York EABC-F018S Quick start guide

036-21320-002 Rev. A (1103)
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
SPLIT-SYSTEM HEAT PUMPS
12 SEER
MODELS:
E*BC-F018 THRU 060
(1.5 THRU 5 TONS, 1 PH)
E*BC-(T,W)036 THRU 060
(3 THRU 5 TONS, 3 PH)
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at www.york.com for the most
up-to-date technical information.
Additional rating information can be found at
www.ariprimenet.org.
U
NI
T
A
R
Y
HE
A
T
P
U
M
P
T
E
Q
U
I
P
M
E
N
R
S
EC
T
I
O
N
S
A
T
I
O
N
E
RT
I
F
I
C
C
OF
D
ST
A
N
D
A
R
I
A
R
2
4
0
M
A
NU
F
A
CT
U
R
E
R
C
E
R
T
I
F
I
E
D
C
L
Y
OM
P
I
N
G
T
O
A
R
IA
S
LISTED
This product was manufactured
in a plant whose quality system
is certified/registered as being
in conformity with ISO 9001.
Certification applies only
when the complete
system is listed
with ARI.
TECHNICAL
GUIDE
TECHNICAL
GUIDE
DESCRIPTION
The 12 SEER series heat pumps are designed for use with a
variety of UPG evaporator sections to suit any application
need. A full line of matching Add-On Coils are available for use
with upflow, downflow or horizontal furnaces. Matching Air
Handlers are also available for upflow, downflow or horizontal
installation to provide a complete system. Electric heat may be
installed in air handlers. All units are factory charged to assure
easy installation.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
10-year limited compressor warranty.
Three Phase Units:
1-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
•DURABLE CONSTRUCTION - The outdoor unit is con-
structed of pre-painted steel that offers tough protection
against corrosion and resists fading when exposed to sun-
light. Drain holes are incorporated into the base pan to per-
mit free drainage of moisture.
•QUALITY COILS - The coil is constructed of copper tube
and aluminum fins.
•COIL PROTECTION - Coils are protected from damage by
a polymer mesh applied between the coil face, and a PVC
coated steel coil guard.
•PROTECTED COMPRESSOR - The hermetic compressor
is internally protected against high pressure and tempera-
ture by the simultaneous operation of a high pressure relief
valve and temperature sensors which stop the compressor
if operating temperatures go too high. Both protectors reset
automatically. A discharge line solid core filter drier further
protects the compressor.
•TIME TEMPERATURE DEFROST CONTROL - Includes a
five-minute anti-short cycle timer to protect the compressor
from short cycling. Field selectable 30, 60, 90 minutes
defrost intervals.
•LOW OPERATING SOUND LEVEL - The compressor is
mounted on rubber isolators to reduce operating sounds.
The slow moving condenser fan keeps air turbulence and
sound to a low level.
•EASY ACCESS - Removable panel affords accessibility to
the electrical box.
•FULLY CHARGED AND FACTORY WIRED - to simplify
installation and reduce labor costs. Only power supply and
control wiring and refrigerant lines must be connected. All
models are sweat connect with reusable service valves.
•Factory tested - to verify system operation and control
functioning before shipment.
•U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment certi-
fication program, which is based on ARI Standard 210/240.

036-21320-002 Rev. A (1103)
2Unitary Products Group
Physical and Electrical Data - 1 Phase
MODEL EABC-F018S EABC-F024S EABC-F030S EABC-F036S EABC-F042S EBBC-F048S EBBC-F060S
Unit Supply Voltage 208/230 – 1 – 60
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 11.7 14.9 18.4 21.3 30.6 31.1 42.6
Max. Overcurrent Device Amps 220 25 30 30 45 50 70
Compressor Type 3Inertia Inertia Inertia Inertia Scroll Scroll Scroll
Compressor Amps Rated Load 9.0 10.9 13.7 16 23.5 23.8 33.1
Locked Rotor 48 60 75 81 104 124 175
Crankcase Heater Yes Yes Yes Yes No No No
Fan Motor Amps Rated Load 0.5 1.3 1.3 1.3 1.3 1.3 1.3
Fan Diameter Inches 18 22 22 22 22 24 24
Fan Motor Rated HP 1/12 1/4 1/4 1/4 1/4 1/4 1/4 Nominal RPM 1,100 850 850 850 850 850 850
Nominal CFM 1,850 3,150 3,150 3,150 3,150 3,250 3,250
Coil Face Area Sq. Ft. 12.58 15.72 15.72 19.65 19.65 22.50 22.50 RowsDeep 1111122
Fin / Inches 13 13 13 13 13 14 14
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 3/4 3/4 7/8 7/8 7/8 1 1/8
Unit Charge (Lbs. - Oz.) 45 - 13 6 - 7 6 - 9 7 - 4 7 - 1 13 - 9 12 - 11
Charge Per Foot, Oz. 0.68 0.68 0.68 0.70 0.70 0.70 0.76
Operating Weight Lbs. 142 163 167 178 180 254 262
Physical and Electrical Data - 3 Phase
MODEL EABC-T036S EABC-T048S EABC-T060S EABC-W036S EABC-W048S EABC-W060S
Unit Supply Voltage 208/230-3-60 460 - 3 - 60
Normal Voltage Range 1187-252 432-504
Minimum Circuit Ampacity 13.7 20.8 24.2 7.2 10.5 11.7
Max. Qvercurrent Device Amps 220 35 40 15 15 20
Compressor Type3Recip ScrollBScrollCRecip ScrollBScrollC
Compressor Amps Rated
Load 9.9 15.6 18.3 5.1 7.7 8.7
Locked
Rotor 78 93 123 40 47 62
Crankcase Heater Yes No No Yes No No
Fan Motor Amps Rated
Load 1.31.31.30.80.80.8
Fan Diameter Inches 22 24 24 22 24 24
Fan Motor Rated HP 1/4 1/4 1/4 1/4 1/4 1/4
Nominal
RPM 850 850 850 850 850 850
Nominal
CFM 3,300 3,400 3,400 3,300 3,400 3,400
Coil Face Area Sq. Ft. 19.65 27.00 27.00 19.65 27.00 27.00
RowsDeep 122122
Fin / Inches 18 14 14 18 14 14
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 7/8 7/8 3/4 7/8 7/8
Unit Charge (Lbs. - Oz.) 49 - 5 13 - 9 12 - 9 9 - 5 13 - 9 12 - 9
Charge Per Foot, Oz. 0.68 0.70 0.70 0.68 0.70 0.70
Operating Weight Lbs. 185 240 258 185 241 258
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than
15 feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.

036-21320-002 Rev. A (1103)
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit EABC-F018S EABC-F024S EABC-F030S EABC-F036S EABC-F042S EBBC-F048S EBBC-F060S
Unit Orifice (s) 153,55 59,61 67,69,71 71,75 81 87 96
Factory R-22 Charge, lbs-oz 5 - 13 6 - 7 6 - 9 7 - 4 7 - 1 13 - 9 12 - 11
Indoor Coil Coil Orifice 2System Orifice - Additional Charge, Oz
G2FD024(S,H)14,17(T) 61 53 + 247013,5 + 0
G2FD030(S,H)17(T) 65 61 + 0469 + 3
7013,5 + 0 7013,5 + 3
G2FD035(S,H)14 65 61 + 0469 + 3
G2FD036(S,H)17,21(T) 75
71 + 5475 + 04
7013+ 5 7023,5 + 0
G2FD042(S,H)21(T) 78
75 + 3 78 + 114
7023,5 + 0 7023,5 +11
G2FD046(S,H)17 78 75 + 3
G2FD048(S,H)21,24 84
7023+14 87 + 0
81 + 17
G2FD060(S,H)24 90
81 + 24 87 + 0 96 + 54
7023+24
G2FD061H24 90 87 + 10 96 + 154
G1HA024H14 61 53 + 02
G1HA024H14T TXV 701 +02 +0
G1HA036H14 75
G1HA036H14T TXV 702 +05 +0
G1HA036H17 78 75 + 03 78 + 11
G1HA036H17T TXV 702 +0 +11
G1HA048H21 84 75 + 08 87 + 00
G1HA048H21T TXV 703
G1HA060H24 90 87 + 05 96 + 05
G1HA060H24T TXV 703
G1HD024 59 53 + 047013+0
G1HD036 69 61 + 647013+8 7023+2
G1HD048 81
69 + 14475 + 7478 + 74
G1HD060 93 87 + 0 96 + 14
G1FA/G1UA024S14,17 59 53 + 04
G1FA/G1UA030S14 65 53 + 0 7013+0
G1FA/G1UA036S14 73
69 + 54
G1FA/G1UA036S17,21 73 61 + 0469 + 34
G1FA/G1UA048S21 84
75 + 8481 + 11487 + 0
G1FA/G1UA060S21,24 90 87 + 5 96 + 54
G1NA030S17K 63 55 + 4459 + 14
G1NA030S21M 63 59 + 14
G1NA036S17L 71
67 + 0471 + 114
G1NA048S21D 78
67 + 0471 + 11478 + 04
G1NA048S24P 78
78 + 04
G1NA042S24W 84 87 + 20
G1NA060S24T 87
96 + 04
G1NF036SOF 67 59 + 1467 + 1471 + 114
G1NF048SOF 78
78 + 04
G1NF060SOF 87
87 + 20496 + 94
F2RP/F2FP024 61 55 + 0
F2RP/F2FP030 65 61 + 0
F2RP/F2FP036 75 71 + 7 75 + 0

036-21320-002 Rev. A (1103)
4Unitary Products Group
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaportor and for 15 feet of
interconnecting line tubing.
2. Verify the orifice size and additional charge required for specific evaportor coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaportor + adder for line set.
5. If the orifice in the evaportor was changed, verify the evaportor nameplate has been marked with the correct orifice size.
F2RP/F2FP042 (T) 78 75 + 3 7023,5 +11
F2FP045 78 87 + 5
F2FP048 (T) 84 81 + 17 7033,5 + 0
F2FP060 (T) 90
7033,5 + 5
F2FV060 90 87 + 5 96 + 5
FOOTNOTES:
1. These orifices are packed in the customer packet of each outdoor unit.
2. These orifices are factory mounted in the flow control device of each indoor coil. A TXV is factory mounted if model number has (T) suffix.
3. A TXV kit must be used with these coils to obtain system performance. (701,702,703 indicates 1TV07 ...series).
4. Systems matched with furnaces or air handlers not equipped with blower-off delays, may require blower Time Delay Kit #2FD0670224.
5. This TXV is factory installed on Indoor Coil model with (T) suffix.
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaportor and for 15 feet of
interconnecting line tubing.
2. Verify the orifice size and additional charge required for specific evaportor coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in the table above.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for evapor-
tor + adder for line set.
5. If the orifice in the evaportor was changed, verify the evaportor nameplate has been marked with the correct orifice size.
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit EABC-F018S EABC-F024S EABC-F030S EABC-F036S EABC-F042S EBBC-F048S EBBC-F060S
Unit Orifice (s) 153,55 59,61 67,69,71 71,75 81 87 96
Factory R-22 Charge, lbs-oz 5 - 13 6 - 7 6 - 9 7 - 4 7 - 1 13 - 9 12 - 11
Indoor Coil Coil Orifice 2System Orifice - Additional Charge, Oz
Additional R-22 Charge / Orifice Size for Various Matched Systems - 3 Phase
Outdoor Unit EABC-(T,W)036S EABC-(T,W)048S EABC-(T,W)060S
Unit Orifice (s) 173 87 99
Factory R-22 Charge, lbs-oz 9 - 5 13 - 9 12 - 9
Indoor Coil Coil Orifice 2System Orifice = Additional Charge, Oz
G1UA048S(21,24) 84 73 + 0 87 + 0 —
G1UA060S24 90 — 87 + 5 99 + 0
G1FA048S(21,24) 84 73 + 0 87 + 0
G1FA060S24 90 — 87 + 5 99 + 0
G1HA048H21 84 73 + 2 — —
G1HA060H24 90 — 87 + 5 99 + 0
G2FD048S(21,24) 84 73 + 2 87 + 2 —
G2FD060S24 90 — 87 + 5 99 + 0
Footnotes:
1. These orifices are packed in the instruction/warranty packet of each outdoor unit.
2. These orifices are factory mounted in the flow control device of each indoor coil.
3. A TXV is factory mounted in the coil or air handler.

