YORKVILLE ELITE LS700P Quick start guide

U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: [phone]
Fax: [phone]
WORLD HEADQUARTERS
WEB ACCESS: http://www.yorkville.com
CANADA
Yorkville Sound
550 Granite Court
Pickering, Ontario
L1W-3Y8 CANADA
Voice: [phone]
Fax: [phone]
Quality and Innovation Since 1963
Printed in Canada
SERVICE MANUAL
LS700P
MODEL TYPE: ES700P

IMPORTANT SAFETY INSTRUCTIONS
safety-4v2.eps Aug 26/05
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
INSTRUCTIONS PERTAINING TO A
RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS
Read Instructions
The Owner’s Manualshould be read and understood
before operation of your unit. Please, save these instruc-
tions for future reference.
Packaging
Keep the box and packaging materials, in case the unit
needs to be returned for service.
Warning
When using electric products, basic precautions should
always be followed, including the following:
Power Sources
Your unit should be connected to a power source only of the voltage
specified in the owners manual or as marked on the unit. This unit has
a polarized plug. Do not use with an extension cord or receptacle
unless the plug can be fully inserted. Precautions should be taken so
that the grounding scheme on the unit is not defeated.
Hazards
Do not place this product on an unstable cart, stand, tripod, bracket or
table. The product may fall, causing serious personal injury and serious
damage to the product. Use only with cart, stand, tripod, bracket, or
table recommended by the manufacturer or sold with the product.
Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer.
The apparatus should not be exposed to dripping or splashing water;
no objects filled with liquids should be placed on the apparatus.
Terminals marked with the “lightning bolt” are hazardous live; the
external wiring connected to these terminals require installation by an
instructed person or the use of ready made leads or cords.
No naked flame sources, such as lighted candles, should be
placed on the apparatus.
Power Cord
The AC supply cord should be routed so that it is unlikely that it will be
damaged. If the AC supply cord is damaged DO NOT OPERATE THE UNIT.
Service
The unit should be serviced only by qualified service personnel.
AVIS:
AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE)
NE CONTIENT AUCUNE PIECE
REPARABLE PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE
POUR L’ENTRETIENT
INSTRUCTIONS RELATIVES AU RISQUE
DE FEU, CHOC ÉLECTRIQUE, OU
BLESSURES AUX PERSONNES
Veuillez Lire le Manuel
Il contient des informations qui devraient êtres comprises
avant l’opération de votre appareil. Conservez S.V.P. ces
instructions pour consultations ultérieures.
Emballage
Conservez la boite au cas ou l’appareil devait être
retourner pour réparation.
Attention:
Lors de l’utilisation de produits électrique, assurez-vous
d’adhérer à des précautions de bases incluant celle qui
suivent:
Alimentation
L’appareil ne doit être branché qu’à une source d’alimentation
correspondant au voltage spécifié dans le manuel ou tel qu’indiqué sur
l’appareil. Cet appareil est équipé d’une prise d’alimentation polarisée.
Ne pas utiliser cet appareil avec un cordon de raccordement à moins
qu’il soit possible d’insérer complètement les trois lames. Des
précautions doivent êtres prises afin d’eviter que le système de mise à
la terre de l’appareil ne soit désengagé.
Risque
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une
table instables. L’appareil pourrait tomber et blesser quelqu’un ou subir
des dommages importants. Utiliser seulement un chariot, un support,
un trépied ou une table recommandés par le fabricant ou vendus avec
le produit. Suivre les instructions du fabricant pour installer l’appareil et
utiliser les accessoires recommandés par le fabricant.
Il convient de ne pas placer sur l’appareil de sources de flammes
nues, telles que des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des
éclaboussures et qu’aucun objet rempli de liquide tel que des vases
ne doit être placé sur l’appareil.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties
dangereuses au toucher et que les câblages extérieurs connectés à
ces dispositifs de connection extérieure doivent être effectivés par un
opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’Alimentation
Évitez d’endommager le cordon d’alimentation. N’UTILISEZ PAS
L’APPAREIL si le cordon d’alimentation est endommagé.
Service
Consultez un technicien qualifié pour l’entretien de votre appareil.

