YKO YKO-705 User manual

INFANT SAFETY CARRIER
YKO-705
Group 0+
WARNING
DO NOT place rear-facing child
seat on front seats with airbags.
ENG-705-001
INSTRUCTIONS FOR USE
""
""
Notice
1.This is a Universal child restraint. It is approved to Regulation No.44,04
series of amendments, for general use in vehicles and it will fit most, but not
all, car seats.
2.A correct fit is likely if the vehicle manufacturer has declared in the vehicle
handbook that the vehicle is capable of accepting a Universal child
restraint for this group.
3.This child restraint has been declared "Universal" under more stringent
conditions than those applied to earlier designs which do not carry this
notice.
4.If in doubt , consult either the child restraint manufactured or the retailer.
Only suitable if the vehicle is fitted with 3-
point safety belts, approved to UN/ECE
Regulation No.16 or other equivalent
standards.

2
Contents
1. Applicability
2 Safety instructions
3 Parts and interior equipment
General use
5. Securing the infant carrier
6. Securing your baby
7. Maintenance and cleaning
8. Procedure after an accident
............................................................. 3
................................................... 4
.................................... 5
4. .............................................................. 6
4.1 Snapped the handle................................................... 6
........................................ 7
.................................................. 9
6.1 Setting the shoulder belt height................................... 9
6.2 Loosening the shoulder straps......................................9
6.3 Securing the baby with the harness.............................. 10
6.4 The use of buckle........................................................10
.......................................11
7.1 Take off the fabric cover...............................................11
7.2 Cleaning of the fabric cover..........................................11
7.3 Maintenance and cleaning............................................11
..................................... 11
.
.

3
NOTES
Please read through these instructions carefully before
using the baby car seat for the first time. You risk endangering
your child’s life if you use the product incorrectly
The baby car seat is suitable for weight categories 0+.
DO NOT place this baby seat on seats with
front airbags.
Only suitable if the vehicle is fitted with 3-point static, 3-
point retractor safety belts, approved to UN/ECE Regul-
ation No. 16 or other equivalent standards.
1. Applicability
roup 0 -13kg
G+:Birth
DIAGONAL BELT
LAP BELT

2. Safety instructions
Please invest a few minutes in your child’s safety to
read these instructions, Many injuries, which are easily
avoidable, are caused by carelessness and incorrect use.
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
The instructions can be retained on the baby car seat for
its life period in the case of built-in restraints.
DO NOT place this baby seat on seats with front airbags.
The baby car seat must be installed rearwards facing(in the
direction opposite the one in which you are travelling)
This baby car seat can only be installed using a three-point
vehicle belt.
Before each journey check whether the baby car seat is
installed firmly.
Do not change the baby car seat in any way.
Do not leave your baby unattended in the seat at any time.
Never use the seat as a shopping bag or as a means for
transporting something.
Protect the baby car seat system against direct sun light
otherwise the high temperature will hurt your child.
Ensure that all parts are locked in place correctly and not
penned in the adjustable seats or doors.
Luggage or other objects liable to cause injuries in the
event of a collision shall be properly secured.
The baby car seat must not be used without the cover.
The seat cover should not be replaced with any other than
the one recommended by the manufacturer.
Periodically inspect the harness , pay particular attention to
attachment points, stitching and adjusting devices
Do not continue to use the baby car seat if parts have
become damaged or have loosened after an accident.
4

5
Handle
Canopy
Shoulder belt slot
Harness
Chest pad
Buckle
Comfort pad
Harness
adjuster lever
Harness
adjuster strap
Shell
Button of handle
Lap belt guide
●
●
●
●
●
●
.
The handle of the baby car seat has to against the back of the
vehicle seat. If necessary, adjust the head rest of the vehicle
seat.
When you drive without a baby in the baby car seat, always
secure the system with the adult belt.
Not to use any load bearing contact points other than those
described in the instructions and marked in the child car seat.
We recommend using the baby car seat on the back seat of
cars.
There must be any covering above the child car seat.
It could be very dangerous to modify the baby car seat without
the certification from qualified authoritative institution, or add
any extra components, or install the baby car seats without
applying to the installation instruction of the manufactory.
3Parts and interior equipment

6
Fig.1 Fig.2 Fig.3 Fig.4
Diagonal belt guide
Shoulder belt slot
4. General use
4.1 Snapped the handle
The handle for the baby car seat can be
snapped into 4 stable positions.
To adjust the handle, please press the
red button of handle on both side at
the same time. now it can be rotated.
Adjust the handle of the baby car seat
when locking to suitable position and
check if it is locked well.
Fig. 1 Installed in the car (Position when the vehicle is been
driving).
This position(only this position)is suitable for the baby car
seat installed on the vehicle seat.
Fig 2:
：.
.Straight up for carrying.