036-21320-002 Rev. A (1103)
Unitary Products Group 5
- = Not applicable
COOLING CAPACITY - With Air Handler Coils
UNIT MODEL
AIR HANDLER COIL1,6
MODEL
COOLING
MODEL6ELECTRIC2
HEAT KW WRATED
CFM NET MBH SEER
W/O TXV SEER
+ TXV3EER
TOTAL SENS.
1 PH 12 SEER HP WITH N-AH / G2FD
EABC-F018S N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 (T) 650 17.8 12.8 - 12.00 10.35
EABC-F024S N1AHB0806 2,5,8,10 17 G2FD024(S,H)17 (T) 840 23.4 17.3 - 12.00 10.25
N1AHB0806 2,5,8,10 17 G2FD030(S,H)17 (T) 840 23.8 17.6 12.0 12.10 10.35
EABC-F030S N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 (T) 1025 28 20.7 11.8 12.00 10.30
EABC-F036S N1AHB1206 5,8,10,15,19 17 G2FD036(S,H)17 (T) 1250 33.4 24.7 12.0 12.10 10.10
EABC-F042S N1AHC1606 5,8,10,15,20 21 G2FD042(S,H)21 (T) 1400 40 30.0 12.0 12.00 10.45
EBBC-F048S N1AHC1606 5,8,10,15,20 21 G2FD048(S,H)21 1600 45.5 33.3 12.0 - 10.70
N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1600 46.5 34.4 12.0 - 10.90
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 1600 47 36.3 12.0 - 11.00
EBBC-F060S N1AHD2006 8,10,15,20,25,30 24 G2FD060(S,H)24 1700 57.5 40.4 12.0 - 10.75
N1AHD2006 8,10,15,20,25,30 24 G2FD061H24 2000 59 44.0 - 12.00 10.80
1 PH 12 SEER HP / N1VS - VARIABLE SPEED
EABC-F018S N1VSB12 5,8,10,15,19 17 G2FD024(S,H)17 645 18.4 12.8 13.00 - 11.80
EABC-F024S N1VSB12 5,8,10,15,19 17 G2FD030(S,H)17 785 24.4 17.6 13.00 - 11.50
EABC-F030S N1VSB12 5,8,10,15,19 17 G2FD036(S,H)17 1000 28.6 20.7 13.00 - 11.20
EABC-F036S N1VSB12 5,8,10,15,19 17 G2FD036(S,H)17 1150 34.0 24.7 13.00 - 11.00
N1VSB12 5,8,10,15,19 17 G2FD046(S,H)17 1150 34.6 25.1 13.00 - 11.00
EABC-F042S N1VSC16 5,8,10,15,20 21 G2FD048(S,H)21 1425 41.5 30.4 13.00 - 11.00
EBBC-F048S N1VSD20 8,10,15,20,25,30 24 G2FD060(S,H)24 (T) 1600 47.0 34.4 - 12.60 11.40
N1VSD20 8,10,15,20,25,30 24 G2FD061H24 1600 47.5 36.3 - 12.65 11.55
EBBC-F060S N1VSD20 8,10,15,20,25,30 24 G2FD060(S,H)24 (T) 1860 59.0 40.4 - 13.50 11.90
N1VSD20 8,10,15,20,25,30 24 G2FD061H24 1900 59.5 44.0 - 12.35 11.05
1 PH 12 SEER HP / F2RP / FP / FV 4,5
EABC-F018S F2RP/F2FP024 5,8,10 18 - 650 18.0 13.3 12.00 - 10.50
EABC-F024S F2RP/F2FP030 5,8,10,15 18 - 800 23.6 17.5 12.00 - 10.50
EABC-F030S F2RP/F2FP030 5,8,10,15 18 - 1025 27.8 20.6 11.30 - 10.25
F2RP/F2FP036 5,8,10,15,19 21 - 1000 28.6 21.2 12.00 - 10.60
EABC-F036S F2RP/F2FP036 5,8,10,15,19 21 - 1200 34.0 25.2 12.00 - 10.40
F2RP/F2FP042 5,8,10,15 21 - 1200 34.0 25.2 12.00 - 10.40
EABC-F042S F2RP/F2FP042 (T) 5,8,10,15 21 - 1400 39.5 29.2 - 11.70 10.25
F2FP048 5,8,10,15,20,25 24 - 1400 41.0 30.3 12.00 - 10.60
EBBC-F048S F2FP045 5,8,10,15 24 - 1500 46.0 33.5 12.00 - 11.00 F2FP048 (T) 5,8,10,15,20,25 24 - 1600 45.5 33.7 - 12.00 10.55
F2FV060 8,10,15,20,25 24 - 1600 47.0 35.9 12.60 - 11.40
EBBC-F060S F2FP060 (T) 5,8,10,15,20,25 24 - 1700 57.0 39.9 - 12.00 10.40
F2FV060 8,10,15,20,25 24 - 1900 57.5 43.4 12.30 - 10.65
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at a 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Single phase units require single phase 2HK heaters. Three phase units require three phase 2HK heaters.
3. TXV = Thermal Expansion Valve kit required. Use 1TV700 series kit.
4. To meet R=4.2 insulation requirements, substitute F2FP for F2RP, and F2FC for F2RC. models. All ratings remain the same.
5. FG8, FG9, and FL8 furnaces and F2RP / F2RC air handlers have B.O.D (Blower on Delay) standard.
6. A TXV is factory mounted in the Indoor Coil or Air Handler with model numbers containing a (T) suffix.

036-21320-002 Rev. A (1103)
6Unitary Products Group
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils
UNIT MODEL FURNACE** COIL1
MODEL
COOLING
CFM RANGE
(MIN.-MAX.) WRATED
CFM NET MBH SEER W/0 TXV SEER + TXV2EER
TOTAL SENS.
EABC-F018S 575
725
14,17 G1FA024S14,17 650 17.6 13.0 11.70* - 10.30
14 G1FA030S14 650 17.8 13.2 11.85* - 10.40
14 G1HA024H14 (T) 650 17.4 12.8 12.00 12.00 10.25
- G1HD024 650 18.0 12.2 12.00* - 10.55
17 G1NA030S17K 650 18.0 12.2 12.00* - 10.50
14,17 G1UA024S14,17 650 17.6 13.0 11.70* - 10.30
14 G1UA030S14 650 17.8 13.2 11.85* - 10.40
14,17 G2FD024(S,H)14,17(T) 650 17.8 12.8 - 12.00 10.35
EABC-F024S 750
950
14 G1FA030S14(T) 840 23.4 17.3 - 12.00 10.25
17,21 G1FA036S17,21 840 23.8 17.6 12.00* - 10.35
14 G1HA024H14T 840 23.0 17.3 12.00 12.00 10.25
- G1HD024 840 23.8 18.7 - 12.20 10.35
- G1HD036 840 24.2 19.0 12.00* - 10.50
17 G1NA030S17K 850 23.6 16.9 12.00 - 10.50
21 G1NA030S21M 850 23.6 16.9 12.00 - 10.50
14 G1UA030S14 840 23.4 17.3 - 12.00 10.25
17,21 G1UA036S17,21 840 23.8 17.6 12.00* - 10.35
14,17 G2FD024(S,H)14,17(T) 840 23.4 17.3 - 12.00 10.25
17 G2FD030(S,H)17(T) 840 23.8 17.6 12.00* 12.10 10.35
14 G2FD035(S,H)14 840 23.8 17.6 12.00* - 10.35
EABC-F030S 900
1150
14 G1FA036S14 1025 28.2 20.4 11.50* - 10.35
17,21 G1FA036S17,21 1025 27.8 20.6 11.50* - 10.25
14 G1HA036H14T 1025 27.4 20.7 12.00 12.00 10.45
- G1HD036 1025 28.2 22.4 - 12.00 10.35
- G1HD048 1025 29.4 23.3 12.15* - 10.70
17 G1NA036S17L 1000 30.0 20.7 12.00* - 10.90
21 G1NA048S21D 1000 30.0 20.7 12.00* - 10.85
14 G1UA036S14 1025 28.2 20.4 11.50* - 10.35
17,21 G1UA036S17,21 1025 27.8 20.5 11.50* - 10.25
17 G2FD030(S,H)17(T) 1025 27.8 20.5 11.50* 11.65 10.25
14 G2FD035(S,H)14 1025 27.8 20.5 11.65 - 10.25
17 G2FD036(S,H)17 1025 28.0 20.7 11.80* 12.00 10.30
21 G2FD036(S,H)21 1025 28.0 20.7 - 12.00 10.55
EABC-F036S 1050
1350
21 G1FA048S21 1250 34.8 25.8 12.20* - 10.50
14 G1HA036H14T 1150 33.6 25.2 - 12.00 10.35
17 G1HA036H17(T) 1200 33.4 25.4 12.00 12.00 10.30
21 G1HA048H21 1200 34.0 25.8 12.00 12.00 10.50
- G1HD036 1250 33.4 26.4 - 12.00 10.10
- G1HD048 1250 36.0 27.9 12.00* - 10.50
17 G1NA036S17L 1200 34.0 24.1 12.00* - 10.70
21 G1NA048S21D 1200 34.0 24.1 12.00* - 10.60
21,24 G1UA048S21 1250 34.8 25.8 12.20* - 10.50
17 G2FD036(S,H)17(T) 1250 33.4 24.7 12.00* 12.10 10.10
21 G2FD036(S,H)21(T) 1200 34.0 25.2 - 12.15 10.35
21 G2FD042(S,H)21(T) 1250 34.2 25.4 12.10* 12.20 10.30
EABC-(T,W)036S 1050
1450
21 G1FA048(S,H)21 1250 34.6 25.8 12.00 - 10.55
21 G1HA048H21 1250 34.4 25.1 12.00 - 10.50
21 G1UA048(S,H)21 1250 34.6 25.8 12.00 - 10.55
21,24 G2FD048(S,H)21,24 1250 35.0 25.1 12.00 - 10.70
For Notes see Page 7.

