YOKOGAWA YS1000 Series User manual

User’s
Manual
YS1350 Manual Setter for SV Setting
YS1360 Manual Setter for MV Setting
User’s Manual
IM 01B08E02-02EN
IM 01B08E02-02EN
4th Edition
Functional
Enhancement

i
IM 01B08E02-02EN
4th Edition : Dec. 2019 (YK)
All Rights Reserved, Copyright © 2014 Yokogawa Electric Corporation
Introduction
Thank you for purchasing the YS1000 series single-loop controller (hereinafter referred to as “YS1000”).
This manual describes how to use YS1350 and YS1360 functions other than communication function. Please read
through this user’s manual carefully before using the product.
Note that the manuals for the YS1350/YS1360 comprise the following ve documents:
● Printed manual
Manual Name Manual Number Description
YS1350/YS1360 Operation Guide IM 01B08E02-01EN This manual describes the basic operation method.
● Electronic manuals
Manual Name Manual Number Description
YS1350/YS1360 Operation Guide IM 01B08E02-01EN This is identical to the printed manual.
YS1350/YS1360 User’s Manual IM 01B08E02-02EN This manual. It describes the usage of all functions except the
communication functions.
YS1000 Series Communication
Interface User’s Manual IM 01B08J02-01EN
This manual describes how to use YS1000 in Ethernet, serial,
and DCS-LCS communications. For communication wiring, see
the Operation Guide.
YSS1000 Setting Software/YS1700
Programmable Function User’s Manual IM 01B08K02-02EN
This manual describes how to use YSS1000 and YS1700’s
programmable function and peer-to-peer communication
function.
YS1000 Series Replacement Manual IM 01B08H02-01EN This manual describes the compatibility of installation and
wiring with YS100, YS80, EBS, I, EK, HOMAC, and 100 line.
User’s manuals for YS1000 are available on the following web site: www.yokogawa.com/ns/ys/im/
You need Adobe Reader 7.0 or later (but the latest version is recommended) installed on the computer in order to
open and read the manuals.
Notice
●The contents of this manual are subject to change without notice as a result of continuing improvements to the
instrument’s performance and functions.
● Every e󰀨ort has been made to ensure accuracy in the preparation of this manual. Should any errors or
omissions come to your attention, however, please inform YOKOGAWA Electric’s sales o󰀩ce or sales
representative.
●Under no circumstances may the contents of this manual, in part or in whole, be transcribed or copied without
our permission.
Trademarks
●Our product names or brand names mentioned in this manual are the trademarks or registered trademarks of
YOKOGAWA Electric Corporation (hereinafter referred to as YOKOGAWA).
●Microsoft, MS-DOS, Windows are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
●Adobe, Acrobat, and Postscript are either registered trademarks or trademarks of Adobe Systems Incorporated.
●Ethernet is a registered trademark of XEROX Corporation.
●We do not use the TM or ® mark to indicate these trademarks or registered trademarks in this user's manual.
●All other product names mentioned in this user's manual are trademarks or registered trademarks of their
respective companies.

ii IM 01B08E02-02EN
How to Use This Manual
Usage
First read through the Operation Guide to understand the basic operations and then read this manual. For the
communication functions and replacements, see the respective manuals.
This User’s Manual is organized into Chapters 1 to 6 as shown below:
Chapter Title and Description
1 Input/output and Auxiliary Function
Describes the input/output function, operation and setting items.
2 Display Function/Security Function
Provides the LCD display functions, adjustments, and setting items.
3 Adjustment of Direct Inputs (Temperature, Resistance, and Frequency)
Describes the settings and adjustments for the direct input converter built into the YS1350/1360.
4 Power Failure Recovery Processing
Describes operations performed after momentary power interruption and power failures.
5 Maintenance
Describes ordinary inspections, indicating accuracy inspections, and part replacement cycles.
6 Specifications
Provides the YS1350/1360 specifications.

iii
IM 01B08E02-02EN
Symbols Used in This Manual
This symbol is used on the instrument. It indicates the possibility of injury to the user or damage to the instrument,
and signies that the user must refer to the user’s manual for special instructions. The same symbol is used in the
user’s manual on pages that the user needs to refer to, together with the term “WARNING” or “CAUTION.”
WARNING
Calls attention to actions or conditions that could cause serious or fatal injury to the user, and indicates precautions
that should be taken to prevent such occurrences.
CAUTION
Calls attention to actions or conditions that could cause injury to the user or damage to the instrument or property
and indicates precautions that should be taken to prevent such occurrences.
Note
Identies important information required to operate the instrument.
Indicates related operations or explanations for the user’s reference.
[ ]
Indicates a character string displayed on the display.
Setting Display
Indicates a setting display and describes the keystrokes required to display the relevant setting display.
Setting Details
Provides the descriptions of settings.
Description
Describes restrictions, etc. regarding a relevant operation.

