rear of the gears.
This Operator’s Manual belongs to the machine with
the manufacturing number: Engine Transmission

English-6
SYMBOLS AND DECALS
These symbols are found on the machine and in the operator’s manual.
Study them carefully so that you know what they mean.
Used in this publication to notify the reader of a risk of personal injury or death, particularly if the reader should
neglect to follow instructions given in the manual.
Used in this publication to notify the reader of a risk of material damage, particularly if the reader should neglect
to follow instructions given in the manual. Used also when there is a potential for misuse or misassembly.
WARNING!
Xxxx xxxxxx xxxxx xxxx
xxxxxxxxx xxxxxx xxxxxxxxx.
xx xxxxxxxx xxxx xxxxxx.
IMPORTANT INFORMATION
Xxxx xxxxxx xxxxx xxxx xxxxxxxxx
xxxxxx xxxxxxxxx. xx xxxxxxxx xxxx
xxxxxx.
RN
Reverse Neutral Fast Slow Choke Fuel
Warning! Parking Brake CE conformity Warning! Rotating blades, Do not touch parts
marking. Only for keep away from the
European market discharge deck
Battery acid is corrosive, explosive and flammable Do not stand here
Noise emissions to the
surroundings in accordance with
the European Union’s directive.
The machine’s emission is stated
in the chapter TECHNICAL DATA
and on the decals.
Only machines for European
market
Use protective glasses Use protective gloves
P

English-7
SYMBOLS AND DECALS
Read Shut off engine and Keep a safe Use on slopes No passengers
Operator’s remove key before distance from no greater
Manual performing any the machine than 10°
maintenance or repair work
Whole body Severing of fingers Do not open or Careful backing up, Careful going
exposure to and toes remove safety watch for other forward, watch for
thrown objects shields while people other people
engine is running
Moving sharp blades under cover

English-8
SAFETY
These instructions are for your safety. Read them carefully.
IMPORTANT: THIS CUTTING MACHINE IS
CAPABLE OF AMPUTATING HANDS AND FEETAND
THROWING OBJECTS. FAILURE TO OBSERVE
THE FOLLOWING SAFETY INSTRUCTIONS COULD
RESULT IN SERIOUS INJURY OR DEATH.
General Operation
• Read, understand, and follow all instructions
on the machine and in the manual before
starting.
• Do not put hands or feet near rotating parts
or under the machine. Keep clear of the
discharge opening at all times.
• Only allow responsible adults, who are
familiar with the instructions, to operate the
machine.
• Clear the area of objects such as rocks, toys,
wire, etc., which could be picked up and
thrown by the blades.
• Be sure the area is clear of bystanders
before operating. Stop machine if anyone
enters the area.
• Never carry passengers. The machine is only
intended for use by one person.
• Do not mow in reverse unless absolutely
necessary. Always look down and behind
before and while backing.
• Never direct discharged material toward
anyone. Avoid discharging material against
a wall or obstruction. Material may ricochet
back toward the operator. Stop the blades
when crossing gravel surfaces.
• Do not operate machine without the entire
grass catcher, discharge guard, or other
safety devices in place and working
• Slow down before turning.
• Never leave a running machine unattended.
Always turn off blades, set parking brake,
stop engine, and remove keys before
dismounting.
WARNING!
This symbol means that important safety instructions need to be emphasized.
It concerns your safety.
8011-512
Read the operator’s manual before starting the machine
Clear the area of objects before mowing 8011-513

English-9
SAFETY
WARNING!
Engine exhaust and certain
vehicle components contain
or emit chemicals considered
to cause cancer, birth defects,
or other reproductive system
damage. The engine exhaust
contains carbon monoxide,
which is a odorless, colorless,
poisonous gas. Do not use the
machine in enclosed spaces.
8011-520
Never take passengers
• Disengage blades when not mowing. Shut
off engine and wait for all parts to come to a
complete stop before cleaning the machine,
removing the grass catcher, or unclogging
the discharge guard.
• Operate machine only in daylight or good
artificial light.
• Do not operate the machine while under the
influence of alcohol or drugs.
• Watch for traffic when operating near or
crossing roadways.
• Use extra care when loading or unloading
the machine into a trailer or truck.
• Always wear eye protection when operating
machine.
• Data indicates that operators, age 60
years and above, are involved in a large
percentage of riding mower-related injuries.
These operators should evaluate their ability
to operate the riding mower safely enough to
protect themselves and others from serious
injury.
• Follow the manufacturer’s recommendation
for wheel weights or counterweights.
• Anyone who operates this machine must first
read and understand this Operation Manual.
Local laws may regulate the age of the user.
• Keep machine free of grass, leaves or other
debris buildup which can touch hot exhaust
/ engine part and burn. Do not allow the
mower deck to plow leaves or other debris
which can cause buildup to occur. Clean any
oil or fuel spillage before operating or storing
the machine. Allow machine to cool before
storage.