7
Fig.1
Fig.2
Fig.3
Click
Fig 3: Handle clicked back to initiate the rocking feature.
Fig 4: Handle clicked down for a more upright sitting position,
easy to feeding.
.
.
Always ensure that the baby was fitted in the seat firmly by
the harness, and the handle is locked in position.
5. Securing the infant carrier
Step 1.
Step 2.
Step 3.
Please read the operating handbook in your vehicle to
inform yourself about the basics concerning children’s seats
in vehicles
DO NOT place this baby seat on seats with front airbags.
This baby car seat can only be installed using a three-point
vehicle belt.
The baby car seat must be Installed rearwards facing(in the
direction opposite the one in which you are traveling)
Adjust the handle to the forward
position (Fig. 1).
Put the seat in car's seat (Fig. 2). Put
the baby car seat against the backrest
of the vehicle seat.
Slide the lap belt of the vehicle’s 3-
point seatbelt through both Lap belt
guides. Let the tongue plate snap in the
belt lock with a clearly audible “click”.
Pull the shoulder belt in narrow
direction to tighten the lap belt
Check to make sure the tongue plate is
locked by pulling on the belt(Fig. 3).
.
.

8
Step .
Step .
4 Place the diagonal belt in the
diagonal belt guide at the back of the seat.
Turn the handle of the seat to the
appropriate place in the car. (Hearing
“click”) Be sure the handle has been
locked and it should be firmly against the
backrest of car’s seat.
5 Tighten the vehicle`s own 3-point
seatbelt by pulling hard on the positions
showed in fig. 5
Attention: The handle of the seat must be firmly against the
backrest of car seat.
You can release the child if you act the above steps in
reversal ways.
Make sure all the belts` position is right and they has not
become twisted. Also check that the cover is not impeding the
movement or fit of the belt webbing in any way.
The satisfactory position of the adult safety-belt buckle
relative to the child car seat is as the Fig 6. Fig.7 is incorrect.
You can contact the child car seat manufacturer if in doubt
about this point.
.
Fig.4
Fig.6 Fig.7
Fig.5

9
ý- Too high
ý- Too low
6. Securing your baby
6.1 Setting the shoulder belt height
Check whether the shoulder belts are set at the right height for
your child. The shoulder belts should be fed into the belt slots that
lie at shoulder height or just above.
If the height of your shoulder belts in child car seat is not fit for
your child, Adjust the height of the shoulder belts, please
proceed as follows:
loosen the shouider harness (see
point 6.2).
Pull out the buckle tongues from
the chest pad and the slots on the
cover and the shell, then thread them into
the corre-sponding belt slots.
Ensure that both of the shoulder belts go through slots at the
same height, and not twisted.
The shoulder straps is slackened by
pressing the lever (under the seat cover)
on the front of the seat.
Press down on the label marked“Press”
as you grip the two shoulder straps with
your other hand. Pull the shoulder straps
towards you to loosen it.
Step 1:
Step 2:
6.2 Loosening the shoulder straps
●
●

10
Fig.2
Fig.1 Fig.3
6.3 Securing the baby with the harness
1. Firstly adjust the shoulder straps height (see point 6.1) ,
proceed as follows.
2. Loosen the harness (see point 6.2),open the buckle, and place
them down sideways.Seat your child in the child car seat Place
both shoulder straps over your child’s shoulders.
3. Lock the buckle tightly.
4. Ensure that the straps are close to the should of the child by
pulling the straps tightly.
,
.
●The harness should be adjusted as tightly
as possible without causing discomfort to
your child.
●It is dangerous not to tighten the straps.
Check the adjuster and be sure that the
straps are pulled tightly, not twisted after
install it each time.
6.4 The use of buckle
1. Put the two metal sections of the buckle connectors together
(fig.1).
2. Slot the two buckle connectors into the slot in the top of the
buckle until they “click” into place (fig.2).
3. Check the harness is correctly locked by pulling the shoulder
straps upwards (fig.3).
4. To release the harness, press the red button on the buckle
downwards.

11
7. Cleaning
Maintenance and
7.1 Take off the fabric cover
Step 1:
Step 2:
Step 3:
7.2 Cleaning of the fabric cover
First pull out the harness from the seat.
Unfasten the bottles crew on the handle, then take off the
canopy from backwards.
Loosen the elastic, you can take off the fabric cover from
upwards.
You can put on the canopy if you act the above steps in
reversal ways.
Use only neutral detergent and warm water to wash.Do not wash
by machine, spin-dry or tumble-dry are not recommended.
30
P
THIS COVER SHOULD BE HAND WASH
7.3 Maintenance and cleaning
1. Please often check the function and spare parts of the baby car
seat are in good condition to avoid accident.
2. Before using, please check the locking fastness of the buckle by
pulling in effort the straps and see whether the buckle is loose or
not.
3. Do not use the baby car seat in cold, wet or hot circumstance for
long time.
8. Procedure after an accident
The child car seat must be replaced when it has been subject to
violent stresses in an accident.
Manufacturer: Zhenjiang YKO Child Product Co.,Ltd
Address: 8Sigewan jiangqiao,Zhenjiang, Jiangsu
Tel: +(86)-511-85950011
Fax: +(86)-511-85950033