Blank Page

v
IM 01B08E02-02EN
6
5
4
3
2
1
Index
Contents
Introduction ........................................................................................................................................i
How to Use This Manual ..................................................................................................................ii
Symbols Used in This Manual ........................................................................................................ iii
Chapter 1 Input/output and Auxiliary Function
1.1 Function Block Diagram ................................................................................................... 1-1
1.1.1 YS1350...................................................................................................................................1-1
1.1.2 YS1360...................................................................................................................................1-1
1.2 Compensating or Computing Process Variables ............................................................. 1-4
1.2.1 Input Filter (First-order Lag Operation) ..................................................................................1-4
1.2.2 Square Root Extraction (Low Cuto󰀨 Adjustable) ...................................................................1-4
1.3 Changing the Valve Direction (YS1360)........................................................................... 1-5
1.4 Setting Alarm Output Hysteresis ..................................................................................... 1-6
1.5 Setting Digital Input Function ........................................................................................... 1-7
1.6 Setting Digital Output Function......................................................................................... 1-9
1.7 Using the Event Function .............................................................................................. 1-10
1.7.1 Displaying Messages (Event Display Function (Settable Only in YSS1000)) ......................1-10
1.7.2 Changing the PV Bar Display Color in the Event of a Process Alarm (Active Display Function) .1-12
1.7.3 Operator Notication Using Tag Number Display (Alternate Tag Number Color Display
Function) .............................................................................................................................1-13
1.8 Setting the Display for When Measurement Input Is Not Wired ..................................... 1-14
Chapter 2 Display and Security Functions
2.1 Display Function............................................................................................................... 2-1
2.1.1 Setting Visible/Invisible Status of the Operation Display........................................................2-1
2.1.2 Setting Visible/Invisible Status of TREND Display Data ........................................................2-3
2.1.3 Changing the Time Span of TREND Displays........................................................................2-4
2.1.4 Setting Display Data on the TREND 3 Display.......................................................................2-5
2.1.5 Changing Scale Divisions on the LOOP, TREND, and DUAL Displays .................................2-6
2.1.6 Automatic Scale Divisions/Making Scale Values More Legible on the METER Display ..... 2-7
2.1.7 Selecting the Operation Display to be Displayed First at Power ON......................................2-8
2.1.8 Turning the LCD Backlight ON/OFF.......................................................................................2-9
2.1.9 Changing the Background and Loop Colors ........................................................................2-10
2.1.10 Adjusting LCD Brightness .................................................................................................... 2-11
2.2 Security Function............................................................................................................ 2-12
2.2.1 Setting/Releasing Keylock ...................................................................................................2-12
2.2.2 Inhibiting/Enabling Parameter Change.................................................................................2-13
Chapter 3 Adjusting Direct Inputs (Temperature/Resistance/Frequency)
3.1 List of Direct Input Specications and Basic Operations.................................................. 3-1
3.2 Setting Sensor Type ........................................................................................................ 3-4
3.3 Setting Burnout................................................................................................................. 3-5
3.4 Making Zero and Span Adjustments of Input .................................................................. 3-6
Chapter 4 Processing during Power Failures
4.1 Processing during Power Failures.................................................................................... 4-1
Chapter 5 Maintenance
5.1 Inspecting Indication Accuracy ........................................................................................ 5-1
5.1.1 Calibration Instruments ..........................................................................................................5-1
5.1.2 Inspecting Input Indication Accuracy......................................................................................5-1

vi IM 01B08E02-02EN
5.1.3 Inspecting Output Indication Accuracy ..................................................................................5-2
5.2 Recommended Part Replacement Period ....................................................................... 5-3
5.3 Packaging when Shipping the Product for Repair ........................................................... 5-4
Chapter 6 Specications
6.1 General Specications .................................................................................................... 6-1
Index
Revision Information

1-1
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
1.1 Function Block Diagram
1.1.1 YS1350
The following figure shows the function configuration.
Measurement input
X1
Square root
extraction and low
cutoff adjustable
PLC1
ON
OFF
High/Low limit alarm
PV
display
LCD
backlight
Backlight OFF
DI2
PH1
DO1
PSR1
PV1
Action mode
switching input
DI1
SV
display