English-10
SAFETY
WARNING!
When using the machine, approved personal protective equipment (shown in
illustrations) shall be used. Personal protective equipment cannot eliminate the
risk of injury but it will reduce the degree of injury if an accident does happen.
Ask your retailer for help in choosing the right equipment.
Personal Safety Equipment
• Make sure that you have first aid equipment
close at hand when using the machine.
• Never use the machine when barefoot.
• Always wear protective shoes or boots,
preferably with steel toe caps.
• Always wear approved protective glasses or
a full visor when assembling or driving.
• Always wear gloves when handling the
blades.
• Never wear loose clothing that can get
caught in moving parts.
• Use ear protectors to avoid damage to
hearing.
Slope Operation
Slopes are a major factor related to loss of control and
tip-over accidents, which can result in severe injury or
death. Operation on all slopes requires extra caution. If
you cannot back up the slope or if you feel uneasy on
it, do not mow it.
• Mow up and down slopes (10 degrees
maximum), not across.
• Watch for holes, ruts, bumps, rocks, or
other hidden objects. Uneven terrain could
overturn the machine. Tall grass can hide
obstacles.
• Choose a low ground speed so that you will
not have to stop while on the slope.
• Do not mow on wet grass. Tires may lose
traction.
• Avoid starting, stopping, or turning on a
slope. If tires lose traction, disengage blades
and proceed slowly straight down the slope.
• Keep all movement on the slopes slow and
gradual. Do not make sudden changes in
speed or direction, which could cause the
machine to roll over.
• Use extra care while operating machine with
grass catchers or other attachments; they
can affect the stability of the machine.
WARNING!
Do not drive up or down hills
with slopes greater than 10
degrees. And do not drive across
any slopes.
6003-004
Mow up and down, not side to side
8011-670a
Personal protective equipment

English-11
SAFETY
• Do not use on steep slopes.
• Do not try to stabilize the machine by putting
your foot on the ground.
• Do not mow near drop-offs, ditches, or
embankments. The machine could suddenly
roll over if a wheel is over the edge or if the
edge caves in.
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are often
attracted to the machine and the mowing activity.
Never assume that children will remain where you last
saw them.
• Keep children out of the mowing area and in
the watchful care of a responsible adult other
than the operator.
• Be alert and turn machine off if a child enters
the area.
• Before and while backing, look behind and
down for small children.
• Never carry children, even with the blades
shut off. They may fall off and be seriously
injured or interfere with safe machine
operation. Children who have been given
rides in the past may suddenly appear in
the mowing area for another ride and be run
over or backed over by the machine.
• Never allow children to operate the machine.
• Use extra care when approaching blind
corners, shrubs, trees, or other objects that
may block your view of a child.
8011-509
Be extra cautious when driving on slopes
8011-517
Never allow children to operate the machine
8011-518
Keep children away from work area