036-21320-002 Rev. A (1103)
Unitary Products Group 7
* Requires a 2FD Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.
EABC-F042S 1225
1575
21 G1FA048S21 1400 40.5 30.0 12.00* - 10.65
17 G1HA036H17(T) 1300 39.5 30.0 12.00 12.00 10.35
- G1HD048 1400 40.5 31.5 12.00* - 10.60
21 G1NA048S21D 1400 40.5 29.7 12.00* - 10.50
21,24 G1UA048S21 1400 40.5 30.0 12.00* - 10.65
21 G2FD042(S,H)21(T) 1400 40.0 30.0 12.00* 12.00 10.45
21,24 G2FD048(S,H)21,24(T) 1450 40.5 30.4 - 12.00 10.65
24 G2FD060(S,H)24(T) 1400 41.0 30.8 12.10* 12.30 10.90
EBBC-F048S 1400
1800
21 G1FA048S21 1500 45.5 33.0 12.00 - 10.80
21,24 G1FA060S21,24 1600 46.5 34.4 12.00 - 10.90
21 G1HA048H21 1500 44.5 33.0 12.00 - 10.80
24 G1HA060H24 1600 46.0 34.4 12.00 - 10.90
- G1HD060 1600 46.0 34.1 12.00 - 10.80
24 G1NA042S24W 1500 46.0 32.8 12.00 - 10.75
21,24 G1UA048S21 1500 45.5 33.0 12.00 - 10.80
21,24 G1UA060S21,24 1600 46.5 34.4 12.00 - 10.90
21,24 G2FD048(S,H)21,24 1600 45.5 33.3 12.00 - 10.70
24 G2FD060(S,H)24 1600 46.5 34.4 12.00 - 10.90
24 G2FD061H24 1600 47.0 36.3 12.00 - 11.00
EABC-(T,W)048S 1400
1800
21 G1FA048(S,H)21 1600 45.0 32.5 12.00 - 10.25
21,24 G1FA060(S,H)21,24 1600 45.5 33.0 12.00 - 10.35
24 G1HA060H24 1600 45.0 32.5 12.00 - 10.30
21 G1UA048(S,H)21 1600 45.0 32.6 12.00 - 10.25
21,24 G1UA060(S,H)21,24 1600 45.5 33.0 12.00 - 10.35
21,24 G2FD048(S,H)21,24 1600 45.0 32.5 12.00 - 10.25
24 G2FD060(S,H)24 1600 45.5 33.0 12.00 - 10.35
EBBC-F060S 1600
2100
21,24 G1FA060S21,24 1700 57.5 40.4 12.00* - 10.75
24 G1HA060H24 1700 57.5 40.0 12.00 - 10.75
- G1HD060 1800 58.0 40.7 12.00* - 10.80
24 G1NA060S24T 1800 56.5 39.6 12.00* - 10.55
21,24 G1UA060S21,24 1700 57.5 40.4 12.00* - 10.75
24 G2FD060(S,H)24 1700 57.5 40.4 12.00* - 10.75
24 G2FD061H24 2000 59.0 44.0 - 12.00* 10.80
EABC-(T,W)060S 1500
1900
21,24 G1FA060(S,H)21,24 1700 55.5 38.4 12.00 - 10.70
24 G1HA060H24 1700 55.0 37.5 12.00 - 10.70
21,24 G1UA060(S,H)21,24 1700 55.5 38.4 12.00 - 10.70
24 G2FD060(S,H)24 1700 55.5 38.4 12.00 - 10.70
1. A TXV is factory mounted in the Indoor Coil or Air Handler with model numbers containing a (T) suffix.
2. TXV = Use 1TV700 Series Kit.
COOLING CAPACITY - Upflow, Downflow, & Horizontal Furnaces and Coils (Continued)
UNIT MODEL FURNACE** COIL1
MODEL
COOLING
CFM RANGE
(MIN.-MAX.) WRATED
CFM NET MBH SEER W/0 TXV SEER + TXV2EER
TOTAL SENS.

036-21320-002 Rev. A (1103)
8Unitary Products Group
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL VARIABLE SPEED
FURNACE MODEL COIL MODEL1,4 WCOOLING
RATED
CFM NET MBH SEER W/O TXV SEER + TXV2EER
TOTAL SENS.
1 PH 12 SEER HP - VARIABLE SPEED3
EABC-F018S
G8V***12UHA G1FA024S14(T) 14 685 18.0 13.4 - 12.75 11.40
G8V***12UHA G1FA030S14(T) 14 685 18.2 13.6 - 13.00 11.55
G8V***12UHA G2FD024(S,H)14(T) 14 685 18.2 13.2 - 13.00 11.50
G9V***12DHB G2FD024(S,H)17(T) 17 620 18.2 13.2 - 13.00 11.75
G9V***12UPB G1FA024S17(T) 17 660 18.0 13.4 - 12.75 11.40
G9V***12UPB G2FD024(S,H)17(T) 17 660 18.2 13.2 - 13.00 11.50
EABC-F024S
G8V***12UHA G1FA030S14(T) 14 875 23.8 17.7 - 12.75 11.05
G8V***12UHA G2FD024(S,H)14(T) 14 875 23.8 17.7 - 12.75 11.05
G8V***16UHB G1FA036S17 17 840 24.2 18.0 - 12.75 11.20
G8V***16UHB G2FD024(S,H)17(T) 17 840 23.8 17.7 - 12.75 11.05
G8V***16UHB G2FD030(S,H)17(T) 17 840 24.2 18.0 - 13.00 11.15
G9V***12DHB G2FD024(S,H)17(T) 17 815 23.6 17.5 - 13.00 11.30
G9V***12DHB G2FD030(S,H)17(T) 17 830 24.2 18.0 - 13.20 11.60
G9V***12UPB G1FA036S17 17 820 24.4 18.2 - 13.00 11.35
G9V***12UPB G2FD024S17(T) 17 820 24.0 17.9 - 13.00 11.20
G9V***12UPB G2FD030S17(T) 17 820 24.4 18.2 - 13.00 11.35
EABC-F030S
G8V***12UHA G1FA036S14 14 1080 28.6 20.8 - 12.00 10.80
G8V***12UHA G2FD035(S,H)14(T) 14 975 28.2 20.9 - 12.50 11.05
G8V***16UHB G1FA036S17 17 1050 28.4 21.2 - 12.25 11.20
G8V***16UHB G2FD036(S,H)17 17 1050 28.6 21.3 - 12.75 11.25
G9V***12UHB G1FA036S17 17 1050 28.2 21.0 - 12.25 10.95
G9V***12UHB G2FD030(S,H)17(T) 17 1050 28.2 20.9 - 12.50 10.95
G9V***12UHB G2FD036(S,H)17 17 1050 28.4 21.1 - 12.75 11.05
G9V***12DHB G2FD036(S,H)17 17 1040 28.2 20.9 - 12.40 10.85
EABC-F036S
G8V***16UHB G2FD036(S,H)17(T) 17 1250 33.8 25.1 - 12.50 10.70
G8V***20UHC G1FA048S21 21 1250 35.4 26.4 - 12.75 11.40
G8V***20UHC G2FD036(S,H)21(T) 21 1200 34.6 25.8 - 12.75 11.15
G8V***20UHC G2FD042(S,H)21(T) 21 1200 34.8 26.2 - 12.75 11.10
G9V***12DHB G2FD036(S,H)17(T) 17 1130 33.4 24.7 - 12.00 10.85
G9V***12UPB G2FD036(S,H)17(T) 17 1200 33.8 25.1 - 12.25 10.50
G9V***16UPC G1FA048S21 21 1260 35.4 26.4 - 12.75 11.20
G9V***16UPC G2FD036(S,H)21(T) 21 1200 34.4 25.6 - 12.75 11.00
G9V***16UPC G2FD042(S,H)21(T) 21 1200 34.8 26.2 - 12.75 11.00
EABC-F042S
G8V***20UHC G1FA048S21 21 1400 41.0 30.5 - 12.50 11.15
G8V***20UHC G2FD042(S,H)21(T) 21 1400 40.5 30.5 - 12.50 10.95
G8V***20UHC G2FD048(S,H)21 21 1460 41.0 30.9 - 12.25 11.05
G9V***20DHD G2FD048(S,H)24 24 1365 41.5 71.9 - 12.80 11.35
G9V***16UPC G1FA048S21 21 1400 41.0 30.5 - 12.50 11.15
G9V***16UPC G2FD042(S,H)21(T) 21 1400 40.5 30.5 - 12.25 10.85
G9V***16UPC G2FD048(S,H)21 21 1480 40.5 30.4 - 12.10 10.70
EBBC-F048S
G8V***20UHC G1FA048S21(T) 21 1500 46.0 33.5 - 12.25 11.15
G8V***20UHC G1FA060S21(T)(T) 21 1610 46.5 34.4 - 12.10 11.15
G8V***20UHC G2FD048(S,H)21(T) 21 1610 45.5 33.3 - 12.10 10.90
G9V***20DHD G2FD048(S,H)24(T) 24 1610 47.0 34.8 - 12.40 11.00
G9V***16UPC G1FA048S21(T) 21 1480 45.5 33.0 - 12.10 10.90
G9V***16UPC G1FA060S21(T) 21 1480 46.0 33.9 - 12.10 10.95
G9V***16UPC G2FD048(S,H)21(T) 21 1480 45.0 32.8 - 12.10 10.65
G9V***20UPD G1FA060S24(T) 24 1620 46.5 34.4 - 12.10 11.10
G9V***20UPD G2FD060(S,H)24(T) 24 1620 46.5 34.4 - 12.20 11.10
EBBC-F060S
G8V***20UHC G1FA060S21(T) 21 1730 57.5 40.4 - 12.10 10.80
G9V***20DHD G2FD060(S,H)24(T) 24 1805 57.5 40.4 - 11.80 10.40
G9V***20UPC G1FA060S21(T) 21 1620 57.0 39.9 - 12.10 10.70
G9V***20UPD G1FA060S24(T) 24 1620 57.0 39.9 - 12.10 10.70
G9V***20UPD G2FD060(S,H)24(T) 24 1620 57.0 39.9 - 12.10 10.70
G9V***20UPD G2FD061H24 24 1620 58.5 43.5 - 12.10 10.55
1. G2FD coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. TXV = Use 1TV700 Series Kit.
3. Variable speed furnaces have B.O.D (Blower on Delay) standard.
4. A TXV is factory mounted in the Indoor Coil or Air Handler with model numbers containing a (T) suffix.

