YUGE CLP500 User manual

Product Name
CLP500 4G Routing Equipment User Manual
Number of Pages
27
Produce Version
V1.1
Date
2020/7/15
CLP500 4G Routing
Equipment User Manual
V1.1
Shanghai Yuge Information Technology Co., Ltd.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 2 -
Revise history
Version
Date
Author
Description
V1.0
2020/6/11
Document Group
Initial
V1.1
2020/7/15
Document Group
Synchronization software V2.3
Synchronous hardware V1.1
Add remote diagnosis function (only
applicable to Qualcomm platform module)

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 3 -
Content
Chapter 1. Overview...............................................................................................................- 4 -
Chapter 2. WEBUI management system................................................................................- 6 -
2.1 Login........................................................................................................................ - 6 -
2.2 Home........................................................................................................................ - 7 -
2.3 Internet......................................................................................................................- 9 -
2.3.1 WAN...................................................................................................... - 9 -
2.3.2 LAN.......................................................................................................- 9 -
2.3.3 Mobile Net...........................................................................................- 10 -
2.3.4 Wi-Fi....................................................................................................- 11 -
2.3.5 Client................................................................................................... - 12 -
2.4 Firewall...................................................................................................................- 13 -
2.4.1 WIFI MAC filter..................................................................................- 13 -
2.4.2 Port Forward........................................................................................- 13 -
2.4.3 DMZ.................................................................................................... - 14 -
2.5 App......................................................................................................................... - 15 -
2.5.1 PING Net............................................................................................. - 15 -
2.5.2 Serial App............................................................................................ - 16 -
2.5.3 Auto Reboot.........................................................................................- 17 -
2.6 Admin..................................................................................................................... - 18 -
2.6.1 User Management................................................................................- 18 -
2.6.2 Time.....................................................................................................- 19 -
2.6.3 Telnet Service...................................................................................... - 19 -
2.6.4 Remote Diag........................................................................................- 20 -
2.6.5 Upgrade Management......................................................................... - 22 -
2.6.6 Reboot................................................................................................. - 26 -

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 4 -
Chapter 1. Overview
CLP500 is a 4G routing terminal device that can be freely equipped with Qualcomm
MDM9x07 and ASR platform 4G wireless communication module. Support three network
ports, support dual WIFI antenna, support serial port transparent transmission function.
The WAN network port can be configured as a LAN port or a WAN port. By default, the IP
address is automatically assigned. After the network cable is inserted, the PC can use this
device to bring 4G network functions.
The device provides Wi-Fi AP function. The default name of the Wi-Fi SSID is the last four
digits of the 4G_AP_MAC address, and the default password is 12345678.
The default address of the device is 192.168.1.1, log in to the http://192.168.1.1 WEBUI
management page, you can make various settings, and the login account is admin:admin.
The following is the equipment diagram：
Note:
1) The DC power supply voltage range is 6V to 25V, it is recommended to use the matching
power adapter.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 5 -
2) Supports LTE network indicator, flashes when there is no card or registration, and always
lights up during normal registration.
3) Support WAN and LAN network port indicator and WiFi indicator.
4) WAN port can be configured as WAN or LAN function on the page.
5) Supports factory reset button.
6) Please clear the browsing history of the browser before using the WEBUI management
function.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 6 -
Chapter 2. WEBUI management system
The device's default settings can work, or you can modify the default settings through the
WEBUI management page. WEBUI management page supports Internet Explorer 11 and
higher, Firefox, Chrome, Safari and other mainstream browsers.
2.1 Login
Open the browser, enter the address 192.168.1.1 and press Enter, the browser will display the
login interface of the web management system, enter the user name admin, password admin,
and click login to enter the management system.
Note:
1) If you enter the wrong username/password three times in a row, the login function will be
locked. During the lock, you will not be able to log in to the web management system.
You can only try to enter the password again after the lock time has passed.
2) The default username/password is very simple. For security reasons, users should change
to a more secure username/password after logging in to the system. For how to modify
the user name/password, please refer to the “Admin” chapter.
3) If you have forgotten your password, you can click on the forgotten password to proceed
to the next step according to the prompts.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 7 -
2.2 Home
This page displays the current network mode, connection status, IP address, LAN related
information, WIFI related information, device IMEI and SIM card related information and
device information (such as system time, boot time, device version number, etc.). Display
current network status and related information (such as connected network type, signal
strength value, etc.).