English-12
SAFETY
Safe Handling of Gasoline
To avoid personal injury or property damage, use
extreme care in handling gasoline. Gasoline is
extremely flammable and the vapors are explosive.
• Extinguish all cigarettes, cigars, pipes, and
other sources of ignition.
• Use only approved gasoline container.
• Never remove gas cap or add fuel with the
engine running. Allow engine to cool at least
two (2) minutes before refueling.
• Never fuel the machine indoors.
• Never store the machine or fuel container
where there is an open flame, spark, or pilot
light such as on a water heater or other
appliances.
• Before you begin refueling, minimize the
risk of static electricity by touching a metal
surface.
• Never fill containers inside a vehicle or on a
truck or trailer bed with plastic liner. Always
place containers on the ground away from
your vehicle when filling.
• Remove gas-powered equipment from the
truck or trailer and refuel it on the ground.
If this is not possible, then refuel such
equipment with a portable container, rather
than from a gasoline dispenser nozzle.
• Keep the nozzle in contact with the rim of the
fuel tank or container opening at all times
until fueling is complete. Do not use a nozzle
lock-open device.
• If fuel is spilled on clothing, change clothing
immediately.
• Never overfill fuel tank. Replace gas cap and
tighten securely.
• Do not start the engine near spilled fuel.
• Never use gasoline as a cleaning agent.
• If leaks arise in fuel system, engine must not
be started until problem has been resolved.
• Check the fuel level before each use and
leave space for the fuel to expand, because
the heat from the engine and the sun may
otherwise cause the fuel to expand and
overflow.
WARNING!
The engine must not be started when the driver’s floor plate or any protective
plate for the mower deck’s drive belt is removed.
WARNING!
The engine and the exhaust
system, become very hot
during operation.
Risk for burns if touched.
Allow engine and exhaust
system to cool at least two (2)
minutes before refueling.
8011-516
Never fill the fuel tank indoors

English-13
SAFETY
WARNING!
The battery contains lead and
lead compounds, chemicals
that are considered to cause
cancer, birth defects, and other
reproductive system damage.
Wash your hands after handling
the battery.
Use protective glasses for
maintenance work.
General Maintenance
• Never operate machine in a closed area.
• Keep all nuts and bolts tight to be sure the
equipment is in safe working condition.
• Never tamper with safety devices. Check
their proper operation regularly.
• Keep machine free of grass, leaves, or other
debris buildup. Clean oil or fuel spillage
and remove any fuel-soaked debris. Allow
machine to cool before storing.
• If you strike a foreign object, stop and
inspect the machine. Repair, if necessary,
before restarting.
• Never make any adjustments or repairs with
the engine running.
• Check grass catcher components and the
discharge guard frequently and replace with
manufacturer’s recommended parts, when
necessary.
• Mower blades are sharp. Wrap the blade or
wear gloves, and use extra caution when
servicing them.
• Check brake operation frequently. Adjust and
service as required.
• Maintain or replace safety and instruction
labels, as necessary.
• Do not modify safety equipment. Check
regularly to be sure it works properly. The
machine must not be driven with defective
or unmounted protective plates, protective
cowlings, safety switches, or other protective
devices.
• Do not change the settings of governors and
avoid running the engine with overly high
engine speeds. If you run the engine too fast,
you risk damaging the machine components.
• Be very careful when handling battery acid.
Acid on skin can cause serious corrosive
burns. If you spill battery acid on your skin,
rinse immediately with water.
• Acid in the eyes can cause blindness,
contact a doctor immediately.
• Be careful when servicing the battery.
Explosive gases form in the battery. Never
perform maintenance on the battery when
smoking or near open flames or sparks.
• The battery can explode and cause serious
injury/damage.
8011-515
Never drive the machine in an enclosed space

English-14
SAFETY
• Ensure that nuts and bolts, especially the
fastening bolts for the blade attachments,
are properly tightened, torqued and that the
equipment is in good condition.
• Do not modify safety equipment. Check
regularly to be sure it works properly. The
machine must not be driven with defective
or unmounted protective plates, protective
cowlings, safety switches, or other protective
devices.
• Do not change the settings of governors and
avoid running the engine with overly high
engine speeds. If you run the engine too fast,
you risk damaging the machine components.
• Sparking can occur when working with the
battery and the heavy cables of the starter
circuit. This can cause battery explosion,
fire or eye injury. Sparking in this circuit can
not occur after the chassis cable (normally
negative, black) is removed from the battery.
• Use protective goggles.
• Ensure that the fuel filler cap is mounted
tightly and no flammable substances is
stored in an open vessel.
• Never work with the starter circuit if there is
spilled fuel.
• Disconnect the chassis cable from the
battery first and reconnect it last.
• Do not make a bridge short circuit across the
starter relay to run the starter.
• Never use the machine indoors or in spaces
lacking proper ventilation. The exhaust
fumes contain carbon monoxide, an
odorless, poisonous, and lethal gas.
• Stop and inspect the equipment if you run
over or into anything. If necessary, make
repairs before starting.
• Never make adjustments with the engine
running.
• The machine is tested and approved only
with the equipment originally provided or
recommended by the manufacturer. Only use
approved repair parts for the machine.
Risk of sparking 8009-728
WARNING!
Avoid electrical sparking and its
consequences by the following
routines:
6003-009
Do not smoke when performing maintenance on the battery.
The battery can explode and cause serious injury/damage.