LS700P Parts List 8/31/2005
YS # Description Qty. YS # Description Qty. YS # Description Qty.
6405 RED 3MM LED 1V7 5MA BRT 2 3501 B52200F006 COMP WASH #4 SMALL 2 8823 6-32 X 1 PAN PH TAPTITE JS500 8
6410 GRN 3MM LED 1V7 5MA CLEAR BRT 1 3556 XSISTOR HOLD SPRING-BAR (PLATED) 4 8998 6-32 X 1 FLAT PH MS ZINC CLEAR 4
6419 BRIDGE 35A 400V WIRE LEAD GI3504 2 3800 BELLY BUTTON #BB1 CORDS CANADA 8 8803 8-32 X 3/8 PAN PHIL TAPTITE JS500 4
6425 BAV21 200V 0A25 DIODE T&R 8 3862 SIL PAD 400 1.5X6.75 2 8815 8-32 X 3/4 PAN PH TAPTITE JS500 12
6825 1N4148 75V 0A45 DIODE T&R 28 9897 CABINET COVER, BLACK, 54" WIDE 20.069 8749 10-32 X 1/2 QDX PH TAPTITE JS500 2
6438 1N4007 400V 1A0 DIODE T&R 16 3803 NYLON SECUR-A-TACH MINI PLASTIC TIE 1 8756 #10 X 3/4 PAN PH TYPE A BLACK OXIDE 40
6479 MUR415 150V 4A0 DIODE FASREC 12 3810 4" NYLON CABLE TIE 13 8727 #10 X 1" PAN PH TYPE A JS500 BLACK 24
5121 MZ4615RL 2V0 W25 ZENER 5% T&R 2 8661 BUTTON KNOB FLAT GREY 2 8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK 8
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 4 8693 S ROTARY KNOB GREY 2 8777 #14 X 1FLAT PH TYPE A JS500 M6 HEAD 4
6436 1N753ARL 6V2 0W5 ZENER 5% T&R 1 3468 8' 3/16 SJT AC LINE CORD STRIP 17" 1 8928 #14X11/4 ALLEN FLHD WOOD SCRW JS500 6
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 6 3821 HEYCO #1200 STRAIN RELIEF 1 8794 5/16-18 X 3 1/2 GRD5 HEX BOLT JS500 1
6450 1N5242B 12V0 0W5 ZENER 5% T&R 2 8259D "Y" LOGO ELITE SERIES LARGE DOMED 1 3741 .5 SPACER ID-.171 OD-.25 #912-500 6
6465 1N5250B 20V0 0W5 ZENER 5% T&R 1 3521 SIDE ENTRY PCB CONN .156 8POS 1 8657 6-32 X 3/8" HEX SPACER ALUMINUM 4
6856 NJM7815FA TO220 P 15V0 REG IS V1 1 3538 24 PIN BREAKAWAY LOCK .156 0.708 7269 10" 4R 350WPGM SPEAKER CAST FRAME 2
6857 NJM7915FA TO220 N 15V0 REG IS V2 1 3607 SIDE ENTRY PCB CONN. 9 POS. 1 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
5101 BC550C TO92 NPN TRAN T&R TB 10 3674 9 CIR CABLE HOLDER .098 1 3511 #6 FLAT WASHER NYLON 2
5102 BC560C TO92 PNP TRANSISTOR T&R TB 5 8701 4-40 KEPS NUT ZINC 2 8485 #6 SPLIT WASHER ZINC 2
5109 MPSA43 TO92 NPN TRAN TA 10 8800 6-32 KEPS NUT ZINC 14 8820 #8 FLAT WASHER JS500 4
5114 MPSA92 TO92 PNP TRAN T&R TA 14 8797 5/16-18 KEPS NUT JS500 1 8473 #10 BLACK CUPWASHER SWF-10BK 1
5119 2N5638 TO92 NCH JFET T&R TC 4 4597 22AWG STRAN TC WIR JMP 9 3436 DPDT PUSH SW PCMT H BREAK B4 MAKE 2
6928 IRFP250 TO247 NCH MFET TM 6 4599 22AWG SOLID SC WIR T&R JMP 31 3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65 1
6991 MJL21193 TO3P PNP TRAN TK 2 5299 24AWG SOLID SC WIR RAD JMP 7 3399 THERMO/BRKR:N/CLOSED OPEN@96C 1
6878 TL071CP IC FET OP AMP 1 4745 5.0W 0R1 5% BLK RES 6 8468 VELCRO STRAP 3/4"X22CM (VELSTRAP) 1
6882 TL072CP IC FET DUAL OP AMP 7 4688 1/2W 2R2 5% T&R RES 4 CH1287 PPW /EPW 120VAC 60HZ T'RD 1
6745 LM13600N IC XCONDUCTANCE AMP 1 4748 2.0W 3R9 5% T&R 4
5190 MBS4992 TO92 8V5 TRNSISTR DIAC T&R 2 4675 1/2W 10R 5% T&R RES 2
6470 MAC15A6FP TO220 15A TRIAC 400V 2 2013 1/8W 22R1 1%FLAME PROOF T&R RES 2
6472 4K7 3% 0W0 THERMISTOR 2 4816 1/4W 33R 5% T&R RES 1
6473 68K 3% 0W0 THERMISTOR 4 2019 1/8W 100R0 1%FLAME PROOF T&R RES 2
6482 115R 20% 0W0 PTC THERMISTOR 2 4921 1/4W 100R 5% .2"U T&R RES 6
5405 _27P 200V 5%CAP T&R RAD CER.2"NPO 2 4909 1/4W 200R 5% T&R RES 2
5199 100P 100V 2%CAP T&R RAD CER.2"NPO 4 4932 1/4W 200R 5% .2"U T&R RES 8
5197 220P 100V 2%CAP T&R RAD CER.2"NPO 2 4857 1/4W 220R 5% T&R RES 2
5201 470P 100V 5%CAP T&R RAD CER.2"NPO 10 2024 1/8W 249R 2%FLAME PROOF T&R RES 4
5816 680P 100V 5%CAP T&R RAD CER.2"NPO 2 2025 1/8W 274R 1%FLAME PROOF T&R RES 4
5275 __3N3 100V 5%CAP T&R RAD .2"FLM 6 4933 1/4W 470R 5% .2"U T&R RES 2
5209 __4N7 250V 5%CAP T&R RAD .2"FLM 2 2028 1/8W 475R 1%FLAME PROOF T&R RES 4
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 2030 1/8W 681R 1%FLAME PROOF T&R RES 2
5204 _10N 100V 10%CAP T&R RAD .2"FLM 1 4923 1/4W 680R 5% .2"U T&R RES 3
5840 _22N 400V 10%CAP BLK RAD POLY FLM 1 4758 1/4W 953R 1% T&R RES 8
6435 _22N 275V 20%CAP BLK 'X2' 15MM AC 1 4823 1/4W 1K 5% T&R RES 3
5222 _33N 100V 10%CAP T&R RAD .2"FLM 1 4981 1/4W 1K 5%MINI T&R RES 1
5224 _47N 100V 10%CAP T&R RAD .2"FLM 8 4825 1/4W 1K8 5% T&R RES 1
5228 100N 100V 5%CAP T&R RAD .2"FLM 21 4936 1/4W 2K7 5% .2"U T&R RES 10
5229 150N 63V 10%CAP T&R RAD .2"FLM 2 4764 1/4W 2K740 0.1% *** T&R RES 2
5231 220N 63V 10%CAP T&R RAD .2"FLM 7 4826 1/4W 3K3 5% T&R RES 1
5318 220N 50V 10%CAP T&R BEAD X7R 1 4943 1/4W 4K7 5% .2"U T&R RES 4
5259 __4U7 63V 20%CAP T&R RAD .2"EL 2 4982 1/4W 4K7 5%MINI T&R RES 3