036-21320-002 Rev. A (1103)
Unitary Products Group 9
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
HEATING PERFORMANCE - With Air Handler
UNIT
MODEL* COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F17°FHSPF-3°F7°F27°F37°F57°F
MBH COP KW MBH COP KW STD MBH KW MBH KW MBH KW MBH KW MBH KW
EABC-F018S F2RP/F2FP024 19.0 3.20 1.74 10.6 2.06 1.52 7.20 7.2 1.44 8.9 1.47 13.0 1.63 14.8 1.58 19.3 1.75
EABC-F024S F2RP/F2FP030 24.0 3.16 2.23 14.0 2.06 2.00 7.30 9.1 1.75 1.3 1.86 15.8 2.08 21.1 2.13 27.1 2.32
EABC-F030S F2RP/F2FP030 29.0 3.30 2.58 18.0 2.20 2.40 7.60 10.7 2.28 14.3 2.34 22.2 2.59 26.4 2.78 32.7 2.63
F2RP/F2FP036 29.6 3.40 2.55 18.0 2.30 2.29 8.00 11.6 2.02 15.0 2.22 20.2 2.34 26.0 2.43 33.9 2.68
EABC-F036S F2RP/F2FP036 35.0 3.50 2.93 20.6 2.30 2.62 8.00 12.1 2.26 15.9 2.40 25.0 2.86 30.8 2.79 39.6 3.12
F2RP/F2FP042 35.0 3.50 2.93 20.6 2.30 2.62 8.00 12.1 2.26 15.9 2.40 25.0 2.86 30.8 2.79 39.6 3.12
EABC-F042S F2RP/F2FP042 41.5 3.38 3.60 25.2 2.30 3.21 8.00 14.3 2.95 19.8 3.08 31.4 3.43 37.6 3.65 46.9 3.73
F2FP048 42.0 3.60 3.42 25.4 2.38 3.14 8.00 14.8 2.93 20.1 3.04 30.9 3.24 36.7 3.33 48.8 3.54
EBBC-F048S F2FP045 47.0 3.22 4.28 29.4 2.40 3.59 8.00 17.7 3.13 23.5 3.36 33.7 3.71 37.9 3.78 52.9 4.39 F2FP048 47.5 3.18 4.38 30.0 2.40 3.66 8.00 18.3 3.19 24.2 3.42 34.3 3.76 38.6 3.86 53.3 4.62
F2FV060 46.0 3.34 4.04 28.4 2.54 3.28 8.25 16.7 2.77 22.5 3.02 32.7 3.40 37.0 3.52 51.9 4.29
EBBC-F060S F2FP060 59.0 3.40 5.08 35.2 2.30 4.41 7.75 19.3 3.96 27.3 4.18 38.8 4.45 42.5 4.49 66.9 5.31
F2FV060 57.5 3.80 4.43 33.6 2.50 3.94 8.25 17.7 3.61 25.6 3.77 37.2 3.94 40.9 3.95 65.5 4.60
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental
electric heat operation.
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.
HEATING PERFORMANCE - Furnace Coils
UNIT
MODEL* COIL1
MODEL
ARI HEATING2Variable
Speed OUTDOOR TEMP3
47°F17°FHSPF -3°F7°F27°F37°F57°F
MBH COP KW MBH COP KW STD N1VS MBH KW MBH KW MBH KW MBH KW MBH KW
EABC-F018S
G2FD024(S,H)14,17 18.8 3.40 1.65 10.6 2.04 1.52 7.0 7.1 7.2 1.44 8.9 1.47 13.0 1.63 14.8 1.58 19.3 1.71
G1HA024H14(T) 18.4 3.40 1.65 10.2 2.04 1.52 7.0 -- 7.2 1.44 8.9 1.47 13.0 1.63 14.8 1.58 19.3 1.71
G1HD024 19.0 3.24 1.72 10.4 2.04 1.49 7.0 -- 4.7 1.34 7.5 1.42 12.8 1.62 15.2 1.74 21.9 1.79
G1NA030S17K 18.0 3.26 1.62 10.8 2.06 1.54 7.2 -- 6.0 1.48 8.4 1.51 13.0 1.58 15.2 1.63 20.4 1.65
G1UA024S14,17 18.8 3.14 1.75 10.4 2.02 1.50 7.0 -- 5.0 1.33 7.7 1.42 13.1 1.59 15.8 1.67 21.8 1.84
G1UA030S14 19.0 3.22 1.73 10.4 2.04 1.49 7.1 -- 4.7 1.33 7.5 1.42 12.8 1.59 15.2 1.69 21.9 1.81
G1FA024S14,17 18.8 3.14 1.75 10.4 2.02 1.50 7.0 -- 5.0 1.33 7.7 1.42 13.1 1.59 15.8 1.67 21.8 1.84
G1FA030S14 19.0 3.22 1.73 10.4 2.04 1.49 7.1 -- 4.7 1.33 7.5 1.42 12.8 1.59 15.2 1.69 21.9 1.81
EABC-F024S
G2FD024(S,H)14,17 23.4 3.04 2.26 13.8 2.02 2.00 7.2 -- 7.4 1.83 10.6 1.92 16.5 2.03 19.1 2.06 26.6 2.34
G1HA024H14(T) 23.0 3.04 2.26 13.6 2.02 2.00 7.2 -- 7.4 1.83 10.6 1.92 16.5 2.03 19.1 2.06 26.6 2.34
G2FD030(S,H)14,17 23.6 3.12 2.22 14.0 2.06 1.99 7.3 7.3 7.9 1.81 11.0 1.90 17.8 2.08 20.3 2.60 27.7 2.31
G2FD035(S,H)14 23.6 3.12 2.22 14.0 2.06 1.99 7.3 -- 8.0 1.82 11.0 1.90 17.0 2.08 20.3 2.16 27.6 2.31
G1HD024S 23.4 3.08 2.22 13.8 2.05 1.97 7.2 -- 7.7 1.78 10.7 1.88 16.9 2.07 20.1 2.15 27.5 2.32
G1HD036S 23.6 3.24 2.22 14.0 2.12 1.99 7.3 -- 7.9 1.80 11.0 1.90 17.0 2.09 20.2 2.16 27.9 2.30
G1NA030S17K 24.0 3.16 2.23 14.0 2.06 1.99 7.3 -- 7.3 1.84 10.7 1.91 16.9 2.08 19.7 2.16 27.3 2.30
G1NA030S21M 24.0 3.16 2.23 14.0 2.06 1.99 7.3 -- 7.3 1.84 10.7 1.91 16.9 2.08 19.7 2.16 27.3 2.30
G1UA030S14 23.6 3.12 2.22 14.0 2.06 1.99 7.3 -- 7.9 1.81 11.0 1.90 17.0 2.08 20.3 2.16 27.7 2.34
G1UA036S17,21 23.6 3.12 2.22 14.0 2.06 1.99 7.3 -- 7.9 1.81 11.0 1.90 17.0 2.08 20.3 2.16 27.7 2.34
G1FA030S14 23.6 3.12 2.22 14.0 2.06 1.99 7.3 -- 7.9 1.81 11.0 1.90 17.0 2.08 20.3 2.16 27.7 2.34
G1FA036S17,21 23.6 3.12 2.22 14.0 2.06 1.99 7.3 -- 7.9 1.81 11.0 1.90 17.0 2.08 20.3 2.16 27.7 2.34
EABC-F030S
G2FD030(S,H)17 29.63.362.5818.02.282.31 8.0 -- 10.22.1014.12.2121.92.4226.12.5235.22.78
G2FD035(S,H)14 29.63.362.5818.02.282.31 8.0 -- 10.22.1014.12.2121.92.4226.12.5235.22.78
G2FD036(S,H)17 30.0 3.40 2.59 18.2 2.30 2.32 8.0 8.1 10.3 2.10 14.2 2.21 22.2 2.45 26.4 2.52 35.8 2.77
G2FD036(S,H)21 29.63.382.5518.02.282.32 8.0 -- 10.52.1314.42.2222.02.4126.12.5035.12.74
G1HA036H14(T) 29.0 3.38 2.55 17.6 2.28 2.32 7.9 -- 10.5 2.13 14.4 2.22 22.0 2.41 26.1 2.50 35.1 2.74
G1HD036S 30.0 3.50 2.51 18.2 2.34 2.27 8.0 -- 10.3 2.07 14.2 2.17 22.2 2.37 26.4 2.46 35.7 2.70
G1HD048S 30.4 3.54 2.51 18.4 2.36 2.27 8.0 -- 10.3 2.08 14.3 2.17 22.3 2.37 26.6 2.46 36.1 2.68
G1NA036S17L 29.6 3.40 2.55 18.0 2.30 2.29 8.0 -- 10.3 2.12 14.1 2.21 21.3 2.34 24.6 2.39 33.5 2.64
G1NA048S21D 29.6 3.40 2.55 18.0 2.30 2.29 8.0 -- 10.3 2.12 14.1 2.21 21.3 2.34 24.6 2.39 33.5 2.64
G1UA036S14 29.8 3.42 2.57 18.2 2.28 2.34 8.0 -- 10.5 2.19 14.3 2.26 20.8 2.31 23.3 2.27 33.7 2.64
G1UA036S17,21 29.6 3.36 2.58 18.0 2.28 2.31 8.0 -- 10.2 2.10 14.1 2.21 21.9 2.42 26.1 2.52 35.2 2.78
G1FA036S14 29.8 3.42 2.57 18.2 2.28 2.34 8.0 -- 10.5 2.19 14.3 2.26 20.8 2.31 23.3 2.27 33.7 2.64
G1FA036S17,21 29.6 3.36 2.58 18.0 2.28 2.31 8.0 -- 10.2 2.10 14.1 2.21 21.9 2.42 26.1 2.52 35.2 2.78
For Notes see Page 10.