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 8 -
Note:
If there is no problem of registering the network or being unable to access the Internet, you
can check whether the connection status has been successfully connected. The device time on
this page shows that the network time cannot be synchronized. If you want to synchronize the
network time, you can modify the settings by referring to "Time " on the "Admin " page.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 9 -
2.3 Internet
2.3.1 WAN
Select the network mode is to choose the way to go online.
4G mode: You need to insert a SIM card to go online.
DHCP mode: You can not insert a SIM card, but you need to insert the interface labeled
WAN into other routers or switches to automatically obtain an IP address for Internet access.
STATIC: Compared to the "DHCP" method, you also need to manually configure Internet
access information such as IP addresses.
The network mode needs to be reconnected after changing.
2.3.2 LAN
Configure the device IP address and device name, and configure the DHCP service
parameters. After modifying the settings, you need to reconnect to the network.
If you do not know what DNS to use, you can configure only the primary DNS as the device
IP address, leave the standby DNS blank, and enable the DNS proxy function.
Static IP address assignment function can assign fixed IP to the specified MAC address. Up to
3 designated MAC addresses can be assigned fixed IP.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 10 -
2.3.3 Mobile Net
This setting modifies 4G related parameters, such as modifying the network mode (LTE only,
GSM only, etc.). After setting to automatic mode, the device will automatically search for the
best network according to the SIM card, for example, the LTE network is searched first, the
WCDMA or EVDO network is searched second, and the GSM or CDMA 1x network is
searched last. It is recommended to keep this setting.
APN setting function, the device presets most operator APN related settings, APN is set to
automatically select the mode to automatically match. If the SIM card is special, it may not be
automatically matched. In this case, you can manually set the APN. If the APN is set

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 11 -
according to the requirements of the SIM card operator and you still cannot access the
network, you can try to modify the authentication type. The three authentication types are
different, and you can try them all.
Note: If equipped with CLM920_AC3 module, the network standard only supports LTE and
WCDMA.
2.3.4 Wi-Fi
This page can enable and disable WIFI. This setting can modify the Wi-Fi AP SSID,
transmission channel, bandwidth, transmit power, encryption method and password. After
ticking the √in front of the broadcast SSID, other devices will not be able to search for this
Wi-Fi AP.
After WPS is enabled, you can use the WPS function for WIFI connection.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 12 -
2.3.5 Client
The device functions as a router. Wi-Fi AP and Ethernet are a local area network. This page
displays the related settings of the local area network and the LAN client list..

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 13 -
2.4 Firewall
2.4.1 WIFI MAC filter
Accept list: Only MAC addresses added to the whitelist can access the network.
Deny list: Only MAC addresses added to the blacklist cannot access the network.
Before setting to accept list mode, add yourself to the accept list, otherwise you will be
disconnected and can no longer connect to the device. After adding or deleting the mac
address, remember to click the save button to take effect.
2.4.2 Port Forward
Port forward function, if the data packet sent from the external network to the router is
forwarded to the host on the internal network if it is within the set port or port range. Use this
function to allow intranet hosts to provide network services.
Ordinary SIM cannot use the port forwarding function due to operator restrictions. Some
special network cards and IoT cards can use this function. After adding or deleting, you need
to click the save button to take effect.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 14 -
2.4.3 DMZ
DMZ is used to map the host address of the router's internal network to the external network,
so that the internal network's host can provide network services. After setting up the DMZ
host, the external network's access to the router's IP address will be forwarded to the
corresponding DMZ host.
Ordinary SIM cannot use the DMZ function due to operator restrictions. Some special
network cards and IoT cards can use the DMZ function. Selecting the "80 port" button means
that port 80 is not forwarded. Uncheck the "80 port" button, then forward all ports.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 15 -
2.5 App
2.5.1 PING Net
The PING function is a function to increase the stability of the mobile data connection.
Sending PING packets will consume mobile data traffic.
The PING function detects that PING data packets are sent at a set time interval. If no data
packets are received within the timeout period, the data packets are sent a set number of times
in succession. If both times out, the device is restarted.
After setting, you need to restart the device.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 16 -
2.5.2 Serial App
Serial port transparent transmission is to transmit the frame-by-frame data received by the
serial port to the server, and forward the data on the server to the serial port device.
This page can change the serial port transparent transmission setting, and can also modify this
setting by receiving commands through the serial port. However, if the serial port transparent
transmission function is disabled, you cannot continue to receive AT commands to modify the
settings. If you do not need to connect to the server, you can set the server address to empty.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 17 -
2.5.3 Auto Reboot
To maintain device stability, you can set the device to automatically restart. The mode every
few hours means that the device will restart after a few hours from the start. Daily fixed time
mode, which means that the device will restart at a set time every day, this mode requires
clock synchronization to be turned on.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 18 -
2.6 Admin
2.6.1 User Management
Modify login account and password.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 19 -
2.6.2 Time
You can set the time zone and whether to enable the function of synchronizing to the network
time. After setting, you need to restart the device. Disabled by default.
2.6.3 Telnet Service
After enabling, the device can be connected through Telnet tool.

CLP500 4G Routing Equipment User Manual
Shanghai Yuge Information Technology co., LTD
- 20 -
2.6.4 Remote Diag
QXDM can grab log after filling in the correct IP address with the NC3 module.
