Thank you and congratulations,
for choosing VIPdigital. Straightforward and quick to use, VIPdigital will readily meet your very own
requirements. Please read this brief introduction carefully, which will give you the most important
information you need to start using your new system. These instructions provide you with the basic
information you need for the assembly and operation of the parts supplied.
Your opinion is important to us!
The innovative dedication of the YELLOWTEC organization lies behind this product. When you tell us
about your new ideas and requirements, we listen to you closely!
Use our web site www.yellowtec.com to stay constantly up to date with product developments, and to
communicate with us. You will also find valuable tips and tricks here as well as new software to
download for your VIPdigital, and a host of other interesting information from the world of
YELLOWTEC.
All In One
VIPdigitalis a powerful digital voice processor. Its advanced Sharc DSP technology and its algorithms
especially optimized for voice offer you an unprecedented arsenal of processing tools to create
powerful, yet clear sounds.
- reference class microphone amplifier, subsonic filter, phase rotator, de-esser, 4-band parametric EQ,
expander, automatic gain control, compressor, limiter, reverb and delay -
VIPdigitaloffers all these tools in a compact 19“ format on only 1 HU.
Some more features in keywords:
-Set all audio parameters conveniently in real time using VIPremote Windows®software.
-Save audio parameters as presets on SmartCard. Or load your audio presets to the non-
volatile memory of your VIPdigital, or save them on your PC hard disk.
-Operating without PC, recall your presets by just activating a push-button switch or inserting a
SmartCard.
-Define a basic VIPdigital configuration using VIPcon Windows®software, and thus make the
unit perfectly match the requirements of your studio.
-Use a variety of analog and digital audio inputs and outputs including external sync facility as
well as GPI/GPO-ports and serial RS232 ports for PC-connection.
Unpacking
VIPdigital is delivered in a carton. Unpack the carton carefully. Remember the environment and
dispose of the parts of foamed material and the cartons separately.
The VIPdigital scope of delivery includes:
1. VIPdigital, 19“/1HU unit
2. Serial interconnecting cable to the computer (RS232)
3. Mains cable (not for all countries)
4. YELLOWTEC CD-ROM with software
5. YELLOWTEC SmartCard®(1 piece)
6. “Getting Started“ brochure (not included in each delivery)
Check whether the scope of delivery is complete. Please contact your dealer directly in the case of
questions.

Yellowtec VIPdigital Getting started 2
VIPdigital 22.06.2004 Getting Started
Electrical connection
Connect VIPdigital to your local power supply. VIPdigital is equipped with a switched-mode power
supply unit and can be operated on 90 to 240 V AC without any transfer.
Always follow the local safety regulations! Also, read the safety information below!
Activation
Switch on the power supply of the unit, using the power switch on the back panel. The Function
Display briefly shows VIPdigital, followed by the version identification of the firmware loaded. Your
VIPdigital is now ready for operation.
Please note that VIPdigital can only be deenergized by the power switch on the rear side of the
unit! Disconnect the mains plug before opening the housing in each case!
Using Internal Presets
VIPdigital has a non-volatile memory and on power-up it restores the last operating status existing
prior to a deactivation.
If no SmartCard has been inserted, one of the three Preset Recall memories is active. This is signalled
by the corresponding LED above one of the black Preset Recall buttons, marked with numbers 1, 2
and 3.
First of all, make yourself familiar with the preset functions. Press the Preset Recall buttons to select
the three available presets directly. The active preset is shown by a LED above the respective button.
The upper line of the display shows “Internal Preset” and the number of the selected preset; its name
appears in the lower line.
Using SmartCard
Note: Part of what is described below can only be performed when using a SmartCard that has presets
stored on it. There are no presets stored on the YELLOWTEC SmartCard supplied with the unit.
Insert a YELLOWTEC SmartCardinto the card slot. Please make sure that the gray double arrow of
the card is on the top, pointing to the front to the unit (the chip is upside down).
Once the card has been inserted, the LED of the previous selected Preset Recall button will flash to
indicate that the SmartCard has been detected, but none of its presets were loaded.
The three Preset Recall buttons now allow an access to the three presets stored on the SmartCard.
Select one of the three card presets. The display will show the name of the card holder in the upper
line and the name of the preset below.
Once the SmartCard has been removed, the LED of the preset loaded last will flash to indicate a new
access to the internal preset. At this time, the preset loaded last by the SmartCard will be active.
Press one of the three buttons to load an internal preset.