036-21320-002 Rev. A (1103)
10 Unitary Products Group
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
EABC-F036S
G2FD036(S,H)17 35.4 3.54 2.93 20.8 2.20 2.77 8.0 8.1 10.6 2.61 15.7 2.69 25.9 2.85 31.6 2.93 41.1 3.03
G2FD036(S,H)21 35.0 3.46 2.96 20.4 2.16 2.77 7.8 -- 10.1 2.56 15.2 2.66 25.6 2.87 31.2 2.96 40.7 3.14
G2FD042(S,H)21 35.4 3.52 2.95 20.8 2.30 2.65 8.0 -- 11.1 2.45 15.9 2.55 24.9 2.66 28.9 2.68 40.3 3.05
G1HA036H17 34.6 3.52 2.95 20.4 2.30 2.65 7.9 -- 11.1 2.45 15.9 2.55 24.9 2.66 28.9 2.68 40.3 3.05
G1HD036S 35.4 3.56 2.91 20.8 2.20 2.76 8.0 -- 10.4 2.58 15.6 2.67 26.0 2.85 31.6 2.92 41.2 3.07
G1HD048S 35.4 3.58 2.89 20.8 2.22 2.75 8.0 -- 10.4 2.58 15.6 2.66 26.0 2.83 31.7 2.90 41.2 3.04
G1NA036S17L 36.0 3.50 3.01 20.6 2.30 2.62 8.0 -- 10.3 2.37 15.5 2.49 24.5 2.70 28.4 2.78 41.1 3.14
G1NA048S21D 36.0 3.50 3.01 20.6 2.30 2.62 8.0 -- 10.3 2.37 15.5 2.49 24.5 2.70 28.4 2.78 41.1 3.14
G1UA048S21 35.8 3.58 2.93 20.8 2.32 2.63 8.0 -- 0.4 2.37 15.6 2.50 26.0 2.76 31.9 2.88 41.6 3.07
EABC(T,W)036S
G1FA048(S,H)21 34.0 3.38 2.95 20.2 2.50 2.37 8.00 11.0 2.00 15.6 2.19 24.1 2.50 27.9 2.63 38.6 3.15
G1UA048(S,H)21 34.0 3.38 2.95 20.2 2.50 2.37 8.00 11.0 2.00 15.6 2.19 24.1 2.50 27.9 2.63 38.6 3.15
G1HA048H21 33.6 3.36 2.93 19.8 2.48 2.34 8.00 10.6 1.95 15.2 2.14 23.6 2.46 27.4 2.58 38.2 3.13
G2FD048(S,H)21,24 34.4 3.38 2.98 20.4 2.50 2.39 8.00 11.1 2.01 15.7 2.21 24.3 2.53 28.3 2.66 39.1 3.18
EABC-F042S
G2FD042(S,H)21 41.5 3.42 3.56 25.2 2.32 3.18 8.0 -- 14.5 2.90 19.9 3.04 30.5 3.32 36.3 3.45 48.1 3.71
G2FD048(S,H)21,24 41.5 3.42 3.56 25.2 2.32 3.18 8.0 8.1 14.3 2.93 19.8 3.06 28.1 3.15 31.1 3.12 46.9 3.68
G2FD060(S,H)24 42.0 3.58 3.44 25.4 2.36 3.15 8.0 -- 14.3 2.96 19.9 3.06 29.7 3.31 34.1 3.47 47.5 3.53
G1HA048H21 41.5 3.50 3.52 25.0 2.36 3.15 7.9 -- 14.6 2.94 20.0 3.05 30.8 3.26 36.7 3.38 48.9 3.59
G1HD048S 42.0 3.54 3.47 25.4 2.38 3.13 8.0 -- 14.7 2.89 20.0 3.01 30.8 3.24 36.6 3.35 48.8 3.64
G1NA048S21D 41.0 3.30 3.64 27.4 2.50 3.21 8.0 -- 18.3 2.93 22.9 3.07 30.3 3.33 33.2 3.45 45.5 3.78
G1UA048S21 42.0 3.50 3.52 25.4 2.36 3.15 8.0 -- 14.6 2.94 20.0 3.05 30.8 3.26 36.7 3.38 48.9 3.59
G1FA048S21 42.0 3.50 3.52 25.4 2.36 3.15 8.0 -- 14.6 2.94 20.0 3.05 30.8 3.26 36.7 3.38 48.9 3.59
EBBC-F048S
G2FD048(S,H)21,24 47.5 3.22 4.35 29.8 2.42 3.61 8.0 -- 18.0 3.11 23.9 3.36 34.1 3.71 38.4 3.81 53.4 4.60
G2FD060(S,H)24 47.5 3.16 4.04 29.6 2.38 3.28 8.0 8.2 16.7 2.77 22.5 3.02 32.7 3.40 37.0 3.52 51.9 4.29
G2FD061H24 45.0 3.30 4.00 28.6 2.56 3.27 -- 8.2 17.7 2.79 23.1 3.03 32.6 3.39 36.6 3.51 50.5 4.24
G1HA048H21(T) 46.5 3.24 4.30 29.0 2.40 3.61 7.9 -- 17.7 3.16 23.6 3.39 34.0 3.70 38.4 3.79 53.5 4.52
G1HD060S 46.5 3.24 4.21 29.6 2.38 3.64 8.0 -- 18.3 3.27 24.0 3.46 33.7 3.71 37.9 3.78 52.1 4.39
G1NA042S24W 48.5 3.36 4.22 30.4 2.50 3.56 8.0 -- 18.3 3.13 24.4 3.35 34.3 3.65 37.2 3.73 54.5 4.44
G1UA048S21 47.5 3.24 4.30 29.6 2.40 3.61 8.0 -- 17.7 3.16 23.6 3.39 34.0 3.70 38.4 3.79 53.5 4.52
G1UA060S21,24 47.5 3.16 4.17 29.6 2.38 3.60 8.0 -- 17.6 3.21 23.3 3.40 34.7 3.80 40.8 4.00 55.6 4.46
G1FA048S21 47.5 3.24 4.30 29.6 2.40 3.61 8.0 -- 17.7 3.16 23.6 3.39 34.0 3.70 38.4 3.79 53.5 4.52
G1FA060S21,24 47.5 3.16 4.17 29.6 2.38 3.60 8.0 -- 17.6 3.21 23.3 3.40 34.7 3.80 40.8 4.00 55.6 4.46
EABC(T,W)048S
G1UA048(S,H)21 46.5 3.36 4.06 29.0 2.38 3.57 8.00 17.3 3.25 23.2 3.41 36.5 3.97 44.0 4.37 52.3 4.22
G1UA060(S,H)21,24 47.0 3.40 4.05 29.4 2.40 3.59 8.00 17.5 3.34 23.4 3.46 36.7 3.97 44.2 4.36 52.9 4.05
G1FA048(S,H)21 46.5 3.36 4.06 29.0 2.38 3.57 8.00 17.3 3.25 23.2 3.41 36.5 3.97 44.0 4.37 52.3 4.22
G1FA060(S,H)21,24 47.0 3.40 4.05 29.4 2.40 3.59 8.00 17.5 3.34 23.4 3.46 36.7 3.97 44.2 4.36 52.9 4.05
G1HA060H24 47.0 3.40 4.05 29.4 2.38 3.62 8.00 17.5 3.34 23.4 3.46 36.7 3.97 44.2 4.36 52.9 4.05
G2FD048(S,H)21,24 47.0 3.38 4.08 29.2 2.40 3.57 8.00 17.3 3.23 23.3 3.40 36.6 3.97 44.1 4.37 52.9 4.24
G2FD060(S,H)24 47.0 3.40 4.05 29.4 2.40 3.59 8.00 17.5 3.34 23.4 3.46 36.7 3.97 44.2 4.36 52.9 4.05
EBBC-F060S
G2FD060(S,H)24 58.5 3.50 4.90 34.8 2.40 4.25 8.0 8.3 19.0 3.82 26.9 4.03 38.6 4.31 42.3 4.36 66.4 5.11
G2FD061H24 59.5 3.50 4.98 35.6 2.40 4.31 8.0 8.1 19.7 3.86 27.6 4.09 39.2 4.35 42.9 4.39 67.5 5.21
G1HA060H24(T) 57.5 3.50 4.90 34.8 2.40 4.25 8.0 -- 19.0 3.82 26.9 4.03 38.6 4.31 42.3 4.36 66.4 5.11
G1HD060S 59.0 3.50 4.90 35.0 2.40 4.28 8.0 -- 19.0 3.88 29.9 4.08 38.4 4.33 42.1 4.37 66.4 5.10
G1NA060S24T 58.5 3.38 5.07 35.0 2.40 4.27 7.8 -- 19.3 3.74 27.2 4.01 38.6 4.35 42.2 4.43 66.3 5.34
G1UA060S21,24 58.5 3.50 4.90 34.8 2.40 4.25 8.0 -- 19.0 3.82 26.9 4.03 38.6 4.31 42.3 4.36 66.4 5.11
G1FA060S21,24 58.5 3.50 4.90 34.8 2.40 4.25 8.0 -- 19.0 3.82 26.9 4.03 38.6 4.31 42.3 4.36 66.4 5.11
EABC(T,W)060S
G1UA060(S,H)21,24 59.0 3.48 4.97 37.0 2.92 3.72 8.00 22.3 3.86 30.0 4.08 40.4 4.32 43.8 4.33 66.3 5.19
G1FA060(S,H)21,24 59.0 3.48 4.97 37.0 2.92 3.72 8.00 22.3 3.86 30.0 4.08 40.4 4.32 43.8 4.33 66.3 5.19
G1HA060H24 58.5 3.48 4.93 36.6 2.92 3.68 8.00 22.0 3.81 29.3 4.03 40.0 4.27 43.4 4.29 65.8 5.15
G2FD060(S,H)24 59.0 3.48 4.97 37.0 2.92 3.72 8.00 22.3 3.86 30.0 4.08 40.4 4.32 43.8 4.33 66.3 5.19
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental
electric heat operation.
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.
HEATING PERFORMANCE - Furnace Coils (Continued)
UNIT
MODEL* COIL1
MODEL
ARI HEATING2Variable
Speed OUTDOOR TEMP3
47°F17°FHSPF -3°F7°F27°F37°F57°F
MBH COP KW MBH COP KW STD N1VS MBH KW MBH KW MBH KW MBH KW MBH KW

036-21320-002 Rev. A (1103)
Unitary Products Group 11
HEATING PERFORMANCE - With Variable Speed Furnaces
UNIT
MODEL FURNACE COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F 17°F HSP
F-3°F 7°F 27°F 37°F 57°F
MBH COP KW MBH COP KW STD MBH KW MBH KW MBH KW MBH KW MBH KW
EABC-F018S
G8V***12UHA G1FA024S14 18.4 3.32 1.62 10.0 2.12 1.38 7.50 4.6 1.29 7.3 1.37 12.7 1.46 15.4 1.54 21.4 1.62
G8V***12UHA G1FA030S14 18.5 3.40 1.60 9.8 2.16 1.33 7.45 4.2 1.29 7.1 1.36 12.3 1.46 14.7 1.56 21.4 1.60
G8V***12UHA G2FD024(S,H)14 18.3 3.62 1.49 10.0 2.16 1.36 7.50 6.7 1.34 8.4 1.39 12.5 1.50 14.3 1.45 18.8 1.52
G9V***12DHB G2FD024(S,H)17 18.3 3.40 1.58 11.2 2.26 1.45 7.00 6.7 1.32 8.4 1.37 12.5 1.48 14.3 1.43 18.8 1.50
G9V***12UPB G1FA024S17 18.4 3.32 1.62 10.0 2.12 1.38 7.50 4.6 1.29 7.3 1.37 12.7 1.46 15.4 1.54 21.4 1.62
G9V***12UPB G2FD024(S,H)17 18.3 3.62 1.49 10.0 2.14 1.37 7.50 6.7 1.34 8.4 1.39 12.5 1.50 14.3 1.45 18.8 1.52
EABC-F024S
G8V***12UHA G1FA030S14 23.0 3.16 2.13 13.4 2.10 1.87 7.50 7.5 1.77 10.6 1.86 16.6 1.95 19.9 2.03 27.3 2.09
G8V***12UHA G2FD024(S,H)14 23.0 3.16 2.13 13.4 2.10 1.87 7.50 7.0 1.79 10.2 1.87 16.1 1.90 18.7 1.93 26.2 2.13
G8V***16UHB G1FA036S17 23.2 3.26 2.08 13.6 2.14 1.86 7.60 7.5 1.77 10.6 1.86 16.6 1.95 19.9 2.03 27.3 2.09
G8V***16UHB G2FD024(S,H)17 23.0 3.16 2.13 13.4 2.10 1.87 7.50 7.0 1.79 10.2 1.87 16.1 1.90 18.7 1.93 26.2 2.13
G8V***16UHB G2FD030(S,H)17 23.2 3.26 2.08 13.6 2.14 1.86 7.60 7.5 1.77 10.6 1.86 17.4 1.95 19.9 2.03 27.3 2.09
G9V***12DHB G2FD024(S,H)17 22.9 3.20 2.10 13.0 2.06 1.85 7.20 6.9 1.77 10.1 1.85 16.0 1.88 18.6 1.91 26.1 2.11
G9V***12DHB G2FD030(S,H)17 23.0 3.28 2.06 13.2 2.10 1.84 7.30 7.3 1.74 10.4 1.83 17.2 1.92 19.7 2.00 27.1 2.06
G9V***12UPB G1FA036S17 23.1 3.28 2.06 13.4 2.16 1.82 7.60 7.4 1.74 10.5 1.83 16.5 1.92 19.8 2.00 27.2 2.06
G9V***12UPB G2FD024(S,H)17 22.9 3.20 2.10 13.2 2.10 1.84 7.50 6.9 1.77 10.1 1.85 16.0 1.88 18.6 1.91 26.1 2.11
G9V***12UPB G2FD030(S,H)17 23.1 3.28 2.06 13.4 2.16 1.82 7.60 7.4 1.74 10.5 1.83 17.3 1.92 19.8 2.00 27.2 2.06
EABC-F030S
G8V***12UHA G1FA036S14 29.5 3.52 2.46 17.8 2.34 2.23 8.30 10.2 2.17 14.0 2.25 20.5 2.22 23.0 2.18 33.4 2.48
G8V***12UHA G2FD035(S,H)14 29.1 3.50 2.44 17.4 2.38 2.14 8.30 9.7 2.06 13.6 2.16 21.4 2.27 25.6 2.37 34.7 2.43
G8V***16UHB G1FA036S17 29.0 3.54 2.40 17.4 2.38 2.14 8.35 9.6 2.04 13.5 2.14 21.3 2.25 25.5 2.35 34.6 2.41
G8V***16UHB G2FD036(S,H)17 29.4 3.58 2.41 17.6 2.42 2.13 8.45 9.7 2.03 13.6 2.14 21.6 2.27 25.8 2.34 35.2 2.41
G9V***12UHB G1FA036S17 29.0 3.54 2.40 17.4 2.38 2.14 8.30 9.6 2.04 13.5 2.14 21.3 2.25 25.5 2.35 34.6 2.41
G9V***12UHB G2FD030(S,H)17 29.0 3.54 2.40 17.4 2.38 2.14 8.30 9.6 2.04 13.5 2.14 21.3 2.25 25.5 2.35 34.6 2.41
G9V***12UHB G2FD036(S,H)17 29.4 3.58 2.41 17.6 2.42 2.13 8.35 9.7 2.03 13.6 2.14 21.6 2.27 25.8 2.34 35.2 2.41
G9V***12DHB G2FD036(S,H)17 29.6 3.50 2.48 17.8 2.34 2.23 8.00 9.8 2.11 13.7 2.21 21.5 2.32 25.7 2.42 34.8 2.48
EABC-F036S
G8V***16UHB G2FD036(S,H)1734.93.682.7820.22.262.628.2010.12.5515.22.6325.42.7131.12.7940.62.79
G8V***20UHC G1FA048S21 35.1 3.78 2.72 20.0 2.44 2.40 8.30 9.7 2.30 14.9 2.43 25.3 2.56 31.2 2.68 40.9 2.73
G8V***20UHC G2FD036(S,H)21 34.4 3.62 2.78 19.8 2.24 2.59 8.10 9.5 2.48 14.6 2.59 25.0 2.69 30.6 2.78 40.1 2.78
G8V***20UHC G2FD042(S,H)21 34.4 3.64 2.77 19.6 2.24 2.56 8.10 9.5 2.47 14.6 2.58 25.0 2.68 30.6 2.77 40.1 2.77
G9V***12DHB G2FD036(S,H)1735.03.502.9319.82.302.528.0010.22.5615.32.6425.52.7231.22.8040.72.80
G9V***12UPB G2FD036(S,H)1735.13.642.8220.42.242.678.2510.32.5915.42.6725.62.7531.32.8340.82.83
G9V***16UPC G1FA048S21 35.3 3.74 2.76 20.2 2.40 2.47 8.30 9.9 2.34 15.1 2.47 25.5 2.60 31.4 2.72 41.1 2.77
G9V***16UPC G2FD036(S,H)21 34.5 3.60 2.81 19.8 2.24 2.59 8.10 9.6 2.51 14.7 2.62 25.1 2.72 30.7 2.81 40.2 2.81
G9V***16UPC G2FD042(S,H)21 34.5 3.60 2.80 19.8 2.24 2.59 8.10 9.6 2.50 14.7 2.61 25.1 2.71 30.7 2.80 40.2 2.80
EABC-F042S
G8V***20UHC G1FA048S21 41.5 3.60 3.38 24.8 2.40 3.03 8.50 14.1 2.91 19.5 3.01 30.3 3.12 36.2 3.24 48.4 3.38
G8V***20UHC G2FD042(S,H)2141.03.523.4224.62.383.038.4014.02.9019.43.0430.03.1835.83.3147.63.42
G8V***20UHC G2FD048(S,H)2141.73.583.4125.02.403.058.2514.02.9619.53.0827.83.0530.83.0246.63.46
G9V***20DHD G2FD048(S,H)24 -0.5 3.48 0.04 27.2 2.70 2.95 8.00 13.8 2.91 19.3 3.03 27.6 3.00 30.6 2.97 46.4 3.41
G9V***16UPC G1FA048S21 41.6 3.60 3.38 25.0 2.42 3.03 8.40 14.2 2.92 19.6 3.02 30.4 3.13 36.3 3.25 48.5 3.39
G9V***16UPC G2FD042(S,H)2141.23.503.4524.82.363.088.2514.22.9419.63.0830.23.2236.03.3547.83.46
G9V***16UPC G2FD048(S,H)21 42.0 3.52 3.49 25.4 2.38 3.13 8.15 14.3 3.05 19.8 3.17 28.1 3.14 31.1 3.11 46.9 3.55
EBBC-F048S
G8V***20UHC G1FA048S21 47.2 3.30 4.19 29.2 2.44 3.51 8.20 17.4 3.29 23.3 3.51 33.7 3.60 38.1 3.69 53.2 4.20
G8V***20UHC G1FA060S21 47.3 3.20 4.33 29.4 2.42 3.56 8.15 17.4 3.33 23.1 3.53 34.5 3.73 40.6 3.93 55.4 4.10
G8V***20UHC G2FD048(S,H)2147.33.264.2529.62.443.558.1517.83.3123.73.5633.93.6638.23.7653.24.30
G9V***20DHD G2FD048(S,H)2447.47.951.7529.42.383.627.9517.93.3323.83.5834.03.6838.33.7853.34.32
G9V***16UPC G1FA048S21 47.4 3.26 4.26 29.4 2.42 3.56 8.15 17.6 3.36 23.5 3.58 33.9 3.67 38.3 3.76 53.4 4.27
G9V***16UPC G1FA060S21 47.3 3.18 4.35 29.0 2.38 3.57 8.05 17.4 3.33 23.1 3.53 34.5 3.73 40.6 3.93 55.4 4.10
G9V***16UPC G2FD048(S,H)2147.33.244.2729.22.423.548.1017.83.2923.73.5433.93.6438.23.7453.24.28
G9V***20UPD G1FA060S24 47.3 3.20 4.33 29.4 2.40 3.59 8.10 17.4 3.35 23.1 3.55 34.5 3.75 40.6 3.95 55.4 4.12
G9V***20UPD G2FD060(S,H)2447.33.204.3329.42.403.598.1017.43.3523.13.5534.53.7540.63.9555.44.12
For Notes see Page 12.