5281 _10U 16V 20%CAP T&R RAD .2"NP 4 4939 1/4W 5K1 5% .2"U T&R RES 2
5945 _10U 63V 20%CAP T&R RAD .2"EL 2 4685 1.0W 5K6 5% T&R RES 2
5260 _22U 50V 20%CAP T&R RAD .2"EL 6 4862 1/4W 5K6 5% T&R RES 8
5961 _33U 16V 20%CAP T&R RAD .2"NP 6 4829 1/4W 10K 5% T&R RES 6
5265 _68U 25V 20%CAP T&R RAD .2"EL 4 4940 1/4W 10K 5% .2"U T&R RES 8
5267 100U 25V 20%CAP T&R RAD .2"EL 3 4983 1/4W 10K 5%MINI T&R RES 9
5914 100U 63V 20%CAP BLK 10X13MM EL 2 4630 1/2W 15K 5% T&R RES 3
5621 470U 63V 20%CAP BLK 12X25MM EL 4 4885 1/4W 20K 5% T&R RES 4
5859 4700U 50V 20%CAP BLK 25X36MM ELS 2 4832 1/4W 22K 5% T&R RES 2
5890 5600U 100V 20%CAP RAD 35X50MM ELS 4 4941 1/4W 30K 5% .2"U T&R RES 8
4403 _10K 5B LIN 16MM P14 1 4917 1/4W 31K6 1% T&R RES 6
4389 _20K 1B LIN 16MM E432B STEREO P24 1 4840 1/4W 33K 5% T&R RES 5
713 25 X 20 X 50 2 MIL PLASTIC BAG 1 6122 1/4W 33K 5%MINI T&R RES 5
3819 ___5UH COIL 18AWG R000 AIR CORE 2 4794 1/4W 37K90 0.1% *** T&R RES 2
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK 1 4878 1/4W 43K 5% T&R RES 2
8547 PLASTIC FOOT BLACK, POLYETHYLENE 4 4834 1/4W 47K 5% T&R RES 2
8567 CORNER, 2 LEGS/1 LIP BLACK OXIDE 2 6119 1/4W 47K 5%MINI T&R RES 2
8569 CORNER, 2 LEGS NO LIP BLACK OXIDE 6 4835 1/4W 56K 5% T&R RES 2
3489 CLIP 250X032 18-22AWG DISCO/INSL 7 4836 1/4W 68K 5% T&R RES 1
3490 CLIP 250X032 14-16AWG DISCO/INSL 1 4763 1/4W 82K50 0.1% *** T&R RES 2
3491 CLIP 205/187X020 18-22AWG DISCO/INS 4 4772 1/4W 82K5 1% T&R RES 4
3601 RING TERMINAL 16AWG WIRE & #8 SCREW 2 4838 1/4W 100K 5% T&R RES 4
3682 250 MALE PCB TAB REEL 19 6120 1/4W 100K 5%MINI T&R RES 1
3795 #8 GROUND LUG ZIERICK 505-169 2 4839 1/4W 150K 5% T&R RES 2
3498 1/4" JCK PCB MT HORZ 4 4841 1/4W 220K 5% T&R RES 6
3451 EYELET SMALL 0.089 OD PLATED 57 4844 1/4W 1M 5% T&R RES 4
3412 LOWPROFILE FUSEHOLDER FOR .25X1.25 1 4888 1/4W 4M7 5% T&R RES 1
3414 INTERNATIONAL PC MOUNT FUSEHOLDER 8 8742 4-40 X 3/8 PAN PH TAPTITE JS500 16
2427 5.0 AMP SLO-BLO .25X1.25 FUSE 1 8861 4-40 X 3/8 PAN PH MS JS500 2
2438 12.0 AMP SLO-BLO .25X1.25 FUSE 4 8799 #6 X 1/4 PAN PH TYPE B JS500 1
8565 BAR HANDLE ALL METAL 2 8801 6-32 X 3/8 PAN PH TAPTITE JS500 2
8604 10-32 T NUT 8 8806 6-32 X 1/2 PAN PH TAPTITE JS500 2

YORKVILLE NAME: PCB#&VER:
MODELS: SCH ISSUE:
TITLE:
DATE:
M508
PS218P
ES700P
M508A.SCH
AUG/26/2004
PWR_AMP
1.60
D1
10V 3n3
C18
5K6
R51
680R
R64
680R
R1
220K
R2
100v
3n3
C20
1N4004
D15
100R
R36
274R
R4
PILOT
RED
LD1
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
D
D
D
D
D
D
D
D
D
AUG/26/04
V
V
V
V
V
V
V
V
V
1.60
N
N
N
N
N
N
N
N
N
PC#6722_ADD_R66,R67_E->B,Q13,Q8
LS700P-PS218P
M508A.SCH_DATABASE_HISTORY
4K7
R5
S
G
D
N
IRFP250
Q19
5K6
1W
R41
220K
R6
MC2
2
953R
R7
25v 27p
C19
22K
R9
953R
R10 68U16V C1
68U16V C2
MC2
1
274R
R54
12v
500mW
D22
475R
R55
BC550
Q8
249R
R13
MPSA92
Q9
30K
R52
MPSA43
Q3
MPSA43
Q4
2K7
R14
2K7
R15
BC550
Q10
200R
R16
4K7
R23
249R
R17
BC550
Q11 16V
33U
C6
D4
D5
10K
R18
10K
R42
BAV21
D32
BC550
Q12
10V 3N3
C10
10K
R19
60v
470P
C11
S
G
D
N
IRFP250
Q15
S
G
D
N
IRFP250
Q16
0R1
5W
R45
0R1
5W
R46
25v 680P
C12
63v
220n
C14
MUR415
D9
10K
R20
500mW
10v
D10
500mW
10v
D11
MPSA43
Q2
MPSA92
Q13
MPSA43
Q21
100R
R21
10v 100N
C15
200R
R22
MPSA92
Q22
BAV21
D21
BC560
Q14
16V
33U
C7
BAV21
D14
2K7
R24
2K7
R25
475R
R26
470R
R59
2V0
250mW
D12
5K1
R11
100u 63v
C4
D6
D7
56K
R28
43K
R29
100R
R30
16V
33U
C5
31K6
R32
68K
R47
68K
R48
5K6
R44
25v 100p
C9
25v 100P
C13
100R
R34
5uH
L1
2N5638
Q25
953R
R40
D2
MPSA43
Q1
30K
R50
MPSA92
Q7
MPSA92
Q6
16v
10u
C8
MT1
MT2
G
TRIAC_MAC15A4FP
Q17
MT1
G
MT2
MBS4992
Q18
953R
R43
4K7
R56
D33
1M
R33
MPSA92
Q5
MUR415
D30
2K7
R27
2N5638
Q24
1N4004
D16
22R
R39
10R
0.5W
R49
30K
R35
5K6
R3
22u
16v
C25
BAV21
D17
30K
R57
10v
500mW
D23
200R
R58
MUR415
D24
MJL21193
Q20
470u
63v
C23 5600u
100v
C26
1N4004
D28
1N4004
D29 MUR415
D25
MUR415
D26
1N4004
D31
470u
63v
C24
5600u
100v
C27
D18
D19
D20
MPSA92
Q23
1M
R60
31K6
R61
31K6
R8
MUR415
D27
2R2
0.5W
R62
2R2
0.5W
R63
63v
220n
C28
63v
220n
C29
MC3
2
MC1
1
MC3
4
MC1
5
63v
220n
C30
60v
470P
C33
5K6
R65
4u7 63v
C34
3R9
0.5W
R12
63v
100n
C3
200R
R31
63v
4n7
C22
25v
470p
C31
25v
470p
C32
G
MT2 MT1
MAC15A4FP BC550C
CBE
BC560C MPSA43
EBC
MPSA92
DSG
2N5638
MT1
NC
MT2
MBS4992
200R
R53
50v
470p
C21
MJL21193
ECB
4.7V
1N750A
D36
4.7V
1N750A
D35
IRFP250
SDG
4K7
R67
4K7
R66
IAMP_IN
POS_IN_R
VMID+
NEG_IN_L
NEG_IN_L
VA_OUT
NEG_IN_R VH-
VMID-
CLIP_R
GND
GND
GND
GND
GND
GND
GND
GND
GND GND
GND
GND
GND
FET_CNTL
POS_IN_L
POS_IN_L
CLIP_L
CLIP_L
VH+
VH+
CONNECTED TO M509 MX1
9
8
7
6
5
4
3
2
1
SERVICE WARNING: POTENTIALS GREATER THAN 130VDC PRESENT.