SV key
Cascade
input
X2
SV1
M C
PL1
DO2
SV output
Y2
C/M status
DO4
0101E.ai
Input filter
PLG1
Function Block Diagram of YS1350
1.1.2 YS1360
The following figure shows the function configuration.
Measurement input
X1
Square root
extraction and low
cutoff adjustable
PLC1
ON
OFF
High/Low limit alarm
PV
display
LCD
backlight
Backlight OFF
DI2
PH1
DO1
PSR1
PV1
Action mode
switching input
DI1
MV
display
Cascade
input
X2
MV1
M C
PL1
DO2
MV output 2
Y2
C/M status
DO4

MV key
< >

MV output 1
Y1
Limiters
MH1, ML1
0102E.ai
Input filter
PLG1
Function Block Diagram of YS1360
Chapter 1 Input/output and Auxiliary Function

1-2 IM 01B08E02-02EN
■ Ramp Follow-up (YS1350/YS1360)
The YS1350 manual setter for SV setting and YS1360 manual setter for MV setting
switch the ramp characteristic bumplessly when switching from mode M to mode C.
The switching rate is 40 seconds/full scale.
For example, if 50% output in mode M is switched to 75% output in mode C as shown in
the figure below, the output reaches the 75% level in 10 seconds following a gradient of
being full scale in 40 seconds.
10 sec.
10 sec.
40 sec. Time
Output
%
100
75
50
25
0
M mode C mode
0103E.ai
Setting Details
Parameter Name Setting Range Display Transition and Display Title
CMOD1 C-mode 1
-: None,
CAS: Analog cascade setting mode,
CMP: Computer cascade setting
mode
Tuning Display >
Engineering Display >
[CONFIG2] (Conguration Display 2)
■ Current Output Characteristics (YS1360)
The current output of the YS1360 manual setter for SV setting provides a forced full-
closing function for valves (final control elements).
When a signal decreases, if an output signal becomes -6% (equivalent to 3.04 mA)
or less, the current output decreases abruptly, reaching -20% (equivalent to 0.8 mA).
When a signal increases, if the output signal reaches -5% or more, the current output is
released from -20% (equivalent to 0.8 mA) and returns to -5% (equivalent to 3.2 mA).
When the output signal is 100% or more, the current output increases linearly and is
limited at approximately 106.25% (21 mA).
21
Output Signal
(%)
Current Output
(mA)
20
4
3.2
3.04
0.8
0 100 106.25-6 -5
0104E.ai
1.1 Function Block Diagram

1-3
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
■ High and Low Limiters for Manipulated Output Signals (YS1360)
In mode C (Analog cascade or Computer cascade), limiters can be set for manipulated
output signals. (This feature does not function in mode M.)
High limit, MH1: -6.3 to 106.3%
Low limit, ML1: -6.3 to 106.3%
Main Parameter Functions
Main Functions Reference Destination
Square root extraction 1.2.1 Square Root Extraction (Low Cuto󰀨 Adjustable)
Digital input function 1.5 Setting Digital Input Function
Other Function
Main Functions Reference Destination
Display function Chapter2, Display/Security Functions
Communication function YS1000 Series Communication Interface User's Manual
1.1 Function Block Diagram

1-4 IM 01B08E02-02EN
1.2 Compensating or Computing Process
Variables
1.2.1 Input Filter (First-order Lag Operation)
Description
First-order lag operation is performed on PV input. This function is used if there are
significant variations in the display value such as the presence of noise. The greater the
time constant, the stronger the filtering function.
Input Example of filtering
for 2 seconds
Example of filtering
for 10 seconds
0201E.ai
Setting Details
Parameter Name Setting Range Display Transition and
Display Title
PLG1 First-order lag time constant for PV 0.0 to 800.0 sec
Tuning Display >
[SETTING] (Setting
Display)
1.2.2 Square Root Extraction (Low Cutoff Adjustable)
Description
Square root extraction is performed on a process variable (PV). The input and output
characteristics are that input = output at the low cutoff point or below. There is no
hysteresis.
Low cutoff adjustable
Output = input
Output
Input
0202E.ai
Square Root Extraction Characteristics
Setting Details
Parameter Name Setting Range Display Transition and Display Title
PSR1 Square root extraction for
PV1 OFF, ON
Tuning Display >
Engineering Display >
[CONFIG3] (Conguration Display 3)
PLC1 Square root extraction low
cuto󰀨 setpoint for PV 0.0 to 100.0% Tuning Display > [SETTING] (Setting Display)