036-21320-002 Rev. A (1103)
12 Unitary Products Group
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by the total electric
power input during the same period.
— = Not Applicable.
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit (2SA067*)
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Hard Start Kits - Provides required starting torque for use
with Thermal Expansion Valve Kit.
Low Temperature Cutout (2LT06700224) - Prevents heat
pump operation below -10°F ambient temperature.
Compressor Blanket - Designed to further reduce the nor-
mal operating sound.
Add-on Fossil Fuel Control - Interface controls for use with
gas, oil furnaces and the heat pump system are available.
Thermal Expansion Valve Kit - 1TV0700 Series TXV kit
used to improve system performance.
Outdoor Thermostat (2TD06700124) - Provides additional
staging of supplemental electric heat.
Room Thermostats - A wide selection of matching thermo-
stats is available to provide features required for any installa-
tion.
2H/1C, manual change-over electronic non-programmable
thermostat.
3H/2C, non-programmable digital thermostat.
3H/2C, auto/manual changeover, electronic programmable,
7-day, hardwire thermostat.
* For the most current accessory information, refer to the
price book or consult factory.
SOUND RATINGS
*Rated in accordance with ARI Standard 270.
All dim ensions are in inches. They are subject to change without
notice. Certified dimensions will be provided upon request.
EBBC-F060S
G8V***20UHC G1FA060S21 58.4 3.52 4.86 34.6 2.42 4.19 8.05 18.9 4.00 26.8 4.22 38.5 4.28 42.2 4.33 66.3 4.87
G9V***20DHD G2FD060(S,H)2459.28.002.1735.42.344.438.0019.74.2527.64.4739.34.5343.04.5867.15.12
G9V***20UPC G1FA060S21 58.1 3.56 4.78 34.4 2.44 4.13 8.10 18.6 3.92 26.5 4.14 38.2 4.20 41.9 4.25 66.0 4.79
G9V***20UPD G1FA060S24 58.1 3.56 4.78 34.4 2.44 4.13 8.10 18.6 3.92 26.5 4.14 38.2 4.20 41.9 4.25 66.0 4.79
G9V***20UPD G2FD060(S,H)2458.13.564.7834.42.444.138.1018.63.9226.54.1438.24.2041.94.2566.04.79
G9V***20UPD G2FD061H24 58.7 3.62 4.76 34.6 2.44 4.15 8.25 18.9 3.87 26.8 4.09 38.4 4.13 42.1 4.17 66.7 4.76
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and no supplemental
electric heat operation.
3. Integrated heating capacities include the effect of defrost cycles in the temperature range where they occur.
HEATING PERFORMANCE - With Variable Speed Furnaces (Continued)
UNIT
MODEL FURNACE COIL1
MODEL
ARI HEATING2OUTDOOR TEMP3
47°F 17°F HSP
F-3°F 7°F 27°F 37°F 57°F
MBH COP KW MBH COP KW STD MBH KW MBH KW MBH KW MBH KW MBH KW
UNIT MODEL SOUND
RATINGS DECIBELS
018 80
024 80
030 80
036 80
042 80
048 80
060 80
UNIT
MODEL DIMENSIONS (INCHES)
REFRIGERANT
CONNECTION
LINE SIZE
A1
1. Including Fan Guard.
B C Liquid Vapor
018 25 35 23
3/8”
3/4”024 27 37 27
030 27 37 27
036 33 37 27 7/8”042 33 37 27
048 32 43 32
060 32 43 32 7/8”2
2. Three-phase uses 7/8”. Single-phase uses 1-1/8”.
1-1/8”2
C
B
A

036-21320-002 Rev. A (1103)
Unitary Products Group 13
TYPICAL INSTALLATION - DRHS018 THRU 060
TYPICAL FIELD WIRING - 1 Phase Application
TYPICAL FIELD WIRING - 3 Phase Application
MINIMUM 18” SERVICE ACCESS
CLEARANCE ON ONE SIDE
60” OVERHEAD
CLEARANCE
10” CLEARANCE
COIL AREA
WEATHERPROOF
DISCONNECT
SWITCH
THERMOSTAT TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 1 WIRING
NEC CLASS 2 WIRING
TO INDOOR COIL
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
CONTROL ACCESS PANEL
NOTE: ALL OUTDOOR WIRING
MUST BE WEATHERPROOF.
THERMOSTAT INDOOR UNIT
OUTDOOR UNIT
LOW VOLTAGE TERMINAL BLOCK
IN AIR HANDLER WITH ELECTRIC HEAT
3,4
DEFROST
CONTROL
1FIELD
INSTALLED
JUMPER
DEHUMIDIFICATION CONTROL CONNECTION
(Humidistat* Jumper must be removed)
GND.
SCREW
CONTACTOR
T2 T1
L2 L1
M
R
LorX
Y
O
W
G
T2
E2
RR
YY
O
O
W2 W
W1
CC
X/L
G
W1
BK
GND.
LUG
CIRCUIT
BREAKER***
POWER WIRING
24V CONTROL WIRING
(NEC CLASS 2)
JUMPER TERMINALS E AND W TOHEAT
ON FIRST STAGE DURING EMERGENCY HEAT.
1
2
TERMINAL NOT USED ON ALL THERMOSTATS. POWER WIRING
208/230-1-60
230-1-50
3CHECK THE LOW VOLTAGE TERMINAL BLOCK ON THE INDOOR UNIT FOR THE ACTUAL ARRANGEMENT OF THE TERMINALS.
4CONNECT POWER WIRING TO TERMINAL BLOCK 3TB ON UNITS WITHOUT ELECTRIC HEAT OR CIRCUIT BREAKER.
BorC
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
RED
BLK
YEL
ORG
BRN
PUR
WHT
CC
GRY
/66
5GRAY FOR USE WITH OPTIONAL OUTDOOR THERMOSTAT KITS.
5
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-3-60
460-3-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

036-21320-002 Rev. A (1103)
14 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-F018S
INDOOR COIL MODEL NO. F2RP/F2FP024
CONDENSER
ENTERING AIR
TEMPERATURE
D CFM 500 650 800
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 21.0 19.0 17.5 21.4 19.8 18.3 21.9 20.6 19.2 S.C. 12.7 12.1 11.3 13.9 13.7 13.1 15.2 15.4 14.8
KW 1.49 1.45 1.44 1.55 1.52 1.50 1.59 1.57 1.55
85 T.C. 20.2 18.0 16.3 20.9 18.9 17.2 21.7 19.8 18.0 S.C. 12.4 11.6 10.8 14.0 13.5 12.5 15.6 15.5 14.2
KW 1.58 1.55 1.52 1.65 1.61 1.59 1.70 1.67 1.64
95 T.C. 19.3 17.0 15.1 20.4 18.0 16.0 21.6 19.0 16.8 S.C. 12.1 11.1 10.3 14.0 13.3 11.9 16.0 15.5 13.5
KW 1.68 1.64 1.61 1.75 1.71 1.67 1.81 1.76 1.73
105 T.C. 17.7 15.5 13.5 18.8 16.4 15.2 19.8 17.3 16.9 S.C. 11.5 10.4 9.6 13.4 12.4 11.0 15.3 14.4 12.4
KW 1.76 1.71 1.69 1.83 1.78 1.75 1.89 1.84 1.81
115 T.C. 16.2 14.1 11.9 17.1 14.8 14.5 18.0 15.6 17.0 S.C. 10.9 9.8 8.9 12.8 11.5 10.2 14.7 13.2 11.4
KW 1.84 1.78 1.77 1.91 1.85 1.83 1.97 1.91 1.89
125 T.C. 14.6 12.6 10.4 15.4 13.3 13.7 16.3 13.9 17.1 S.C. 10.3 9.2 8.2 12.1 10.6 9.3 14.0 12.1 10.4
KW 1.92 1.85 1.85 1.99 1.92 1.91 2.05 1.98 1.97
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB0806 G2FD024(S,H)17 0.99 0.96 1.00
N1VSB12 G2FD024(S,H)17 1.02 0.96 0.91
G1FA024S14,17 0.98 0.98 1.00
G1FA030S14 0.99 0.99 1.00
G1HD024 1.00 0.92 1.00
G1NA030S17K 1.00 0.92 1.00
G1UA024S14,17 0.98 0.98 1.00
G1UA030S14 0.99 0.99 1.00
G2FD024(S,H)14,17 0.99 0.96 1.00
G1HA024H14 0.97 0.94 0.98
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA024S14 1.00 1.01 0.92
G8V***12UHA G1FA030S14 1.01 1.02 0.92
G8V***12UHA G2FD024(S,H)14 1.01 0.99 0.92
G9V***12DHB G2FD024(S,H)17 1.01 0.99 0.90
G9V***12UPB G1FA024S17 1.00 1.01 0.92
G9V***12UPB G2FD024(S,H)17 1.01 0.99 0.92

