YOKOGAWA JUXTA F Series User manual

User’s
Manual
1
Thank you for purchasing the JUXTA Signal Conditioner.
Please read through this manual before use for correct handling.
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
http://www.yokogawa.com/ns/juxta/im/
You can download the latest manuals from the following website:
IM 77J08P01-01EN
1st Edition Oct. 2017 (YK)
CAUTIONARY NOTES FOR SAFE USE OF THE
PRODUCT
This User’s Manual should be carefully read before installing and
operating the product. Please keep this User’s Manual for future
reference. The following symbol is used on the product and in this
manual to ensure safe usage.
WARNING
Calls attention to actions or conditions that could
cause serious or fatal injury to the user, and indicates
precautions that should be taken to prevent such
occurrences.
The following symbols are used only in this manual.
CAUTION
Calls attention to actions or conditions that could
cause injury to the user or damage to the instrument
or property and indicates precautions that should be
taken to prevent such occurrences.
CHECKING PRODUCT SPECIFICATIONS AND
PACKAGE
(1) Checking the Model and Product Specications
Check that the model and specications indicated on the
nameplate
attached to the main unit are as ordered.
(2) Packaged Items
Check that the package contains the following items:
zFP1P: 1
zMounting block: 2
zTag number label : 1
zMounting screw (M4 x 0.7): 2
zUser’s Manual (this manual)
GENERAL
The FP1P is a compact, front terminal connection type pulse
repeater that converts pulses from voltage-free contacts, open
collector contacts, voltage pulses, and current pulses into isolated
transistor switch pulses.
MODEL AND SUFFIX CODES
Model Sufx codes Description
FP1P -1 *C Pulse Repeater
Input Signal -1 Transmitter power supply (12 V ±10%)
-2 Transmitter power supply (24 V ±10%)
Output Signal 0 Open collector
Style code *C Style C
1. MOUNTING METHOD
1.1 Installing/Uninstalling the Mounting Block
The mounting block is necessary for rack mounting or wall
mounting.
Installing the mounting block
zFit the mounting block into the grooves of the converter, and
slide it in the direction of an arrow as shown below-left.
Uninstalling the mounting block
zLift the stopper using a slotted screw-driver as shown be-
low-right, and pull the mounting block to remove it.
Groove
(Rack mounting)
Groove (Wall mounting) Stopper
Mounting block
1.2 Rack Mounting
Take the FRK panel and install it on a mounting angle as shown
below. This method is suitable for high density mounting of the
converters on a 19-inch rack panel.
Mounting angle
M5 screw
(4 places)
FRK panel
Mounting screw (M4x0.7)
(2 screws in the package)
Mounting Dimensions
Mounting angle
450±1
465±1
Supplied spacer(50) or Wiring space(30 to 60)
50
25
25
50
Unit: mm
FP1P
Pulse Repeater
2IM 77J08P01-01EN 1st Edition 2017.10.30-00
1.3 Wall Mounting
Mount the converter onto the FRK panel as shown below or
mount it directly on the wall.
FRK panel
1.4 DIN Rail Mounting
Place the converter so that the DIN rail ts into the upper part of
the DIN-rail groove at the rear of the converter, and push until it
clicks. The converter is xed by a slide lock (at the lower part on
the rear side of the converter).
To remove the converter, pull down the slide lock using a slotted
screw-driver.
Slide lock
DIN rail
DIN rail groove
1.5 Mounting Dimensions
Angle Mounting Dimensions
Mounting angle
M4×0.7 Mounting screw
Support
24.5
24.5
24.5
24.5 24.5
n×24.5+2
Unit: mm
73 90
Wall Mounting Dimensions
M4×0.7 Mounting screw
Unit: mm
24.5
24.5
24.5 24.5 24.5
90
2. INSTALLATION LOCATION
zAvoid the following environments for installation locations:
Areas with vibration, corrosive gases, dust, water, oil, solvents,
direct sunlight, radiation, a strong electric eld, and/or a strong
magnetic eld, altitude of more than 2000m above sea level.
zIf there is any risk of a surge being induced into the power line
and/or signal lines due to lightning or other factors, a dedicated
lightning arrester should be used as protection for both this
converter and a eld-installed device.
zOperating temperature/humidity range: 0 to 50ºC/5 to 90%RH
(no condensation)
3. EXTERNAL WIRING
WARNING
Be sure to turn OFF the power supply before wiring to
avoid the risk of electric shock. Use a tester or similar
device to ensure that no power is being supplied to a
cable to be connected
.