USE EXTREME CAUTION.
AMPLIFIER
THE LEFT CHAN
CONNECTIONS TO
1.7mA
7.5mA
OUTPUTS
MC2
MC1
*
A
U:\M508AV16.PRN

VCD
.020"
.012"
.008"
.005"
.020"
.012" .008"
.005"
SHEARSHEAR
SHEAR SHEAR
SHEAR SHEAR
SOLDERSIDE M508-6.00
BLANK SIZE=17.35"X8.625"
M508-6.00
2 oz COPPER
VCD
DRILL DETL M508-5.20
D1L
4148
D14L BAV21
D2L
4148
Q1L
A43
Q2L
A43
Q3L
A43
Q4L
A43
Q5L
A92 Q6L
A92
Q7L
A92
R36L
100R
R7L
953R
R11L 5K1
D33R
4148 D36R
4V7
R55L
475R
R19L
10K
C3R
100n
R20L
10K
R22L
200R R18L
10K
C18L
3N3
R14L
2K7
R30L
100R
R57R30K
R5R
4K7
R44L
5K6
R10R 953R
J6L
D15L
4004
R27L
2K7
R6L 220K
R33R 1M
R31L200R
R24L
2K7
R35L 30K
R25L
2K7
R21L
100R
R15L
2K7
MC1_B
FUNCTION
R56R 4K7
R28L
56K
R2L
220K
R29L
43K
R39L
22R1
LD1L
R
C4L
63V
100U
Q8L
550
Q13L
A92
Q10L
550
Q11L
550
Q12L
550
R60L
1M
Q14L
560
R52L
30K
D18R
4148
C11L
470P
C12L680P
C13L 100P
C10L
3N3
C14L
220N
C33L
470P
R17R 249R
R17L249R
C20L
3N3
R40R 953R
R7R 953R
R26L
475R
R33L
1M
R49L
0.5W
10R
C15L
100N
R47L
68K
R48L
68K
R65R
5K6
Q24L
2N5638
C8L
10U 16V
J13
C1L
68U
16V
C2L
68U
16V
C29L
220n
D11L
10V
Q18L
MBS4992
Q9L A92
C5L
33U 16V
D35R
4V7
C7L
33U 16V
R32L
31K6
C22L
4N7
R50L
30K
R62L
0.5WATT
2R2
C6L
33U 16V
DOWN
BAR
D24L
MUR415
C21L
470p
R26R 475R
R23L
4K7
L1L
5UH
R51L
5K6
D5L 4148
Q15R
PART#6928
IRFP250
D7R
4148
J7L
DOWN
BAR
D27L
MUR415
R45L
0R1
5WATTS
C30L
220n
H1R
D34L
4004
D28L
4004
D12L
2V0
DOWN
BAR
D9L
MUR415
C32R
470P
D4L
4148
DOWN
BAR
D25L
MUR415
J5L
D32L
BAV21
R40L
953R
D33L
4148
D18L
4148
J2
WC1
J4
C24L
470u
63v
C27
PART#
5600U
100V
Q17L
#XXXX TRIAC
MAC15A4FP
YYY
D28R
4004
D17R
BAV21
R65L 5K6
C28R
220n
C34L
22U
50V
C25R
16v
22u
C31L
470P
Q16L
PART#
IRFP250
R41L
1WATT
5K6
D34R 4004
R3L 5K6
R46L
0R1
5WATTS
D10L
10V
DOWN
BAR
D26L
MUR415
Q23L
A92
Q22L
A92
Q21L
A43
D23L
10v
D22L
12V
C23L
470u
63v
R12L 3R9
2_WATTS
DOWN
BAR
D30L
MUR415
R62R
0.5WATT
2R2
Q20L
MJL21193
Q19L
PART#6928
IRFP250
R9R 22K
Q25L
2N5638
R58L
200R
H6R
R57L
30K
R56L
4K7
R43R 953R
R10L
953R
R53L
200R
R58R 200R
Q15L
PART#6928
IRFP250
D7L
4148
H1L
D19R
4148
RTV
D17L
BAV21
C28L
220n
R3R 5K6
C25L
16v
22u
R9L
22K
J15
C21R
470p
C26
PART#
5600U
100V
R12R
3R9
2_WATTS
H6L
J9
R50R
30K
R53R
200R
Q25R
2N5638
R61R
31K6
Q19R
PART#6928
IRFP250
Q20R
MJL21193
R52R
30K
R63L
0.5WATT
2R2
D2R
4148
C23R
470u
63v
D22R
12V
D23R
10v
Q21R
A43
Q22R
A92
Q23R
MPSA92
DOWN
BAR
D26R
MUR415
D10R
10V
R46R
0R1
5WATTS
D21R
BAV21
D15R
4004
R41R
1WATT
5K6
Q16R PART#
IRFP250
R44R
5K6
D16R
4004
Q17R
#XXXX TRIAC
MAC15A4FP
YYY
C24R 470u
63v
D20R
4148
R16L
200R
J5R
DOWN
BAR
D25R
MUR415
D4R
4148
C20R
3N3
DOWN
BAR
D9R
MUR415
D12R
2V0
D31R
4004
D29L
4004
C30R
220n
EY6R
R45R
0R1
5WATTS
DOWN
BAR D27R
MUR415
J11
EY7R
EY8R
D5R
4148
D6L
4148
R51R
5K6
L1R
5UH
R23R
4K7
D35L
4V7
C33R
470p
DOWN
BAR
D24R
MUR415
C6R
33U
16V
R59R
470R
C7R
33U
16V
C22R
4N7
C5R
33U 16V
Q9R
A92
Q18R
MBS4992
D11R
10V
C29R
220n
C2R
68U 16V
C1R
68U 16V
C8R
10U 16V
Q24R
2N5638
R32R
31K6
R67R
4K7
R48R
68K
R47R
68K
C15R 100N
R49R
0.5W
10R
R55R
475R
D36L
4V7
R54R
274R
R13R
249R
C10R
3N3
R13L
249R
C13R
100P
C14R
220N C12R
680P
C11R
470P
C18R