English-15
SAFETY
8011-514
Clean the machine regularly
IMPORTANT INFORMATION
The parking brake is not sufficient
to lock the machine in place during
transport. Ensure that the machine is
well fastened to the transport vehicle.
Always reverse the machine onto the
transport vehicle to avoid tipping it over.
WARNING!
This mower is equipped
with an internal combustion
engine and should not
be used on or near any
unimproved forest-covered,
bush-covered or grass-
covered land unless the
engine’s exhaust system
is equipped with a spark
arrester meeting applicable
local or state laws (if any).
If a spark arrester is used,
it should be maintained in
effective working order by
the operator.
A spark arrester for the muffler is available through
your authorized Yazoo/Kees dealer.
• The blades are sharp and can cause
cuts and gashes. Wrap the blades or use
protective gloves when handling them.
• Check the parking brake’s functionality
regularly. Adjust and service as necessary.
• The mulch blades should only be used in
familiar areas when higher quality mowing is
desired.
• Reduce the risk of fire by removing grass,
leaves, and other debris that may have
accumulated on the machine. Allow the
machine to cool before putting it in storage.
• Regularly clean deck and underside of
deck, avoid spraying engine and electrical
components with water.
Transport
• The machine is heavy and can cause serious
crushing injuries. Be extra cautious when it
is loaded on or unloaded from a vehicle or
trailer.
• Use an approved trailer to transport the
machine. Activate the parking brake, turn off
the fuel supply, and fasten the machine with
approved fastening devices, such as bands,
chains, or straps, when transporting.
• Do not operate this machine on public
roadways.
• Check and abide by local traffic regulations
before transporting the machine on any road.
• Do not tow this machine, it may cause
damage to the drive system.
• Do not tow any trailers with this mower. They
may jackknife or overturn causing damage to
the mower and possibly serious injury to the
operator.
•Load the unit onto truck or trailer by driving
up ramps of suitable strength using a slow
speed. Do not lift! The machine is not
intended to be lifted by hand.
Customer responsibilities
• Read and observe the safety rules.
• Follow a regular schedule in maintaining,
caring for and using your mower.
• Follow the instructions under “Maintenance”
and “Storage” sections of this owner’s
manual.

CONTROLS
English-16
Motion Control Levers
The machine’s speed and direction are continuously
variable using the two steering controls. The steering
controls can be moved forward or backward about
a neutral position. Furthermore, there is a neutral
position, which is locked if the steering controls are
moved outward.
When both controls are in the neutral position (N), the
machine stands still.
By moving both controls an equal amount forward
or backward, the machine moves in a straight line
forward or backward respectively.
In order, for example, to turn right while moving
forward, move the right control towards the neutral
position. The rotation of the right wheel is reduced and
the machine turns to the right.
Zero turn can be achieved by moving one control
backward (behind the neutral position) and carefully
moving the other steering control forward from its
neutral position. The rotation direction when zero
turning is determined by which steering control is
moved backward behind the neutral position. If the left
steering control is pulled backward, the machine turns
to the left. Use extra care when using this maneuver.
Tracking
If the mower is not tracking straight, check the air
pressure in both rear tires. Recommended air pressure
is 15 psi (1 bar). Tracking must be checked on a flat
and level concrete or blacktop surface. If unit still does
not track straight, contact a Yazoo/Kees dealer for
adjustment.
8050-106
Steering controls
1
23
4
8011-791
1. Forward
2. Neutral
3. Neutral slot, Neutral lock
4. Reverse
Motion control lever pattern (right side)
WARNING!
The machine can turn very
rapidly if one steering control
is moved much further forward
than the other.