M4 screw terminals are provided for the connection of external
signals. Attach a crimp-on lug to each wire for connection to the
terminals.
zRecommended cables: A nominal cross-sectional area of 0.5
mm2 or thicker for signal cables, and that of 1.25 mm2or thicker
for power cables.
1
2 3
4 5
6 7
6
7
4
5
Output
Input
Power supply
1
2
3
1
2
2
3
Transmitter
Transmitter
Transmitter PS+
+
–
+
–
+
–
PS+
–
+
–
When receiving
current pulse by
running a
transmitter on an
internal power
supply
When receiving
voltage pulse by
running a
transmitter on an
internal power
supply
When receiving
non-voltage
contact signal or
voltage pulse
CAUTION
● Thisinstrumentmayoutputapulsewhenthepower
is turned on/off. Depending on the connected
devices, this pulse output is counted as “one
pulse.”
● Donotconnectanythingtotheterminalsthatare
not used in the wiring diagram. Otherwise it may
cause the malfunction or damage.
● Thepowerlineandinput/outputsignallinesshould
be installed away from noise-generating sources.
Otherwise accuracy cannot be guaranteed.
● Adherestrictlytothespecicationstoavoid
overheating or damage. Before turning on the
power, ensure the following:
(a) Power supply voltage and input signal value applied
to the product should meet the required specica-
tions.
(b) The external wiring to the terminals are as specica-
tions.
● Donotoperatetheproductinthepresenceof
ammableorexplosivegasesorvapors.
● Theproductissensitivetostaticelectricity;
exercisecareinhandling.Beforeyouoperatethe
product, touch a nearby metal part to discharge
static electricity.
3IM 77J08P01-01EN 1st Edition 2017.10.30-00
Power Supply and Isolation
Power supply voltage: 24 V DC ±10% (percentage ripple: less
than 5% p-p)
Current consumption:24V DC 60 mA
Insulation resistance: 100 MΩ at 500 V DC between input and
output, output and power supply, and input and
power supply.
Withstand voltage: 1500 V AC/min. between input and (output
and power supply)
500 V AC/min. between output and power supply.
4. SETTING THE LOAD RESISTANCE FOR
CURRENT PULSES AND THE INPUT FILTER
If the signal from the generator is a current pulse, it needs to be
converted into voltage using load resistance for current pulses.
Further, if the input contains chattering noise and the like, you can
set an input lter to suppress its effect.
zThe load resistance and lter are set using a DIP switch (SW1)
inside the product.
4.1 SETTING THE LOAD RESISTANCE
Set the load resistance so that the relationship between the peak
current i (p-p) from the generator and the combined load resis-
tance RL satises the following: swing width i × RL ≥ 3V.
EL
EH
24 V or less
(peak value)
EH – EL = 3 V or more
(swing width)
0V
Set the resistance by turning on or off the DIP switch (SW1-2,
SW1-3, SW1-4).
When the SW1 settings are all off
1 2 3 4
ON
Use a pointed object to flip
the switches between on
and off.
SW1
ON
OFF
Resistance
value
SW1 DIP switch setting
234
200 Ω ON
1 2 3 4
ON
OFF OFF
510Ω ON
1 2 3 4
ON
OFF OFF
1kΩ ON
1 2 3 4
ON
OFF OFF
144Ω ON ON
1 2 3 4
ON
OFF
167Ω ON ON
1 2 3 4
ON
OFF
338Ω ON ON
1 2 3 4
ON
OFF
126Ω ON ON ON
1 2 3 4
ON
4.2 SETTING THE INPUT FILTER
Set SW1-1 to ON. An input lter with a time constant around 10
ms will be connected.
1 2 3 4
ON
ON
zIf the input lter is set to ON, the input frequency will be limited
to no more than 100 Hz and the pulse width to no less than 3
ms.
5. MAINTENANCE
The product starts running immediately when the power is turned
on; however, it needs 10 to 15 minutes of warm-up before it
meets the specied performance.
5.1 Calibration Apparatus
zA calibrator (YOKOGAWA CA150 or equivalent)
5.2 Calibration Procedure
1. Connect the instruments as shown below.
1
2 3
4 5
6 7
2
3
6
7
Calibrator
Calibrator
24 V DC
Power supply
Input
Output
+
−
+
−
+
−
4
5
2 Apply a calibrator-generated rectangular pulse at any frequency
within the specications to the input.
3. Measure the output with the calibrator, and check that the pulse
frequency is the same as the input frequency.