3N3
C3L 100n
C9L
100P
R15R
2K7
Q14R
560
Q12R
550
Q11R
550
Q10R 550
Q13R
A92
Q8R
550
C4R
63V
100U
LD1R
R
R61L
31K6
R29R
43K
C19L
27p
R28R
56K
R21R
100R
R25R
2K7
R35R
30K
R24R 2K7
R31R
200R
R4R
274R
R27R
2K7
R34L 100R R6R
220K
R34R
100R
D16L
4004
J6R
R30R
100R
R1L
681R
R14R
2K7
R18R
10K
R59L
470R
R22R 200R
R20R 10K
R19R 10K
R11R
5K1
D19L
4148
R5L
4K7
R60R
1M
D32RBAV21
R36R
100R
R43L
953R
R42L
10K
Q7R
A92
Q6R
A92
Q5R
A92
Q4R A43
Q3R
A43
Q2R
A43
Q1R
A43
D6R
4148
D14R
BAV21
D1R 4148
J12
R66R
4K7
FUNCTION PART#
RTV
R67L
4K7
1
FUNCTION
R66L
4K7
J3
WC2
J18
J10
RTV
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
M508/A/C.PCB_DATABASE_HISTORY
LS700P_PS218_PS210PX
SOME_TRACES_ALTERED.PADS_FOR_MOLEX
CHANGED_FROM_S100_TO_R120.
ROUTING_BY_FILTER_CAPS_CHANGED.
PC#XXXX_FILTER_CAPS_CHANGED
PC#4409_Q11R_MOVED
PC#XXXX_Q1L/R_Q2L/R_MOVED
J10_RADIAL->AXIAL
PC#6621_ALL_MPSA93->MPSA92
PC#6722_TACK-ON_4K7_E->B
Q8R/L,Q13L/R,R66,R67-L/R
PC#6878 REDO SOLDERMASK
N
N
N
N
N
N
N
N
N
3.40
.
.
4.00
.
.
5.00
5.10
5.20
.
6.00
V
V
V
V
V
V
V
V
V
FEB/24/95
.
.
AUG/27/97
.
SEP/05/97
MAR/25/98
SEP/08/03
AUG/26/04
.
JUN/16/05
D
D
D
D
D
D
D
D
D
GUIDE
ETCH
GUIDE
ETCH
J14
MC1_A
FUNCTION
DOWN
BAR
D30R
MUR415
R63R
0.5WATT
2R2
R2R
220K
C19R
27p
R42R
10K
C31R
470P
R64R
680R
C32L
470P
D20L
4148
#3638
FROM_M1055
PART#
R64L
680R
D21L
BAV21
C9R
100P
C34R
22u 50V
D29R
4004
D31L
4004
R16R200R
R54L
274R
R4L 274R
R39R
22R1
R8L
31K6 R8R 31K6 R1R
681R
1
FUNCTION
RTV
9POS.RT.ANGLE_MOLEX
VMID-
RREF
OUTPUT_A
RSIG
VH+ VH+
VH+
VH+ VH+
LCLIP
GND
GND
GND
GND
GND
GND
GND
VMID+
VMID+
LSIG
LREF
RCLIP
POUTR
VH-
VH-
POUT
OUTPUT_B
ASSEMBLY M508-6.00
BLANK SIZE=17.35"X8.625"
PCB MECH M508-6.00
VER. 6.00M508
BOARD ASSEMBLY
R66R/L R67R/L TO BE TACKED ON IN
INSERTEDQ9R Q9L TO BE HAND
8
8
BOARD ASSEMBLY
Q1L/Q1R, Q2L/Q2R
AUTO-INSERTION
THE SAME BATCH (MANUFACTURERS LOT # )
THE ABOVE TRANSISTORS MUST BE FROM
BEND THERMISTORS R23L/R OVER FLAT TO PCB.
7.
C7L/R,C26L/R.
BEFORE IT IS PUT INTO THE STRAIN RELIEF
.
ADD RTV UNDER THE MOLEX RIBBON CABLE
6.
C34L/R, C5L/R, C1L/R, C2L/R, L1L/R
RTV'D IN PLACE
LD1L/R ARE BENT OVER FLAT TO PCB AND
5.
4.
3.
USE #8799 SCREW TO MOUNT Q17L/R.
SOLDER.
ADD TOOTH PICKS TO EYELETS BEFORE WAVE
TIES.
AND HELD IN POSITION WITH NYLON CABLE
CORRECT POSITION. THESE CAPS ARE RTV'D
SOLDER AND SOLDERED MANUALLY TO THEIR
C26 AND C27 ARE BROKEN AWAY AFTER WAVE
2.
ADD RTV BETWEEN C23L/R , C24L/R AND
R45L/R, R46L/R, C6L/R, C8L/R, C25L/R
ADD RTV TO THE FOLLOWING COMPONENTS
1.
1.
PRODUCTION NOTES
0.125" UP 0.125" UP
MOUNT R48 MOUNT R48
LS700P
M508A /LS700P/PS218/PS210P
NO CLIP#3491 CLIP
ES700P
PS210P
PS210P
33" BLACK
33" RED
#3491 CLIP
#3491 CLIP
#3491 CLIP
9 1/2" RED
PS218P
PS218P
27" BLACK
27" RED
250 CLIP 250 CLIP250 CLIP
30" RED
9" GREEN 9" GREEN
12" RED
12" BLACK
RTV RTV
RTV
RTV
RTV
RTV
#3491 CLIP
NO CLIP
THIS JUMPER FOR
P:\508VR.PRN

10KR75
T12A/250V
5A-SB/250V
F5
10KR74
T12A/250V
T12A/250V
230/245VAC
50Hz
#1287E
T12A/250V
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
JUL/14/99
JAN/25/99
SEP/15/98
.