Yellowtec VIPdigital Getting started 3
VIPdigital 22.06.2004 Getting Started
First audio connections
If you not only wish to view, but also wish to listen for a test how the presets are working, please apply
an analog signal with studio line level (CD/MD player, mixer output etc., preferably speech) to Analog
Input 1.
In first line, VIPdigital is a processor for microphone signals. However, the default internal presets
have been configured with a gain-setting of 0dB for reasons of safety to avoid feedback and
unintentional loud levels during the first setup. In addition, the phantom power is deactivated in the
default presets. Of course, you can adapt the gain-setting to your individual needs later at any time,
using the VIPremote Windows®software.
The following is the recommended procedure for a demonstration setup. Connect an analog line
source to the XLR Analog Input 1 on the back panel of the unit. Connect the Analog Left Out/Right Out
analog outputs to the line inputs of a mixer or a monitor unit.
Note that the audio level of your test signal is relevant. The settings of some audio modules e.g.
compressor and expander are related to the input level. You can check the input level tendency on the
upper LED-segment level indicator on the frontpanel of the unit.
Recall the first 3 internal presets by operating alternately the Preset Recall buttons.
Refer to the manual ...
... to become acquainted to the whole functional range of VIPdigital.
Find out, how to access all of the 100 internal preset memories of VIPdigital and how to work “online”
with your PC running VIPcon and VIPremote Windows®Software, and …
On the supplied CD-ROM there is an interactive manual in the pdf-format, which is also suited
for print-out. During software installation it is copied automatically to the VIPdigital program
folder. The file name is VIPd_manual.pdf .
(You need Adobe Acrobat Reader 5.0 or higher, supplied with the CD-ROM)
Software Installation
To use the whole functionality of VIPdigital, you will need a PC with Windows 95 or higher, a CD-ROM
drive and a free serial port (RS232).
Connect the PC serial port to one of the RS232 ports of your VIPdigital. Place the CD-ROM in the
drive and start the installation routine (SETUP.EXE). The user-friendly software guides you through
what you need to do. No need to worry – the set-up software will be copied onto your PC without
changing any settings on your computer!
Read all installation instructions carefully.
Note: VIPcon software has password protection. The default password is dvp
You can find a detailed description of all functions in the manual.
Please read the manual before using VIPdigital.
Any questions? Please get in touch with your dealer or contact us by e-mail on
[e-mail]
The YELLOWTEC team wishes you great enjoyment with your VIPdigital !

Yellowtec VIPdigital Getting started 4
VIPdigital 22.06.2004 Getting Started
Safety instructions
1. Before installation or operation of equipment read all safety instructions warnings and
operating instructions.
2. Heed all warnings on the equipment.
3. Follow the operating instructions.
4. Keep operating instructions for future reference.
5. Never use the equipment in the immediate vicinity of water. Ensure that water or damp cannot
get into the equipment.
6. Only install or fit the equipment in accordance with the manufacturers recommendations.
7. Ensure adequate ventilation when installing.
8. Never install or fit the equipment in the immediate vicinity of sources of heat such as boilers,
heating units and other equipment which generates heat. (Including amplifiers and other
electronic equipment.)
9. When connecting to a power supply ensure that it is the correct voltage and only use cables
as specified by the manufacturer in the operating instructions, or, as shown on the connector
panel of the equipment.
10. Only connect the equipment to a legally approved, earthed, mains power supply.
11. Position the power cable or cord in such a way that it cannot be walked upon or come into
contact with any object or thing that could damage the cable or cord. Attention should be given
to the point where the cable is attached to the equipment, and, where the cable connects to
the approved supply.
12. Ensure that foreign objects and liquids cannot get into the equipment.
13. Only clean the equipment as recommended by the manufacturer.
14. Disconnect the power cable or cord from the power supply if the equipment will be out of use
for a prolonged period.
15. In any situation where an incident occurs which could render the equipment unsafe, for
example
· damage to the power cable or cord
· entry of foreign objects or liquids (including water) into the equipment
· the equipment has been dropped or the casing has been damaged in any way
· any apparent change in performance
have the equipment checked immediately by a person technically qualified to make such
checks.
16.Never carry out any work on the equipment other than as specified in the operating manual.