1-5
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
1.3 Changing the Valve Direction (YS1360)
Description
The valve direction is used to decide "C-O" or "O-C" displayed in LCD.
Setting Details
Parameter Name Setting Range Display Transition and Display
Title
VDIR1 Valve direction
C–O: Manipulated
output variable
0% = C
100% = O
O–C: Manipulated
output variable
0% = O
100% = C
Tuning Display > Engineering
Display > [CONFIG2]
(Conguration Display 2)

1-6 IM 01B08E02-02EN
1.4 Setting Alarm Output Hysteresis
Description
Setting hysteresis (differential gap) to alarm action prevents chattering in digital output.
High limit alarm setpoint for PV
Low limit alarm setpoint for PV
High limit alarm output for PV
Low limit alarm output for PV
PV
Closed
Open
Closed
For an example in the figure above, the contact type is such that the contact
opens if an event occurs (factory default).
Alarm hysteresis (HYSn)
Alarm hysteresis (HYSn)
Open
Time
0213E.ai
Setting Details
Parameter Name Setting Range Display Transition and Display Title
HYS1 Alarm hysteresis
Equivalent to 0.0
to 20.0% in the
engineering unit
Tuning Display >
[SETTING] (Setting Display)

1-7
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
1.5 Setting Digital Input Function
Description
Changing action of Operation mode by digital input.
When using this in the analog cascade mode (CMOD1=CAS), the operation mode can
be switched through digital input.
Operation
Mode Display
Lamp
DI1F
Parameter
DI1D
Parameter
Digital
Input
LOOP Display
Control Status
Display
Operation
Mode
Operation
Mode Status
Output
M lamp lights - or E-MAN OPN or
CLS
OPEN or
CLOSE No display M OPEN
C lamp lights – OPN or
CLS
OPEN or
CLOSE CAS C CLOSE
C lamp lights
and M lamp
blinks
E-MAN
OPN OPEN CAS,
EXT-MAN M OPEN
C lamp lights CLOSE CAS C CLOSE
CLS
OPEN CAS C CLOSE
C lamp lights
and M lamp
blinks
CLOSE CAS,
EXT-MAN M OPEN
Switching to manual control (TR-MAN)
When a digital input signal (DI) is switched from "Close" to "Open", the operation mode
switches to manual (MAN) mode. The M mode key lights in yellow in the Operation
Display.
When a digital input signal (DI) is switched from "Open" to "Close", the operation does
not change.
(When the contact type is OPN)
Switching to cascade control (TR-CAS)
When a digital input signal (DI) is switched from "Close" to "Open", the operation mode
switches to cascade (CAS) mode. The C mode key lights in green in the Operation
Display.
When a digital input signal (DI) is switched from "Open" to "Close", the operation does
not change.
(When the contact type is OPN)
All event elimination (TR-EVT.C)
When a digital input signal (DI) is switched from "Close" to "Open", all the displayed
events are cleared. For all other cases, events are displayed when the display conditions
are met.
After the event display is cleared, if the digital input signal (DI) remains "Open", when an
event display condition is met, the corresponding event (1 to 5) is displayed.
(When the contact type is OPN)
If any front panel key is pressed once while the LCD backlight is OFF, it will be turned
ON again.

1-8 IM 01B08E02-02EN
Setting Details
Parameter Name Setting Range Display Transition and
Display Title
DI1F DI1 function selection
NONE: No function
E-MAN: Switching to manual
mode (status)
TR-MAN: Switching to manual
mode
TR-CAS: Switching to cascade
mode
TR-EVT.C: All event OFF
Tuning Display >
Engineering Display >
[CONFIG3] (Conguration
Display 3)
DI2F DI2 function selection
NONE: No function
TR-MAN: Switching to manual
mode
TR-CAS: Switching to cascade
mode
LCD-OFF: LCD backlight OFF
TR-EVT.C: All event OFF
DI1D DI1 contact type OPN: Function is available
when the contact is open.
CLS: Function is available
when the contact is closed.
DI2D DI2 contact type
1.5 Setting Digital Input Function