AUG/06/98
JUN/27/97
APR/03/96
.
SEP/12/95
AUG/24/95
2.70
2.50
2.40
.
2.30
2.20
2.10
2.80
2.60 R70_1/2W->1/4W_TO_AGREE_WITH_LAYOUT
CE_XFMR_WIRE_COLOURS_UPDATED
RELACE_FUSE_SYMBOL
NA_8A-SB->5A-SB
PC#5785_PRIMARY_FUSE_CE_T5A->T2,5A_
CORRECTIONS_CLARIFICATIONS
.
.
.
.
LS700P
M518.SCH_DATABASE_HISTORY
OUT
IN
SW1
1 2 3
2K74
R13
OUT
IN
SW1
4 5 6
82K5
R10
16V10u
C27
CSA
4n7
12A-SB/250V
F1
SW3
PCB#:YORKVILLE NAME:
MODELS: SCH ISSUE:
TITLE:
DATE:
M518
POWERED_SUB-WOOFER
LS700P
M518V29.SCH
APR/04/2003
EPW_PWR_SUPPLY
2.90
CSA
22n
"P24"
STYLE "P14"
STYLE
0.1R
5W
R63
10K
R73
33K
R20
1/2
TLO72
U1
6
5
7
13A/205C
CW
VOLUME
10K
LINP1
4K7
R17
#7269
10"
4R
82K5
R9
2K74
R16
37K90
R15
37K90
R14
1K
R62
D12
82K5
R8
82K5
R7
SRT
IN
RIGHT
JB3 1
2
3
4
5
6
SRT
OUT
LEFT
JB2 1
2
3
4
5
6
1/2
TLO72
U1
2
3
1
D13
100n
C42
100n
C43
#1287
120VAC
60Hz
680R
R19
100n
C44
POWER_ON
GREEN
LD1
4u7
35v
C5
4M7
R2
D3
12A-SB/250V
F2
WC8
1
1N4004 D1
TB9
10u
50V
C8
10u
50V
C7
IN
REF
OUT
7815Q1
1
2
3
IN
REF
OUT
7915Q2
2
1
3
20v
500mW
D4
100n
C41
100n
C34
100n
C35
1K
R18
OUT
IN
SW2
4 5 6
12A-SB/250V
F4
13AMP
DB1
3
4
1
2
13AMP
DB2
3
4
1
25600u
100V
C4
4700u
50v
C1
4700u
50v
C2
5600u
100V
C3
TB6
T3,15A/250V
100n
C36
WC3
1
TB4
CSA
4n7
C30
WC4
1
1N4004 D2
CSA
22n
C29
1N4004
D6
1N4004
D5 100n
C33
WC6
1
100K
R1
3K3
R3
1K8
R70
4u7
35v
C6
TB7
TB1
WC9
1
TB5
TB3
15K
0.5W
R4
TB2
OUT
IN
GND/LIFT
SW2
1 2 3
22n
275V
C49
100n
C37
MX1
1
2
3
4
5
6
7
8
9
47K
R68
100n
C48
SRT
OUT
RIGHT
JB4 1
2
3
4
5
6
SRT
LEFT
IN
JB1 1
2
3
4
5
6
REF
IN
OUT
7915
IN
REF OUT
7815
10K
R61
CW
20K
AP2
10K
R59
CW
20K
B
P2
0.1R
5W
R64
100n
C39
13A/205C
BR1
82K50
R11
220p
C9
220p
C10
82K50
R12
TB8
100n
C40
100n
C46
12A-SB/250V
F3
BC BC
V-
V+
TLO71
U9
2
3
158
6
4
7
15K
0.5W
R5
15K
0.5W
R6
O
T
115R
RV1
11
O
T
115R
RV2
11
100u
16V
C28
BC550C
CBE
BC560C
100n
C45
1/2
TLO72
U3
6
5
7
220R
R24
100K
R23
10n
C12
47n
C14
33K
R22
33K
R21
150n
C11
1/2
TLO72
U3
2
3
1
33K
R26
100u
16V
C13
47n
C15
20K
R28
1/2
TLO72
U4
2
3
1
220K
R27
100K
R29
1/2
TLO72
U4
6
5
7
47K
R72
150K
R36
100n
C32
1/2
TLO72
U5
2
3
1
33K
R35
47n
C18
47n
C17
68K
R39
150K
R38
1/2
TLO72
U5
6
5
7
33K
R37
47n
C20
47n
C19
D14
10K
R40
1/2
TLO72
U7
2
3
1
100K
R41
47n
C21
47n
C22
1/2
TLO72
U8
2
3
1
4K7
R43
4K7
R44
10K
R45
33n
C23
1/2
TLO72
U8
6
5
7
1/2
TLO72
U7
6
5
7
20K
R47
150n
C24
20K
R46
10K
R48
10u16V
C31
10K
R65
100K
R66
D11
33K
R67
1/2
TLO72
U6
2
3
1
10K
R50
10K
R51
D7
D8 10K
R52
20K
R49
1/2
TLO72
U6
6
5
7
IN753ARL
6V2
D9
D10
47K
R53
10K
R55
BC550
Q4
BC560
Q6
TB11
10K
R56
BC560
Q5
22u
16V
C25
1K
R58
22u
16V
C26 10K
R60
BC550
Q3
220K
R69
#7269
10"
4R
BC560
Q7
PIN 11
D
IABC
1/2
LM13600
U2
13
15
14
16
12 910
47K
R71
1K
R54
TB10
33K
R32
220R
R31
33K
R33
33K
R34
PIN 11
D
IABC
1/2
LM13600
U2
4
2
3
1
587
33R
R57
100u
16V
C16
FET_CTRL
FET_CTRL
VH-
CHASSIS
WHITE
VM-
VM-
VH+
GND
GND
GND
GND
GND
GND GND
GND
GND
GND
GND GND
GND GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
VM+
VM+
A
A
V-
V-
V-
+15V
V+
V+
V+
V+
V+
V+
REPLACE WITH BUSSMAN GDC TYPE FUSE ONLY YS PT#2475
245V
230V
BRN/BLK
BRN
BLUE
REPLACE WITH SAME TYPE FUSE REPLACE WITH SAME TYPE FUSE
REPLACE WITH SAME TYPE FUSE
GREY
GREY
YELL
GREY
YELL
GREY
LS700P
GRN
RED
RED
BLACK
BLACK
RIGHT
LEFT
PC#5079 R18 2K74 TO 1K
WITH PIN 3 OF U9. R65 1K TO 10K
PC#4886 REPLACE R25,R30 WITH JUMPER ADD 47K (R71,R72 IN SERIES
PC#4871 R45 4K7 TO 10K R11,R12 9K760 TO 82K50
GRN/YEL
RED
RED
OUTPUT
OUTPUT
M508
HIGH FREQUENCY CUT OFF
A.C VOLTAGES MEASURED WITH 1V 80HZ SPEAKER/LINE @ SPEAKER POSITION
71mVAC
71mVAC
71mVAC
71mVAC
+73VDC
-73VDC
+31VDC
-31VDC
+15VDC
-15VDC
-14VDC
-18V
BLACK
CONNECTOR MC1
HIGH CURRENT TO M508
TO M508 MC2 CONNECTOR
RED
RED
SPEAKER/LINE
SPEAKER/LINE
TURN ON/OFF FET CTRL
NEG_IN_L
POS_IN_L
CLIP_L
GND
GND
CLIP_R
POS_IN_R
NEG_IN_R
IS OFF-PCB
IS OFF-PCB
IS OFF-PCB
ENCLOSED CIRCUITRY
ENCLOSED CIRCUITRY
ENCLOSED CIRCUITRY
GREEN
POWER SUPPLY
BLUE
WHITE
BLACK
YELLOW
RED
ALL UNMARKED DIODES ARE 1N4148.