036-21320-002 Rev. A (1103)
Unitary Products Group 15
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-F024S
INDOOR COIL MODEL NO. F2RP/F2FP030
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 700 850 1000
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 27.7 25.3 23.3 20.9 28.1 25.8 23.8 21.3 28.3 25.9 24.0 21.5 S.C. 16.6 16.5 15.9 16.7 17.4 17.5 16.8 17.7 17.8 17.9 17.2 18.1
KW 1.90 1.89 1.89 1.85 1.95 1.94 1.94 1.91 2.00 2.00 1.99 1.96
85 T.C. 27.1 24.8 22.8 20.4 27.6 25.3 23.3 21.1 27.8 25.4 23.4 21.3 S.C. 16.7 16.7 16.1 16.9 17.7 17.8 17.1 18.2 18.2 18.3 17.6 18.7
KW 2.05 2.03 2.01 1.97 2.11 2.09 2.07 2.03 2.16 2.14 2.12 2.09
95 T.C. 25.5 23.3 21.4 19.2 25.9 23.6 21.7 19.6 26.0 23.7 22.0 19.8 S.C. 16.4 16.4 15.8 16.6 17.6 17.5 16.9 17.7 18.0 18.0 17.5 18.3
KW 2.22 2.19 2.16 2.11 2.28 2.25 2.22 2.17 2.33 2.30 2.28 2.23
105 T.C. 23.4 21.4 19.6 17.6 23.7 21.6 20.0 17.9 23.8 21.8 20.2 18.3 S.C. 15.8 15.8 15.2 15.9 17.0 17.0 16.3 17.0 17.6 17.6 16.9 17.6
KW 2.39 2.35 2.31 2.25 2.45 2.41 2.38 2.31 2.50 2.47 2.43 2.38
115 T.C. 21.3 19.4 17.9 15.9 21.5 19.7 18.2 16.6 21.7 19.9 18.3 16.8 S.C. 15.1 15.1 14.5 15.1 16.3 16.3 15.5 15.9 17.0 16.8 16.0 16.1
KW 2.56 2.51 2.46 2.39 2.62 2.57 2.52 2.46 2.68 2.63 2.58 2.53
125 T.C. 19.2 17.4 16.1 14.2 19.3 17.8 16.3 15.3 19.6 18.0 16.3 15.3 S.C. 14.4 14.4 13.7 14.3 15.6 15.6 14.8 14.8 16.4 16.0 15.1 14.6
KW 2.73 2.67 2.61 2.53 2.79 2.73 2.66 2.61 2.86 2.79 2.73 2.68
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB0806 G2FD024(S,H)17 0.99 0.99 1.02
N1AHB0806 G2FD030(S,H)17 1.01 1.01 1.02
N1VSB12 G2FD030(S,H)17 1.03 1.01 0.94
G1FA030S14 0.99 0.99 1.02
G1FA036S17,21 1.01 1.01 1.02
G1HD024 1.01 1.07 1.02
G1HD036 1.03 1.09 1.03
G1NA030S17K 1.00 0.97 1.00
G1NA030S21M 1.00 0.97 1.00
G1UA030S14 0.99 0.99 1.02
G1UA036S17,21 1.01 1.01 1.02
G2FD024(S,H)14,17 0.99 0.99 1.02
G2FD030(S,H)17 1.01 1.01 1.02
G2FD035(S,H)14 1.01 1.01 1.02
G1HA024H14 0.97 0.97 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA030S14 1.01 1.01 0.96
G8V***12UHA G2FD024(S,H)14 1.01 1.01 0.96
G8V***16UHB G1FA036S17 1.03 1.03 0.96
G8V***16UHB G2FD024(S,H)17 1.01 1.01 0.96
G8V***16UHB G2FD030(S,H)17 1.03 1.03 0.97
G9V***12DHB G2FD024(S,H)17 1.00 1.00 0.93
G9V***12DHB G2FD030(S,H)17 1.03 1.03 0.93
G9V***12UPB G1FA036S17 1.03 1.04 0.96
G9V***12UPB G2FD024(S,H)17 1.02 1.02 0.95
G9V***12UPB G2FD030(S,H)17 1.03 1.04 0.96

036-21320-002 Rev. A (1103)
16 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-F030S
INDOOR COIL MODEL NO. F2RP/F2FP036
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 800 1000 1200
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 32.2 30.6 28.5 32.6 31.4 30.0 32.9 31.8 30.4 S.C. 20.3 20.0 19.0 21.3 21.2 21.5 22.0 22.2 22.8
KW 2.32 2.32 2.30 2.40 2.40 2.38 2.52 2.52 2.51
85 T.C. 31.2 28.9 26.0 32.2 30.0 27.5 32.6 30.8 28.3 S.C. 20.1 19.3 18.0 22.0 21.2 20.5 23.2 22.9 22.2
KW 2.48 2.46 2.43 2.57 2.55 2.52 2.70 2.68 2.65
95 T.C. 30.2 27.1 23.4 31.7 28.6 24.9 32.3 29.9 26.1 S.C. 19.9 18.7 17.0 22.8 21.2 19.5 24.5 23.6 21.6
KW 2.64 2.60 2.56 2.74 2.70 2.65 2.87 2.84 2.79
105 T.C. 27.6 24.4 21.5 29.1 25.8 22.7 29.9 26.9 23.5 S.C. 18.9 17.7 15.9 21.8 20.2 18.5 23.8 22.5 20.4
KW 2.79 2.75 2.70 2.89 2.84 2.79 3.03 2.98 2.93
115 T.C. 25.0 21.7 19.5 26.5 23.0 20.5 27.5 24.0 20.9 S.C. 18.0 16.7 14.8 20.9 19.2 17.5 23.1 21.3 19.2
KW 2.93 2.89 2.84 3.04 2.98 2.93 3.19 3.12 3.08
125 T.C. 22.3 19.1 17.6 23.9 20.2 18.2 25.2 21.1 18.4 S.C. 17.0 15.8 13.7 19.9 18.2 16.5 22.4 20.2 18.0
KW 3.07 3.03 2.98 3.19 3.12 3.07 3.35 3.26 3.23
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB1206 G2FD036(S,H)17 0.98 0.98 1.01
N1VSB12 G2FD036(S,H)17 1.00 0.98 0.95
F2RP/F2FP030 0.97 0.97 1.01
G1FA036S14 0.99 0.96 1.01
G1FA036S17,21 0.97 0.97 1.01
G1HD036 0.99 1.06 1.01
G1HD048 1.03 1.10 1.02
G1NA036S17L 1.05 0.98 1.02
G1NA048S21D 1.05 0.98 1.02
G1UA036S14 0.99 0.96 1.01
G1UA036S17,21 0.97 0.97 1.01
G2FD030(S,H)17 0.97 0.97 1.01
G2FD035(S,H)14 0.97 0.97 1.01
G2FD036(S,H)17 0.98 0.98 1.01
G2FD036(S,H)21 0.98 0.98 0.98
G1HA036H14 0.96 0.96 0.96
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***12UHA G1FA036S14 1.00 0.98 0.98
G8V***12UHA G2FD035(S,H)14 0.99 0.99 0.95
G8V***16UHB G1FA036S17 0.99 1.00 0.94
G8V***16UHB G2FD036(S,H)17 1.00 1.00 0.94
G9V***12UHB G1FA036S17 0.98 0.99 0.96
G9V***12UHB G2FD030(S,H)17 0.98 0.99 0.96
G9V***12UHB G2FD036(S,H)17 0.99 0.99 0.96
G9V***12DHB G2FD036(S,H)17 0.99 0.99 0.96

036-21320-002 Rev. A (1103)
Unitary Products Group 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-F036S
INDOOR COIL MODEL NO. F2RP/F2FP036
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1000 1200 1400
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75 T.C. 38.3 36.4 34.5 38.5 36.7 35.1 38.8 37.0 35.7 S.C. 23.5 23.4 23.4 24.5 24.5 25.1 25.5 25.6 26.8
KW 2.85 2.83 2.80 2.91 2.89 2.86 3.03 3.01 3.00
85 T.C. 37.0 34.7 31.8 37.6 35.3 32.6 38.2 36.0 33.5 S.C. 23.9 23.2 22.3 25.5 24.8 24.2 27.2 26.5 26.2
KW 3.06 3.02 2.98 3.07 3.03 2.99 3.26 3.21 3.17
95 T.C. 35.7 33.0 29.1 36.6 34.0 30.1 37.5 35.0 31.2 S.C. 24.3 22.9 21.2 26.6 25.2 23.4 28.9 27.4 25.6
KW 3.27 3.20 3.15 3.34 3.27 3.22 3.48 3.41 3.35
105 T.C. 33.0 29.7 26.6 34.0 30.7 27.4 35.0 31.6 28.2 S.C. 23.4 21.6 20.1 25.8 23.9 22.2 28.1 26.1 24.2
KW 3.19 3.10 3.04 3.26 3.17 3.11 3.39 3.32 3.25
115 T.C. 30.4 26.5 24.1 31.4 27.4 24.7 32.4 28.2 25.3 S.C. 22.6 20.3 19.1 24.9 22.5 21.0 27.3 24.8 22.9
KW 3.12 3.00 2.92 3.18 3.08 3.00 3.31 3.23 3.15
125 T.C. 27.7 23.3 21.6 28.8 24.1 21.9 29.8 24.9 22.3 S.C. 21.8 18.9 18.1 24.1 21.2 19.8 26.5 23.4 21.5
KW 3.05 2.90 2.80 3.10 2.99 2.89 3.23 3.14 3.05
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHB1206 G2FD036(S,H)17 0.98 0.98 1.01
N1VSB12 G2FD036(S,H)17 1.00 0.98 0.95
N1VSB12 G2FD046(S,H)17 1.02 1.00 0.96
F2RP/F2FP042 1.00 1.00 1.00
G1FA048S21 1.02 1.02 1.01
G1HD036 0.98 1.05 1.01
G1HD048 1.06 1.11 1.05
G1NA036S17L 1.00 0.96 0.97
G1NA048S21D 1.00 0.96 0.98
G1UA048S21 1.02 1.02 1.01
G2FD036(S,H)17 0.98 0.98 1.01
G2FD036(S,H)21 1.00 1.00 1.00
G2FD042(S,H)21 1.01 1.01 1.02
G1HA036H17 0.99 0.99 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***16UHB G2FD036(S,H)17 0.99 1.00 0.97
G8V***20UHC G1FA048S21 1.04 1.05 0.95
G8V***20UHC G2FD036(S,H)21 1.02 1.02 0.95
G8V***20UHC G2FD042(S,H)21 1.02 1.04 0.96
G9V***12DHB G2FD036(S,H)17 0.98 0.98 0.94
G9V***12UPB G2FD036(S,H)17 0.99 1.00 0.98
G9V***16UPC G1FA048S21 1.04 1.05 0.97
G9V***16UPC G2FD036(S,H)21 1.01 1.02 0.96
G9V***16UPC G2FD042(S,H)21 1.02 1.04 0.97