1-9
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
1.6 Setting Digital Output Function
Description
There are the follwing three digital outputs.
DO1: Hig limit alarm output, current output open status output or no function
DO2: Low limit alarm output, current output open status output or no function
DO4: C/M status output, current output open status output or no function
Setting Details
Parameter Name Setting Range Display Transition and
Display Title
DO1F DO1 function
selection
NONE: No function assigned
PH1: High limit alarm for PV1
OOP: Current output open
Tuning Display >
Engineering Display >
[CONFIG3] (Conguration
Display 3)
DO2F DO2 function
selection
NONE: No function assigned
PL1: Low limit alarm for PV1
OOP: Current output open
DO4F DO4 function
selection
NONE: No function assigned
CAS: Cascade mode
OOP: Current output open
DO1D DO1 Contact type
OPN: When the event occurs,
the contact is open.
CLS: When the event occurs,
the contact is closed.
DO2D DO2 Contact type
DO4D DO4 Contact type

1-10 IM 01B08E02-02EN
1.7 Using the Event Function
1.7.1 Displaying Messages (Event Display Function (Settable Only in
YSS1000))
Description
The event display function displays a message (in Japanese, English, or Chinese) on the
Operation Display if an event such as an abnormality occurs, providing guidance for the
operator. A maximum of five events can be set using the YSS1000 Setting Software (sold
separately). Events will be displayed on all Operation Displays. The display area is 200 ×
80 dots, with 50 × 80 dots of that used to display a clearing guide.
If multiple events occur simultaneously, they are displayed in an overlaid condition. The
order of priority is (high) event 1 > 2 > 3 > 4 > 5 (low), and the event with the highest
priority is displayed on top. The event being displayed can be cleared by pressing and
holding the SHIFT key for three seconds, contact input (DI), or communication. Moreover,
events can be redisplayed on Alarm Display.
► For how to redisplay events: see “Monitoring and Operating the Alarm Display” in the YS1350
Manual Setter for SV Setting/YS1360 Manual Setter for MV Setting Operation Guide.
Only foreground event
is cleared.
Press and hold
the SHIFT key
for three
seconds
Press and hold
the SHIFT key
for three
seconds
SHIFT SHIFT
0209E.ai
Set using the YSS1000
Setting Software
Clearing guide display
(fixed display)
Events are overlaid for
display if multiple events
occur simultaneously.

1-11
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
Event flag
The status register is the flag to indicate an event. An event is displayed if the status
register changes from 0 to 1 or from 1 to 0.
Process alarm such as a high limit alarm and operation mode can be registered as a flag.
Simulation Display
After downloading the event display data from YSS1000, the event can be displayed
forcibly. Simulation display can be set when operation is stopped.
To cancel simulation display:
(1) Turn OFF simulation display on YSS1000.
(2) Change the operation stop status from stopped to operating.
(3) Turn the power supply OFF and then ON.
Deletion Guide Display Language
0105E.ai
English
1.7 Using the Event Function

1-12 IM 01B08E02-02EN
1.7.2 Changing the PV Bar Display Color in the Event of a Process Alarm (Active
Display Function)
Description
The active color display function changes the colors of the PV bar on the LOOP Display
to red to inform the operator of instrument abnormality. Active color display can be set on
a loop basis and items can be selected from each loop’s process alarms (see the table
below).
Occurrence of
event
Loop 1
active display
0211E.ai
Setting Details
Parameter Name Setting Range Display Transition and
Display Title
ACTD1
Active color
display
selection 1
OFF: None
PH1: High limit alarm setpoint for PV 1
PL1: Low limit alarm setpoint for PV 1
1-ALM: Logical OR of all loop 1 alarms
Tuning Display >
Engineering Display >
[DISPLAY] (Setting Display
for Operation Display)
1.7 Using the Event Function

1-13
IM 01B08E02-02EN
Input/output and Auxiliary Function
1
1.7.3 Operator Notification Using Tag Number Display (Alternate Tag Number
Color Display Function)
Description
In the event of an ALM lamp lighting, the alternate tag number color display function
notifies the operator of instrument abnormality by alternating the color of the tag number
background back and red.
► For lighting of ALM lamp: see “How to Take Actions if the ALM Lamp or FAIL Lamp Lights up ”
in the YS1350 Manual Setter for SV Setting/YS1360 Manual Setter for MV Setting Operation
Guide.
Alternate tag
number color display
Event
occurrence
0212E.ai
Setting Details
Parameter Name Setting Range Display Transition and Display Title
TAGAL
Color
inversion of
tag number
OFF: Disabled
ON: Enabled
Tuning Display > Engineering Display
> [DISPLAY] (Setting Display for
Operation Display)
1.7 Using the Event Function