BLK
BLK
120 VAC 60 Hz LINE
-
-
+
+

VCD
.020"
.012"
.008"
.005"
S0LDERSIDE M518-11.00
10.00
M518
BLANK SIZE=12.250" X 10.800"
PCB MECH M518-10.00
V
T
R
C16 16V
100u
R63 5W
0R1
R57 33R
U2
LM13600
Q3
BC550
V
T
R
R59
10K
R20
33k
D10
4148
JB3
LINE_IN
U6
TLO72
D2
4004
Q1
+15V 7815
Q2
-15V 7915
C4
#5889
100V
5600u
C1
#5859
50V
4700u
TB5
250TAB
C-TAP
C30
4n7
250V
R4
0.5W
15K
C31
16V
10u
C24
150n
C28
16V
100u C26
16V 22u
_WC6
BLK
C25
16V 22u
SW1
SPKR./LINE
#3436
R9
82K5
C13 16V
100u
R34 33K
R33
33K
R31
220R
D14
4148
R71
47K
R68
47K
R69
220K
R15
37K90
RV1 115R
P2
STYLE-P24
1B
20K/20K
HIGH-FREQUENCY
#4389
R60
10K
R33K3
R56
10K
R58
1K
R53
47K
R4920K
RV2 115R
R51
10K
R54
1K
R67
33K
R174K7
R8
82K5 R162K74
R65
10K
M508_AMP(L)_GND
TO_M508_GND"L"
R48
10K
R29
100K
R46
20K
R181K
R1
100K
TB9
TO-SPKR(-)
TO-SPEAKER(-)
J29
R6
0.5W
15K
R47
20K
R43
4K7
C5
63V
4u7
C8
50V
10u
C7
50V
10u
C6
63V
4u7
R45
10K
R64
5W
0R1
D3
4148
CHAS.GND
CHASSIS
J13
R41
100K
J18
D13
4148
"P24"
STYLE
R38
150K
R52
10K
R39
68K
R66
100K
D12
4148
R27
220K
R28 20K
-
+
LD1
R12
82K50
R73
10K
U1
TLO72
R21
33K
JB2
LINE_OUT
JB4
LINE_OUT
JB1
LINE_IN
R14
37K90
V
T
R
WC3
F
CSA-12A-SB/125V
CE-T12A/230V
WC9
BLUE
R22
33K
R23100K
C46 100n
D6
4004
D5
4004
C3
#5889
100V
5600u
C2
#5859
50V
4700u
TB3
SEC.
FUNCTION
TB6
SEC.
FUNCTION
TB11
NEUTRAL
AC_WHT
TB4
SEC.
FUNCTION
TB7
SEC.
FUNCTION
TB10
HOT
AC_BLK
C29
22n
400V
R72
47K
J31
J20
WC6
BLACK
D8
4148
_WC3
RED
R61 10K
KNOBPART#FUNCTIONREF
MODEL(S):- AS_OF
F
F
F
F
HIGH_FREQ
VOLUME
P
P
P
P
#4389
#4403
N
N
N
N
DEC/99
DEC/99
K
K
K
K
#8693
#8693
R
R
R
R
P2
P1
EPW/LS700P
M518.PCB_POT_LIST
R62 1K
Q5 BC560
R19680R
TB2
NEUTRAL
AC_WHT
F2
TYPE #3414FUNCTION
F1
TYPE #3414FUNCTION
F4
TYPE #3414FUNCTION
Q6
BC560
Q4
BC550
Q7
BC560
D9
6V2
D7
4148
D114148
U9
TLO71
U7
TLO72
V+
FUNCTION
U8
TLO72
U5
TLO72
U4
TLO72
D4
20V
WC8
WHITE
TB1
HOT
AC_BLK
U3
TLO72
J16
C27
10u
16V
J27
C23 33n
CHASSIS
J11
C2247n
SW2
GND_LIFT
#3436
J9
J21 J25
C21
47n
C19 47n
J22
C20
47n
J23
C17
47n
LEADS UP
DB1
KBPC__-W
C18
47n
C32100n
LEADS UP
DB2
KBPC__-W
C15
47n
MX1
C11
150n
AC
FUNCTION
V-
FUNCTION
AC
FUNCTION
C1447n
J14
D1
4004
_WC8
WHT
R13
2K74
MC1
8POS.RT.ANGLE_MOLEX
#3521
TO_M508_MC1
_WC4
YEL
WC4
YELLOW
CSA-12A-SB/125V
CE-T12A/230V
C12 10n
C45
100n
C44100n
R5
0.5W
15K
C47
100n
C9
220p
C10
220p
R7
82K5
R10
82K5
C40
100n
R11 82K50
J32
R40 10K
C39
100n
C38
100n
J33
C37
100n
C33
100n
C36
100n
C35
100n
C34 100n
C41
100n
C43100n
V
T
R
J10
J12
R5510K
P1
10K/LIN
STYLE-P14
VOLUME
#4403
V
T
R
_WC9 BLUE
C42
100n
J24
R44
4K7
V
T
R
V
T
R
V
T
R
RTV
J19
RTV RTV
C48100n
J17
J15
R24
220R
J28
J26
CSA-12A-SB/125V
CE-T12A/230V
R32
33K
R37
33K
R50
10K
GUIDE
ETCH
"P14"
STYLE
J30
R70
1K8
R26
33K
R35
33K
R36
150K
MOLEX
9_PIN
CSA-12A-SB/125V
CE-T12A/230V
J34
R2 4M7
CHASSIS
C49 22N
400V
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
# DESCRIPTION OF CHANGEVER#DATE
MODEL(S):-
PC#6905 ADD ROUTGAUGE REDO MASK11.00JUN/16/0521
M518.PCB_DATABASE_HISTORY
LS700P
DESIGN_BY_TOM_WOOD
PC#4871_R45_4K7-->10K__R11,R12_
9K760-->82K50_0.1%
PC#4877_MOVE_RTV_HOLES_FOR_C1
PC#4885/4886_REPLACE_R25,30_WITH
JUMPERS_ADD_10K_IN_SERIES_WITH
PIN_3_U9_ADD_47K_IN_SERIES_WITH
PIN_5,12_U2_R65_1K->10K__R66 10K->100K
C27 MOVED FOR CLEARANCE AT MOLEX
PC#5079 R18 2K74 -> 1K
PC#5303 C7 MOVED.ROUTING AT JACKS CHGD
PC#6130_MOVE R3 AWAY FROM R2
PC#6109 REDO GND LIFT SW. ADD C49
ADD EYELET. CHANGE PADS FOR RAD JUMPR
NEW PADS FOR TABS AND FUSEHOLDERS
PC#6413 FIX TRACES AT U5
ADD ROUTING NO OTHER CHANGES
PC#6573 TABS FOR BRIDGE
PC6596_ADD R74, R75
MOVE FUSEHOLDER AWAY FROM TRACE
1.00
1.10
.