Yellowtec VIPdigital Getting started 5
VIPdigital 22.06.2004 Getting Started
CE conformity declaration
EU Declaration of Conformity (EN 61000)
Product Audio equipment for digital and analog signals (Voice Processor)
Product name YELLOWTEC VIPdigital
Manufacturer THUM + MAHR GmbH
Heinrich-Hertz Str. 1-3
D-40789 Monheim am Rhein
Germany
Safety EN 60950
Basic standard EN 50081 – 1
EN 50082 – 2
Noise emission Radio interference EN 55103-1 class B
RF Interference EN 55103-2 class B
Immunity (EMC) IEC 1000 – 4 – 2
IEC 1000 – 4 – 4
IEC 1000 – 4 – 5
The manufacturer declares that the unit described here is in compliance with all technical
specifications mentioned and assumes operational conditions and typical equipment working
environment as described in the manual.
Monheim, January 17, 2000
Peter Thum

Yellowtec VIPdigital Getting started 6
VIPdigital 22.06.2004 Getting Started
Notice of Warranty
The terms and conditions of the Warranty applying to the Product accompanying this Notice of
Warranty are found exclusively in the Notice of Warranty. To the extent there is any inconsistency of
conflict between the terms and conditions of the Notice of Warranty and the terms and conditions
found anywhere else, including the Manual accompanying this Product, the terms and conditions of
this Notice of Warranty are superseding and control.
This Warranty covers „the Products“, which are defined as the various audio equipment, parts,
software and accessories manufactured, sold and/or distributed by Thum + Mahr GmbH (hereinafter
„T+M“).
With the exception of software-only items, the Products are warranted to be free from defects in
material and workmanship for a period of one year from the date of receipt by the end-user. Software-
only items are warranted to be free from defects in material and workmanship for a period of 90 days
from the date of receipt by the end-user. The terms and conditions of T+M‘s warranty in effect at the
time of shipment shall apply. In order to invoke this Warranty, notice of a warranty claim must be
received by T+M within the above-stated warranty period and warranty coverage must be authorized
by T+M. Notice of a warranty claim may be made orally by telephoning (++49-2173-967300) or in
writing sent by facsimile (++49-2173-967400) to or by e-mail ([email protected]). If T+M
authorizes the performance of warranty service and if T+M will be performing the warranty service, the
defective Product must be delivered, shipping prepaid, to: T+M, Heinrich-Hertz-Str. 1-3, D-40789
Monheim, Germany. If T+M authorizes the performance of warranty service and if it authorizes
another entity to perform that warranty service, the Product must be delivered, shipping prepaid, to
that entity, whose address will be provided by T+M. T+M (or its designee) at its option will either repair
or replace the Product and such action shall be the full extent of T+M‘s obligation, and buyer’s sole
remedy, under this Warranty. After the Product is repaired or replaced, T+M (or its designee) will
return it to the party that sent the Product and T+M will pay for the cost of shipping. T+M will have no
responsibility under this Warranty for any Products subject to: Acts of God, including (without
limitation) lightning; improper installation or misuse, including (without limitation) the failure to use
telephone and power line surge protection devices; accident; neglect or damage. T+M‘s dealers are
not authorized to assume for T+M any additional obligations or liabilities in connection with the
dealers‘ sale of the Products.
EXCEPT FOR THE ABOVE-STATED WARRANTY, T+M MAKES NO WARRANTIES, EXPRESS OR
IMPLIED (INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE).
In no event will T+M, its employees, agents or authorized dealers be liable for incidental or
consequential damages, or for loss, damage, or expense directly or indirectly arising from the use of
any Product or the inability to use any Product either separately or in combination with other
equipment or materials, or from any other cause.
Limited Warranty Duration
The duration of limited warranty for YELLOWTEC VIPdigital is one year according to the terms and
conditions of warranty of the manufacturer (see Notice Of Warranty).