036-21320-002 Rev. A (1103)
18 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-(T,W)036S
INDOOR COIL MODEL NO. G1FA048S21
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1050 1250 1450
ID DB (°F) 80 80 80 80 75 80 80 80 80 75 80 80 80 80 75
ID WB (°F) 72 67 62 55 62 72 67 62 55 62 72 67 62 55 62
75 T.C. 40.0 37.2 33.6 32.2 33.6 40.7 37.7 34.4 33.7 34.4 41.4 38.2 35.2 35.2 35.2 S.C. 18.8 24.9 29.9 32.1 25.5 19.4 26.5 32.3 33.7 27.7 20.0 28.0 34.6 35.2 29.9
KW 2.77 2.71 2.55 2.53 2.63 2.89 2.79 2.69 2.67 2.72 3.00 2.87 2.83 2.80 2.80
85 T.C. 39.1 35.3 31.4 30.5 31.4 39.7 36.2 33.1 32.2 33.1 40.3 37.0 34.9 33.8 34.9 S.C. 18.8 24.3 29.1 30.1 24.6 19.7 26.3 31.5 31.9 26.8 20.6 28.2 33.9 33.8 29.1
KW 3.00 2.90 2.77 2.75 2.80 3.10 3.00 2.92 2.88 2.98 3.20 3.10 3.07 3.01 3.17
95 T.C. 38.2 33.4 29.1 28.8 29.1 38.7 34.6 31.8 30.6 31.8 39.2 35.8 34.5 32.4 34.5 S.C. 18.7 23.7 28.2 28.0 23.6 20.0 26.1 30.7 30.2 25.9 21.2 28.4 33.2 32.4 28.2
KW 3.23 3.08 3.00 2.98 2.97 3.31 3.21 3.15 3.10 3.25 3.39 3.33 3.31 3.22 3.53
105 T.C. 34.9 30.5 27.2 26.9 27.2 35.5 31.5 29.3 28.5 29.3 36.1 32.6 31.5 30.0 31.5 S.C. 17.6 22.6 26.5 26.4 22.5 18.9 24.9 28.6 28.2 24.5 20.2 27.2 30.6 30.0 26.5
KW 3.39 3.24 3.16 3.15 3.20 3.49 3.37 3.31 3.27 3.44 3.58 3.49 3.45 3.39 3.69
115 T.C. 31.6 27.5 25.2 25.1 25.2 32.3 28.4 26.9 26.4 26.9 32.9 29.3 28.5 27.7 28.5 S.C. 16.6 21.6 24.9 24.7 21.3 17.9 23.8 26.4 26.2 23.1 19.3 26.0 27.9 27.6 24.9
KW 3.56 3.40 3.32 3.32 3.42 3.66 3.53 3.46 3.44 3.64 3.77 3.65 3.60 3.57 3.85
125 T.C. 28.3 24.6 23.3 23.2 23.3 29.1 25.4 24.4 24.3 24.4 29.8 26.1 25.5 25.3 25.5 S.C. 15.5 20.5 23.2 23.1 20.2 16.9 22.7 24.3 24.2 21.7 18.3 24.8 25.3 25.2 23.2
KW 3.72 3.57 3.49 3.49 3.65 3.84 3.68 3.61 3.62 3.83 3.96 3.80 3.74 3.74 4.01
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Coil T.C. S.C. KW
G1UA048S21 1.00 1.00 1.00
G1HA048H21 1.01 1.02 1.00
G2FD048S(21,24) 0.99 0.97 1.00

036-21320-002 Rev. A (1103)
Unitary Products Group 19
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EABC-F042S
INDOOR COIL MODEL NO. F2FP048
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1200 1400 1600
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 47.5 43.8 40.7 36.7 48.0 44.3 41.2 37.4 48.4 44.7 41.7 37.7 S.C. 29.2 29.4 28.4 30.1 30.7 30.9 29.9 31.9 31.9 32.1 31.2 32.9
KW 3.24 3.19 3.18 3.13 3.33 3.29 3.28 3.23 3.47 3.42 3.41 3.36
85 T.C. 45.4 41.9 38.9 35.1 45.8 42.3 39.5 35.7 46.1 42.5 39.8 36.0 S.C. 28.5 28.7 27.8 29.3 29.9 30.2 29.4 31.0 31.1 31.2 30.3 32.1
KW 3.54 3.50 3.48 3.43 3.55 3.51 3.48 3.44 3.77 3.74 3.71 3.66
95 T.C. 42.4 39.1 36.4 32.8 42.8 39.5 37.0 33.3 43.0 39.9 37.2 33.7 S.C. 27.4 27.6 26.7 28.2 29.0 29.2 28.3 29.9 29.1 29.5 28.3 31.0
KW 3.79 3.76 3.73 3.68 3.89 3.85 3.82 3.78 4.02 3.98 3.96 3.92
105 T.C. 39.4 36.3 33.9 30.6 39.8 36.8 34.3 31.1 40.0 37.0 34.5 31.9 S.C. 26.4 26.5 25.8 27.2 28.0 28.3 27.1 28.8 29.3 29.3 28.1 30.2
KW 4.07 4.04 4.00 3.96 4.17 4.13 4.11 4.06 4.29 4.26 4.24 4.21
115 T.C. 36.6 33.8 31.4 28.4 36.9 34.1 31.8 29.4 37.1 34.3 32.1 29.8 S.C. 25.5 25.6 24.6 26.2 27.2 27.2 26.2 27.9 28.2 28.2 27.3 28.2
KW 4.38 4.35 4.33 4.27 4.47 4.44 4.42 4.38 4.61 4.58 4.55 4.51
125 T.C. 33.8 31.3 28.8 26.2 34.0 31.4 29.3 27.7 34.2 31.6 29.7 27.7 S.C. 24.6 24.7 23.5 25.2 26.4 26.1 25.2 27.0 27.1 27.1 26.5 26.2
KW 4.69 4.66 4.66 4.58 4.77 4.75 4.73 4.70 4.93 4.90 4.86 4.81
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHC1606 G2FD042(S,H)21 0.98 0.99 0.99
N1VSC16 G2FD048(S,H)21 1.01 1.00 0.98
F2RP/F2FP042 0.96 0.96 1.00
G1FA048S21 0.99 0.99 0.98
G1HD048 0.99 1.04 0.99
G1NA048S21D 0.99 0.98 1.00
G1UA048S21 0.99 0.99 0.98
G2FD042(S,H)21 0.98 0.99 0.99
G2FD048(S,H)21,24 0.99 1.00 0.98
G2FD060(S,H)24 1.00 1.02 0.97
G1HA036H17 0.96 0.97 0.97
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***20UHC G1FA048S21 1.00 1.01 0.95
G8V***20UHC G2FD042(S,H)21 0.99 1.01 0.96
G8V***20UHC G2FD048(S,H)21 1.00 1.02 0.96
G9V***20DHD G2FD048(S,H)24 1.01 2.37 0.95
G9V***16UPC G1FA048S21 1.00 1.01 0.95
G9V***16UPC G2FD042(S,H)21 0.99 1.01 0.97
G9V***16UPC G2FD048(S,H)21 0.99 1.00 0.98

036-21320-002 Rev. A (1103)
20 Unitary Products Group
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
* Matchups marked with asterisks are the only ones that may be
matched with 3-Phase outdoor units.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. EBBC-F048S, EABC(T,W)048S*
INDOOR COIL MODEL NO. G1NA042S24W
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1400 1600 1800
ID DB (°F) 85 80 75 70 85 80 75 70 85 80 75 70
ID WB (°F) 72 67 62 57 72 67 62 57 72 67 62 57
75 T.C. 52.6 48.2 44.5 39.8 53.5 49.1 45.4 41.0 53.9 49.5 45.8 41.4 S.C. 32.6 32.8 31.5 33.2 34.9 35.0 33.7 35.7 36.0 36.2 34.9 36.9
KW 3.74 3.68 3.64 3.57 3.87 3.82 3.78 3.71 3.93 3.88 3.84 3.77
85 T.C. 50.5 46.3 42.7 38.2 51.3 47.1 43.6 39.3 51.8 47.5 44.0 39.7 S.C. 31.9 32.0 30.8 32.3 34.1 34.2 33.0 34.9 35.4 35.5 34.3 36.0
KW 3.92 3.85 3.79 3.70 4.06 3.99 3.93 3.84 4.12 4.05 3.99 3.91
95 T.C. 48.7 44.5 41.0 36.8 49.7 45.5 42.1 37.7 49.9 45.7 42.5 38.1 S.C. 31.1 31.2 30.0 31.7 33.6 33.7 32.6 34.1 34.6 34.7 33.6 35.2
KW 4.26 4.17 4.08 3.96 4.40 4.31 4.22 4.11 4.47 4.37 4.29 4.18
105 T.C. 46.7 42.7 39.3 35.3 47.6 43.6 40.3 36.1 47.9 43.9 40.5 36.5 S.C. 30.4 30.4 29.3 30.9 32.9 32.9 31.7 33.3 33.9 33.9 32.7 34.5
KW 4.60 4.48 4.37 4.22 4.74 4.62 4.52 4.38 4.82 4.69 4.59 4.46
115 T.C. 44.8 40.9 37.5 33.6 45.5 41.6 38.4 34.4 45.8 41.9 38.7 34.9 S.C. 29.8 29.8 28.7 30.1 32.0 32.0 30.8 32.2 33.1 33.2 31.8 33.5
KW 4.95 4.79 4.66 4.50 5.11 1.95 4.82 4.66 5.18 5.02 4.90 4.74
125 T.C. 42.9 39.1 35.8 32.0 43.4 39.6 36.5 32.7 43.7 39.8 36.8 33.2 S.C. 29.2 29.2 28.1 29.3 31.1 31.1 29.8 31.1 32.3 32.5 31.0 32.5
KW 5.30 5.10 4.95 4.78 5.48 -0.72 5.12 4.94 5.54 5.35 5.21 5.02
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
N1AHC1606 G2FD048(S,H)21 0.99 1.02 0.99
N1AHD2006 G2FD060(S,H)24 1.01 1.05 1.00
N1AHD2006 G2FD061H24 1.02 1.11 1.00
N1VSD20 G2FD060(S,H)24 1.02 1.05 0.96
N1VSD20 G2FD061H24 1.03 1.11 0.96
F2FP045 1.00 1.02 0.98
F2FP048 0.99 1.03 1.01
F2FV060 1.02 1.09 0.96
G1FA048S21* 0.99 1.01 1.09
G1FA060S21,24 1.01 1.05 1.00
G1HD060 1.00 1.04 1.00
G1UA048S21* 0.99 1.01 0.98
G1UA060S21,24 1.01 1.05 1.00
G2FD048(S,H)21,24* 0.99 1.02 0.99
G2FD060(S,H)24 1.01 1.05 1.00
G2FD061H24 1.02 1.11 1.00
G1HA048H21 0.97 0.99 1.07
Variable Speed
Furnace Coil T.C. S.C. KW
G8V***20UHC G1FA048S21 1.00 1.02 0.96
G8V***20UHC G1FA060S21 1.01 1.05 0.97
G8V***20UHC G2FD048(S,H)21 0.99 1.02 0.98
G9V***20DHD G2FD048(S,H)24 1.02 1.06 1.00
G9V***16UPC G1FA048S21 0.99 1.01 0.98
G9V***16UPC G1FA060S21 1.00 1.03 0.98
G9V***16UPC G2FD048(S,H)21 0.98 1.00 0.99
G9V***20UPD G1FA060S24 1.01 1.05 0.98
G9V***20UPD G2FD060(S,H)24 1.01 1.05 0.98