1.20
2.00
.
.
.
2.10
2.11
3.00
4.00
.
5.00
6.00
7.00
7.10
8.00
9.00
10.00
AUG/21/95
AUG/24/95
.
SEP/01/95
SEP/12/95
.
.
.
SEP/25/95
APR/3/96
MAY/20/97
OCT/06/99
.
DEC/02/99
APR/18/02
JUL/16/02
OCT/23/02
NOV/14/02
APR/04/03
SEP/02/03
AC
FUNCTION
V+
FUNCTION
AC
FUNCTION
V-
FUNCTION
R7510K
F3
TYPE #3414FUNCTION
R74
10K
L&R_AMPFET_CTRL
LS700P
V:11.00
GRN
CSA-12A-SB/125V
CE-T12A/230V
CSA-12A-SB/125V
CE-T12A/230V
CE-T12A/230V
CSA-12A-SB/125V
CSA-12A-SB/125V
CE-T12A/230V
YEL
BLK
M518
BLK
BLK
BLK
WHT
RED
RED
BLU
BLK
WHT
RED
YEL
GND
GND
VH-
VH-
VH+
VH+
VM-
VM-
VM+
VM+
10" GREEN
ASSEMBLY M518-11.00
LOCK
MOLEX FOR MX1
NOTE ORIENTATION OF LOCK ON THE
1
PRODUCTION NOTES
BLANK SIZE=12.250" X 10.800"
GRN
TO M508 INPUT...9POS_3538
PCB MECH M518-11.00
P:\518CMP.PRN

M508
Y E LWH T B L K
B L U
R E D
TAB 10 TAB 1
J 8
T B5
C -T AP
C 30
4n7
250V
M508_AMP( L)_G N D
TO _M508_G N D"L "
T B9
T O -S P KR (- )
TO -S P EA K ER (-)
C H A S .G N D
C H A S S IS
WC 3
F
WC9
J 6
T B 3
S E C .
T B6
S EC .
T B11
NE U T R AL
AC _W H T
T B 4
S E C .
T B7
S E C .
T B10
HO T AC _B L K
C 29
22n 400V
WC 6
B LA C K
T B2
NE U T R AL
AC _W H T
F 3
J 5
W C 8
W HITE
T B 1
HO T
AC _B L K
K B P C __- W
WC 4
Y E L LO W
R 5
Y E L
B LK
B LK
B LK
B LK
B LK
WHT
R E D
R E D
B LK
WH T
R ED
Y EL
G N D
V H +
V M-
V M+
B LU
V H -
B LU E
LS 700P AC WIRE S E X P ORTVERSION
NO V 2005
4" B L AC K
6" B LAC K
20" B L AC K
19 " W H IT E
4" W HIT E
7" GR E E N
O N E 4-P L U G W H & R E D F O R 240
O N E 2-P L UG W H 7 B L F O R 220
P UT 3487 C LIP O N U NUS E D P IN
P UT C E L OG O ON LY O N 220 +C E S E R #
NO C E O N 240 US E E 4 S E R #
WHT
B L UE
G R E Y
G R E Y
R E D
R E D
S HOWN WIR E D F OR 230V
B R N /B L K
B R N

M508
YELWH T BLK
BLU
RED
TAB10 TAB1
J8
TB5 C-TAP
C30
4n7
250V
M508_AMP(L)_GND
TO_M508_GND"L"
TB9
TO-SPKR(-)
TO-SPEAKER(-)
CHAS.GND
CHASSIS
WC3
F
WC9
J6
TB3
SEC.
TB6
SEC.
TB11
NEUTRAL
AC_W HT
TB4
SEC.
TB7
SEC.
TB10
HOT AC_BLK
C29
22n 400V
WC6
BLACK
TB2
NEUTRAL
AC_W HT
F3
J5
WC8
WHITE
TB1
HOT
AC_BLK
KBPC__-W
WC4
YELLOW
R5
YEL
BLK
BLK
BLK
BLK
BLK
WHT
RED
RED
BLK
WHT
RED
YEL
GND
VH+
VM- VM+
BLU
VH-
BLUE
LS700P AC WIRES EXPORTVERSION
APR 22, 2003
4" BLACK
6" BLACK
20" BLACK
19" WHITE
4" WHITE
7" GREEN
ON E4-PLUG WH & RED FOR 240
ON E2-PLUG WH 7 BL FOR 220
PUT 3487 CLIP ON UNUSED PIN
PUT CE LOGO ONLY ON 220 +CE SER#
NO CE ON 240 USE E4 SER#
WHT
BLUE
GREY
GREY
RED
RED
SHOWN WIRED FOR 245V
1287E
BROWN
BROWN/BLK