CONTROLS
English-17
8050-165
Seat adjustment
Seat adjustment lever
The seat can be adjusted lengthways. When making
adjustments, sit on the seat. Slide the lever to the side
and maneuver seat to appropriate placement and
release lever.
Refueling
The machine has one fuel tank, just behind the seat.
The tank capacity is 4.5 gallons (17 liters).
The engine will run on a minimum of 85-octane
unleaded gasoline (no oil mix). Environmentally
adapted alkylate gasoline can be used. See also
Technical Data concerning ethanol fuel. Methanol fuel
is not allowed.
When operating below 32°F (0°C) use fresh, clean
winter grade gasoline to help insure good cold
weather starting.
8050-768
Fuel tank
WARNING!
Gasoline is highly flammable.
Observe caution and fill the tank
outdoors. (See Safety)
WARNING!
Fill to the bottom of the filler
neck. Do not overfill. Wipe off
any spilled oil or fuel. Do not
store, spill or use gasoline near
an open flame.
WARNING!
The engine and the exhaust
system, become very hot during
operation. Risk for burns if
touched.
Allow engine and exhaust
system to cool at least two (2)
minutes before refueling.
IMPORTANT INFORMATION
Experience indicates that alcohol blended
fuels (called gasohol, ethanol or methanol)
can attract moisture which leads to
separation and formation of acids during
storage. Acidic gas can damage the fuel
system of an engine while in storage. To
avoid engine problems, the fuel system
should be emptied before storage of 30
days or longer. Drain the gas tank, start the
engine and let it run until the fuel lines and
carburetor are empty. Use fresh fuel the
next season. See Storage Instructions for
additional information. Never use engine
or carburetor cleaners in the fuel tank or
permanent damage may occur.

CONTROLS
English-18
Hour Meter
The hour meter displays the total operating time.
It will flash CHG OIL (Change Oil) at 50 hour intervals.
The flash duration is one hour before and one hour
after the interval. The CHG OIL icon will come on
and shut off automatically. The hour meter cannot be
manually reset.
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
8058-018
Hour meter
IMPORTANT INFORMATION
Do not run the starter for more than five
seconds each time. If the engine does
not start, wait about 10 seconds before
retrying.
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
Ignition Switch
The ignition key is placed on the driver’s panel and is
used to start and stop the engine.
Choke Control
The choke mode is used for cold starts in order to
provide the engine with a richer fuel mixture.
Choke the engine by pulling the knob fully up.
Throttle Control
The throttle control regulates the engine speed and
thereby the rate of rotation of the blades, assuming the
blade switch is pulled out, see Engaging the Mower
Deck.
In order to increase or decrease the engine speed, the
control is moved.
Avoid idling the engine for long periods, as there is a
risk of fouling the spark plug.
USE FULL THROTTLE WHEN MOWING, for best
mower performance and battery charging.
8058-018
Ignition switch
8058-018
Choke control
8058-018
Throttle control

CONTROLS
English-19
Blade switch
In order to engage the mower deck, pull the knob out;
the mower blades are disengaged when the knob is
depressed.
Circuit breaker
The circuit breaker provides protection for the electrical
system by (1) 15 amp circuit breaker. If the circuit
breaker trips, push the button to reset. If the condition
repeats, consult a dealer for inspection and repair.
Parking Brake
The parking brake is found on the operator’s left. Pull
the lever upward to activate the brake and downward
to release it.
The park brake is designed to hold the mower from
moving and is not intended for use in stopping the
mower while it is in motion. The engine will stop if the
park brake is engaged while the control levers are in
the drive position.
IMPORTANT INFORMATION
The machine must stand absolutely still
when applying the parking brake. Always
set the parking brake before dismounting.
Release the parking brake before moving
the mower.
Parking brake activated 8050-773
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
8058-018
Blade switch
CHOKE
CHOKE
THROTTLE
THROTTLE
BLADE
BLADE
DRIVE
DRIVE
8058-018
Circuit breaker

CONTROLS
English-20
Mower Deck Cut Height Lift Lever
Located to the right and front of the operator, the lift
lever controls the cutting height. The deck cutting
height is obtained by pressing the foot pedal forward
to lift the deck. To lower the deck, apply pressure to
the top side of the foot pedal and allow it to pivot while
depressing the trigger and moving the lever forward.
Set the desired cut height with pin.
The cutting height range is from 1½" (38 mm) to 5½"
(140 mm) in ½" (13 mm) increments. The heights are
measured from the ground up to the blade tip with the
engine not running.
8050-774
1. Lift lever
2. Trigger
3. Set pin
4. Foot pedal
Cut height lift lever and pedal
1
3
4
IMPORTANT INFORMATION
In order to obtain an even cutting height it
is important that the air pressure in all four
tires is the same 15 psi (1 bar).
IMPORTANT INFORMATION
Always use the high position to transport.
2
